Audiovox APS-520, 128-8146 User Manual
Model APS-520
Owner’s Manual
ARMING THE SYSTEM - ACTIVE
1. Turn off the engine, exit the vehicle, and close all doors, hood lid
and trunk lid.
2. Press and release Lock/Arm button on the keychain transmitter.
The dash mounted LED begins to flash slowly. Parking Light s flash
one time.
Siren sounds one chirp.
If the siren/horn sounds 3 chirps, then you have left a door, trunk,
or hood lid ajar. Simply close the opened entry point to provide full
protection. If the siren "chirped" three times, sometime after arm-
been programmed and the system detected a open entry point after the
learned delay expired. Again, closing the hood, trunk, or doors will correct
the problem and you do not need to disarm the system to make the correction.
If the siren/horn did not sound when arming, then the chirps have been
turned off and you should refer to the section titled "ELIMINATING THE ARM/
DISARM CHIRPS" in this manual.
NOTE: If selectable feature 9, Chirp Delete From Transmitter, was set to the on position during
installation, then you can selectively defeat the arm & disarm chirps by holding the transmitters Lock
or Unlock button for about 2 seconds.
Note: If Passive Arm Mode was selected on during installation, then 30 seconds after the last
PROTECTION WHILE THE SYSTEM IS ARMED
Opening any protected door, hood or trunk lid will cause the alarm to immediately sound. The alarm will
continue to sound for 30 seconds, then stop and continue to monitor all protected entry points. If the thief left
a door opened, the alarm will sound for six 30 second cycles, remain armed and ignore that triggered zone.\
Whenever the system is armed, the dash mounted LED indicator will slowly flash. This serves as a visual
deterrent to the potential thief. The LED is a very low current bulb and will not cause the vehicle’s battery to
drain, even when left unattended for extended periods.
Whenever the system is triggered, the vehicle’s parking lights will flash for the full 30 second alarm cycle,
attracting visual attention to the vehicle.
Optional - Whenever the system is armed, the vehicle’s starting circuit will be bypassed. If the thief should
choose to ignore the siren, the vehicle can not be started.
Any mild impact to the vehicle’s glass will cause the alarm to sound a short series of warning tones.
Any strong impact to the vehicle’s glass will cause the alarm to trigger for the full 30 second alarm cycle.
NOTE: If the optional interior illumination circuit was installed, the interior light will flash as well for the full 30
DISARMING THE SYSTEM
1. As you approach the vehicle, press and release the Unlock/Disarm button on the keychain transmitter.
The dash mounted LED turns off. If passive arming is selected on, the LED will start flashing rapidly, indicating
that the system is re-arming automatically . Open any door to suspend the automatic arming. Parking Lights flash
two times. If the parking lights flashed three times, then the alarm was triggered in your absence. Before
turning the key on, examine the LED to identify which zone was triggered. Siren sounds two chirps. If the
siren sounds 4 chirps, then the alarm was triggered in your absence. Before turning the key on, examine the
LED and refer to the INTRUSION WARNING SIGNALS section of this manual to identify which zone was
triggered.
If the siren did not sound when disarming, then the chirps have been turned off
and you should refer to the section titled “ELIMINATING THE ARM / DISARM CHIRPS“ in this manual.
Doors Unlock - Optional
NOTE: If the optional Interior illumination feature has been added as an added convenience, the system will
WHILE THE SYSTEM IS SOUNDING
If during a triggered state, you wish to shut off the siren without disarming your security system, simply press
and release any transmitter button other than the Unlock/Disarm button. This action will turn off the siren yet
leave the vehicle fully armed and protected. This feature is particularly useful if you are aware of children
playing near your vehicle that may accidently trigger your security system. In this case you can cancel the
siren sounding without disarming your alarm.
INTRUSION WARNING SIGNALS
This system will inform you if an intrusion attempt has occurred while you were away from the vehicle. If an
vehicle door is closed, the unit will arm automatically.
second alarm cycle.
turn on the interior lights when the system is disarmed.
ing, the exclusive, patented, delayed dome light learn circuit has
Page 1
128-8146
1 of 8
intrusion attempt has occurred, the siren will chirp 4 times and the parking lights will flash 3 times when
disarming the system. Enter the vehicle and observe the red dash mounted LED to identify which zone
was triggered.
