Avaya B5800 Overview

Avaya B5800 Branch Gateway Solution
Overview

Release 6.2

18-603903

June 2012

Issue 1

©

2012 Avaya Inc.

All Rights Reserved.

Notice

While reasonable efforts have been made to ensure that the
information in this document is complete and accurate at the time of
printing, Avaya assumes no liability for any errors. Avaya reserves the
right to make changes and corrections to the information in this
document without the obligation to notify any person or organization of
such changes.

Documentation disclaimer

“Documentation” means information published by Avaya in varying
mediums which may include product information, operating instructions
and performance specifications that Avaya generally makes available
to users of its products. Documentation does not include marketing
materials. Avaya shall not be responsible for any modifications,
additions, or deletions to the original published version of
documentation unless such modifications, additions, or deletions were
performed by Avaya. End User agrees to indemnify and hold harmless
Avaya, Avaya's agents, servants and employees against all claims,
lawsuits, demands and judgments arising out of, or in connection with,
subsequent modifications, additions or deletions to this documentation,
to the extent made by End User.

Link disclaimer

Avaya is not responsible for the contents or reliability of any linked Web
sites referenced within this site or documentation provided by Avaya.
Avaya is not responsible for the accuracy of any information, statement
or content provided on these sites and does not necessarily endorse
the products, services, or information described or offered within them.
Avaya does not guarantee that these links will work all the time and has
no control over the availability of the linked pages.

Warranty

Avaya provides a limited warranty on its Hardware and Software
(“Product(s)”). Refer to your sales agreement to establish the terms of
the limited warranty. In addition, Avaya’s standard warranty language,
as well as information regarding support for this Product while under
warranty is available to Avaya customers and other parties through the
Avaya Support Web site:
you acquired the Product(s) from an authorized Avaya reseller outside
of the United States and Canada, the warranty is provided to you by
said Avaya reseller and not by Avaya.

Licenses

THE SOFTWARE LICENSE TERMS AVAILABLE ON THE AVAYA
WEBSITE,
APPLICABLE TO ANYONE WHO DOWNLOADS, USES AND/OR
INSTALLS AVAYA SOFTWARE, PURCHASED FROM AVAYA INC.,
ANY AVAYA AFFILIATE, OR AN AUTHORIZED AVAYA RESELLER
(AS APPLICABLE) UNDER A COMMERCIAL AGREEMENT WITH
AVAYA OR AN AUTHORIZED AVAYA RESELLER. UNLESS
OTHERWISE AGREED TO BY AVAYA IN WRITING, AVAYA DOES
NOT EXTEND THIS LICENSE IF THE SOFTWARE WAS OBTAINED
FROM ANYONE OTHER THAN A V A Y A, AN A V A Y A AFFILIA TE OR AN
AVAYA AUTHORIZED RESELLER; AVAYA RESERVES THE RIGHT
TO TAKE LEGAL ACTION AGAINST YOU AND ANYONE ELSE
USING OR SELLING THE SOFTWARE WITHOUT A LICENSE. BY
INSTALLING, DOWNLOADING OR USING THE SOFTWARE, OR
AUTHORIZING OTHERS TO DO SO, YOU, ON BEHALF OF
YOURSELF AND THE ENTITY FOR WHOM YOU ARE INSTALLING,
DOWNLOADING OR USING THE SOFTWARE (HEREINAFTER
REFERRED TO INTERCHANGEABL Y AS “YOU” AND “END USER”),
AGREE TO THESE TERMS AND CONDITIONS AND CREATE A
BINDING CONTRACT BETWEEN YOU AND AVAYA INC. OR THE
APPLICABLE AVAYA AFFILIATE (“AVAYA”).

Avaya grants End User a license within the scope of the license types
described below. The applicable number of licenses and units of
capacity for which the license is granted will be one (1), unless a

HTTP://SUPPORT.AVAYA.COM/LICENSEINFO/ ARE

http://support.avaya.com. Please note that if

different number of licenses or units of capacity is specified in the
Documentation or other materials available to End User. “Designated
Processor” means a single stand-alone computing device. “Server”
means a Designated Processor that hosts a software application to be
accessed by multiple users. “Software” means the computer programs
in object code, originally licensed by Avaya and ultimately utilized by
End User, whether as stand-alone Products or pre-installed on
Hardware. “Hardware” means the standard hardware originally sold by
Avaya and ultimately utilized by End User.

