Axis 0927-001 User Manual

AXISP1265NetworkCamera

UserManual

Aboutthisdocument

Thismanualisintendedforadministratorsandusersof
AXISP1265NetworkCamera,andisapplicabletormware6.50and
later.Itincludesinstructionsforusingandmanagingtheproducton
yournetwork.Previousexperienceofnetworkingwillbeofusewhen
usingthisproduct.SomeknowledgeofUNIXorLinux-basedsystems
mayalsobeusefulwhendevelopingshellscriptsandapplications.Later
versionsofthisdocumentwillbepostedatwww.axis.comSeealsothe
product’sonlinehelp,availablethroughtheweb-basedinterface.

Legalconsiderations

Videosurveillancecanberegulatedbylawsthatvaryfromcountryto
country.Checkthelawsinyourlocalregionbeforeusingthisproduct
forsurveillancepurposes.

Thisproductincludesthefollowinglicences:

•one(1)H.264decoderlicense

Topurchasefurtherlicenses,contactyourreseller.
TheproductcontainsU.S.-origincontrolledtechnology/component,the

USExportAdministrationRegulations(EAR)arealwaysapplicableto
theproduct.Youshouldcomplyatalltimeswithallapplicablenational
andinternational(re-)exportcontrolregulations.

Liability

Everycarehasbeentakeninthepreparationofthisdocument.Please
informyourlocalAxisofceofanyinaccuraciesoromissions.Axis
CommunicationsABcannotbeheldresponsibleforanytechnicalor
typographicalerrorsandreservestherighttomakechangestothe
productandmanualswithoutpriornotice.AxisCommunicationsAB
makesnowarrantyofanykindwithregardtothematerialcontained
withinthisdocument,including,butnotlimitedto,theimplied
warrantiesofmerchantabilityandtnessforaparticularpurpose.Axis
CommunicationsABshallnotbeliablenorresponsibleforincidentalor
consequentialdamagesinconnectionwiththefurnishing,performance
oruseofthismaterial.Thisproductisonlytobeusedforitsintended
purpose.

Intellectualpropertyrights

AxisABhasintellectualpropertyrightsrelatingtotechnologyembodied
intheproductdescribedinthisdocument.Inparticular,andwithout
limitation,theseintellectualpropertyrightsmayincludeoneormoreof
thepatentslistedataxis.com/patent.htmandoneormoreadditional
patentsorpendingpatentapplicationsintheUSandothercountries.

Thisproductcontainslicensedthird-partysoftware.Seethemenuitem
“About”intheproduct’suserinterfaceformoreinformation.

ThisproductcontainssourcecodecopyrightAppleComputer,
Inc.,underthetermsofApplePublicSourceLicense2.0(see

opensource.apple.com/apsl).Thesourcecodeisavailablefrom
developer.apple.com/bonjour/

Equipmentmodications

Thisequipmentmustbeinstalledandusedinstrictaccordancewiththe
instructionsgivenintheuserdocumentation.Thisequipmentcontains
nouser-serviceablecomponents.Unauthorizedequipmentchangesor
modicationswillinvalidateallapplicableregulatorycertications
andapprovals.

Trademarkacknowledgements

AXISCOMMUNICATIONS,AXISandVAPIXareregisteredtrademarksor
trademarkapplicationsofAxisABinvariousjurisdictions.Allother
companynamesandproductsaretrademarksorregisteredtrademarks
oftheirrespectivecompanies.

Apple,Boa,Apache,Bonjour,Ethernet,InternetExplorer,Linux,
Microsoft,Mozilla,Real,SMPTE,QuickTime,UNIX,Windows,Windows
VistaandWWWareregisteredtrademarksoftherespectiveholders.
JavaandallJava-basedtrademarksandlogosaretrademarksor
registeredtrademarksofOracleand/oritsafliates.TheUPnPWord
MarkandUPnPLogoaretrademarksofOpenConnectivityFoundation,
Inc.intheUnitedStatesorothercountries.

