Product Specification
AU OPTRONICS CORPORATION
G190EG02 V0
( ) Preliminary Specification
( V ) Final Specification
Module 19.0” SXGA Color TFT-LCD
Model Name G190EG02 V0
Customer Date
Approved by
Checked &
Approved by
Vito Huang
Prepared by
Ginger Lin
Date
July 1, 2013
July 1, 2013
Note: This Specification is subject to
change without notice.
document version 1.2 1/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Desktop Display Business Group /
AU Optronics corporation
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
G190EG02 V0
Record of Revision
Version & Date Page Old Description New Description Remark
0.1 2010/1/19 All First Edition for Customer
0.2 2010/8/05 12 New Block Function Diagram
28 New Drawing (Front)
29 New Drawing (Rear)
0.3 2010/12/10 6 New Physical Size
7,13,16 New LED Current
16 Updated Swing Voltage
22 New Power ON/OFF Sequence
27 New Drawing (Front)
28 New Drawing (Rear)
1.0 2011/040/6 27 New Drawing (Front)
28 New Drawing (Rear)
1.1 2011/06/20 16
Dimming Frequency:
Min. Typ. Max. Unit
18 20 ʳ [kHz]
Dimming Frequency:
Min. Typ. Max. Unit
200 - 20Kʳ [Hz]
28 Indicate connector Pin 1
Remove “Thickness 18 mm Max”
1.2 2013/07/01 24 Update 7.1.1 Connector
1.2 2013/07/01 25 Update 7.2 Backlight Connector
1.2 2013/07/01 25 Update 7.2.1 Pin#7 & #9
1.2 2013/07/01 27~29 Add Packing Form
document version 1.2 2/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
G190EG02 V0
Contents
1. Handling Precautions ..................................................................................................................4
2. General Description..................................................................................................................... 5
2.1 Display Characteristics ........................................................................................................................6
3. Functional Block Diagram.........................................................................................................12
4. Absolute Maximum Ratings...................................................................................................... 13
4.1 Absolute Ratings of TFT LCD Module ............................................................................................. 13
4.2 Absolute Ratings of Backlight Unit ................................................................................................... 13
4.3 Absolute Ratings of Environment ...................................................................................................... 13
5. Electrical characteristics .......................................................................................................... 15
5.1 TFT LCD Module ............................................................................................................................. 15
5.2 Backlight Unit.................................................................................................................................... 16
6. Signal Characteristic .................................................................................................................17
6.1 Pixel Format Image ........................................................................................................................... 17
6.2 The Input Data Format ...................................................................................................................... 18
6.4 Interface Timing................................................................................................................................. 21
6.5 Power ON/OFF Sequence................................................................................................................. 23
7. Connector & Pin Assignment ...................................................................................................24
7.1 TFT LCD Module ............................................................................................................................. 24
7.2 Backlight Unit.................................................................................................................................... 25
8. Reliability Test............................................................................................................................ 26
9. Shipping Label............................................................................................................................27
10. Packing Form............................................................................................................................27
11. Mechanical Characteristic ......................................................................................................30
document version 1.2 3/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
G190EG02 V0
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when
handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was taken out
from the container, do not press the center of the LED reflector edge. Instead, press at the far ends
of the LED Reflector edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module even
momentary. At designing the enclosure, it should be taken into consideration that no
bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT Module
may be damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The LCD module
should be supplied by power complied with requirements of Limited Power Source (IEC60950 or
UL1950), or be applied exemption.
13) The LCD module is designed so that the LED in it is supplied by Limited Current Circuit (IEC60950 or
UL1950).
document version 1.2 4/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
G190EG02 V0
2. General Description
G190EG02 V0 is a Color Active Matrix Liquid Crystal Display composed of a TFT-LCD panel, a driver circuit,
and backlight system. The screen format is intended to support the SXGA (1280(H) x 1024(V)) screen and
16.7M colors 8-bits. All input signals are LVDS interface compatible. G190EG02 V0 is designed for a
general display unit.
