C 300 H C 300 HI C 300 H x4 C 300 HI x4 C 350 H C 350 HI C 350 H x4 C 350 HI x4

OPERATOR’S MANUAL

ENGLISH

ORIGINAL MANUAL

AUSA

C 300 H C 300 HI C 300 H x4 C 300 HI x4 C 350 H C 350 HI C 350 H x4 C 350 HI x4

Above chassis number 57168202

ORIGINAL MANUAL

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

(fig. 1)

Foreword

Thank you for choosing this AUSA forklift truck (hereinafter forklift). The purpose of this Operators and Safety Manual is to provide you, the user, with instructions concerning the productive, safe and efficient use of this forklift. You should read and understand this manual before operating the forklift. The Manual contains safety messages concerning the use of the forklift. Remember that “you” are the key to safety.

The preservation of these qualities over a long period of time is in your hands. The correct use of your forklift will allow you to make the most of the resultant benefits.

The Operator’s and Safety Manual also contains instructions for some adjustments and for maintenance of this fork-lift. Follow these instructions carefully while performing routine maintenance checks and keep a record of all maintenance. As wide variations in operating conditions may be experienced, you are urged to contact your AUSA Distributor to resolve any operational or service problems.

Please have all operators of this forklift read and understand this Operator’s and Safety Manual.

Any damage resulting from the incorrect use of the forklift shall not be considered to be the responsibility of AUSA. In the event of query, complaint or to place an order for spares, please contact your Official AUSA Dealer.

This forklift is designed and intended for off highway use. If it is temporarily operated on any public street or highway, the state and local laws governing speed, size, weight, brakes and lighting must be complied with.

For further information you may write, FAX or E-mail to:

AUSA Center, S.L.U.

Apartado P.O.B. 194

08243 MANRESA (Barcelona) SPAIN

Tel. 34-93 874 75 52 / 93 874 73 11

Fax 34-93 873 61 39 / 93 874 12 11 / 93 874 12 55

E-mail: ausa@ausa.com

Web: http://www.ausa.com

AUSA is continuously trying to improve the efficiency, productivity and safety of its products and reserves the right to make such improvements without incurring any obligation to make changes to forklifts previously sold. Because of this policy of striving for constant product improvement, the specifications and operating instructions shown in this Operator’s and Safety Manual may be different from prior forklift models. As such, we will not accept claims that are based on the data, illustrations or descriptions included in these instructions.

Only original AUSA spare parts should be used. This is the only way to

guarantee that AUSA machinery has the same operational level as at the time of delivery. No alterations should be made to the forklift without the prior authorization of the manufacturer.

When not in use keep it stored on the forklift in the Manual holder box in the engine’s

compartment in the control valve support (fig. 1).

MOP 120213 01

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Uses and improper uses of the forklift .................................................................... 5

Identification of the forklift components .................................................................. 6

Vehicle Identification and Serial Numbers .............................................................. 7

Technical Specifications .......................................................................................... 8

Controls and instruments ........................................................................................ 64

Instrument Panel and controls ................................................................................ 67

Operating the forklift ................................................................................................ 73

Special procedures ................................................................................................. 78

Special Safety Messages ........................................................................................ 81

Parking the machine ............................................................................................... 89

Transporting the machine ....................................................................................... 90

Maintenance Chart .................................................................................................. 95

Periodic Maintenance Operations ........................................................................... 97

Electric circuit

C300H / C300HI ................................................................................................ 121

C300H x4 / C300HI x4 / C350H / C350HI / C350H x4 / C350HI x4 .................. 126

Hydraulic diagram (Hydraulic appliances) ............................................................. 131

Hydraulic diagram (Transmission) .......................................................................... 132

C300H / C300HI ................................................................................................ 132

C300H x4 / C300HI x4 / C350H / C350HI / C350H x4 / C350HI x4 .................. 133

Transmission Troubleshooting ................................................................................ 134

EC Declaration of conformity ................................................................................. 135

Index

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Uses and improper

Uses of the forklift

 Uses for which the forklift is designed

Forklifts C300H-HI / C300H-HI x4 / C350H-HI / C350H-HI x4 have been designed and manufactured for lifting, handling and transporting loads on rough ground and industrial use. The safety of individuals and of the loads carried must be ensured through the use of forks or other accessories and equipment.

ROUGH TERRAIN USE (C300H / C350H)

This forklift truck is designed for transporting and lifting loads on grounds not in good condition, roughly flat, not too steep slopes and small obstacles, so that the stability conditions are not optimal.

INDUSTRIAL USE (C300HI / C350HI)

This forklift truck is designed for transporting and lifting loads on good condition floors, that means flat, levelled and paved ground, so that there are optimal stability conditions.

Any use other than that described above shall be considered inappropriate and therefore improper. Strict adherence to the operating, maintenance and repair conditions specified by the manufacturer are essential in order to maintain the forklift in good working order. Driving, maintenance and repair of the forklift should only be carried out by suitably qualified personnel, with the necessary tools and knowledge of the control and safety procedures relative to the forklift. When handling loads or carrying out maintenance and/or repair work, the occupational health and safety regulations, together with those relative to accident prevention, should be observed. When driving with the forklift on public highways, special care should be taken to ensure compliance with the current legislation for this type of vehicle (Highway Code). AUSA does not assume responsibility for any damage resulting from modifications made to the forklift without express authorization.

The texts following this symbol provide information on recycling and protecting the

environment.

 Improper use

Improper use is understood to mean the use of the forklift in a manner not in keeping with the criteria and instructions given in this Operator’s and Safety Manual and in a way which might cause damage to persons or objects. Some of the more common and dangerous examples of improper use are given below:

- Carrying persons other than the operator on the forklift.

- Not strictly observing the instructions for use and maintenance given in this Operator’s and Safety Manual.

- Exceeding the limits for load and centre of gravity given in the relevant load charts.

- Working on unstable, unshared grounds or at the edges of trenches and ditches.

- Working on excessively steep slopes.

- The use of accessories or equipment for purposes other than those for which they have been designed.

- The use of accessories or equipment not manufactured or authorized by AUSA.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Term such as right, left, front and rear when used in this Operator’s and Safety Manual indicate the right and left sides of the machine, the front and back of the machine, as viewed from the operators seat looking forward.

 Identification components

1- Overhead guard. 2- Driving and load control (Joystick) 3- Parking brake switch. 4- Driver seat with seat belt. 5- Diesel tank. 6- Hydraulic tank. 7- Forks. 8- Lifting mast. 9- Rotating beacon. 10- Lighting equipment (¬). 11- Rear-view mirror.

Identification of the

forklift components

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 ¡Important! Write your machine Model number, date of sale, chassis and engine

serial number in the spaces provided below. Give this information to your AUSA dealer when you need parts or information for your machine. Make a record of these numbers in your files.

Model number: .....................................................................

Date of sale: .........................................................................

Chassis serial number: ........................................................

Engine serial number: ..........................................................

 The Vehicle Identification Plate Is located at the left of the operators seat (fig. 1).

 The Chassis Serial Number Is located on the right side of the chassis (fig. 2).

 The Engine Serial Number Is located on the left side of the engine (fig. 3, 4).

 Principals components of identification plates

The plates of every components not built directly by AUSA, (for example: engines, pumps, etc.) are directly applied on the same components, in points where the respective makers put them origi

(fig. 3)(fig. 4) (fig. 2) (fig. 1)

V ehicle Identification

and Serial Numbers

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Dimensions (in)

DIMENSIONS C300H C300HI C300H x4 C300HI x4 C350H C350HI C350H x4 C350HI x4

A 7ft 2in 7ft 2in 7ft 2in 7ft 2in 7ft 4in 7ft 4in 7ft 4in 7ft 4in B 9in 9in 8in 8in 9in 9in 8in 8in C 1ft 1ft 1ft 1ft 1ft 2in 1ft 2in 1ft 2in 1ft 2in D 4ft 9in 4ft 9in 4ft 9in 4ft 9in 4ft 9in 4ft 9in 4ft 9in 4ft 9in

(narrow axle)

5ft 5ft 5ft 5ft 5ft 9in 5ft 9in 5ft 9in 5ft 9in

(wide axle)

6ft 1in - 6ft 1in - 6ft 3in - 6ft 3in -

F 11ft 5in 11ft 5in 15ft 5in 15ft 5in 11ft 5in 11ft 5in 15ft 5in 15ft 5in G 9ft 4in 9ft 4in 9ft 10in 9ft 10in 9ft 4in 9ft 4in 9ft 10in 9ft 10in

I 4,1in 4,1in 4,1in 4,1in 4,1in 4,1in 4,1in 4,1in J 1,1in 1,1in 1,1in 1,1in 1,1in 1,1in 1,1in 1,1in K 2ft 5in 2ft 5in 2ft 5in 2ft 5in 2ft 5in 2ft 5in 2ft 5in 2ft 5in L 14ft 9in 14ft 9in 14ft 9in 14ft 9in 14ft 9in 14ft 9in 14ft 9in 14ft 9in

M 1ft 11in 1ft 11in 1ft 11in 1ft 11in 1ft 11in 1ft 11in 1ft 11in 1ft 11in N 6ft 4in 6ft 4in 6ft 4in 6ft 4in 6ft 4in 6ft 4in 6ft 4in 6ft 4in O 3ft 11in 3ft 11in 3ft 11in 3ft 11in 3ft 11in 3ft 11in 3ft 11in 3ft 11in

P 51ft 11in 51ft 11in 22ft 3in 22ft 3in 51ft 11in 51ft 11in 22ft 3in 22ft 3in

 Dimensions (mm)

DIMENSIONS C300H C300HI C300H x4 C300HI x4 C350H C350HI C350H x4 C350HI x4

A 2200 2200 2200 2200 2240 2240 2240 2240

B 250 250 220 220 250 250 220 220 C 325 325 325 325 380 380 380 380 D 1460 1460 1460 1460 1460 1460 1460 1460

(narrow axle)

1540 1540 1540 1540 1770 1770 1770 1770

(wide axle)

1870 - 1870 - 1910 - 1910 -

F 3500 3500 4700 4700 3500 3500 4700 4700

G 2850 2850 3005 3005 2850 2850 3005 3005

I 120 120 120 120 120 120 120 120 J 50 50 50 50 50 50 50 50

K 750 750 750 750 750 750 750 750

L 4500 4500 4500 4500 4500 4500 4500 4500

M 600 600 600 600 600 600 600 600 N 1950 1950 1950 1950 1950 1950 1950 1950 O 1200 1200 1200 1200 1200 1200 1200 1200

P 5600 5600 6805 6805 5600 5600 6805 6805

Technical

Specifications

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Mast chart (in)

Type of mast

Maximum

lifting

height

(mm)

Front axle

Free lift

(mm)

Machine height with mast retracted (mm) C300H

C300HI

C350H

C350HI

C300Hx4 C350Hx4

Dúplex (Std.) 10ft 10in Narrow / Wide (op.) 4,1in 21ft 11in 8ft 9in 21ft 11in 8ft 9in

Dúplex 13ft 1in Narrow / Wide (op.) 4,1in 9ft 9in 9ft 9,1in 9ft 9in 9ft 9,1in

Triplex (free lift)

12ft 1in Narrow / Wide (op.) 3ft 11in 6ft 10in 6ft 10in 6ft 10in 6ft 10in

Triplex (free lift)

17ft 8in Wide 5ft 6in 5ft 6in 5ft 7in 5ft 6in 5ft 7in

Triplex (free lift)

22ft 2in Wide 7ft 6in - 10ft 6in - 10ft 6in

Type of mast

Machine height with

mast extended (mm)

Load (Kg) at max. height

C300H

C300HI

C300H x4

C350H

C350HI

C350H x4

(a)

C300H

C300H x4

(b)

C300HI

(a)

C300H

C300H x4

(b)

C350H

C350H x4

(a)

C350HI

(b)

C350H

C350H x4

(narrow

axle)

(narrow

axle)

(wide axle)

(narrow

axle)

(narrow

axle)

(wide axle)

Dúplex (Std.) 14ft 9in 14ft 9in 9ft 11in 9ft 11in 9ft 11in 11ft 5in 11ft 5in 11ft 5in

Dúplex 17ft 1in 17ft 1in 7ft 5in 8ft 5in 7ft 5in 9ft 11in 9ft 11in 11ft 5in

Triplex (free lift)

16ft 1in 16ft 1in 7ft 11in 5ft 7in 7ft 11in 10ft 6in 10ft 6in 11ft 5in

Triplex (free lift)

61ft 11in 61ft 11in - 4ft 3in 4ft 11in -- 4ft 11in 11ft 11in

Triplex (free lift)

- 25ft 7in - 3ft 4in - 3ft 11in 1ft 11in

 Mast chart (mm)

Type of mast

Maximum

lifting

height

(mm)

Front axle

Free lift

(mm)

Machine height with mast retracted (mm) C300H

C300HI

C350H

C350HI

C300Hx4 C350Hx4

Dúplex (Std.) 3300 Narrow / Wide (op.) 120 2600 2670 2600 2670

Dúplex 4000 Narrow / Wide (op.) 120 2950 2990 2950 2990

Triplex (free lift)

3700 Narrow / Wide (op.) 1200 2090 2130 2090 2130

Triplex (free lift)

5400 Wide 1680 2660 2700 2660 2700

Triplex (free lift)

6780 Wide 2280 - 3220 - 3220

Type of mast

Machine height with

mast extended (mm)

Load (Kg) at max. height

C300H

C300HI

C300H x4

C350H

C350HI

C350H x4

(a)

C300H

C300H x4

(b)

C300HI

(a)

C300H

C300H x4

(b)

C350H

C350H x4

(a)

C350HI

(b)

C350H

C350H x4

(narrow

axle)

(narrow

axle)

(wide axle)

(narrow

axle)

(narrow

axle)

(wide axle)

Dúplex (Std.) 4500 4500 3000 3000 3000 3500 3500 3500

Dúplex 5200 5200 2250 2550 2250 3000 3000 3500

Triplex (free lift)

4900 4900 2400 2700 2400 3200 3200 3500

Triplex (free lift)

6600 6600 - 1300 1500 -- 1500 1600

Triplex (free lift)

- 7820 - 1000 - 1200 600

Technical

Specifications

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Diesel engine

Four cylinders, four strokes, water-cooled. Electric starter. Mixed radiator (water/oil).

C300H / C300HI: KUBOTA V2403-M – E3B

Power 49.6 HP (36.5 kw at 2,600 rpm in accordance with SAE J 1995 Norm).

C300H x4 / C300HI x4 / C350H / C350HI / C350H x4 / C350HI x4: KUBOTA V3600T – E3B.

Power 66 CV (48.6 kw at 2,600 rpm in accordance with SAE J 1995 Norm).

See the engine instructions handbook.

 Transmission

Hydrostatic system, with variable flow pump and inching function. Hydrostatic motor with variable flow.

Maximum operating pressure: 6092 psi. (420 bar).

4WD FullGrip® system on-demand with immediate engagement and disengagement device.

 Directional control

The selection of the drive (forwards/ backwards) is made using a switch on the lower part of the joystick. A lamp in the shape of an arrow lights up on the top of it when a movement mode is selected.

 Steering

Hydrau lic powered with one double acting hydraulic cylinder on the rear axle.