SD,SDHCandSDXCaretrademarksorregisteredtrademarksofSD-3C,
LLCintheUnitedStates,othercountriesorboth.Also,miniSD,microSD,
miniSDHC,microSDHC,microSDXCarealltrademarksorregistered
trademarksofSD-3C,LLCintheUnitedStates,othercountriesorboth.

Regulatoryinformation

Europe

ThisproductcomplieswiththeapplicableCEmarkingdirectives

andharmonizedstandards:

•ElectromagneticCompatibility(EMC)Directive2014/30/EU.See

Electromagneticcompatibility(EMC)onpage2.

•LowVoltage(LVD)Directive2014/35/EU.SeeSafetyonpage3.

•RestrictionsofHazardousSubstances(RoHS)Directive201 1/65/EU.

SeeDisposalandrecyclingonpage3.
Acopyoftheoriginaldeclarationofconformitymaybeobtainedfrom
AxisCommunicationsAB.SeeContactinformationonpage3.

Electromagneticcompatibility(EMC)

Thisequipmenthasbeendesignedandtestedtofulllapplicable
standardsfor:

•Radiofrequencyemissionwheninstalledaccordingtothe

instructionsandusedinitsintendedenvironment.

•Immunitytoelectricalandelectromagneticphenomenawhen

installedaccordingtotheinstructionsandusedinitsintended

environment.

USA

Thisequipmenthasbeentestedusingashieldednetworkcable(STP)
andfoundtocomplywiththelimitsforaClassBdigitaldevice,
pursuanttopart15oftheFCCRules.Theselimitsaredesigned
toprovidereasonableprotectionagainstharmfulinterferenceina
residentialinstallation.Thisequipmentgenerates,usesandcanradiate
radiofrequencyenergyand,ifnotinstalledandusedinaccordance
withtheinstructions,maycauseharmfulinterferencetoradio
communications.However,thereisnoguaranteethatinterference
willnotoccurinaparticularinstallation.Ifthisequipmentdoes
causeharmfulinterferencetoradioortelevisionreception,which
canbedeterminedbyturningtheequipmentoffandon,theuseris
encouragedtotrytocorrecttheinterferencebyoneormoreofthe
followingmeasures:

•Reorientorrelocatethereceivingantenna.

•Increasetheseparationbetweentheequipmentandreceiver.

•Connecttheequipmentintoanoutletonacircuitdifferentfrom

thattowhichthereceiverisconnected.

•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

Theproductshallbeconnectedusingashieldednetworkcable(STP)
thatisproperlygrounded.

Canada

ThisdigitalapparatuscomplieswithCANICES-3(ClassB).Theproduct
shallbeconnectedusingashieldednetworkcable(STP)thatis
properlygrounded.Cetappareilnumériqueestconformeàlanorme
CANNMB-3(classeB).Leproduitdoitêtreconnectéàl'aided'uncâble
réseaublindé(STP)quiestcorrectementmisàlaterre.

Europe

ThisdigitalequipmentfulllstherequirementsforRFemission
accordingtotheClassBlimitofEN55032.Theproductshallbe
connectedusingashieldednetworkcable(STP)thatisproperly
grounded.

Australia/NewZealand

ThisdigitalequipmentfulllstherequirementsforRFemission
accordingtotheClassBlimitofAS/NZSCISPR32.Theproductshall
beconnectedusingashieldednetworkcable(STP)thatisproperly
grounded.

Japan

この装置は、クラスB情報技術装置です。この装置は、家
庭環境で使⽤することを⽬的としていますが、この装置が
ラジオやテレビジョン受信機に近接して使⽤されると、受
信障害を引き起こすことがあります。取扱説明書に従って
正しい取り扱いをして下さい。本製品は、シールドネット
ワークケーブル(STP)を使⽤して接続してください。また
適切に接地してください。

Korea

이기기는가정용(B급)전자파적합기기로서주로가정에
서사용하는것을목적으로하며,모든지역에서사용할수
있습니다.적절히접지된STP(shieldedtwistedpair)케이
블을사용하여제품을연결하십시오.

