Preface

Thank you for buying the “AQUOS PHONE SERIE SHL21” (simply called the “SHL21” or the “product” from here on). Before using the product, be sure to read the “Basic Manual” (this PDF manual) on the au homepage to ensure correct use. After you have finished reading this PDF manual, be sure to store it and the printed manuals (Accessories) in safe places so that you can retrieve them whenever you need them. If you lose the printed manuals (Accessories), contact an au shop or Customer Service Center.

Operating Instructions

■ “Basic Manual” (This PDF Manual)

This manual describes basic operations of major functions. For detailed descriptions of various functions, refer to the “Instruction Manual application” (Japanese) that can be used on the product or “Full Instruction Manual” (Japanese) on the au homepage:

(http://www.au.kddi.com/torisetsu/index.html)

■ “Instruction Manual Application”

(Japanese)

You can use the “Instruction Manual application” on the product to check detailed operational procedures. Also, you can activate intended functions from an explanation screen depending on the functions. On the home screen, tap [APPS] [[Instruction Manual].

• To use the application for the first time, you need to download and install it by following on-screen instructions.

■ Downloading Manuals

You can download the “Basic Manual” (this PDF manual) and the “Instruction Manual” (Accessory) (Japanese) or “Full Instruction Manual” (Japanese) in PDF format from the au homepage.

Safety Precautions

Before you start using the product, be sure to read the “Safety Precautions” to ensure correct use. Before you assume that the product is malfunctioning, check for possible remedies in the following au Customer Support site of au homepage:

(http://cs.kddi.com/support/komatta/kosho/

index.html)

Page 3

When Using the Product

• Communication is not possible even inside the service area in places where the signal does not reach (e.g. tunnels and basements). Also, communication may not be possible in poor reception areas. Communication may be interrupted if you move into a poor reception areas during communications.

• Since this product uses radio waves, the possibility of communication intercepts by third parties cannot be eliminated. (Though the LTE/CDMA/GSM/UMTS system has highly secure confidential communication features.)

• The product is compatible with the international roaming service. Each network service varies depending on the area and service content. For details, refer to “auのネットワークサービス・海外利用” (au Network Services/International Roaming) described in “Instruction Manual application” (Japanese) or “Full Instruction Manual” (Japanese).

• Since the product is a radio station under the Radio Law, you may be asked to temporarily submit the product for inspection in accordance with the Radio Law.

• The IMEI information of your cell phone is automatically sent to KDDI CORPORATION for maintenance and monitoring operational status of your cell phone.

• Since the battery is built into the product, you cannot replace it yourself. For replacing the battery, contact an au shop or Customer Service Center.

• Take care not to inconvenience people around you when you use the product in a public place.

• If you are using the product overseas, check the relevant laws and regulations of the country/region you visit.

• When the product is used by a child, parents or guardians should thoroughly read this PDF manual and teach the child how to use it.

Page 4

Cell Phone Etiquette

Cell phones always emit weak radio waves when power is on. Use cell phones in an enjoyable and safe manner without forgetting to be considerate of others around you.

■ Use of cell phones is not allowed in the

following places!

• Do not use a cell phone while driving a car or riding a motorbike or bicycle. It may cause a traffic accident. Use of a cell phone while driving a car or motorbike is prohibited by law. Use of a cell phone while riding a bicycle may be punishable by some regulations.

• Be sure to turn off the product while you are aboard an airplane. Otherwise, safety of your flight may be compromised.

■ Be considerate of where you use the cell

phone and how loudly you talk!

Do not make calls in theaters, museums, libraries, and other similar places. Turn the power off or turn on the manner mode so as not to disturb others around you by ringtones.

• Do not use the cell phone on a street where you might interrupt the flow of pedestrians.

• Move to areas where you will not inconvenience others on trains, in hotel lobbies, etc.

• Refrain from talking in a loud voice.

• Obtain the permission of other people before you take

their photos with the cell phone’s camera.

■ Be considerate of people around you!

• Some people close to you in crowded places such as packed trains may be using a cardiac pacemaker. Turn the cell phone off in such places.

