Axis P1343 User Manual

USER MANUAL

AXIS P1343 Network Camera

About this document

This manual is intended for administrators and users of the AXIS P1343 Network Camera, and is applicable to ﬁrmware 5.40 and l ater. It includes instructions for u sing and managing the product on your network. Previous experience of networking will be of use when using this product. Some knowledge of UNIX or Linux-based syste ms may also be beneﬁcial, for developing shell scripts and applications. Laterversionsofthisdocumentwill be posted to the Axis website, as required. See also the product’s online h e lp, available v ia the web-based interface.

Liability

Every care has been taken in the preparation of this manual. Please inform your local Axis ofﬁce of any inaccuracies or omissions. Axis Communications AB cannot be held responsible for any technical or typographical errors and reserves the right to make changes to the product and manuals without prior notice. Axis Communications AB makes no warranty of any kind with regard to the material contained within this document, including, but not limited to, the implied warranties of merchantability and ﬁtness for a particular purpose. Axis Communications AB shall not be liable nor responsible for incidental or consequential damages in connection with the furnishing, performance or use of this m aterial.

Intellectual Property Rights

Axis AB has intellectual property rights relating to technology embodied in the product described in this document. In particular, and without limitation, these intellectual property rights may include one or more of the patents listed at http://www.a xis.com/patent.htm and o ne or more additional patents or pending patent applications in the US and other countries.

This product contains licensed third-party software. See the menu item “About” in the product’s user interface for more information.

This product contains source code copyright Apple Computer, Inc.,underthetermsofApplePublicSourceLicense2.0(see http://www.opensource.apple.com/apsl). The source code is available from http://developer.apple.com/darwin/projects/bonjour/

Equipment Modiﬁcations

This equipment must be installed and used in strict accordance with the instructions given in the user documentation. This equipment contains no user-serviceable components. Unauthorized equipment changes o r modiﬁcations will invalidate all applicable regulatory certiﬁcations and approvals.

Trademark Acknowledgments

Apple, Boa, Bo njour, Ethernet, Internet Explorer, Linux, Microsoft, Mozilla, Real, SMPTE, QuickTime, UN IX, Windows, Windows Vista and WWW are registered trademarks of the respe ctive holders. Java and all Java-based trademarks and logos are trademarks or registered trademarks of Oracle and/or its afﬁliates. UPnP mark of the UPnP

Implementers Corporation.

is a certiﬁc

ation

Support

Should you require any technical assistance reseller. If your questio ns cannot be answered immediately, your reseller will forward your queries through the appropriate channels to ensure a rapid response. If you are connec

,pleasecontactyourAxis

tedtotheInternet,youcan:

• download user documentation and software updates

• ﬁnd answers to resolved problems in the FAQ database. Search

by product, category, or phrase

• report problems to Axis support staff by logging in to your private

support area

• chat with Axis support staff (selected countries only)

• visit Axis Support at www.axis.com/techsup/

AXIS P1343 Network Camera

Table of Contents

Hardwareoverview .......................................... 5

Connectors .................................................... 6

LEDindicators .................................................. 7

StatusLEDwhenusingFocusAssistant .............................. 8

Replacingthelens ............................................... 8

Accessingtheproduct ....................................... 9

Accessfromabrowser ........................................... 9

AccessfromtheInternet .......................................... 10

Settherootpassword ............................................ 10

TheLiveViewpage .............................................. 11

Mediastreams .............................................. 14

HowtostreamH.264 ............................................ 14

MJPEG ........................................................ 14

AXISMediaControl(AMC) ........................................ 14

Alternativemethodsofaccessingthevideostream .................... 15

Accessingaudiostreams .......................................... 16

Settinguptheproduct ....................................... 17

BasicSetup .................................................... 17

VideoandAudio ............................................ 18

VideoStream ................................................... 18

Stream Proﬁles ................................................. 19

CameraSettings ................................................ 20

ViewArea ..................................................... 21

Overlay ........................................................ 21

PrivacyMask ................................................... 22

Focus ......................................................... 22

AudioSettings .................................................. 22

AudioClips .................................................... 24

Live View Conﬁg ............................................ 25

PTZ (Pan Tilt Zoom) ......................................... 27

PresetPositions ................................................. 27

GuardTour ..................................................... 27

Advanced ...................................................... 28

Detectors .................................................. 29

CameraTampering .............................................. 29

MotionDetection ............................................... 29

Audiodetection ................................................. 31

Applications . .............................................. 32

Events .................................................... 33

ConvertEventTypestoActionRules ................................ 33

SettingUpanActionRule ........................................ 33

Recipients ..................................................... 34

Schedules ...................................................... 34

Recurrences .................................................... 34

Recordings ................................................. 36

RecordingList .................................................. 36

Continuousrecording ............................................ 36

SystemOptions ............................................. 38

Security ....................................................... 38

Date&Time .................................................... 39

Network ....................................................... 40

Storage ....................................................... 44

Ports&Devices ................................................. 45

Maintenance ................................................... 45

Support ....................................................... 46

Advanced ...................................................... 47

Resettofactorydefaultsettings ................................... 47

Troubleshooting ............................................ 49

Checking the ﬁrmware ........................................... 49

Upgrading the ﬁrmware .......................................... 49

Emergencyrecoveryprocedure ..................................... 49

AXIS P1343 Network Camera

Table of Contents

Symptoms,possiblecausesandremedialactions ...................... 50

Technical Speciﬁcations ...................................... 54

Performanceconsiderations ....................................... 56

AXIS P1343 Network Camera

Hardware overview

SD card slot

Microphone

Status LED indicator

Zoom puller

Focus puller

Audio in

Audio out

Network connector (PoE)

Power LED indicator

Network LED indicator

Control button

Iris connector

Power connector

I/O terminal

Part number (P/N) & Serial number (S/N)

connector

2 3 4

10 11

7 8

12 13 14

AXIS P1343 Network Camera

Hardware overview

Connectors

Network connector - RJ-45 Ethernet connector. Supports Power over Ethernet (PoE).

Caution

To protect the product against power surges, a shielded network cable (STP) must be used between the product and the network switch. Ensure that the network switch is properly grounded.

Audio in (pink) - 3.5 mm input for a mono microphone, or a line-in mono signal (left channel is used from a stereo signal).

Audio out (green) - 3.5 mm output for audio (line level) that can be connected to a public address (PA) system or an active speaker

with a built-in ampliﬁer. A stereo connector must be used for the audio out.

SD card slot - A standard or high-capacity SD card (not included) can be used for l ocal recording with removable storage. For instructions on how to insert and remove an SD card, please refer to the Installation Guide.

Note

Before removal, the SD card should be unmounted to prevent c orruption of recordings. To unmount the SD card, go to Setup

>SystemOptions>Storage>SDCardand click Unmount.

Control button - The control button is used for:

• Enabling the Focus Assistant. Press and very quickly release the Control button.

• ConnectingtoanAXISVideoHostingSystemservice.Seepage 41. To connect, press and hold the button for about 1 second until the Status LED ﬂashes green.

• ConnectingtoAXISInternetDynamicDNSService. Seepage 41. To connect, press and hold the button for about 3 seconds.

• Resetting the product to factory default settings. See page 47.

Power connector - 2-pin terminal block for power input.

I/O connector

Note

For technical speciﬁc

DC power input

ations, see page 54.

I/O terminal connector - Use in applications for e.g. motion detection, event triggering, time lapse recording and alarm notiﬁcations. In addition to an auxiliary power and a GND pin, the I/O terminal connector provides the interface to:

• Digital output the VAPIX® Application Programming Interface, output buttons on the Live View page or by an Action Rule. The output will show as active (shown under System Options > Ports & Devices) if the alarm device is activated.

— For connecting external devices such as relays and LEDs. Connected devices c an be activated by

AXIS P1343 Network Camera

Hardware overview

• Digital input — An alarm input for connecting devices that ca n toggle between an open and closed circuit, for example: PIRs, door/window contacts, glass break detectors, etc. When a signal is received the state changes and the input becomes active (shown under System Options > Ports & Devices).

Note

The I/O connector is connected to the housing (fan/heater) on delivery, and will trigger an input port event to indicate a fan or heater error when activated. See Events, on page 33 for information on how to set up an event.

Function Pin Notes

GND

3.3 V DC Power

Digital Input

Digital Output

Ground

Can be used to power auxiliary equipment. Note: This pin can only be used as power out.

Connect to GND to activate, or leave ﬂoating (unconnected) to deactivate.

Internal connection to ground when activated, ﬂoating (unconnected) when deactivated. If used with an inductive load, e.g. a relay, a diode must be connected in parallel with the load, for protection against voltage transients.

3.3 V max 50 mA

Speciﬁcations

Max load = 50 mA

0to+40VDC

Max load =100 mA Max voltage = +40 V DC

LED indicators

LED

Network

Status

Color

Green

Amber

Unlit No network connection.

Green Steady green for normal operation.

Amber

Red

Indication

Steady for conne

Steady for connection to a 10 MBit/s network. Flashes for network activity.

Steady during startup and when restoring settings.

Slow ﬂash for failed upgrade.

ction to a 100 MBit/s network. Flashes for network activity.

AXIS P1343 Network Camera

Hardware overview

Power

Note

Green

Amber

• The Status LED can be conﬁgured to be unlit during normal operation. To conﬁgure, go to Setup > System Options > Ports & Devices > LED. See the online help for more information.

• The Status LED can be conﬁgured to ﬂash while an event is active.

• The Status LED can be conﬁgured to ﬂash for identifying the unit. This can be done under Setup > System Options >

Maintenance.

Normal operation.

