SERVICE
C6N0AV101X
Cooker
DER 242 BS
SPARE PARTS CATALOGUE
DER 242 BS
C6N0AV101X
1.2
1.3
2.18
2.8
2.9
2.10
2.19
2.1
2.19
1.1
2.2
2.18
5.15
5 .12
5.17
5.16
5.14
2.15
5.11
5.10
2.16
5.7
5.24
5.5
5.18
tav. 1
5.6
5.2
5.3
4.7
4.28
4.8
4.32
2.7
4.5
4.15
4.49
4.39
4.4
2.7
4.9
4.6
4.27
4.11
5.9
4.14
5.26
5.4
4.38
4.44
4.13
4.34
4.25
5.27
5.23
5.25
4.21
3.8
5.8
3.5
5.1
3.2
3.4
3.1
3.3
3.7
4.50
4.48
4.12
4.10
4.1
4.28
4.18
4.30
4.21
4.24
4.23
4.20
4.22
05
REF. CODE DESCRIPTION REF. CODE DESCRIPTION
Cooker DER 242 BS
Tav. 1
C6N0AV101X
1.1 1031007063 Rear trim
1.2 001130 Screw
1.3 040031002 Plug
2.1 355VC6133 Glass with frame
2.2 094507 Hotplates protection
2.3 001175 Screw
2.7 51B6113.1 Hotplates support
2.8 035075 Spring
2.9 085043 Spacer
2.10 001111 Screw
2.15 050064240 Energy regulator
2.16 2183A3X559 Knob
2.18
2.19
3.1 35C6N32SA1 Control panel
3.2 030165.1 Control panel insulation
3.3 053111 Seal
3.4 213007 Clip
3.5 4116N07 Insulation support
3.7 51B6N02H Deflector
3.8 003066 Spacer
4.1 4416N1ES02 Oven body
4.4 030159 Oven insulation
4.5 030160 Rear insulation
4.6 094354DX Rear right coupler
4.7 094354SX Rear left coupler
4.8 4116N08 Rear panel
4.9 4216101Z Upper shelter
4.10 103854 Shim
4.11 040011 Buffer
4.12 214056 Nut shim
4.13 053039 Seal
4.14 094333DX Front right coupler
4.15 094333SX Front left coupler
4.18 103160061 Base panel
4.20 040012 Buffer
4.21 094075 Drawer rail
4.22 094138 Drawer fixing bracket
4.23 39E6603L Drawer front panel
4.24 39K6101Y Drawer
4.25 081073 Drawer stopper
4.27 36C6ND1HH Right side panel
4.28 36C6NS1HH Left side panel
4.30 68061010 Plinth
4.32 4219604Z Rear insulation support
4.34 053097 Rotisserie hole plug
4.38 081083080 Right front trim plug
4.39 081084080 Left front trim plug
4.44 053074 Top/bottom seal
4.48 103326 Balance weight
4.49 213016 Balance weight bracket
4.50 094495 Anti-tip stabilit
04777240 Hotplate - Ø 145 - 1200W
04778240 Hotplate - Ø 180 - 1700W
y device
5.1 032653275 Door glass
5.2 1031484080 Spacer
5.3 037316061 Door handle
5.4 053112 Door seal
5.5 51B6N05 Handle bar
5.6 001183 Screw
5.7 030177.1 Door insulation
5.8 063154 Door hinge (male)
5.9 063148 Door hinge (female)
5.10 373FF722G Door panel
5.11 053084 Gasket
5.12 0311000.1T Inner glass
5.14 214021 Nut
5.15 001214 Screw
5.16 003035 Washer
5.17 103205.1 Washer
5.18 0312474 Third glass
5.23 51B6N03 Left inner glass support
5.24 51B6N04 Right inner glass support
5.25 040056 Third glass rubber
5.26 001253 Screw
5.27 030178.1 Side insulation door
7.1
7.3
7.4
DER 242 BS
C6N0AV101X
tav. 2
8.15
7.2
7.2
8.27
7.1
8.1
8.16
8.2
11.34
11.2
11.30
11.33
11.1
8.23
8.17
11.35
11.27
11.25
8.24
11.26
8.22
8.20
8.25
11.16
05
REF. CODE DESCRIPTION NOTE
7.1 217291 Shelf support
7.2 217722 Oven shelf
7.3 48B6105G
7.4 48E6104G Broiling pan tray
Pastry plate
Cooker DER 242 BS
Tav. 1
C6N0AV101X
2183H0X5591.8
2183H2X5592.8 Thermostat knob
8.15 050040.1 Oven switch
8.16 066141 Oven thermostat
8.17 062120001 Grill element - 240V
8.20 4216102Z Bottom element support
8.22 030083.1 Bottom element insulation
8.23 062121001 Bottom element - 240V
8.24 4216108Z Bottom element plate
8.25 4216N02Z.1 Bottom protection plate
= 4216N03Z Bottom protection plate
8.27 213023 Clip
11.1 072005 Lamp holder
11.2 073013001 Lamp
11.16 1131555 Wiring
11.16 1131556 Wiring
11.25 051064 Terminal block
11.26 094539 Power cord bracket
11.27 094538 Terminal block support
11.30 066057 Cut-off thermostat
11.33 07306202.2 Control lamp cover - Red
11.34 073078 Control lamp
11.35 094221 Earth plate
Switch knob
- 1105081 Users operating instructions
- 1105080 Installation instructions