License types

Designated System(s) License (DS). End User may install and use
each copy of the Software on only one Designated Processor, unless
a different number of Designated Processors is indicated in the
Documentation or other materials available to End User. Avaya may
require the Designated Processor(s) to be identified by type, serial
number, feature key, location or other specific designation, or to be
provided by End User to Avaya through electronic means established
by Avaya specifically for this purpose.

Copyright

Except where expressly stated otherwise, no use should be made of
materials on this site, the Documentation, Software, or Hardware
provided by Avaya. All content on this site, the documentation and the
Product provided by Avaya including the selection, arrangement and
design of the content is owned either by Avaya or its licensors and is
protected by copyright and other intellectual property laws including the
sui generis rights relating to the protection of databases. You may not
modify, copy, reproduce, republish, upload, post, transmit or distribute
in any way any content, in whole or in part, including any code and
software unless expressly authorized by Avaya. Unauthorized
reproduction, transmission, dissemination, storage, and or use without
the express written consent of Avaya can be a criminal, as well as a
civil offense under the applicable law.

Third-party components

Certain software programs or portions thereof included in the Product
may contain software distributed under third party agreements (“Third
Party Components”), which may contain terms that expand or limit
rights to use certain portions of the Product (“Third Party Terms”).
Information regarding distributed Linux OS source code (for those
Products that have distributed the Linux OS source code), and
identifying the copyright holders of the Third Party Components and the
Third Party Terms that apply to them is available on the A vaya Support
Web site:

Preventing Toll Fraud

“T oll fraud” is the unauthorized use of your telecommunications system
by an unauthorized party (for example, a person who is not a corporate
employee, agent, subcontractor, or is not working on your company's
behalf). Be aware that there can be a risk of Toll Fraud associated with
your system and that, if Toll Fraud occurs, it can result in substantial
additional charges for your telecommunications services.

Avaya Toll Fraud Intervention

If you suspect that you are being victimized by T oll Fraud and you need
technical assistance or support, call Technical Service Center Toll
Fraud Intervention Hotline at [phone] for the United States
and Canada. For additional support telephone numbers, see the Avaya
Support Web site:
vulnerabilities with Avaya products should be reported to Avaya by
sending mail to: [e-mail].

Trademarks

Avaya is a registered trademark of Avaya Inc.
Aura is a registered trademark of Avaya Inc.
All non-Avaya trademarks are the property of their respective owners,

and “Linux” is a registered trademark of Linus Torvalds.

http://support.avaya.com/Copyright.

http://support.avaya.com. Suspected security

2 Avaya B5800 Branch Gateway Solution Overview June 2012

Comments? [e-mail]

The trademarks, logos and service marks (“Marks”) displayed in this
site, the Documentation and Product(s) provided by Avaya are the
registered or unregistered Marks of Avaya, its affiliates, or other third
parties. Users are not permitted to use such Marks without prior written
consent from Avaya or such third party which may own the Mark.
Nothing contained in this site, the Documentation and Product(s)
should be construed as granting, by implication, estoppel, or otherwise,
any license or right in and to the Marks without the express written
permission of Avaya or the applicable third party.

Downloading Documentation

For the most current versions of Documentation, see the Avaya
Support Web site:

Contact Avaya Support

See the Avaya Support W eb site:
notices and articles, or to report a problem with your Avaya product.
For a list of support telephone numbers and contact addresses, go to
the Avaya Support Web site:
bottom of the page, and select Contact Avaya Support.

http://support.avaya.com.

http://support.avaya.com for product

http://support.avaya.com, scroll to the

Avaya B5800 Branch Gateway Solution Overview June 2012 3

4 Avaya B5800 Branch Gateway Solution Overview June 2012

Comments? [e-mail]

Contents

Chapter 1: B5800 Branch Gateway overview...................................................................

Management.............................................................................................................................................

Voicemail support options.........................................................................................................................

System components..................................................................................................................................

Supported telephones...............................................................................................................................

New in this release....................................................................................................................................

Chapter 2: Roadmap...........................................................................................................

High-level tasks for B5800 Branch Gateway and Avaya Aura® configurations........................................

High-level tasks for B5800 Branch Gateway and CS 1000 configurations...............................................

