Introduction
Dear Customer,
Congratulations on your purchase of the worlds finest brand of car audio products. Here at DUB audio we are devoted to making our musical reproduction the very best, and we are pleased you have chosen our product. Through years of engineering expertise, hand craftsmanship, and critical testing procedures, we have created a wide range of products that reproduce music with all the clarity and richness you deserve.
For maximum performance we recommend you have your DUB audio product installed by an Authorized DUB audio Dealer. Please read your warranty, keep your receipt, and original carton for possible future use.
To get a free brochure on DUB audio products in the U.S. call (714) 988-0400 or e-mail us at www.dubaudioseries.com
WARNING
Continuous exposure to sound pressure levels over 100 dB may cause permanent hearing loss. High powered autosound systems may produce sound pressure levels well over 135dB. Need we say more! Use common sense.
If after reading this manual, you still have questions regarding your product, we recommend that you see your nearest DUB audio Dealer. A list of Authorized DUB audio Dealers can be found on our web page. If you need further assistance, feel free to call us at (800)488-8595 and ask for the Technical Department. Be sure to have the model number, date of purchase, and invoice number available when you call.
The model number can be located on the outside of the carton. Record this in the space provided below along with the date of purchase. It is a good idea to keep your receipt with this, as you will need it in the case of a warranty repair or exchange.
Model Number:___________________
Date of Purchase: _____________________
01
Table of Contents
Introduction |
01 |
Getting Started |
02 |
Woofer Introduction |
03 |
Woofer Features |
04-05 |
Theile / Small Parameters |
06 |
Box Parameters |
07 |
Graphical Response Curves |
08-10 |
Enclosure and Setup |
11 |
Troubleshooting |
12 |
Warning and Disclaimer |
13 |
Warranty |
14-15 |
Getting Started
Welcome to DUB audio This manual has been designed to provide information for the owner, salesperson, and installer. For those of you who want quick information on how to install this product, please turn to the installation section of this manual. Other information can be located by using the table of contents. We at Audiobahn have worked very hard to make sure that all of the information in this manual is current, but, as we are costantly finding new ways to improve our product, this information is subject to change without notice. All updated information can be found on our web page in the technical support section.
02
Woofer Introduction
Audiobahn woofers are a low frequency driver designed primarily for use in small sealed or vented enclosures depending on the model of sub. Please check the specifications in this manual, our website at www.audiobahninc.com , or call us at 714-988-0400 or 800-488-8595. As specifications and parameters are subject to change, we highly advise always checking our web site or calling us for the most current information. By utilizing the latest materials and construction design and techniques, we are able to offer a subwoofer with optimized low frequency response.
Woofer
Audiobahn Dual 4 Ohm Coil
High Excursion Sub
Audiobahn Sticker
Installation & Owner's Manual
Wipe Towel
Registration and Warranty Card
Technical Design Features
Cast
The dual voice coil woofers use a polished chrome steel stamped basket. This ensures a perfect alignment on each and every woofer.
Poly Coated Cone
The cone material used in the cast basket sub woofer is spruce pulp paper. This provides a combination of weight and strength and allows high levels of output without cone failure. The spruce pulp paper also provides a very good quality of sound. The cone is non-pressed and has a 2-layer poly coating which increases the cone rigidity and lowers distortion.
03
W W W . D U B S E R I E S . C O M
Woofer Features
2 inch Treated Foam
The 2 inch treated foam surround is resilient to temperature variations and provides the consistent support necessary for the linear motion of the speaker cone. In addition, the inherent damping capabilities eliminates the transmission of sonic disturbances between the cone and the frame of the speaker. This greatly improves the clarity of the speakers frequency response.
Flat Spider
The speakers linear compliance is balanced through the use of a flat spider design. A flat spider provides symmetrical control of the voice coil through it's cone excursion. Linear cone excursion reduces harmonic distortion for improved sound quality. This allows for reduced mechanical distortion for better sound quality.
Chrome Finish
Chrome has long been an industry standard in terms of durability in protective metal finishes. We have spared no expense in this area, and not only is it a protective finish, but it is also a great addition to any plexi style enclosure.
Convex Dust Cap
The use of a convex dust cap is used to increase the cone rigidity and improve power handling by forcing more air through the voice coil. Added benefits include smooth frequency response.
04