Safety

ThisproductcomplieswithIEC/EN/UL62368-1,safetyofaudio/video
andITequipment.

Ifitsconnectingcablesareroutedoutdoors,theproductshallbe
groundedeitherthroughashieldednetworkcable(STP)orother
appropriatemethod.

Thepowersupplyusedwiththisproductshallfullloneofthe
followingrequirements:

•SafetyExtraLowVoltage(SELV)accordingtoclause2.2of

IEC/UL60950-1andLimitedPowerSource(LPS)accordingto
clause2.5ofIEC/UL60950-1orCEC/NECClass2sourceofsupply
asdenedintheCanadianElectricalCode,CSAC22.1andNational
ElectricalCode,ANSI/NFPA70

•Class1electricalenergysource(ES1)andClass2powersource

(PS2)ratedoutputpowerlimitedto≤100Waccordingto
IEC/UL62368-1

Battery

TheAxisproductusesa3.0VBR/CR1220lithiumbatteryasthepower
supplyforitsinternalreal-timeclock(RTC).Undernormalconditions
thisbatterywilllastforaminimumofveyears.

LowbatterypoweraffectstheoperationoftheRTC,causingittoreset
ateverypower-up.Whenthebatteryneedsreplacing,alogmessage
willappearintheproduct’sserverreport.Formoreinformationabout
theserverreport,seetheproduct´ssetuppagesorcontactAxissupport.

Thebatteryshouldnotbereplacedunlessrequired,butifthebattery
doesneedreplacing,contactAxissupportataxis.com/supportfor
assistance.

Lithiumcoincell3.0Vbatteriescontain1,2-dimethoxyethane;ethylene
glycoldimethylether(EGDME),CASno.1 10-71-4.

WARNING

•Riskofexplosionifthebatteryisincorrectlyreplaced.

•Replaceonlywithanidenticalbatteryorabatterywhichis

recommendedbyAxis.

•Disposeofusedbatteriesaccordingtolocalregulationsor

thebatterymanufacturer'sinstructions.

Disposalandrecycling

Whenthisproducthasreachedtheendofitsusefullife,disposeof
itaccordingtolocallawsandregulations.Forinformationabout
yournearestdesignatedcollectionpoint,contactyourlocalauthority
responsibleforwastedisposal.Inaccordancewithlocallegislation,
penaltiesmaybeapplicableforincorrectdisposalofthiswaste.

Europe

Thissymbolmeansthattheproductshallnotbedisposedof
togetherwithhouseholdorcommercialwaste.Directive2012/19/EU
onwasteelectricalandelectronicequipment(WEEE)isapplicablein
theEuropeanUnionmemberstates.Topreventpotentialharmto
humanhealthandtheenvironment,theproductmustbedisposed
ofinanapprovedandenvironmentallysaferecyclingprocess.For
informationaboutyournearestdesignatedcollectionpoint,contact
yourlocalauthorityresponsibleforwastedisposal.Businessesshould
contacttheproductsupplierforinformationabouthowtodispose
ofthisproductcorrectly .

ThisproductcomplieswiththerequirementsofDirective201 1/65/EUon
therestrictionoftheuseofcertainhazardoussubstancesinelectrical
andelectronicequipment(RoHS).

