8300A
User Instructions
1: Important Safety Information
AVIS: RISQUE DE CHOC ELECTRIQUE-NE PAS
OUVRIR WARNING: SHOCK HAZARD-DO NOT OPEN
IMPORTANT SAFETY INFORMATION
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not blo c k an y ve n t i l at io n op e n i ng s . In s t al l in
accordance with the manufacturer’s instructions.
Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
Do not defeat the safety purpose of the polarized or
grounding plug. A grounding plug has two blades and a
third grounding prong. The wide blade or the third prong
is provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of
the obsolete outlet.
Protect the power cord from being walked
on or pinched partic ularly at the plugs,
convenience receptacles, and at the point
where they exit from the apparatus.
Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart or rack is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
Unplug this apparatus during lightning storms or when
unused for long periods of time.
Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
Mains Supply: The mains operating voltage of Audiolab
8300 series units is shown on the rear panel. If this voltage
does not match the mains voltage in your area, consult
your Audiolab dealer about converting the unit.
The mains supply fuse on the rear panel is accessible when
the IEC mains plug has been removed. In the rare event
that it has broken, check for any obvious cause before
replacing the fuse with one of the correct rating and type.
The fuse values are:
220 – 240V (UK, China, etc.) T2.5AL 250V Slow Blow
100 – 120V (UK, China, etc.) T4.0AL 250V Slow Blow
WARNING: Only use attachments/accessories specified or
provided by the manufacturer (such as the exclusive supply
adapter, battery etc.).
WARNING: The mains plug/appliance coupler/direct
plug-in adapter is used as disconnection device; the
disconnection device shall remain readily operable.
CAUTION: These servicing instructions are for use by
qualified service personnel only. To reduce the risk of
electric shock, do not perform any servicing other than
that contained in the operating instructions unless you are
qualified to do so.
Do not install this equipment in a confined or built-in
space such as a bookcase or similar unit, and keep well
ventilated in open space. The ventilation should not be
impeded by covering the ventilation openings with items
such as newspaper, table-cloths, curtains etc.
WARNING: To reduce the risk of fire or electric shock,
do not expose this apparatus to rain or moisture. The
apparatus shall not be exposed to dripping or splashing
and ensure that objects filled with liquids, such as vases,
shall not be placed on the apparatus. No naked flame
sources, such as lighted candles, should be placed on the
apparatus.
This equipment is a Class II or double insulated
electrical appliance. It has been designed in such a
way that it does not require a safety connection to
electrical earth.
Page 1
2: Getting Started
Welcome to Audiolab 8300 Series.
8300A is the latest in a long line of Audiolab integrated amplifiers with a pedigree that stretches back to
the very first 8000A that made Audiolab and overnight sensation.
Inside 8300A you’ll find the latest discrete technology from designers that understand analogue circuitry
inside out. Delivering a balance of refined musical detail and powerful transient performance, 8300A
packs far more weight than its svelte looks would indicate.
Designed to drive any loudspeaker load with absolute stability and finesse, 8300A is the perfect partner
for other Audiolab sources such as 8300CD.
We hope you will enjoy its performance for many years to come.
Please read through this manual to obtain the very best performance from 8300A.
Inputs:
• Six external analog inputs.
• One external analog power input
• XLR balance analog input
Outputs:
• Two pre-amplifier output
• Loudspeaker output
Operating Features:
Unpacking
• Unpacking the product fully. The carton should contain:
• The Audiolab 8300A
• One IEC power cord suitable for your area.
• One Remote handset with two AAA batteries
• This instruction manual.
If an item is missing or damaged report this to your dealer as soon as possible. Retain the
packing for safe transport of your unit. If you dispose of the packing, do so with regard to
any recycling regulation in your area.
Placement
The unit is designed to run warm during normal operation but ensure you do not black any
ventilation openings.
Place the unit on a sturdy shelf or table. If you use equipment rack, ensure the unit has
adequate ventilation and is on its own shelf. To minimize any interference place the power
supply in a stable location as far from sensitive analogue input ads possible.
Ensure your mains voltage corresponds to the rating plate on the rear of the product’s power
supply. If in doubt, consult your dealer. If you move to an area with a different mains voltage
seek advice from an Audiolab appointed dealer or a competent service technician.
• Automatic detection decoding of external digital input source.
• Selectable digital filler setting.
• Fully variable output in the digital domain absolute fidelity with the straightest possible signal path.
• Automatic trigger post equipments via 12V trigger output.
• Analogue output level selectable between fixed and variable.
• Eight display brightness available with display on/off options.
• Auto standby function with function on/off options.
Page 2
