Installation Manual 1/5/98
Table of Contents
Required Installation Tools .......................2
Important Information.......................... 2
Wiring Diagram.............................. 3
11 Pin Con nec tor.............................. 4
2 Pin Con nec tor .............................. 4
Installation Procedures..........................5
Con trol Unit................................ 5
An tenna .................................. 5
Wir eloom.................................. 5
Valet Switch ................................5
LED In di ca tor...............................6
Ig ni tion In put................................6
Chan nel 2 Ac ces sory Out put........................6
Park ing Light Out put............................ 6
In te rior Light Trig ger ...........................7
Op tional In te rior Light Il lu mi na tion Out put................ 7
Starter Dis able Out put ........................... 7
Door Lock/Un lock Out puts ........................ 8
Hood/Trunk Pin Switch ..........................8
Si ren .................................... 8
Power and Ground Con nec tions...................... 8
Door Lock Diagrams.......................... 9-11
Programming Alarm System Features.................12
Pro gram ming Ta ble for Alarm Fea tures ................. 12
Programming Your Re mote Con trols ................. 13
Pro gram ming Ta ble for Re mote Con trols ................ 13
Tornado
2
2
Installation Manual 1/5/98
Required Installation Tools
Voltmeter
Wire Strippers
Electric Drill & Bits
Phillips Screw Driver
Convoluted Tubing *
Solder Gun *
Wire Crimpers
Shrink Tube or Electrical Tape
* Op tional
Important Information
1.Test all circuits with a voltmeter.
2. Make all wiring connections with butt connectors. DO NOT twist wires
or use "scotch-lok" connectors.
3. Route RED, RED/WHITE and BLACK wires from the control unit
directly to the battery.
4. Keep extensions as short as possible. Use same gauge wires for short
extensions and larger gauge wires for longer extensions.
5. Before installing, discuss the placement of the LED indicator and valet
switch with the vehicle owner. DO NOT disconnect the battery cables.
6.Make all connections by removing the lug from the cable clamp
without detaching clamp.
7. Turn off dome light or remove dome light fuse to prevent battery drain.
This de vice com plies with Part 15 of the FCC rules. Any changes or
modi fi ca tions made to the sys tem with out the ex press ap proval of
Avi tal Tech nolo gies, Inc. could void the user's author ity to op er ate this
equip ment.
3
2
Tornado
Installation Manual 1/5/98
Wiring Diagram
Tornado
4
2
Installation Manual 1/5/98
11 Pin Con nec tor
Wire color De scrip tion
Red/Black Parking Light Output
Red Battery (+)
Gray (-) Armed Output for Optional Starter Disable Relay
Black Battery (-)
Violet Siren (-) Output
Tan Hood/Trunk (-) Input
White/Black Interior Light Illumination (-) Output/Requires Optional Relay
Dark Blue Channel 2 (-) Accessory Output
White Door Trigger Input (+) or (-)
Pink Ignition Switched +12 Volt Input
Red/White Parking Light Polarity Select (+) (-)
2 Pin Con nec tor
Wire color De scrip tion
Blue/White (-) Door Lock Output
Green/White (-) Door Unlock Output
Tornado
5
2
Installation Manual 1/5/98
Installation Procedures
Con trol Unit
1. Select a location under the dash that will allow you to use tie wraps to
securely fasten the control unit.
2. Mount the control unit as high as possible to ensure maximum range.
3. Do not mount the control unit near moving parts.
4. Avoid areas that are in the direct path of air blowing from the vents.
5. Route wires from this point, leaving slack for ease of service.
An tenna
1. Do not shorten or lengthen the antenna.
2. Route the antenna away from the control unit.
3. Keep the antenna as far away from metal and wire harnesses as possible
to optimize range.
Wir eloom
1. Plug the wireloom securely into the control unit.
2. Route wires from the control unit directly to each connection point.
3. Separate the RED, BLACK, RED/WHITE, VIOLET and TAN wires.
4. Sleeve the wires with vinyl tubing or electrical tape and route them
through an existing rubber grommet into the engine compartment.
5. If an existing grommet is not available, drill a hole and install a snap
grommet.
Valet Switch
1. Discuss placement with the owner.
2. Choose a location for the valet switch that is hidden, but convenient for
the owner to access.