China

有毒有害物质或元素

部
件
名
称

电
气
实
装
部
分

0:表示该有毒有害物质在该部件所有均质材料中的含量均在
GB/T26572标准规定的限量要求以下。

X:表示该有毒有害物质至少在该部件的某一均质材料中的含
量超出GB/T26572标准规定的限量要求。

Contactinformation

AxisCommunicationsAB
Emdalavägen14
22369Lund
Sweden

Tel:[phone]
Fax:[phone]

axis.com

铅

(Pb)

X

汞

(Hg)

00000

镉

(Cd)

六价

铬

(Cr(VI)
)

多溴

联苯

(PBB)

多溴
二苯
醚

(PBDE)

Support

Shouldyourequireanytechnicalassistance,pleasecontactyourAxis
reseller.Ifyourquestionscannotbeansweredimmediately,your
resellerwillforwardyourqueriesthroughtheappropriatechannelsto
ensurearapidresponse.IfyouareconnectedtotheInternet,youcan:

•downloaduserdocumentationandsoftwareupdates

•ndanswerstoresolvedproblemsintheFAQdatabase.Search

byproduct,category ,orphrase

•reportproblemstoAxissupportstaffbyloggingintoyourprivate

supportarea

•chatwithAxissupportstaff

•visitAxisSupportataxis.com/support

Warrantyinformation

ForinformationaboutAxis’productwarrantyandtheretorelated
information,gotoaxis.com/warranty

Learnmore!

VisitAxislearningcenteraxis.com/academyforusefultrainings,
webinars,tutorialsandguides.

ThisproductcomplieswiththerequirementsofSJ/T1 1364-2014,
Markingfortherestrictionofhazardoussubstancesinelectricaland
electronicproducts.

AXISP1265NetworkCamera

TableofContents

Safetyinformation..........................................6

Hazardlevels...................................................6

Othermessagelevels.............................................6

Productoverview...........................................7

Aboutthesensorunits...........................................8

Howtoshortenthesensorunitcable...............................8

Howtoaccesstheproduct....................................10

Howtoaccesstheproductfromabrowser...........................10

HowtoaccesstheproductfromtheInternet.........................10

Howtosettherootpassword.....................................10

Abouttheliveviewwindow.......................................11

Aboutmediastreams........................................13

AboutH.264format.............................................13

AboutMJPEGformat............................................13

AboutAXISMediaControl(AMC)...................................13

Alternativemethodsofaccessingthevideostream....................14

Howtosetuptheproduct....................................16

Howtoperformabasicsetup.....................................16

Aboutvideosettings........................................17

Howtosetupvideostreams......................................17

Aboutstreamproles............................................19

AboutONVIFmediaproles.......................................20

Aboutcamerasettings...........................................20

Aboutoverlays..................................................20

Aboutprivacymasks.............................................22

Howtoconguretheliveviewwindow.........................23

Howtosetdefaultviewerforbrowsers..............................23

Aboutviewersettings............................................23

Aboutuser-denedlinks..........................................23

Aboutapplications..........................................24

Aboutapplicationlicenses........................................24

Howtouploadandstartanapplication.............................24

ApplicationConsiderations........................................24

Aboutevents...............................................25

Howtosetupactionrules........................................25

Howtoaddrecipients............................................26

Howtocreateschedules..........................................28

Howtosetuprecurrences........................................28

Aboutrecordings...........................................29

Howtondrecordings...........................................29

Howtoplayrecordings...........................................29

Howtoexportavideoclip........................................30

Aboutcontinuousrecording.......................................30

Aboutlanguages............................................31

Aboutsystemoptions........................................32

Security.......................................................32

Date&Time....................................................34

Network.......................................................35

Storage.......................................................40

Maintenance...................................................42

Support.......................................................43

Advanced......................................................43

Howtoresettofactorydefaultsettings.............................44

Troubleshooting............................................45

Howtocheckthecurrentrmware.................................45

Howtoupgradethermware.....................................45

Symptoms,possiblecausesandremedialactions......................46

Specications..............................................49

SDcardslot....................................................49

Buttons.......................................................49

Connectors....................................................49

4

AXISP1265NetworkCamera

TableofContents

Performanceconsiderations.......................................50

5

AXISP1265NetworkCamera

Safetyinformation

Safetyinformation

Hazardlevels

DANGER

Indicatesahazardoussituationwhich,ifnotavoided,willresultindeathorseriousinjury.