Flashes green/amber during ﬁrmware upgrade.

Status LED when using Focus Assistant

Status Color

Green

Amber The camera has been moved, or an object has been inserted in front of the lens. Exit and

Red The camera has been moved, or an object has been inserted in front of the lens. Exit and

Indication

Focus Assistant is enabled The lens is optimally adjuste d

restart the Focus Assistant. The lens is less optimally adjusted

restart the Focus Assistant. The lens is poorly adjusted

Replacing the lens

It is possible to use optional lenses for the Axis p roduct.

To replace the lens:

1. Disconnect the iris cable.

2. Unscrew the standard lens.

3. Attach and screw on the new lens.

AXIS P1343 Network Camera

Accessing the product

To install the Axis product, refer to the I ns talla tion Guide supplied with the product.

The product can be used with most operating systems and browsers. The recommended browsers are Internet Explorer with Windows, Safari with Macintosh and Firefox with other operating systems. See Technical Speciﬁcations, on page 54.

Note

• To view streaming video in Internet Explorer, allow installation of AXIS Media Control (AMC) when prompted.

• QuickTime

• If your computer restricts the use of additional software components, the product can be conﬁgured to use a Java applet for viewing Motion JPEG.

• The Axis product includes (1) H.264 decode r license for viewing video streams and (1) AAC audio license. These licenses are automatically installed with AMC. The administrator can disable the installation of the deco ders, to prevent installation of unlicensed copies.

Access from a browser

is also supported for viewing H.264 streams and for audio.

1. Start a browser (Internet Explorer, Firefox, Safari).

2. Enter the IP address or host name of the Axis product in the browser’s Location/Address ﬁeld. To access the product from a Macintosh computer (M ac OS X), click on the Bonjour tab and select the product from the drop-down list.

If you do not know the IP address, use AXIS IP Utility to locate the product on the network. For more information on how to discover and assign an IP address, refer to the Installation Guide.

3. Enter your user name and password. If this is the ﬁrst time the product is accessed, the root password must ﬁrst be conﬁgured; for instructions see Set the root password, on page 10.

4. The product’s Live View page appears in your browser.

Note

The layout of the Live View p age may have been customized to meet speciﬁcrequi examples and functions featured here may differ from those displayed in your own Live View page.

rements. Consequently, some of the

AXIS P1343 Network Camera

Accessing the product

Access from the Internet

Once connected, the Axis product is accessible on your local network (LAN). To access the product from the Internet you must conﬁgure your network router to allow incoming data trafﬁc t o the product. To do this, enable the NAT-travers al feature, which will attempt to automatically conﬁgure the router to allow access to the product. This is enabled fr

Network > TCP/IP Advanced.

For more information, please see NAT traversal (port mapping) for IPv4, on pag e 42.SeealsoAXISInternetDynamicDNSServiceat www.axiscam.net For Technical notes on this and other topics, visit the Axis Support web at www.axis.com\techsup

om Setup > System Options >

Set the root password

To gain access to the Axis product, you must set the password for the default administrator user root. This is done in the Conﬁgure Root Password dialog, w hich appears when the product is accessed for the ﬁrst time.

To prevent network eavesdropping, the root password can b e set via an encrypted HTTPS connection, which requires an HTTPS certiﬁcate. HTTPS (Hypertext Transfer Protocol over SSL) is a protocol used to encrypt trafﬁc between web browsers and servers. The HTTPS certiﬁcate ensures encrypted exchange of information.

To set the password via a standard HTTP connection, enter it directly in the ﬁrst dialog.

To set the password via an encrypted HTTPS connection, follow these steps:

1. Click Create self-signed certiﬁcate.

2. Provide the requested information and click OK.Thecertiﬁcate is created and the password can now be set securely. All trafﬁc to and from the product is encrypted from this point on.

3. Enter a password and then re-enter to conﬁrm the spelling. Click OK. The password has now been conﬁgured.

AXIS P1343 Network Camera

Accessing the product

Note

• The default administrator user name root is permanent and cannot be deleted.

• If the password for root is lost, the product must be reset to the factory default settings. See Reset to factory default settings, on page 47.

The Live V iew page

If the Axis product has been customized to meet speciﬁc requirements, not all the items described below will appear in the Live View page. The following provides an overview of each available button.

Controls on the Live View page

The Stream Proﬁle drop-down list allows you to select a customized or pre-programmed stream proﬁle. Stream proﬁles are conﬁgured under Video & Audio > Stream Proﬁles.SeeStream Proﬁles, on page 19.

Click Pulse to activate the output for a deﬁnedperiodoftime

Click the Active/Inactive buttons to manually start and stop a connected device — e.g. switch an external light on and off.

The Manual Trigger button can trigger an event directly from the Live View page. The button is conﬁgured under Live View Conﬁg > Action Buttons.

Click Snapshot to save a s napshot of the video image. Right-click the video image to save it in JPEG format on your computer. This button is primarily intended for use when the AXIS Media Control viewer toolbar is not available. Enable this button from Live View Conﬁg > Action Buttons.

, such as switching on an external light for 20 seconds.

The Audio clip drop-down list allows you to play an audio clip from the Live View page. Select the audio clip and click the Play button.

AXIS P1343 Network Camera

Accessing the product

AXIS Media Control viewer toolbar

The AXIS Media Control viewer toolbar is available in Internet Explorer only. S ee AXIS Media Control (AMC), on page 14 for more information. The toolbar displays the following buttons:

The Play button connects to the Axis product and starts playing a media stream.

The Stop button stops the media stream.

The Snapshot button takes a snapshot of the video image. The location where the image is saved can be speciﬁed in the AMC Control Panel.

Click the View Full Screen button and the video image will ﬁll the entire screen. Press ESC (Escape) on the computer keyboard to cancel full screen view.

The Record button is used to record the current video stream. The location where the recording is saved can be speciﬁed in the AMC Control Panel.

AMC Audio controls

AMC audio buttons control the speakers and microphone c onnected to the client computer. The buttons are only visible when audio is enabled.

Speaker button — Click to turn the speakers on or off.

Microphone button – Click to mute or unmute the microphone. In Simplex - Network Camera speaker only mode,

click this button to stop sending audio to the product.

Use the slider to control the volume of the speakers and the microphone.

Half-duplex mode

The Talk/Listen button is used to switch between sending and receiving audio. The button can be conﬁgured from the Audio tab in the AMC Control panel:

• Push-To-Talk mode: Click and hold the button to talk/send. Release the button to listen.

• Toggle mode: Click once to switch between talking and listening.

Simplex – Network Camera speaker only mode

To send audio, the Talk and Microphone buttons must both be enabled. Click either button to stop audio transmission.

PTZ Controls

The Live View page also displays Pan/Tilt/Zoom (PTZ) controls. The administrator can enable/disable controls for speciﬁed users under System Options > Security > Users.

Note

These controls are available if di

gital PTZ is enabled in the selected view area, see View Area, on page 21.

AXIS P1343 Network Camera

Accessing the product

Click the Emulate joystick mode button and click in the image to move the camera view in the direction of the mouse pointer.

Click the Center mode button and click in the image to center the camera view on that position.

Click the Ctrl panel button to open the PTZ c ontrol panel which provides additional PTZ controls. User-deﬁned buttons can also appear in the Control panel. See Controls, on page 28.

Pan and Tilt bars – Use the arrows to pan and tilt the camera view, or click on a position on the bar to steer the camera view to that position.

Zoom bar – Use the arrows to zoom in and out, or click on a position on the bar to zoom to that position.

The PTZ controls can be disabled under PTZ > Advanced > Controls,seeControls, on page 28.

AXIS P1343 Network Camera

Media streams

The Axis product provides several audio and video stream formats. Your requirements and the properties of your network will determine the type you use.

The Live View page in the product provides access to H.264 and Motion JPEG video streams, audio streams and to the list of available stream proﬁles. Other applications and clients can access video and audio s treams directly, without going via the Live View page.

How to s tream H.264

The video com pression standard H.264 makes good use of bandwidth, and can provide high quality video streams at less than 1 Mbit/s.

Deciding which combination of protocols and methods to use depends on your viewing requirements, and on the properties of your network. The available options in AXIS Media Control are:

Unicast RTP

RTP over RTSP

RTP over RTSP over HTTP

Multicast RTP

AXIS Media Control negotiates with the Axis product to determine the transport protocol to use. The order of priority, listed in the AMC Control Panel, can be changed and the opti

Note

H.264 is licensed technology. The Axis product includes one H.264 viewing client license. Installing additional unlicensed copies of the client is prohibited. To purchase additional licenses, contact your Axis reseller.

This unicast method (RTP over UDP) is used for live unicast video, especially when it is important to always have an up-to-date video stream, even if some images are dropped.

This unicast method (RTP tunneled over RTSP) is useful as it is relatively simple to conﬁgure ﬁrewallstoallowRTSPtrafﬁc.

This unicast method can be used to traverse ﬁrewalls. Firewalls are commonly conﬁgured to allow the HTTP protocol, thus allowing RTP to be tunneled.

This method (RTP over UDP) should be used for live multicast video. The video stream is al up-to-date, even if some images are dropped. Multicasting provides the most efﬁcient usage of bandwidth when there are large numbers of clients viewing simultaneously. A multicast cannot however, pass a network ro router is conﬁgured to allow this. It is not possible to multicast over the Internet, for example. Note also that all multicast viewers count as one unicast viewer in the maximum total of 20 simultaneous connections.

ons disabled, to suit speciﬁc requirements.

