This system overview gives a high-level understanding of the core capabilities and features of the
BCM 4.0 upgrade. In addition, it also indicates what capabilities and features are not supported
with the BCM 4.0 upgrade.
Audience
This overview is for installers, network administrators, and anyone else who is interested in the
BCM 4.0 upgrade.
5
Acronyms
The following is a list of acronyms used in this guide.
AcronymDescription
OSOperating System
PVQMProactive Voice Quality Monitoring
QoEQuality of Experience
FRFrame Relay
PPPPoint-to-Point Protocol (PPP)
MCDNMeridian Customer Defined Network
TATTrunk Anti-Tromboning
TROTrunk Route Optimization
SIPSession Initiated Protocol
NCRINetwork Call Redirection Info
ICCLISDN Call Connection Limit
MWIMessage Waiting Indication
SHA1Secure Hashing Algorithm 1
SFTPSecure File Transfer Protocol
SNMPSimple Network Management Protocol
KEMKey Expansion Module
CDRCall Detail Records
BCM 4.0 System Overview
6Chapter 1 Getting started
AcronymDescription
MIBManagement Information Base
CIMCommon Information Model
DMTFDistributed Management Task Force
NCMNetwork Configuration Manager
CCRCustom Call Routing
VPIMVoice Profile for Internet Mail
AMISAudio Messaging Interchange Specification
ICCIntelligent Contact Center
CCCall Center
PSTNPublic Switched Telephone Network
CTIComputer Telephony Integration
LAN CTELocal Area Network Computer Telephony Engine
IVRInteractive Voice Response
Related publications
This section provides a list of additional documents for BCM 4.0. To locate specific information,
you can refer to the Master Index of BCM 4.0 Library.
CallPilot Fax Set Up and Operation Guide (P0606017)
CallPilot Message Networking Set Up and Operation Guide (N0027249)
BCM 4.0 Personal Call Manager User Guide (N0027256 02)
Contact Center Set Up and Operation Guide (N0060620)
BCM 4.0 LAN CTE Configuration Guide (N0060604)
BCM 4.0 Call Detail Recording System Administration Guide (N0060599)
N0060607
How to get Help
This section explains how to get help for Nortel products and services.
Getting Help from the Nortel Web site
The best way to get technical support for Nortel products is from the Nortel Technical Support
Web site:
http://www.nortel.com/support
This site provides quick access to software, documentation, bulletins, and tools to address issues
with Nortel products. More specifically, the site enables you to:
•download software, documentation, and product bulletins
•search the Technical Support Web site and the Nortel Knowledge Base for answers to
technical issues
•sign up for automatic notification of new software and documentation for Nortel equipment
•open and manage technical support cases
Getting started Chapter 17
Getting Help over the phone from a Nortel Solutions Center
If you don’t find the information you require on the Nortel Technical Support Web site, and have a
Nortel support contract, you can also get help over the phone from a Nortel Solutions Center.
In North America, call 1-800-4NORTEL (1-800-466-7835).
Outside North America, go to the following Web site to obtain the phone number for your region:
http://www.nortel.com/callus
Getting Help from a specialist by using an Express Routing Code
To access some Nortel Technical Solutions Centers, you can use an Express Routing Code (ERC)
to quickly route your call to a specialist in your Nortel product or service. To locate the ERC for
your product or service, go to:
http://www.nortel.com/erc
Getting Help through a Nortel distributor or reseller
If you purchased a service contract for your Nortel product from a distributor or authorized
reseller, contact the technical support staff for that distributor or reseller.
BCM 4.0 System Overview
8Chapter 1 Getting started
N0060607
Chapter 2
BCM 4.0 system overview
The Nortel Business Communications Manager Release 4.0 (BCM 4.0) brings the benefits
introduced with the BCM50 to the BCM200/400 platform. These benefits include a Linux
operating system (OS) which enhances product security and an improved operational cost model.
The BCM 4.0 release also builds upon previous BCM releases to continue to deliver a global,
industry leading enterprise solution for businesses of all types and sizes. These solution
enhancements include improvements in IP telephony solutions, applications and new features.
The BCM200/400 OS moves to the Nortel Corporate Linux which provides a more secure
environment, direct Nortel control over the operating system for fast issue resolution and BCM
portfolio migration to Linux which aligns with BCM50. Software upgrades for the installed base,
BCM200/400 and BCM1000, provide investment protection.
The new Element Manager support introduced with BCM50 provides improved system
programming and installation time; as well as on-going management tasks. Common operational
tasks such as performing backups and applying software updates will be easily handled with the
optimized tools included with the Element Manager. As well, support for Startup Profile
customizes the system level programming of the BCM200/400 as well as USB port support.
9
Enhancements to IP telephony include support for a new way of monitoring voice quality
(PVQM), new IP sets, SIP interoperability and features, and voice quality improvement for low
speed links (voice enabled WAN). These BCM VoIP improvements continue to allow BCM to
offer industry leading converged solutions.
Application enhancements include as the introduction of Intelligent Contact Centre, an evolution
of Call Centre with more granular agent and skillset selection, simplifying the product offering.
The BCM voice mail solution (CallPilot) also receives a series of enhancements there by
continuing to evolve this solution and its competitiveness.
BCM 4.0 excels in the areas of security, IP telephony, applications and Ad-Hoc conferencing.
Security improvements align with those introduced with BCM50 which provides a major advance
in the security paradigm for BCM. These improvements, along with the Linux operating system
provide a more secure environment for BCM users.