Working pressure (all models): 2175 PSI (150 bar).

 External turning circle C300H: 11ft 5in (3500 mm) C350H: 11ft 5in (3500 mm) C300HI: 11ft 5in (3500 mm) C350HI: 11ft 5in (3500 mm) C300H x4: 15ft 5in (4700 mm) C350H x4: 15ft 5in (4700 mm) C300HI x4: 15ft 5in (4700 mm) C350HI x4: 15ft 5in (4700 mm)

Technical

Specifications

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Wheels Dimensions:

Dimensions Front wheels Rear wheels C300H 12.5/80 - 18” (16PR) 27x10 - 12” (14PR) C300HI 12.5/80 - 18” (16PR) 27x10 - 12” (14PR) C300H x4 12.5/80 - 18” (16PR) 10.0/75 - 15,3” (18PR) C300HI x4 12.5/80 - 18” (16PR) 10.0/75 - 15,3” (18PR) C350H 16/70 - 20” (14PR) 27x10 - 12” (14PR) C350HI 16/70 - 20” (14PR) 27x10 - 12” (14PR) C350H x4 16/70 - 20” (14PR) 10.0/75 - 15,3” (18PR) C350HI x4 16/70 - 20” (14PR) 10.0/75 - 15,3” (18PR)

Pressures:

Pressures Front wheels Rear wheels C300H 5 ± 0,5 bar 6,5 ± 0,7 bar C300HI 5 ± 0,5 bar 6,5 ± 0,7 bar C300H x4 5 ± 0,5 bar 5 ± 0,5 bar C300HI x4 5 ± 0,5 bar 6 ± 0,7 bar C350H 3,5 ± 0,4 bar 6,5 ± 0,7 bar C350HI 3,5 ± 0,4 bar 6,5 ± 0,7 bar C350H x4 3,5 ± 0,4 bar 5 ± 0,5 bar C350HI x4 3,5 ± 0,4 bar 5 ± 0,5 bar

 Brakes Service brake. Multidisc sealed hydraulic brake. Parking brake. Multidisc sealed brake spring applied, hydraulically released.

 Hydraulic circuit

Activated by double gear pump; one gear for the drive circuit and one for the hydraulic steering, connected to the hydrostatic pump of the transmission.

Pump flows:

Pump flows

C300H

36/12 l/min a 1500 rpm

C300HI C300H x4

45/12 l/min a 1500 rpm

C300HI x4 C350H C350HI C350H x4 C350HI x4

Monoblock control valve with two spools and selectable solenoid for side-shift. Restrictor valve to control the speed of the mast lowering with load.

Oil tank capacity: 22 US Gal (85 l.)

 Working temperature

From 5ºF to 104F. (From -15ºC to 40ºC)

Technical

Specifications

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Vibration and noise levels Sound power level:

Warrantee sound power (according to 2000/14/EC sound emissions in the environment by machinery for outdoor use):

• Lwa = 104 dB (A)

Sound pressure level on the operator’s site:

A weighted sound pressure in the operator’s ear measured (following norms EN 12053 and ISO 4871):

• Kubota V2403-M - E3B: Lpa = 82 dB (A)

• Kubota V3600T - E3B: Lpa = 84 dB (A)

Measurement uncertainty: 2,5 dB (A)

Vibration level produced by the machine:

Root-mean-square frequency-weighted, hand-arm vibration acceleration value: < 2,5 m/s

Root-mean-square frequency-weighted, whole body vibration acceleration value: < 0,5 m/s

 Electrical equipment

Starter motor: Pre-heating spark plugs. Electrical starter 2,0 Kw. (V2403M-E3B engine) and 3.0 kW (V3600T-E3B engine).

480W alternator and regulator (V2403M-E3B engine) and 720W (V3600T-E3B engine). engine).

Battery: 12V / 110Ah (motor V2403M-E3B) y 12V / 92 Ah / 760A (V3600T-E3B engine).

Rotating beacon, horn, back-up alarm, engine oil pressure alarm, hydraulic oil level alarm, coolant temperature alarm.

 Weights Unladen weight (with full tanks): C 300 H-HI: 12566 lb. (5700 kg.) C 300 H-HI x4: 12566 lb. (5700 kg.) C 350 H-HI: 13228 lb. (6000 kg.) C 350 H-HI x4: 13228 lb. (6000 kg.)

Fully laden weight: C 300 H-HI: 19180 lb. (8700 kg.) C 300 H-HI x4: 19180 lb. (8700 kg.) C 350 H-HI: 20944 lb. (9500 kg.) C 350 H-HI x4: 20944 lb. (9500 kg.)

 Load Capacity

With the load center of the load at 19,6 inches (500 mm) (see LOAD CHARTS In this

manual)

C300H-HI / C300H-HI x4: 6614 lb. (3000 Kg.) C350H-HI / C350H-HI x4: 7716 lb. (3500 Kg.)

With the load center at 24 inches (600 mm) (see LOAD CHARTS In this manual) C300H-HI / C300H-HI x4: 6614 lb. (3000 Kg.) C350H-HI / C350H-HI x4: 7716 lb. (3500 Kg.)

Technical

Specifications

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Standard mast

Side-shift 3ft 11in. (1200 mm ) width Lifting height: 10ft. 10in. (3300 mm). Free litf: 4 in. (120 mm). Forks length: 3ft 11in. (1200 mm).

C300H / C300HI / C300H x4 / C300HI x4

MAST Lift height (mm) h1 (mm) h2 (mm) h3 (mm) h4 (mm)

DUPLEX

3300 2480 ≥120 3250 ≥4500 4000 2830 ≥120 3950 ≥5200

TRIPLEX

3700 2130 ≥1200 3650 ≥4900 5400 2698 ≥1680 5350 ≥6600

C300H / C300HI / C300H x4 / C300HI x4

MAST Lift height (in) h1 (in) h2 (in) h3 (in) h4 (in)

DUPLEX

10ft 10in 7ft 11in ≥4in 10ft 7in ≥14ft 9in

13ft 1in 9ft 3in ≥4in 12ft 11in ≥17ft

TRIPLEX

12ft 2in 6ft 11in ≥3ft 11in 11ft 11in ≥16ft 17ft 8in 8ft 10in ≥5ft 6in 17ft 6in ≥21ft 7in

C350H / C350HI / C350H x4 / C350HI x4

MAST Lift height (mm) h1 (mm) h2 (mm) h3 (mm) h4 (mm)

DUPLEX

3300 2480 ≥120 3250 ≥4500 4000 2830 ≥120 3950 ≥5200

TRIPLEX

3700 2130 ≥1200 3650 ≥4900 5400 2698 ≥1680 5350 ≥6600 6850 3180 2200 6800 7780

C350H / C350HI / C350H x4 / C350HI x4

MAST Lift height (in) h1 (in) h2 (in) h3 (in) h4 (in)

DUPLEX

10ft 10in 7ft 11in ≥4in 10ft 7in ≥14ft 9in

13ft 1in 9ft 3in ≥4in 12ft 11in ≥17ft

TRIPLEX

12ft 2in 6ft 11in ≥3ft 11in 11ft 11in ≥16ft 17ft 8in 8ft 10in ≥5ft 6in 17ft 6in ≥21ft 7in 22ft 5in 10ft 5in 7ft 2in 22ft 3in 25ft 6in

 Fork carriage

Clase FEM III.

 Lifting speed

C300H

Without load: 0,42 m/sec. With load: 0,4 m/sec.

Without load: 8 ft/min. With load: 7 ft/min

C300HI C300H x4

Without load: 0,48 m/sec. With load: 0,48 m/sec.

Without load: 7 ft/min. With load: 7 ft/min

C300HI x4 C350H C350HI C350H x4 C350HI x4

Technical

Specifications

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Lowering speed

C300H

Without load: 21 m/min. With load: 32,2 m/min

Without load: 6 ft/min. With load: 10 ft/min

C300HI C300H x4

Without load: 21,6 m/min. With load: 34,8 m/min

Without load: 7 ft/min. With load: 11 ft/min

C300HI x4 C350H C350HI C350H x4 C350HI x4

WARNING

This forklift is not designed to travel with elevated load or with the mast tilted forward. Do not tilt forward the mast with the forks elevated except to pick up or deposit the load.

 Control panel

The controls, switches and warning lights are integrated in the steering column and below the joystick.

 Lighting ()

Work lighting equipment, steering indicators, parking lights and warning.

 Overhead guard

Manufactured according with ISO 6055.

WARNING

The operator is protected by an overhead guard which complies with the ISO 3449 and ISO 3471 / ASME B56.6 standards. It provides protection against falling objects and together with the mast, provides protection should the forklift overturn. The seat belt is an important part of the safety system and should always be fastened before starting to operate the forklift. In the event of the forklift overturning, if the seat belt is not fastened the operator may suffer serious injury or even loss of life as a result of crushing from the forklift or even the overhead guard itself.

 Aisle widths

See graph.

Technical

Specifications

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

ROUGH TERRAIN USE (C300H / C350H)

Load charts for C300H / C300H x4 front wide axle (500 mm. load centre)

Load charts for C300H / C300H x4 front wide axle(600 mm. load centre)

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3 3,7 4

3000

2771

2574

2404

2255

2123

2005

1900

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3 4 3,7

2771

2574

2404

2255

2123

2005

1900

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

5,4

1500

1385

1285

1202

1127

1061

1003

950

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

5,4

1385

1285

1202

1127

1061

1003

950

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

6,85

2000

1847

1716

1603

1503

1415

1337

1267

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

6,85

1847

1716

1603

1503

1415

1337

1267

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C300H / C300H x4 front wide axle (24 in. load centre)

C300H / C300H x4

10ft 10in 12ft 2in 13ft 1in

6.109

5.675

5.291

4.971

4.680

4.420

4.189

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

C300H / C300H x4

17ft 8in

3.053

2.832

2.649

2.484

2.339

2.211

2.094

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

C300H / C300H x4

22ft 5in

4.071

3.783

3.534

3.313

3.119

2.947

2.793

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C300H / C300H x4 wide front axle and quick attach fork carriage (500 mm. load centre)

Load charts for C300H / C300H x4 wide front axle and quick attach fork carriage (600 mm. load centre)

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3 4 3,7

2858

2650

2469

2312

2174

2051

1941

1843

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3 4 3,7

2650

2469

2312

2174

2051

1941

1843

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

5,4

1429

1325

1235

1156

1087

1025

971

921

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

5,4

1325

1235

1156

1087

1025

971

921

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C300H / C300H x4 wide front axle and quick attach fork carriage (24 in. load centre)

C300H / C300H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

10ft 10in 13ft 1in 12ft 2in

5.643

5.443

5.097

4.792

4.521

4.279

4.063

C300H / C300H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

17ft 8in

2.921

2.722

2.548

2.396

2.259

2.140

2.030

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C300H / C300H x4 front narrow axle (500 mm. load centre)

Load charts for C300H / C300H x4 front narrow axle(600 mm. load centre)

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

2078

1931

1803

1961

1592

1504

1425

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,7

2217

2060

1923

1804

1698

1604

1520

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3

2771

2574

2404

2255

2123

2005

1900

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

2250

2078

1931

1803

1961

1592

1504

1425

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,7

2400

2217

2060

1923

1804

1698

1604

1520

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3

3000

2771

2574

2404

2255

2123

2005

1900

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C300H / C300H x4 front narrow axle (24 in. load centre)

C300H / C300H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

13ft 1in

4.581

4.257

3.974

3.728

3.509

3.315

3.141

C300H / C300H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

12ft 2in

4.887

4.541

4.239

3.977

3.743

3.536

3.351

C300H / C300H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

10ft 10in

6.109

5.675

5.291

4.971

4.680

4.420

1.189

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C300H / C300H x4 front narrow axle and and quick attach fork carriage (500 mm. load centre)

Load charts for C300H / C300H x4 front narrow axle and and quick attach fork carriage (600 mm. load centre)

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

2144

1987

1852

1734

1630

1538

1456

1382

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,7

2287

2120

1976

1850

1739

1641

1553

1474

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3

2858

2650

2469

2312

2174

2051

1941

1843

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

1987

1852

1734

1630

1538

1456

1382

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,7

2120

1976

1850

1739

1641

1553

1474

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3

2650

2469

2312

2174

2051

1941

1843

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C300H / C300H x4 front narrow axle and and quick attach fork carriage (24 in. load centre)

C300H / C300H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

13ft 1in

4.380

4.082

3.822

3.593

3.390

3.209

3.046

C300H / C300H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

12ft 5in

4.673

4.356

4.078

3.833

3.617

3.423

3.249

C300H / C300H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

10ft 10in

5.842

5.502

5.097

4.792

4.521

4.279

4.063

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C350H / C350H x4 front narrow axle (500 mm. load centre)

Load charts for C350H / C350H x4 front narrow axle (600 mm. load centre)

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

2771

2574

2404

2255

2123

2005

1900

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,7

2956

2746

2564

2404

2264

2139

2027

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3

3233

3004

2805

2630

2477

2340

2217

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3000

2771

2574

2404

2255

2123

2005

1900

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,7

3200

2956

2746

2564

2404

2264

2139

2027

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3

3500

3233

3004

2805

2630

2477

2340

2217

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C350H / C350H x4 front narrow axle (24 in. load centre)

C350H / C350H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

13ft 1in

6.109

5.674

5.299

4.971

4.680

4.420

4.188

C350H / C350H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

12ft 2in

6.516

6.053

5.652

5.299

4.991

4.715

4.468

C350H / C350H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

10ft 10in

7.127

6.622

6.183

5.798

5.460

5.158

4.887

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C350H / C350H x4 front narrow axle and and quick attach fork carriage (500 mm. load centre)

Load charts for C350H / C350H x4 front narrow axle and and quick attach fork carriage (600 mm. load centre)

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

2650

2469

2312

2174

2051

1941

1843

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,7

2826

2634

2466

2319

2188

2071

1965

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3

3091

2881

2697

2536

2393

2265

2150

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

2858

2650

2469

2312

2174

2051

1941

1843

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,7

3049

2826

2634

2466

2319

2188

2071

1965

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3

3335

3091

2881

2697

2536

2393

2265

2150

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C350H / C350H x4 front narrow axle and and quick attach fork carriage (24 in. load centre)

C350H / C350H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

13ft 1in

5.842

5.443

5.097

4.792

4.521

4.279

4.063

C350H / C350H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

12ft 2in

6.230

5.806

5.436

5.112

4.823

4.565

4.332

C350H / C350H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

10ft 10in

6.814

6.351

5.945

5.590

5.275

4.993

4.739

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C350H / C350H x4 wide axle (500 mm. load centre)

Load charts for C350H / C350H x4 wide axle (600 mm. load centre)

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

6,85

554

515

481

451

425

401

280

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

5,4

1478

1373

1282

1202

1132

1070

1014

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3 4 3,7

3233

3004

2805

2630

2477

2340

2217

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

6,85

600

554

515

481

451

425

401

280

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

5,4

1600

1478

1373

1282

1202

1132

1070

1014

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3 4 3,7

3500

3223

3004

2508

2630

2477

2340

2217

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C350H / C350H x4 wide axle (24 in. load centre)

C350H / C350H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

22ft 5in

1.221

1.135

1.060

0.994

0.936

0.884

0.617

C350H / C350H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

17ft 8in

3.258

3.026

2.826

2.649

2.495

2.358

2.235

C350H / C350H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

10ft 10in 13ft 1in 12ft 2in

7.127

6.622

6.183

5.798

5.460

5.158

4.887

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C350H / C350H x4 front wide axle and and quick attach fork carriage (500 mm. load centre)

Load charts for C350H / C350H x4 front wide axle and and quick attach fork carriage (600 mm. load centre)

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

6,85

530

494

462

435

410

388

369

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

5,4

1413

1317

1233

1159

1094

1035

983

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3 4 3,7

3091

2881

2697

2536

2393

2265

2150

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

6,85

572

530

494

462

435

410

388

369

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

5,4

1524

1413

1317

1233

1159

1094

1035

983

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350H / C350H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3 4 3,7

3335

3091

2881

2697

2536

2393

2265

2150

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C350H / C350H x4 front wide axle and and quick attach fork carriage (24 in. load centre)

C350H / C350H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

22ft 5in

1.168

1.089

1.018

0.959

0.903

0.855

0.813

C350H / C350H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

17ft 8in

3.115

2.903

2.718

2.555

2.411

2.281

2.167

C350H / C350H x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

10ft 10in 13ft 1in 12ft 2in

6.814

6.351

5.945

5.590

5.256

4.993

4.739

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

INDUSTRIAL USE (C300HI / C350HI)

This forklift truck is designed for transporting and lifting loads on good condition floors, that means flat, levelled and paved ground, so that there are optimal stability conditions.