Unicasting is used for video-on-demand transmission so that there is no video trafﬁc on the network until a client connects and requests the stream. Note that there are a maximum of 20 simultaneous unicast connections.

ways

uter unless the

MJPEG

This format uses s to create a stream that shows constantly updated motion.

The Motion JPEG stream uses considerable amounts of bandwidth, but provides excellent image qualityandaccesstoeveryimage contained in the stream. The recommended method of accessing Motion JPEG live video from the Axis product is to use the AXIS

ontrol in Internet Explorer in Windows.

Media C

tandard JPEG still images for the video stream. These images are then displayedandupdatedataratesufﬁcient

AXIS Media Control (AMC)

AXIS Media Control (AMC) in I nternet Explorer in Windows is the recommended method of accessing live video from the Axis product.

AXIS P1343 Network Camera

Media streams

TheAMCControlPanelcanbeusedtoconﬁgure various video and audio settings. Please see the AXIS Media Control User’s Manual for more information.

The AMC Control Panel is automatically installed on ﬁrst use, after which it can be conﬁgured. Open the AMC Control Panel from:

• Windows Control Panel (from the Start menu)

• Alternatively, right-click the video image in Internet Explorer and click Settings.

Alternative methods of accessing the video stream

You can also access video and images from the Axis product in the fo llowing ways:

• Motion JPEG server push (if supported by the client, Firefox, for example). This option maintains an open HTTP connection to the browser and sends data as and when required, for as long as required.

• Still JPEG images in a browser.Enterthepathhttp://<ip>/axis-cgi/jpg/image.cgi

• Windows Media Player. This requires AXIS Media Control and the H.264 decoder to be installed. The following paths can be used:

-UnicastviaRTP:axrtpu://<ip>/axis-media/media.amp

- Unicast via RTSP: axrtsp://<ip>/axis-media/media.amp

- Unicast via R TSP, tunneled via HTTP: axrtsphttp://<ip>/axis-media/media.amp

-Multicast:axrtpm://<ip>/axis-media/media.amp

• QuickTime

- rtsp://<ip>/axis-media/media.amp

- rtsp://<ip>/axis-media/media.3gp

. The following paths can be used:

AXIS P1343 Network Camera

Media streams

Note

• <ip>= IP addess

• The Axis product supports QuickTime 6.5.1 and later.

• QuickTime adds latency to the video stream.

• It may be possible to use other players to view the H.264 stream using the paths above, although Axis does not guarantee this.

Accessing audio streams

The Live View page provides access to audio through AXIS Media Control; in addition audio can be accessed in the following ways:

• VAPIX® Application Programming Interface (API) For more information, visit www.axis.com/developer

• Windows Media Player supports simplex audio. The following paths can be used:

-UnicastviaRTP:axrtpu://<ip>/axis-media/media.amp

- Unicast via RTSP: axrtsp://<ip>/axis-media/media.amp

- Unicast via R TSP, tunneled via HTTP: axrtsphttp://<ip>/axis-media/media.amp

-Multicast:axrtpm://<ip>/axis-media/media.amp

• QuickTime

- rtsp://<ip>/axis-media/media.amp

- rtsp://<ip>/axis-media/media.3gp

•TheJava applet supports simplex audio with G.711 encoding.

supports G.711 and AAC audio encoding. The following paths can be used:

AXIS P1343 Network Camera

Setting up the product

The Axis product can be conﬁgured by users with administrator or operator rights. Click Setup in the top right-hand corner of theLiveViewpage.

• Administrators have unrestricted access to all settings.

• Operators have access to all settings except System Options

See also the online help

Basic Setup

Basic Setup provides shortcuts to the settings thatshouldbemadebeforeusingtheAxisproduct:

1. Users. See page 38.

2. TCP/IP. See page 40.

3. Date & Time. See page 39.

4. Video Stream. See page 18.

5. Focus. See page 22

6. Audio Settings. See page 22.

The Basic Setup menu can be disabled from System Options > Security > Users.

AXIS P1343 Network Camera

Video and Audio

The video and audio settings c a n be used to optimize video and audio quality. You can conﬁgure the following:

• Video stream settings. See page 18.

•Streamproﬁles. See page 19.

• Camera settings. See page 20.

•Viewarea.Seepage 21.

• Overlay image. See page 21.

•Privacymask.Seepage 22.

•Focus.Seepage 22.

• Audio settings. See page 22.

• Audio clips. See page 24.

Video Stream

You can deﬁne the following video stream settings from Video & Audio > Video Stream:

•Image.Seepage 19.

• H.264. See page 19.

•MJPEG.Seepage 19.

Pixel Counter

The pixel counter shows the number of pixels in an area of the image. The pixel counter is useful in situations where there is a requirement that the image is a certain size, for e xample in face recognition.

The pixel counter can be accessed from:

AXIS P1343 Network Camera

Video and Audio

• Video & Audio > Video Stream.UnderPreview, click Open and select the Show pixel counter option to enable the rectangle in the image. Use the mouse to move and resize the rectangle, or enter the number of pixels in the Width and Height ﬁelds and click Apply.

• Video & Audio > Focus.SelecttheShow pixel counter option to enable the rectangle in the image. Use the mouse to move and resize the rectangle, or enter the number of pixels in the Width and Height ﬁelds and click Apply.

• The Live View page in Internet Explorer in Windows. Right-click in the image and select Pixel counter.Usethemouse to move and resize the rectangle.


You can modify the image resolution and compression, and rotate the i mage from the Image tab (Video & Audio > Video Stream).

The image can also be mirrored from the Image tab.

Setting the c om pression level affects the image quality and bandwidth; the lower the compression, the higher the image quality with higher bandwidth requirements.

To avoid bandwi dth problems on the network, you can limit the frame rate allowed to each viewer. The maximum frame rate can be set to Unlimited, or you can limit the frame rate to a value.

An image or text can be superimposed over the image as overlay. See Overlay, on page 21.

Save your settings before they can take effect.

H.264

H.264, also known as MPEG-4 Part 10/AVC, is a video compression standard that provides high quality video streams at low bit rates. An H.264 video stream c onsists of different types of frames such as I-frames, P-frames and B-frames. An I-frame is a complete image whereas P-frames and B-frames only contain the differences from previous/future fram

The GOV length is the number of frames between two consecutive I-frames. Increa bandwidth requirements in some cases, but may also have an adverse affect on image quality.

ThebitratecanbesetasVariable Bit Rate (VBR) or Constant Bit Rate (CBR). VBR adjusts the bit rate according to the image complexity, using up more bandwidth for increased activity in the image, and less for lower image activity. CBR allows you to set a ﬁxed Target bit rate that consumes a predictable amount of bandw image activity, but in this case cannot, frame rate and image quality are affected negatively. To partly compensate for this, it is possible to prioritize either frame rate or image quality. Not setting a priority means that frame rate and image quality are equally affected. You must save your se ttings befo

The current bit rate can be set to appe and enter the code #b in the ﬁeld.

re they can take effect.

ar as text overlay. To do this, select the Include text check box option under Overlay Settings

idth. As the bit rate would usually need to increase for increased

es.

sing the GOV length may s ave considerably on

MJPEG

Sometimes the image size is large due to low light or complex scenery. Adjusting the maximum frame size helps to control the bandwidth and stor provides consistently good image quality at the expense of increased bandwidth and storage usage in low light. Limiting the frame size optimizes bandwidth and storage usag e, but may give poor image quality. To prevent i ncreased bandwidth and storage usage, the maximum fr

age used by the Motion JPEG video stream in these situations. Setting the frame size to the Default setting

ame size should be set to an optimal value.

Stream Proﬁles

There are four pre-programmed stream proﬁles available for quick set up . The settings for these can be adjusted. New customize d proﬁles can also be created. Each proﬁle has a descriptive name, indicating its purpose.

•Thestreamproﬁles can be accessed from the Stream proﬁle drop-down list in the Live View page.

• To add, copy, modify, and remove stream proﬁles go to Video & Audio > Stream Proﬁles.

AXIS P1343 Network Camera

Video and Audio

• To select the default stream proﬁle go to Live View Conﬁg > Stream Proﬁle and choose the proﬁle from the drop-down list.

For more information see the online help

on this page.

Camera Settings

The Video & Audio > Camera Settings page provides access to advanced image settings for the Axis product.

Image Appearance

Increasing the Color level increases the color s aturation. The value 100 gives maximum color saturation. The value 0 gives a black and white image.

The image Brightness can be adjusted in the range 0–100, where a higher value produces a brighter image.

Increasing the Sharpness can increase bandwidth usage. A sharper image might increase image noise especially in low light conditions. A lower setting reduces image noise, but the whole image will appear less sharp.

The Contrast changes the relative difference between light and dark. It can be adjusted using the slidebar.

White balance

White balance is used to make colors in the image appear the same regardless of the color temperature of the light s ource. The Axis product can be set to automatically identify the light source and compensate for its color. Alternatively, select the type of light

source from the drop-down list. For a description of each available setting, see the online help

Wide Dynamic Range

Wide dynamic range can improve the exposure when there is a considerable contrast between light and dark areas in the image. In intense backlight conditions, enable WDR. Disable WDR In low light conditions for optimal exposure .

Note

This setting is only possible when using automatic exposure control.

Exposure Settings

Conﬁgure the exposure settings to suit the image qual considerations.

Exposure value - Click in the bar to ﬁne-tune the expo sure.

Exposure control - These settings is used to adapt to the amount of light used. Automatic is the default settings can be used in most situations. The shutter speed is automatically set to produce optimum image quality. Flicker-free 50 or 60 Hz is used to remove

ﬂicker which can be caused by

Enable Backlight compe

the image to appear too dark.

