Item No. Description Part code Qty per unit
1 Backsplash assembly G24F08-011500Z assm 1
2 Oven/Broil injector base G20A01-021100 2
4 Grill burner aluminum pipe G20C01-023300 1
5 Oven burner aluminum pipe G20C01-023100 1
6 Bottom cup mounting plate G24C01-024200 2
7 Mid burner cover G20A01-040102 2
7 Mid burner G20A01-040101 2
7 Mid burner cup G20A01-040100 2
8 Spark plug-for top burner 900mm G20A01-170405 1
9 Large burner G20A01-040201 1
9 Large burner cup G20A01-040200 1
10 Spark plug-for top burner 680mm G20A01-170404 1
11 Small burner cover G20A01-04002 1
11 Small burner G20A01-040001 1
11 Small burner cup G20A01-040000 1
12 Spark plug-for top burner 1050mm G20A01-170406 2
14 Cook top plate G24F08-020100 1
15 Aluminum pipe-L/B G24F08-022300 1
16 Aluminum pipe-L/F G24F08-022400 1
17 Aluminum pipe-R/B G24F08-022600 1
18 Aluminum pipe-R/F G24F08-022500 1
20 Main gas pipe G24F08-030700 1
23 Safety valve 0.81 G20D02-030530 2
24 Safety valve 0.95 G20D02-030531 1
25 Control panel G24F08-030300 1
26 Knob G20A07-030100 6
27 Digital timer with LED lights G24F08-190300 1
28 Knob ring G20A07-030200-00 6
29 Digital timer support G24F08-191000 1
* Complete door assembly GC0097-100400Z 1
31 Internal fixation plate G20C01-102500 4
32 Door inside glass G24F08-100500 2
34 Do or inner seal ring G24C01-103000 1
35 Oven door frame G24C01-100600 1
DGR24P3S
3 Nozzle 1.3 G20A01-021213 1
9 Large burner cover G20A01-040202 1
13 Cast iron grate left G24F08-021400 1
13 Cast iron grate r ight G24F08-021500 1
21 Thermostat G20C02-030617 1
22 Safety valve 0.5 G20D02-030523 1
30 Side plate G20C01-071002 2
33 Door inner seal bar G24C01-103100 1
Item No. Description Part code Qty per unit
36 Window fixing piece for door G20C01-102600 4
37 Door body strengthening part G20C01-101000 2
38 Door hinge G24C01-110000 2
39 Door glass wool G24C01-103500 1
40 Door inside window G24F08-101100 1
41 Outer door glass GC0097-100400 1
42 Handle G24B03-101900 2
43 Do or handle strut G20C01-100300 2
44 Door glass bracket G20A10-100900 2
45 Door stainless steel trim G24F08-102000 1
* Drawer assembly G24F08-120100Z 1
47 Drawer outside plate G24F08-120100 1
48 Drawer inside plate G24C02-120200-04 1
49 Drawer plate G24F08-120500-02 1
50 Drawer slid rail G24F08-120700 2
51 Front plate G24C01-070102 1
54 baffle G20C01-111100 2
55 Foot G20C01-071500 4
56 Cavity right plate G20A01-070500 1
57 Oven burner fire board G20A01-080900 1
58 Oven burner pipe G20B01-080100 1
59 Spark plug-for oven burner 230mm G20C01-170502 1
60 Anti-tip bracket G20A01-212500 1
62 Drawer heat insulation board G24C01-072100 1
63 Bottom tray (with hole) G24A01-070700 1
64 Rack G24C01-071900 2
65 Broil tray G20C01-215000 1
66 Broil grill G20C01-215100 1
67 Broil burner pipe G20C01-090100 1
68 Broil burner fire board G20C01-090300 1
69 Spark plug-for grill burner 540mm G20C01-170500 1
70 Thermocouple G20C01-072400 1
71 Cavity top pla te G24C01-070601 1
74 Weight block G20A01-210200 1
75 Fixed plate G20C01-034500 2
76 Power cord G20A07-160105 1
77 Power cord fixed part G20A01-160200 1
78 Ignition G20C01-170106 1
80 Back plate G24C01-070301 1
52 Front plate Beam G24A01-070200 1
61 Leg installation plate G20A01-071100 2
68 Broil burner infrared radiation net G20C01-090500 1
79 Cavity left plate G20A01-070400 1
Item No. Description Part code Qty per unit
81 Oven lamp G20C01-180101 1
82 Cavity back glass wool G24C01-072900 1
84 Baffle plate G24C01-072000 1
85 Rear connecting plate G20C01-022000 2
86 Diversion plate G20C01-075000 1
87 Regulator G20C01-034001 1
88 Regulator adapter G24G02-034200 1
89 Glass wool G24A01-070800 1
91 Control panel rubber mat G24F08-120900 1
92 Control panel barrier str ip G24F08-214500 1
93 Control panel glass wool G24F08-036000 1
95 Regulator support G24G02-034500 1
* Front plate seal bar G24G02-071200 1
* Lamp switch C20F08-170800 1
* Cooktop thermocouple 300mm G20A01-030900 2
* Cooktop thermocouple 500mm G20A01-030901 2
* nozzle 1.0 G20A01-021206 2
* nozzle 1.4 G20A01-021224 2
* nozzle 0.82 G20A01-021204 1
* Roasted motor G20A01-200101 1
* Roasted axis'24 G24A01-200500 1
* Cavity ring G24F08-071200 1
* nozzle 0.8 G20A01-021202 2