Load charts for C300HI narrow axle (500 mm. load centre)

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C300HI

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

5,4

1300

1200

1120

1050

980

920

880

830

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C300HI

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

2550

2310

2150

2010

1890

1780

1690

1600

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C300HI

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,7

2700

2500

2320

2180

2040

1930

1820

1730

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C300HI

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3

3000

2771

2574

2404

2255

2123

2005

1900

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C300HI narrow axle (600 mm. load centre)

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C300HI

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

5,4

1200

1120

1050

980

920

880

830

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C300HI

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

2310

2150

2010

1890

1780

1690

1600

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C300HI

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,7

2500

2320

2180

2040

1930

1820

1730

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C300HI

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3

2771

2574

2404

2255

2123

2005

1900

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C300HI narrow axle (24 in. load centre)

C300HI

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

17ft 8in

2.866

2.645

2.469

2.314

2.160

2.028

1.829

C300HI

13ft 1in

5.092

4.739

4.431

4.166

3.924

3.725

3.527

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

C300HI

12ft 2in

5.511

5.114

4.806

4.497

4.254

4.012

3.813

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

C300HI

10ft 10in

6.109

5.675

5.291

4.971

4.680

4.420

4.189

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C350HI / C350HI x4 wide axle (500 mm. load centre)

Load charts for C350HI / C350HI x4 wide axle (600 mm. load centre)

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350HI / C350HI x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

6,85

1847

1716

1603

1503

1415

1337

1267

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350HI / C350HI x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

5,4

2956

2746

2564

2405

2264

2139

2027

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350HI / C350HI x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

6,85

2000

1847

1716

1603

1503

1415

1337

1267

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350HI / C350HI x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

5,4

3200

2956

2746

2564

2405

2264

2139

2027

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C350HI / C350HI x4 wide axle (24 in. load centre)

C350HI / C350HI x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

22ft 5in

4.071

3.783

3.534

3.313

3.119

2.947

2.793

C350HI / C350HI x4

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

17ft 8in

6.516

6.053

5.652

5.302

4.991

4.715

4.468

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C350HI narrow axle (500 mm. load centre)

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350HI

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

6,85

1200

1110

1030

970

910

860

810

770

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350HI

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

5,4

1500

1390

1290

1210

1140

1070

1000

960

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350HI

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3000

2771

2574

2404

2255

2123

2005

1900

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350HI

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,7

3200

2956

2746

2564

2404

2264

2139

2027

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110 120

G kgs

C350HI

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3

3500

3233

3004

2805

2630

2477

2340

2217

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C350HI narrow axle (600 mm. load centre)

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350HI

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

6,85

1110

1030

970

910

860

810

770

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350HI

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

5,4

1390

1290

1210

1140

1070

1000

690

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350HI

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

2771

2574

2404

2255

2123

2005

1900

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350HI

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,7

2956

2746

2564

2404

2264

2139

2027

08243 MANRESA (ESPAÑA)

30.12004.00

AUSA Center, S.L.U.

D cm.

60 70 80 90 100 110 120

G kgs

C350HI

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3

3233

3004

2805

2630

2477

2340

2217

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Load charts for C350HI narrow axle (24 in. load centre)

C350HI

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

22ft 5in

2.425

2.447

2.270

2.138

2.006

1.895

1.697

C350HI

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

17ft 8in

3.064

2.843

2.667

2.513

2.358

2.204

2.116

C350HI

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

13ft 1in

6.109

5.675

5.291

4.971

4.680

4.420

4.189

C350HI

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

12ft 2in

6.516

6.053

5.652

5.299

4.991

4.715

4.468

C350HI

08243 MANRESA (SPAIN)

43.01350.28

AUSA Center, S.L.U.

D = Load center extension from face of forks

D inches

24 28 32 36 40 44 48

G LBS

MAXIMUM FORKLIFT LOAD

ON LEVEL SURFACE

MODEL

10ft 10in

7.127

6.622

6.183

5.798

5.460

5.158

4.887

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Optional equipment

Optional equipment is marked with an asterisk (). Optional equipment is only supplied

at the express wish of the customer, for certain versions of forklift or even only in certain countries.

- 4000 mm. maximum height Duplex Mast

- 3700 mm, 5400 mm and 6780 mm maximum height Triplex mast (free lift)

- Load back-rest

- Wheels: solid, super-elastic and extra wide

- Oxi-catalytic exhaust purifier

- Exhaust Spark arrestor

- Partially closed or close cab with heating

- 600, 800 and 1000 l. hydraulic shovels

- Extra hydraulic connection for attachments

- Lightning equipment

- Front laminated windshield with wiper

- Rear windshield

- 1870mm. width front axle for C300H / C300HI / C300H x4 / C300HI x4

- Fuel filter with water separator

Where the forklift comes equipped with accessories mounted at factory, please read the relevant Instruction Manual for each accessory carefully before use. Each accessory has its own Instruction Manual issued by the manufacturer, and this is provided with the forklift Operator’s and Safety Manual.

Where accessories and equipment are fitted to the basic chassis or fork carriage plate at a later date by companies other than the manufacturer, the specifications and limitations of the forklift with respect to weight and dimensions, the adjustment and effectiveness of the lighting system, the protective system requirements, or any additional systems required to guarantee vehicle safety should be taken into consideration.

Technical

Specifications

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (except USA)

STICKER:

JOYSTICK FUNCTION

REFERENCE: DESCRIPTION: QUANTITY:

10.15003.01 INDICATIVE STICKER 60X75 1

POSITION:

Stuck on the inside of the right front fender, in the top center position. Just above sticker ref. 10.15005.01, at 0.1969 in.

STICKER:

JOYSTICK FUNCTION BUTTONS

REFERENCE: DESCRIPTION: QUANTITY:

10.15005.01 INDICATIVE STICKER MAST SIDE SHIFT 1

POSITION:

Stuck on the inside of the right front fender, in the top center position. Just above sticker ref. 10.15003.01, at 0.1969 in.

STICKER:

JOYSTICK FUNCTION BUTTONS

REFERENCE: DESCRIPTION: QUANTITY:

10.15009.00

INDICATIVE STICKER AUXILIAR HYDRAULIC LINE ()

POSITION:

Stuck on the inside of the right front fender, in the top center position. Just above sticker ref. 10.15005.01, at 0.1969 in.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (except USA)

STICKER:

JOYSTICK FUNCTION BUTTONS

REFERENCE: DESCRIPTION: QUANTITY:

10.15011.00

INDICATIVE STICKER 4WD CONNECTION ()

POSITION:

Stuck on the inside of the right front fender, in the top center position. Just above sticker ref. 10.15005.01 o 10.15009.00, at 0.1969 in.

STICKER:

DANGEROUS AREA

REFERENCE: DESCRIPTION: QUANTITY:

45.01352.00 INDICATIVE STICKER 2

POSITION:

On both sides of the mast, above the beam, with its upper side aligned at 4ft 92 in from the ground, below the sticker ref. 13.12136.00 “AUSA Make”, and 0.3937 in away from it.

STICKER:

TO HOIST MACHINE

REFERENCE: DESCRIPTION: QUANTITY:

58.01353.01 INDICATIVE STICKER 105X100 2

POSITION:

On the left side of the machine, at the lower exterior part of the front fender, aligned on its upper side with sticker 45.19101.00 “EC mark”.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (except USA)

STICKER:

AUSA

REFERENCE: DESCRIPTION: QUANTITY:

13.12136.00 AUSA STICKER 2

POSITION:

On both sides of the machine, at a distance of 0.984 in and a height of 1.969 in from the lower rear corner of each tank, aligned with the bottom of the tank.

STICKER:

FRONT AXLE WHEELS INFLATED PRESSURE (modelos C350H / C350HI / C350H x4 / C350HI x4)

REFERENCE: DESCRIPTION: QUANTITY:

01.12103.00 INDICATIVE STICKER 3,5 BAR / 51 PSI 2

POSITION:

On both sides of the machine, above the fenders of the front wheels, at the front outer end of the fenders, aligned with the outer edge.

STICKER:

FRONT AXLE WHEELS INFLATED PRESSURE (modelos C300H / C300HI / C300H x4 / C300HI x4)

REFERENCE: DESCRIPTION: QUANTITY:

01.12106.00 INDICATIVE STICKER 5 BAR / 74 PSI 2

POSITION:

On both sides of the machine, above the fenders of the front wheels, at the front outer end of the fenders, aligned with the outer edge.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (except USA)

STICKER:

REAR AXLE WHEELS INFLATED PRESSURE (C300H x4 / C350H x4 / C350HI x4)

REFERENCE: DESCRIPTION: QUANTITY:

01.12106.00 INDICATIVE STICKER 5 BAR / 74 PSI 2

POSITION:

On both sides of the machine, on top of the vertical face, in the upper rear position of each tank, aligned with the bottom of the tank.

STICKER:

REAR AXLE WHEELS INFLATED PRESSURE (C300HI x4)

REFERENCE: DESCRIPTION: QUANTITY:

32.12102.00 INDICATIVE STICKER 6 BAR / 89 PSI 2

POSITION:

On both sides of the machine, on top of the vertical face, in the upper rear position of each tank, aligned with the bottom of the tank.

STICKER:

REAR AXLE WHEELS INFLATED PRESSURE (C300H / C300HI / C350H / C350HI x4)

REFERENCE: DESCRIPTION: QUANTITY:

01.12107.01 INDICATIVE STICKER 6,5 BAR / 96 PSI 2

POSITION:

On both sides of the machine, on top of the vertical face, in the upper rear position of each tank, aligned with the bottom of the tank.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (except USA)

STICKER:

FUEL TYPE INDICATION

REFERENCE: DESCRIPTION: QUANTITY:

43.01356.00 INDICATIVE STICKER 90x45 FUEL 1

POSITION:

On the right tank of the machine, next to the fuel cap, aligned with the vertical outer wall of the tank.

STICKER:

EC INDICATION

REFERENCE: DESCRIPTION: QUANTITY:

45.19101.00 INDICATIVE STICKER 70x70 2

POSITION:

On the left side of the machine, at the bottom inner side of the front fenders, aligned on its upper side with mark id 58.01353.01 “To hoist machine”.

STICKER:

HYDRAULIC OIL TYPE

REFERENCE: DESCRIPTION: QUANTITY:

43.01352.20 INDICATIVE STICKER 70x32 HYDRAULIC OIL 1

POSITION:

On the left-hand side tank, below the filler cap, aligned with the inner edge of the tank, and centered with the cap.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (except USA)

STICKER:

ENGINE OIL TYPE

REFERENCE: DESCRIPTION: QUANTITY:

43.01170.02 INDICATIVE STICKER 90x45 1

POSITION:

On the inner cab lock, easily legible with the cab raised.

STICKER:

MACHINE MODEL INDICATION (C300H - C300H x4 )

REFERENCE: DESCRIPTION: QUANTITY:

57.12001.00 INDICATIVE STICKER 68x267 MODEL C300H / HI 2

POSITION:

On both sides of the machine, at a distance of 0.984 in and a height of 5.906 in from the lower rear corner of each tank, aligned with the bottom of the tank.

STICKER:

MACHINE MODEL INDICATION (C350H - C350H x4 )

REFERENCE: DESCRIPTION: QUANTITY:

57.12002.00 INDICATIVE STICKER 68x267 MODEL C350H / HI 2

POSITION:

On both sides of the machine, at a distance of 1.969 in and a height of 5.906 in from the lower rear corner of each tank, aligned with the bottom of the tank.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (except USA)

STICKER:

CHARACTERISTICS PLATE

REFERENCE: DESCRIPTION: QUANTITY:

01.00779.26 PLATE CHARACTERISTICS 100x130 1

POSITION:

Riveted on top of the engine bulkhead, on its rear upper left-hand side (in forward direction of machine), in the holes prepared. Etched according to assembly instruction.

STICKER:

AUSA ANAGRAM

REFERENCE: DESCRIPTION: QUANTITY:

46.08099.00 AUSA ANAGRAM 1

POSITION:

Embedded in the cab front panel, on its outer side, in the upper left-hand part (in forward direction of machine).

STICKER:

WARNING IN CASE OF OVERTURNING THE MACHINE

REFERENCE: DESCRIPTION: QUANTITY:

12.12010.00 SAFETY STICKER 1

POSITION:

Top left-hand corner of the dashboard, under sticker ref. 02.00774.00 “Do not use” and aligned with this on its left side.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (except USA)

STICKER:

ACOUSTIC OPERATOR PROTECTION

REFERENCE: DESCRIPTION: QUANTITY:

01.00757.00 INDICATIVE STICKER D40 1

POSITION:

Top left-hand corner of the instrument panel, under sticker 02.00774.00 “Do not use”, aligned with this on its right side and centered with sticker ref. 12.12010.00.

STICKER:

POINT HOISTED MACHINE

REFERENCE: DESCRIPTION: QUANTITY:

09.15720.00 INDICATIVE STICKER 35x35 4

POSITION:

Above each of the four eyebolts at the bottom of the frame for lifting the machine.

STICKER:

MAXIMUM SOUND LEVEL

REFERENCE: DESCRIPTION: QUANTITY:

09.12014.00 STICKER NOISE 104 DB 1

POSITION:

On the inside of the right front wheel arch, aligned with the cab floor.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (except USA)

STICKER:

FullGrip® System

REFERENCE: DESCRIPTION: QUANTITY:

43.00397.00 INDICATIVE STICKER 110x110 2

POSITION:

On both sides of the machine, next to the AUSA sticker (ref. 13.12136.00) and aligned on the right side.

STICKER:

MAST TILTING FORWARD MARKER (MACHINES WITH SEMI-CLOSED AND FULL CAB)

REFERENCE: DESCRIPTION: QUANTITY:

57.12010.00 INDICATIVE STICKER LOWERING MAST 1

POSITION:

Into the cabin, on the left side of the engine’s cover next to the handle that releases the cabin latch.

