1 - W A Y 2 - B U T T O N A U T O M A T I C / M A N U A L T R A N S M I S S I O N
M U L T I - C H A N N E L R E M O T E S T A R T E R S Y S T E M
INDUSTRY CANADA USER NOTICE:
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired operation of the
device.
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (EIRP) is not more than that required for successful
communication.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user's authority to operate the equipment.
D1001 2014-07-14 -CP- Canada
User Guide
WARNING!
It is the responsibility of the vehicle operator to ensure their vehicle
is parked in a safe and responsible manner.
1. a) Manual transmission: When leaving the vehicle, it is the user’s
responsibility to ensure that the gearshift lever is in the NEUTRAL
position and the parking brake is engaged in order to avoid accidents
upon remote starting.
b) Automatic transmission: When leaving the vehicle, it is the user’s
responsibility to ensure that the gearshift lever is in “Park” in order to
avoid accidents upon remote starting.
(Note: Make sure that the automatic vehicle cannot start in "Drive".)
2. It is the user's responsibility to ensure that the remote starter is
disabled or put into valet mode before servicing.
Designed & engineered in Canada
P.2 User Guide
Table of Contents
GOVERNMENT REGULATIONS ....................................................................................................... 3
INTRODUCTION WITH SMARTSTART™ .............................................................................. 3
USING THE REMOTE CONTROL ..................................................................................................... 4
VEHICLE PRESETS .......................................................................................................................... 4
Heater ............................................................................................................................................ 4
Windshield Wipers, Radio & Headlights ........................................................................................ 4
REMOTE-STARTING YOUR VEHICLE ............................................................................................. 4
Setting Your Vehicle into Ready Mode .......................................................................................... 4
Remote-starting .............................................................................................................................. 5
Driving Off ...................................................................................................................................... 6
ARMING AND DISARMING THE STARTER KILL (IF INSTALLED) ............................................... 6
REMOTE STARTER FEATURES ...................................................................................................... 7
Remote Door Locks ....................................................................................................................... 7
Remote Trunk Release .................................................................................................................. 7
Idle Mode ....................................................................................................................................... 7
Valet Mode ..................................................................................................................................... 8
Cold Weather Mode ....................................................................................................................... 8
Panic Mode .................................................................................................................................... 9
Quick Lockout
TM
............................................................................................................................ 9
ADVANCED FEATURES: INSTALLATION-PROGRAMMABLE OPTIONS .................................... 9
Ignition-controlled Door Locks ....................................................................................................... 9
Secure Lock ................................................................................................................................. 10
Passive or Active Arming ............................................................................................................. 10
Engine Run Time ......................................................................................................................... 10
Turbo Mode .................................................................................................................................. 10
Horn Confirmation ........................................................................................................................ 11
POOR TRANSMITTING RANGE ISSUES....................................................................................... 11
DIAGNOSTICS – PARKING LIGHT FLASH TABLE ...................................................................... 12
User guide P.3
Government regulations
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with the Industry Canada Radio Standards Specification RSS 210. Its use is authorized
only on a no-interference, no-protection basis; in other words, this device must not be used if it is determined
that it causes harmful interferences to services authorized by IC. In addition, the user of this device must accept
any radio interface that may be received, even if this interference could affect the operation of the device.
Warning:
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate this device.
Introduction with SmartStart™
This is a state-of-the-art remote car starter system. The system is packed with advanced features
such as priority access to the driver’s door (commodity features), the Safe Start children safety
feature and SmartStart™.
SmartStart™ is a groundbreaking technology that enables your remote starter features to be
accessed by your smartphone. Features include keyless entry, trunk release, panic, remote
start/stop toggle and alarm notifications1. Note: SmartStart™ must be professionally installed. For
more information, see your nearest authorised Directed Canada dealer.
With many advanced functions, this product will satisfy any one of your expectations from high-end
commodity and security systems, without neglecting any standard feature commonly offered by
entry-level starters.
1
Certain conditions apply. See your authorised Directed Canada dealer.
P.4 User Guide
Using the Remote Control
Your Remote Car Starter is equipped with a 2-button multi-channel remote control that can be
configured into 2 different functions.
