Page 1

Basic Manual

Contents

Getting Ready

Basic Operation

au Disaster Countermeasure

Safety Precautions

Appendix

Page 2

Preface

Thank you for buying the "miraie" (simply called the "product" or "main unit" from here on). Before using the product, be sure to read the "Basic Manual" (this manual) to ensure correct use. After you have finished reading this PDF and the printed manuals, be sure to store them in safe places so that you can retrieve them whenever needed. If you lose the printed manuals (Accessories), contact an au shop or the Customer Service Center.

About Operating Instructions

"Basic Manual" (This manual)

Handles only basic operations for main features. For detailed descriptions on various functions, refer to the "Instruction Manual" app installed on the product or "取扱説明書詳細版 (Full Instruction Manual)" (Japanese) available on the au homepage.

　（http://www.au.kddi.com/support/mobile/guide/

manual/）

•Company names and product names referred to in this manual are trademarks or registered trademarks of respective companies.

"Instruction Manual" App (Japanese Only)

You can use the "Instruction Manual" app on the product to confirm detailed operational procedures.

From the Home screen, [Apps]  [Basic Manual]

•When you activate for the first time, follow the onscreen instructions to download and install app.

Downloading Manuals

You can download the "Basic Manual" (this PDF manual), the "取扱説明書 (Instruction Manual)" (Accessory) (Japanese) and "取扱説明書詳細版 (Full Instruction Manual)" (Japanese) in PDF format from the au homepage.

Download URL:

　（http://www.au.kddi.com/support/mobile/guide/

manual/）

Page 3

Safety Precautions

Before you start using the product, make sure to read the "Safety Precautions" to ensure correct use. Before you assume that the product is malfunctioning, check for possible remedies in the following au Customer Support site of au homepage:

　（http://www.au.kddi.com/english/support/）

When using the product

•Communication is not possible even inside the service area in places where the signal does not reach (e.g. tunnels and basements). Also, communication is sometimes not possible in poor reception areas. Communication is sometimes interrupted if you move into a poor reception areas during communications.

•Since this product uses radio waves, the possibility of communication intercepts by third parties cannot be eliminated. (Though LTE/CDMA system has highly secure confidential communication features.)

•This Product is designed for use in Japan only and cannot be used in any other country.

•Since this product is a radio station under the Radio Law, you may be asked to temporarily submit the product for inspection in accordance with the Radio Law.

•IMEI information of your cell phone is automatically sent to KDDI CORPORATION for maintenance and monitoring operational status of your cell phone.

•Take care not to inconvenience people around you when you use the product in a public place.

•When the product is used by a child, parents or guardians should thoroughly read the "Basic Manual" (this manual) and teach the child how to use it.

Page 4

Cell Phone Etiquette

Use of the product is not allowed in the following places!

•Do not use a cell phone while driving a car or riding a motorbike or bicycle. It might cause a traffic accident. Use of a cell phone while driving a car or motorbike is prohibited by law. Use of a cell phone while riding a bicycle may be punishable by some regulations.

•Use of cell phones on board is restricted. Follow the instructions of each airline.

Pay attention to the place of use and volume of your voice!

•To prevent ringtone from bothering other people, not only refrain from making a call but also power off or use Silent mode at a movie theater, theater, museum, library, etc.

•In a city area, use in a place where you do not bother people walking.

•It is extremely dangerous to walk while looking at the screen of the cell phone. Do not make calls or operate a cell phone while walking or by stopping suddenly.

•Move to a place where you do not disturb others while you are in shinkansen, a hotel lobby, etc.

•Be careful not to be loud while talking.

•Ask permission if you take photos with your cell phone camera.

Consider people around you!

•There may be a person with a cardiac pacemaker nearby at a place filled with people such as in a crowded train. Set "Airplane mode" or turn off beforehand.

•When a medical institution has laid down designated areas where use of the product is prohibited or is not allowed to be brought in, abide by the instructions of that medical institution.

Page 5

List of Packaged Items

Before your start using the product, make sure that you have all the following packaged with the product.

Battery pack

(KYL23UAA)

◎ Purchase the specified charging equipment (sold

separately).

◎ The illustrations of cell phone in the manual are used only

for explaining. They may differ from the actual product.

Main unit

Back cover

(KYL23TPA/

KYL23TWA/KYL23TLA)

* Installed on back of main unit

•取扱説明書（ご家族用） (Instruction Manual (Family)) (Japanese)

•かんたん操作ガイド（お子様用） (Quick Operation Guide (Child)) (Japanese)

•本体保証書 (Warranty for the main unit) (Japanese)

The following items are not included in the package.

•microSD memory card

•AC adapter

•microUSB cable

•Earphones

Page 6

Regarding notations used in this document

Note on key illustrations

In this manual, keys are represented by simplified illustrations as shown below.

Description of Operations for Selecting Item/Icon/Key etc.

The notations used for operation procedures in this manual are as follows. Tap onscreen keys and icons to select them by touching them lightly (▶P. 41).

Description Explanation

On the Home screen → [Phone] → [1][4] [1] → [Call]

In sleep mode,

Tap "

(Phone)" at the bottom of the Home screen. And tap " ", " ", " ", then tap "Outgoing call" at the end.

In sleep mode, press F.

Page 7

Notes on illustrations/Screenshots

Screen illustrations shown in this manual may look different from the actual screens. In some cases, minor details or a part of a screen may be omitted.

In this manual, some icons on a screen are omitted.

Actual screen

Notations used in

this manual

◎ Operations from the vertical display are mainly described.

Menu items/icons/keys on a screen may be different from the ones in the horizontal display.

◎ Menu items/layers/icons may be different depending on

functions, conditions, etc.

◎ In this manual, screenshots for body color "meteor blue" are

provided as examples.

◎ In this manual, "microSD™ memory card" and

"microSDHC™ memory card" are abbreviated as "microSD memory card" or "microSD".

◎ All of the indicated amounts exclude tax unless otherwise

specified.

Page 8

Preface .......................................................................ii

About Operating Instructions .....................................ii

Safety Precautions ..................................................... 1

When using the product ............................................ 1

Cell Phone Etiquette .................................................. 2

Contents

List of Packaged Items .............................................. 3

Regarding notations used in this document.............. 4

Contents ..................................................6

Getting Ready ..........................................8

Names and functions of parts ................................... 8

Attaching/Removing the battery pack ..................... 13

au Micro IC Card (LTE) ............................................ 15

Attaching/Removing microSD memory card ........... 17

Charging .................................................................. 19

Turning the power on/off .......................................... 21

Preparing the product for the child ......................... 22

Setting an au ID ....................................................... 26

Parental settings menu ............................................ 27

Basic Operation ....................................41

Using the touch panel ............................................. 41

Switching character entry ........................................ 41

Using Home screen ................................................. 42

Using the Apps list .................................................. 42

Monitoring the product's status ............................... 46

Setting Airplane mode ............................................. 48

Setting Silent mode ................................................. 48

Making a call ........................................................... 49

Registering a contact to Contacts and making a call

Receiving a call ....................................................... 50

Checking your own phone number (Profile) ............ 50

E-mail ....................................................................... 51

Backing up & restoring e-mail ................................. 52

Using Eco Mode ...................................................... 53

Displaying menu ...................................................... 53

Wireless LAN (Wi-Fi®) function ................................ 53

Tethering .................................................................. 54

Capturing photos and video .................................... 55

Viewing files with the photo library .......................... 55

... 50

au Disaster Countermeasure ...............56

Using Disaster Message Board............................... 56

Using Emergency Rapid Mail .................................. 57

Using Disaster Voice Messaging Service ............... 59

Using Disaster information ...................................... 59

Page 9

Safety Precautions ................................60

Exemptions .............................................................. 60

Safety Precautions (Observe Strictly) ...................... 61

Handling precautions .............................................. 75

Notes on water, dust, and shock resistance ........... 84

Notes on using Bluetooth®/Wireless LAN (Wi-Fi®)

function .................................................................... 92

Notes on packet communication charge ................ 94

Notes on applications .............................................. 94

Appendix ................................................95

Introduction of related accessories ......................... 95

How do I . . .? Q&A .................................................. 96

Updating Software or OS....................................... 100

After-sales service ................................................. 102

Main specifications ................................................ 105

Specific Absorption Rate of Cell Phone ................ 108

Intellectual property rights ..................................... 110

OpenSSL License .................................................. 113

Contents

Page 10

Getting Ready

②

⑬ ⑭

⑨ ⑩ ⑪ ⑫

⑮

Names and functions of parts

③

⑤ ⑥ ⑦ ⑧

④

⑯ ⑰

⑱

㉑

⑳

㉒

㉔

㉓

㉕

Getting Ready

①

②

⑬ ⑭

⑨ ⑩ ⑪ ⑫

⑲

󰴤 d Volume UP/DOWN key

Adjusts sound volume. Press and hold l (Volume

⑮

DOWN key) to set "Silent mode" (▶P. 48).