Exposure zones - This settings determines which part of the image is used to calculate the exposure. For most situations, the Auto setting can be used. For particular requirement, select a predeﬁned a rea.

Exposure priority - When Motion is prioritized and maximum Shutter time is set to a small value, motion blur in the image is

ed. This can be useful for recognition of moving objects such as people and vehicles. However, prioritizing motion may cause

minimiz an increase in image noise, especially in low light situations. When Low noise is prioritized and Gain is set to a small value, image noise is minimi zed. The ﬁle size is reduced, which can be useful if storage space or bandwidth is limited. H owever, prioritizing low

se may result in a very dark image, especially in low light situations.

noi

ﬂuorescent and other l ight sources. The Hold current option locks the current exposure settings.

nsation - Enable this option if a bright spot of light, for example a light bulb, causes other areas in

ity req uirements in relation to lighting, frame rate and bandwidth

AXIS P1343 Network Camera

Video and Audio

Day/Night

The IR cut ﬁlter prevents infrared (IR) light from reaching the image sensor. In poor lighting conditions, for example at night, or when using an IR lamp, set the IR cut ﬁlter to Off. This increases light sensitivity and allows the product to “see” infrared light. The image is shown in black and white w hen the IR cut ﬁlter is off.

If using automatic Exposure control,settheIRcutﬁlter to Auto to automatically switch between On and Off accordingtothe lighting conditions.

Iris conﬁguration

Iris conﬁguration shows the current conﬁgured iris type. Do not change the iris conﬁguration unless the lens has been changed, see Replacing the lens, on page 8 .

Iris adjustment

Select Enable automatic iris adjustment to automatically compensate for changing light conditions. This option is not available if a ﬁxed iris is used.

View Area

A view area is a cropped part of the full view. The view area is treated as a video source in Live View and has its own video stream and PTZ settings.

To enable a view area, go to Video & Audio > Camera Settings and select Enable View Area.

When setting up a view area it is recommended that the video stream resolution is the same size as or smaller than the view area size. Setting the video stream resolution larger than the view area size implies digitally scaled up video after sensor capture, requiring more bandwidth without adding image information.

To conﬁ gure the view area:

1. Go to Video & Audio > View Area.

2. Select an Aspect ratio and a Video stream resolution.

3. A new view area covers the whole image. Usethemousetomoveandresizetheviewarea.

4. Select Enable PTZ to enable digital PTZ for the view area.

5. Click Save to save the settings.

To modify the view area, modify the settings as required. Click Save.

Tip:

• The PTZ functionality is useful during installation of the Axis product. Use a view area to crop out a speciﬁcpartof the full view.

Overlay

Overlays include date and time or view the current bit rate as overlay text.

To include the current bit rate as overlay text go to Video & Audio > Video Stream > Overlay Settings,selecttheInclude text check

box option, and enter the code #b in the ﬁeld. See the online help

can be used to provide extra information and are superimposed over the video image. With overlay text it is possible to

for supported formats.

Overlay image

An overlay image can be used to provide extra i n forma tion, or to mask a part of the video image.

AXIS P1343 Network Camera

Video and Audio

To use your own image, such as a logo, ﬁrst upload the image to the Axis product. Go to Video & Audio > Overlay Image, click Browse to locate the ﬁle and then click Upload.TheﬁlecanthenbeselectedfromtheUse overlay image drop-down list.

To place an overlay image at speciﬁccoordinates,gotoVideo & Audio > Video Stream and select the Include overlay image at coordinates check box option and enter the X and Y coordinates.

For more information see the online help

Privacy Mask

A privacy mask is an area of solid color that prohibits users from viewing parts of the monitored area. Privacy masks cannot b e bypassed via the VAPIX® Application Programming Interface (API).

The Privacy Mask List (Video & Audio > Privacy Mask) shows all the masks that are currently conﬁgured in the Axis product and indicates if they are enabled.

You can add a new mask, re-size the mask with the mouse,chooseacolorforthemask,andgivethemaskaname.

For more information, see the online help

Focus

You can focus the Axis product under Video & Audio > Focus. For most applications, the adjustments on the Basic tab are sufﬁcient. If required, additional adjustments can be made on the Advanced tab. Before focusing, always click Open iris to open the iris to its maximum. This gives the smallest depth of ﬁeld and thus best conditions for correct focusing. Click Enable iris when ﬁnished focusing.

Basic

Follow the on-screen instructions on the Basic tab to adjust zoom and focus. The pixel counter is used to determine the number of pixels in an area of the image, for example to ensure that the image size fulﬁlls s click on the text and drag the window to the desired position.

Note

• The back focus (step 2) should only be reset if the camera has been focused previously.

• Set focus as precisely as possible using the focus puller on the lens (step 3) before starting the automatic ﬁne-tuning (step 4).

• If the camera is placed so that it is difﬁcult to look at the image and move the pullers at the same time, you can use the Focus Assistant to focus the camera; for instructions, see the Installation Guid e supplied with the product.

Advanced

The tools on this page can be used to ﬁnd the op t imal focus position. Always open the iris before focusing and enable it when ﬁnished focusing. Focus is measured in th and then click Fine-tune focus automatically. If needed, click in the Focus position baroronthearrowsattheendsofthebar,to further adjust the focus. The buttons < and > move the focus position one step in either direction. The buttons << and >> move the focus position multip completing the above instructions, try the Full range focus scan. The scan, which can take several minutes, transforms the focus position bar to a graph where peaks indicate the best focus positions. Click in the graph to set focus to the desired position.

le steps in either direction. Clicking on the bar sets focus to that position. If the c amera is not focused after

epartoftheimagecoveredbytheFocus window. Use the mouse to move and resize the window

peciﬁc requirements. To position the pixel counter,

Audio Settings

The audio functionality for each video stream is enabled under Video & Audio > Video Stream > Audio.

Audio Channels

Select the type of audio transmission from the Audio mode: drop-down list (Video & Audio> Audio Settings). The different types are:

Full duplex - Simultaneous two-way audio allowing you to transmit and receive audio (talk and listen) at the same time. There is no

echo cancellation; if feedback loops appear, try moving the m icrophone or the speaker.

AXIS P1343 Network Camera

Video and Audio

Half-duplex - Audio can b e transmitted in both directions between the Axis product and the client computer, but only in one direction at a time. You must actively receive sound using the Talk/Listen button visible in the Live View page (see AXIS Media Control viewer toolbar). In Push-To-Talk mode, click and hold the button to speak and re lease it when done. In Toggle mode, click once to switch between speaking and listening. The Talk/Listen mode is conﬁgured from the Audio tab in the AMC control panel (see AXIS Media Control on page 14).

Simplex - Network Camera speaker only - Audio is transmitted from the client to the Axis product and played by the speaker connected to the product. To send audio, the Talk and Microphone buttons in the AMC toolbar must both be enabled. Click either button to stop audio transmission.

Simplex - Network Camera microphone only - Audio captured by the microphone connected to the Axis product is transmitted from theproducttooneormoreclients.

For more information about these settings, please see the online help

Audio Input

An external micropho n e or a line source can be connected to the product’s Audio-in connector. Conﬁgure the audio input settings under Video & Audio > Audio Settings.

Source - Select Microphone for an external microphone or Line for a Line in device, e.g. an audio mixer for multiple microphones or a microphone with a built-in ampliﬁer.

Microphone power - The Enab le microphone p ower option provides DC power for an external microphone. Microphone power should only be used with microphones that have no battery and when using the internal microphone. This setting should not be enabled when using a dynamic or battery powered microphone. Microphone power will not harm the microphone; if you are uncertain, try switching it off and on. To use a professional microphone requiring 48V phantom power, you need an external power supply and a balanced-unbalanced converter (audio transformer) in between.

Input gain - Control the volume (dB Full Scale) of the audio inp ut. If the sound is too low, choose a higher dB, to amplify the sound. If the sound is too high, choose a lower dB. The Level bar gives a visual representation of the audio signal level in dB relative to the full-scale input level.

• Green — the signal is at a good level.

• Yellow — the signal is becoming distorted.

• Red — the signal is distorted.

Encoding - Select digital audio encoding format.

• AAC requires a license for both encoding and decoding. AAC is the least complicated and most widely used codec. If achieving the best possible audio qua is included in the Axis product.

lity is a priority, AAC is the recommended codec to use. An AAC license

• G711

• G726

Sample rate - The number of times per second the sound is sampled. A higher sample rate will provide better audio quality, but also r equires a greater bandwidth.

Bit rate

rate may have latency or delay, but will require less bandwidth.

For more information about these settings, please see the online help

- Set the required bit rate depending on the selected encoding. A higher bit rate will give better audio quality. A lower bit

AXIS P1343 Network Camera

Video and Audio

Audio Output

An external speaker can be connected to the product’s Audio-out connector. The output can be used with high impedance headphones or connected to another ampliﬁer with speakers.

Conﬁgure the audio output settings under Video & Audio > Audio Settings.

Output gain - Control the volume (dB Full Scale) of the line audio output. If the sound is too low, choose a higher dB. If the sound is too high, choose a lower dB.

Audio Clips

An audio c lip is a sound ﬁle that can be played either whe n an event occurs or manually from the Live View page. Audio clips can be uploaded to the product or recorded by a microphone connected to the product.

You can add, play, download, modify and remove audio clips from Video & Audio > Audio Clips. For more information see the

online help

Note

Audio clips cannot be used if the product’s audio functionality is enabled. The audio functionality is enabled on the Audio tab under Video & Audio > Video Stream.

AXIS P1343 Network Camera

Live View Conﬁg

You can customize the Live View page and alter it to suit your requirements. It is possible to deﬁne the following features of theLiveViewpage.