BCM 4.0 capabilities
BCM 4.0 is the next major software release for the BCM200 and BCM400 systems as well as the
installed base of BCM1000 systems. It provides an improved installation and operational cost
model and is built upon a Linux operating system, aligning these products with the BCM50
product. The BCM 4.0 release also brings enhanced VoIP and application capabilities as well as
the addition of ad-hoc conferencing to the BCM.
BCM 4.0 System Overview
10Chapter 2 BCM 4.0 system overview
Following is a detailed description of each of the incremental capabilities that BCM 4.0 will bring
to the BCM200/400 platform as well as to BCM1000 platform through software upgrades.
“Linux upgrade” on page 11•Improves security and replaces WinNTe end-of-life
“Management upgrade” on
page 14
“Proactive Voice Quality
Monitoring” on page 15
“Ad-Hoc Conferencing” on
page 15
“Meridian Customer-Defined
Network Trunk
Anti-Tromboning with
integrated applications” on
page 16
“Voice enabled WAN” on
page 16
“Session-initiated protocol
enhancements” on page 17
“Security enhancements” on
page 17
•Reduces installation and operations costs associated
with BCM with faster and easier programming,
remote administration and simplified operations
•Provides ability for proactive identification of voice
quality of experience (QoE) issues on a per-call basis
•Enables troubleshooting of voice quality issues on the
LAN
•Allows ad-hoc conference users to bring in more
participants as required and not be limited to three
•Optimizes network resource usage for call scenarios
involving applications, such as Auto Attendant and
voicemail
•Enables customers with low-speed links (PPP, FR) for
data / voice to experience improved QoS for voice
traffic
•Improves link utilization
•Enables greater application integration
•Enables H.323 users to migrate to SIP
•Provides increased security capabilities, addressing
a major area of customer concern
•Provides ubiquitous capabilities across the BCM
portfolio (enhancements introduced with BCM50 R1)
N0060607
“Terminal and mobility
support” on page 20
“Global market” on page 21•Multilingual voice prompts
“Intelligent Contact Centre”
on page 31
“CallPilot/Voicemail
enhancements” on page 30
•Expands the IP set portfolio to conference rooms
•Expands positioning of IP offering to those solutions
requiring IP KEM sets
•second dial tone
•12 digit support
•Ability to choose the number of agents and skillsets
that a customer or customer site requires
•Fills the gap between Basic and Professional CC
•Increased number of greeting tables
•Expands set-based programming
•Mailbox restrictions
•Citrix support
•Additional languages
BCM 4.0 system overview Chapter 211
BCM 4.0 capability restrictions
The following items are no longer supported with BCM 4.0 software release:
Companion
•Keycodes will be unavailable with BCM 4.0 and sets will no longer work
•BCM3.7 introduces a new digital mobility solution which will be supported with BCM 4.0
•T7406 cordless phone and 802.11 WLAN IP phones continue to be supported
Matra DECT
•KIRK DECT is the digital mobility solution on BCM and is available with BCM 3.7 and
supported with BCM 4.0
Symbol
•This product has not been available for order since May 2004
•Nortel WLAN Handsets 2210 and 2211 have been available since 2004. WLAN Handsets
2212 is now supported.
Miscellaneous Data Features
•PPTP functionality has been removed, although IP Sec will continue to be supported on
BCM 4.0
•Though a BCM 3.x system may use the Nortel Optivity Policy Server to push networking
policies to the BCM using COPS-PR, this functionality is unavailable in this release.
Local policies must be established using the Element Manager.
•Voice Applications: Mailbox/Operator Manager
— As with BCM50 R1, Mailbox Manager and Operator Manager will be unavailable
with BCM 4.0.
Support for USB is being introduced with BCM 4.0 for loading startup profiles and software
updates. Please be aware of the following limitations:
•BCM 4.0 adds support for USB port to BCM200/400
•BCM1000 USB continues to be unsupported
•BCM200/400 continues not to support UPS over USB
Linux upgrade
The WinNTe end-of-life drives the migration to a Linux-based operating system using Nortel
Corporate Linux. This provides ownership of the operating system, strategic direction, and direct
access to the operating system for fast issue resolution and ensuring an effective, long-term
support strategy within Nortel.
For customers concerned about potential WinNTe security vulnerability and whose systems are
accessible on a WAN or LAN, it is recommended you upgrade to BCM 4.0.
BCM 4.0 System Overview
12Chapter 2 BCM 4.0 system overview
Nortel corporate Linux
The BCM portfolio is now built upon Nortel Corporate Linux, which was developed for the high
reliability and secure carrier market. There have been no, significant Linux kernel issues in the two
years of exposure for Nortel Corporate Linux on the Compact Call Server product.
The BCM 4.0 software release is an important part of the BCM portfolio evolution in 2006. A
major part of this evolution includes a move to a more secure product on a Linux operating system.
This portfolio evolution was first introduced with the first release of the BCM50 and continues for
the BCM200/400 with the BCM 4.0 release.
BCM 4.0 will support the Linux operating system for the installed base of BCM200, BCM400 and
BCM1000 platforms through a software upgrade. All new BCM200/400 shipments will be Linux
-based BCM 4.0 as of the General Availability of BCM 4.0 system.
Nortel Linux OS has been tailored for the BCM platforms by restricting and removing OS
capabilities that are not required, providing a "hardening" of the OS. This hardening ensures that
extraneous capabilities are not potentially available to hackers.
The advantages of BCM built upon Nortel Corporate Linux include an improved security
environment, proven reliability, direct developer access to the operating system layer for fast issue
resolution and Nortel ownership of the strategic direction providing effective, long term support.