Related resources.....................................................................................................................................

User guides for supported telephones.............................................................................................

Additional documents for reference..................................................................................................

Avaya Mentor videos........................................................................................................................

Web sites..........................................................................................................................................

Index.....................................................................................................................................

7
7
9
9
12
15

19
19
20
21
21
26
27
27
29

Avaya B5800 Branch Gateway Solution Overview June 2012 5

6 Avaya B5800 Branch Gateway Solution Overview June 2012

Chapter 1: B5800 Branch Gateway

overview

The Avaya B5800 Branch Gateway is a flexible, cost-effective communications platform for enterprise
branch offices. It enables access via SIP to Avaya Aura® Session Manager in the enterprise center,
optional access to centralized PSTN trunking, and access to centralized applications, such as
conferencing, messaging, and more. The B5800 Branch Gateway solution provides centralized
management by Avaya Aura® System Manager and centralized licensing by WebLM.

B5800 Branch Gateways are deployed in the distributed branch user model. In the distributed branch user
model, call processing for the branch phones is provided locally. Non-IP phones are connected to the
B5800 Branch Gateway and IP and certain SIP endpoints (not including the A vaya 9600 SIP phones) can
be administered with B5800 Branch Gateway as their controller (see
for more information). Access to and from the rest of the Avaya Aura® network is via the B5800 Branch
Gateway system's A vaya Aura® Session Manager link across the enterprise WAN. This connection allows
for VoIP connectivity to other B5800 Branch Gateway systems, to centralized PSTN trunking, and to
centralized applications such as conferencing and A vaya Aura® Messaging. The centralization capability
is based primarily on the infrastructure at the enterprise core. The local B5800 Branch Gateway can be
accessed as a SIP gateway connected to the core Avaya Aura®Session Manager to provide access to
local PSTN trunks and services when required.

Supported telephones on page 12

Beginning in R6.2, B5800 Branch Gateway is supported in an Avaya Communication Server 1000 (CS

1000) configuration. B5800 Branch Gateway can be deployed as a new branch in an existing CS 1000
configuration or as a replacement for Business Communications Manager (BCM) as a branch office in a
CS 1000 branch office model. In these deployments, B5800 Branch Gateway operates as a distributed
branch.

Integration of the B5800 Branch Gateway for a Communication Server 1000 configuration and for an
Avaya Aura configuration is provided in separate documents. For more information, see:

• Implementing the Avaya B5800 Branch Gateway for a Communication Server 1000 Configuration,
document number 03-604053

• Implementing the Avaya B5800 Branch Gateway in an Avaya Aura® Configuration, document number
18-603853

Management

The primary method for configuring and managing the branches in a B5800 Branch Gateway
system is centrally using Avaya Aura® System Manager R6.2. Avaya Aura® System Manager
is a central management system that delivers a set of shared management services and a

Avaya B5800 Branch Gateway Solution Overview June 2012 7

B5800 Branch Gateway overview

common console for different components of the Avaya Aura® solution. System Manager
provides a single access interface to administer multiple branch locations and multiple
distributed B5800 Branch Gateway users. System Manager also launches IP Office Manager
in the appropriate mode where you can remotely administer individual B5800 Branch
Gateways.

As an alternative to System Manager, you can use IP Office Manager that is directly connected
to the B5800 Branch Gateway to configure a branch locally when you need to administer an
isolated branch or System Manager is not available. IP Office Manager is an application for
viewing and editing a B5800 Branch Gateway system's configuration. It is included in the
B5800 Branch Gateway administration software suite. Manager is an off-line editor . It receives
a copy of the system's current configuration settings. After changes are made to that copy and
the file is saved, Manager automatically sends the file back to the system for those changes
to become active.

Avaya Aura® System Manager

Using Avaya Aura® System Manager R6.2, you are able to:

• Upgrade B5800 Branch Gateway systems.

• Add B5800 Branch Gateway devices from the network to System Manager.

• Create B5800 Branch Gateway endpoint templates that are used to create B5800 Branch
Gateway users. These templates can be edited, duplicated, or deleted.

• Create B5800 Branch Gateway system configuration templates that can be applied to
selected B5800 Branch Gateway systems. These templates are used for initial device
provisioning. These templates can be edited, duplicated, or deleted.