STICKER:

NON MOVEMENTS WITH LOAD OFFCENTERED (MASTS OF MORE THAN 3,7M / 12ft 2 in)

REFERENCE: DESCRIPTION: QUANTITY:

43.02187.02 INDICATIVE STICKER 70x210 ENGLISH 1

POSITION:

In the upper part of the dashboard, next to the sticker ref. 02.00777.00 “Do not use” aligned with this on its upper side.

* In heated enclosed cab, position at the bottom left-hand side of the window

0.3937 in away from the edge (bottom left side).

Heated cab

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (except USA)

STICKER:

AUSA STICKER

REFERENCE: DESCRIPTION: QUANTITY:

13.12136.00 AUSA STICKER 2

POSITION:

On both sides of the mast, above the beam, with its lower side aligned at 4ft 95 in from the ground, above the sticker ref. 45.01352.00 “Dangerous area”, and

0.3937 in away from it.

STICKER:

INDICATION TRANSFER BOX OIL.

REFERENCE: DESCRIPTION: QUANTITY:

43.00396.02 INDICATIVE STICKER 60x95 1

POSITION:

Into the engine compartment on the external face of the joystick control valve support, above “Brake fluid indication” sticker.

STICKER:

NOT USE WITHOUT AUTHORIZATION

REFERENCE: DESCRIPTION: QUANTITY:

02.00777.00 INDICATIVE STICKER 50x120 ENGLISH 1

POSITION:

Top left-hand corner of the dashboard, aligned on its left side with sticker nº

12.12010.00 “Safety warning”.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (except USA)

STICKER:

BRAKE FLUID INDICATION

REFERENCE: DESCRIPTION: QUANTITY:

43.70780.01 INDICATIVE STICKER 60x100 BRAKE 1

POSITION:

Into the engine compartment on the external face of the joystick control valve support, below “Transfer box oil” sticker.

STICKER:

HOT PARTS INDICATION

REFERENCE: DESCRIPTION: QUANTITY:

02.00765.00 INDICATIVE STICKER 40x80 ENGLISH 1

POSITION:

Inside the counterweight, near the exhaust manifold, easily readable when trying to work on the engine.

STICKER:

LOAD CHART PLATE

REFERENCE: DESCRIPTION: QUANTITY:

43.01350.28 / 30.12004.00 INDICATIVE PLATE 91x156 LOAD CHARTS 1

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3

3000

2771

2574

2404

2255

2123

2005

1900

POSITION:

Riveting in 4 holes provided, in the central outer part the left-hand front fender. Etched according to assembly instruction. * Add another unit at the top in the event of installing a mast higher than 12ft 14 in.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (USA Market)

STICKER:

JOYSTICK FUNCTION. SUBSTITUTE REF. 10.15003.01

REFERENCE: DESCRIPTION: QUANTITY:

10.15006.01 INDICATIVE STICKER 60X75 1

POSITION:

Stuck on the inside of the right front fender, in the top center position. Just above sticker ref. 10.15008.01, at 0.1969 in.

STICKER:

JOYSTICK FUNCTION . SUBSTITUTE REF. 10.15005.01

REFERENCE: DESCRIPTION: QUANTITY:

10.15008.01 INDICATIVE STICKER MAST SIDE-SHIFT (USA) 1

POSITION:

Stuck on the inside of the right front fender, in the top center position. Just above sticker ref. 10.15006.01, at 0.1969 in.

STICKER:

JOYSTICK FUNCTION BUTTONS

REFERENCE: DESCRIPTION: QUANTITY:

10.15009.00

INDICATIVE STICKER AUXILIAR HYDRAULIC LINE ()

POSITION:

Stuck on the inside of the right front fender, in the top center position. Just above sticker ref. 10.15005.01, at 0.1969 in.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (USA Market)

STICKER:

JOYSTICK FUNCTION BUTTONS

REFERENCE: DESCRIPTION: QUANTITY:

10.15011.00

INDICATIVE STICKER 4WD CONNECTION ()

POSITION:

Stuck on the inside of the right front fender, in the top center position. Just above sticker ref. 10.15005.01 o 10.15009.00, at 0.1969 in.

STICKER:

DANGEROUS AREA.. SUBSTITUTE REF. 45.01352.00

REFERENCE: DESCRIPTION: QUANTITY:

45.01352.01 INDICATIVE STICKER 2

POSITION:

On both sides of the mast, above the beam, with its upper side aligned at 4ft 92 in from the ground, below the sticker ref. 13.12136.00 “AUSA Make”, and 0.3937 in away from it.

STICKER:

TO HOIST MACHINE

REFERENCE: DESCRIPTION: QUANTITY:

58.01353.01 INDICATIVE STICKER 105X100 2

POSITION:

On the left side of the machine, at the lower exterior part of the front fender, aligned on its upper side with sticker 45.19101.00 “EC mark”.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (USA Market)

STICKER:

AUSA

REFERENCE: DESCRIPTION: QUANTITY:

13.12136.00 AUSA STICKER 2

POSITION:

On both sides of the machine, at a distance of 0.984 in and a height of 1.969 in from the lower rear corner of each tank, aligned with the bottom of the tank.

STICKER:

FRONT AXLE WHEELS INFLATED PRESSURE (modelos C350H / C350HI / C350H x4 / C350HI x4)

REFERENCE: DESCRIPTION: QUANTITY:

01.12103.00 INDICATIVE STICKER 3,5 BAR / 51 PSI 2

POSITION:

On both sides of the machine, above the fenders of the front wheels, at the front outer end of the fenders, aligned with the outer edge.

STICKER:

FRONT AXLE WHEELS INFLATED PRESSURE (modelos C300H / C300HI / C300H x4 / C300HI x4)

REFERENCE: DESCRIPTION: QUANTITY:

01.12106.00 INDICATIVE STICKER 5 BAR / 74 PSI 2

POSITION:

On both sides of the machine, above the fenders of the front wheels, at the front outer end of the fenders, aligned with the outer edge.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (USA Market)

STICKER:

REAR AXLE WHEELS INFLATED PRESSURE (C300H x4 / C350H x4 / C350HI x4)

REFERENCE: DESCRIPTION: QUANTITY:

01.12106.00 INDICATIVE STICKER 5 BAR / 74 PSI 2

POSITION:

On both sides of the machine, on top of the vertical face, in the upper rear position of each tank, aligned with the bottom of the tank.

STICKER:

REAR AXLE WHEELS INFLATED PRESSURE (C300HI x4)

REFERENCE: DESCRIPTION: QUANTITY:

32.12102.00 INDICATIVE STICKER 6 BAR / 89 PSI 2

POSITION:

On both sides of the machine, on top of the vertical face, in the upper rear position of each tank, aligned with the bottom of the tank.

STICKER:

REAR AXLE WHEELS INFLATED PRESSURE (C300H / C300HI / C350H / C350HI x4)

REFERENCE: DESCRIPTION: QUANTITY:

01.12107.01 INDICATIVE STICKER 6,5 BAR / 96 PSI 2

POSITION:

On both sides of the machine, on top of the vertical face, in the upper rear position of each tank, aligned with the bottom of the tank.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (USA Market)

STICKER:

FUEL TYPE INDICATION

REFERENCE: DESCRIPTION: QUANTITY:

43.01356.00 INDICATIVE STICKER 90x45 FUEL 1

POSITION:

On the right tank of the machine, next to the fuel cap, aligned with the vertical outer wall of the tank.

STICKER:

HYDRAULIC OIL TYPE (USA). SUBSTITUTE REF. 43.01352.20

REFERENCE: DESCRIPTION: QUANTITY:

60.01352.01 INDICATIVE STICKER 70x32 HYDRAULIC OIL 1

POSITION:

On the left-hand side tank, below the filler cap, aligned with the inner edge of the tank, and centered with the cap.

STICKER:

ENGINE OIL TYPE. SUBSTITUTE REF. 43.01170.02

REFERENCE: DESCRIPTION: QUANTITY:

43.01170.03 INDICATIVE STICKER 90x45 1

POSITION:

On the inner cab lock, easily legible with the cab raised.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (USA Market)

STICKER:

MACHINE MODEL INDICATION (C300H - C300H x4 )

REFERENCE: DESCRIPTION: QUANTITY:

57.12001.00 INDICATIVE STICKER 68x267 2

POSITION:

On both sides of the machine, at a distance of 0.984 in and a height of 5.906 in from the lower rear corner of each tank, aligned with the bottom of the tank.

STICKER:

MACHINE MODEL INDICATION (C350H - C350H x4 )

REFERENCE: DESCRIPTION: QUANTITY:

57.12002.00 INDICATIVE STICKER 68x267 MODEL C350H / HI 2

POSITION:

On both sides of the machine, at a distance of 1.969 in and a height of 5.906 in from the lower rear corner of each tank, aligned with the bottom of the tank.

STICKER:

CHARACTERISTICS PLATE. SUBSTITUTE 01.00779.26

REFERENCE: DESCRIPTION: QUANTITY:

01.00779.23 PLATE CHARACTERISTICS 100x130 1

POSITION:

Riveted on top of the engine bulkhead, on its rear upper left-hand side (in forward direction of machine), in the holes prepared. Etched according to assembly instruction.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (USA Market)

STICKER:

AUSA ANAGRAM

REFERENCE: DESCRIPTION: QUANTITY:

46.08099.00 AUSA ANAGRAM 1

POSITION:

Embedded in the cab front panel, on its outer side, in the upper left-hand part (in forward direction of machine).

STICKER:

WARNING IN CASE OF OVERTURNING THE MACHINE

REFERENCE: DESCRIPTION: QUANTITY:

12.12010.00 SAFETY STICKER 1

POSITION:

Top left-hand corner of the dashboard, under sticker ref. 02.00774.00 “Do not use” and aligned with this on its left side.

STICKER:

ACOUSTIC OPERATOR PROTECTION

REFERENCE: DESCRIPTION: QUANTITY:

01.00757.00 INDICATIVE STICKER D40 1

POSITION:

Top left-hand corner of the instrument panel, under sticker 02.00774.00 “Do not use”, aligned with this on its right side and centered with sticker ref. 12.12010.00.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (USA Market)

STICKER:

POINT HOISTED MACHINE

REFERENCE: DESCRIPTION: QUANTITY:

09.15720.00 INDICATIVE STICKER 35x35 4

POSITION:

Above each of the four eyebolts at the bottom of the frame for lifting the machine.

STICKER:

MAXIMUM SOUND LEVEL

REFERENCE: DESCRIPTION: QUANTITY:

09.12014.00 STICKER NOISE 104 DB 1

POSITION:

On the inside of the right front wheel arch, aligned with the cab floor.

STICKER:

FullGrip® System

REFERENCE: DESCRIPTION: QUANTITY:

43.00397.00 INDICATIVE STICKER 110x110 2

POSITION:

On both sides of the machine, next to the AUSA sticker (ref. 13.12136.00) and aligned on the right side.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (USA Market)

STICKER:

MAST TILTING FORWARD MARKER (MACHINES WITH SEMI-CLOSED AND FULL CAB)

REFERENCE: DESCRIPTION: QUANTITY:

57.12010.00 INDICATIVE STICKER LOWERING MAST 1

POSITION:

Into the cabin, on the left side of the engine’s cover next to the handle that releases the cabin latch.

STICKER:

NON MOVEMENTS WITH LOAD OFFCENTERED (MASTS OF MORE THAN 3,7M / 12ft 2 in)

REFERENCE: DESCRIPTION: QUANTITY:

43.02187.02 INDICATIVE STICKER 70x210 ENGLISH 1

POSITION:

In the upper part of the dashboard, next to the sticker ref. 02.00777.00 “Do not use” aligned with this on its upper side.

* In heated enclosed cab, position at the bottom left-hand side of the window

0.3937 in away from the edge (bottom left side).

Heated cab

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (USA Market)

STICKER:

AUSA STICKER

REFERENCE: DESCRIPTION: QUANTITY:

13.12136.00 AUSA STICKER 2

POSITION:

On both sides of the mast, above the beam, with its lower side aligned at 4ft 95 in from the ground, above the sticker ref. 45.01352.00 “Dangerous area”, and

0.3937 in away from it.

STICKER:

INDICATION TRANSFER BOX OIL.

REFERENCE: DESCRIPTION: QUANTITY:

43.00396.02 INDICATIVE STICKER 60x95 1

POSITION:

Into the engine compartment on the external face of the joystick control valve support, above “Brake fluid indication” sticker.

STICKER:

NOT USE WITHOUT AUTHORIZATION. SUBSTITUTE REF. 02.00777.00

REFERENCE: DESCRIPTION: QUANTITY:

02.00777.04 INDICATIVE STICKER 50x120 1

POSITION:

On top of the vertical face of the engine cover, easily readable before accessing the forklift, aligned with the cab floor.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (USA Market)

STICKER:

BRAKE FLUID INDICATION

REFERENCE: DESCRIPTION: QUANTITY:

43.70780.01 INDICATIVE STICKER 60x100 BRAKE 1

POSITION:

Into the engine compartment on the external face of the joystick control valve support, below “Transfer box oil” sticker.

STICKER:

HOT PARTS INDICATION

REFERENCE: DESCRIPTION: QUANTITY:

02.00765.00 INDICATIVE STICKER 40x80 ENGLISH 1

POSITION:

Inside the counterweight, near the exhaust manifold, easily readable when trying to work on the engine.

STICKER:

LOAD CHART PLATE

REFERENCE: DESCRIPTION: QUANTITY:

43.01350.28 / 30.12004.00 INDICATIVE PLATE 91x156 LOAD CHARTS 1

08243 MANRESA (ESPAÑA)

43.01350.20

AUSA Center, S.L.U.

D cm.

50 60 70 80 90 100 110120

G kgs

C300H / C300H x4

MOD.

CARGA MAXIMA EN TERRENO HORIZONTAL

CHARGE ADMISSIBLE EN PALIER

PERMISSIBLE LOAD ON LEVEL

MAX. ZULAESSIGE LAST BEI EBENEM BODEN

3,3

3000

2771

2574

2404

2255

2123

2005

1900

POSITION:

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (USA Market)

STICKER:

REFLECTIVE TRIANGLE WITH PLATE. (MACHINE WITH OPEN CAB) (USA)

REFERENCE: DESCRIPTION: QUANTITY:

10.15120.00 INDICATIVE STICKER 350x400 1

POSITION:

Fixed at the bottom edge of the cab rear opening, centered horizontally, aligned with the lower edge of the cab opening.

STICKER:

REFLECTIVE TRIANGLE (MACHINES WITH SEMI-CLOSED AND FULL CAB)) (USA)

REFERENCE: DESCRIPTION: QUANTITY:

10.15122.00 INDICATIVE STICKER 356x356 1

POSITION:

On the cab rear window, centered horizontally on the glass, aligned with the lower edge 0.3937 in away from it.