Nortel provides the ability to upgrade a BCM200/400/1000 system to a Linux operating system
with BCM 4.0, with the following key attributes:
•Upgrade supported from BCM3.6 or
BCM3.7 without hardware changes
•Upgrade target operational time of less
than 1.5 hours (BCM3.6 or BCM3.7
upgrade to BCM 4.0)
•Software-only upgrade; does not
require hardware upgrade
•Preserves telephony data and voicemail
programming data. Preservation is the goal,
with maximum preservation of other data
•Automatic transfer of existing system
keycode-enabled capabilities through the
BCM4.0 upgrade keycode generation
•Clearly defined upgrade steps and back-out
points, as in previous BCM releases
BCM 4.0 functionality and capability
BCM 4.0 upgrade will include functionality and capability equivalence or better to BCM3.7 in all
major areas, including:
•Telephony capability set (including
applications, core telephony, VoIP,
terminals, IVR)
•Data functionality equivalence
•Equivalent global country and
localization support
•Equivalent mobility and terminal
support
•Equivalent data capability set
•Integrated management of voice and data
capabilities
•Equivalent scalability to existing BCM3.7
scalability
•Equivalent connectivity and
•Terminals and mobility equivalency
•Single keycode generated for a release and
site capability set
interoperability
N0060607
BCM 4.0 system overview Chapter 213
BCM 4.0 dependencies
The eligibility for the upgrade is dependent on these upgrade paths:
Software
Release
BCM 3.6
BCM 3.7
BCM 3.5BCM200
BCM 3.0BCM200
BCM 2.5 / FP1BCM1000Hard drive replacement (20 GByte) and reprogram
BCM 2.0xBCM1000Hard drive replacement (20 GByte) and reprogram
Hardware
Platform
BCM200
BCM400
BCM1000
BCM400
BCM1000
BCM400
BCM1000
Recommended Upgrade Path
BCM 3.6 or BCM 3.7 to BCM 4.0
•Software Upgrade preserving customer data
BCM 3.5 to BCM 3.7 to BCM 4.0
•Software Upgrade preserving customer data
BCM 3.0 to BCM 3.6 to BCM 4.0
•Software Upgrade preserving customer data
customer data
•Requires 4.0 upgrade keycode
customer data
•Requires 4.0 upgrade keycode + 256Mb RAM
Note: The only supported 20 Gb HD is available through Nortel.
BCM 4.0 System Overview
14Chapter 2 BCM 4.0 system overview
Management upgrade
The new BCM 4.0 management system reduces the cost of selecting, deploying, and maintaining
BCM to minimize the cost of ownership and maximize system availability. BCM 4.0 adopts the
BCM50 Release 1 management model, which improves ease of use and remote management.
The table below presents common tasks and the advantages of BCM 4.0 over BCM 3.x.
TasksBCM3.xBCM 4.0 and BCM50 Release 1
Ease of UseManagement Tools•Multiple•Element Manager
Configuration
application
navigation
Speed of performing
common tasks
Remote configuration
(dial-up)
Software updates•Patch per problem, 2
MaintenanceRecord keeping•Lengthy manual
Diagnostic and
monitoring
InstallationIP assignment•Must be configured•DHCP, set-based
•Streamlined and task-based,
improving speed of tasks
•Optimized for speed
•Software update packages;
0-1 reboot per package;
scheduled loading and
activation; USB port loading
•Programming Record for
configuration print
•4 standard MIBs; 50% less
alarms with per alarm filtering
programming or start-up
profile
•Boot–Start-up Profile from
USB memory port and
defaults
See “BCM 4.0 Management” on page 22 for management system details, which includes
installation, remote management, on-box and device management features, set-based
administration, Element Manger, software updates and Network Configuration Manager.
N0060607
BCM 4.0 system overview Chapter 215
Proactive Voice Quality Monitoring
BCM4.0 introduces Proactive Voice Quality Monitoring (PVQM) on BCM. This capability
provides the ability to set call quality thresholds for IP sets and be alerted if these thresholds are
violated. This provides for the ability to proactively identify voice quality of experience (QoE)
issues on a per call basis. This, in turn, enables troubleshooting of voice quality issues within the
network.
PVQM supports calls from an IP set to any other set or trunk, and IP sets support auto notification.
Measured call quality metrics include:
•packet loss
•inter-arrival jitter
•listening R-value
•RTCP round trip delay.
Listener "R" value is a direct measure of the call quality or transmission quality, incorporating the
effects of CODEC type, packet loss, discard, burstiness, delay, and other relevant voice quality
metrics.
With PVQM. a system wide summary view is maintained of threshold violation alert occurrences.
Threshold violations can be sent as alarms and used by the centralized AppManager VoIP
performance monitoring product from NetIQ to generate a system wide view of the voice quality
of the network and help diagnose voice quality issues. The alarms include extensive call quality
information in accordance with IETF RTCP-XR RFC 3611.
PVQM advantages
•Provides ability to monitor quality and integrity of IP-based voice networking
•Significant differentiator in VoIP convergence network sales with its market-leading,
proactive, per call focus
•Mitigates customer issues over whether the data network or the BCM is at fault when there
are call-quality issues situations
•Consistency in QoE solution across Nortel enterprise call servers facilitates mixed
network deployments
Ad-Hoc Conferencing
Currently, the BCM supports three-party conferencing. Ad-Hoc Conferencing extends this
capability to support large multi-party conferencing.
Ad-Hoc Conferencing advantages
•User interface model is similar to today’s F3 conference.
