AXIS PS12
Outdoor Power Supply
Installation Guide
AXIS PS12 Outdoor Power Supply
Connect the AXIS PS12 Outdoor Power Supply
This guide provides instructions for connecting and preparing the AXIS PS12 Outdoor
Power Supply for use. This product is designed for use with Axis products which have a
power-in terminal connector. The AXIS 225FD is one example.
Primary Cable Secondary Cable
Important!
• Read through the instructions before starting the installation.
• All electrical connections and adjustments should be made by an authorized
electrician.
• Please observe relevant national and local regulations for the installation.
AXIS PS12 Outdoor Power Supply
Extend the length of the secondary side cable
The power supply is delivered with a 5-meter cable on both the primary and secondary
sides, (see the illustration). The primary cable must be fitted with the appropriate
country-specific plug.
Cables may be shortened or lengthened to fit the application. If the secondary cable needs
to be more than 5 meters (the original cable length) or if more than one product is to be
connected, follow these recommended instructions:
Cut the secondary cable to a maximum length of 25cm. This length will minimize the
voltage drop in the shared part of the cable.
Split the secondary cable and connect it to the cable(s) that will run to your unit(s) - one
cable for each connected product.
• Use an appropriate splitter/connec-
Splitter/Connector
tor (not included).
• You may need to substitute the power
Extended cable
cable which was supplied with your
Axis product with a new cable of
minimum 18AWG (not included).
• Place the splitter device in a protec-
AXIS PS 12
Max 25cm
Extended cable
Extended cable
tive, weather-tight conduit.
Important!
• The total maximum current consumption for all connected products must not exceed the PS12 maximum
output current limit (4.5A).
• Use cables and conduits suitable for the installation and that are in compliance with the IP67 rating.
• Note that if your installation is to be vandal resistant, you will also need to make sure all cable conduits are
vandal resistant.
Unit 1
Unit 2
Unit 3
AXIS PS12 Outdoor Power Supply
Calculate the maximum extended cable length
Use the formula below to calculate the maximum extended cable length (Lmax in meters)
for each connected device. The formula uses the cable resistance of 18AWG (same cable
dimension as the secondary cable). It is recommended that you use this cable dimension or
thicker.
L
max
is the minimum specified input voltage to the product
U
min
is the maximum input current to the product
I
max
is the maximum power to the product
P
max
13 U
–()I
min
max
0 045.×()⁄=
Notes:
I
maxPmaxUmin
• The 18 AWG Cable resistance is approximately 0.045 ohms per meter.
⁄=
• You may need to substitute the power cable which was supplied with your Axis product
with a new cable of minimum 18AWG (not included). Only do this if the camera you
are attaching has a power-in terminal connector.
Connect to the AXIS 225FD when using the Built-in Heater
To prepare the AXIS PS12 Outdoor Power Supply in conjunction with the AXIS 225FD
when you are using the built-in heater, please follow these instructions. A maximum of
three AXIS 225FD cameras can be connected to the PS12. The AXIS 225FD power
consumption with active heaters is 16.5W at 12VDC.
1. Cut the PS12 secondary cable to a maximum length of 25cm.
2. Connect one extended cable for each connected AXIS 225FD, see Calculate the
maximum extended cable length. Be sure to use cable dimension 18AWG or thicker.
AXIS 225FD Maximum length ( )
version xxxx-xxx-02 30m
version xxxx-xxx-01 20m
L
max
AXIS PS12 Outdoor Power Supply
Use an appropriate splitter/connector
that will accommodate the number of
units you plan to use with the
AXIS PS12 Power Supply
Caution!
All electrical connections and adjustments should be made by an authorized electrician.
Power Connector Specifications
Name Type Specification
in Input Voltage 100-240VAC 50/60Hz
U
out Output Voltage 13VDC (no load)
U
I
out Output Current *Max 4.5A
Temperature Ambient -30 to +70 C
IP class Class IP67
Secondary cable On power supply 18AWG
°°
*With no extended cable, which gives approximately 12VDC at 4.5A out
More information
For information on the setup and configuration of your Axis camera, please refer to the
installation guide and User’s Manual for your Axis product, available from the Axis Web
site at http://www.axis.com or from the Axis Network Video Product CD.
AXIS PS12 Outdoor Power Supply v2.0 November 2007
Copyright © Axis Communications AB, 2007 Part No. 29895