󰴥 Strap eyelet 󰴦 Earphone microphone terminal 󰴧 F Power key

Power ON/OFF, activate/deactivate Sleep mode, etc.

Page 11

󰴨 Proximity sensor/Light sensor

The proximity sensor turns the screen off and prevents

erroneous touch panel operation.

Light sensor detects the ambient light level to adjust the

display brightness.

󰴩 Incoming (Charging) light

Lights in red while charging. Blinks according to the settings for incoming call/mail.

󰴪 Receiver

With Smart sonic receiver (▶P. 10), hear the other party's

voice on call, play sound of answer memo, etc.

󰴫 In camera (lens) 󰴬

Display (touch panel)

󰴭 C Back key

Return to the previous screen.

󰴮 H Home key

Used for displaying the Home screen.

󰴯 N Recent apps key

Display the recently-used apps.

󰴰 External connection terminal

Used for connecting Common AC Adapter 05 (sold

separately), microUSB cable 01 (sold separately), etc.

󰴱 Microphone

Transmits your voice to the other party during a call. Or

used for recording the voice sound. Take car

e not to cover the microphone with your fingers during a call or recording a video.

󰴲 z Personal alarm

Press and hold z for at least 2 seconds to cause the

product to vibrate and display the personal alarm standby screen. Press z again to operate the personal alarm (▶P. 11).

󰴳 Speaker

Ringtone or alarm sound can be heard from here.

󰴴 Built-in sub antenna 󰴵 Built-in Bluetooth®/Wi-Fi® antenna 󰴶 Built-in main antenna

󰴷 Photo light/Simple light/Personal alarm flash 󰼼 Out camera (lens) 󰽇 Built-in GPS antenna

󰽈 Back cover

Remove the back cover and then the battery pack to

access the au Micro IC Card (LTE) and microSD memory card slots.

󰽉 microSD memory card slot 󰽊 au Micro IC Card (LTE) slot

* Do not cover antennas with your hand or put stickers etc. It might affect

communication quality.

◎ Do not adhere stickers, etc. on the proximity sensor/light

sensor.

Getting Ready

Page 12

About Smart sonic receiver

The product is equipped with Smart Sonic Receiver, which transmits sound by vibrating the display. Although there is not receiver hole, you can use as usual.

Touching to your ear

Touch receiver part of the product to your ear as shown below. By covering your ear to shut out surrounding noise, voice sound will be heard more easily. Move position of the product up/down/left/right to adjust according to your hearing condition or an immediate environment.

Getting Ready

Receiver

Microphone

◎ Take care not to cover the microphone with your fingers

during a call.

◎ When the earphones (sold separately) are connected, voice

sound can be switched to the one via earphones not using Smart sonic receiver.

◎ Do not put stickers, etc. on the display. May make receiver

sound to be heard hard.

◎ There may be differences in the hearing easiness among

individuals.

◎ Depending on environment, the hearing effect differs.

Page 13

Personal alarm

The product can be used as a personal alarm. When the personal alarm is activated, it can automatically report the current location, take and then send photos with the cameras, and immediately allow a phone call to be made.

Sounding the personal alarm

z (press and hold for at least 2 seconds)

The product vibrates and the personal alarm standby screen is displayed.

While the screen is displayed, [Start] or z

again

The personal alarm is activated, and an alarm screen is displayed.

•A buzzer sounds at high volume. Do not hold the product close to ears.

•The product returns to normal after 10 seconds.

Operation while the personal alarm is activated

Once the personal alarm is activated, the personal alarm flash flashes, and 5 seconds after* the alarm is first activated, the product automatically takes 4 photos with the out camera and 1 photo with the in camera.

* If a call is made while the cameras are counting down, photos are taken

after the call is ended.

The location and taken images are then sent to the emergency contacts that are registered. After mail is sent, the personal alarm flash begins flashing again.

To disable the personal alarm flash and sending of images, refer to "Setting the personal alarm" (▶P.

29).

Making a call while the personal alarm is activated

A call can be immediately made while the personal alarm is activated to emergency contacts that have been preregistered. For details on registering emergency contacts, refer to "Adding or editing emergency contacts" (▶P. 28). While "Automatic calling" (▶P. 29) is enabled, the product automatically dials the emergency contacts that are registered in order at the same time that the personal alarm is activated.

To call a parent or guardian

[Phone to a protector]

A call is made to the contact that is registered as emergency contact 1.

To select an emergency contact and make a call

[Emergency list]

Tap " " next to the contact to call

•A contact can be selected from emergency contact 1/2/3*, 110 (Police), 119 (Fire/Ambulance), and 118 (Maritime rescue) and called.

* Not displayed if phone numbers are not registered as emergency

contacts.

Getting Ready

Page 14

Stopping the personal alarm

While the personal alarm is activated, z

(press and hold for at least 3 seconds)

◎ If there is no operation for 10 seconds after the personal

alarm standby screen is activated, the personal alarm stops.

◎ The personal alarm discontinues sounding while a call is

being made. Once a call is ended, the buzzer sounds again; immediately hold the product away from ears.

Getting Ready

◎ While the alarm screen is displayed, F, C, N, and

cannot be operated.

◎ Caution: If the power is not turned on, the personal alarm

cannot be activated.

◎ Caution: The personal alarm will activate in the following

situations, however, voice calls and mail notification cannot be made to emergency contacts.

•When no UIM card is installed

•When out of service ar

Product operation when the personal alarm is operated

◎ Depending on the personal alarm settings, some product

function settings automatically change when the personal alarm is activated. Settings do not return to as before; make settings again as required.

•When Airplane mode is "ON": Airplane mode switches to "OFF".

•When "Location information" is on: "Location" and "Data enabled" switch on, and "Set data connection limit" switches off.

•When "Photos" (▶P. 29) is on: "Data enabled" switches on, and "Set data connection limit" switches off.

◎ The personal alarm cannot be activated in the following

situations.

•During a software update

•While "Lookout for au" is locked

•While the screen is displayed for entering the PUK code

Page 15

Attaching/Removing the battery pack

Use a dedicated battery pack and attach it properly.

◎ Before attaching/removing the battery pack and back

cover, always turn the power off.

Attaching the battery pack

Remove the back cover of the back side of

the product

Lift the back cover by the notch at the bottom of the main unit in the direction shown to remove.

Back cover

Notch

After locating the battery pack contacts, slide

the battery pack in direction ① while pressing firmly in direction ② to match the battery pack with the tabs on the main unit

Tabs

Battery pack

②

①

Contacts

Getting Ready

Page 16

Attach the back cover on the main unit, then

press along the back cover in the direction from ① to ② following the arrows leaving no gaps, and then press at ③ firmly

①

Getting Ready

③

Removing the battery pack

Remove the back cover of the back side of

the product (▶P. 13)

Pressing from the notch on the main unit,

press the battery pack in direction ① while lifting in direction ②

Battery pack

②

①

Notch

◎ Be sure to check the au Micro IC Card (LTE) is certainly

attached and then attach the battery pack.

◎ Attaching the back cover incorrectly might damage the

battery pack or back cover or allow intrusion of liquid.

Attach the back cover (▶P. 14)

Page 17

au Micro IC Card (LTE)

The au Micro IC Card (LTE) contains customer phone number and other information. The product is compatible with au Micro IC Card (LTE) only. You cannot use the product with an IC card other than au Micro IC Card (LTE).

◎ Do not insert the IC card held in a card adapter. Doing so

may cause malfunction.

◎ Note the following while handling the au Micro IC Card

(LTE). Otherwise, handling may cause malfunction or damage of the card or product.

•Do not touch the IC (metal) part of the au Micro IC Card (LTE) or the IC card terminal inside the product.

•Insert in the correct direction.

•Do not use force to attach or remove.

◎ Before removing the au Micro IC Car

remove the microUSB plug of a specified AC adapter, etc. from the product.