•There is no impact on the user’s feature-button “footprint” (that is, there is no need for
additional IC keys or an additional feature key).
BCM 4.0 System Overview
16Chapter 2 BCM 4.0 system overview
•This extends the current three-party conferencing capabilities, allowing users the
flexibility to have larger multi-party conferences.
•Support up to 40 simultaneous ad-hoc participants on multiple conferences
Meridian Customer-Defined Network Trunk Anti-Tromboning with
integrated applications
The BCM currently uses MCDN signaling to optimize network resource utilization when
transferring or forwarding station-to-station calls. This feature adds the ability for applications
such as Voicemail and AutoAttendant to leverage these MCDN capabilities to optimize network
utilization.
MCDN TAT advantages
•Provides customers with optimal utilization of trunk facilities
•Enables a greater number of feasible networking scenarios for servicing customers
MCDN TAT applications
This feature allows the BCM to determine if calls routed across a network by the integrated
AutoAttendant or Voicemail should invoke the TAT or Trunk Route Optimization (TRO) MCDN
functionality to optimize the trunking network connection.
Voice enabled WAN
For low-speed Frame Relay and Point-to-Point Protocol (PPP) access to BCM through the WAN
interface, effective voice and data communications over this link require fragmentation and
compression. Fragmentation techniques allow data frames to be fragmented, meaning that voice
packets will not get “stuck” behind large data frames, avoiding the introduction of jitter to voice
calls. The use of Header Compression greatly reduces the overhead associated with sending voice
packets, allowing more efficient use of the available bandwidth.
This feature enables this support for fragmentation on both FR (FRF.12) and PPP (using
MultiLink PPP) and provides RFC2508 on the BCM WAN interface. This capability also adds
support for the WAN 520 card.
Voice enabled WAN advantages
•This enables customers with low speed PPP and Frame Relay links to experience
improved QoS for voice traffic and better link utilization.
•Many branch offices only require low-speed links for data transmission and tariffing. This
capability allows these offices to utilize these links for VoIP as well.
•Enhances the usability of the WAN card on the BCM.
N0060607
BCM 4.0 system overview Chapter 217
Voice enabled WAN applications
This is typically used for low speed links over Frame Relay and PPP which share Voice over IP
and data traffic.
Session-initiated protocol enhancements
BCM supports H.323 and SIP VoIP basic call communication for BCM-to-BCM calls. H.323 also
supports the same features that the MCDN (Meridian Customer Defined Network) capability
supports. This SIP enhancement adds the following to the BCM SIP capability:
•Support for the MCDN features with SIP
•Expands SIP interoperability to the CS1K and MCS5100
The MCDN features supported include:
•Private Name/Number
•Network Call Redirection Info (NCRI)
•Trunk Anti-Tromboning (TAT)
•ISDN Call Connection Limit (ICCL)
•Message Waiting Indication (MWI)
•Trunk Route Optimization (TRO)
SIP advantages
SIP allows you to begin to transition your entire network to use SIP signaling, which allows
greater application integration than can be achieved using H.323.
SIP applications
In enterprise network systems, the SIP feature provides the ability to support private numbering
plans, optimize the use of network traffic (TAT/TRO/ICCL), and provides support for centralized
voicemail applications (NCRI, MWI) using the SIP messaging protocol. By making these
capabilities available using the SIP protocol, you can begin to transition your network to the latest
standard.
Security enhancements
The security enhancements with BCM 4.0 are best described in the following sections:
•“User account access management” on page 17
•“Secure interface and audit logging” on page 19
User account access management
This feature significantly improves BCM user account access management by enhancing
password, session and account authentication and access management enhancements. These
improvements bring the BCM in alignment with the security enhancements being introduced with
BCM50 and add incremental capabilities.
BCM 4.0 System Overview
18Chapter 2 BCM 4.0 system overview
Password Management and Policy Enhancements:
•Minimize the vulnerability of passwords
— Password characteristics are now more stringent (length, criteria)
— Password aging, history and change notification added
— Forced password change on initial login
— Password storage hashing with Secure Hashing Algorithm 1 (SHA1)
Session Management Enhancements:
•Minimize the vulnerability of logged-in sessions
— Idle session time-out
Account Management
•Minimize the vulnerability of UserIDs
— Automatic disabling of unused accounts
— Set-based admin requires userID and password
Account UserID Access Privilege Management
•Logged-in userID session/access display
User account access management advantages
These enhancements to user account access management provide a more secure BCM access
environment, making it more difficult for a malicious user to gain access to a BCM.
User account access management applications
These enhancements allow owners of BCM to enforce more secure account access controls to the
BCM, to ensure secure management of the BCM and thereby increase protection against potential
vulnerabilities.
N0060607
BCM 4.0 system overview Chapter 219
Secure interface and audit logging
This feature enhances interface security by adding more secure access controls. It also adds
security audit logs, allowing capture of configuration changes and system activity by UserID, date
and time. These improvements bring the BCM in alignment with the security enhancements being
introduced with BCM50.
Secure Interface Access and Communications Controls provide:
•Support for Secure Copy (SFTP),
providing for SSH encrypted file
transfers
•Support for Simple Network
Management Protocol (SNMP) v2 & v3,
including encryption provided with v3
•BCM owner control of Nortel technical
support access
•Use of digital signatures and enhanced
tamper detection to ensure trusted sources
for software upgrades (patches, software
release upgrades)
•Ability to test the system’s ability to generate
alarms and logs, including system security
alarms and logs
Audit Log capabilities:
•Tracks of critical changes to system and login attempts
— Last successful login identification and interface
— Last failed login attempt, total failed logins since last successful login
— Configuration change log, tracking configuration changes to system by UserID
•RADIUS Support
— Centralized Authentication
— Radius Client to authenticate and authorize using a centralized Radius server
Secure interface and audit logging advantages
In addition to supporting IPsec tunnels for management, the ability to encrypt SNMP and file
transfers provides BCM users with an expanded capability set for secure interface
communications.