•StreamProﬁle. See page 19.

• Default Viewer for Browser. See page 25.

• Viewer Setting s. See page 26.

• Action Buttons. These are the buttons described in Controls on the Live View page, on page 11.

•UserDeﬁned Links. See page 26.

• Output Buttons. See page 26.

Default viewer for browsers

From Live View Conﬁg > Default Viewer se le ct the default method for viewing video images in your browser. The product attempts to show the video images in the selected video format and viewer. If this is not possible, the product overrides the settings and selects the

best available combination.

AXIS P1343 Network Camera

Live View Conﬁg

Browser Viewer Description

Windows Internet E xplorer

Other browsers

For more information, please see the online help .

AMC

QuickTime

Java applet

Still image Displays still images only. Click the Refresh button in your brow ser to view a

Server Push

QuickTime

Java applet

Still image Displays still images only. Click the Refresh button in your brow ser to view a

Recommended viewer in Internet Explorer (H.264/Motion JPEG)

H.264

A slower imaging alternative to AMC (Motion JPEG). Requires one of the following install ed on the client:

• JVM (J2SE) 1.4.2 or higher

• JRE (J2SE) 5.0 or higher

new image

Recommended viewer for other browsers (Motion JPEG).

H.264

A slower imaging alternative to Server Push (Motion JPEG only).

new image

Viewer Settings

Options for the viewer are conﬁgured under Live View Conﬁg > Viewer Settings.

•TheShow viewer toolbar option will display the AX IS Media Control (AMC) or the QuickTime viewer toolbar under the video image in your browser.

• H.264 decoder installation. The administrator can disable installation of the H.264 decoder included with AXIS Media Control. This is used to prevent installation of unlicensed copies. Further decoder licenses can be purchased from your Axis reseller.

•SelectShow crosshair in PTZ joystick mode to enable a cross that will indicate the center of the image in PTZ joystick mode.

•SelectUse PTZ joystick mode as default to enable joystick mode. The mode can be changed temporarily from the PTZ control panel.

• You can enable recording from the Live View page. The recordings are saved to the location speciﬁed in the AMC Control Panel. See AXIS Media Control (AMC), on page 14.

User Deﬁned Links

To display user-deﬁned links in the Live View page, select the Show custom link option, give the link a name and then enter the URL to link to. When deﬁning a web link do not remove the 'http://' from the URL address. Custom links can be used to run scripts or activate external d evices connected to the product, or they can link to a web page. Custom links deﬁned as cgi links will run the script in the background, in a hidden frame. Deﬁning the link as a web link will open the link in a new window.

Output Buttons

An output on the Axis product can be controlled directly from the Live View page, by enabling the display of output buttons. To display the output buttons in the Live View page, select the type of control to use for the port from the drop-down list under Live View Conﬁg > Output Buttons:

• Pulse activates the output for a deﬁned period of time. The pulse time can be set as short as 1/100 second, and as long as 60 seconds

• Active/Inactive displays two buttons (on/off). The output ports must ﬁrst be conﬁgured under System Options> Ports & Devices > I/O Ports.SeeI/O Ports, on page 45.

AXIS P1343 Network Camera

PTZ (Pan Tilt Zoom)

Preset Positions

A preset position is a predeﬁned view that can be used to quickly steer the camera to a speciﬁc location. Preset positions can be accessed in several ways:

• By selecting the preset from the Preset positions drop-down list in the Live View Page.

• When setting up action rules. See page 33.

• When setting up Guard Tour. See page 27.

To add a preset position:

1. Go to PTZ > Preset Positions.

2. Use the pan, tilt and zoom controls to steer the camera view to the desired position.

3. Enter a descriptive name in the Current position ﬁeld.

The product can be conﬁgured to return to the Home position when the PTZ functionality has been inactive for a speciﬁed length of time. Enter the leng th of time in the ﬁeld and click Save. Set the time to zero to prevent the product from automatically returning to the Home position.

To include the preset position name in the overlay text, go to Video & Audio,selectInclude overlay text and enter the modiﬁer #P in

the ﬁeld. For more information about modiﬁers, see File Naming & Date/Tim e Formats intheonlinehelp

Guard Tour

A guard tour displays the video stream from different preset positions, one-by-one, in a predetermined order or at random and for

urable time periods. The enabled guard tour will keep running after the user has logged off or closed the browser.

conﬁg

o add a guard tour:

1. Go to PTZ>GuardTourand click Add.

2. Enter a descriptive name.

3. Specify the pause length between runs.

AXIS P1343 Network Camera

PTZ (Pan Tilt Zoom)

4. Select an available preset position and click Apply.

6. Specify the View Time in seconds or minutes.

7. Specify the View order or select the Random view order check box option.

8. Click Save.

To modify or remove guard tours, go to PTZ>GuardTour, select the guard tour in the Guard Tour List and click Modify/Remove.

For more information see the online help

Advanced

Controls

Panel Shortcut Command Buttons can be conﬁgured to provide direct access to commands issued via the VAPIX® Application Programming Interface. The buttons will be displayed in the PTZ control panel, which is available in the Live View page through the Ctrl panel button, see page 12.

Note

Disabling PTZ controls will not affect preset positions. For example, if the tilt control is disabled, the product can still move to preset positions that require a tilt movement.

AXIS P1343 Network Camera

Detectors

Camera Tampering

Camera Tampering can generate an alarm whenever the camera is repositioned, or when the lens is covered, sprayed or severely defocused. To send an alarm, for example an email, an action rule must be set up.

To conﬁ gure tampering:

1. Go to Detectors > Camera Tampering.

2. Set the Minimum duration, that is, the time that must elapse before an alarm is generated. This can help prevent false alarms for known conditions that affect the image.

3. Select Alarm for dark images if an alarm should be ge n erated if lights are dimmed or turned off, or if the lens is sprayed, covered, or rendered severely out of focus.

4. Click Save.

To conﬁgure the product to send an alarm when tampering occurs:

1. Go to Events > Action Rules.

2. Click Add to set up a new action rule.

3. Enter a Name for the action rule.

4. Under Condition,selectDetectors from the Trigger list.

5. Select Tampering from the list of detectors.

6. Optionally, select a schedule and set additional conditions.

7. Select the action. To send an email, select Send Notiﬁcation a

Note

The While the rule is active option under Duration cannot be used with camera tampering, since camera tampering does not have a duration and once it has been triggered it will not automatically return to its untriggered state .

For more information on actions r ules, see Events, on page 33.

nd select a Recipient from the list of deﬁned recipients.

Motion Detection

Motiondetectionisusedtogenerateanalarmwhenevermovementoccurs(orstops)intheview. Upto10IncludeandExclude windows can be conﬁgured:

• Include windows — target speciﬁc areas within the whole video image

• Exclude windows —deﬁne areas within an Include window that should be ignored (areas outside Include windows

re automatically ignored)

Once conﬁgured, motion detection windows appear in the list of Detectors in Action rule setup. See Setting Up an Action Rule, on page 33.

Note

Using the motion detection feature may decrease the product’s overall performance.

AXIS P1343 Network Camera

Detectors

Set up motion detection

To set up a motion detection Include Window , follow these instructions:

1. Go to Detectors > Motion Detection.

2. Select the Conﬁgure Included Windows option and click New. Select the new window in the list of window s and enter adescriptivename.

3. Adjust the size (drag the bottom right-hand corner) and the position (click on the text at the top and drag to the desired position) of the active window (window with red frame).

4. Adjust the Object Size, History and Sensitivity proﬁle sliders (see Motion detection parameters for details). Any detected motion within an active window is indicated by red peaks in the Activity window.

5. Click Save.

To exclude parts of the include window, select the Conﬁgure Excluded Windows and position the exclude window within the include window.

To delete an include or exclude window, select the window in the list of

windows and click Del.

Motion detection parameters

The parameters controlling motion detection are described in the table below:

Parameter

Description

High level (100%)

Medium l

Low level (0%)

evel (50%)

Object Size

Object size relative to window size.

Only very large objects trigger motion detection.

ven very small objects trigger

E motion detection.

History

Object memory length.

An object that appears in the window triggers motion detection for a l before it is considered as non-moving.

n object that appears in

A the window triggers motion detection only for a very short time before it is considered as non-moving.

ong time

Sensitivity

Difference in luminance between background and object.

Ordinary colored objects on ordinary background s trigger motion detection.

A large difference in luminance is req u ired to trigger motion detection.

Only very bright objects on a dark background trigger motion detection.

AXIS P1343 Network Camera

Detectors

Recommended values

Default values

Tips:

• To trigger on small objects or movements, use several small m otion detection windows rather than one large window and select a low object size.

• To avoid triggering on small objects, select a high object size.

• If no objects should appear in the Include Window, select a high history level. This will cause motion detection to trigger as long as the object is present in the window.

• To only detect ﬂashing light, select a low sensitivity. In other cases high sensitivity is recommended.

5–15% 60–90% 75–95%

15% 90% 90%

Audio detection

The Axis product can be conﬁgured to generate an alarm when audio rises ab ove or falls below the threshold value. The threshold value can be set in the range 0–100 where 0 is the most sensitive and 100 the least sensitive.

1. Go to Detectors > Audio Detection.

2. Set the audio alarm level and click Save.

3. Go to Events > Action Rules and set up an action rule, see Setting Up an Action Rule, on page 33.

Detected audio is indicated by colored peaks in the Activity indicator. An ev ent is triggered when detected audio rises above or falls below the threshold value, which is represented by the bar.