◎ Be sure to turn off the product before installing/removing

the au Micro IC Card (LTE).

au Micro IC Card (LTE)

IC (metal) part

d (LTE), be sure to

◎ An error message is displayed for an improperly installed or

abnormal au Micro IC Card (LTE).

◎ Do not lose the au Micro IC Card (LTE) after it has been

removed.

If the au Micro IC Card (LTE) is not inserted

The product cannot be used with any card other than the au Micro IC Card (LTE) inserted. If the product is turned on without the au Micro IC Card (LTE) inserted, the following operations*1 are not possible. " " is also displayed in the status bar.

•Making*2/accepting a call

•Sending/receiving SMS

•Making initial settings for and sending/receiving e-mail (@ezweb.ne.jp)

•UIM card lock settings

•Checking the product's phone number and e-mail address

*1 In addition to the above operations, functions requiring customer phone

number, etc. may also be unavailable.

*2 Emergency calls also cannot be made to 110 (Police), 119 (Fire/

Ambulance), or 118 (Maritime rescue).

Restricting product use with a PIN code

Your au Micro IC Card (LTE) contains valuable personal information. To protect this information, you can change the PIN code and lock the UIM card to restrict use by other persons (▶P. 82 "PIN code").

Getting Ready

Page 18

Attaching au Micro IC Card (LTE)

Before installing the au Micro IC Card (LTE), turn the product off and remove the battery pack.

Turn the power off and remove the back cover

and battery pack (▶P. 14)

Confirm the orientation for inserting the au

Micro IC Card (LTE) and insert gently all the way in without bending

Check the orientation of the notch.

•Correctly locate the bottom slot for the au Micro IC

Getting Ready

Card (LTE).

microSD memory card slot (upper)

au Micro IC Card (LTE) slot (lower)

Notch

Attach the battery pack/back cover (▶P. 13)

Removing au Micro IC Card (LTE)

Before removing the au Micro IC Card (LTE), turn off the product and remove the battery pack.

Turn the power off and remove the back cover

and battery pack (▶P. 14)

Slowly remove the microSD memory card

Slowly pull the microSD memory card straight out.

Attach the battery pack/back cover (▶P. 13)

Page 19

Attaching/Removing microSD memory card

Attaching microSD memory card

Turn off the product and remove the back

cover and battery pack (▶P. 14)

Confirm the direction of the microSD memory

card and slowly insert it all the way in its slot without bending

Insert with the metal contact side downward.

•Insert in the correct (upper) slot.

microSDmemorycard slot(upper)

auMicroICCard(LTE) slot(lower)

Install the battery pack and back cover

(▶P. 13)

◎ Insert a microSD memory card with the right side up in the

appropriate direction. Inserting a microSD memory card forcefully into the slot could result in failure to remove the microSD memory card or damage to the microSD memory card.

Getting Ready

Page 20

Removing microSD memory card

Home screen → [Settings] → [Parental

settings] → Enter parental password → [OK]

[Other settings] → [Storage] → [Unmount SD

card] → [OK]

Turn off the product and remove the back

cover and battery pack (▶P. 14)

Getting Ready

Slowly remove the microSD memory card

Slowly pull the microSD memory card straight out.

Install the battery pack and back cover

(▶P. 13)

◎ Do not touch the terminal part of microSD memory card. ◎ Do not remove the microSD memory card forcefully. It may

result in damage to the microSD memory card or the data loss.

◎ The microSD memory card may be warm after a long time

use. It is normal.

◎ When removing the microSD memory card, be sure to

unmount it to prevent data from loss (deletion).

Page 21

Charging

When you purchase your product, the battery pack is not fully charged. Make sure to charge the battery pack before use. When the charging light in red turns off, charging is complete.

◎ The product may become warm while charging, depending

on the situation, but this is not abnormal.

◎ Charging while using camera etc. may take longer. ◎ For handling the battery pack, thoroughly read "Safety

Precautions" (▶P. 61) for proper use.

◎ Turning on the flashlight while charging causes charging to

stop. Turning off the flashlight allows charging to start again.

◎ When you operate the product with the specified charger

connected, the product may repeat short-time charging/ discharging r

◎ When temperature of environment or the product becomes

extremely high or low, charging may be stopped. Try to charge the battery as far as possible at room temperature.

◎ If the charging light blinks in red, check if the battery pack

is correctly attached or connected. Even if the light keeps blinking, stop charging and then contact an au shop or Keitai Guarantee Service Center.

◎ If charging is stopped while the charging light is still turned

on, the battery may not be fully charged even with " (Full) displayed. In that case, available time will be short.

esulting in short battery life.

◎ Do not allow conductive foreign objects (metal fragments,

pencil leads, etc.) to come into contact with or get inside the connection terminals.

Charging with specified AC Adapter (sold separately)/DC Adapter (sold separately)

Charging with Common AC Adapter 05 (sold separately)/ Common DC Adapter 03 (sold separately) is explained. For information on the specified Common AC Adapter (sold separately)/Common DC Adapter (sold separately), see "Introduction of related accessories" (▶P. 95).

Getting Ready

Page 22

Check the orientation of the microUSB plug

of Common AC Adapter 05 (sold separately)/ Common DC Adapter 03 (sold separately) and insert it straight into the external connection terminal

With the projection

facing down

Getting Ready

Common AC Adapter 05 (sold separately)/ Common DC Adapter 03 (sold separately)

Insert the power plug of Common AC Adapter

05 (sold separately) into an outlet (100 VAC to 240 VAC)/Insert the plug of Common DC Adapter 03 (sold separately) into a cigarette lighter socket

Check that the charging light on the product lights in red. When the battery power turns on, " " appears on the status bar. When charging ends, the charging light turns off.

Common AC Adapter 05 (sold separately)

When charging ends, pull out the microUSB

Common DC Adapter 03 (sold separately)

plug of Common AC Adapter 05 (sold separately)/Common DC Adapter 03 (sold separately) straight from the external connection terminal

Pull out the power plug of Common AC

Adapter 05 (sold separately) from the outlet/ Pull out the plug of Common DC Adapter 03 (sold separately) from the cigarette lighter socket

◎ Note that applying unnecessary force with the external

connection terminal connected to the external device might cause damage.

◎ When charging starts with the battery empty, the charging

light may not light immediately. But charging has started.

Page 23

Turning the power on/off

Turning the power on

F (press and hold for at least 2 seconds)

When the start screen appears, disable security.

•The first time the power is turned on, initial settings open. Make settings referring to "Preparing the product for the child" (▶P. 22).

◎ While logos are displayed after the power is on, initial

settings for touch panel are in process. Do not touch the screen. The touch panel may not work properly.

Turning the power off

F (press and hold for at least 1 second)

[Power off] → [OK]

Forcing shutdown and restarting

Force shutdown and restart the product when the screen freezes or the power cannot be turned off.

F (press and hold for at least 10 seconds)

◎ If the product is forced shutdown and restarted, unsaved

data will be erased. Do not force shutdown except when the product becomes inoperative.

Switching to English display

Home screen → [設定 (Settings)] → [保護者設

定 (Parental settings)] → Enter the parental password → [OK] → [その他の設定 (Other settings)] → [言語と入力 (Language & input)] → [言語 (Language)] → [English] → [OK]

Getting Ready

Page 24

Preparing the product for the child

After purchasing the product and turning it on for the first time, follow the onscreen instructions to make initial settings so the child can use the product safely. During initial settings, a communication test, registration of parental information (phone number, e-mail, password), setting of emergency contacts, setting of restrictions, registration of an au ID, and application usage settings can be made.

Getting Ready

Parental password

A parental password is used when making parental settings or when temporarily canceling restrictions on Contacts and applications. Setting a password prevents anyone other than a parent or guardian from changing settings.

Emergency contacts

au ID By setting an au ID, you can use various

Up to 3 contacts can be registered as emergency contacts. Emergency contact 1 cannot be left unregistered. As these are contacts for emergencies, you should register phone numbers and e-mail addresses that you are sure contact can be made with. When the personal alarm is activated, the location and taken images are automatically sent to the emergency contacts. Also, if the parental password is forgotten, a cancelation password is sent to emergency contact 1.

services provided by au such as "auかんたん決済 (au Simple Payment Service)" which allows you to purchase applications available with auスマートパス (au Smart Pass).

Page 25

STEP1: Call service settings

The operation screens (or call service settings screens) in

to 4 may not be displayed.

[開通試験 (Communication test)]

A call is automatically made to 111, and a communication confirmation message is played.