• Upload and convert audio files to System Manager to be used in the B5800 Branch
Gateway System Configuration Auto Attendant feature.

• Manage B5800 Branch Gateway system configurations. From System Manager, you are
able to launch IP Office Manager to view or edit a system configuration. With this feature,
you make changes to the B5800 Branch Gateway device through System Manager. You
are able to apply the changes immediately or schedule the changes to run at a specified
time.

• Manage B5800 Branch Gateway security configuration. From System Manager, you are
able to launch IP Office Manager to view or edit a system security configuration. With this
feature, you make changes directly to the B5800 Branch Gateway device.

• Create B5800 Branch Gateway user templates. These templates can be edited or
deleted.

• Perform a B5800 Branch Gateway backup with the option of storing the backup output in
System Manager or creating a local backup where the system stores the backup output
on the local storage attached to the B5800 Branch Gateway device.

• Perform a B5800 Branch Gateway restore. This feature allows you to restore:

- a saved B5800 Branch Gateway system configuration onto a B5800 Branch
Gateway from System Manager.

- a backup of a B5800 Branch Gateway system configuration onto a B5800 Branch
Gateway from the device SD card.

- users from System Manager to the B5800 Branch Gateway.

8 Avaya B5800 Branch Gateway Solution Overview June 2012

Comments? [e-mail]

Voicemail support options

- a saved B5800 Branch Gateway system configuration and user from System
Manager onto a B5800 Branch Gateway.

• View events and alarms regarding various operations that occur on the B5800 Branch
Gateway.

Voicemail support options

B5800 Branch Gateway supports a range of options for voicemail services to the branch's
native users. It supports Embedded Voicemail for native branch users and auto attendants to
service local PSTN trunks. Standalone Voice Mail is also available for B5800 Branch Gateway
systems when additional port capacity is required. Centralized voice messaging systems,
Avaya Aura® Messaging, Modular Messaging over SIP, or CallPilot (for CS 1000 deployments)
can also be configured. When using any of the centralized voice messaging systems, you are
still able to use Embedded Voicemail or Standalone V oice Mail at each branch to provide auto­attendant operation and announcements for waiting calls.

System components

The B5800 Branch Gateway system is comprised of the following hardware components.

• B5800 Branch Gateway control unit — B5800 Branch Gateway is supported on the
IP500v2 platform or on the B5800 Branch Gateway hardware platform which is based on

Avaya B5800 Branch Gateway Solution Overview June 2012 9

B5800 Branch Gateway overview

IP500v2. The B5800 Branch Gateway control unit stores the system configuration and
performs the routing and switching for telephone calls and data traffic. It includes 4 slots
for optional base cards to support trunk and phone extension ports. The slots are
numbered 1 to 4 from left to right. They can be used in any order; however , if the capacity
for a particular type of card is exceeded, the card in the right-most slot will be disabled.

• B5800 Branch Gateway System SD card — The B5800 Branch Gateway System SD
card is a specific Avaya SD card that is required. It determines the system operation as
B5800 Branch Gateway. It is uniquely numbered and has a serial number that must be
used as the Host ID in the PLDS license file if the B5800 Branch Gateway is operating
with an individual license file and not with WebLM licensing. The B5800 Branch Gateway
System SD card also provides Embedded Voicemail support and storage for system
software files. The card fits into a slot in the rear of the control unit.

• Base cards — The control unit has slots for up to 4 base cards. The base cards are used
to add analog extension ports, digital extension ports, and voice compression channels.
Each base card includes an integral front panel with ports for cable connections. The
following base cards are supported:

- Digital station base card — This card provides 8 digital station (DS) ports for the
connection of A vaya digital phones other than IP phones. The card can be fitted with
a trunk daughter card which uses the base card ports for trunk connection. A
maximum of 3 digital station base cards are allowed per control unit.

- Analog phone base card — This card is available in two variants, supporting either
2 or 8 analog phone ports. The card can be fitted with a trunk daughter card which
uses the base card ports for trunk connection. A maximum of 4 analog phone base
cards are allowed per control unit. The analog phone ports do not include a ringing
capacitor. Where this is a requirement, connection should be via a Master socket
containing ringing capacitors. If fitted with an analog trunk daughter card, during
power failure phone port 8 is connected to analog trunk port 12.

