AVerMedia Technologies EB1304 MPEG4+ User Manual

AVerMedia®
AVerDiGi EB1304 MPEG4+
Operation Manual
FCC NOTICE (Class A)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Federal Communications Commission Statement
NOTE- This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
CAUTION ON MODIFICATIONS
To comply with the limits for the Class A digital device, pursuant to Part 15 of the FCC Rules, this device must be installed in computer equipment certified to comply with the Class A limits. All cables used to connect the computer and peripherals must be shielded and grounded. Operation with non-certified computers or non-shielded cables may result in interference to radio or television reception.
Changes and modifications not expressly approved by the manufacturer could void the user’s authority to operate this equipment.
European Community Compliance Statement (Class A)
This product is conformity with the protection requirements of EU Council Directives 89/336/EEC amended by 92/31/EEC on the laws of the Member States relating to electromagnetic compatibility.
Warning - This is a Class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures to correct this interference.
DISCLAIMER
No warranty or representation, either expressed or implied, is made with respect to the contents of this documentation, its quality, performance, merchantability, or fitness for a particular purpose. Information presented in this documentation has been carefully checked for reliability; however, no responsibility is assumed for inaccuracies. The information contained in this documentation is subject to change without notice.
In no event will AVerMedia be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of such damages.
TRADEMARKS
AVerMedia is registered trademarks of AVerMedia TECHNOLOGIES, Inc. IBM PC is a registered trademark of International Business Machines Corporation. Macintosh is a registered trademark of Apple Computer, Inc. Microsoft is a registered trademark and Windows is a trademark of Microsoft Corporation. All other products or corporate names mentioned in this documentation are for identification and explanation purposes only, and may be trademarks or registered trademarks of their respective owners.
COPYRIGHT
© 2006 by AVerMedia TECHNOLOGIES, Inc. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any means without the written permission of AVerMedia TECHNOLOGIES, Inc.
THE MARK OF CROSSED-OUT WHEELED BIN INDICATES THAT THIS PRODUCT MUST NOT BE DISPOSED OF WITH YOUR OTHER HOUSEHOLD WASTE. INSTEAD, YOU NEED TO DISPOSE OF THE WASTE EQUIPMENT BY HANDING IT OVER TO A DESIGNATED COLLECTION POINT FOR THE RECYCLING OF WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT. FOR MORE INFORMATION ABOUT WHERE TO DROP OFF YOUR WASTE EQUIPMENT FOR RECYCLING, PLEASE CONTACT YOUR HOUSEHOLD WASTE DISPOSAL SERVICE OR THE SHOP WHERE YOU PURCHASED THE PRODUCT.
Battery Safety Information
- Store the ba tteries in a cool dry place.
- Do not dispose of used batteries in domestic waste. Dispose of batteries at special collection points or
return to point of sale if applies.
- Remove the batteries during long periods of non-use. Always remove exhausted batteries from the remote control. Battery leakage and corrosion can damage this remote control, dispose of batteries safely.
- Do not mix old and new batteries.
- Do not mix different types of batteries: alkaline, standard (carbon-zinc) or rechargeable
(nickel-cadmium).
- Do not dispose of batteries in a fire. The batteries may explode or leak.
- Never short circuit the batte ry termina ls.
WARNING
TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE
CAUTION
IF THERE IS ANY DAMAGE, SHORTAGE OR INAPPROPRIATE
ITEM IN THE PACKAGE, PLEASE CONTACT WITH YOUR LOCAL
DEALER. WARRANTY VOID FOR ANY UNAUTHORIZED
PRODUCT MODIFICATION
Table of Contents
Chapter 1 Introduction ......................................................................1
1.1 Package Content........................................................................................ 2
1.2 Features and Specifications....................................................................... 2
1.3 Front Panel ................................................................................................ 3
1.4 Back Panel................................................................................................. 4
1.5 Setting Up the DVR Unit ............................................................................ 4
1.5.1 Installing the Hard Disk.......................................................................... 4
1.5.2 Connecting Devices............................................................................... 7
1.5.3 Connecting the Sensor/Relay device.....................................................8
Chapter 2 Operating the EB1304 MPEG4+.......................................9
2.1 Using the EB1304 MPEG4+ for the First Time ...........................................9
2.2 Surveillance Screen ...................................................................................9
2.3 Playback the Video .................................................................................. 10
2.3.1 To Playback Video ...............................................................................10
Chapter 3 OSD Navigation Tree......................................................12
3.1 Remote Control Function .........................................................................13
3.2 Menu Function ......................................................................................... 14
Chapter 4 Using the USB Player ....................................................19
4.1 Recommended system requirements....................................................... 19
4.2 Installing the USB Playback Application................................................... 19
4.3 Running the USB Playback Application....................................................20
4.3.1 To Cut and Save the Portion of the Recorded Video ........................... 21
Chapter 5 Backup and View Recorded Video File.........................22
5.1 Recommended system requirements....................................................... 22
5.2 To Backup Recorded Video File ...............................................................22
5.3 To View the Backup File...........................................................................24
5.3.1 To Cut and Save the Recorded Video..................................................25
Chapter 6 ImageVerification ...........................................................27
6.1 To Run the ImageVerification ................................................................... 27
Chapter 7 Warranty Notice..............................................................28
Chapter 1 Introduction
EB1304 MPEG4+ is a 4-channel stand-alone DVR unit that provides real-time
monitoring and digital recording of surveillance video. Up to four video cameras
and four sensor devices can be hooked up to this DVR unit. It is also equipped with
an output relay that allows connection of an alarm device.