[通話終了 (Call end)]

[割込通話の停止 (Stop 3rd-party caller

priority)]/[留守番電話の停止 (Stop voicemail)]/ [ボイスメールの停止 (Stop au direct voicemail)] → [通話終了 (Call end)]

Follow the guidance instructions to make settings.

Once settings are made, [次へ (Next)]

Proceed to settings for parental information.

STEP2: Setting parental information

When you activate for the first time, the display is shown in Japanese. To display in English, first switch to English and then activate "Initial settings" in "Parental settings" (▶P. 27). To switch to English display, refer to "Switching to English display" (▶P. 21).

Registering emergency contacts

•The phone number and e-mail address of the parent or guardian are registered as emergency contact 1.

•Be sure to correctly enter the domain after the "@" mark for the e-mail address.

Set the parental password → [次へ (Next)]

Enter any letters and numbers, from 4 to 17 characters in length (twice).

Getting Ready

Page 26

[au IDを設定する (Register "au ID")] → [au ID

の設定・保存 (Set/save au ID)]

Authentication starts. An au ID cannot be registered that is the same as another user's. An au ID can still be set later if this operation is skipped. To set an au ID later, tap [Apps] → "au ID Setting" (▶P. 26).

Getting Ready

Follow the onscreen instructions to set an au

ID → [次へ (Next)]

If you already have an au ID, set that au ID. If you do not already have an au ID, set a new au ID here. Follow onscreen instructions.

Tap and confirm the "利用規約 (Terms of

use)" for each application → [OK] → Tap " " for "同意する (Agree)" → [次へ (Next)] → [OK]

Presettings for "Lookout for au" are complete.

Page 27

Check the setting for "子どもが使える機能を

制限 (Restrict functions for children)" → [次へ (Next)]

Tap "個別設定 (Edit)" to change settings for each function. For details on making settings, refer to "Restricting functions that children can use" (▶P. 30).

•Recommended settings are set by default. To use settings that were changed on a previous product, select "変更した値を設定 (Use changed settings)" in the confirmation screen. To return the settings to their defaults, select "推奨値を設定 (Set the recommended value)".

* If "次へ (NEXT)" is tapped in the "個別設定 (Edit)" screen, a

confirmation screen is not displayed, and changed settings are applied.

Recommended settings (initial value)

電話・メールができる人を制限

(Restrict call/mail) アプリを制限 (Restrict apps)

利用を制限する時間帯 (Restricted

period for use)

1日の利用時間 (Available time per day)

通話時間 (Available call time)

有害サイトへのアクセスを制限

(Restrict access to website)

不適切なワードの入力を検知

(Detect unsuitable words)

制限開始 (Restriction Start) : 21:00 制限終了 (Restriction End) : 06:00 繰り返し (Repeat) : 毎日 (Everyday)

利用時間 (Available time) : 2時間00 分 (2 h 00 min) 繰り返し (Repeat) : 毎日 (Everyday)

ON 1日の通話時間 (Call time per day) : 10分 (10 min) 1ヶ月の通話時間 (Call time per month) : 5時間 (5 hours) レベル (Level) : 小学生

•No OFF setting is available.

Getting Ready

(school child)

Page 28

Tap and confirm the "利用規約 (Terms of

use)" for "防犯ブザーの設定 (Personal alarm)" → [OK] → Tap " " for "利用規約に同意する (Agree)" → [次へ (Next)] → [OK]

•Tapping "利用規約に同意しない (Disagree)" prevents "位置情報の通知 (Send location information)" and "画像の送信 (Send photos)" from activating at the same time as when the personal alarm is activated.

•If agreement is displayed for location information, follow the onscreen instructions. To increase the

Getting Ready

accuracy of location information when using the personal alarm, use of IZat is recommended. Location information is sometimes obtained even when the application is not activated.

[完了 (Complete)]

◎ To change parental information settings, from the Home

screen, [Settings] → [Parental settings] → Enter the parental password → [OK] → [Initial settings] and change settings.

◎ After making initial settings, be sure to complete e-mail

application settings (▶P. 51). E-mail from the personal alarm will not be sent.

Setting an au ID

Home screen → [Apps] → [au ID Setting]

[au IDの設定・保存 (Set/save au ID)] → Enter

PIN → [OK]

Enter password → [設定 (Set)]

The au ID is set.

Page 29

Parental settings menu

The product features a parental settings menu for a parent or guardian to make settings. A parent or guardian should register information and make settings before handing the product to a child.

Displaying the parental settings menu

Settings and restrictions for use by parents or guardians can be made from the parental settings menu. To access the menu, the parental password set when initial settings were made is required.

Home screen → [Settings] → [Parental

settings]

A screen for entering the parental password is displayed.

Enter the password → [OK]

The parental settings menu is displayed.

Parental settings menu

Option Setting Page Change parental password Add/edit emergency contacts

Change parental password. P. 28

Add or edit emergency contacts.

P. 28

Personal alarm settings

Restrict functions for children

Texting While Walking Alert

E-mail privacy setting Profile Edit the child's profile. P. 38 Auto answering, incoming reject, additional settings Software update Update to the latest software. P. 100 Factory data reset Initial settings Launch an initial settings

Other settings Display other setting options. －

Set product operation when the personal alarm is activated. Restrict use of Contacts, e-mail, applications, and length of time the product can be used. Make settings for preventing use of the product while walking. Make e-mail privacy settings. P. 37

Set voice services, etc. P.

Return the product to its default settings.

wizard to change parental information and other initial settings.

P. 29

P. 30

P. 36

P. 22

－

Getting Ready

Page 30

Authenticating with the parental password

To allow a child to use not-as-yet approved "pending" Contacts entries or applications, the parental password can be entered to cancel restrictions.

◎ Enter letters and numbers, from 4 to 17 characters in

length, for the parental password. Both letters and numbers must be used.

◎ Entering an incorrect parental password three times causes

a temporary cancelation password to be sent to the e-mail address registered for the first emergency contact.

Getting Ready

◎ In the following instances, the product reverts to its

unauthenticated state.

•Returning to the Home screen

•The display turns off

•A call arrives

•A set alarm sounds

•An application is activated fr notification panel

If the product reverts to its unauthenticated state while a parent or guardian is making settings, the product returns to the screen before the product is authenticated. Enter the parental password to resume making settings.

om the recent apps or

Changing the parental password

You can change the parental password.

Parental settings menu → [Change parental

password]

A screen for changing the parental password is displayed.

Enter a new parental password → [Continue]

Enter the new parental password again for

confirmation → [OK]

The new parental password is set.

Adding or editing emergency contacts

You can register up to 3 contacts as emergency contacts that location and image information is sent to when the personal alarm is activated.

Parental settings menu → [Add/edit

emergency contacts]

A screen for adding and editing emergency contacts is displayed.

[Add new] → Enter required items → [OK]

•To select and add an emergency contact from Contacts, tap "Add contacts".

Page 31

◎ Once 3 emergency contacts are registered, new or

additional contacts cannot be registered. To register a new contact, first remove a registered emergency contact and then add a contact.

Removing registered emergency contacts

Screen for adding and editing emergency

contacts → Tap " " for the emergency contact to remove → [OK]

◎ Emergency contact 1 cannot be removed unless a phone

number/e-mail address is registered for emergency contact

◎ Contacts that are removed from the emergency contacts

remain registered in Contacts.

Setting the personal alarm

When the personal alarm is activated, the location and images taken automatically with the cameras (out camera 4 photos, in camera 1 photo) are sent by e-mail to the registered emergency contacts. Product operation when the personal alarm is activated can be set individually.

Parental settings menu → [Personal alarm

settings]

The personal alarm settings menu is displayed.

Personal

alarm sound Personal alarm flash

Location information

Photos Set whether the images taken with the

Automatic calling

Set whether the personal alarm sounds when the personal alarm is activated.

Set whether the personal alarm flash flashes when the personal alarm is activated. Set whether the location is automatically sent by e-mail to emergency contacts 1 to 3 when the personal alarm is activated.

cameras are automatically sent by e-mail to emergency contacts 1 to 3 when the personal alarm is activated. Set

whether a voice call is automatically made to dialed to emergency contacts 1 to 3 when the personal alarm is activated. Display the terms of use for the personal alarm.

Getting Ready

Page 32

◎ If "Location information" and "Photos" are set on, "Data

enabled" switches on, and "Set data connection limit" switches off.