STICKER:

NOT TO TOUCH INDICATION

REFERENCE: DESCRIPTION: QUANTITY:

02.00766.00 INDICATIVE STICKER 40x80 USA 1

POSITION:

On the top of the radiator fan guard.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Decals / labels / identification plates all markets (USA Market)

STICKER:

PROTECTION STRUCTURE INDICATION

REFERENCE: DESCRIPTION: QUANTITY:

10.01414.01 INDICATIVE STICKER 60x125 USA 1

POSITION:

In the upper left-hand corner of the dashboard, aligned at the left with the adhesive ref. 10.01414.01 “Warning Security”.

STICKER:

CALIFORNIA INDICATION (USA)

REFERENCE: DESCRIPTION: QUANTITY:

43.01171.00 INDICATIVE STICKER 42x77 1

POSITION:

In the upper right-hand corner of the dashboard, aligned at the top with the bend in the dashboard.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Pedals (fig. 1) a- Inching pedal.

When the pedal is depressed the machine stops, allowing the engine to accelerate for faster operation of the mast. When the pedal is slowly released the machine will start to move again.

WARNING

The inching pedal also acts on the parking brake when it is kept fully depressed.

b- Service brake pedal.

Acts on a pump located below the pedal.

c- Accelerator pedal.

Acts on the engine through a cable

 Emergency brake

In the event of emergency use the inching pedal.

 Parking brake (fig. 2)

The parking brake is operated electronically using the switch (d). It is also operated

electronically when the inching pedal is kept fully depressed.

 Joystick (fig. 3)

Forward and backward directional travel control (FNR control)

The direction of travel is changed using the electric switch (e) located on the lower part

of the joystick. In each case the corresponding arrow showing the direction of travel lights up. When the direction arrows are not lit, the direction of travel control is at the stop position (neutral). By pressing the front of the switch the machine travels forwards and by pressing the rear of the switch the machine travels backwards.

Safety: When the parking brake is not on and/or the operator is not sitting in the driver’s

seat, the direction arrows are also switched off and the direction of travel control is disconnected.

 Back-up alarm

It sounds when reverse is selected.

WARNING

If the forklift is equipped with lighting, the back-up alarm is disconnected when the lights are switched on. However, the rear white reversing lights continue to work.

Controls

and instruments

(fig. 2)

(fig. 3)

(fig. 1)

a b c

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Horn (fig. 1, 2) C300H / C300HI / C350H / C350HI

The horn is operated using the button (f) located on the right of the joystick. C300H x4 / C300HI x4 / C350H x4 / C350HI x4

The horn is operated using the button (g) located on the upper right switch of the

instrument panel.

 4x4 connection (FullGrip® System) (fig.3) Connecting the 4x4

The 4x4 connects by pressing yellow switch (i) located underneath the joystick at the

right side.

Disconnecting the 4x4 The 4x4 disconnects just leaving yellow switch (i) on its rest position.

CAUTION

Do not connect the 4x4 traction at high speed

REMARK: Moreover, some models may differ from (fig. 3) and assemble a plastic plug instead of red switch (h).

Controls

and instruments

(fig. 2)(fig. 3) (fig. 1)

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Load handling controls (fig. 1)

The mast and the load are moved by using the joystick.

Raising and lowering the mast.

If the joystick is pulled backwards the mast and the forks lift and if pushed forwards the mast and the forks lower.

Tilting the forks.

If the joystick is pulled to the left, the mast forks tilt backwards (forks lift) and if pushed to the right, they tilt forward (forks lower).

Side-shift (fig. 2).

By holding down button (5) on the joystick and pulling the joystick to the left, the forks

move to the left.

By holding down button (5) and pushing the joystick to the right the forks move to the

right. Always centre the carriage when in transit or when transporting a load.

Additional hydraulic control for attachments () (fig. 3).

By holding down button (6) of the joystick and pulling it to the left (towards the operator),

or pushing it to the right, pressure is supplied to the quick hydraulic

WARNING

The fork positioner allows the operator to set the forks with a variable gap matching different pallet size without removing the forks manually. Be aware this attachment is NOT foreseen for lateral pushing operation (similar to an hydraulic clamp). This type of operation is forbidden, it could be dangerous for the persons and it is considered a misuse, consequently, the manufacturer does not accept any claim for damages caused in this way.

(fig. 3) (fig. 2) (fig. 1)

Controls

and instruments

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Starter switch (fig. 1) See section STARTING THE ENGINE

a- In this position the ignition and the engine are disconnected. b- Ignition on. The engine pre-heating system and the lamp on the control panel are

activated for a few seconds.

c- Starter. Turning the key to position (c) starts the engine. Before re-starting the engine, the key should first be switched to position (a).

 Fuse box (fig. 2)

This is located at the right of the steering column, next to the starter switch.

See the section ELECTRIC CIRCUIT in this Operator’s and Safety Manual to identify

the number and function of each fuse.

Instrument Panel

and controls

(fig. 2) (fig. 1)

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

NOTE

For ease of understanding, the picture shows the panel with the steering wheel removed.

 C300H / C300HI / C350H / C350HI instrument panel: Components and Operation (fig. 1)

1- Multi-function instrument. See the section Multi-function instrument. 2- Light switch. This switch has two positions, the first switches on the low beam

and the second switches on the high beam.

3- Heating switch (). This has two positions to give two fan speeds. 4- Working light switch (). To connect the front lights switch turn on the switch. 5- Parking brake. To activate the forklift parking brake, press the switch. 6- Windscreen wiper switch (). To switch on the windscreen wiper, press the

switch. To activate the windscreen wiper washer pump, press the same switch again.

7- Rotating beacon switch. To switch on, press the button and it will light up. To

switch off, press the button again.

8- Indicators switch (). The turning indicators are switched on by pressing the

switch to the left or to the right.

9- Hazard lights switch (). To switch on, press the button and it will blink. To

switch off, press the button again.

Instrument Panel

and controls

(fig. 1)

1 2

789

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 C300H x4 / C300HI x4 / C350H x4 / C350HI x4 instrument panel (): Components and Operation (fig. 1)

1- Multi-function instrument. See the section Multi-function instrument. 2- Light switch. This switch has two positions, the first switches on the low beam

and the second switches on the high beam.

3- Heating switch (). This has two positions to give two fan speeds. 4- Horn switch. To activate the horn, press the switch. 5- Parking brake. To activate the forklift parking brake, press the switch. 6- Windscreen wiper switch (). To switch on the windscreen wiper, press the

switch. To activate the windscreen wiper washer pump, press the same switch again.

7- Rotating beacon switch. To switch on, press the button and it will light up. To

switch off, press the button again.

8- Indicators switch (). The turning indicators are switched on by pressing the

switch to the left or to the right.

9- Working light switch (). To connect the front lights switch turn on the switch. 10- Hazard lights switch (). To switch on, press the button and it will blink. To

switch off, press the button again.

Instrument Panel

and controls

10 9 8 7 6 5

2 3 4

(fig. 1)

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Multifunction instrument (fig. 1)

A- Hourmeter. This gauge indicates the total running time of the forklift engine to

enable servicing of the engine at proper intervals. (See MAINTENANCE CHART

for servicing frequency).

B- Fuel level. This gauge indicates the diesel fuel level in the tank. C- Fuel reserve indicator lamp. This lights up when the level of fuel in the tank falls

into reserve.

D- Air filter warning lamp. When the air filter of the diesel engine becomes clogged

with dirt, this lamp will light. The air filter should be immediately cleaned or serviced.

E- Engine pre-heat indicator lamp. When this lamp glows it indicates that the

engine pre-heat plugs are in operation and heating the combustion chamber the temperature required to start the engine.

F- Hydraulic oil level warning lamp. This lights up and emits an audible warning

when the hydraulic oil level is at the minimum level. Oil should be added to top up the level to the correct level

G- Engine oil pressure warning lamp. When the ignition is on, this lamp lit and

turns off when the engine is running. If this lamp turns on emits an audible warning while the engine is running, the engine must be stopped immediately to prevent damages. Check the level and add oil if necessary.

H- Battery charge warning lamp. This lamp shows the condition of the battery

and indicates if the battery charge is too low or if the alternator is not charging properly.

Once the engine starts to run, this red lamp turns off If it remains lit, stop the engine and determine the cause.

I- Engine temperature warning lamp. This gauge shows the temperature of

the coolant in the engine cooling system. When this lamp glows emits an audible warning means that the engine is operating at high temperature which could damage the engine. The engine should be stopped immediately to determine the cause of the high temperature. It could be low coolant, debris in the radiator or a thermostat, which does not operate correctly.

J- No application in this model K- High beam indicator lamp (with lighting equipment) (). This lamp is lit

when high beams are selected.

L- Turn signal indicator lamp (with lighting equipment) (). This lamp will

blink indicating turn signals are operating.

(fig. 1)

Instrument Panel

and controls

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Fuel

The current regulations of exhaust emissions, require that, for the whole life of the machine, the level on the different components of these emissions, are under the maximum figures stated on the regulations. As a consequence of that, the maintenance plan of the engine has to be followed up carefully, giving special attention to the quality and pureness of the fuel, the cleanliness of the filters and, in general, to the general maintenance of the fuel circuit.

Handling

- Only use the fuel type authorized by AUSA. Do not use fuel mixed with oil, other fuels or unsuitable additives.

- The correct fuel for the forklift is diesel. For further details regarding fuel type and required specifications see the section FLUIDS AND LUBRICANTS.

- Do not allow the fuel to come into contact with the skin and avoid inhaling the fumes, which are toxic. High concentrations of fuel vapour may cause sickness, loss of consciousness or even loss of life in the event of prolonged exposure. If you experience symptoms such as sickness or loss of consciousness seek medical advice immediately.

- Do not store fuel in closed places. The fuel vapours will alter the atmosphere of the enclosure and may cause a fire or explosion.

- Use suitable impermeable clothing, safety glasses and gloves when handling fuel. When refuelling from a tank, bucket or barrel using a siphon, the following precautions should be taken.

- If refuelling is by gravity, from a raised tank, open the fuel output valve of the tank slowly.

- If the tank or barrel does not have an output valve use a suitable vacuum pump.

WARNING

Never suck the fuel into the pipe by mouth to start the siphoning. Fuel and its vapours are highly toxic.

- In the event of fuel spillage, please inform the supervisor, mark the area suitably and cover the spillage with absorbent material.

- Take suitable measures to avoid risk until the remains of the fuel have been completely removed.

Instrument Panel

and controls

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Refuelling

WARNING

Smoking, naked flames or sparks are not permitted in the refuelling area. Fuel vapours can be explosive.

- Refuel in a well-ventilated area.

- Position the forklift as close as possible to the fuel pump so that the filler hose reaches the opening of the tank comfortably.

- Apply the parking brake, switch off the engine and lights, including the rotating beacon.

NOTE

If the fuel pump is equipped with a vehicle earth connection, connect this to a non-isolated metal component of the forklift.

- Clean the fuel cap and surrounding area with a cloth if they have been dirtied. Do not allow dust, water, or any other substance to enter the tank.

- Open the fuel cap using the key and turning to the left.

- Fill the tank without exceeding the volume specified for the forklift. Take care not to spill fuel outside the tank. If you do, clean immediately and dry the surface well.

- Close the tank using the key and remove it from the cap. Check that the cap is correctly closed.

Instrument Panel

and controls

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

WARNING

Before each period of operation, check the forklift for correct operation of the steering, brakes, hydraulic controls, instruments and safety equipment. Check the neutral position of the FNR switch. A machine that runs correctly is more efficient and can prevent accidents. Make all necessary adjustments or repairs before you operate the machine.

 Entering and leaving the operator cabin (fig. 1)

Don’t hold and pull of the steering wheel to come in/out the forklift, use the handles located on the overhead guard and always place your foot on the rough bands of the step, to prevent any downfall when you come in or come out.

 Standard seat adjustment (fig. 2, 3, 4)

Each day, before operating the dumper, adjust your seat to a position in which you feel comfortable.

Pull the lever (a) to up to unlock the seat. Slide the seat forward or backwards to reach

the desired position. Releasing the leaver the seat locks. The damping of the seat can be adjusted between 50 and 130 Kg, depending upon

the operator’s weight; to do so turn knob (b) clockwise or counter-clockwise in order to

adjust properly the seat damping.

For correct adjustment of the damping, with the operator sitting the needle (c) should

remain within the range of green scale into the gauge.

Using the lever (d) located on the left side of the seat backrest, the backrest inclination

can be changed. Pulling down the lever the backrest unlocks. Adjust the backrest and release the leaver to lock again. Ensure that you fasten your seatbelt.

Operating

the forklift

(fig. 1)

(ﬁ g. 4) (ﬁ g. 3) (ﬁ g. 2)

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Adjusting the seat and the steering wheel (figs. 2, 3, 4, 5)

Before using the forklift adjust the seat and the steering wheel to a comfortable driving position.

On all machines the operator is able to adjust the seat in the fore-aft direction by lifting

knob (a) and sliding seat to the desired position, then releasing the knob to lock the

seat into position.

The seat suspension may be adjusted from 132 to 264 lb. (60 to120 Kg) for driver’s

weight by turning knob (b). Turning clockwise the weight decreases and turning counter-

clockwise it increases. Seats normally leave the factory adjusted for a driver weighting 198 lb. (90 Kg).

It is also possible to adjust the seat backrest angle. The seat backrest tilts forward or

backwards by turning knob (c).

WARNING

Securely fasten the seat belt.

The position of the steering wheel is adjusted by tilting forward/backwards the steering

column. Loose the lever (d) and release the steering column. Adjust it to the most comfortable position. Tight lever (d) to lock it again.

Operating

the forklift

(fig. 2)(fig. 3) (fig. 1)

(fig. 4)

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Starting the engine (fig. 2) Starting engine when the operator is seated:

1. Directional travel control in NEUTRAL position: the park brake switch may be in any position (ON / OFF)

2. Directional travel control in FORWARD / REVERSE: the park brake must be in position ON

Starting engine when the operator is not seated:

The FNR control switch o the parking brake switch can be in any position.

WARNING

For safety reasons, when starting the engine the driver should be seated, directional control switch in neutral, seatbelt fastened and the parking brake applied.

Then proceed as follows:

- Place the key in the ignition switch and turn to position (b) ignition. Wait a few

moments until the engine preheating light goes out.

- Press the accelerator pedal 1/4 of the way and turn the key to position (c) to start

the engine. Do not hold the key in this position for more than 15 seconds.

- If the engine does not start, repeat the above steps and wait 30 seconds between each attempt. Before re starting the engine, the key should first be switched to

position (a).

CAUTION

With ambient temperatures lower than 0ºC (32ºF), AUSA recommends to run the engine at idle speed for 3 minutes before starting to work with the forklift in order to reach the appropriate fluency on the engine and hydraulic oil

 Checks

With the engine running at idle and the forklift is warming-up, carry out the following tests:

- Check the instrument panel controls.

- Check the steering by turning it gently to the left and right.

- Lift the forks off the ground 6 in (15 cm).

- Check the parking brake.

- Check that the brake pedal action is firm.

Operating

the forklift

(fig. 1)

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Forklift nominal load (fig. 1)

The Rated Capacity of this forklift is the weight the machine is capable of lifting under safe operating conditions. The lifting capacity of a forklift is determined by the height and weight limits of the load. Poor ground conditions as well as shape of the load may reduce the weight that can be safely lifted. Overloading the forks can make the forklift unstable, hard to handle, and may be in danger of tipping over. Inspect the load you intend to lift and make certain it is within the limits of the Load Capacity Chart located on the left hand side mudguard.