- VCM base card — This card is available in variants supporting either 32 or 64 V oice
Compression Channels (VCM) for use with VoIP calls. A maximum of 2 VCM base
cards are allowed per control unit. The card can be fitted with a trunk daughter card
which uses the base card ports for trunk connection.

- 4–port expansion base card — This card adds an additional 4 expansion ports for
external expansion modules. The card is supplied with four 2m yellow interconnect
cables. This card does not accept any trunk daughter cards. A maximum of 1 4–port
expansion base card is allowed per control unit (right-hand slot 4 only). See

External
expansion modules on page 11 for a list of the supported external expansion

modules.

- BRI combination card — This card provides 6 digital station ports (1-6), 2 analog
extension ports (7-8) and 2 BRI trunk ports (9-10, 4 channels). The card also includes
10 VCM channels. This card has a pre-installed BRI trunk daughter card. A maximum
of 2 BRI combination cards of any type are allowed per control unit.

- ATM combination card — This card provides 6 digital station ports (1-6), 2 analog
extension ports (7-8) and 4 analog trunk ports (9-12). The card also includes 10 VCM
channels. This card has a pre-installed analog trunk daughter card. A maximum of

10 Avaya B5800 Branch Gateway Solution Overview June 2012

Comments? [e-mail]

System components

2 ATM combination cards of any type are allowed per control unit. The analog phone
ports do not include a ringing capacitor. Where this is a requirement, connection
should be via a Master socket containing ringing capacitors. If fitted with an analog
trunk daughter card, during power failure phone port 8 is connected to analog trunk
port 12.

- TCM 8 card — This card provides 8 digital station ports (1-8).

• Trunk daughter cards — Most base cards can be fitted with a trunk daughter card to
support the connection of trunks to the base card. The following trunk daughter cards are
supported:

- Analog trunk card — This card allows the base card to support 4 analog loop-start
trunks. The analog phone ports do not include a ringing capacitor. Where this is a
requirement, connection should be via a Master socket containing ringing capacitors.
If fitted with an analog trunk daughter card, during power failure phone port 8 is
connected to analog trunk port 12. A maximum of 4 analog trunk cards are allowed
per control unit.

- BRI trunk card — This card allows the base card to support up to 4 BRI trunk
connections, each trunk providing 2B+D digital channels. The card is available in 2
port (4 channels) and 4 port (8 channels) variants. A maximum of 4 BRI trunk cards
are allowed per control unit. For S-Bus connection, the card can be switched from
To trunk mode to So mode. This mode requires additional terminating resistors and
an ISDN crossover cable connection.

- PRI trunk card — This card allows the base card to support up to 2 PRI trunk
connections. The card is available in single and dual port variants. The card can be
configured for E1 PRI, T1 robbed bit, T1 PRI or E1R2 PRI trunks. A maximum of 4
PRI trunk cards are allowed per control unit. The B5800 Branch Gateway system
supports 8 unlicensed B-channels on each IP500 PRI-U port fitted. Additional B­channels, up to the capacity of ports installed and PRI mode selected require
Universal PRI (Additional Channels) licenses added to the configuration. These
additional channels consume the licenses based on which additional channels are
configured as in-service from port 9 of slot 1 upwards. D-channels are not affected
by licensing.

• Combination cards — Combination cards are pre-paired base and trunk daughter cards.
They provide 6 digital station ports, 2 analog phone ports, 10 VCM channels and either
4 analog trunk ports or 4 BRI channels (2 ports). The trunk daughter card cannot be
removed or replaced with another type of trunk daughter card.

• External expansion modules — External expansion modules are used to add additional
analog and digital ports. If the control unit is fitted with a 4–port expansion base card, then
up to 12 external expansion modules are supported. The following external expansion
modules are supported:

- Analog trunk module — This module rovides an additional 16 analog ports for
connection of analog trunks. It supports both loop-start and ground-start trunks.

Avaya B5800 Branch Gateway Solution Overview June 2012 11

B5800 Branch Gateway overview

- BRI So8 module — This module provides 8 ETSI BRI-So ports for the connection
of ISDN devices. This module is not intended to support BRI trunks.

- Digital station module — This module provides, depending on variant, an
additional 16 or 30 DS ports for supported Avaya digital phones.