E-mail that is sent when sending location information/ images

◎ Location information and images are sent as separate

e-mail. The message "【緊急】お子様の携帯の防犯ブザーが作動しました。（位置情報）／（画像情報）" ([Emergency] The child's personal alarm has activated. (Location)/(Image)) appears in the subject line of the e-mail.

Getting Ready

◎ The sent 5 images are sent together as mail attachments. ◎ If e-mail is not able to be sent when the personal alarm is

activated, it is automatically sent when e-mail can be sent.

Restricting functions that children can use

You can limit the use of Contacts entries and applications, limit usage time, etc.

Parental settings menu → [Restrict functions

for children]

The "Restrict functions for children" menu is displayed.

Restrict call/

mail Restrict apps ▶P. 32 "Restricting applications" Restrict use time Restrict Wi-Fi ▶P. 34 "Restricting use of Wi-Fi Restrict access to website Detect the unsuitable word

▶P. 31 "Restricting persons that calls

and e-mail can be exchanged with"

▶P. 33 "Restricting the amount of time

that the product can be used"

▶P. 34 "Restricting access to harmful

sites"

▶P. 35 "Detection of inappropriate

language entry (worry-free text entr

y)"

Page 33

Restricting persons that calls and e-mail can be exchanged with

Limit calls and e-mail to only persons that are registered in Contacts and for which access is permitted.

"Restrict functions for children" menu →

[Restrict call/mail]

Tap "ON"/"OFF" at the top of the screen to

turn "ON" → [OK]

"Restrict functions for children" is turned "ON", and contacts are listed.

[Allow]/[Disallow] for contacts

Tap to toggle allow and disallow setting.

•"Pending" is displayed for newly added contacts. Tap to set "Allow" or "Disallow".

•Tap [Allow all] to set "Allow" for all contacts.

[OK] → [OK]

◎ Recipients registered as emergency contacts are available

even when "Restrict call/mail" is set to "ON".

◎ When the personal alarm is activated, the "emergency list"

can be tapped to place a call to 110 (Police), 119 (Fire/ Ambulance), 118 (Maritime rescue), or an emergency contact (3 contacts including a parent or guardian) even when "Restrict call/mail" is set to "ON".

◎ Calls from contacts set in "Restrict call/mail" are handled in

the same way as incoming reject.

◎ If another call arrives from a contact set in "Restrict call/

mail" while talking on the phone, the current call ends.

Getting Ready

Page 34

Restricting applications

Restrict the use of applications. Applications with "Restrict apps" set no longer appear in the Apps list.

"Restrict functions for children" menu →

[Restrict apps]

Tap "ON"/"OFF" at the top of the screen to

turn "ON"

"Restrict apps" is turned "ON", and applications are listed.

[Allow]/[Disallow] for applications

Getting Ready

Tap to toggle allow and disallow setting.

•"Pending" is displayed for newly installed applications. Tap to set "Allow" or "Disallow".

•Tap [Allow all] to set "Allow" for all applications.

[OK] → [OK]

◎ This product does not support Google Play. ◎ To add widgets, the parental password is required. ◎ Application icons are deleted from the Home screen/Apps

list if the application is set to "Disallow". If an application with "Disallow" is returned to "Allow", the application is added at the end of the Apps list.

" icon is displayed in the Apps list for pending

◎ A "

applications. You can tap the icon and enter the parental password to display a settings screen and set application restrictions.

◎ Additionally, for details on the availability of usage

restrictions on each application, refer to "Main icons in the "Apps list"" (▶P. 43).

Page 35

Restricting the amount of time that the product can be used

Set the time of day the product can be used and the amount of time that calls can be made.

"Restrict functions for children" menu →

[Restrict use time]

Restricting the time of day and amount of time for using the product

Set the time of day that use is restricted to and the amount of time the product can be used per day.

[Restricted period for use]/[Available time per

day]

Tap "ON"/"OFF" at the top of the screen to

turn "ON"

The time of day that use is restricted/usable time restriction is turned "ON", and a settings screen is displayed.

Tap and set the time → Tap " " to set the

day, etc.

Restricting call time (one day/one month)

Set the amount of time that calls can be made per one day/ one month.

[Call time per day]/[Call time per month]

Tap "ON"/"OFF" at the top of the screen to

turn "ON"

The amount of time that calls can be made per one day/one month is turned "ON", and a settings screen is displayed.

Tap and set the amount of time that calls can

be made

The time of day that use is restricted/usable time per day

◎ Tap " " to register a new setting.

(Delete)" to delete a setting.

◎ Tap " ◎ Auto-answer functions such as hold answer, auto

answering, incoming reject, etc. are also counted in call time. Call time to emergency contacts is not counted.

◎ 10 minutes before a use restriction starts, a notification

appears in the status bar.

◎ Once a use restriction starts, "

and use is restricted.

◎ To ensure safety in an emergency at night, calling, e-mail,

SMS, 安心ナビ (Security Navi), the personal alarm, etc. are not subject to usable time restrictions.

Operation when the personal alarm is activated

◎ The personal alarm can always be used regardless of

restrictions on use time and call time.

Operation during a call

◎ If a call exceeds the set call time, restriction starts after the

call ends.

" appears in the status bar

Getting Ready

Page 36

Restricting use of Wi-Fi

Restrict Wi-Fi® networks that can be connected to.

"Restrict functions for children" menu →

[Restrict Wi-Fi]

Tap "ON"/"OFF" at the top of the screen to

turn "ON"

Wi-Fi® access point restriction is turned "ON", and available Wi-Fi® networks are displayed.

[EDIT] → Set the networks

•For details on Wi-Fi® connection, refer to "Connecting

Getting Ready

to a Wi-Fi® network" (▶P. 54).

Restricting access to harmful sites

Restrict Internet use.

Precaution

The product's browser filtering cannot be turned off. Select either the Elementary or Junior high setting.

"Restrict functions for children" menu →

[Restrict access to website]

Change the

current level (elementary/ junior high)

Customize the filtering

Personalized filtering list

Set the filtering level appropriate for the child's age (elementary/junior high). Elementary: For a child first using or a little used to using a smartphone Junior high: For a child fairly used to using a smartphone

•For details on filtering levels, refer to

"Filtering strength" (▶P. 35).

Add information for sites to be individually restricted or to permitted to the filtering list.

•A we

bpage displayed in the browser

can also be registered. Allows you to edit/delete webpages with viewing permitted/restricted from in the filtering list. Up to 100 site pages can be registered to the filtering list. For details, refer to "Cancelling restrictions on viewing webpages" (▶P. 40).

Page 37

Filtering strength

Elementary •Sites inappropriate for viewing by the

Junior high •Sites inappropriate for viewing by the

* Content Evaluation and Monitoring Association

◎ The filtering feature in this product restricts access to sites

registered in the URL database provided by NetSTAR Inc., and does not regularly check content and regulate access. There may therefore be instances where content in the above categories is displayed.

child, sites allowing exchanges with unknown persons, sites requiring knowledge, experience, and judgment, sites containing depictions of swimwear or underwear, sites that could be unworthwhile, and sites with any other content that would be a source of concern cannot be viewed.

•EMA*-approved sites also cannot be viewed.

child, sites allowing exchanges with unknown persons, sites requiring knowledge, experience, and judgment, and sites containing depictions of swimwear or underwear, cannot be viewed.

•EMA

-approved sites also cannot be

viewed.

Detection of inappropriate language entry (worry-free text entry)

Display a confirmation screen when language inappropriate for children is entered for Internet searching, e-mail and SMS, etc.

"Restrict functions for children" menu →

[Detect the unsuitable word]

Word check Toggle detection/no detection of

Input history Allows entered inappropriate

inappropriate language entry.

language and number of times to be checked.

•Tap "Reset History" to delete history.

Getting Ready

Page 38

Preventing use of a smartphone while walking

Make settings to prevent use of a smartphone while walking.

Parental settings menu → [Texting While

Walking Alert]

•If a permissions screen/terms of use are displayed, confirm content and follow the onscreen instructions.

Tap "ON"/"OFF" at the top of the screen to

turn "ON"

Getting Ready

The smartphoning while walking alert application is turned "ON", and detects any such activity.

Make detailed settings for the alert

application

バイブレーション

(Vibration)

表示アニメーション

(Display animation) 感度 (Strength)

ヘルプ (Help) Display help for the alert application.

Set the product to vibrate when smartphoning while walking is detected. Set the product to display an animated alert when smartphoning while walking is detected.

Set the smartphoning while walking detection strength to "高 (high)" or "低 (low)".