• Abide by the rules of hospitals and other medical institutions where it is forbidden to use or carry cell phones.

List of Packaged Items

Before you start using the product, make sure that you have all the following packaged items with the product.

microSD memory card*

(2 GB) (Sample)

Card removal/insertion tool*

* This is inserted in the SHL21

SHL21

at the time of purchase.

Page 5

Warranty

(Japanese)

• Instruction Manual (Japanese)

• Setting Guide (Japanese)

• Before Using the Product (Japanese)

The following items are not included in the package.

• AC adapter

• Earphone

• microUSB cable

• Purchase a specified charger (sold separately).

• Illustrations of cell phones in this manual are only for

reference. They may look different from the actual product.

Desktop holder

(SHL21PUA)

Using au Disaster Countermeasure Application

au Disaster Countermeasure is an application in which you can use Disaster Message Board, Emergency Rapid Mail (Earthquake Early Warning, Disaster and Evacuation Information, and Tsunami Warning) and Disaster Voice Messaging Service.

A On the home screen, [APPS]

[[au災害対策] (au Disaster Countermeasure).

The au Disaster Countermeasure menu is displayed.

《au Disaster Countermeasure menu》

Page 6

■ Using Disaster Message Board

memo

Disaster Message Board is a service to enable customers in disaster areas to register their safety information via LTE NET when large-scale disasters, such as an earthquake whose Japan seismic scale is approximately 6-lower or more, occur. The registered safety information can be checked by customers using au phones, and also from other carriers’ cell phones, PCs, etc. For details, refer to “Disaster Message Board Service” on the au homepage.

A From the au Disaster Countermeasure

menu, [災害用伝言板] (Disaster Message Board).

Follow the on-screen instructions for registration/ confirmation.

◎ To register the safety information, an e-mail address

(~ezweb.ne.jp) is required. Set the mail address in advance.

◎ Deletion of the safety information and configurations for

Safety Notification Mail are not available during Wi-Fi® connection.

◎ The Company does not guarantee the quality of this service.

The Company, regardless of the cause, shall not be liable for any problems related to registration of safety information due to the concentration of access to this service or equipment errors, any loss due to the damage, ruination, etc. of safety information or any loss arising from registere d safety information.

■ Using Emergency Rapid Mail

Emergency Rapid Mail is a service to collectively deliver Earthquake Early Warning and Tsunami Warning provided by the Japan Meteorological Agency, and Disaster and Evacuation Information provided by the national government or the local governments to au phones in the specified areas. At the time of purchase, receiving setting of Emergency Rapid Mail (Earthquake Early Warning, and Disaster and Evacuation Information) is set to “受信する” (Receive). You can receive Tsunami Warning by setting 災害・避難情報 (Disaster and Evacuation Information). When receiving Earthquake Early Warning, secure your safety and act composedly according to the surrounding situations. When receiving Tsunami Warning, leave sea coasts immediately and evacuate to safe places such as hills and strongly-built tall buildings.

Page 7

A From the au Disaster Countermeasure

memo

menu, [緊急速報メール] (Emergency Rapid Mail).

The inbox is displayed. Select a mail to check to display the details of the mail.

削除

Delete received mails.

(Delete) 設定 (Settings)

緊急地震速報 (Earthquake Early Warning)

Set whether to receive Earthquake Early Warning.

• Tap [受信する] (Receive)/[受信しない] (Not receive) [[OK].

災害・避難情報 (Disaster and Evacuation Information)

Set whether to receive Disaster and Evacuation Information, and Tsunami Warning.

• Tap [受信する] (Receive)/[受信しない] (Not receive) [[OK].

音量 (Volume)

Set the volume of the receiving sound.

バイブ (Vibrator)

Set whether to activate the vibrator at the time of reception.

設定 (Settings)

マナー時の鳴動 (Linkage to the manner mode)

Set whether to notify you with the manner mode settings applied in the manner mode.

緊急地震速報 (Earthquake Early Warning)

Check the operations of the receiving sound and vibrator for Earthquake Early Warning.

