Vtfs!Jotusvdujpot
N.OFU
AVIS: RISQUE DE CHOC ELECTRIQUE-NE PAS
OUVRIR WARNING: SHOCK HAZARD-DO NOT OPEB
2; !Jnqpsubou!Tbgfuz!Jogpsnbujpo
Page 1
This lightning flash with arrowhead
symbol within an equilateral triangle is
intended to alert the user to the presence
of non-insulated “dangerous voltage”
within the product’s enclosure that may
be of sufficient magnitude to constitute a
risk of electric shock.
WARNING: To reduce the risk of electric shock, do not
remove cover (back) as there are no user-serviceable
parts inside. Refer servicing to qualified personnel.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance instructions
in the literature accompanying the
appliance.
Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two lades
with one wider than the other. A grounding plug has
two blades and a third grounding prong. The wide
blade or the third prong is provided for your safety. If
the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or
pinched particularly at the plugs, convenience
receptacles, and the point where they exit from the
apparatus.
Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart or rack is
used, use caution when moving the
cart/apparatus combination to avoid injury from tipover.
Unplug the apparatus during lightning storms or
when unused for long periods of time.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
CAUTION: These servicing instructions are for use
by qualified service personnel only. To reduce the
risk of electric shock, do not perform any servicing
other than that contained in the operating instructions
unless you are qualified to do so.
Do not install this equipment in a confined or
building-in space such as a book case or similar
unit, and remain a well ventilation conditions at
open site. The ventilation should not be impeded by
covering the ventilation openings with items such as
newspaper, table-cloths, curtains etc.
WARNING: Only use attachments/accessories
specified or provided by the manufacturer (such as
the exclusive supply adapter, battery etc).
WARINING: To reduce the risk of fire or electric
shock, do not expose this apparatus to rain or
moisture. The apparatus shall not be exposed to
dripping or splashing and that objects filled with
liquids, such as vases, shall not be placed on
apparatus. No naked flame sources, such as lighted
candles, should be placed on the apparatus.
CAUTION: Danger of explosion if battery is
incorrectly replaced. Replace only with the same or
equivalent type.
WARNING: The battery (battery or batteries or battery
pack) shall not be exposed to excessive heat such as
sunshine, fire or the like.
WARNING: The mains plug is used as disconnect
device shall remain readily operable.
The all-pole mains switch and all-pole circuit breakers
are not provided with the apparatus, the installation
shall be carried out in accordance with all applicable
installation rules.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
3; !Hfuujoh!Tubsufe
Page 2
The Audiolab M-NET is a network audio player incorporating the outstanding
level of quality and design you’ve come to expect in all Audiolab products.
Before installing your M-NET please take a few minutes to read this manual
carefully. This will get you on the road to a quick and easy set up with full
functionality.
Inputs:
Ethernet socket for connecting a local area network (LAN)
Wi-Fi socket to allow the wireless connection to networks
USB input to connect a USB storage device
Outputs:
Optical and coaxial digital outputs
Unpacking
Unpack the product fully. The carton should contain:
The Audiolab M-NET
One power pack
Four switchover plugs
One aerial
Remote handset
Warranty Card
If an item is missing or damaged report this to your dealer as soon as possible.
Retain the packing for safe transport of your unit. If you dispose of the packing, do
so with regard to any recycling regulations in your area.
Placement
Place the unit on a sturdy shelf or table. If you use an equipment rack, ensure the
unit has adequate ventilation and is on its own shelf. To minimize any interference
place the power supply in a stable location as far from sensitive analogue inputs
as possible.
Make sure you locate the unit so that the front panel is in view otherwise the
infrared-remote handset will not work.
4; !Dpouspmt!boe !Dpoofdupst
Page 3
5; !Sfnpuf!Iboetfu!
Page 4
1. Press for the Preset recall/save
2. Browse up
3. Press to move to next track. Hold to fast forward
4. Browse down
5. Press to go back to previous menu
6. Press to view more information of station or tracking playing
7. Play/Pause
8. Press to show menu for the current mode
9. Press to select a song, station or submenu
10. Press to move to previous track. Hold to fast reverse
11. Source selection
How to load battery
Put your finger on the battery cover claw located behind the remote handset.
The battery cover can be opened by sliding downwards.
Put a battery (CR2025) in the battery case as shown in the illustration.
Slide the cover back into the case.
Ȕ
Ȕ
Ȕ
* When the battery starts to lose power, the effective distance becomes shorter or
the unit will not function properly. Replace the existing battery with new one to
restore functionality.
* If the remote handset is not used for a long time, the battery should be removed
from the case.
6; !Joqvut!boe !Pvuqvut
Page 5
DIGITAL (SPDIF) OUTPUTS
Coaxial and optical outputs are provided for connecting the M-NET to an external
D/A converter (DAC) like Audiolab Q-DAC or digital recorder. Connect an optical
or a digital cable from the appropriate output to the input of your DAC, etc.
USB INPUT
A USB memory device can be connected to the USB input of this unit to play music
files stored on the memory device.
POWER INPUT
The M-NET should only be connected to a power supply designed exclusively for
this unit. Connect the output from the AC adaptor to the power connector at the
rear panel of the M-NET and then the adaptor to the mains supply.
Plug in any of the switchover plugs in below way:
* Use the appropriate plug for your own region.
ETHERNET SOCKET
Connect the unit to the network permanently with RJ45-RJ45
“straight through” (not “crossover”) networking cable.
Use cable suited to the network type, e.g. 10/100 base-T (most
home networks).
Wi-Fi SOCKET
Connect the supplied aerial to the SMA connector on the back
panel. The aerial should be in the upright position as shown. This
allows connection to 802.11a/b/g or n.