WARNING

Indicatesahazardoussituationwhich,ifnotavoided,couldresultindeathorseriousinjury .

CAUTION

Indicatesahazardoussituationwhich,ifnotavoided,couldresultinminorormoderateinjury.

NO

TICE

NO NO

TICE TICE

Indicatesasituationwhich,ifnotavoided,couldresultindamagetoproperty.

Othermessagelevels

Important

Indicatessignicantinformationwhichisessentialfortheproducttofunctioncorrectly.

Note

Indicatesusefulinformationwhichhelpsingettingthemostoutoftheproduct.

6

AXISP1265NetworkCamera

Productoverview

Productoverview

AXISP12MkIIMainUnit

1
2
3
4
5

StatusLED
Controlbutton
RJ12connector
Networkconnector(PoE)
SDcardslot(microSDcard)

7

AXISP1265NetworkCamera

Productoverview

AXISFA1 125SensorUnit

1

Mountingbracket

2

Mountingnut

3

Sensorunit

4

Micro-USBcable

5

Sensorunitcable

6

RJ12connector

Aboutthesensorunits

Werecommendthatyouconnectthesensorunitstothemainunitbeforepoweringthemainunit.Ifyoudisconnectasensorunit,
andconnectadifferentsensorunit,itmaybenecessarytorestartthemainunit.

Howtoshortenthesensorunitcable

Note

Thiscablecanonlybeshortened,notextendedormodiedinanyotherway.

Thesensorunitisdeliveredwithacable.Toshortenthecablefollowthesesteps:

1.Cutthecabletothedesiredlength.Measurefromthesensorunit.

2.Striptheplasticoutercoatingfromtheendofthecable.

3.Peelbacktheshield.

4.Flattenthecoloredwiresintheorderdescribedbelow.

8

AXISP1265NetworkCamera

Productoverview

1

2

3

4

5

6

NO

TICE

NO NO

TICE TICE

Makesurethatthewiresstayinthecorrectorderandthatthecableshieldmakesgoodcontactwiththeconnectorshield.

5.Insertthewiresallthewayintoashielded6P6CRJ12connector.

6.Useacrimpingtooltofastentheconnectortothecable.

Brown

White/brown

Notused

Notused

White/blue

Blue

9

AXISP1265NetworkCamera

Howtoaccesstheproduct

Howtoaccesstheproduct

ToinstalltheAxisproduct,seetheInstallationGuidesuppliedwiththeproduct.

Theproductcanbeusedwithmostoperatingsystemsandbrowsers.Werecommendthefollowingbrowsers:

•InternetExplorer

•Safari

•Chrome

ToviewstreamingvideoinInternetExplorer,allowinstallationofAXISMediaControl(AMC)whenprompted.

TheAxisproductincludesone(1)H.264decoderlicenseforviewingvideostreams.ThelicenseisautomaticallyinstalledwithAMC.
Theadministratorcandisabletheinstallationofthedecoderstopreventinstallationofunlicensedcopies.

Note

•QuickTime

®

withOSX

TM

®

withWindows

®

orFirefox

TM

®

withotheroperatingsystems.

isalsosupportedforviewingH.264streams.

®

Howtoaccesstheproductfromabrowser

1.Startawebbrowser.

2.EntertheIPaddressorhostnameoftheAxisproductinthebrowser’saddresseld.

ToaccesstheproductfromaMaccomputer(OSX),gotoSafari,clickonBonjourandselecttheproductfromthe
drop-downlist.

IfyoudonotknowtheIPaddress,useAXISIPUtilitytolocatetheproductonthenetwork.Forinformationabout
howtodiscoverandassignanIPaddress,seethedocumentAssignanIPAddressandAccesstheVideoStreamonAxis
Supportwebataxis.com/support

Note

ToshowBonjourasabrowserbookmark,gotoSafari>Preferences.