document version 1.2 5/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 oC condition:
Screen Diagonal [mm]
Active Area [mm]
Pixels H x V
Pixel Pitch [mm]
Pixel Arrangement
Display Mode
White Luminance [cd/m2] 600 (center, Typ)
Contrast Ratio
Optical ResponseTime [msec]
Nominal Input Voltage VDD [Volt]
Items Unit Specifications
482.6 (19.0" )
376.32 (H) x 301.056 (V)
1280(x3) x 1024
0.294 (per one triad) x 0.294
R.G.B. Vertical Stripe
Normally Black
2000: 1 (Typ)
8ms GTG (Avg. Typ.); 20 ms(Typ, on/off)
+5.0 V
G190EG02 V0
Power Consumption [Watt] 55 W (Typ)
Weight [Grams]
Physical Size (H x V x D) [mm]
Electrical Interface
2000 (Typ) ; 2100 (Max)
396 (H) x 324 (V) x 21.35 (D) (Typ)
Dual channel LVDS
Surface Treatment Hard-coating (3H), Non-Glare treatment
Support Color
Temperature Range
Operating
Storage (Non-Operating)
RoHS Compliance
o
[
C]
o
[
C]
16.7M colors 8-bits
0 to +50
-20 to +60
RoHS Compliance
document version 1.2 6/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
G190EG02 V0
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25oC (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
Horizontal (Right)
CR = 10 (Left)
Viewing Angle [degree]
Vertical (Up)
CR = 10 (Down)
Luminance Uniformity [%] 9 Points 75 80 - 2, 3
Rising 15 25 4,6
Falling 5 15 4,6
Response time [msec]
Rising + Falling 20 40 4,6
75
75
75
75
89
89
89
89
-
1
-
Grey to Grey (Avg.) - 8 16 4,6
Red x 0.617 0.647 0.677
Red y 0.31 0.34 0.37
Green x 0.277 0.327 0.377
Color / Chromaticity
Coordinates
(CIE 1931)
Green y 0.571 0.601 0.641
4
Blue x 0.112 0.142 0.172
Blue y 0.037 0.067 0.099
White x 0.283 0.313 0.34
White y 0.299 0.329 0.359
Black Luminance
(At LED =100mA)
White Luminance
(At LED =100mA)
[cd/m2 ]
[cd/m2 ]
0.3 0.45 4
450 600 - 4
Contrast Ratio 1000 2000 - 4
Cross Talk (At 75Hz) [%] - - 1.5 5
Flicker [dB] - - -20
C.G.L
Ӕu’v’
- - 0.02
7
8
Optical Equipment: BM-5A, PR880, SR3, CS1000 or equivalent.
document version 1.2 7/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Note 1: Definition of viewing angle
Viewing angle is the measurement of contrast ratio Њ10, at the screen center, over a 180° horizontal and
180° vertical range (off-normal viewing angles). The 180° viewing angle range is broken down as follows;
90° (Ӱ) horizontal left and right and 90° (ӥ) vertical, high (up) and low (down). The measurement direction
is typically perpendicular to the display surface with the screen rotated about its center to develop the desired
measurement viewing angle.
G190EG02 V0
Note 2: 9 points position
90 %
50 %
10 %
10 %
50 %
90 %
Note 3: The luminance uniformity of 9 points is defined by dividing the maximum luminance values by the
minimum test point luminance
document version 1.2 8/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Ӭ
W9
Minimum Luminance of 9 points
=
Maximum Luminance of 9 points
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Note 4: Measurement method
The LCD module should be stabilized at given temperature for 30 minutes to avoid abrupt temperature
change during measuring. In order to stabilize the luminance, the measurement should be executed after
lighting Backlight for 30 minutes in a stable, windless and dark room. ʳ
G190EG02 V0
Photo detector
Field=2
50 cm
Note 5: Definition of Cross Talk (CT)
CT = | YB – YA | / YA Ø 100 (%)
Where
YA = Luminance of measured location without gray level 0 pattern (cd/m2)
YB = Luminance of measured location with gray level 0 pattern (cd/m2)
LCD Panel
Center of the screen
TFT-LCD Module
document version 1.2 9/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Note 6: Definition of response time:
B
A
100%
90%
10%
0%
Optical Response Driving Signal
Product Specification
AU OPTRONICS CORPORATION
G190EG02 V0
Time
Tr Tf
Algorithm:
16 B Level - A Level ≥ then the average of Grey-to-Grey response time is 8ms. ( F= 60 Hz).
Tr
(rising time; from “All Black” to “All White”) + Tr
R
Note 7: Subchecker Pattern
R G B R G B
R G B R G B
G B R G B
Method: Record dBV & DC value with (WESTAR)TRD-100
(Falling time; from “All White” to “All Black”) = 20ms(typ).
F
Gray Level = L127
Gray Level = L0
Time
document version 1.2 10/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Amplitude
DC
log20(dB)Flicker =
Note 8: Color Grayscale Linearity
a. Test imageΚ100% full white pattern with a test pattern as below
b. Test patternΚSquares,40mm by 40mm in size, filled with 255, 225,195,165,135 and 105 grays
steps should be arranged at the center of the screen.
Product Specification
AU OPTRONICS CORPORATION
AC
Time
Hz) 30Level(at AC
Level DC
G190EG02 V0
c. Test method
st
gray scaleΚMove a square of 255 gray level should be moved into the center of the screen
-1
and measure luminance and u’ and v’ coordinates.
- Next gray stepΚMove a 225 gray square into the center and measure both lumince and
coordinates, too.
d. Test evaluation
22
)''()''(''
vvuuvu −+−=Δ
BABA
Where A,BΚ2 gray levels found to have the largest color differences between them
i.e. get largest
'uΔ and 'vΔ of each 6 pair of 'u and 'v and calculate '' vuΔ
document version 1.2 11/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
G190EG02 V0
AU OPTRONICS CORPORATION
3. Functional Block Diagram
The following diagram shows the functional block of the 19.0 inches Color TFT-LCD Module:
document version 1.2 12/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
V
www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
G190EG02 V0
4. Absolute Maximum Ratings
Absolute maximum ratings of the module are as following:
4.1 Absolute Ratings of TFT LCD Module
Item Symbol Min. Max. Unit Conditions
Logic/LCD Drive
oltage
VDD -0.3 +6 [Volt] Note 1, 2
4.2 Absolute Ratings of Backlight Unit
Item Symbol Min. Max. Unit Conditions
LED Current ILED - 100 [mA] rms Note 1, 2
4.3 Absolute Ratings of Environment
Item Symbol Min. Max. Unit Conditions
Operating Temperature TOP 0 +50 [oC]
Operation Humidity HOP 5 90 [%RH]
Storage Temperature TST -20 +60 [oC]
Storage Humidity HST
5 90
[%RH]
Note 3
document version 1.2 13/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
G190EG02 V0
AU OPTRONICS CORPORATION
Note 1: With in Ta= 25
o
C
Note 2: Permanent damage to the device may occur if exceed maximum values
Note 3: For quality performance, please refer to AUO IIS (Incoming Inspection Standard).
Operating Range Storage Range
document version 1.2 14/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
G190EG02 V0
AU OPTRONICS CORPORATION
5. Electrical characteristics
5.1 TFT LCD Module
Input power specifications are as follows:
Symble Parameter Min. Typ. Max. Unit Condition
VDD
IDD Input Current - 1.50 1.80 [A]
PDD VDD Power - 7.5 9.0 [Watt]
Logic/LCD Drive
Voltage
4.5 5.0 5.5 [Volt] ±10%
VDD= 5.0V, All White Pattern
At 60Hz
VDD= 5.0V, All White Pattern
At 60Hz , Note 1
IRush Inrush Current - 2 3 [A] Note 2
Note 1: The variance of VDD power consumption is ±10%.