 Load Center (fig. 1, 2)

To rate the lifting capacity of forklifts manufacturers have standardized on a certain size of load. The rated capacity of this forklift is based on a cube measuring 39in (1 m.), in all three dimensions with the center of gravity in the center of this cube. This is known as 24in (600 mm) or 20in (500 mm) load center from both the vertical face of the mast and from the lifting surface of the forks. lt is important to keep load center in mind for as the load center increases the lifting capacity of the forklift decreases.

 Load Capacity Rough terrain use:

- With load center at 20in (500 mm) from vertical face of the forks, the C300H / C300H x4 has a rated capacity of 6614lbs (3000 kg)

- With load center at 24in (600 mm) from vertical face of the forks, the C300H / C300H x4 has a rated capacity of 6172lbs (2800 kg)

- With load center at 20in (500 mm) from vertical face of the forks, the C350H / C350H x4 has a rated capacity of 7716lbs (3500 kg)

- With load center at 24in (600 mm) from vertical face of the forks, the C350H / C350H x4 has a rated capacity of 7165lbs (3250 kg)

Industrial use:

- With load center at 20in (500 mm) from vertical face of the forks, the C300HI / C300HI x4 has a rated capacity of 6614lbs (3000 kg)

- With load center at 24in (600 mm) from vertical face of the forks, the C300HI / C300HI x4 has a rated capacity of 6172lbs (2800 kg)

- With load center at 20in (500 mm) from vertical face of the forks, the C350HI / C350HI x4 has a rated capacity of 7716lbs (3500 kg)

- With load center at 24in (600 mm) from vertical face of the forks, the C350HI / C350HI x4 has a rated capacity of 7165lbs (3250 kg)

If the load is too heavy split it and re-stack it. Use of attachments other than the pallet forks that came with this machine may reduce lifting capacity and affect other machine handling characteristics.

Reproduced copies of the Load Charts are included in the section TECNICAL SPECIFICATIONS on this Operator’s and Safety Manual. Study the Load Capacity

Chart of your machine carefully and make certain you understand it before lifting loads on the forks

(fig. 2)

1- Fork Face 2- Load Center

(fig. 1) 24in

39 in.

24 in. load center

(fig. 1) 600mm

1 m

load center

600 mm

(fig. 1) 500mm

1 m

load center

500 mm

Operating

the forklift

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Alteration to the forklift / load relation

The relationship between the forklift and the load is altered by changes in:

- Removable attachments (see LOAD CHARTS in this manual).

- Height of the forks.

- Changes in the motion of the machine and the grade of the ground on which it is moving.

- Smoothness and stability of the ground.

- Machine stability must be maintained while these factors change constantly during forklift operation.

This requires careful judgement on the part of the operator.

 Lifting Capacity

Machine stability is maintained only when the forklift handles loads within its rated

lifting capacity. The Load Capacity Charts are included in the section TECHNICAL SPECIFICATIONS on this Operator’s and Safety Manual. The lifting capacity of the

machine is determined by the safe height and weight limits of the load. An overload on the forks makes the forklift unstable, hard to handle, and will present the danger of tipping over.

 Load charts (fig. 1, 2)

The charts you can see in the section TECHNICAL SPECIFICATIONS on this

Operator’s and Safety Manual shows how much your forklift can lift as the load centre increases out to 4in (100 mm) load center from the 20in (500 mm) or 24 in (600 mm) (depending on models and market). Note how the lift capacity decreases as the load centre increases. This chart is reproduced as a machine decal and is located on both the right and the left side of the mast and at the driver seat for ease of reference during machine operation.

The charts you can see in the section TECHNICAL SPECIFICATIONS on this

Operator’s and Safety Manual represents the load that can be lifted on a level surface, with the load evenly displaced (like a square box with the weight centred), at certain lift height (depending on the mast height and use) .

The horizontal axis “D” (often referred to as the “X” axis), represents the distance in

inches that the load centre is moved forward from the face of the forks.

The vertical axis “G” (often referred to as the “Y” axis), shows the load weight in pounds

o kilos.

Operating

the forklift

(fig. 1)

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Engine overheating

If the engine overheats and the engine temperature warning light on the control panel lights up, try the following:

- Check and clean the radiator coolant blades. See the section PERIODIC MAINTENANCE OPERATIONS in this Operator’s and Safety Manual.

- Slow down the speed but keep the forklift moving in order to allow air to circulate around the radiator.

- If the engine is still overheating after approximately one minute, stop driving the forklift, set the forward / backwards directional travel control switch to neutral, apply the parking brake and stop the engine.

WARNING

The radiator may be extremely hot. Use gloves before touching the radiator.

- Allow the engine to cool down. Check the coolant level and refill if necessary.

- If the engine continues to overheated, pls. contact to an authorized AUSA dealer as soon as possible.

 After-use care

When the forklift is used in salt water areas (beach areas, etc.), rinse the machine with fresh water to protect the forklift and its components from rust. We recommend lubricating the metal components. This should be carried out at the end of every day after using the forklift. When the forklift has been working in muddy areas, it should be washed with fresh water to protect the forklift and keep the lights clean.

Note: Never use high-pressure water to clean the forklift. ONLY USE LOW-PRESSURE

WATER. High-pressure water may cause electrical and mechanical damage.

 Rolling over (fig. 1)

In the event of the machine rolling over it is important that the driver avoids being caught between the machine and the ground. To prevent this we recommend:

1. Try to remain within the seated operator area / cabin.

2. Grasp the steering wheel firmly.

3. Push feet, firmly, against the ground floor of the cabin.

4. Try to keep as far away from the point of impact as possible.

(fig. 1)

Special procedures

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

When the forklift overturns or is knocked onto one side, restore it to normal operating position (on all four wheels).

WARNING

DO NOT TRY TO START THE FORKLIFT without first checking with an authorized AUSA dealer.

- Remove the four glow plugs.

- Turn the key in the ignition to position (c). Hold the key in position until the oil has

come out of the combustion chamber.

WARNING

The oil will come out of the combustion chambers at high pressure and may cause injury.

- Re-assemble the four glow plugs.

- Check the engine oil level and refill if necessary.

- If the engine oil pressure warning light remains lit after starting the engine, stop immediately to prevent internal damages and refer contact to an authorized AUSA dealer as soon as possible.

 Immersion of the forklift

If the forklift becomes submerged under water, it will be necessary to take it to an authorized AUSA dealer as soon as possible.

CAUTION

DO NOT START THE ENGINE. Immersion of the forklift may cause serious damage to the engine if the start-up procedures are not followed correctly.

- Arrange for an authorized AUSA dealer to carefully inspect the supply system as

shown in the MAINTENANCE CHART.

 Storage and pre-parking preparation.

When the forklift is not to be used for more than a month it should be stored correctly. When the forklift is brought out for use again after a period of storage, special preparation is required. Ask an authorized AUSA dealer about the appropriate procedures.

Special procedures

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Tilting the mast while the engine is stopped (emergency movement)

It is possible to tilt the mast of the forklift (emergency movement) forwards with the ignition off. To do so, proceed as follows:

- Locate the emergency movement connector under the dash panel, next to the steering column (fig. 1)

- Remove the protective cover from the connector by lifting the locking tab and moving it forwards.

- With the help of an external battery supply the connector with + 12V DC and earth (-) as follows:

Connector, contact 1: + 12V DC Connector, contact 2: earth (-)

- Push the joystick to the right in order to tilt the mast.

NOTE

To help this movement, we recommend applying a small load on the end of the forks.

(fig. 1)

Special procedures

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

WARNING

Do not operate this machine unless you have read and understand the safety and operational instructions contained in this Operator’s and Safety Manual and have been instructed and trained in the safe operation of this Forklift. REMEMBER THAT “YOU” ARE THE KEY TO SAFETY.

 General comments Operator responsibilities

Before using the forklift that is initially unfamiliar, you should read the Operator’s

and Safety Manual carefully and resolve any doubts with a supervisor (fig. 1). It is

your responsibility to read and understand this Operator’s and Safety Manual before operating any rough terrain forklift. This Operator’s and Safety Manual takes you step by step through your working day. In order to help you better understand the text, graphics have been provided in this Operator’s and Safety Manual. It’s important that you know and apply all applicable laws and rules including OSHA requirements for operator training and certification. The forklift must only be used by authorized and correctly trained personnel AUSA manufactures its forklifts in accordance with ASME B56.6 and the corresponding International Standards. The Occupational Safety and Health Administration (OSHA) enforces federal laws that apply to safety of operation, application and maintenance of equipment on a worksite. Because it is an employer’s responsibility to apply these laws, an OSHA representative may periodically inspect a worksite to see that these laws are being followed. There may also be local or state/provincial laws that apply to this equipment and its use along with specific worksite or employer rules. It is important that you know and apply all applicable laws and rules. Any danger resulting from improper use, not complying with these provisions or others which are specifically provided with the machinery, shall be the responsibility of the user and not of AUSA. This section provides instructions on the use of the forklift, in accordance with that established by ASME B56.6, 2006/42/EC standard and OSHA documents.

Description of a forklift truck

A forklift truck is a powered vehicle used for transporting or handling loads with the aid of tools specific to the task to be carried out. The forklift is able to lift loads. It consists of a resistant chassis resting upon two axles. The front axle is the drive axle and the rear axle the steering axle, although versions exist in which both axles are driving axles. At the front of the forklift there is a mast, along it moves the front carriage. The unit formed by both is designed to lift and tilt the load forwards and backwards, making handling easier

(fig. 1)

Special

Safety Messages

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 General recommendations for driving a forklift truck

Basic information for starting up a forklift truck Entering and leaving the operator cabin, do not hold or pull the steering wheel to enter the driver cabin, use the handles provided on the front structure of the overhead guard. Always place one foot on the tread of the sill to prevent slipping when climbing in or out

(fig. 1).

Never start or operate any of the controls unless seated on the driver’s seat. Keep the driver’s cab free of objects and tools. These may move around, block a control or a pedal, and prevent a manoeuvre or stop the forklift. Before starting to work with the forklift, clean any oil or fuel spills, clean and remove

grease from hands and the soles of shoes (fig. 2). Do not forget to carry out the operations and daily checks listed in the MAINTENANCE CHART on this Operator’s

and Safety Manual. Check the correct position and fastening of all the guards, caps and safety stops. Check that all the controls are operating correctly. Check that informative and safety plates on the forklift are clean and in good condition. If they are not in good condition, replace them. Wear suitable protective that will protect you in the working environment. This may

include a helmet, ear plugs, protective goggles or reflective clothing (fig. 3). Do not

wear loose clothing or jewellery or long hair as these could become entangled in the controls, in moving parts or edges of the machine and prove dangerous. If working in an enclosed area make certain there is sufficient ventilation to prevent excessive build-up of exhaust fumes. Under this conditions always stop this engine when not in use. Before starting the forklift be certain to check or test the following items:

- Check for any leaks in the fuel, hydraulic or cooling system.

- Clean any oil or fuel leaks that may exist on the forklift controls or operating area.

- Check tire conditions and pressures.

- Re-tight wheel nuts if necessary.

- Check that all controls are working correctly.

- Check the operator seat belt and its attachments.

Ensure seat belt is properly latched. Inspect carefully the condition of this security system with special attention to:

- cuts or damages in the belt.

- wear or damages in the metallic parts including the anchorage elements.

- badly functioning of the buckle.

- seams or free points of sewing.

Check brake pedal travel and effectiveness. Check the following fluid levels:

- Fuel

- Braking fluid

- Hydraulic fluid

- Cooling system fluid

- Engine oil

Check the horn. Check that lighting and signalling systems are clean and work correctly. If they do

not work check the corresponding fuses and bulbs as shown in MAINTENANCE OPERATIONS on this Operator’s and Safety Manual.

Jumping on or off the forklift can cause serious injury. Always face the machine and use rails and steps to slowly get on and slowly get off the forklift. Adjust seat position so you are comfortable and can easily reach all the controls. Now fasten your seat belt.

Always stop the engine and do not smoke when fuelling the machine. (fig. 4) Follow the

instructions given in the section “Fuel” on this Operator’s and Safety Manual.

Special

Safety Messages

(fig. 4) (fig. 3) (fig. 2) (fig. 1)

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Before starting and operating the forklift

- Stay alert. Concentrate fully on your work. Your safety and that of others depends on the care you take when operating this forklift.

- Remember that you are the key to safety. Good safety practices not only protect you but also the people around you.

The surrounding area

Be careful around any pedestrians in the surrounding area This forklift was designed to lift loads not people. Never transport people on any part of

the forklift. Do not let people ride on the forks (fig. 1). Do not let people stand or walk under raised forks, loaded or unloaded (fig. 2).

Give way to the right to pedestrians found in your path. Do not drive rapidly. Driving too fast is dangerous to the driver and to the load. The speed at which the forklift is operated should always be suited to the working conditions and to the space available for manoeuvring. Always drive smoothly and not in a jerky fashion.

Never put any part of your body between the fork mast and the forklift body. (fig. 3).

Be careful around any load edges, pressure zones or revolving movements and extensions. Be certain you have good visibility at all times. It is important that you can see clearly both forward and backward when operating the forklift. If the load does not allow clear

forward visibility, then drive with caution in reverse. (fig. 4).

This forklift is not designed to be used as a tow truck or tow vehicle. However if the forklift

is to be towed to or from work location, see the section TOWING THE FORKLIFT on

this Operator’s and Safety Manual.

Work circuit

The movement of loads within an installation or enclosure must be carried out following certain instructions concerning the circulation of forklifts and pedestrians. If you are not aware of these regulations, please check with your supervisor. Study the movements of the forklift to avoid making manoeuvres which are unnecessary, or involve risk to the surrounding areas. Find out which paths are suited to the type of vehicle you are driving and the load carried. If it is necessary to drive along public highways, first check that the forklift complies with current regulations of the country. Highway use of this off-road equipment may be restricted or prohibited by the laws of a State or Province.

Work cycle

If it is necessary to move loads continuously and repeatedly, try to do so with the minimum number of movements necessary, where possible. Reducing the number of movements saves fuel and reduces the emission of exhaust fumes. If the work is very intense, remember to check the instrument panel from time to time, especially in extreme climates, as the engine will be working in particularly hard conditions.

Forklift truck circulation

When approaching a junction with poor visibility, reduce speed, emit acoustic warnings and proceed slowly according to the available visibility. The speed of the forklift should at all times be adapted to the working conditions and the surrounding area. Systematically driving at the maximum speed permitted by the machine may put the operator and the surrounding area at risk.

(fig. 4)

(fig. 3)

(fig. 2)

(fig. 1)

Special

Safety Messages

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Driving in reverse

Ensure good visibility of the path to be taken. If the load being carried obstructs visibility, drive in reverse with the utmost of caution. Before reversing, the operator should ensure that this does not involve risks for the

forklift, people or objects in the surrounding area (fig. 1).

Driving on gradients

Special care should be taken when driving on gradients: move slowly, avoid placing the machine across the gradient and do not work on higher gradients than those recommended. The maximum permitted gradient does not imply that it is possible to manoeuvre here in absolute safety under full load, ground and operating conditions. Gradients should be descended in reverse, with the load facing the direction of greatest

stability (fig. 2).