AXIS P1343 Network Camera

Applications

Third party applications can be uploaded to and installed on the Axis product. For information about available applications, downloads, trials and licenses, go to www.axis.com/applications

To upload an application, go to Applications > Overview, click Browse to locate the ﬁle and then click Upload Package. Click on the uploaded application’s name to open the menu options Settings, License and About.Forconﬁguration instructions, please refer to the documentation provided with the application.

Most applica tions need a license to run. To install the license, select the License menu option. If the product is connected to the Internet, Automatic Installation appears in the web page. If the product is not connected to the Internet, go to www.axis.com/applications to acquire a License key. You will need a license code and the product’s serial number (found on the label and under System Options > Support > System Overview) to receive a license key.

Installed Applications lists installed applications with informa tion about the version and the vendor, the status of the a pplication (running or not running), and information about the license.

Use the Start and Stop buttons to start and stop the application.

To generate a log ﬁle for the application, select the application and click Log.

Note

It is recommended to run one application at a time. Avoid running applications when motion detection is active.

AXIS P1343 Network Camera

Events

The Axis product can be conﬁgured to perform actions whe n different events occur, for exa mple, start a recording when motion is detected. The set of conditions that deﬁnes how and when the action is triggered is called an Action Rule. The action rule will apply at speciﬁc periods called Schedules. It is possible to specify how often the action rule will recur. This is called Recurrences.

Available A ction Rule triggers include:

• Detectors, for example audio detection and motion detection, see Detectors, on page 29

• Input Signal — when the product’s I/O port receives a signal from an external device, such as a smoke detector or switch

• PTZ — when the product’s pan/tilt/zoom controls are activated or when the view stops at a preset position

• Storage — when a storage device is available, locked or full

• System — when the product is started

•Time,seeRecurrences, on page 34

Possible actions include:

• Day/Night Vision Mode

• Output Port — activate an output to, for example, sound an alarm or lock a door

• Play Audio Clip

• Record Video — record video and save to a selected storage

•SendImagesandNotiﬁcations — once recipients have been set up, a notiﬁcation can be sent that an event has occurred

•StatusLED

Convert Event Types to Action Rules

The internal Event Management system has been redesigned from ﬁrmware version 5.40. The legacy user Event Types in the camera will continue to work but wi Action rules to become visible in the user interface.

To convert Event Types to Action Rules go to Events > Action Rules and click Convert.

Caution

This is not recomme

ll not be visible in the user interface of the camera. The Event Types need to be converted to

nded when using a VMS b ased on the old Event Management System.

Setting Up an Action Rule

An action rule deﬁnes the conditions that must be met for the product to perform an action, for example record video or send email notiﬁcations. If multiple conditions are deﬁned, all must be met to trigger the action.

The following example describes how to set up an action rule to send an email if there is movement in the product’s ﬁeld of view:

1. Go to Events > Action Rules and click Add.

2. Select the Enable rule option and enter a descriptive name for the rule.

3. Select Detectors from the Trigger drop-down list.

4. Select Motion Detection from the drop-down list. This option is only available if a motion detection window has been conﬁgured, see page 30.

AXIS P1343 Network Camera

Events

5. Set one of the available pre-programmed time intervals from the Schedule drop-down list.

6. Select Send Notiﬁcation from the Type drop-down list.

7. Select where to send the notiﬁcation from the Recipient drop-down list.

To add additional criteria, select the Additional conditions option. Add and select the desired options as described above. To prevent an action from being triggered repeatedly, a Wait at least time can be set. Enter the time in hours, minutes and seconds, during which the trigger should be ignored before the action rule can be activated again.

To copy, modify or remove an action rule, select the action rule in the Action Rule List and click Copy, Modify or Remove.

The recording Duration of some actions can be set to include time immediately before and after the event. Select Pre-trigger time and/or Post-trigger time and enter the number of seconds. When While the rule is active is enabled and the action is triggered again during the post-trigger time, the recording time will be extended with another post-trigger time period.

For more information, see the online help

Recipients

Recipients receive image ﬁles and notiﬁcation messages. A recipient can be an FTP, HTTP or TCP server, a network share or an email address. TCP servers are used for notiﬁcation messages only.

To add a recipient:

1. Go to Events > Recipients and click Add.

2. Enter a descriptive name

3. Select a recipient Type.

4. Enter the information needed for the recipient type.

5. Click Test to test the connection to the recipient.

6. Click OK.

Schedules

An action can be set up to occur on a schedule. Included in the list are predeﬁned schedules for after and during ofﬁce hours, weekdays or weekends.

To create a new schedule:

1. Go to Events > Schedules and click Add.

2. Enter a descriptive name and the information needed for a daily, weekly, monthly or y early schedule.

3. Click OK.

To use the schedule in an Action Rule, select the schedule from the Schedule drop-down list in the Action Rule Setup page.

Recurrences

An action can be set up to recur a speciﬁc number of times in a period, for example every 2 minutes or every hour.

To s et up a recurrence:

1. Go to Events > Recurrences and click Add.

2. Enter a descriptive name and re curre nce pattern.

AXIS P1343 Network Camera

Events

3. Click OK.

To use the recurrence in an Action R ule, ﬁrst select Time from the Trigger drop-down list in the Action Rule Setup page and then select the recurrence from the second drop-down list.

To modify or remove recurrences, select the recurrence in the Recurrences List and click Modify or Remove.

AXIS P1343 Network Camera

Recordings

TheAxisproductcanbeconﬁgured to record video continuously or according to an action rule:

• To start a continuous recording, see page 36.

• To set up action rules, see page 33.

• To access recordings, see Recording List, on page 36.

•Toconﬁgure camera controlled storage, see Storage, on page 44.

Recording List

Recordings made to the SD card and network share are listed on the Recordings > List page. The list shows each recording’s start date and time, duration and the event that triggere d the recording.

To play or d ownload a recording, follow these steps:

1. Go to Recordings > List.

2. Use the ﬁlter to narrow the list of recordings. Enter the desired ﬁlter criteria and click Filter. Some ﬁlters may take a long time to complete.

3. Select the recording.

4. Click Play to play the recording, or click Download to download the recording.

Multiple recordings can be downloaded at the same time. Select the recordings and click Download. The downloaded ﬁle is a zip ﬁle containing a minimum of three ﬁles, of which the Matroska (mkv) ﬁles are the actual recordings. The recordings are time-stamped with the date and time they were downloaded (that is, not the date the

Note

To play recordings in Windows Media Player, AXIS Matroska File Splitter must be installed. AXIS Matroska File Splitter can be downloaded from www.axis.com/techsup/software

For detailed recording and video information, select a recording and click Properties.

To remove a recording, select the recording and click Remove.

recordings were made).

Continuous recording

The Axis product can be conﬁgured to continuously save video to an SD card or network share. To prevent the disk from becoming full, it is recommended to conﬁgure the disk to automatically remove old recordings see Storage, on page 44.

To start a continuous recording, follow these steps:

1. Go to Recordings > Continuous.

2. Select Enabled.

3. Select from the SD card or network share from the Disk list.

4. Select a Stream proﬁle to use for continuous recordings.

5. Click Save to save and start the recording.

AXIS P1343 Network Camera

Recordings

Note

If a new stream proﬁle is selected while a recording is ongoing, the recording will be stopped and saved in the recording list and a new recording with the new stream proﬁle will start. All previous continuous recordings will remain in the recording list until they are removed manually or through automatic removal of old recordings .

AXIS P1343 Network Camera

System Options

Security

Users

User access control is enabled by default and can be conﬁgured under System Options > Security > Users. An administrator can set up other users by giving them user names and passwords. It is also possible to allow anonymous viewer login, which means that anybody may access the Live View page.

The user list displays authorized users and user groups (access levels):

Viewer - Access to the Live View page

Operator - Access to the Live View page and to all settings except System Options

Administrator - Unrestricted access to all settings; can add, modify and remove other users.

Under HTTP/RTSPPasswordSettings, select the type of password to allow. You may need to allow unencrypted passwords if there are viewing clients that do not suppo rt encryption, or if y ou upgraded the ﬁrmware and existing clients support encryption but need to log in aga in and be conﬁguredtousethisfunctionality.

Under User Settings, select the Enable anonymous viewer login option to allow anonymous users access to the Live View page.

Select the Enable anonymous PTZ control login to allow anonymous users access to the PTZ controls.

Deselect the Enable Basic Setup option to hide the Basic S etup menu. Basic Setup provides quick access to settings that s hould be made before using the A xis product.

ONVIF

ONVIF (Open Network Video Interface Forum) is a global interface standard that makes it easier for end users, integrators , consultants, and manufacturers to take advantage of the p ossibilities offered by network video technology. ONVIF enables interoperablity between different vendor products, increased ﬂexibility, red

By creating a user you automaticall with the product. For more information see www.onvif.org

y enable ONVIF communication. Use the user nam e and password with all ONVIF communication

uced cost and future-proof systems.

IP Address Filter

IP address ﬁlter ing is enabled on the System Options > Security > IP Address Filter page. Once enabled, the listed IP address are allowed or denie d acces

The administr

ator can add up to 256 IP address entries to the list (a single entry can conta in multiple IP addre sses ).

s to the Axis product. Select Allow or Deny from the list and click Apply to enable IP address ﬁltering.

HTTPS

The Axis product supports encrypted browsing using HTTPS. This is conﬁgured on the System Options > Security > HTTPS page.

A self-signed certiﬁcate can be used until a Certiﬁcate Authority-issued certiﬁcate has been obtained. Click Create self-signed certiﬁcate to install a self-signed c ertiﬁcate. Although self-signed certiﬁcates are free and offer some protection, true security is only implemented after the installation of a signed certiﬁcate issued by a Certiﬁcate Authority.

