Avycon AVC-BHN51AVT-AI-SL Specsheet

FUNCTIONS

DIMENSIONS

AVC-BHN51AVT-AI-SL

5MP SMART DEFENDER BULLET IP CAMERA

. . . . . . . . . . . . . . .

OPTIONAL ACCESSORIES

5MP H.265 Real Time Encoding

Maximum Resolution: 2592 x 1944 Motorized 2.8 - 12mm Zoom Lens

Smart IR Illumination Up to 164ft.

True Day/Night

True WDR

Hardware Reset

Built-in Micro SD Card Slot

Supports Three Streams

NAT/P2P Function Optional Integrated Speaker and Warning LEDs to alert intruders

when motion (Standard & Advanced) is detected Video Analytics: Line Crossing, Scene Change, Region

Intrusion, Video Tampering, etc. Supports Mobile Monitoring by Smart Phones with iOS and

Android OS IP67 Outdoor Rating

DC12V / PoE (802.3af) <11W

5MP SMART DEFENDER BULLET IP CAMERA

5MP SMART DEFENDER BULLET IP CAMERA WITH ADVANCED VIDEO ANALYTICS

The AVC-BHN51AVT-AI-SL is a 5MP H.265 Bullet IP Camera with a motorized 2.8 - 12mm auto-focus lens and featuring our newest generation of video analytics, with an integrated speaker and LEDs to warn intruders when their motion is detected. This camera supports True Day/Night mode, True WDR capabilities and also includes a microSD memory card slot for standalone recording applications. The AVC-BHN51AVT-AI-SL can be powered by both PoE(802.3af) and DC12V and also includes a hardware reset button. Integrated Video Analytics include Missing/Abandoned Objects, Line Crossing, Heat Map, Vehicle/People Counting and Facial Detection.

Unit : inch (mm)

8.57 in (217.7mm)

3.17 in (80.5mm)

AVM-BDMT-W-TL1

CAMERA

SPECIFICATIONS

. . . . . . . . . . . . . . .

AVC-BHN51AVT-AI-SL

5MP SMART DEFENDER BULLET IP CAMERA

Image Sensor

Resolution

Image Size

Electronic Shutter

Iris Type

IR Distance

Min. Illumination

Angle Adjustment

Wide Dynamic Range

Backlight Compensation (BLC)

VIDEO STREAM

Max. Image Resolution

Primary Stream

Secondary Stream

Tertiary Stream

Video Compression

Video Bit Rate

Image Settings

Network Storage

Remote Monitoring

Online Connections

Audio Compression

Advanced Function

Video Analytics

Visual Warning

Auditory Warning

Supported Protocols

Power Consumption

Hardware Reset

Ingress Protection

Working Environment

Working Humidity

Lens

Lens Mount

Digital NR

Defog

HLC

Sharpness

Language

NETWORK

Ethernet

Protocol

AUDIO

Audio I/O

SYSTEM

Alarm

Local Storage

Event Trigger

GENERAL

Input Voltage

Weight

Dimensions

1/2.7” Progressive Scan CMOS 5MP 2592 x 1944 1/25s to 1/100,000s DC Iris Up to 164ft. (50m)

0.008luxF1.4(AGC ON), 0Lux with IR ON Motorized 2.8mm - 12mm Zoom Lens @F1.4; Horizontal Field of View: 92.7°~29.8° Ø14 Pan: 0°~360°, Tilt: 0°~90°, Rotation: 0°~360° 120dB Yes (3D DNR) Yes Yes Yes Yes Support for 12 Different Languages

2592 x 1944 (2592 x 1944): 30fps

(2592 x 1520, 2560 x 1440, 2304 x 1296, 1920 x 1080, 1280 x 720): 30fps (1920 x 1080, 1280 x 720): 60fps (High Frame Rate) (1280 x 720, 720 x 480, 480 x 240, 352 x 240): 30fps (720 x 480, 480 x 240, 352 x 240): 30fps

Smart H.265 / H.265+ / H.265 / Smart H.264 / H.264+ / H.264 / MJPEG 64 Kbps~8Mbps (CBR / VBR Adjustable) ROI, Saturation, Brightness, Chroma, Contrast, Wide Dynamic, Sharpen, NR, etc.

1 x RJ45 10M / 100M Ethernet Port Network Remote Storage Web Browser Interface, AVYCON CVMS / CVMS 2.0 Supports Up to 6 Concurrent Users UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, SNMP, HTTP, 802.1x, UPnP, HTTPs, QoS

G711A / U 1/1; 1(Built-in Speaker)

1/1 Built-in Micro SD Card Slot; Up to 128 GB Video Masking, Illegal Login Lock, Watermarking, IP Address Filtering, Heartbeat Tracking, Sensor Alarm Motion Detection, IP Address Conﬂict, Cable Disconnection, SD Card Error, SD Card Full Region Entrance, Region Exit, Intrusion Detection, Line Crossing Detection, Video Tampering Detection, Scene Change Detection 3 LEDs, Can be Conﬁgured When Motion is Detected Built-in Speaker, can be conﬁgured when motion is detected

ONVIF Proﬁles S and G DC 12V (±10%) / PoE(802.3af) <11W Yes IP67

-22°~140° F (-30°~60° Celcius) <95% (Non-Condensing)

1.4lbs

8.57" x 3.17" (217.7mm x 80.5mm)

phone: 949-752-7606 email: info@avycon.com social: @avycon_aivo website: avycon.com