3.Enteryourusernameandpassword.Ifthisisthersttimetheproductisaccessed,therootpasswordmustrstbe
congured.

4.Theproduct’sliveviewpageopensinyourbrowser.

HowtoaccesstheproductfromtheInternet

Onceconnected,theAxisproductisaccessibleonyourlocalnetwork(LAN).ToaccesstheproductfromtheInternetyoumust
congureyournetworkroutertoallowincomingdatatrafctotheproduct.Todothis,enabletheNAT-traversalfeature,which
willattempttoautomaticallyconguretheroutertoallowaccesstotheproduct.ThisisenabledfromSetup>SystemOptions>
Network>TCP/IPAdvanced.

Formoreinformation,seeNATtraversal(portmapping)forIPv4onpage37.

ForTechnicalnotesonthisandothertopics,visittheAxisSupportwebatwww.axis.com/support

SeealsoAXISInternetDynamicDNSServiceatwww .axiscam.net

Howtosettherootpassword

ToaccesstheAxisproduct,youmustsetthepasswordforthedefaultadministratoruserroot.ThisisdoneintheCongureRoot
Passworddialog,whichopenswhentheproductisaccessedforthersttime.

10

AXISP1265NetworkCamera

Howtoaccesstheproduct

Topreventnetworkeavesdropping,therootpasswordcanbesetviaanencryptedHTTPSconnection,whichrequiresanHTTPS
certicate.HTTPS(HypertextTransferProtocoloverSSL)isaprotocolusedtoencrypttrafcbetweenwebbrowsersandservers.The
HTTPScerticateensuresencryptedexchangeofinformation.SeeHTTPSonpage32.

Thedefaultadministratorusernamerootispermanentandcannotbedeleted.Ifthepasswordforrootislost,theproductmustbe
resettothefactorydefaultsettings.SeeHowtoresettofactorydefaultsettingsonpage44.

TosetthepasswordviaastandardHTTPconnection,enteritdirectlyinthedialog.

TosetthepasswordviaanencryptedHTTPSconnection,followthesesteps:

1.ClickUseHTTPS.

Atemporarycerticate(validforoneyear)iscreated,enablingencryptionofalltrafctoandfromtheproduct,andthe
passwordcannowbesetsecurely.

2.Enterapasswordandthenre-enterittoconrmthespelling.

3.ClickOK.Thepasswordhasnowbeencongured.

Abouttheliveviewwindow

Thecontrolsandlayoutoftheliveviewwindowmayhavebeencustomizedtomeetspecicinstallationrequirementsanduser
preferences.Consequently,someoftheexamplesandfunctionsfeaturedheremaydifferfromthosedisplayedinyourownliveview
window.Thefollowingprovidesanoverviewofeachavailablecontrol.

Aboutthecontrolsintheliveviewwindow

SelectastreamprolefortheliveviewwindowfromtheStreamProledrop-downlist.Forinformation
abouthowtocongurestreamproles,seepage19.

UsetheManualTriggerbuttontotriggeranactionrulefromtheliveviewwindow.Forinformation
abouthowtocongureandenablethebutton,seeAboutthemanualtriggeronpage1 1.

ClickSnapshottosaveasnapshotofthevideoimage.Thisbuttonisprimarilyintendedforusewhen
theAXISMediaControlviewertoolbarisnotavailable.EnablethisbuttonfromLiveViewCong>
ActionButtons.

Aboutthemanualtrigger

TheManualTriggerisusedtotriggeranactionrulefromtheLiveViewpage.Themanualtriggercanforexamplebeusedto
validateactionsduringproductinstallationandconguration.

Tocongurethemanualtrigger:

1.GotoSetup>Events.

2.ClickAddtoaddanewactionrule.

3.FromtheTriggerdrop-downlist,selectInputSignal.

4.Fromtheseconddrop-downlist,selectManualTrigger.