Note 2: Measurement conditions:
+5.0V
R1
47K
(High to Low)
Control
Signal
SW1
SW MAG-SPST
1 2
+12.0V
C2
1uF/25V
R2
1K
VR1
47K
D6
D5
D2 S
D1
G
C3
0.01uF/25V
Q3
AO6402
D2SD1D5
G
D6
Q3
AO6402
F1
90%
C1
1uF/16V
VCC
(LCD Module Input)
5.0V
VDD rising time
0V
10%
470 us
document version 1.2 15/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
5.2 Backlight Unit
Following characteristics are measured under a stable condition at 25
Symbol Parameter Min. Typ. Max. Unit Remark
VCC Input Voltage 12
I
Input Current 3.96
VCC
P
VCC
Irush LED Inrush Current - 4.3 -
F
PWM
Swing Voltage - 3.3 -
Dimming Duty Cycle 10 - 100
Power Consumption 47.5 51
Dimming Frequency 200 20K
[Volt]
[A] 100% PWM Duty
[Watt] 100% PWM Duty
[A] at rising time=470us
[Hz]
V
%
G190EG02 V0
IF LED Forward Current 100 mA Ta = 25oC
- - - Volt
VF LED Forward Voltage
- 3.33 - Volt IF =100mA, Ta = 25oC
- - -
P
LED
Operation
Lifetime
LED Power
Consumption
- 40 - Watt
50,000
Hrs IF=100mA, Ta= 25oC
=100 mA, Ta = 25oC
I
F
Note 1: Ta means ambient temperature of TFT-LCD module.
Note 2: VCC, Ivcc, P
Note 3: I
, VF , P
F
LED
Irush
VCC ,
LED are defined for LED B/L.(100% duty of PWM dimming)
are defined for LED Light Bar. There is two LED channel (AN1-CA1-CA2) in back light unit.
Note 4: If G190EG02 V0 module is driven by high current or at high ambient temperature & humidity condition. The
operating life will be reduced.
Note 5: Operating life means brightness goes down to 50% initial brightness. Minimum operating life time is estimated
data.
document version 1.2 16/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
6. Signal Characteristic
6.1 Pixel Format Image
Following figure shows the relationship of the input signals and LCD pixel format.
1st Line
0 1 1279 1280
R G B R G B
G190EG02 V0
R G B R G B
1024th Line
R G B R G B
R G B R G B
document version 1.2 17/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
6.2 The Input Data Format
Product Specification
AU OPTRONICS CORPORATION
G190EG02 V0
Note1: Normally, DE, VS, HS on EVEN channel are not used.
Note2: Please follow VESA.
Note3: 8-bit in
document version 1.2 18/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
G190EG02 V0
6.3 Signal Description
The module using a pair of LVDS receiver SN75LVDS82(Texas Instruments) or compatible. LVDS is a
differential signal technology for LCD interface and high speed data transfer device. Transmitter shall be
SN75LVDS83(negative edge sampling) or compatible. The first LVDS port(RxOxxx) transmits odd pixels
while the second LVDS port(RxExxx) transmits even pixels.
PIN # SIGNAL NAME DESCRIPTION
1 RxOIN0- Negative LVDS differential data input (Odd data)
2 RxOIN0+ Positive LVDS differential data input (Odd data)
3 RxOIN1- Negative LVDS differential data input (Odd data)
4 RxOIN1+ Positive LVDS differential data input (Odd data)
5 RxOIN2- Negative LVDS differential data input (Odd data, H-Sync,V-Sync,DSPTMG)
6 RxOIN2+ Positive LVDS differential data input (Odd data, H-Sync,V-Sync,DSPTMG)
7 VSS Power Ground
8 RxOCLKIN- Negative LVDS differential clock input (Odd clock)
9 RxOCLKIN+ Positive LVDS differential clock input (Odd clock)
10 RxOIN3- Negative LVDS differential data input (Odd data)
11 RxOIN3+ Positive LVDS differential data input (Odd data)
12 RxEIN0- Negative LVDS differential data input (Even data)
13 RxEIN0+ Positive LVDS differential data input (Even data)
14 VSS Power Ground
15 RxEIN1- Negative LVDS differential data input (Even data)
16 RxEIN1+ Positive LVDS differential data input (Even data)
17 VSS Power Ground
18 RxEIN2- Negative LVDS differential data input (Even data)
19 RxEIN2+ Positive LVDS differential data input (Even data)
20 RxECLKIN- Negative LVDS differential clock input (Even clock)
21 RxECLKIN+ Positive LVDS differential clock input (Even clock)
22 RxEIN3- Negative LVDS differential data input (Even data)
23 RxEIN3+ Positive LVDS differential data input (Even data)
24 VSS Power Ground
25 VSS Power Ground
26 NC No Connection ( for AUO test)
27 VSS Power Ground
28 VCC +5.0V Power Supply
29 VCC +5.0V Power Supply
30 VCC +5.0V Power Supply
document version 1.2 19/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
r
V
www.panelook.com
Note1: Start from left side
Product Specification
G190EG02 V0
AU OPTRONICS CORPORATION
Connecto
30
RxOIN0-
CC
Note2: Input signals of odd and even clock shall be the same timing.