1. If the LED is flashing one time...pause...one time...pause...etc., then an intrusion attempt was made
to the shock sensor, or an accessory triggering device that may have been added to the system.
2. If the LED is flashing two times...pause...two times...pause...etc., then an intrusion attempt was
made to a hood or trunk pin switch that was added to the system or to a light activated entry point
if the alarm was installed using the voltage sensing feature.
3. If the LED is flashing three times...pause...three times...pause...etc., then an intrusion attempt was
made through one of the vehicle’s doors.
These intrusion warning indicators are stored in the system’s memory and will only be erased when the
ignition key is turned on.
VALET SWITCH
The valet switch allows you to temporarily bypass all alarm functions, eliminating the need to hand your
transmitter to parking attendants or garage mechanics. When the system is in valet mode, all alarm functions
are bypassed, however the remote panic feature and remote door locks will remain operational. In addition,
the parking lights will flash to indicate locking and unlocking. To use the valet mode, the system must first be
disarmed either by using your keychain transmitter or by activating your personalized manual override code.
1. Enter the vehicle and turn the ignition key to the on position.
2. Press and hold the valet pushbutton switch until the dash-mounted LED turns on solid. The system will
remain in the valet mode.
3. To return to normal operation, press and release the pushbutton switch any time the ignition is on.
NOTE: Always remember to return the system to normal operation. This will ensure that the vehicle
remains protected at all times.
MANUALL Y OVERRIDING YOUR SYSTEM:
USING THE VALET SWITCH MANUAL OVERRIDE
Your Security System can be disarmed without the use of the keychain transmitter. This is necessary, since you will
need the ability to operate your vehicle if the transmitter is lost or its battery fails. If your system has been selected for
Valet Switch manual override as indicated on the last page of this manual, to bypass the alarm system;
1. Open the vehicle door. The alarm will sound.
2. Turn the ignition key to the on position.
3. Within 5 seconds, press and release the valet pushbutton switch.
The alarm system will stop sounding and enter the (bypass) mode. You can now start and operate the vehicle
normally.
Typically this override mode is used only if the transmitter has become inoperative.
PROGRAMMING YOUR CUSTOM OVERRIDE CODE:
Unlike override switches easily found, and defeated, this security system allows the consumer to program a personal
override code, offering a higher level of security . To take advant age of this option, programmable feature # 10 must be
selected for the Custom Code Option. Consult your installation center for programming details. The system comes from
the factory with a pre-programmed override code of 11. To change this default override code, do the following:
1. Disarm the system by use of the transmitter, or by use of the emergency override sequence. Turn the
ignition switch to the on position.
2. Within 10 seconds, press and release the valet/override switch, 3 times.
3. Within 10 seconds turn the ignition switch off, on, off, on, off, on.
(The siren or horn will beep and the lights will flash one time with each ignition switch cycle.)
4. Within 10 seconds, begin to enter your chosen 10ths digit by pressing and releasing the pushbutton
switch from 1 up to 9 times.
5. Within 10 seconds of the last entered 10ths digit, turn the ignition switch off then on.
6. Within 10 seconds, begin to enter your chosen units digit by pressing and releasing the pushbutton
switch from 1 up to 9 times.
7. Finish by turning the ignition switch to the off position.
If the new code was accepted, the unit will report back the newly entered code, by flashing the LED, first
indicating the 10ths digit, pause and then the units digit. The unit will report the new code three times with a
one second pause between each code, then the system will begin arming. If the LED flash pattern reports the
previously stored code, the new code was not entered correctly. Please repeat steps 1 through 7 above
considering the following.
NOTE: Acceptable digits 10ths or units are 1 through 9. The unit will not recognize a 0 (Zero), or no
NOTE: If 15 seconds of inactivity expire or if the ignition switch is turned off for more then 5 seconds during
Custom Code Programming Example:
To Change the code from the factory pre-assigned code of 11 to “52” you would do the following:
digit entered in any place, units or tenths.
any of the above steps, the unit will revert back to the last successfully stored code.