利用規約

(Terms of use)

バージョン

(Version)

◎ If the personal alarm is activated or use restrictions are

canceled remotely (▶P. 39), the alert application is temporarily deactivated.

Display terms of use for the alert application.

Display the version of the alert application.

Page 39

Making e-mail privacy settings

Set an e-mail password and make secrecy settings.

Parental settings menu → [E-mail privacy

setting]

•If initial e-mail address setting has not been made, a settings screen is displayed. Follow the onscreen instructions to make the initial setting.

Set password/ Change password

Set/change password for the folder lock and secrecy function.

Enter folder unlock password (letters and numbers, 4 to 16 characters)  [OK]  Enter same password again  [OK]  Select secret question  [OK]  Enter answer to secret question  [OK]

•Once a password is set, "Change password" is displayed.

•If the password for the folder lock is incorrectly entered 3 times, the secret question is displayed. Tap [Proceed] → Enter the answer → [OK] and set a new password.

Reset password

Secret Enable/disable the secrecy function.

Reset the password.

Enter folder unlock password  [OK]  [Reset]

•This cannot be selected if no password is set.

•Once the password is reset, the folder lock and secrecy function are canceled.

Enter password  [OK]

•Use this feature after carefully reading the displayed description for secret mode.

•This cannot be set if no password is set.

•No pop-up or other hint will be displayed for a mistaken password when either enabling/disabling or temporarily canceling the secrecy function.

Getting Ready

Page 40

Checking/editing the child's profile

You can check and edit the child's profile on the product.

Parental settings menu → [Profile]

The profile screen is displayed.

Editing the profile

Profile screen → [ (Edit)]

•You can share the profile via e-mail, etc. by tapping

[ (Menu)] → [Share].

Enter required items → [OK]

Getting Ready

◎ The child can also directly check and edit their profile

without requiring the parental password (▶P. 50 "Checking your own phone number (Profile)").

Making call settings

Check call time and make voicemail and other settings.

Parental settings menu → [Auto answering,

incoming reject, additional settings]

The call menu is displayed.

•Alternatively, you can display the call menu by

tapping parental settings menu → [Other settings] → [Call].

Call Time Display previous/accumulated call time

Hide Caller ID Auto answering

and amount of time that calls can be made. Set whether a caller's name and image are displayed when a call arrives. Auto answering response settings

Answer time

Recorded messages

Set whether to play an answer recording and record a caller's message when a call cannot be answered. Set the time until calls are answered with auto answering. Select and play auto answering messages.

•In the auto answering list, tap "

" or long-touch a message to protect, delete, etc. messages.

Page 41

Voice memo

Incoming Reject

Call service settings SMS response

Call time

◎ Displayed call time is for calls made from the product. ◎ Call time might not be updated in instances such as when

a call is interrupted and not ended normally or when making an international call.

Auto answering

◎ Up to 20 calls of up to about 1 minute in length can be

recorded. If 20 calls are recorded, played-back and unprotected recordings are deleted, starting from the oldest recording.

◎ If no recorded messages have been played back and all

are protected, auto answering does not answer calls.

Select and play voice memos.

•In the voice memo list, tap " " or long-touch a message to protect, delete, etc. messages.

Set criteria for automatically rejecting calls. This cannot be set if "Restrict call/mail" is "ON". Set voicemail, call forwarding, and other network services.

Edit an SMS answer recording.

Canceling use restrictions remotely

In case of disaster or other emergency, "Restricted period for use", "Available time per day", and "Restrict apps" can be temporarily canceled.

From a device (phone number) registered as an

emergency contact, send an SMS with "制限解除 (Cancel restriction)" entered in the text body

After receiving the SMS with the product, "

(Restriction was released)" is displayed in the notification panel

Use restrictions are temporarily canceled.

Ending temporary cancelation of restrictions

Open the notification panel and tap " (Start

restrict)"

[OK]

◎ Always enter "制限解除" using kanji in the SMS for canceling

use restrictions.

◎ While restrictions are temporarily canceled, "Restricted

period for use", "Available time per day", and "Restrict apps" settings are disabled. Settings cannot be changed. After ending temporary cancelation of restrictions, all settings are enabled.

Getting Ready

Page 42

Cancelling restrictions on viewing webpages

Webpages, to which access became restricted due to harmful site restriction, can be individually set to a personalized filtering list to allow viewing.

Webpage with blocked access → [Ask for

permission?] → Enter parental password → [OK]

Enter title → [OK] → [OK]

Getting Ready

Browser screen → [ ] → [Refresh]

If " " is not displayed, slide screen downward to display.

Replacing restriction on allowed webpage

Replace the restriction on a webpage that was set to the personalized filtering list to allow viewing.

Browser screen → [ ] → [Parental Controls]

→ Enter parental password → [OK]

[Personalized filtering list] → Tap "

(Allowed)" for webpage to restrict

The setting changes to " (Disallowed)" and viewing is no longer possible.

• Tap to toggle " (Allowed)" and " (Disallowed)".

◎ If a keyword is entered in the URL field, the search engine

set in "Set search engine" in the browser settings menu is used for searching.

◎ If the quick controls are on, the URL field is not displayed at

the top of the browser. Display it from the quick controls.

◎ If the URL field is not displayed, slide the browser screen

downward.

◎ Websites can also be set to the personalized filtering list

from "Restrict access to website" (▶P. 34).

Page 43

Basic Operation

Using the touch panel

The product's display is a touch panel that can be used by touching directly.

Tap

Lightly touch a screen and then immediately release your finger.

Long-touch

Keep touching an item or key.

Flick

Quickly move (flicking) your finger up, down, right, or left.

Switching character entry

When entering text, you can switch the type of character entry by tapping the character entry key " ". Tap to cycle the type of characters through hiragana/kanji, single-byte alphabet, and single-byte numbers.

Basic Operation

Page 44

Using Home screen

The Home screen comprises several sheets. Slide or flick left/right to switch to other sheets. Press H to display the Home screen anytime.

①

②

Using the Apps list

A list of installed apps is displayed.

Home screen → [Apps]

The Apps list appears.

① ②

Basic Operation

󰴤 Status bar 󰴥 Shortcuts/widgets/folders 󰴦 Indicator 󰴧 Quick launch area 󰴨 Apps

③ ④

⑤

《Home screen》

《Apps list》

③

󰴤 Category name

Tap to display navigation.

•Alternatively, slide or flick right from the left edge of the screen to display navigation.

󰴥 Menu icon

Display the Apps list menu.

󰴦 Indicator

Check the current position in the Apps list.

Page 45

Main icons in the "Apps list"

You can restrict the use of any application indicated with a "○" in "Usage restrictable" by setting "Restrict apps" (▶P. 32) to "ON".

Displayed icon name

Eco Mode

Set to maintain battery consumption at a minimum.

Camera ○ P. 55

カレンダーLifebear (calendar Lifebear) ○ ― スマートフォン自動診断 (smartphone

auto-diagnose) Downloads

Manage downloaded data.

デジラアプリ (dejira app)

Dejira App allows you to

- check your remaining data amount

- use the Data Charge service

- use the Data Gift service

- request your family to give you data amount

ナビウォーク (Navi for walkers)

Helps you navigate route combining public transportation and walk

Usage

restrictable

× P. 53

○ ―

× ―

○ ―

Page

Displayed icon name

BarcodeReader

ICONIT - Barcode Reader Evolving Shoot barcode with ICONIT to get something more than ever. Just scan QR code or UPC/EAN code and you will get high-quality movies, music, images on your Smartphone.

Usage

restrictable

○ ―

Page

File Commander ○ ― ファミリーガイド (family guide) ○ ― Photo library ○ P. 55 Browser ○ ― Memo pad ○ ― リモートサポート (Remote Support)

Call for technical supports on the phone operations by sharing the screen that you are watching with au operators.

安心ナビ（探される） (Security Navi

○ ―

× ―

(device being searched for))

You can confirm the position of the child in this application.

Sound Recorder ○ ― Flashlight × ― Search ○ ― 使い方ガイド (operation guide) ○ ― Clock × ― Basic Manual

Use an "Instruction Manual" application.