To obtain a signed certiﬁcate from an issuing Certiﬁcate Authority, click Create Certiﬁcate Request. When the signed certiﬁcate is returned, click Install signed certiﬁcate to import the certiﬁcate. The properties of any certiﬁcate request currently resident in the product or installed can be viewed by clicking Properties.

To enable HTTPS in the Axis product, the HTTPS Connection Policy must be set for each user group.

For more information, see the online help

AXIS P1343 Network Camera

System Options

IEEE 802.1X

IEEE 802.1X is a standard for po rt-based Network Admission Control providing secure authentication of wired and wireless network devices. IEEE 802.1X is based on EAP (Extensible Authentication Protocol).

To access a network protected by IEEE 802.1X, devices must authenticate themselves. The authentication is performed by a third-party entity called an authentication server, typically a RADIUS server, examples of which are FreeRADIUS and Microsoft Internet Authentication Service.

In Axis' implementation, the network device and the authentication server authenticate themselves with the help of digital certiﬁcates using EAP-TLS (Extensible Authentication Protocol - Transport Layer Security). The certiﬁcates are provided by an Certiﬁcation Authority (CA). You need:

•aCAcertiﬁcate to validate the identity of the authentication server

• a CA-signed client certiﬁcate and a private key to authenticate the network device.

To allow the network device to access a network protected by IEEE 802.1X:

1. Obtain a CA certiﬁcate, a client certiﬁcate and a client private key (contact your network administrator).

2. Go to Setup > System Options > Security > IEEE 802.1X and upload the CA certiﬁcate, the client certiﬁcate and the client private key.

3. Under Settings, select the EAPOL version, provide your EAP identity and private key password.

4. Check the box to enable IEEE 802.1X and click Save.

Certiﬁcates

CA Certiﬁcate The CA certiﬁcate is used to validate the identity of the authentication server. Enter the path to

the certiﬁcate directly, or locate the ﬁle using the Browse button. Then click U acertiﬁcate, click Remove.

Client certiﬁcate Client private key

Settings

EAPOL version

EAP identity

Private key password

Enable IEEE 802.1X

The client certiﬁcate and private key are used to authenticate the network device. They can be uploaded as separate ﬁles or in one combined ﬁle (e.g. a PFX ﬁle or a PEM ﬁle). Use the Client

private key ﬁeld if uploading one combined ﬁle. For each ﬁle, enter the path to the ﬁle, or locate the ﬁ

le using the Browse button. Then click Upload.Toremoveaﬁle, click Remove.

SelecttheEAPOLversion(1or2)asusedinyournetworkswitch.

Enter the user identity (maximum 16 characters) associated with your certiﬁcate.

Enter the password (maximum

Check the box to enable the IEEE 802.1X protocol.

16 characters) for the private key.

pload.Toremove

Audio Support

Select Enable audio support to allow clients to retrieve audio streams from the Axis product. For information on how to conﬁgure audio setti ngs, see Audio Settings, on page 22.

Note

Deselecting this option will disable audio globally in the Axis product, for conﬁg ured events and proﬁles with audio as well.

Date & Time

The Axis product’s date and time settings are conﬁgured under System Options > Date & Time.

Current Server Time displays the current date and time (24h clock). The time can be displayed in 12h clock in the text overlay (see

below).

AXIS P1343 Network Camera

System Options

To change the date and time settings, select the p referred Time mode under New Server Time:

• Synchronize with computer time sets date and time according to the computer’s clock. With this option, date and time are set once and will not be updated automatically.

• Synchronize with NTP Server obtains date and time from an NTP server. With this option, date and time settings are updated continuously. For information on NTP settings, see NTP Conﬁguration, on page 41.

If using a host name for the NTP server, a DNS server must be conﬁgured. See DNS Conﬁguration, on page 41.

• Set manually allows you to manually set date and time.

If using an NTP server, select your Time zone from the drop-down list. If required, check Automatically adjust for daylight saving time changes.

The Date & Time Format Used in Images is the date and time format displayed as a text overlay in the video stream. Use the

predeﬁned formats or see File Naming & Date/Time Formats in the online help time formats. To include date and time in the overlay text, go to Video & Audio and s elect Include date and Include time.

Network

for information on how to create custom date and

Basic TCP/IP Settings

The Axis product supports IP version 4 and IP version 6. Both versions can be enabled simultaneously, and at least one version must always be enabled.

IPv4 Address Conﬁguration

By default, the Axis product is set to use IPv4 (IP version 4) and to obtain the IP address a utomatically via DHCP. The IPv4 settings are conﬁgured under System Options > Network > TCP/IP > Basic.

DHCP (Dynamic Host Conﬁguration Protocol) allows network administrators to centrally manage and automate the assignment of IP addresses. DHCP should only be enabled if using dynamic IP address notiﬁcation,oriftheDHCPcanupdateaDNSserver,which when allows you to access the Axis product by name (host name).

If DHCP is enabled and the product cannot be accessed, run AXIS IP Utility to search the netwo rk for connected Axis products, or reset the product to the factory default settings (see page 47) and then perform the installation again.

To use a static IP address, check Use the following IP address and specify the IP address, subnet mask and default router.

IPv6 Address Conﬁguration

If IPv6 (IP version 6) is enabled, the Axis product will receive an IP addr ess according to the conﬁguration in the network router.

To enab le IPv6, go to System Options > Network > TCP/IP > Basic. Other settings for IPv6 should be conﬁgured in the network router.

ARP/Ping

The IP address can be set using ARP and Ping. For instructions, see the product’s Installation Guide.

ARP/Ping is enabled by default. To disa b le , uncheck the box under System Options > Network > TCP/IP > Basic.

The ARP/Ping service is automatically disabled two minute s after the product is started, or as soon as an IP address is set. To reset the IP address, the product must be restarted to activate ARP/Ping for an additional two minutes.

Pinging the product is still possible when this service is disabled.

AXIS P1343 Network Camera

System Options

AXIS Video Hosting System (AVHS)

AVHS used in conjunction with an AVHS service, provides easy and secure Internet access to live and recorded video accessible from any location. For more information and help to ﬁnd a local AVHS Service Provider go to www.axis.com/hosting

AVHS is enabled by default. The settings are conﬁgured under System Options > Network > TCP IP > Basic.

One-click enabled - Press the product’s control button (see Hardware overview, on page 5 ) to connect to an AVHS service over the Internet. Once registered, Always will be enabled and the Axis product stays connected to the AVHS service. If the product is not registered within 24 hours from when the button is pressed, the product will disconnect from the AVHS service.

Always - The Axis product will constantly attempt to connect to the AVHS service over the Internet. Once registered the product will stay connected to the service. This option can be used when the product is already installed and it is not convenient to use the one-click installation.

AXIS Internet Dynamic DNS Service

AXIS Internet Dynamic DNS Service assigns a host name for easy access to the product. For more information, see www.axiscam.net

To register the Axis product with AXIS Internet Dynamic DNS Se rvice, go to System Options > Network > TCP/IP > Basic.Under Services, click the AXIS Internet Dynamic DNS Service Settings button (requires access to the Internet). The domain name currently registered at AXIS Internet Dynamic DNS service for the product can at any time be removed.

Advanced TCP/IP Settings

DNS Conﬁguration

DNS (Domain Name Service) provides the translation of host names to IP addresses. The DNS settings are conﬁgured under System Options > Network > TCP/IP > Advanced.

Select Obtain DNS server address v ia DHCP to use the DNS settings provided by the DHCP server.

To make manual settings, select Use the following DNS server address and specify the following:

Domain name - Enter the domain(s) to search for the host name used by the Axis product. Multiple domains can be separated by semicolons. The host name is always the ﬁrstpartofafullyqualiﬁed domain name, for example, myserver is the host name in the fully qualiﬁed domain name myserver.mycompany.com where mycompany.com is the domain name.

Primary/Secondary DNS server - Enter the IP addresses of the primary and secondary DNS servers. The secondary DNS server is optional and will be used if the primary is unavailable.

NTP Conﬁguration

NTP (Network Time Protocol) is used to synchronize the clock times of devices in a network. The NTP settings are conﬁgured under System Options > Network > TCP/IP > Advanced.

Select Obtain NTP server address via DHCP to use the NTP settings provided by the DHCP server.

To make manual s ettings, select Use the following NTP server address and enter the host name or IP address of the NTP server.

Host Name Conﬁguration

The Axis product can be accessed using a host name ins tead of an IP address. The host name is usually the same as the assigned DNS name. The host name is conﬁgured under System Options > Network > TCP/IP > Advanced.

Select Obtain host name via IPv4 DHCP to use host name provided by the DHCP server running on IPv4.

Select Use the host name to set the host name manually.

Select Enable dynamic DNS updates to dynamically update local DNS servers whenever the Axis product’s IP address changes.

For more information, see the online help

AXIS P1343 Network Camera

System Options

Link-Local IPv4 Address

Link-Local Address is enabled by default and assigns the Axis product an additional IP address which can be used to access the product from other hosts on the same segment on the local network. The product can have a Link-Local IP and a static or DHCP-supplie d IP address at the same time.

This function can be disabled under System Options > Network > TCP/IP > Advanced.

HTTP

The HTTP port used by the Axis product can be changed under System Options > Network > TCP/IP > Advanced. In addition to the default setting, which is 80, any port in the range 1024–65535 can be used.

HTTPS

The HTTPS p ort used by the Axis product can be changed under System Options > Network > TCP/IP > A dvanced . In addition to the default setting, which is 443, any port in the range 1024–65535 can be used.

To enable HTTPS, go to System Options > Security > HTTPS. For more information, see page 38.