Audit logging of login attempts provides the BCM user with the ability to track security violation
attempts and determine if further action is required.
If a userID security breach is suspected as a result of system configuration changes, the audit
logging of configuration changes provides traceability to userIDs and interfaces.
Increased ease of use and reduce user lost productivity by ensuring system availability (protection
against DoS attacks). Reduced impacts of potential vulnerabilities, attacks and tampering and
reduced Administrative & Support overheads, lower OPEX expenses (RADIUS, User Account,
Password, Session by management of Security Policies).
Increase overall Security with effective logging capabilities for Audit Trail logs, Alarm logs,
Configuration Change logs.
BCM 4.0 System Overview
20Chapter 2 BCM 4.0 system overview
Secure interface and audit logging applications
A BCM user who requires improved interface access and communications security for alarm, log
and file transfers can use these enhancements. As well, a user can audit and identify the critical
system changes that were initiated by specific users.
Terminal and mobility support
The BCM 4.0’s Terminal and mobility support is equivalent to that of BCM3.7, and it now
supports two new IP telephones:
•“IP Audio Conference Phone 2033” on page 20
•“IP Key Expansion Module I24” on page 21
IP Audio Conference Phone 2033
The IP Audio Conference Phone 2033 expands the IP portfolio to conference rooms and delivers
high-quality audio.
IP Audio Conference Phone 2033
•Familiar Nortel user interface, emulates IP
Phone 2001
•Well-known Polycom design, acoustics
•Nortel branded, sold, supported
•Full duplex handsfree with 360° room coverage
•Expandable using extension microphones
•Local AC power option
•Color: Charcoal
•Icons for global market
•Future safe investment (enhancement through
firmware download)
IP Audio Conference Phone 2033 applications
•Ideal for conference rooms and executive offices
•Fosters collaboration and idea exchange
N0060607
BCM 4.0 system overview Chapter 221
IP Key Expansion Module I24
The I24 Key Expansion Module (KEM) expands the IP portfolio to conference rooms, delivers
high quality audio and features a large speed dial list.
I24 KEM
•Hardware module to expand line/feature
buttons
•Self-label display to customize desktop
•Connects through accessory port on IP Phone
2002 or IP Phone 2004
•Powered by host phone via accessory port
•BCM supports up to 5 KEMs per IP phone
•Maximum 20 sets per system with KEM
I24 KEM applications
•Ideal for Secretary and Health care
IP firmware
IP phones incorporate network management and security enhancements. The firmware can be
upgraded with a patch or call sever release providing:
•Enhanced VLAN (configured manually or with DHCP) and PC VLAN (configured
manually) tagging
•Enhanced display for local Network Diagnostic Utilities
Global market
BCM 4.0 delivers country and regulatory support equivalent to BCM3.7 and adds additional
support for Polish, Irish English, Finnish, Korean, and Turkish Voice prompts.
The following additional capabilities will be available with the BCM4.0 release.
•Addition of second dial tone for PRI/BRI
— In some markets, it is the responsibility of a PBX to provide a local tone to the
originating party (as opposed to the central office)
— This feature adds the ability to provide the local tone
•Increasing public received digit length from 7 to 12 digits
— Some markets require > 7 digit public received digits to support dial plans
BCM 4.0 System Overview
22Chapter 2 BCM 4.0 system overview
BCM 4.0 Management
You can quickly install, configure, and administer your BCM. These topics summarize the
BCM 4.0 management areas:
•“Ease of installation” on page 22
•“Remote management accessibility” on page 23
•“On-Box and device manageability features” on page 23
•“Set-Based administration” on page 24, for “no-PC” programming of most of the system
•“Element Manager” on page 25, an interface that supports all aspects of BCM 4.0 element
management
•“Software updates” on page 26
•“Network Configuration Manager” on page 27, for multi-element support
Ease of installation
For BCM 4.0 installations that require data networking, IP sets or VoIP trunking, BCM 4.0 can
function as a DHCP client to a network DHCP server for automated IP address assignment. BCM
4.0 can also be a DHCP server to provide both IP phone sets and a directly connected Element
Manager PC with their IP configuration.
If you use Norstar set-based programming, you can install and program BCM telephony and
applications through set-based administration. Also, installers who familiarize themselves with
set-based programming use a system connected telephone keypad to program the system without
requiring access to a PC.
All configuration programming can be done using the “Element Manager” on page 25.
Startup profile
To accelerate the initial installation programming of system-level parameters, you can use the
Startup Profile to quickly bring the BCM 4.0 to a basic operational state, ready to program,
without having to use Element Manager or set-based administration.
The Startup Profile is an easy-to-use template you can data-fill using Microsoft Excel.
The Startup Profile gives you a quick interface for defining parameters such as:
•system profile including country, telephony template and key voicemail attributes
•system IP parameters
•system-level telephony attributes to automatically create the system DNs
•keycode information through automated application of keycodes
•users and groups
You fill out the template, save it to a USB memory stick, and insert the memory stick into the USB
port of the BCM during the initial boot-up of the system. This information is read into BCM 4.0
and applied through a single restart sequence.