○ P. ii

Basic Operation

Page 46

Displayed icon name

restrictable

Settings × ― 超ブルーライト削減 (super blue light

*1*2

reduction) Calculator ○ ― Phone × P. 49 Contacts × P. 50 au Cloud

The application to move photos & movies of smart Phone into au Cloud either automatically or manually. Automatic movement is limited to the area covered by Wi-Fi®.

au ID Setting ○ P. 26

Basic Operation

au Market

You can install Android-based applications offered with au Smart Pass service.

au Wi-Fi接続ツール (au Wi-Fi connection tool)

You can easily set up Wi-Fi® connection with the private access points such as "HOME SPOT CUBE". You can use the all au's public Wi-Fi spots. You can also find the location/venue information to provide au Wi-Fi.

Usage

○ ―

Page

Displayed icon name

auスマートパス (au Smart Pass)

You can enjoy as many applications as you want from among over 500 apps by ￥372 (tax excluded) per month! Also coupons, presents, photo storage and security apps are available. Please enjoy your safety and comfortable smartphone life!

au Backup App

"au Backup App" can backup and restore various data in your smartphone to SD card.

au災害対策 (au Disaster

Usage

restrictable

○ ―

× P. 56

Page

Countermeasure)

This is an application in which you can use Disaster Message Board, Emergency Rapid Mail (Earthquake Early Warning and Disaster and evacuation Information and Tsunami Warning) and Disaster Voice Messaging Service.

E-mail × P. 51

*1*2

LINE

This communication app allows you to enjoy calling and texting as much as you want for free, any time and any place.

LISMO

With LISMO application, you can enjoy music, find hot music information, try and purchase songs.

○ ―

Page 47

Displayed icon name

Lookout for au

"Lookout for au" enables KDDI operator to remotely lock and/or locate your device on behalf of you in case of loss or theft.

OfficeSuite

View Word, Excel, and other files.

SMS × ―

*1*2

wellnote

wellnote is communication service only for family members. You can privately save and share a private collection of family photos and videos.

*1 Requires download and installation. *2 This application is deleted when performing "Factory data reset".

Usage

restrictable

× ―

○ ―

Page

◎ When using the functions of each application,

communication charges may result for some functions.

◎ Displayed icon names may change without notice. ◎ Applications can only be downloaded from au Market or au

スマートパス (au Smart Pass) (Google Play unsupported). Some applications, including LINE and ナビウォーク (Navi for walkers), are applications designed especially for this product.

Basic Operation

Page 48

Monitoring the product's status

Icons

Notification icons appear on the left of the status bar, showing missed calls, new mail, operations in progress, etc., and status icons appear on the right, showing the status of the product.

Examples of main notification icon

Icon Description

Missed call New mail message (SMS) New mail message (E-Mail)

Basic Operation

New Emergency Rapid Mail message Snoozed alarm, or stopped alarm that is still set Call arriving New auto answering message Internal memory is low Request from other Bluetooth® device to receive file Send/upload data Receive/download data Installation complete Update notification for installed application VPN connected

Icon Description

Major update (for OS) and software update available Tethered by USB Tethered by Wi-Fi Tethered by Bluetooth Tethered simultaneously by Wi-Fi® or Bluetooth® and USB Eco Mode activated Screenshot captured microSD memory card unmounted Use restricted Restriction on arriving calls cancelled

Page 49

Examples of main status icon

Icon Description

Time Battery level

100%/ empty/ charging

Signal strength/Signal used (LTE/3G)

level 4/ out of range/ in communication

LTE available/ 3G available Airplane mode is activated au Micro IC Card (LTE) uninserted Wi-Fi® signal strength

level 4/ level 0 Alarm set Silent mode (Vibrate) set Silent mode (Mute) set Bluetooth® in use

standby/ connected Auto answering set

auto answering set/

maximum messages recorded GPS in use

Notification panel

Slide down the status bar to display the notification panel. You can check details of notification icons or start corresponding apps. Also, you can set frequently-used functions, add shortcuts and activate apps from shortcuts.

◎ You can also hide the notification panel by tapping the top

area of the screen, where date, time and battery icon are displayed.

◎ If "Restrict apps" (▶P. 32) is "ON", applications with their

restriction set to "Disallow" cannot be registered as shortcuts. Setting an application that is registered as a shortcut to "Disallow" deletes the application from shortcuts.

Basic Operation

Page 50

Setting Airplane mode

When Airplane mode is set, wireless functions are disabled (telephone, packet transmission, wireless LAN (Wi-Fi®)/ Bluetooth® functions).

Settings menu → Tap "ON"/"OFF" for

"Airplane mode" to turn "ON"

Airplane mode switches "ON" and " " is displayed in the status bar.

◎ The wireless LAN (Wi-Fi®)/Bluetooth® functions can be

switched on even when Airplane mode is on. Follow airline or institution instructions when using these functions aboard

Basic Operation

an aircraft or in a hospital or similar place.

◎ Calls cannot be made when Airplane mode is on. However,

calls can be made to 110 (Police), 119 (Fire/Ambulance), and 118 (Maritime rescue). In these instances, Airplane mode switches "OFF" and remains "OFF" after the call ends.

◎ Setting Airplane mode to on prevents calls from being

answered. Also, sending/r by wireless LAN (Wi-Fi also not possible.

◎ Alternatively, F (press and hold for at least 1 second) →

[Airplane mode] to toggle Airplane mode on/off.

eceiving of mail, communication

) and Bluetooth® functions, etc. is

Setting Silent mode

Set the silent mode not to inconvenience people around you in a public place.

Settings menu/Other settings menu →

[Sound/Vibration/LED] → Select "Silent mode" → Confirm "Attention" notice → [OK]

Silent mode is set on.

•Select "Understood" in the "Attention" notice to no longer display the "Attention" notice.

Changing the Silent mode type

Settings menu/Other settings menu →

[Sound/Vibration/LED] → [Silent mode type] → [Vibrate]/[Mute]

◎ Alternatively, F (press and hold for at least 1 second) →

[ ]/[ ]/[ ] to switch between Mute/Vibrate/Off.

◎ You can keep l (volume DOWN key) pressed to set

Silent mode on or off.

◎ Even in Silent mode, the shutter click and recording start

and stop beeps sound.

◎ When playing back an electronic file in Silent mode on

mute, you can press d (volume UP/DOWN key) during playback to adjust the volume depending on the function.

Page 51

Making a call

Home screen → [Phone]

The phone number entry screen appears.

•If the call history/favorites screen appears, tap [Dialpad].

Enter a phone number

When calling to a fixed-line phone, enter the phone number starting with the area code even if you are in the same area.

[Call] → Call → [End call]

Press d during a call to adjust volume of the other party's voice.

◎ If "Restrict call/mail" (▶P. 31) is "ON", calls can only be

made to contacts registered in Contacts that have been allowed by a parent or guardian. If a call is initiated to a not-as-yet approved "pending" contact, a message is displayed indicating the call is prohibited.

◎ If "Call time per day" or "Call time per month" (▶P. 33) is set,

it may not be possible to make or receive calls depending on the amount of accumulated call time.

◎ If you cover the screen by your face etc. while dialing/

calling, the display turns off for pr

◎ Note that even if you cover the microphone, the sound can

be conveyed to the other party.

◎ Calls can be made to emergency reporting numbers (110,

119, 118) even when "Airplane mode" is set.

eventing false operation.

Basic Operation

Page 52

Registering a contact to Contacts and making a call

Registering a contact to Contacts

Apps list → [Contacts]

The contacts list is displayed.

[ (Add)]

Enter required items → [OK]

The contact is registered.

◎ To use contacts registered in Contacts, parental permission

Basic Operation

is required. For details, refer to "Restricting persons that calls and e-mail can be exchanged with" (▶P. 31).

Making a call from a contact

Contacts list → Tap the contact to call

[ ]

Receiving a call

Arriving call screen → Slide right from " "

to " "

Call → [End call]

Checking your own phone number (Profile)

Home screen → [Settings] → [Profile]

Profile screen appears.

◎ To edit the profile, refer to "Editing the profile" (▶P. 38). ◎ Alternatively, tap [Apps] → [Contacts] → [All contacts] →

Your own name to check your phone number (▶P. 50).

Page 53

E-mail

Use of e-mail (@ezweb.ne.jp) requires subscription to LTE NET. If you did not apply when purchasing the product, inquire at an au shop or the Customer Service Center. Completing initial settings automatically assigns an e-mail address. The e-mail address assigned during initial settings can be changed.

Initial settings

Home screen → [Apps] → [E-mail]

Confirm content, [接続する (Connect)]

After completing initial settings, the assigned e-mail address is displayed.