NAT traversal (port mapping) for IPv4

A network route r allows devices on a private n e t w o rk (LAN) to sha re a single connection to the Internet. This is done by forwarding network trafﬁc from the private network to the “outside”, that is, the Internet. Security on the private network (LAN) is increased since most routers are pre-conﬁgured to stop attempts to access the private network (LAN) from the public network (Internet).

Use NAT traversal when the Axis product is located on an intranet (LAN) and you wish to make it available from the other (WAN) side of a NAT router. With NAT traversal properly conﬁgured, all HTTP trafﬁc to an external HTTP port in the NAT router isforwardedtotheproduct.

NAT traversal is conﬁgured under System Options > Network > TCP/IP > Advanced.

Note

• For NAT traversal to work, this must be supported by the router. The router m u st also support UPnP

• The router has many different names: “NAT router”, “Network router”, “Internet Gateway”, ”Broadband router”, “Broadband sharing device” or “Home ﬁrewall” but the essential purp ose of the device is the sa

Enable/Disable - When enabled, the Axis product attempts to conﬁ gure port mapping in a NAT router on your network, using UPnP Note that UPnP

Use m anually selected NAT router - Select this option to manually select a NAT router and enter the IP address for the router in the ﬁeld. If no router is speciﬁed, the product automatically searches for NAT routers o n your network. If more than one router is found, the default router is selected.

Alternative HTTP port - Select this option to manually deﬁne an external HTTP port. Enter the port number in the ﬁeld. If no port is entered here, a port number is automatically selected when NAT traversal is enabled.

Note

must be enabled in the product (see System Options > Network > UPnP).

• An alternative HTTP port can be used or be active even if NAT traversal is disabled. This is useful i f your NAT route r does not support UPnP and you need to manually conﬁgure port forwarding in the NAT router.

• If you attempt to man

• When the port is selected au tomatically it is displayed in this ﬁeld. To change this, enter a new port number and click Save.

ually enter a port that is already in use, another available port is automatically selected.

me.

FTP

The FTP server running in the Axis product enables upload of new ﬁrmware, user applications, etc. The FTP server can be disabled under System Options > Network > TCP/IP > Advanced.

AXIS P1343 Network Camera

System Options

Note

This FTP server has nothing to d o with the product’s ability to transfer images via FTP to other locations and servers.

RTSP

The RTSP server running in the Axis product allows a connecting client to start an H.264 stream. The RTSP port number can be changed under System Options > Network > TCP/IP > Advanced. The default port is 554.

Note

H.264 video streams will not be available if the RTSP server is disabled.

SOCKS

SOCKS is a networking proxy protocol. The Axis product can be conﬁgured to use a SOCKS server to reach networks on the other side of a ﬁrewall or proxy server. This functionality is useful if the Axis product is located on a local network behind a ﬁrewall, and notiﬁcations, uploads, alarms, etc need to be send to a destination outside the local network (for example the Internet).

SOCKS is conﬁgured under System Options > Network > SOCKS. For more information, see the online help

QoS (Quality of Service)

QoS (Quality of Service) guarantees a certain level of a speciﬁed resource to selected trafﬁc on a network. A QoS-aware network prioritizes network trafﬁc and provides a greater network reliability by controlling the amount of bandwidth an application may use.

TheQoSsettingsareconﬁgured under System Options > Network > QoS. Using DSCP (Differentiated Services Codepoint) values, the Axis product can mark the followi ng types of trafﬁc: live video, live audio, event/alarm trafﬁc and management trafﬁc.

Note

Live audio DSCP will be equal to live video DSCP if H.264 over RTSP is used.

SMTP (email)

To send email messages from the Axis product via SMTP (Simple Mail Transfer Protocol), an SMTP mail server must be set up. This is done under System Options > Network > SMTP (email).

Enter the host names or IP addresses and port numbers for the primary and secondary mail servers in the ﬁelds pro vided . A From email address is also required. If the mail server requires a the necessary information.

uthentication, check Use authentication to log in to this server and enter

SNMP

The Simple Network Management Protocol (SNMP) allows remote management of network devices. An SNMP community is the group of devices and management stati

The Axis product can be conﬁgured

on running SNMP. Community names are used to identify groups.

to support SN MP on the System Options > Network > SNMP page.

Depending on the level of sec

SNMP v1/v2 provides the access to all supported SNMP devices. The default password for the Read community is public and the default password for the Write community is write.

Note

If HTTPS is enabled, SNMP v1 and S NMP v2c s hould be disabled.

Traps for SNMP v1/v2 are used by the Axis product to send messages to a management system on important events and status

s. Check Enable traps and enter the IP address where the trap message should be sent and the Trap community that

change should receive the message.

urity required, select the version on SNMP to use.

lowest level of security. The community name can be speciﬁed as a password for read or read/write

AXIS P1343 Network Camera

System Options

The follow ing traps are available:

•Coldstart

•Warmstart

•Linkup

• Authentication failed

SNMP v3 provides encryption and secure passwords. To use traps with SNMP v3, an SNMP v3 management application is required.

To use SNMP v3, HTTPS must be enabled, see HTTPS, on page 38. To enable SNMP v3, check the box and provide the initial user password.

Note

The initial password can only be set once. If the password is lost, the Axis product must be reset to factory default, see Reset to f actory default settings, on page 47.

UPnP

The Axis product includes support for UPnPTM.UPnPTMis enabled by default and the p roduct is automatically detected by operating systems and clients that support this protocol.

UPnP

can be disabled under System Options > Network > UPnPTM.

RTP/H.264

The RTP port range and multicast settings are conﬁgured under System Options > Network > RTP.

The RTP port range deﬁnes the range of ports from which the video/audio ports are auto only certain IP addresses and port numbers should be used.

Select Always Multicast Video and/or Always Multicast Video to start m ulticast streaming without opening an RTSP session.

matically selected. For multicast streams,

Bonjour

The Axis product includes support for Bonjour. Bonjour is enabled by default and the product is automatically detected by operating systems and clients that support this protoc

Bonjour can be disabled under System Op

ol.

tions > Network > Bonjour.

Storage

SD card

The SD/SDHC memory card (not included) is managed on the System Options > Storage page. Click SD card to open Storage Management.

Mounting is do ne automatically when the card is inserted or when the product boots. SD cards are normally preformatted when purchased, but if needed, click Format to format the card.

Format an SD card so that it can be written to one of two available options — VFAT and ext4. During the formatting any previous data stored on the disk will be lost. The recommended format is ext4, due to its resilience against data loss if the c ard is e je cted or if there is a brupt power loss. A third-party ext4 driver or application is also needed to access the ﬁle system from Windows. Note that most SD cards are pre-formatted with vFAT when purchased. The Check Disk option is used to check for errors on the SD card and only works for the ﬁle system ext4. The Repair option repairs the SD card of errors in the ﬁle system ext4. For vFAT ﬁle system use a card reader or PC to perform card maintenance.

Note

To prevent corruption of recordings, the SD car d should always be unmounted before removal.

AXIS P1343 Network Camera

System Options

If the card’s status shows as failed, click Check disk to see if the problem can be found and then try Repair.

To avoid ﬁlling the card, it is recommended to remove recordings continuously. Under Recording Settings, select Remove recordings older than and select the number of days or weeks.

To stop writing to the share and protect recordings fro m being removed, select Lock under Recording Settings.

For more information, see the online help

Network Share

Network share allows you to add network storage such as a NAS (Network Attached Storage) or any server that uses CIFS ( Common Internet File System) and use them for storage of recordings.

To add a network share:

1. Go to System Options > Storage.

2. Click Network Share.

3. Enter the IP address, DNS or Bonjour name to the host server in the Host ﬁeld.

4. Enter the name of the share in the Share ﬁeld.

5. If required, select The share requires login and e nter the user name and password.

6. Click Connect.

To clear all recordings and data from the Axis product’s folder on the designated share, click Clear under Storage Tools.

To avoid ﬁlling the share, it is recommended to remove recordings continuously. Under Recording Settings,selectRemove recordings older than and select the number of days or weeks.

To stop writing to the share and protect recordings fro m being removed, select Lock under Recording Settings.

Ports & Devices

I/O Ports

The Axis product provides one input port and one o utput port for connection of external devices. For information on how to connect external devices, see Connectors, on page 6 .

The I/O ports are conﬁgured under System Options > Ports & Devices > I/O Ports. The ports can be given descriptive names and their Normal states can be conﬁgured as Open circuit or Grounded circuit.

Port Status

The list on the System Options > Ports & Devices > Port Status page shows the status of the product’s input and output ports.

Maintenance

The Axis product provides several maintenance functions. These are available under System Options > Maintenance.

Click Restart to perform a correct restart if the Axis product is not behaving as expected. This will not affect any of the current settings.

Click Restore to reset most settings to the factory default values. The following settings are not affected:

• the boot protocol (DHCP or static)

• the static IP address

AXIS P1343 Network Camera

System Options

• the default router

• the subnet mask

•thesystemtime

• the IEEE 802.1X settings

• the focus position

Click Default to reset all settings, including the IP address, to the factory default values. This button should be used with c aution. The Axis product can a lso be reset to factory default using the control button, see Reset to factory default settings, on page 47.

To identify the product or test the Status LED, click Flash LED under Identify and s pecify the duration in seconds, minutes or hours. This can be useful for identifying the product among othe r products installed in the s ame location.

For information about ﬁrmware upgrade, see Upgrading the ﬁrmware, on page 49.

Support

Support Overview

The System Options > Support > Support Overview page provides information on troubleshooting and contact information, should you require technical assistance.

Axis P1343 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