The Startup Profile is similar to the Quickstart Profile of the BCM200 and BCM400, but can be
data-filled and applied without requiring an IP connection to the unit, or a PC or telephone set. It
executes more quickly, and includes a broader scope of system-level parameters.
N0060607
BCM 4.0 system overview Chapter 223
Remote management accessibility
BCM 4.0 has an integrated analog modem that can accept an incoming modem call on any BCM
4.0 system line. You can configure the BCM 4.0 system to let the modem auto-answer a specific
line with configuration options. Remote users can also first initiate a voice call to a person or an
auto-attendant, who transfers the call to the modem.
The analog modem also supports callback for management access to the BCM 4.0, which can be
used to support auto-dialout on SNMP traps, and automated sending of Call Detail Records (CDR)
to a remote CDR collection point.
Although we do not recommend that you use the analog modem for transferring large files, the
modem gives you a flexible method of remote access to perform all programming tasks remotely.
BCM 4.0 gives you remote management capability with a high-speed connection. Tasks such as
transferring backup files to a remote destination, and transferring software update files, CDR
records and log files, can be more efficiently supported than over the analog modem.
On-Box and device manageability features
BCM 4.0 has an SNMPv3 interface that includes support for SNMP v1/v2 for management by
legacy SNMP managers. SNMPv3 delivers improved security features for SNMP device access.
BCM 4.0 supports the following versions of SNMP:
•SNMP v1 - the first implementation of SNMP; this version supports protocols such as IP
•SNMP v2C - provides improved efficiency and error handling
•SNMP v3 - provides improvements in security and privacy
Using the Element Manager, you can select which versions of SNMP you want the BCM 4.0 agent
to support.
Management Information Bases provide access to the managed objects of a system and specify the
format of traps. BCM 4.0 supports these standard Management Information Bases (MIBs) for
remote management:
•MIBII RFC 1213 - second version of the Management Information Base for use with
network management protocols in a TCP/IP-based internet. It includes System Group,
Interfaces Group, and is a baseline RFC implemented by data networking systems.
•Entity MIB RFC 2737 - describes managed objects used for managing multiple logical
and physical entities managed by a single SNMP agent.
•System Host MIB RFC 2790 MIB for managing host systems. Defines a set of objects
common across many computer system architectures that are useful for the management
of host computers, such as memory, CPU, and so on.
•SmallSiteEvent MIB for traps.
•RFC 2261 - SNMP Framework MIB.
BCM 4.0 System Overview
24Chapter 2 BCM 4.0 system overview
BCM 4.0 has adopted the Common Information Model (CIM) standard according to the industry
standards organization Distributed Management Task Force (DMTF), which provides a modeled
method of managing system programming parameters. BCM 4.0 uses the transport mechanism
CIM operations over HTTP using XML, also referred to as CIM-XML. The BCM 4.0 CIM-XML
interface provides a consistent way to manage data on the device, whether by the Element
Manager, NCM, or third-party network or service management applications.
Log management
BCM 4.0 log management includes, in addition to the component logs that are provided by
BCM200 and BCM400 systems, security logs, configuration change logs, alarm logs and system
logs.
Set-Based administration
BCM 4.0 gives you the ability to use a telephone interface to program much of the system.
Set-Based Administration benefits:
•BCM 4.0 installations that do not have TCP/IP connectivity
•BCM 4.0 installations where the installer does not have access to a computer on-site
•speed of programming
•familiarity with the Norstar interface
With set-based administration, you can manage:
•core telephony
•voicemail services
•IP network settings
•keycode entry
•admin password change
•modem on/off
Multiple languages are supported, consistent with Norstar set-based administration.
N0060607
BCM 4.0 system overview Chapter 225
Element Manager
Element Manager gives you access to BCM 4.0 information in a new off-box management
architecture. Element Manager has a task-based interface for greater ease of use.
If you have used Business Communications Manager Unified Manager, you will find that
performing common BCM 4.0 programming tasks is simpler, faster, and more information-rich on
Element Manager, which requires less clicking through the interface to get to tasks. You can get to
any programming screen in three mouse-clicks or less.
Programming data is organized in the Element Manager to quickly show all of the associations
between data in the form of tables. This eliminates having to look in multiple places to get a
system view of the programming.
Figure 1 Element Manager interface
Element Manager runs on a PC, and the information required to draw the screens is contained
locally within the client application. The only data transferred between Element Manager and the
BCM 4.0 are queries and actual data. Element Manager has familiar Microsoft Office-like
capabilities, such as the ability to sort information.
All of the traditional BCM administration tools have been integrated into Element Manager,
including managing backups and software updates.
Element Manager has an element navigation panel for organizing a network of elements. You can
manage multiple elements at the same time. After you connect to an element, you can perform
configuration and administration tasks.
BCM 4.0 System Overview
26Chapter 2 BCM 4.0 system overview
The Element Manager administration interface
Element Manager’s Administration management environment includes:
•BCM 4.0 diagnostic and maintenance tools, including BCM Monitor.
•Fault management for viewing BCM 4.0 alarms. You can set which alarms are displayed
in the Element Manager alarm browser and which alarms trigger an SNMP trap.
•Log management for off-box transfer of logs, including component logs and administrator
logs such as alarm log, security log, configuration change log, and system log.
•Software management tools for software updates (for example, for corrective software)
and software upgrades.
•Backup and restore. You can schedule configuration backups or application backups. An
application backup includes data generated through the day-to-day use of the on-box
applications as well as the configuration data. A scheduled backup provides the ability to
routinely perform a backup, which can be kept on the BCM 4.0 hard drive or transferred to
an off-box destination such as network folder, FTP server or locally attached USB storage
device.