Default remote functions:
Stop (default value)
Start (default value)
&
Trunk release
Alternate programmable remote functions:
Lock/unlock
Start/stop
&
Trunk release
Vehicle Presets
Heater
When leaving the vehicle it is recommended to preset the accessory controls in preparation for the
next remote start. Settings for the blower motor (fan), front and rear, should not be left on HIGH. It
is recommended to leave the settings on LOW or MEDIUM instead.
Windshield Wipers, Radio & Headlights
Certain vehicles require the radio and / or windshield wipers and / or headlights circuits to become
energized while running under remote start. When leaving the vehicle you must ensure that the
windshield wipers and headlights switches are OFF. Leaving the headlights switch ON on certain
types of vehicles could cause them to remain ON even after remote starter shutdown, resulting in a
dead battery.
Remote-Starting Your Vehicle
Setting Your Vehicle into Ready Mode
If your vehicle has a manual transmission you must read the following indications. The unit must
first be set to Ready Mode in order to start the vehicle by remote. If the unit is not set to Ready
Mode, it cannot remote start the vehicle.
Please note that Ready Mode can be enabled by the remote or the handbrake, depending on the
option that was selected by your installer. Therefore, you must follow the appropriate procedure
between the two described below in order to set your vehicle into Ready Mode.
User guide P.5
Once the system is set to Ready Mode, the vehicle can be remote started and stopped at any time.
The system will exit Ready Mode if a door, the hood or the trunk is opened, if the brake pedal is
pressed, if the parking brake is disengaged or if the ignition key is turned to the IGNITION ON
(RUN) position.
To set the system to Ready Mode:
If Ready Mode is enabled by remote
If Ready Mode is enabled by handbrake
1. Ensure that all the doors, hood and trunk are closed. Make sure that the gear selector is in the
neutral position.
2. With the engine running, apply the parking
brake once and release the brake pedal.
3. Within 20 sec. of engaging the parking
brake, press and hold on the transmitter
(SmartStart™ uses only the SmartStart™
icon).
The parking lights will flash 3 times quickly
and remain lit. Release the button.
2. With the engine running, apply the parking
brake twice within 10 sec.
3. Make sure to release the brake pedal.
The parking lights will flash 3 times quickly
and remain lit.
4. Remove the key: the engine will keep on running.
5. Exit the vehicle. All doors should be closed, including the hood and trunk.
THERE ARE THREE POSSIBLE OPTIONS TO COMPLETE READY MODE (programmable
by installer)
OPTION 1: Automatic shut
down without auto lock
OPTION 2: Manual shut
down
(default)
OPTION 3: Automatic shut
down with auto lock
The engine runs for 8 sec.
before finally shutting down
the engine, without user
interaction.
The engine keeps going until you
press either;
a. to lock the doors and
shut down the engine (if
option 1 was programmed);
to shut down the engine
without affecting the doors (if
option 2 was programmed).
The engine runs for 8 sec.
then locks the doors before
finally shutting down the
engine, without user
interaction.
WARNING: The vehicle is
not armed or locked down.
WARNING: Engine runs until the
pre-programmed run time
expires.
WARNING: Do not leave
your keys in the vehicle!
6. The Parking lights will flash twice to indicate Ready mode is set.
Remote-starting
Press the button for approximately 1 second. The parking lights will turn ON to inform you that
the Remote Car Starter has received your signal. Approximately 5 seconds later, the engine will
start. The parking lights will remain ON during the pre-programmed run time of the engine.
If your vehicle does not start at the first attempt, the system will shut down, wait a few seconds and
try to start the engine again. There will be 3 start attempts before the system gives up.
P.6 User Guide
Driving Off
With the vehicle running remotely, press the button (ONLY if programmed as the LOCK or
UNLOCK button) to disarm the starter kill (if installed) and unlock the doors. Enter the vehicle and
do the following:
1. Turn the ignition key to the IGNITION ON (RUN) position. (Do not turn the key to the CRANK
position while the engine is running. This would cause the starter motor to re-engage.)
2. Press the brake pedal to disengage the remote starter unit.
You are now ready to drive off.