5.Selectthedesiredactionandconguretheothersettingsasrequired.

Formoreinformationaboutactionrules,seeAbouteventsonpage25.

ToshowthemanualtriggerbuttonsintheLiveViewpage:

11

AXISP1265NetworkCamera

Howtoaccesstheproduct

1.GotoSetup>LiveViewCong.

2.UnderActionButtons,selectShowmanualtriggerbutton.

AbouttheAXISMediaControlviewertoolbar

TheAXISMediaControlviewertoolbarisavailableinInternetExploreronly.SeeAboutAXISMediaControl(AMC)onpage13for
moreinformation.Thetoolbardisplaysthefollowingbuttons:

ThePlaybuttonconnectstotheAxisproductandstartsplayingamediastream.

TheStopbuttonstopsthemediastream.

TheSnapshotbuttontakesasnapshotofthevideoimage.

ClicktheViewFullScreenbuttonandthevideoimagewilllltheentirescreen.PressESC(Escape)onthecomputer
keyboardtocancelfullscreenview.

TheRecordbuttonisusedtorecordthecurrentvideostreamonyourcomputer.Thelocationwheretherecordingissaved
canbespeciedintheAMCControlPanel.EnablethisbuttonfromLiveViewCong>ViewerSettings.

12

AXISP1265NetworkCamera

Aboutmediastreams

Aboutmediastreams

TheAxisproductprovidesseveralvideostreamformats.Yourrequirementsandthepropertiesofyournetworkwilldeterminethe
typeyouuse.

TheliveviewwindowintheproductprovidesaccesstoH.264andMotionJPEGvideostreams,andtothelistofavailablestream
proles.Otherapplicationsandclientscanaccessvideostreamsdirectly,withoutgoingviatheliveviewwindow.

AboutH.264format

H.264can,withoutcompromisingimagequality,reducethesizeofadigitalvideolebymorethan80%comparedwiththeMotion
JPEGformatandasmuchas50%morethantheMPEG-4standard.Thismeansthatmuchlessnetworkbandwidthandstoragespace
arerequiredforavideole.Orseenanotherway,muchhighervideoqualitycanbeachievedforagivenbitrate.

Decidingwhichcombinationofprotocolsandmethodstousedependsonyourviewingrequirements,andonthepropertiesof
yournetwork.TheavailableoptionsinAXISMediaControlare:

UnicastRTP

RTPoverRTSP

RTPoverRTSPoverHTTP

MulticastRTP

AXISMediaControlnegotiateswiththeAxisproducttodeterminethetransportprotocoltouse.Theorderofpriority ,listedinthe
AMCControlPanel,canbechangedandtheoptionsdisabled,tosuitspecicrequirements.

Note

H.264islicensedtechnology.TheAxisproductincludesoneH.264viewingclientlicense.Installingadditionalunlicensed
copiesoftheclientisprohibited.Topurchaseadditionallicenses,contactyourAxisreseller.

Thisunicastmethod(RTPoverUDP)isused
forliveunicastvideo,especiallywhenitis
importanttohaveanup-to-datevideostream,
evenifsomeframesaredropped.

Thisunicastmethod(RTPtunneledoverRTSP)
isusefulasitisrelativelysimpletocongure
rewallstoallowRTSPtrafc.

Thisunicastmethodcanbeusedtotraverse
rewalls.Firewallsarecommonlyconguredto
allowtheHTTPprotocol,thusallowingRTPto
betunneled.

Thismethod(RTPoverUDP)shouldbeusedforlivemulticastvideo.Thevideostreamisalways
up-to-date,evenifsomeframesaredropped.
Multicastingprovidesthemostefcientusageofbandwidthwhentherearelargenumbersof
clientsviewingsimultaneously.Amulticastcannothowever,passanetworkrouterunlessthe
routerisconguredtoallowthis.ItisnotpossibletomulticastovertheInternet,forexample.
Notealsothatallmulticastviewerscountasoneunicastviewerinthemaximumtotalof10
simultaneousconnections.