For backup and restore, software management, and log management, a flexible set of source and
destinations is supported along with protocols to access them. For example, you can save backups
from the BCM 4.0 to either the USB port, the Element Manager client PC (on-demand only), a
shared drive available on the network, or a remote FTP server.
Software updates
To ensure that BCM 4.0 will be low-cost to maintain, even in an environment of security and
corrective content updates, this is how BCM 4.0 handles software updates:
•Software updates can be downloaded to the BCM 4.0, either on-demand or according to a
schedule. This flexible file transfer allows:
— Loading software updates from your computer, USB memory device, shared folder, or
FTP server or SFTP server under Element Manager
— From FTP server under centralized NCM control for bulk distribution to a network of
devices
•Update software is automatically checked against the BCM 4.0 software history and
validated before it is transferred. This means only the changes are downloaded, thereby
reducing the typical size of software updates.
•You can schedule the application of the software update separately. For example, you can
schedule a download for Tuesday night, but the application can be scheduled for Friday at
2 a.m.
•Multiple software update packages can be programmed to be applied at the same time.
•One software update package may include updates for multiple software components.
While many software updates will not require a system reboot, some software components
require a reboot for the update to take effect. There will be no more than one system reboot
if one or more of the software components being updated by the software update package
require a reboot.
•Software upgrades are handled in the same way and use the same tool as software updates.
N0060607
BCM 4.0 system overview Chapter 227
•You can set up the entire software update process for hands-off operation if the software
content can either be downloaded remotely, or sent out and installed from the USB port.
•Reliable file transfer
Keycodes
The BCM keycode structure has been redesigned with these capabilities:
•One keycode validates all feature entitlements, which simplifies installation.
•You can apply keycodes in a number of ways:
— through Element Manager
— through set-based administration
— through NCM
— through a USB memory stick
Network Configuration Manager
Many Business Communications Manager customers already use the optional client-server based
management application NCM to manage their multi-site BCM200/400 network. Designed to
provide a system-wide perspective for up to 2000 BCM devices, Network Configuration Manager
is a centralized database that stores information about every Business Communications Manager
device on your network.
NCM for BCM 4.0 includes centralized backup and restore management, common file distribution
(for example, system greeting files), parameter configuration, and automated software update
distribution. You can manage large BCM 4.0 networks and mixed BCM 4.0/200/400 networks
using the NCM.
BCM 4.0 System Overview
28Chapter 2 BCM 4.0 system overview
BCM 4.0 Applications
BCM 4.0 has a wide range of high-value applications. You enable these applications through
keycodes, and do not require any additional hardware.
BCM 4.0 gives you 32 voice ports for connecting to various applications. Each port supports one
connection to that application. For example, four callers could be leaving voice messages, and two
callers could be in the auto attendant while four callers are listening to voice messages. The
number of ports can adequately support a fully configured BCM 4.0 system.
BCM 4.0 comes with CallPilot Messaging. Keycoded optional applications are: Intelligent Contact
Center, Multimedia Contact Center, LAN CTE, Call Detail Recording, Personal Call Manager and
IVR.
CallPilot Messaging
CallPilot Messaging is a versatile business communications tool that you can use to:
•answer incoming calls
•offer callers a selection of options to route their calls or access information
•provide advanced voicemail, Auto Attendant and call handling capabilities
CallPilot Manager is a web-based application that is accessible through the BCM 4.0 Element
Manager. You use CallPilot Manager to set up and administer CallPilot.
N0060607
Figure 2 CallPilot Manager interface
BCM 4.0 system overview Chapter 229
Features included with CallPilot Messaging
Voicemail
Records messages and stores them in a mailbox for easy retrieval. Business telephones on your
system can have their own mailbox and greeting. Information can be distributed quickly to
departments and workgroups.
Auto Attendant
The CallPilot answering service that answers your business calls promptly, 24 hours a day, with a
Company Greeting, plays a list of options to callers, and performs call routing functions in
response to caller selections.
Custom Call Routing (CCR)
Enhances the Auto Attendant menu with customized menus and information messages. With CCR
you can determine the menu options and record the voice prompts that guide callers along call
paths.
Fax Answering
Fax Answering lets outside callers send faxes to the main site telephone number. Fax Answering is
available even if you do not have the Fax option installed on your system. With Fax Answering, a
fax call that arrives through the Auto Attendant or CCR transfers to a specified extension.
BCM 4.0 System Overview
30Chapter 2 BCM 4.0 system overview
CallPilot options
CallPilot has options that enhance your office communications. You need a keycode to enable a
CallPilot option. Contact your vendor if you want to purchase a software authorization code.
Message Networking
Message Networking links your CallPilot system with other voicemail systems and allows the
exchange of voice messages between users at different sites. CallPilot supports Voice Profile for
Internet Mail (VPIM) and Audio Messaging Interchange Specification (AMIS) networking.
For more information, see the CallPilot Message Networking Set Up and Operation Guide.
Fax
Fax is a CallPilot option that enhances your office communications by providing incoming and
outgoing fax capability. With Fax, callers can send and retrieve fax messages as easily as they send
and retrieve voice messages. The Fax option includes Fax Messaging, Fax On Demand and Fax
Overflow. Fax Answering is available even if you do not have the Fax option installed on your
system.
For more information about Fax, refer to the CallPilot Fax Set Up and Operation Guide. Fax is not
available for CallPilot 100/150.