- Phone module — This module provides, depending on variant, an additional 16 or
30 phone ports for analog phones.

• Power supplies — The control unit has an internal power supply unit. Each external
expansion module is supplied with an external power supply unit. Additional power supply
units may also be required for IP phones and some phone add-ons.

• Power cords — Depending on the locale, different power cords need to be ordered for
each control unit, external expansion module, and any phones or devices using external
power supply units.

• Mounting kits — The control unit can be used free-standing, with external expansion
modules stacked above it. With optional rack mounting kits, the control unit and external
expansion modules can also be rack mounted. Alternatively, with an optional wall
mounting kit the control unit can be wall mounted. However, the control unit cannot
support any external expansion modules when wall mounted.

• Surge protectors and barrier boxes — Where the installation includes extensions in
other buildings, additional protective equipment is required. This equipment may also be
required in areas where the lightning risk is high.

• Phones — B5800 Branch Gateway systems support a variety of Avaya digital and IP
phones plus analog phones.

• Application DVDs — The B5800 Branch Gateway applications can be ordered on a
number of DVDs. In addition they can be downloaded from the B5800 Branch Gateway
section of the Avaya support web site (http://support.avaya.com).

Supported telephones

Telephone

Analog
1120E SIP
1140E SIP

Native extensions (local extensions operating

in the distributed branch user model)

1220 SIP
1230 SIP
1403 digital

12 Avaya B5800 Branch Gateway Solution Overview June 2012

Comments? [e-mail]

1408 digital
1416 digital
1603
1603SW
1608
1616
1603SW-I
1608-I
1616-I
BM32 (DSS)
2402D
2410D

Supported telephones

Telephone Native extensions (local extensions operating

in the distributed branch user model)

1

2420
3616 wireless
3620 wireless
3626 wireless
3641 wireless
3645 wireless
3720 DECT R4
3725 DECT R4
3740 DECT R4
3749 DECT R4
3810 digital wireless
4601
4602IP
4602SW
4610IP
4610SW
4621
4625

Avaya B5800 Branch Gateway Solution Overview June 2012 13

B5800 Branch Gateway overview

Telephone Native extensions (local extensions operating

5402
5410
5420
EU24 (DSS)
5601
5602IP
5602SW
5610IP
5610SW
5620
5621
EU24 BL (DSS)

in the distributed branch user model)

1

1

9504 digital
9508 digital
9608
9611G
9621G
9641G
9620L
9620C
9630G
9640
9640G
9650
9650C
SBM24
Avaya 1010/1020/1030/1040 video

conferencing units

2

2

2

2

2

2

2

2

2

2

2

1

B149 conference phone
B159 conference phone
B179 conference phone

14 Avaya B5800 Branch Gateway Solution Overview June 2012

Comments? [e-mail]

Telephone Native extensions (local extensions operating

BM12
BCM TDM sets:

• DECT handsets 4xxx/7xxx series

• T7316E

• T7316

• T7406E

• T7406

• T7208

• T7100

• T7000

• M7310

• M7310N

• M7310+BLF

New in this release

in the distributed branch user model)

1

• M7324

• M7324N

• M7208

• M7208N

• M7100

• M7100N

• Audio conference unit

• T24 KIM (Key Indicator Module for
T7316)

DevConnect–approved 3rd-party SIP
audio and video endpoints

1

When connected to their respective telephones.

2

Supported when running H.323 firmware; not supported when running SIP firmware.

New in this release

Avaya B5800 Branch Gateway Release 6.2 provides the following new features:

• Centralized management provided by Avaya Aura® System Manager — provides
centralized management for single provisioning of native (local) users in distributed
branch deployments. System Manager replaces the Network Management applications

Avaya B5800 Branch Gateway Solution Overview June 2012 15

B5800 Branch Gateway overview

that were used for centralized management in B5800 Branch Gateway R6.1. See

Management on page 7 for more information.

• Licensing — support for centralized licensing by WebLM server. A single license file is
generated in PLDS for multiple branches. License entitlements are shared among
multiple B5800 Branch Gateways.

• Heritage-Nortel branch migration to B5800 Branch Gateway — support for Norstar
and BCM digital T&M Series phones and 11xx/12xx phones running SIP 4.3. Support for
B5800 Branch Gateway with CS 1000 R7.5 core in distributed branch deployments.