Unicastingisusedforvideo-on-demand
transmissionsothatthereisnovideotrafc
onthenetworkuntilaclientconnectsand
requeststhestream.
Notethatthereareamaximumof10
simultaneousunicastconnections.

AboutMJPEGformat

ThisformatusesstandardJPEGstillimagesforthevideostream.Theseimagesarethendisplayedandupdatedataratesufcient
tocreateastreamthatshowsconstantlyupdatedmotion.

TheMotionJPEGstreamusesconsiderableamountsofbandwidth,butprovidesexcellentimagequalityandaccesstoeveryimage
containedinthestream.TherecommendedmethodofaccessingMotionJPEGlivevideofromtheAxisproductistousetheAXIS
MediaControlinInternetExplorerinWindows.

AboutAXISMediaControl(AMC)

AXISMediaControl(AMC)inInternetExplorerinWindowsistherecommendedmethodofaccessinglivevideofromtheAxisproduct.

13

AXISP1265NetworkCamera

Aboutmediastreams

TheAMCControlPanelcanbeusedtocongurevariousvideosettings.PleaseseetheAXISMediaControlUser’sManualformore
information.

TheAMCControlPanelisautomaticallyinstalledonrstuse,afterwhichitcanbecongured.OpentheAMCControlPanelfrom:

•WindowsControlPanel(fromtheStartscreenorStartmenu)

•Alternatively,right-clickthevideoimageinInternetExplorerandclickSettings.

Alternativemethodsofaccessingthevideostream

YoucanalsoaccessvideoandimagesfromtheAxisproductinthefollowingways:

•MotionJPEGserverpush(ifsupportedbytheclient,ChromeorFirefox,forexample).ThisoptionmaintainsanopenHTTP
connectiontothebrowserandsendsdataasandwhenrequired,foraslongasrequired.

•StillJPEGimagesinabrowser.Enterthepathhttp://<ip>/axis-cgi/jpg/image.cgi

•WindowsMediaPlayer.ThisrequiresAXISMediaControlandtheH.264decodertobeinstalled.Thefollowingpaths
canbeused:

-UnicastviaRTP:axrtpu://<ip>/axis-media/media.amp

-UnicastviaRTSP:axrtsp://<ip>/axis-media/media.amp

-UnicastviaRTSP,tunneledviaHTTP:axrtsphttp://<ip>/axis-media/media.amp

-Multicast:axrtpm://<ip>/axis-media/media.amp

•QuickTime

TM

.Thefollowingpathscanbeused:

-rtsp://<ip>/axis-media/media.amp

-rtsp://<ip>/axis-media/media.3gp

14

AXISP1265NetworkCamera

Aboutmediastreams

Note

•<ip>=IPaddress

•TheAxisproductsupportsQuickTime6.5.1andlater.

•QuickTimemayaddlatencytothevideostream.

•ItmaybepossibletouseotherplayerstoviewtheH.264streamusingthepathsabove,althoughAxisdoesnotguarantee

this.

15

AXISP1265NetworkCamera

Howtosetuptheproduct

Howtosetuptheproduct

TheAxisproductcanbeconguredbyuserswithadministratororoperatorrights.Toopentheproduct’ssetuppages,clickSetupin
thetopright-handcorneroftheliveviewwindow.

•Administratorshaveunrestrictedaccesstoallsettings.

•Operatorshaverestrictedaccesstosettings,seeUsersonpage32

Seealsotheonlinehelp

.

Howtoperformabasicsetup

BasicSetupprovidesshortcutstothesettingsthatshouldbemadebeforeusingtheAxisproduct:

1.Users.Seepage32.

2.TCP/IP.Seepage35.

3.Date&Time.Seepage34.

4.VideoStream.Seepage17.

TheBasicSetupmenucanbedisabledfromSystemOptions>Security>Users.

16