Note3: Please follow PSWG.
document version 1.2 20/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
G190EG02 V0
AU OPTRONICS CORPORATION
6.4 Interface Timing
6.4.1 Timing Characteristics
Basically, interface timings described here is not actual input timing of LCD module but output timing of
SN75LVDS82DGG (Texas Instruments) or equivalent.
Item Symbol Min Typ Max Unit
Data CLK Tclk 30 54 83 MHz
H-section
V-section
Frame Rate F 50 60 75 Hz
Note : DE mode only
Period Th 720 844 1024 Tclk
Display Area Tdisp(h) 640 640 640 Tclk
Period Tv 1035 1066 2048 Th
Display Area Tdisp(v) 1024 1024 1024 Th
document version 1.2 21/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
6.4.2 Timing Diagram
RGB Data
(Odd)
RGB Data
(Even)
Invalid Data
Invalid Data
Product Specification
G190EG02 V0
AU OPTRONICS CORPORATION
RGB Data
Line Line Line Line Line Line
N
Invalid Data
DE
Tfp(v)
Tbp(v)
Hsync
Vsync
PWvs
DE
Tbp(h)
PWhs
Hsync
CLK
Tclk
Pixel
Pixel
2
1
Pixel Pixel
Pixel
4
39 M-1
Pixel
6
5M-3
Pixel Pixel Pixel Pixel Pixel Pixel
7
8
10
11
12
M-5
M-4
M-2
M
Invalid Data
Tdisp(h)
PixelPixelPixelPixel
PixelPixel
Tfp(h)
Invalid Data
Tv
2
Tdisp(v)
43
N1
Th
Invalid Data
document version 1.2 22/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
G190EG02 V0
6.5 Power ON/OFF Sequence
VDD power and LED on/off sequence is as follows. Interface signals are also shown in the chart. Signals
from any system shall be Hi-Z state or low level when VDD is off.
Power Sequence Timing
Note: The values of the table are follow VESA.
document version 1.2 23/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
G190EG02 V0
7. Connector & Pin Assignment
Physical interface is described as for the connector on module.These connectors are capable of
accommodating the following signals and will be following components
.
7.1 TFT LCD Module
Connector Name / Designation Interface Connector / Interface card
Manufacturer JAE/ STM
Type Part Number STM:MSBKT2407P30HB
Mating Housing Part Number
JAE: FI-X30HL
STM:PK2407P30V
7.1.2 Pin Assignment
Pin# Signal Name Pin# Signal Name
1 RxOIN0- 2 RxOIN0+
3 RxOIN1- 4 RxOIN1+
5 RxOIN2- 6 RxOIN2+
7 VSS 8 RxOCLKIN-
9 RxOCLKIN+ 10 RxOIN3-
11 RxOIN3+ 12 RxEIN0-
13 RxEIN0+ 14 VSS
15 RxEIN1- 16 RxEIN1+
17 VSS 18 RxEIN2-
19 RxEIN2+ 20 RxECLKIN-
21 RxECLKIN+ 22 RxEIN3-
23 RxEIN3+ 24 VSS
25 VSS 26 NC
27 VSS 28 VCC
29 VCC 30 VCC
document version 1.2 24/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
7.2 Backlight Unit
Connector Name / Designation Backlight Connector
Manufacturer STM
Connector Model Number STM: MS240415HJ
Mating Model Number STM: P240415
7.2.1 Signal for LED connector
Pin # Symbol Pin Description
1 GND GND
2 GND GND
3 GND GND
G190EG02 V0
4 +12v Power +12V
5
6 +12v Power +12V
7 En
8 NC NC
9 Dimming
10
11 +12v Power +12V
12 +12v Power +12V
13 GND GND
14 GND GND
15 GND GND
+12v
+12v
High : 2.5V~5V; Low (max) : 0.8V
Power +12V
Enable On : 2.5V~5V
Enable Off (max) : 0.8V
PWM (duty 10%~ 100%)
Power +12V
document version 1.2 25/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
8. Reliability Test
Environment test conditions are listed as following table.