Surveillance, digital recording and playback are controlled through the front panel
buttons. With the On-Screen-Display (OSD) menu, user can customize video
recording setting, sensor and alarm settings, password protection, hard drive
recycling, and more. Through USB connection, user can playback the video with
the bundled software, segment the video to only keep the wanted portion and save
it in MPG/AVI format, and capture still image and save it in BMP format or print it.
Surveillance video is recorded in high-quality MPEG4 format. Two recording modes
are supported, D1 Mode can record video from each video camera in 720 x 480
resolution at 60fps and CIF Mode can record video in 360 x 240 resolution and up
to 120 fps/100 fps (NTSC/PAL).
Connecting cameras, sensors, alarm, and display device
1
1.1 Package Content
+
®
4
a
G
i
E
d
e
P
M
M
r
4
e
0
V
3
A
1
B
E
i
G
i
D
r
l
e
a
u
V
n
a
A
M
n o i
t a r
e
p
O
(1)
(2)
(3)
(4)
(5)
(6)
(8)
(7)
(1) AVerDiGi EB1304 MPEG4+ unit
(2) Remote Control (batteries included)
(3) Quick Installation Guide
(4) Power Cord
* The power cord varies depending on the standard power outlet of
the country where it is sold.
(5) Power Adapter
(6) DVR accessories (including 4 screws)
(7) Software CD (User Manual included)
(8) USB Cable
1.2 Features and Specifications
Non-PC stand-alone security digital video recorder
4 composite video inputs and 1 composite output
VGA output for LCD and CRT monitor display
OSD control
2
MPEG4 video compression
Auto-detect NTSC or PAL video system
Supports 1 hard disk drive (not included)
Full-screen resolution:
Display: 720 x 480 (NTSC), 720 x 576 (PAL)
Recording: 720 x 480 (NTSC), 720 x 576 (PAL)
Display and recording frame rate:
D1 mode: 60/50fps(NTSC/PAL)
CIF mode: 120/100 fps (NTSC/PAL)
Scheduled recording (00:00~23:00 set by hour )
Search for recorded videos by date/time/event
Input/Output: 4 sensor inputs and 1 relay output control
Multiple language operation screens
One USB 2.0 Port
Software CD with USB playback application for Windows 2000/XP
1.3 Front Panel
(1)(2) (3) (4)
Name Function
(1) DVR Power LED
(2) HDD LED
(3) IR Sensor
(4) USB 2.0 Port
: Light when the unit is on
: Indicate the hard disk running state. Light when the HDD is
running
:
Receive the signal from the remote control to operate the unit
:
Connect to PC for video transfer or playback
3
1.4 Back Panel
Name Function
(1) Audio Out : Output the audio signal to a speaker
(2) Audio In : Input the audio signal from a microphone or audio output device.
The audio is embedded with channel 1
(3) CH1 : Input the video camera signal and display it on channel 1
(4) CH2 : Input the video camera signal and display it on channel 2
(5) CH3 : Input the video camera signal and display it on channel 3
(6) CH4 : Input the video camera signal and display it on channel 4
Output the video signal to a TV (7) Video Out :
The DVR unit support 2 video output ports and you can only select to output the video either from the VGA OUT or
(8) VGA OUT : Output the video signal to a CRT or LCD monitor
(9) Sensor In &
Alarm Out
(10) TV-VGA : Switch to select the video output. Make sure to set the video output
(11) 12V DC : Connect the power adapter into this port
: Support up to 4 sensor device and 1 relay device (Relay: 1A @
125V AC/30V DC)
before turning on the unit
VIDEO OUT
1.5 Setting Up the DVR Unit
1.5.1 Installing the Hard Disk
The DVR unit allows you to install one hard disk. Before installing the hard disk,
make sure to set the hard disk master jumper setting. Adjust the jumper setting
according to the instructions on the hard disk label.
i
Use 40GB/ 7200RPM IDE hard disk or larger is recommended
4
Follow the illustrated instructions below to install the hard disk:
1. Loosen all screws
3. Loosen the hard disk rack 4 screws 4. Secure the brackets on the hard disk
2. Push the cover backward and lift
5. Connect the end of the IDE cable and the power connector to the hard disk
6. Secure the hard disk inside the unit then replace unit cover
5
You may now connect all the cables. When the power is connected, the Power
7. Push the cover forward
9. LED light
turns on
8. Secure the cover
6