1. Disarm the system by use of the transmitter or by use of the emergency override sequence.
Page 2
128-8146
2 of 8
2. Turn the ignition switch to the on position.
3. Within 10 seconds, press and release the valet/override switch, 3 times.
4. Within 10 seconds turn the ignition switch off, on, off, on, off, on. (The siren or horn will beep and the
lights will flash one time.)
5. Within 10 seconds, begin to press and release the pushbutton switch to set the tenths digit.
(As per the example, press and release 5 times to set the tenths digit to 5)
6. Within 10 seconds of the last press of the pushbutton, turn the ignition switch off then on.
7. Within 10 seconds, begin to press and release the pushbutton switch to set the units digit.
(As per the example, press and release 2 times to set the units digit to 2).
8. Turn the ignition switch to the off position. Immediately observe the LED flash pattern.
You will note the LED flashing five times, pause, and then flash two times, pause. This pattern will be repeated
three times indicating the new code (52) has been accepted and stored in memory.
NOTE: If after step 7, the LED flashes a code other than what was just entered, this indicates that the code
Acceptable digits 10ths or units are 1 through 9. The unit will not recognize a 0 (Zero), or no digit entered in
any place, units or tenths.
NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for more then 5 seconds during
MANUALL Y OVERRIDING YOUR SYSTEM:
USING THE CUSTOM CODE OVERRIDE
Assuming the override code programmed has not been changed, and the default override code of 11 is in the
system's memory.
1. Enter the vehicle and turn the ignition switch to the on position.
NOTE: The siren will sound.
2. Within 5 seconds, press and release the pushbutton switch 1 time.
3. Within 5 seconds, turn the ignition switch off then on.
4. Within 5 seconds, press and release the pushbutton switch 1 time.
5. Turn the ignition switch off then on and start the vehicle.
NOTE: If you have changed the programmed override code then substitute your new code tenths for step 2
REMOTE CAR FINDER/PANIC
The Lock or Unlock buttons are also used to access the car finder/panic mode. This feature is particularly
useful in a crowded parking lot where finding your car may be difficult to locate, or if there are suspicious
characters hanging about your vehicle. To access this mode, while within range of your car, simply press and
hold either the lock or unlock button of your transmitter for three seconds. The parking lights will begin to
flash, the siren will sound, and if connected, the vehicle horn will beep making your vehicle audible as
well as more visible. The lights, siren and or horn will stop automatically after 30 seconds. If you wish
to turn off this mode prior to the expiration of the 30 second timer, press and hold for three seconds either the
lock or unlock buttons a second time, or press and release the Trunk/Start button one time.
REMOTE TRUNK RELEASE
If you have electric trunk release in your vehicle and the remote trunk release option was added, simply
press and hold the Key/Trunk button of your keychain transmitter for 3 seconds or until the electric trunk of
your vehicle opens. . .
THE OPTION BUTTON of your transmitter may or may not be used with your system but may be used with
a second similar Audiovox Model system that may be installed on a second vehicle in your family.
ELIMINATING THE NORMAL ARM / DISARM CHIRPS
As explained earlier in the manual, you can eliminate the chirps selectively any time you arm or disarm the
system, if the feature has been activated, simply by holding the ARM or DISARM button for two seconds. If you
find the normal arming and disarming chirps annoying, they can be turned off permanently , eliminating the need
to hold the ARM / DISARM button for 2 seconds. To do this:
If the chirps were off before you started, then you will hear one chirp indicating they have been turned on.
NOTE: Whenever the chirps are bypassed, the 4-chirp intrusion indicator and 3 chirp defective zone
NOTE: Your system must be programmed by the installation center to enable this feature.
RF SHOCK SENSOR MODE SELECTION
The way in which your alarm system reacts to threatening vibrations, created by attempts to enter the vehicle
by breaking a window, is adjustable by the transmitter immediately after arming. There are 4 modes of operation
has not been changed. You will have to repeat steps 1 through 7 above being certain to note the
following:
any of the above steps, the unit will revert back to the last successfully stored code.
above, and units for step 5 above.
1. Turn the ignition key on then off.
2. Within 10 seconds, press and release valet switch three times.
3. If the chirps were on before you started, then you will hear two chirps indicating they have been turned
off.
indicator will always operate. Since these are important warnings to you that something has happened, they cannot be eliminated.
Page 3
128-8146
3 of 8