Note:

Integration of B5800 Branch Gateway with Communication Server 1000 is provided in
a separate document. See Implementing the Avaya B5800 Branch Gateway for a
Communication Server 1000 Configuration.

• Voicemail — support for Avaya Aura Messaging, Standalone Voice Mail, and CallPilot.
Avaya Aura Messaging or CallPilot can be configured as the central voicemail system.

With this option, you are still able to use Embedded Voicemail or Standalone Voice Mail
at each branch to provide auto-attendant operation and announcements for waiting
calls.

Note:

Release 6.2 does not support VMPro.

Standalone Voice Mail provides additional port capacity (40 ports) provided on a Linux
server. You must have a Linux server installed to use this option.

• Endpoints — support for the following new native phones (operating in distributed branch
user model): 3740/3749 DECT R4; 3810 (digital wireless); 9504, 9508 (digital); 9611G;
B149, B159 and B179 conference phones (former Konftel); 1120E, 1140E, 1220, 1230
(SIP); The following BCM digital phones: DECT handsets 4xxx/7xxx series, T7316E,
T7316, T7406E, T7406, T7208, T7100, T7000, M7310, M7310N, M7310+BLF, M7324,
M7324N, M7208, M7208N, M7100, M7100N, ACU (audio conference unit)

• Contact Center — support for Contact Center service interoperability . IP Agent or Avaya
one-X® Agent in branch in Telecommuter mode with CC-Elite; calls transferred from
B5800 Branch Gateway to contact center; B5800 Branch Gateway handling VoicePortal
transfer with UUI in SIP.

• Park and Page — support for the Park and Page feature when the system voicemail type
is configured as Embedded Voicemail or Standalone Voice Mail. Park and Page is also
supported on systems where Avaya Aura Messaging, Modular Messaging over SIP, or
CallPilot is configured as the central voicemail system and the local Embedded Voicemail
provides auto attendant operation. The Park and Page feature allows a call to be parked
while a page is made to a hunt group or extension.

• Additional new features:

- Enable voicemail instructions using DTMF — support for enhanced voicemail
continuity over the PSTN. Available for Avaya Aura Messaging or Modular

16 Avaya B5800 Branch Gateway Solution Overview June 2012

Comments? [e-mail]

New in this release

Messaging over SIP central voicemail systems, this feature facilitates getting the call
to the specific mailbox rather than to the general prompt. When a PSTN number is
configured, B5800 Branch Gateway will send voicemail calls to that PSTN number
when Avaya Aura Session Manager is not available.

Note:

In Release 6.2, this feature is not available for CallPilot.

- Export user tool — for an R6.1 to R6.2 upgrade, support for exporting all users or
selected users from a loaded configuration to an XML file that is then imported in
Avaya Aura System Manager. During a B5800 Branch Gateway R6.1 to R6.2
upgrade, users are not automatically created in System Manager. After an R6.1 to
R6.2 upgrade, B5800 Branch Gateway users are exported to a file and then the file
is imported to System Manager.

- Music on Hold — administrator is able to change the Music on Hold. Supported
audio file formats are PCM or WAW.

Avaya B5800 Branch Gateway Solution Overview June 2012 17

B5800 Branch Gateway overview

18 Avaya B5800 Branch Gateway Solution Overview June 2012

Comments? [e-mail]

Chapter 2: Roadmap

This chapter provides a list of high-level tasks and a reference to the appropriate documents required to
install and configure the Avaya B5800 Branch Gateway. Also provided is a list of supported telephones
and the associated user guides, and additional documents that you may need to reference.

High-level tasks for B5800 Branch Gateway and Avaya Aura® configurations

Task Document title Document

number

If you are going to connect the
B5800 Branch Gateway to an
enterprise over the WAN, Avaya
Aura® Session Manager R6.1 or
R6.2 must be installed and
configured at the headquarters
location.

• Installing and Configuring Avaya Aura
Session Manager

• Administering Avaya Aura® Session
Manager

®

• 03–
603474

• 03-6033
24

If you are going to centrally
manage the B5800 Branch
Gateways, Avaya Aura® System
Manager R6.2 must be installed
and configured at the
headquarters location.