災害・避難情報 (Disaster and Evacuation Information)

Check the operations of the receiving sound and vibrator for Disaster and Evacuation Information, and Tsunami Warning.

◎ This service is available only in Japan (Not available

overseas).

◎ Emergency Rapid Mail is free of both information charges

and communication charges.

◎ Emergency Rapid Mail cannot be received while the power

is turned off or during a call.

◎ Emergency Rapid Mail may not be received during

communication such as while sending and receiving SMSs/ e-mails and while using the browser or when you are in a place where the signal cannot be received (e.g. tunnels and basements) or the signal is weak, even within the service area.

Page 8

◎ Emergency Rapid Mail which failed to be received will not

be able to be received again.

◎ When you receive Emergency Rapid Mail, the dedicated

alarm tone rings. The alarm tone cannot be changed.

◎ Information intended for the areas of other than your present

location may be received.

◎ As for this service, the Company shall not be liable for any

damage incurred on the users resulted from failure or delay of information delivery due to commun ication disturbance or system failure, contents of the information or other problems that are not supposed to be blamed on the Company.

◎ For details on Earthquake Early Warning and Tsunami

Warning provided by the Japan Meteorological Agency, refer to the agency’s homepage.

(http://www.jma.go.jp/)

Earthquake Early Warning

◎ Earthquake Early Warning notifies areas where a strong

shaking (Japan seismic scale 4 or more) is expected when an earthquake whose maximum Japan seismic scale is predicted of 5-lower or more has been detected.

◎ This service detects an earthquake (P-wave, preliminary

tremors) near the seismic center immediately after the earthquake occurs and automatically calculates its location, scale and predicted strength of the shaking. After that, you will be notified of the earthquake as soon as possible within a few seconds to dozens of seconds before a strong shaking from the earthquake (S-wave, principal shock) occurs.

◎ In the vicinity of the seismic center, a strong shaking may

reach you before Earthquake Early Warning.

◎ The Earthquake Early Warning distribution system provided

by this service is different from that provided by TV, radio and other communication media and thus the arriving time of Earthquake Early Warning may be different among those media.

Tsunami Warning

◎ Tsunami Warning notifies areas including target sea coasts

of Tsunami Warning (major tsunami and tsunami) provided by the Japan Meteorological Agency.

Disaster and Evacuation Information

◎ Disaster and Evacuation Information notifies information

related to the safety of citizens, such as evacuation advisories, evacuation orders or various alarms delivered by the national government or the local governments.

■ Using Disaster Voice Messaging Service

Disaster Voice Messaging Service is a service to record voices with a smartphone and deliver them as a voice message to people to whom you want to deliver the information that you are safe when large-scale disasters occur.

A From the au Disaster Countermeasure

menu, [災害用音声お届けサービス] (Disaster Voice Messaging Service).

Page 9

■ Sending voices (Send)

memo

Tap “声をお届け” (Send voices) and operate in order of “①お届け先を選択届けしたい声を録音” (Record voices to send).

* You can al so select to whom to send your voices from the addr ess book.

” (Select to whom to send) [“②お

■ Receiving voices (Receive)

You will be notified via a pop-up screen or an SMS that a voice message has been received. You can listen to the message by receiving (downloading) and playing the voice message.

• If the receivers are using a smartphone on which an au Disaster Countermeasure application supporting Disaster Voice Messaging Service is not enabled or using an au cell phone, they will be notified via an SMS.

• If the receivers are notified via an SMS, the information will not be saved in the au Disaster Countermeasure application.

◎ Sending and receiving voice messages are available only

when you are using LTE/3G network. Disable wireless LAN (Wi-Fi®) communication etc. before use.

◎ Voice messages can be recorded for up to 30 seconds. ◎ Voice messages can be exchanged only among au cell

phones (interoperation with other carriers’ cell phones will be available from the spring of 2013).

◎ Voices may not be heard when the media sound volume is

set to low or the manner mode is set.

◎ When no free space is left on the main unit (memory) , voice

messages may not be saved or played.

◎ Some cell phones cannot receive voice messages. For

details, refer to the au homepage.

Page 10