Rudiments of static equilibrium

In order that the forklift is able to handle loads in a stable and safe manner, certain equilibrium conditions must exist and be maintained between the load and the machinery. Therefore, the forklift is fitted with counterweights at the rear. These are designed to compensate for the weight of the load being carried, as long as the centre of gravity of the load and the forklift are within certain established limits. In order to calculate the values of the transportable weight and the position of the centre of gravity permitted for

the forklift see the Load Charts in the section OPERATING THE MACHINE on this

Operator’s and Safety Manual .

Rudiments of dynamic equilibrium

While the forklift is moving, and as it gains speed, the equilibrium conditions of the load-forklift unit are modified as the centre of gravity shifts. This is accentuated on lifting loads, turning, braking, etc. In these conditions it is necessary to take the utmost care to ensure that the centre of gravity of the load is maintained within the specifications showed on the load chart plate.

Static equilibrium of a conventional forklift

The forklift counterweight produces a situation of imbalance when the forklift is unloaded. The centre of gravity is maintained low and close to the rear of the forklift. When the load is collected, the imbalance is corrected and the centre of gravity shifts forward. If the load is within the margins given on the load chart, equilibrium is maintained. As the load is lifted, the centre of gravity also rises, shifting upwards. At the moment that the centre of gravity shifts beyond the forklift, the equilibrium is lost and the forklift becomes unstable. Therefore, the forklift should not move while the load is raised.

Stability

Do not carry unstable or loose loads, or loads which are oversized with respect to the forklift. If very large or wide loads must be carried, every precaution must be taken to prevent bumps or other possible accidents. When carrying out lifting manoeuvres, particularly at height, ensure that the forklift is on stable ground as levelled as possible. Do not drive over objects which may endanger the stability of the machine.

(fig. 2)

(fig. 1)

Special

Safety Messages

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

The triangle of horizontal stability

To prevent the loads which are being transported from falling, it is necessary to consider

the triangle of horizontal stability (fig. 1). This is an imaginary inverted triangle, with the

lower end located on the centre of the rear axle and the two upper vertices on each of the front wheels. Stability is guaranteed when the centre of gravity of the combination load

(c)+ machine (m) remains within the limits of this imaginary triangle. Longitudinal stabilization

The risk of longitudinal overturning increases if the forklift is driven while the load is raised. Sharp braking and accelerating or rapid tilting movements decrease stability.

Transversal stability

The risk of overturning sideways increases on turning at incorrect speeds, while the forklift is unloaded or when the load is raised. Rough ground, sharp braking or accelerating or shifts in the load make these conditions worse.

Centre of gravity and the capacity of the forklift truck

Do not overload the forklift or handle loads which shift the centre of gravity beyond that for which it is designed. Manoeuvre slowly, especially when changing direction on slippery ground . Do not handle loads that are unstable, loose or disproportionate to the size of the forks and the forklift machine itself. Make certain that long or wide loads are fastened together so as to be stable and secure.

The load and counterweight

The load should be lifted and lowered with the mast in vertical position or slightly tilted backwards. The raised load should only be tilted forwards when it is about to be unloaded. Tilting the load forwards or backwards (swinging) is very useful for collecting or positioning the load, but affects the longitudinal and lateral stability. Therefore, when handling raised loads, do not swing the mast more than is absolutely essential. The forklift may tip forwards when carrying a raised load with the mast tilted forwards, or in the event of sudden braking or accelerating while the load is raised. If using an accessory, attachment or tool, first check the permitted load. The combination of the weight of the forklift plus the weight of the accessory or attachment reduces the nominal load.

WARNING

This forklift is not designed to travel with elevated load or with the mast tilted forward. Do not tilt forward the mast with the forks elevated except to pick up or deposit the load. The fully forward tilting mast angle is only intended to transport the forklift on a truck bed, always without load. For operating with load do not exceed 10º for the forward tilting mast angle.

(fig. 1)

Special

Safety Messages

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Load handling

• Know the lifting capacity of your forklift and operate within those limits.

See the Load Limit Charts shown in the section TECHNICAL SPECIFICATIONS

on this Operator’s Safety Manual and shown in a plate on the left mudguard.

• Never transport loads with the forks raised -keep them as low as possible to attain maximum stability-. The risk of overturning increases when the forklift is driven with

the load raised. Keep it low when in transit. (fig. 1, 2)

• Do not drive on surfaces that could affect the stability of the machine.

• Only raise the forks when the machine is on a level, flat surface.

• If necessary to temporarily operate the forklift in rough, unimproved areas, be very careful when operating near an open trench, a high bank or an overhang that can fall and cause a roll over with the potential of serious injury or death. You must make a careful judgement whether you and your forklift can be safely operated near any of these areas.

• Stay off steep inclines and slopes. Hillside operation can be very dangerous due to the constant potential of rollovers.

• When operating on modest inclines or slopes:

- Move very carefully and slowly.

- Keep the forks and load low.

- Keep the forks facing uphill at all times. This means driving in backwards down a

slope to maintain maximum load stability.

- Always travels directly up or down the slope.

- Do not travel across an incline.

- Never position the forklift sideways on a slope.

• Forks should only be raised on level stable ground. You must be the judge whether ground conditions will permit the safe operation of the forklift. Operation on an incline can be very dangerous. Rain, snow, loose gravel or soft ground can be factors which may prevent the use of the forklift.

• Keep the forks and the loads away from overhead obstructions.

• Never operate the forklift near or close to overhead power lines.

• If the forklift is operated in an enclosed area, use ventilation systems to replace the exhaust fumes with fresh air.

• Use ventilation systems to remove any flammable dust or steam in the working area.

• Do not overload the forklift and do not allow the load centre to move. Always manoeuvre slowly and smoothly especially when changing direction.

• Keep the forks facing uphill at all times. This means reversing backwards down a slope to maintain maximum load stability.

• When depositing a load to a height, tilt the mast forward just enough to leave the load on a shelf or pile. When taking a load from a shelf, tilt the mast back just enough to stabilise the load on the forks.

• Always operate the fork tilt lever slowly and smoothly. (fig. 2).

• Always drive with the forks in the low position and with the mast tilted slightly back.

• Make certain that long or wide loads are fastened together so as to be stable and secure.

(fig. 1)

(fig. 2)

Special

Safety Messages

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Critical speed

The speed at which the forklift moves affects its stability. When turning, braking, or accelerating, the centre of gravity shifts within the triangle of stability. Sharp turns, sudden braking or accelerating cause the centre of gravity to shift sharply and it may fall outside the triangle. This is the moment when the stability of the forklift and the load are not guaranteed and there is a risk of accident. When manoeuvring reduce the speed of the forklift and avoid turning the steering wheel sharply. Do not drive the forklift at a fast speed and then attempt a turn as the forklift may tip over.

Always drive slowly when making a turn and keep the forks low when turning (fig. 1).

 Accesses and doors

Make sure that the passages and doors along the route are sufficiently high to allow all the forklift to pass. When carrying out lifting manoeuvres, pay special attention to the height of the roof, lighting and other overhead installations.

 Ground surface

Check that the ground is strong enough to bear the forklift when loaded, especially when

approaching bridges, the edges of embankments, concrete floors elevators, etc. (fig. 2).

 Lighting

The forklift working area should be adequately lit to prevent the risk of accident, running over persons or colliding with obstacles. As soon as the daylight fades, the forklift lighting system should be switched on. If the forklift is not equipped with lighting, make sure that the working area is adequately lit. If this is not possible, do not continue working with the forklift, this may result in an accident.

 Loading bay. Communication. Shelving and installations. The load

The loading bay or area where the loads are handled should be correctly equipped and signposted. The operating area of the forklift should be free of obstacles and pedestrians, however if their presence is necessary, the pedestrians should move in areas which have been duly marked as such and they should be easily distinguished, for example, by wearing reflective jackets. If the area is closed it should be well-ventilated and the forklift must be equipped with lighting and exhaust gas purifier systems. The forklift operator should be able to communicate normally with pedestrians. If the surrounding area is excessively noisy, pedestrians should refrain from walking in the immediate vicinity. If this is unavoidable, the utmost care should be taken. Radio communication equipment should not be handled while driving the forklift. If it is necessary to use the radio, pull over to one side and signal the position of the forklift, using the lights or hazard warning lights. Shelving for the loads have a series of marked passageways. The width of these should be at least the width of the forklift plus 40 in (1 m). If the passageway is two-way, the width must be sufficient to allow two forklifts to pass plus an additional 55 in (1,5 m). Before using the forklift to handle loads check the load and ensure that the weight does not exceed the forklift capacity. At the same time, check that the load is stabilized and correctly secured, to ensure that no part of the load falls off during transportation.

(fig. 2)

(fig. 1)

Special

Safety Messages

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Order and cleanliness

Carrying out a series of checks before starting the forklift and keeping the operator cab clean help to make the work safer.

To do so, follow the MAINTENANCE CHART given in this Operator’s and Safety

Manual strictly, and keep the operator cab clean and free of earth, gravel, mud, oil or other objects which may cause falls. Do not carry objects in the operator cab. These may injure the operator or accidentally activate the forklift controls.

 Overhead Guard

WARNING

You are protected by an overhead guard which complies with the provisions of ISO 3449 and ISO 3471 / ASME B56.6. It protects the operator against falling objects and, together with the mast, gives protection to the operator in the event of an accidental tip over. The seat belt is an important part of this safety system and must always be fastened before operating the forklift. Failure to wear the seat belt in the event of an accidental tip over could result serious injury or death as you could be crushed by the machine or by the overhead guard.

The above decal is located on the side of the machine. Overhead Guard must be weekly inspected for excessive damage cracks permanent deformation or signs of potential cracks. If these incidents appear, structure must not be repaired but replaced for a new one.

 When leaving / parking the forklift (fig. 1, 2, 3)

A poorly parked forklift truck is a risk. Park the forklift in the areas provided for this purpose, without obstructing the passage of others, exits or entrances to stairs and emergency equipment.

• Place the forks or attachment in the fully lowered position.

• Set all the controls in the “0” neutral position.

• Apply the parking brake.

• Do not park the forklift on a slope. If it is necessary to park the forklift on a gradient, in addition to using the parking brake, place chocks against the wheels.

• Stop the engine and cut the ignition circuit. Remove the ignition key.

• Lock all mechanisms to prevent any unauthorised person from using the machine.

• Remember that you are the key to safety. Good safety practices not only protect you but also the people around you.

(fig. 3)

(fig. 2)

(fig. 1)

Special

Safety Messages

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Parking the machine and stopping the engine

Make certain that the forklift is parked on level ground when leaving it overnight. Also park it on level ground before any scheduled maintenance is attempted.

- Lower the forks to the ground, lock the park brake and push directional switch to NEUTRAL.

- Apply the parking brake

- If it is necessary to park the forklift on a gradient, in addition to using the park brake, place chocks against the wheels.

- If the engine has been working at full load, run the engine at idle for 1 minute - as this procedure will cool the engine components evenly.

- To stop the engine, turn the ignition switch key in a counter-clockwise motion.

- Remove the key from the ignition switch and take it with you. Never leave the key in a parked machine.

- Lock all mechanisms to prevent any unauthorised person from using the forklift

- Remember that you are the key to safety. Good safety practices not only protect you but also the people around you.

 Be careful with the environment

At the end of the operating life of the machine, bring it to a recycling center or an scrapdealer. It is absolutely forbidden to leave the materials in public places.

When changing the engine oil or other fluids, use a big collecting trough. Make sure not to pollute the environment with emerging oil and other waste products (coolant, batteries, etc.) bring them to the corresponding recycling centre. In case that substances escape from the machine that are harmful to the environment and/or to the people, take remedial measures inmediately, (eg.: if hydraulic oil emerges; apply oil bonding agent, put a collecting vessel underneath, tighten leakage, remove and dispose of contaminated earth, if required). At the end of the life cycle of the machine, bring it to the specialised and recognised recycling centres.

Parking the machine

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Fastening the forklift to a lorry or trailer bed. (fig. 1, 2)

When transporting the forklift on a trailer or truck bed, carefully follow the instructions in the Caution Decal. Move slowly and carefully up (or down) the loading ramps. Once on the trailer make certain the forks are lowered, handbrake applied and the forks and tires are blocked. Lastly make certain the forklift is securely tied down. After the machine has been positioned on the Lorry/Trailer bed, put chocks at the front and rear of the forklift tires. Firmly fast the forklift to the trailer or truck bed with chains, cable or tie-down straps to prevent any movement in the position shown in the picture 1.

Use the four eyes welded on to the chassis of the forklift purpose (fig. 2)

WARNING

Before you put the forklift on a trailer or truck bed, make certain that the ramp is strong enough to support the load and that the parking surface is fee of debris, oil, grease or ice.

• Do not transport the forklift with a full diesel fuel tank.

• Make certain your seat belt is properly fastened.

• Move the forklift slowly and carefully up the ramp onto the trailer.

• Shift the directional control lever to neutral.

• Apply the parking brake.

• In transit position lower the forks to their lowest level.

• Stop the engine and remove the key.

• Put blocks under the tips of each fork and tilt the mast slightly forward.

• Choks must be placed on all four wheels.

• Fast the forklift to the lorry chassis using chains, straps or sling cables of sufficiente strengh.

 Loading onto a trailer by crane (fig. 3)

lf a sling and crane are used to load the forklift onto a trailer or truck, attach the sling as shown in the next figure. Before lifting check that the sling cable is firmly attached. While lifting the forklift do not permit riders on the forklift or by standers within 15ft (5m).

To lift the machine with a crane, bear in mind the following advice:

- Front slings must not be shorter than 8ft (2,5 meters).

- Always raise the machine in a balanced position.

- Keep the angle of inclination of the front sling approximately the same as the angle of inclination of the mast.

(fig. 3) (fig. 1)(fig. 2)

Transporting

the machine

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Towing the machine

If the machine must be towed for short distances, only do so with a solid tow-bar to prevent any lateral sway. Attach the tow bar to the bolt at the rear of the counter weight

(fig. 1). Drive slowly and carefully at a speed not exceeding 6 mph (10 Km/h) and of

maximum for a duration not exceeding 3 minutes.. Comply with all state laws governing the operation / towing of an off-highway machine on public roads and highways.

 Before towing the machine: Release the parking brake (fig. 2, 3, 4, 5)

In the event that the parking brake is blocked, due, for example, to a loss of brake fluid, or because the engine does not start, proceed as follows to release it.

- Remove the bleeder (a) from the brake.

- Screw on the nipple (b)supplied in the forklift tool box.

- Remove handbrake release pressure hose and plug in the fitting with a M12 x 1,5

mm. thread plug (c).

- Using a hand pump lubricator (d) insert grease until the internal pressure

manages to release the parking brake.

- To finally release the parking brake, unscrew the nipple (b). The grease will come

out of the brake thanks to the operation of the internal springs.

- Re-assemble the bleeder (a).

- Disassemble plug (c) and connect handbrake hose again.

WARNING

Any repair to the brake system should be carried out by an authorized AUSA dealer.

CAUTION

Not plugging in handbrake hose fitting before inserting grease into the brake unit can lead to a hydrostatic pump damage. Contact your nearest AUSA dealer if you have any doubt.