3. Drill a ¼" hole and mount the switch.
4. Route the valet switch wires to the control unit.
5. Plug the valet switch BLUE connector into the control unit BLUE plug.
6
2
Tornado
Installation Manual 1/5/98
LED In di ca tor
1. Discuss placement with the owner.
2. Choose a location that is visible from both sides of the vehicle.
3. Drill a ¼" hole.
4. Route the LED wires through the hole and press LED into place.
5. Route the LED wires to the control unit.
6. Plug the RED LED connector into the control unit RED plug.
Ig ni tion In put
1. Use a voltmeter to locate the one wire that shows +12 volts when the
ignition key is in the "ON," "CRANK" and "RUN" position, and 0 volts
when the ignition key is in the "OFF" position.
2. Connect the control unit PINK wire to the vehicle’s ignition wire.
Chan nel 2 Ac ces sory Out put
The DARK BLUE wire provides a 0.75 second ground (-) output when the
remote control button #2 is activated for 1-2 seconds. If the remote control
button #2 is continuously pressed, the signal will stay at ground as long as the
button is held. Most trunk releases are positive and require an optional relay.
Park ing Lights
1. If the parking lights are positive trigger, connect the RED/WHITE wire
to the battery positive (+) terminal through the 20 amp fuse.
NOTE: Do not connect the RED/WHITE wire to the control unit RED
wire.
2. If the parking lights are negative (-) trigger, connect the RED/WHITE
wire to control unit BLACK wire.
3. Connect the RED/BLACK wire to the vehicle parking light wire.
In te rior Light Trig ger
7
2
Tornado
Installation Manual 1/5/98
The Tornado2 interior light trigger wire is programmable to accept a positive
(+) or negative (-) input. The module is factory preset for negative (-) door
trigger.
1. Connect the alarm WHITE wire to the vehicle door trigger wire(s).
2. If the vehicle door trigger is positive (+) trigger, follow the "Door
Trigger Input Polarity" section in the "Programming Table for Alarm
Features" to program the module for positive (+) door trigger.
In te rior Light Il lu mi na tion Out put
The WHITE/BLACK wire provides a current limited (-) output for 30
seconds upon remote disarm. Interior light illumnination requires an
optional relay.
1. Connect the alarm WHITE/BLACK wire to relay terminal 85.
2. Connect relay terminal 86 to a fused constant +12 volt source.
3. Connect relay terminal 30 to the vehicle door trigger wire(s).
4. If the vehicle door trigger is positive (+) trigger, connect relay terminal
87 to a fused +12 volt source.
5. If the vehicle door trigger is negative (-) trigger, connect relay terminal
87 to ground (-).
Starter Dis able Out put
The alarm GRAY wire provides a continual ground output while the alarm is
armed. Starter disable requires an optional 30 amp relay.
1. Connect the alarm GRAY wire to relay terminal 85.
2. Connect relay terminal 86 to an ignition switched +12 volt source
(alarm module PINK wire).
3. Locate the ignition switch wireloom under the dashboard.
4. Use a voltmeter to find the one wire that will show +12 volts while the
ignition key is in the cranking cycle only. This should be the starter
solenoid wire.
5. Cut the starter solenoid wire in half. Test by trying to crank the starter.
If it will not crank, you have the correct wire.
6. Connect one end of the starter wire to relay terminal 87A.
7. Connect the other end of the starter wire to relay terminal 30.
Door Lock/Un lock Out puts
Tornado
8
2
Installation Manual 1/5/98
The alarm provides a .75 second 300 MA (-) output for lock and unlock.
Follow the door lock diagrams on pages 9 - 11.
Hood/Trunk Pin Switch
1. Locate the vehicle hood or trunk pin switch that shows ground when
the hood or trunk is open only.
2. Connect the alarm module to the vehicle hood or trunk switch wire.
3. If the vehicle does not have a hood or trunk switch, install an alarm pin
switch and connect it to the alarm module TAN wire.
Si ren
1. Choose a location in the engine compartment away from high heat
engine components, moving parts and direct exposure to water.
2. Make sure the siren and siren wires cannot be seen or reached from
below the vehicle.
3. Mount the siren with the two self tapping screws to a solid metal surface.
4. Connect the siren BLACK wire to the alarm module VIOLET wire.
5. Connect the siren RED wire to the alarm module RED wire.
Power and Ground Con nec tions
Caution: Do not plug in the system fuses until the final step below.
1. Connect the alarm RED wire to one of the supplied fuse assemblies.
2. Connect the alarm RED/WHITE wire to the other fuse assembly (if the
vehicle parking lights are (+) positive).
3. Connect the fuse assembly(s) to one of the supplied 10mm ring
terminals.