If you are going to use centralized
licensing by WebLM, an Avaya
Aura® System Manager WebLM
server or a standalone WebLM
server must be installed and
configured. The WebLM server
can be located at the
headquarters location or
anywhere in the network as long
as the B5800 Branch Gateways
can access it on the network.

A stand-alone Secure Access
Link (SAL) Gateway, R2.0 or
higher, must be deployed.

Implementing Avaya Aura® System
Manager

Installing and Configuring Avaya WebLM
Server

Secure Access Link 2.1, SAL Gateway
Implementation Guide

N/A

N/A

146775

Avaya B5800 Branch Gateway Solution Overview June 2012 19

Roadmap

Task Document title Document

number

Note:

System Platform's virtual SAL
gateway is not supported.

Trunking, voicemail, and station
data must be gathered.

The dial plan must be
determined.

Avaya B5800 Branch Gateway
must be installed and configured.

N/A

Avaya Aura® whitepaper on Dial Plan Best
Practice

Implementing the Avaya B5800 Branch
Gateway in an Avaya Aura® Configuration

N/A

18-603853

High-level tasks for B5800 Branch Gateway and CS 1000 configurations

Task

Avaya Communication Server
1000 R7.5 with SIP Line Gateway
must be installed and configured
at the headquarters location.

SIP Line Fundamentals – Avaya
Communication Server 1000

Document title Document

number

NN43001-508

If you are going to connect the
B5800 Branch Gateway to an
enterprise over the WAN, Avaya
Aura® Session Manager R6.1 or
R6.2 must be installed and
configured at the headquarters
location.

If you are going to centrally
manage the B5800 Branch
Gateways, Avaya Aura® System
Manager R6.2 must be installed
and configured at the
headquarters location.

If you are going to use centralized
licensing by WebLM, an Avaya
Aura® System Manager WebLM
server or a standalone WebLM
server must be installed and

20 Avaya B5800 Branch Gateway Solution Overview June 2012

• Installing and Configuring Avaya
Aura® Session Manager

• Administering Avaya Aura
Session Manager

Implementing A vaya Aura® System
Manager

Installing and Configuring Avaya
WebLM Server

Comments? [e-mail]

• 03–603474

®

• 03-603324

N/A

N/A

Task Document title Document

configured. The WebLM server
can be located at the
headquarters location or
anywhere in the network as long
as the B5800 Branch Gateways
can access it on the network.

Related resources

number

A stand-alone Secure Access
Link (SAL) Gateway, R2.0 or
higher, must be deployed.

Note:

System Platform's virtual SAL
gateway is not supported.

Trunking, voicemail, and station
data must be gathered.

The dial plan must be
determined.

Avaya B5800 Branch Gateway
must be installed and configured.

Secure Access Link 2.1, SAL
Gateway Implementation Guide

• IP Peer Networking Installation
and Commissioning – Avaya
Communication Server 1000

• Network Routing Service
Fundamentals, Avaya
Communication Server 1000

• IP Peer Networking Installation
and Commissioning – Avaya
Communication Server 1000

• Network Routing Service
Fundamentals, Avaya
Communication Server 1000

Implementing the Avaya B5800
Branch Gateway in a
Communication Server 1000
Configuration

146775

• NN43001-313

• NN43001-130

• NN43001-313

• NN43001-130

03-604053

Related resources

User guides for supported telephones

The documents listed below are available on the Avaya support web site at http://

support.avaya.com.

Avaya B5800 Branch Gateway Solution Overview June 2012 21

Roadmap

Telephone User Guide Quick Reference/Getting Started

1120E SIP Avaya 1120E IP Deskphone User

Guide, NN43112–103

1140E SIP Avaya 1140E IP Deskphone User

Guide, NN43113–106

1220 SIP Avaya 1220 IP Deskphone with SIP

Software User Guide – SIP
Software Release 4.3, NN43170–
101

1230 SIP Avaya 1230 IP Deskphone with SIP

Software User Guide – SIP
Software Release 4.3, NN43170–
102

1403, 1408,
1416

Avaya 1400 Series Digital
Deskphone User Guide for Avaya
Aura® Communication Manager,
16-603151

1603,
1603SW,
1603SW-I

• IP Office Release 6, 1403, 1603
Phone Reference Guide,
15-601013

• Avaya 1603/1603SW/1603-I/
1603SW-I IP Deskphone User
Guide, 16-601444
