Audex Telecom MT7000 Users Manual

MOTOR TREND

Bluetooth Headset User Guide

MX6 Noise Canceling Technology

ITEM # MT-7000

Index

1.Notice before Using

2.Package Contents

3.Functional Parts

4.Charging the Headset

5.Power On / Off

6.Pairing the Headset with a Bluetooth Device

7.Operation Guide

8.Low Battery Prompt

9.Specifications

10.Safety Instructions

11.Question and Answers

12.Declaration of Conformity

13.Limited Warranty

1.Notice before Using:

Thank you for purchasing the MOTOR TREND MT-7000 Bluetooth headset. Please check the contents of this package to verify the items listed in the package contents list below has been included in your package. Be sure and read this user guide before you use the headset.

Note:

Before using the headset for the first time, be sure and fully charge the unit at least 4 hours, preferably overnight (8-10 hours)

2.Package Contents:

MT-7000 Bluetooth Headset USB Cable Car Charger AC Charger Ear Cushions Manual

3.Functional Parts

1.Turn On / Off Switch

2.MFB Button

3.Volume +

4.Volume

5.Record

6.Play

7.USB Port

8.Mic

9.LED

10.Speaker

11.Head Band

4.Charging the Headset

The MT-7000 comes with a built in Lithium Polymer battery. To charge the unit: a)Plug the travel charger into an electrical outlet b)Plug the unit end of the travel charger into the power interface adaptor c)While charging, the LED Indicator Light will flash red then stay lit. If the battery level is high, the LED will be Blue.

Note:

·For first time use, make sure to fully charge the headset at least 4 hours, preferably overnight (8-10 hours)

·If headset has not been used for more than 21 days, when recharging it please charge the unit at least 4 hours, preferably overnight (8-10 hours) as the battery will need a full charge and be aware the LED Indicator light may take several hours to show recharging is complete.

·While charging the unit, do not use the headset

·Use original charger included with the headset to charge / recharge the unit

·When the LED indicator light flashes red during usage or while on standby, the battery is low and you should recharge the unit as soon as possible.

5.Power On / Off

Turn On

Switch the on/off Button to ON position, it will turn ON the headset and flash blue.

Turn Off

Switch the on/off Button to OFF position, it will turn OFF the headset and flash red 3 times.

NOTE:

·While turning on the headset, you will hear “Du Du” prompt from the receiver. The blue indicator light will flash 5 times, then 2 times, and after repeating this for 5 cycles the indicator light will flash the blue light every 3 seconds until the unit adjusts into standby mode.

·While the headset is turned on, it will automatically search for the paired device. Under the ON mode and within the effective range of 30 feet from the headset, the indicator will flash the blue light to indicate that it entered the connecting mode.

·When turning the headset off, you will hear “Du” sound, then the indicator will shut off after flashing the red light a few times.

6. Pairing the headset to your Bluetooth mobile device

In order to use this Bluetooth headset with your mobile device it must be paired and connected successfully. A)Insure that your mobile phone is Bluetooth Capable B)Make sure the headset is turned off and fully charged.

1.Now go ahead and switch the on/off Button to ON position.

2.Press and Hold Down the “MFB” Button (Multi Function Button) for 6 seconds until the indicator light flashes alternating “Red Blue Red Blue” to enter the pairing mode.

3.On your mobile device start the Bluetooth search function. Usually located in Settings> Bluetooth > Search or Add new Device. (Use your mobile device manufacturer's instructions to locate your Bluetooth options).

4.After searching the message MT-7000 will appear on your mobile device.

5.If necessary, enter pairing code “0000”

6.If pairing is successful, the LED indicator on the MT-7000 will flash Blue intermediately.

7.The headset is now paired to your Mobile device.

NOTE:

Once the mobile phone is paired with the headset, there is no further pairing action required. As long as the Bluetooth function on the mobile phone is activated and the headset is on, they will recognize each other and they will be automatically connected.

7.MT-7000 Operation Guide

Bluetooth Part Functions Off

On Off status Turn to On

Pairing

Voice Dial

Last number redial

Answer incoming calls Reject incoming calls End Calling Increase Volume Decrease Volume Switch the speach to Cellphone Switch the speech from Cellphone to Mt7000

Connect with Cellphone

Mute On

Status

Any status

Standby

Incoming call

Call status Short Press Call status Short Press Call status Short Press

Call status

Call status but the speech is on the cellphone On but doesn't connect with the

cellphone yet Call Status (but not in Mute status)

On/Off

MFB

Volume

Operation

Turn to Off

Long Press 6 Seconds Short Press Long Press 4 Seconds

Short Press

Long Press 4 Seconds

Long Press

Short Press

Long Press

Mute Off

Delete pairing lists Handup the current call and answer the reserved call

Reserve the current call and answer the reserved call

Recording Part

Functions

Record

Play

Delete the current Recording

Delete all of the Recording

Call and Mute Status Standby

Three parties service

Status

Call Status

Standby

Record

Key

Play Key

Operation

Short Press

Long Press

Keep Pressing

Long Press

Remarks

In standby status, it can't record any sound.

In Call status, it can't play any recording. While hear one "DE" then release the pressing While hear two "DE" then release the pressing

8.Low Battery Prompt

When the battery power gets low, the red LED will flash and there will be a short tone from the headset. If the battery power continues to decrease, the headset will switch off automatically.