Note: On some Push-To-Start (PTS) vehicles, no takeover is possible as pressing the brakes will
shut the engine down. Please talk to your technician to determine if the “Takeover mode” can be
set for your vehicle.
Arming and disarming the starter kill (if installed)
This added security feature will prevent the vehicle from starting with the Ignition key when the
starter kill is armed. If the system was installed with the starter kill option, the vehicle will not be
able to start with the key unless the system has been unlocked first or put into Valet Mode
(page 8).
Note: If the Starter Kill is installed, the vehicle will benefit from a protection against starter motor
damage that could occur after remote-starting the engine should the user, by force of habit, turn
the ignition key to the CRANK position.
The Starter Kill (if installed) can be configured by the installer either to Passive Mode (so as to arm
automatically) or Active Mode (so as to require the user’s intervention for arming). By default, the
Remote Car Starter is configured to Passive Mode.
Note: This feature is only available if the button is configured as LOCK or UNLOCK.
Passive mode:
To arm the Starter Kill:
Press the button on the transmitter.
OR
Let the Starter Kill arm automatically 1 minute (by default) or 3 minutes (if configured this way)
after the ignition is turned OFF or once the last door is closed (if the doors are monitored).
The LED on the antenna will remain OFF during the countdown preceding the activation
of the Starter Kill.
Once the activation countdown expires, the LED will flash slowly to indicate that the
Starter Kill is now armed.
To disarm the Starter Kill:
Press the button on the transmitter.
The Starter Kill will automatically rearm itself after 1 minute (by default) or 3 minutes (if
configured this way) if no door is left opened (if the doors are monitored) and the ignition
is not turned ON.
User guide P.7
Active Mode:
To arm the Starter Kill:
Press the button on the transmitter.
The parking lights will flash once.
The LED on the antenna will flash slowly.
If remote door locks are installed, this will also lock the doors.
To disarm the Starter Kill:
Press the button on the transmitter.
The parking lights will flash twice.
The LED on the antenna will remain OFF.
If remote door locks are installed, this will also unlock the doors.
Remote Starter Features
Remote Door Locks
Note: This feature is only available if button is programmed as LOCK or UNLOCK.
If your system was installed with the Remote Door Locks option, you will have the convenience of
remote keyless entry.
To LOCK your doors and ARM the system (if installed):
1. Press and hold the button for approx. 1 sec.
2. The parking lights will flash once to confirm locking of the doors and arming of the Starter Kill.
To UNLOCK your doors and DISARM the system (if installed):
1. Press and hold the button for approx. 1 sec.
2. The parking lights will flash twice and the LED will go out to confirm unlocking of the doors
and that the Starter Kill feature is disarmed.
Remote Trunk Release
If your system was installed with the Remote Trunk Release option, you can open your trunk by
pressing the & simultaneously for 3 seconds on the remote transmitter.
Idle Mode
Note: Idle Mode can be activated only if is programmed as a LOCK or UNLOCK button.
Convenience feature: Idle Mode allows you to keep the engine running and the doors locked
while you stop, for example, at a convenience store or for a short delivery.
This feature allows you to let the remote starter take over control of the vehicle (i.e. no Key in the
Ignition Switch) while the engine is running.
Activating Idle mode (Automatic transmission):
1. With the engine running, make sure to release the brake pedal and press the button on
the transmitter until the parking lights come ON.
Note: SmartStart™ can be setup to use the SmartStart™ icon to activate Idle mode.
2. Remove the ignition key from the ignition switch.
The engine will continue running.
3. Exit the vehicle. All doors, the hood and trunk should be closed
P.8 User Guide
4. Press the button to lock the doors and to arm the starter kill (if available). The engine
will continue running.
a. When re-entering the vehicle, the user must reinsert the key into the ignition and turn it
to the ON position (not Crank) without pressing on the brake.
b. Once the key is in the ON position, press on the brake pedal to put the transmission in
gear. Pressing the brake pedal at this step will cancel the remote starter takeover.
c. Drive off.
If your vehicle has a manual transmission, Idle Mode can be activated through the same routine as
that used for Ready Mode (page 4); at the last step, press the & buttons together to
lock the doors and leave the engine running.