(fig. 3) (fig. 2)(fig. 4)

(fig. 5)

(fig. 1)

Transporting

the machine

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 By-passing the hydrostatic pump (fig. 1)

The forklift towing is only recommended when there is no other option during a breakdown so the hydrostatic transmission can be seriously damaged. Whenever is possible it is recommended fixing in the place where is stopped. Otherwise, towing should only occur over short distances and at low speed. Comply with all state laws governing the operation / towing of an off-highway machine on public roads and highways.

CAUTION

It is possible to damage the drive motor by operating in bypass mode without charge pressure. Move the forklift at a speed not more than 20% of maximum for a duration not exceeding 3 minutes.

Use this procedure to bypass the pump to allow moving the forklift short distances when you cannot start the engine.

To open the by-pass valves, screw-in (but not over-tight them) the centre screws of he hydrostatic pump safety relief valves. To do so, loose the counter-nuts.

Once the machine is fixed, screw-out again the hydrostatic pump safety relief valves tight the counter-nuts again.

(fig. 1)

Transporting

the machine

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

This section specifies the recommended liquid and lubricants. See the

MAINTENANCE CHART on this Manual for the recommended change / service

intervals.

FLUID OR

LUBRICANT

SPECIFICATION REMARKS AUSA P/N

CAPACITY

(Litres)

CAPACITY

(US Gal.)

FUEL

Usar gasoil limpio tipo automoción (clase A),

preferentemente conforme

a la Directiva 98/70/CEE

modificada por la directiva 2003/17 o a la Norma EN 590 equivalente a las mismas. En

España corresponde al RD

1728/1999. Para el mercado

USA, debe ser conforme

80 21.1

KUBOTA V2403-M

ENGINE OIL

Engine oil in accordance with

MIL- 2104C / API CD or higher

See section

ENGINE OIL

in this section

461.00099.01 8.4 2.2

KUBOTA V3600T

ENGINE OIL

Engine oil in accordance with

MIL- 2104C / API CD or higher

See section

ENGINE OIL in this section

461.00099.01 13.2 3.5

KUBOTA V2403-M

ENGINE

COOLANT

Ethylene glycol antifreeze

with corrosion inhibitors for

aluminum engines with internal combustion. 40% glycol / 60%

distilled water in Standard

machine.

See section

ENGINE

COOLANT

in this section

45.00075.01 10 2.6

KUBOTA V3600T

ENGINE

COOLANT

Ethylene glycol antifreeze

with corrosion inhibitors for

aluminum engines with internal combustion. 40% glycol / 60%

distilled water in Standard

machine.

See section

ENGINE

COOLANT

in this section

45.00075.01 13 3.4

HYDRAULIC

CIRCUIT

Hydraulic oil ISO Grade VG-46 in accordance with ISO 6743/4

HV DIN 51524 Part 3 - class

HVLP

See section

HYDRAULIC

CIRCUIT OIL

in this section

461.00099.06 85 22.4

C300H

FRONT AXLE

DIFFERENTIAL

Transmission oil SAE 90 in

accordance with API GL5 / MIL

L-2105D with additive, LIMITED

SLIP

See section

OIL FOR FullGrip

AND FRONT AXLE

in this section

461.00099.09 4 1.8

C300H

FINAL DRIVE

ON THE FRONT

AXLE

Transmission oil SAE 90 in

accordance with API GL5 / MIL L-2105D with additive, LIMITED

SLIP

See section

OIL FOR FullGrip

AND FRONT AXLE

in this section

461.00099.09 0.4 0.1

C350H

FRONT AXLE

DIFFERENTIAL

Transmission oil SAE 90 in

accordance with API GL5 / MIL L-2105D with additive, LIMITED

SLIP

See section

OIL FOR FullGrip

AND FRONT AXLE

in this section

461.00016.00 6 1.5

C350H

FINAL DRIVE

ON THE FRONT

AXLE

Transmission oil SAE 90 in

accordance with API GL5 / MIL L-2105D with additive, LIMITED

SLIP

See section

OIL FOR FullGrip

AND FRONT AXLE

in this section

461.00004.01 0.7 0.18

REAR AXLE

DIFFERENTIAL

Aceite para transmisiones SAE

90 según API GL5 / MIL-L-

2105B

461.00004.01 3.3 0.8

FINAL DRIVE

ON THE REAR

AXLE x4

Aceite para transmisiones SAE

90 según API GL5 / MIL-L-

2105B

461.00004.01 0.3 0.08

TRANSFER BOX

Transmission oil SAE 90 in

accordance with API GL5 / MIL

L- 2105B

461.00004.01 3.25 0.9

TRANSFER BOX

(FullGrip)

Transmission oil SAE 90 in

accordance with API GL5 / MIL

L- 2105B

See section

OIL FOR FullGrip

AND FRONT AXLE

in this section

461.00016.00 2.75 0.7

BRAKE FLUID

AND INCHING

SAE 10W Hydraulic Oil or ATF

fluid in accordance with CAT TO-4 / TO-2 o ALLISON C-4

/ C-3.

See section

BRAKE FLUID

AND INCHING

in this section

461.00015.00 1 0.26

WINDSCREEN

WIPER WASHER

Freezing point

temperature: - 20ºC

465.00016.00 1.5 0.4

BATTERY

ELECTROLYTE

Distilled Water

See section

BATTERY

ELECTROLYTE

in this section

GREASING

POINTS

Calcic grease NLGI-3

consistency

See section

LUBRICATION

POINTS

in this Operator’s

Manual

461.00009.00

Recommended

fluids and lubricants

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 Engine oil (fig. 1)

Use oil for 4-stroke engines in accordance with MIL-L-2104C / API CD or superior. Always check the API quality on the oil container label to ensure that it is the required quality. Your machine leaves the factory with SAE 15W40 viscosity. However, depending on the environment temperatures, refer to the following chart (fig. 1) to select the proper viscosity. If oils of different brand names are used, ensure that you completely empty the crankcase before adding the new oil.

AUSA recommends oil REPSOL AUSA EFFICIENT for Diesel engines p/n 461.00099.01

 Hydraulic Oil

- VG 32 for environment temperatures usually below 50ºF (10ºC)

- VG 46 for environment temperatures between 50F to 120ºF (10ºC to 40ºC)

- VG 68 for environment temperatures above 120ºF (40ºC)

AUSA recommends oil REPSOL AUSA EFFICIENT hydraulics p/n 461.00099.06

 Coolant

Always use ethyiene-glycol antifreeze containing corrosion inhibitors especially for internal combustion aluminium engines. The cooling systems must be filled with distilled water and antifreeze solution (70 water, 30 antifreeze in a standard machine for temperatures ranging from -17 °C to 127 °C) (50 water, 50 antifreeze for temperatures ranging from -35 °C to 145 “C).

 Oil for FullGrip® System and front axle

Oil AUSA COMPEN EFFICIENT p/n 461.00099.09 with the following characteristics:

- Friction coefficient modifying additives

- “Extreme pressure” and anti-wear capacity

- Good antirust and anticorrosion characteristics

- Excellent thermal stability

- Avoids vibrations and noises

 Brake and inching fluid

Only use only SAE 10W or ATF oil in accordance with CAT TO-4 / TO-2 or ALLISON C-4 / C-3.

AUSA recommends oil REPSOL AUSA EFFICIENT TRANSMISSIONS p/n 461.00099.07

CAUTION:

To avoid serious damage to the brake system or clutch system do not use fluids other than the recommended one, or mix different fluids for topping up.

 Battery electrolyte

This vehicle is equipped with a battery that requires maintenance. Add distilled water if necessary.

Recommended

fluids and lubricants

(fig. 1)

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Maintenance Chart

EVERY

I: Inspect, verify, clean, lubricate, replace if necessary

Initial inspection (50 h)

Every 100 h.

Every 200 h.

Every 400 h.

Every 500 h.

Every 800 h.

Every 1000 h

Every 1500 h.

Every 3000 h.

Every week

Every month

Every year

Every 2 years

To be performed by

C: Clean

L: Lubricate

R: Replace MOTOR

Oil and oil filter (1) R R R CUSTOMER

Alternator belt (1) I I R R DEALER

Valve clearance I DEALER

Compression of the cylinders I DEALER

FUEL SYSTEM

Air filter element (4) C R(5) R CUSTOMER

Intake air I R CUSTOMER

Fuel pipes and clamps I R(2) CUSTOMER

Fuel filter cartridge R CUSTOMER

Fuel prefilter (1) R R CUSTOMER

Fuel tank C CUSTOMER

Fuel injection nozzle injection pressure (2) I DEALER

Injection pump (timing) (2) I I DEALER

Fuel injection timer I DEALER

COOLING SYSTEM

Radiator hoses and clamp bands I R CUSTOMER

Cooling system pressure test I CUSTOMER

Water jacket (radiator interior) C DEALER

Coolant I R R CUSTOMER

ELECTRICAL SYSTEM

Battery electrolyte I I CUSTOMER

Battery connections I CUSTOMER

Dash panel indicators / Warning lights (3) I CUSTOMER

Battery I R CUSTOMER

Electric harness and loose connections I CUSTOMER

HYDRAULIC CIRCUIT

Oil and suction strainer (3) R R I CUSTOMER

Hydraulic cartridge R R CUSTOMER

Mast functions (3) I CUSTOMER

Pipes, hoses and fittings damages or leaks I CUSTOMER

Hoses I CUSTOMER

Steering (3) REPLACE EVERY 6 YEARS DEALER

(1) Initial inspection. The initial maintenance is very important and must not be neglected. (2) To be performed by an authorized AUSA dealer. (3) Daily inspection item. (4) More often under severe use such dusty areas, sand, snow, wet or muddy conditions. (5) Or at least once a year. (6) ….or six times after clean.

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

Maintenance Chart

EVERY

I: Inspect, verify, clean, lubricate, replace if necessary

Initial inspection (50 h)

Every 100 h.

Every 200 h.

Every 400 h.

Every 500 h.

Every 800 h.

Every 1000 h

Every 1500 h.

Every 3000 h.

Every week

Every month

Every year

Every 2 years

To be performed by

C: Clean

L: Lubricate

R: Replace GREASING POINTS

Masts guides L CUSTOMER

Nipples (see section "Greasing points" in this Manual) L CUSTOMER

Cables and articulations (throttle, lifting rams...) L CUSTOMER

TRANSFER-BOX

Oil (1) R R I R CUSTOMER

Oil leaks I CUSTOMER

Screws and nuts torque I CUSTOMER

AXLES (FRONT AND REAR)

Oil (1) R R I R CUSTOMER

Oil leaks I CUSTOMER

Fixation wheel nuts torque I CUSTOMER

Chassis fixation screws (torque) I DEALER

Cardan joint fixation screws (torque) I DEALER

Flange fixation nut (torque) I DEALER

Condition of tires and pressures I CUSTOMER

BRAKES

Brake fluid (3) R I R CUSTOMER

Foot brake adjustment (3) I I CUSTOMER

BODY / FRAME

Cabin I CUSTOMER

Seat belt (3) I CUSTOMER

Foot plate, access steps and handles (3) I/C CUSTOMER

Guards and covers (3) I CUSTOMER

Plates and decals (3) I/C CUSTOMER

Tipped cabin safety latch I CUSTOMER

Cabin lock I CUSTOMER

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

 General comments Only original AUSA spare parts should be used during maintenance operations. This is the only way to guarantee that the AUSA machinery will have the same operational level that it had upon delivery.

This forklift, as with any machine, contains parts and systems which are subject to wear or require re-adjusting, and which may affect the reliability of the machine and the safety of the operator, the environment and the surrounding area, such as for example, exhaust gas emissions. The necessary maintenance should be carried out regularly in order to ensure similar conditions to those existing on leaving the factory. All repair and maintenance operations should be made while the forklift is unloaded, the parking brake applied and the wheels blocked in order to keep the forklift stationary.

Disconnect the battery (fig. 1) before carrying out any work on the electrical system.

Never use a flame to check fluid levels.

Respect the environment

When changing oil or other fluids use a suitable container to collect the old fluid. Take care not to cause damage to the environment and take all the replaced materials (batteries, coolant, etc) to the appropriate recycling centres. In the event of leaks of substances which may be harmful to persons or to the environment, immediately take the necessary measures to reduce their impact, for example in the case of oil leaks, plug the leak, use a recipient to collect the oil, sprinkle absorbent material or collect up and remove the contaminated soil if necessary.

 Access for maintenance

The engine, the transmission and filters are located under the cabin floor (fig.2). To

access them, you have to proceed as follows:

- Start the forklift and tilt the mast forwards (the operator remains seated in the driver’s cabin).

- Stop the engine and remove the key from the ignition.

- Move the joystick to the right until reaching the maximum forward tilt.

- Stop the engine and remove the key from the ignition.

- Get down from the driver’s cabin.

- Pull the handle (a) located at the left side of the seat (fig. 3) to unlock the cabin

latch.

- The cabin will tip up, allowing access in order to carry out the maintenance operations.

Periodic

Maintenance

Operations

(fig. 3) (fig. 2) (fig. 1)

C300H / C300HI / C300H x4 / C300HI x4 C350H / C350HI / C350H x4 / C350HI x4

- After lifting up the cabin, it should be secured using the safety lock

- CAB SAFETY PROP STOWED AWAY (fig. 1)

- CAB SAFETY PROP LOWERED INTO POSITION (fig. 2)

WARNING

Whenever the cabin is raised, the safety lock must be on. This prevents the cabin from causing an accident on descending.

To access the upper part of the engine, after raising and securing the operator cabin, lift

the inspection cover (fig. 3)(a) by pulling on the lock (fig. 3)(b). To access the sides of the engine, undo the bolt (fig. 4)(c) and nut (fig. 4)(d) and

remove the rear wheel cover. There is a wheel cover on each side of the machine.

 Daily checks

- Before starting to work with the forklift, clean any oil or fuel spills, clean and remove grease from hands and the soles of shoes and do not forget to make the following checks:

- Condition of the lifting chains

- Tyre pressure and condition of the tread.

- Brakes.

- Leaks in the hydraulic, coolant, fuel circuits, etc.

- Check the correct position and fastening of all the guards, caps and safety stops.

- Absence of cracks or other structural defects visible at first glance.

- Check that all the controls are operating correctly.

- Check fluid levels:

- fuel.

- brake fluid.

- hydraulic circuit fluid.

- coolant circuit fluid.

- Check that alarm and signalling devices are operating correctly (for example: acoustic warning, air intake filter blocked warning, etc.)

- Check that informative and safety plates on the forklift are clean and in good condition.

- Clean and check lighting and signalling system are operating correctly.

- Check electrical battery connections and level of electrolyte.

- Adjust the seat to your build.

- Carefully inspect the condition of the seatbelt, paying special attention to:

- Cuts or fraying on the belt.

- Wear or damage to the fastenings including the anchorage points.

- Poor functioning of the buckle or automatic reel device.

- Loose stitching.

Correct any problems before using the forklift. Where necessary, refer the problem to an authorized AUSA dealer.

Periodic

Maintenance

Operations

(fig. 1)(fig. 2)

(fig. 4)

(fig. 3)

AUSA C300HI x4, C350H x4, C350HI x4, C300H x4 Operator's Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