9.Specifications:

Product Model No. Standard Conversion / Signal Output Frequency Band Talk / Standby Time Supporting Profile

Connection Data Encryption Power Capacity Power Supply Weight Safety Regulation

MT-7000 Bluetooth v2.1

2.4GHz 2.4835GHz,ISM Band Up to 8 hours / Up to 250 hours Headset & Handfree Peer to Peer 128 bits encrypted Rechargeable Li-Polymer 5V DC, 100~240V AC adapter

66.2g FCC , BQB

10.Safety Instructions

·If the headset LED indicator light is flashing red the battery is low and recharge the unit immediately

·If, after recharging for 20 minutes, the headset does not turn on: For initial use, the power will be on after charging the headset at least 40 minutes. The manufacturers recommended initial charging time is no less than 4 hours.

·If the headset does not show the recharging sign: The battery is completely depleted or the headset has not been used for 21 days, when charging the red LED indicator light will be lit after a few minutes.

·You hear no sound coming from the headset: a)Make sure the headset is turned on b)Make sure the headset has been paired with a Bluetooth enabled device c)Make sure the distance between the headset and the paired Bluetooth device is no more than 30 feet d)Make sure the mobile device has a strong signal as indicated by the mobile devices LCD screen icon. e)Some Bluetooth mobile phones support only one headset. In this case if you pair the MT-7000 with the device the other Bluetooth headsets may be deactivated. Likewise, if you pair other Bluetooth headsets with this type of mobile device, the MT-7000 headset may become deactivated.

11.Questions and Answers:

Q: Why does the fully charged headset under the ON mode not work with my Bluetooth device? A: You must activate the Bluetooth function of the mobile device and complete the device pairing process between the device and the headset.

Q: Can the MT-7000 work with any mobile device? A: No, Only Bluetooth enabled devices

Q: How far is the working distance between the headset and the mobile device?

A: The MT-7000 is certified by BQB, is compatible and compliant with Bluetooth

Please be aware, this distance may be affected by interference with the surroundings.

Q: Why does my Bluetooth mobile device find many Bluetooth devices while searching for the new Bluetooth headset? A: Most of today's mobile phones allow for more than one Bluetooth device within a given (working) range. When searching for a new device the mobile device or phones LCD should recognize and display the MT-7000 or some unknown device. Please select and confirm the MT-7000.

Q: Why can't my mobile device find the MT-7000? A: Check to make sure you are in pairing mode on the mobile device. If in this mode and still unable to locate the headset, please refer to your mobile devices manufacturer's instructions for additional information.

Q: Must I pair the headset every time I use it? A: No. The paired devices should remain paired regardless of turning the power off, reopening the devices or charging the respective devices batteries.

Q: Why is the voice from the headset not clear? A: Possibly for one or both of the following reasons:

1.Your location has insufficient signal. You must move to a better signal area or location.

2.The working range between the headset and the mobile phone has been exceeded. Please make sure the headset and mobile phone are within the working range of 30 feet and there are no obvious interfering factors between them.

Q: Why is the headset suddenly not working? A: (1) The headset battery may need recharging. When the battery is low, the headset flashes the red indicator light, please recharge it as soon as possible.

(2) The Bluetooth function of your mobile device or phone “crashes”. To renew this feature, turn off the Bluetooth function on the phone, turn it back on and repair it with the headset. You may need to perform this more than once to re-sync the device with the headset after this type of interruption.

Q: Why is the voice dialing function of the headset not switched on? A: (1) You may need to re-record the voice tag. (2) Some mobile devices and phones do not support the voice dialing feature. Please refer to your mobile devices manufacturer's instructions for additional information.

12.Declaration of Conformity

FCC: This device complies with part 15 of the FCC rules. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment . This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesiredOperation. CE: We, Premier Accessory Group, LLC. Declare under our sole responsibility that our product MT7000 and in combination with our accessories, to which this declaration relates, is in conformity with the appropriate standards, EN 301489,EN 300328, and EN 60950, following the provisions of Radio Equipment and Telecommunication Terminal Equipment directive 99/5/EC, with requirements covering EMC directive 89/336/EEC, and Low Voltage directive 73/23/EEC. ROHS: All Premier Accessory Group products are fully compliant with the ROHS Directive 2002/95/EC. WEEE: All Premier Accessory Group products are fully compliant with the WEEE Directive 2002/96/EC.

13.Limited Warranty

This warranty covers defects in material and workmanships of Premier Accessory Group, LLC and their respective product divisions MOTOR TREND line of Bluetooth products manufactured and sold by Premier Accessory Group which were purchased and used in the United States or Canada.

The warranty period is for 2 years from the date of purchase of the original product.

Obtaining Original Warranty Service

To return the Bluetooth Product(s) to Premier for warranty service, you must include:

-The original receipt or copy of the receipt for proof of purchase.

-The entire headset including any charger that came as original to the headset.

-If less than 7 days from purchase, please return the original packaging.

-Provide information regarding the nature of the problem and the reason for return.

-Provide your name, address and telephone number.

-When returning product for warranty service, if purchase was made within the last 90 days, no additional Shipping and Handling is due to manufacturer for replacement product.

-If product was purchased more than 90 days prior to return of product for Warranty Service, shipping and handling fee of 14.95 is due to manufacturer for replacement product.

-Manufacturer is not responsible for lost headsets if mailed via first class mail without insurance or delivery confirmation.

Return the product and Shipping and Handling Fee (when applicable) to the address below: Premier Accessory Group, LLC Attn: Customer Service Warranty (Toll Free 866-446-4327) 11-11 44th Drive Long Island City, N.Y. 11101

Legal Notice: This product is manufactured under license for Source Interlink Magazines, LLC, the publisher of MOTOR TREND Magazine and a Source Interlink Media company.

The Bluetooth word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc.