Valet Mode
When the vehicle is in Valet Mode, the remote starter functionalities are disabled. If the vehicle
needs to be serviced, or if you park it indoors, Valet Mode will prevent the engine from being
remote-started accidentally.
Ignition Valet: This feature allows you to set Valet Mode using the ignition key.
To put the system into Valet Mode using the KEY (Ignition Valet Mode):
1. Insert the ignition key into the ignition switch. Within 10 sec., cycle the ignition key to the
IGNITION/RUN and OFF positions 5 times until the parking lights flash 3 times.
2. Turn the ignition OFF.
3. The LED on the antenna will stay ON indicating that the vehicle has successfully entered
Valet mode.
To take the system out of Valet Mode using the KEY (Ignition Valet Mode):
1. Insert the ignition key into the ignition switch. Within 10 sec., cycle the ignition key to the
IGNITION/RUN and OFF positions 5 times until the parking lights flash 2 times.
2. Turn the ignition OFF.
3. The LED on the antenna will switch OFF indicating that the vehicle is now out of Valet mode.
If someone attempted to remote-start the vehicle while in Valet Mode; the parking lights will turn
ON, then OFF, then will flash twice.
Cold Weather Mode
If the vehicle has a manual transmission, Ready mode (page 4) should be set before entering
Cold Weather mode. When Cold Weather Mode is active, the engine starts every 2 hours and runs
for 3 minutes (or for 8 or 20 minutes with diesel engines). Cold Weather Mode automatically ends
after 24 hours (or 12 starts).
To enter Cold Weather Mode:
Press and hold the button for at least 3 seconds
The parking lights will flash for 2 seconds, pause, then flash 3 times.
OR
If was programmed as LOCK & UNLOCK by your installer, press and hold the
button for at least 3 seconds until the parking lights will flash for 2 seconds, pause,
and then flash 3 times.
User guide P.9
To exit Cold Weather Mode, do any one of the following actions:
1. Open the hood.
2. Start the engine by remote.
3. Turn the ignition key to the IGNITION ON (RUN) position.
4. Press and hold the button until the parking lights come ON for 2 seconds, pause,
then flash once.
OR
If was programmed as LOCK & UNLOCK by your installer, press and hold the
button until the parking lights come ON for 2 seconds, pause, then flash once.
To verify whether the system is in Cold Weather Mode:
(Automatic transmissions only) Press the brake pedal: If the vehicle is in Cold Weather
mode, the parking lights will remain ON while the brake pedal is pressed.
Panic Mode
Note: Panic mode can only be activated if the horn has been adequately configured by your
installer.
In an emergency situation, you can activate panic mode by pressing and holding the for
more than 3 seconds, until the horn starts honking. If the vehicle is under a remote start, the engine
will shutdown automatically before setting off the horn. You can stop the horn by pressing
Furthermore; the panic mode can also be stopped by activating Valet Mode (page 8)
Panic Mode will automatically shut down after 30 sec.
Quick Lockout
TM
(Also called Secure Panic.) For fast protection in emergency situations, the system will LOCK all
doors when you press the brake pedal while you hear the Horn sounding. (Quick Lockout is only
available when Panic mode has been triggered.)
Advanced Features: Installation-programmable
Options
The Remote Car Starter was designed with flexibility and OEM integration in mind. With its
programmable options, this unit can single-handedly control nearly any electrical system in your
vehicle.
Caution: The programming of your system should be left to a professional. Changing any one of
the settings may affect the operation of your Remote Car Starter. Please note that the following
programmable options may require additional parts and labor.
Ignition-controlled Door Locks
This is an added security feature. If your Remote Car Starter was installed with the IgnitionControlled Door Locks option, the doors will automatically lock as soon as the ignition key is turned
to the IGNITION ON (RUN) position while the brakes are pressed. The remote car starter will also
lock any door that was unlocked and opened (then closed) the next time the brake pedal is pressed
(only when doors are monitored). When the key is turned to the OFF position, the doors will
automatically be unlocked.
P.10 User Guide
Secure Lock
(Disabled by default.) Before your vehicle can be remote-started, the factory security system must
first be disarmed. The Secure Lock feature may be required on certain vehicle models with factory
security systems that automatically unlock the doors when the security system is disarmed.