Items Required Condition
Temperature Humidity Bias (THB) Ta= 50oC, 80%RH, 300hours
High Temperature Operation (HTO) Ta= 50oC, 50%RH, 300hours
Low Temperature Operation (LTO) Ta= 0oC, 300hours
High Temperature Storage (HTS) Ta= 60oC, 300hours
Low Temperature Storage (LTS) Ta= -20oC, 300hours
Vibration Test
(Non-operation)
Acceleration: 1.5 G
Wave: Random
Frequency: 10 - 200 - 10 Hz
Sweep: 30 Minutes each Axis (X, Y, Z)
G190EG02 V0
Note
Acceleration: 50 G
Shock Test
(Non-operation)
Wave: Half-sine
Active Time: 20 ms
Direction: X,ʳY,ʳZ (one time for each Axis)
Drop Test Height: 60 cm, package test
Thermal Shock Test (TST) -20oC /30min, 60oC /30min, 100 cycles
On/Off Test On/10sec, Off/10sec, 30,000 cycles
1
Contact Discharge: ± 8KV, 150pF(330Ω ) 1sec,
8 points, 25 times/ point.
ESD (ElectroStatic Discharge)
2
Air Discharge: ± 15KV, 150pF(330Ω ) 1sec
8 points, 25 times/ point.
Altitude Test
Operation:10,000 ft
Non-Operation:30,000 ft
Note 1: The TFT-LCD module will not sustain damage after being subjected to 100 cycles of rapid
temperature change. A cycle of rapid temperature change consists of varying the temperature from
-2
o
˃
C to 6
o
˃
C, and back again. Power is not applied during the test. After temperature cycling, the
unit is placed in normal room ambient for at least 4 hours before power on.
Note 2: According to EN61000-4-2, ESD class B: Some performance degradation allowed. No data lost.
Self-recoverable. No hardware failures.
document version 1.2 26/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
9. Shipping Label
The shipping label format is shown as below.
10. Packing Form
Packaging material
G190EG02 V0
FILM PROTECT
BAG ANTI-STATIC
TAPE
TAPE CREPED PAPER
PACKING CARTON
LABEL SPEC
LABEL CARTON.
CUSHION PACKING
document version 1.2 27/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Packing instruction
Product Specification
AU OPTRONICS CORPORATION
G190EG02 V0
Max capacityΚ6 TFT-LCD module per carton
Max weight: 16.5 kg per carton
Outside dimension of carton: 476mm(L)* 274mm(W)*413mm(H)
Pallet sizeΚ 1150 mm * 980 mm * 135mm
Box Stacked
Module by airΚ(2 *4) *3 layersΔone pallet put 24 boxesΔtotal 144pcs module
Module by seaΚ(2 *4) *3 layers + (2 *4) *1 layers , two pallet put 32 boxesΔtotal 192pcs module
Module by sea_HQΚ(2 *4) *3 layers+(2 *4) *2 layers, two pallet put 40 boxes, total 240pcs module
document version 1.2 28/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Palletizing
Product Specification
AU OPTRONICS CORPORATION
G190EG02 V0
document version 1.2 29/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
11. Mechanical Characteristic
G190EG02 V0
document version 1.2 30/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
G190EG02 V0
AU OPTRONICS CORPORATION
document version 1.2 31/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Loading...