Unified Messaging
With Unified Messaging, subscribers can use their e-mail application to access voice, fax and text
messages from their personal computer. Unified Messaging can be used with several popular
e-mail applications:
•Microsoft Outlook 2000, Outlook 2002 (XP), Outlook 2003 including Internet Mail Mode
For more information, see the BCM 4.0 Unified Messaging Configuration Guide.
CallPilot/Voicemail enhancements
The BCM 4.0 release builds upon the existing set of Call Pilot / Voicemail capabilities through the
introduction of a set of feature enhancements on the BCM CallPilot offering.
These enhancements include the following.
N0060607
•Significant increases in number of greeting tables, company greetings and Custom Call
Routing (CCR) trees
BCM 4.0 system overview Chapter 231
— This provides customers the flexibility to use different Auto Attendant / CCR for
different incoming lines.
•F983 Class Of Service Administration
— Expands set-base admin to include programming of Class of Service
•Prevention of trivial mailbox passwords
— This security enhancement will prevent "Trivial passwords" (e.g. 1111, 1234, etc.)
when enabled.
•Up to 5 alternate DNs per Mailbox with Message Waiting Indicator on 6 sets
— Previously up to 2 alternative DNs per Mailbox / MWI on 3 sets was supported
•Mailbox assignable feature restrictions
— Allows the administrator to limit features for selected mailboxes in the system. Great
feature for retail and hospitality industries.
•Unified Messaging R2.5 support of Citrix
— Unified messaging 2.5 will now be supported in a Citrix environment
•Ability to receive VPIM broadcast messages from M1 CallPilot
— The system can re-broadcast a network message from M1 without additional
programming
•Additional Voice Mail Prompt Languages
— Polish, Irish English, Finnish, Korean, Turkish
Intelligent Contact Centre
BCM4.0 introduces the Intelligent Contact Center (ICC) which is an evolution of the existing Call
Center (CC) capability on BCM. ICC will have the same functionality as the current Professional
Call Center with the ability to choose exactly the number of agents and skillsets that a customer or
customer site requires. This provides the following values with ICC:
•Maximum flexibility in granularity
•Any combination of Agents and Skillsets within boundaries of platform. Eliminates any
confusion of features between Basic and Professional. Channel partners and customers do
not have to worry about what functionality is contained with what product
— Intelligent Call Center with Professional Contact Center level of functionality.
•Significantly simplifies product offering
— Intelligent Call Center, x Skillsets, x Agents, RCC
— Eliminates Basic, Pro and upgrade between them
•Increases market potential
— Customers that require more Skillsets than agents
Example: Real Estate - 3 receptionists (3 agents) answering for 20 Real Estate Agents (20
skillsets)
— Big box retail - 3 receptionists (3 agents) answering for 12 Departments (12 skillsets).
Optional components that can be added include:
•x Agents, (keycodes offer granular selection of the number of desired agents)
BCM 4.0 System Overview
32Chapter 2 BCM 4.0 system overview
•x Skillsets, (keycodes offer granular selection of the number of desired skillsets)
•Reporting for ICC
•Multimedia ICC
For more information, see the Call Center Set Up and Operation Guide.
Multimedia Contact Center
Using the Multimedia Contact Center application, agents and callers can participate in multimedia
calls that include:
•speaking over a Public Switched Telephone Network (PSTN) voice connection
•text chatting
•exchanging and viewing Web pages
•viewing screen captures (sent by an agent to the caller)
Multimedia Contact Center supports two call types:
•Phone-and-browser calls (using PSTN), which integrate a standard voice call with a
Contact Center agent and a Multimedia Contact Center browser call session with
follow-me browsing, text chat, and screen capture push.
•Browser-only calls have the same browser features of phone-and-browser calls, but no
voice call component.
LAN CTE
BCM Computer Telephony Integration (CTI) products provide an interface between your personal
computer and your BCM 4.0 system. With these products, you can use telephony applications
through the Windows operating system to control your telephone.
One of the software components of BCM CTI is LAN CTE (Local Area Network Computer
Telephony Engine). LAN CTE provides an interface between your personal computer, your
telephone, and the BCM 4.0 system. With LAN CTE installed on your computer, you can run
LAN CTE or TAPI applications to communicate with and control your telephone.
For more information, see the BCM 4.0 LAN CTE Configuration Guide.
Call Detail Recording
Call Detail Recording (CDR) is an application that collects call activity. Each time a telephone call
is made to or from your company, CDR can record the information about the call. You can use the
information CDR collects to create reports about call activity. CDR also provides an interface to
third-party applications to allow for call accounting and billing.
For more information, see the BCM 4.0 Call Detail Recording System Administration Guide.
N0060607
BCM 4.0 system overview Chapter 233
Personal Call Manager
Personal Call Manager is a TAPI-based application that provides an easy-to-use interface between
your computer and your telephone. You use the telephone to speak with a caller. You can
customize your Address Book and your calls. Basic functions that Personal Call Manager
performs include making and answering calls, putting calls on hold, transferring calls, and making
conference calls.
For more information, see the BCM 4.0 Personal Call Manager User Guide.
Interactive Voice Response
IVR is an automated telephony application that prompts callers with a combination of recorded
menus and prompts, and real-time data from databases. Users enter digits from their touchtone
keypad that direct the Interactive Voice Response application to access databases and play
information back to the caller.
IVR is a call-handling system that allows employees to perform their jobs, and agents to make
sales, rather than answer frequently asked questions. Interactive Voice Response can distribute
calls, make announcements, and give callers access to relevant information from dynamic
databases 24 hours a day, 7 days a week.