To keep your vehicle protected when the factory security system is disarmed for a remote start,
Secure Lock will relock your doors as soon as the vehicle is started. Once the engine is shut down
by remote or after its runtime has expired, Secure Lock will also rearm your factory security system
and relock the doors.
Passive or Active Arming
Note 1: Passive and active arming is only used when a starter kill is installed to your vehicle
Note 2: This feature is only available if the button is configured as LOCK or UNLOCK.
1) Active Mode: The system will not arm automatically. Press to either arm or disarm the
Starter Kill.
2) Passive Mode: The system will automatically arm itself unless remote-armed within 1 minute.
Press to either arm or disarm the Starter Kill.
Engine Run Time
If you have a gas engine, your system can be programmed to run the engine for 3, 15, or
25 minutes (15 min default). If you have a diesel engine, it can be programmed to run the engine
for 8, 20, or 30 minutes (20 min default).
Turbo Mode
Note: Turbo Mode can be activated only if is programmed as a LOCK or UNLOCK button.
If Turbo Mode is configured at installation, it will allow a turbocharger to idle down after the user
leaves the vehicle: the unit will take over the vehicle and keep it running for 60 seconds (or until it
is shut down by remote control), then shut down the engine.
If the vehicle has an automatic transmission, proceed as follows to set the system to Turbo Mode:
1. With the engine running, make sure to release the brake pedal and press the or on
the transmitter until the parking lights come ON.
Note: SmartStart™ can be setup to use the SmartStart™ icon to activate Turbo mode.
2. Remove the ignition key from the ignition switch.
The engine will continue running.
3. Exit the vehicle and close all doors, hood and trunk.
4. Press the & ; this will lock the doors and arm the Starter Kill.
5. The engine will shut down after 60 seconds.
If your vehicle has a manual transmission, Turbo Mode can be activated only if is
programmed as a LOCK or UNLOCK button. Turbo Mode is activated through the same routine as
that used for Ready Mode (page 4); at the last step, is pressed.
Note: The vehicle will enter Ready Mode once the engine run time expires.
User guide P.11
Horn Confirmation
Note: Horn confirmation can be activated only if is programmed as a LOCK or UNLOCK
button.
If configured at installation, the horn will honk every time the doors are locked by pressing .
Poor Transmitting Range Issues
Many factors may affect the operating range of the transmitter. Some of these are:
The condition of the battery in the transmitter.
The operating environment (for example: downtown radio-frequency noise, airports, cellular
phone towers…)
Metal: any type of metal will affect operating range. This includes the metal in the car.
The shape of the vehicle can affect range as well; vans in general have an especially poor
range.
The shape of the roof and A-pillars brings about considerable radio-frequency deflection (in this
case the signal from the remote control). As a result, the direction in which the vehicle is facing
in relation to the remote control can affect the range. Straight on – standing in front of the
vehicle – generally gives you the greatest range; the second best performance is from the back.
Using the remote control from either side of the vehicle will usually give the lowest range.
The range will be significantly lower in a crowded parking lot than in open space.
Always hold the transmitter high, approximately at shoulder height.
The operating range will be somewhat lower on vehicles equipped with an aftermarket or factory
alarm.
Windows and windshields tinted with lead or metallic tints will decrease the operating range.
P.12 User Guide
Diagnostics – Parking Light Flash Table
Parking lights flashes
Description
1
Doors locked.
Trunk released.
Start signal received from the remote.
Runtime has expired.
2 fast
Doors unlocked.
Valet mode is deactivated.
2 slow
Shutdown by remote.
3 slow
Runtime is extended.
1 slow 2 fast
Valet mode activated.
4 fast
Shutdown by brake.
A remote start was attempted while the brake pedal is engaged.
10 fast
Shutdown by hood.
A remote start was attempted while the hood is open.
ON twice
Cold weather mode deactivated.
ON 3 times
Cold weather mode activated.
Solid ON
Engine is running under remote start.
Flash for 30 sec.
Panic mode is triggered.
Flash for 60 sec.
Alarm is triggered.
ON twice twice
A remote start was attempted while the system is in home valet.
Loading...