4. Connect the alarm BLACK wire to the other 10mm ring terminal.
5. Remove the (+) and (-) battery bolts. Do not disconnect the battery
clamps.
6. Connect the empty fuse assembly(s) to the positive battery post.
7. Connect the alarm BLACK wire to the battery negative post.
8. Inspect all alarm wiring. Make sure all wires are connected.
9. Install the 5 amp fuse in the alarm module RED wire fuse assembly.
10. Install the 20 amp fuse in the alarm module RED/WHITE fuse
assembly (if the vehicle parking lights are positive).
Tornado
9
2
Installation Manual 1/5/98
Tornado
10
2
Installation Manual 1/5/98
Tornado
11
2
Installation Manual 1/5/98
One Wire Door Lock/Unlock
(Mer cedes/Audi)
Tornado
12
2
Installation Manual 1/5/98
Programming Alarm System Features
All programmable alarm features are accomplished by turning the ignition
key on (or starting the vehicle) and flicking the valet switch on and off a
pre-set number of times.
1. Remove the alarm from valet. Programming cannot be accessed while
the alarm is in the valet mode indicated by the LED on solid red.
2. Select the feature you wish to program from the "Programming Table
for Alarm Features." Note the number of chirps.
3. Turn the ignition key to the "ON" position.
4. Within 10 seconds, begin flicking the valet switch on and off. The siren
will chirp once each time you flick the switch on then off.
5. Continue flicking the switch on and off until you reach the number of
chirps associated with your chosen feature.
NOTE: Stop on the chirp.
6. After a 3 second pause, you will hear 1 or 2 chirps noted to confirm
that you have changed the setting of that feature.
7. Turn the ignition key off.
8. Repeat steps 1-7 for any other feature you wish to program.
Pro gram ming Ta ble for Alarm Fea tures
Fea ture
Passive/Active
Arming
Passive Door
Locking
Remote Arming
Siren Chirps
Door Trigger
Polarity Select
Fac tory
Set ting
Passive ON 4
OFF 5
ON 6
(-) Trigger 7
# of
Chirps
Sec on dary Ac tion
Wait 3 seconds, the siren chirps once for active or
twice for passive.
Wait 3 seconds, the siren chirps once for OFF or
twice for ON.
Wait 3 seconds, the siren chirps once for OFF or
twice for ON.
Wait 3 seconds, the siren chirps once for (+) trigger
or twice for (-) trigger.
Tornado
13
2
Installation Manual 1/5/98
Programming Your Re mote Con trols
The Tornado2 allows you to add new remote controls in one step, delete lost
or stolen remote controls or rearrange the factory preset remote control
functions.
All remote control programming features are accomplished by turning the
ignition key on (or starting the vehicle) and flicking the valet switch on and
off a preset number of times.
1. Remove the alarm from valet. Programming cannot be accessed while
the alarm is in the valet mode, indicated by the alarm LED on solid red.
2. Select the feature from the "Programming Table for Remote Controls."
Note the number of chirps.
3. Turn the ignition key to the "ON" position.
4. Within 10 seconds, begin flicking the valet switch on and off. The siren
will chirp one time each time you flick the switch on then off.
5. Continue flicking the valet switch on and off until you reach the
number of chirps associated with your chosen feature.
NOTE: Stop on the chirp.
6. Follow the "Secondary Action."
7. Turn the ignition key off.
8. Repeat steps 1-7 for any other feature you wish to program.
Pro gram ming Ta ble for Re mote Con trols
Fea ture
Arm/Disarm/Remote
Panic
Accessory (-) Output Channel 2 9
Silent Arm/Disarm Channel 3 10
All Channel Learn — 11
Instant Code
Deletion
Fac tory
Set ting
Channel 1 8
— 12
Chirps
Tornado
# of
Press any remote control button you choose to operate
this feature. Siren will chirp once for confirmation.
Press any remote control button you choose to operate
this feature. Siren will chirp twice for confirmation.
Press any remote control button you choose to operate
this feature. Siren will chirp 3 times for confirmation.
Press button #1. The siren will chirp 1 time. Remote
control will operate at factory preset order.
Wait 3 seconds. The siren will chirp twice. All remote
controls are erased from memory.
14
2
Installation Manual 1/5/98
Sec on dary Ac tion
© Copy right 1998 Avi tal Tech nolo gies, Inc. 32-3273/T2IM/98
15
2
Tornado
Installation Manual 1/5/98
Loading...