[閉じる (Close)] → Confirm content of

"Information for improvement" → [Agree]/ [Disagree] → [Done]

A description of the e-mail function is

displayed; confirm content and tap "Close"

Changing the e-mail address

Home screen → [Apps] → [E-mail]

[ ] → [E-mail settings]

[Other settings] → [接続する (Connect)]

[Eメールアドレスの変更へ (Change e-mail

address)]

Enter the PIN → [送信 (Send)]

Confirm content, [承諾する (Agree)]

Enter the e-mail address → [送信 (Send)]

[OK] → [閉じる (Close)]

Basic Operation

Page 54

Backing up & restoring e-mail

E-mail can be backed up using one of two methods. Backed up mail data can be loaded back to the product.

◎ Backed up data is saved on a microSD memory card

(\private\au\email\BU) when a microSD memory card is installed. If a microSD memory card is not installed, data is saved in the internal storage (\private\au\email\BU).

Backing up mail data

You can back up mail data (mail text, attachments).

E-mail settings screen → [Backup/Restore]

Basic Operation

[Mail Backup] → [OK]

Select a character code to make backup data

→ [OK]

Checkmark the mail type to back up → [OK]

Restoring mail data

You can restore backed up mail data (mail text, attachments).

E-mail settings screen → [Backup/Restore]

[Restore mails]

[Inbox mails]/[Outbox mails]/[Unsent mails]/

[Search Storage] → [OK]

Select the backed up data to restore → [OK]

[Add]/[Overwrite] → [OK]

Page 55

Using Eco Mode

Use "Eco Mode" to set sleep time and screen brightness to a minimum or to disable auto rotation of the screen, Wi-Fi®, Auto data control, Bluetooth®, CPU clock restriction, etc. so that you can save battery power.

Apps list → [Eco Mode]

The Eco Mode screen is displayed.

[Custom]/[Long life]

Eco Mode is set.

◎ The Eco Mode screen displays available continuous

standby time, call time, etc. based on current product settings.

Wireless LAN (Wi-Fi®) function

Use your home Wireless LAN (Wi-Fi®) or public wireless LAN to connect internet.

Turning the Wi-Fi® function on

To use Wi-Fi®, turn on the Wi-Fi® function and then search for and connect to an available Wi-Fi® network.

Home screen → [Settings] → Tap "ON"/"OFF"

for "Wi-Fi" to turn "ON"

The Wi-Fi® function switches on and scans for available Wi-Fi® networks. Time may be required for the Wi-Fi® function to switch on.

Basic Operation

Displaying menu

There are two types of methods to display a menu screen; by tapping " " and by long-touching entry field or item.

◎ Alternatively, to switch the Wi-Fi® function on, parental

settings menu → [Other settings] → Tap "ON"/"OFF" for "Wi-Fi" to turn "ON".

Page 56

Connecting to a Wi-Fi® network

Home screen → [Settings] → Tap "ON"/"OFF"

for "Wi-Fi" to turn "ON" → [Wi-Fi]

The Wi-Fi settings screen is displayed and available Wi-Fi® networks are displayed.

Select the Wi-Fi® network to connect to →

[Connect]

•To connect to a secured Wi-Fi® network, enter the password (security key)* and tap "Connect".

* The password (security key) is set on the access point. For details,

contact the network administrator.

•Once connection is established, " " is displayed in the status bar.

Basic Operation

◎ If Wi-Fi® is restricted by parental settings, connection is not

possible to Wi-Fi® networks that have not been allowed. For details on cancelling connection restrictions, refer to "Restricting use of Wi-Fi®" (▶P. 34).

Tethering

The tethering function allows access to the Internet using the product as a portable access point. You can also connect up to 10 wireless LAN (Wi-Fi®) devices, connect the product to a PC with a microUSB cable 01 (sold separately), or connect up to 5 Bluetooth® devices and access the Internet.

Home screen → [Settings]→ [Tethering]

Follow the onscreen instructions

◎ Use of the tethering function requires a separate

subscription.

◎ Alternatively, you can set the tethering function by tapping

parental settings menu → [Other settings] → [More...] → [Tethering].

◎ If “Restricting use of Wi-Fi

function is unavailable.

” (▶P. 34) is “ON”, the tethering

Page 57

Capturing photos and video

Capturing a photo

Home screen → [Camera]

Point camera at subject → [ ]

•Tap the screen with the subject appearing to lock the focus and capture a photo. The photo is automatically saved.

•Before capture, you can widen or close two fingers on the screen to adjust the zoom.

Capturing a video

Home screen → [Camera]

Point camera at subject → [ ]

Recording starts.

•Widen or close two fingers on the screen to zoom in or out.

[ ]

Recording stops and the video is automatically saved.

Viewing files with the photo library

The photo library allows the contents of the internal storage/ a microSD memory card to be displayed and played. Contents can be managed as an album.

Playing data

Apps list → [Photo library]

The data list is displayed.

•If there is no image data stored in the product, a camera launch icon is displayed. Follow the onscreen instructions.

① Name of the displayed

album.

Tap to display

navigation for display categories and select the category to display.

② Displays photo library menu.

Select the data

Data is played.

① ②

Basic Operation

Page 58

au Disaster Countermeasure

au災害対策 (au Disaster Countermeasure) is an application with which you can use 災害用伝言板 (Disaster Message

au Disaster Countermeasure

Board), 緊急速報メール (Emergency Rapid Mail) (緊急地震速報 (Earthquake Early Warning), 災害・避難情報 (Disaster

and Evacuation Information), 津波警報 (Tsunami Warning)) and 災害用音声お届けサービス (Disaster Voice Messaging Service).

Apps list → [au災害対策 (au Disaster

Countermeasure)]

au災害対策 (au Disaster Countermeasure) menu appears.

Using Disaster Message Board

Disaster Message Board service enables you to register information of well-being from an area of distress via LTE NET in case of large-scale disaster such as earthquake with a seismic intensity of over 6 lower. Registered information can be viewed on any cell phones and PCs besides by au cell phone users. For details, refer to "Disaster Message Board" of au homepage.

au災害対策 (au Disaster Countermeasure)

menu screen → [災害用伝言板 (Disaster Message Board)]

Follow the onscreen instructions to register/confirm.

◎ To register information of well-being, E-mail address

(～ezweb.ne.jp) is required. Set up E-mail address beforehand. For details on setting an e-mail address, refer to "E-mail" (▶P. 51).

◎ Deleting or changing the setting for information of

well-being is unavailable during Wireless LAN (Wi-Fi connection.

◎ The Company makes no guarantees about the quality of

this service. The Company is not liable in the event of any nonconformities about registration of well-being information or damages by loss of well-being infor intense access to this service or equipment failure or damages caused by registered well-being information.

mation arising from

)

Page 59

Using Emergency Rapid Mail

Emergency Rapid Mail is a service that distributes Earthquake Early Warning or Tsunami Warning delivered from the meteorological bureau or Disaster and Evacuation Information delivered from the government or local public organization to all au cell phones in specified areas simultaneously. When you purchase the product, "受信設定 (Receive options)" of the Emergency Rapid Mail is set to "受信する (Receive)". Reception setting of Tsunami Warning is available in the settings of Disaster and Evacuation Information. When you receive Earthquake Early Warning, ensure your safety and take proper action according to the situation around you. When you receive a Tsunami Warning, draw away from sea coast immediately and evacuate to safe place such as upland or well-built high building.

au災害対策 (au Disaster Countermeasure)

menu screen → [緊急速報メール (Emergency Rapid Mail)]

Inbox appears. Select a mail you want to view to check the detail.

削除 (Delete)

Delete received mail.

設定 (Settings)

 (Earthquake Early Warning): Set whether to receive

earthquake early warnings.

 (Disaster and Evacuation Information): Set whether to receive

disaster and evacuation information and tsunami warnings.  (Volume): Set the volume for arriving warnings.  (Vibration): Set whether the product vibrates for warnings.  (Alarm in Silent mode): Set whether alarm sounds in Silent mode.

 (Earthquake Ear Warning): Confirm the alarm sound and

vibration for an earthquake early warning.

 (Disaster and Evacuation Information): Confirm the alarm sound

and vibration for disaster and evacuation information and tsunami warnings.

au Disaster Countermeasure

Page 60

◎ No information fee or communication charge is required for

receiving Emergency Rapid Mail.

◎ You cannot receive Emergency Rapid Mail when the

au Disaster Countermeasure

product is turned off or when calling.

◎ Emergency Rapid Mail may not be received if you are in a

place where signal does not reach even in the service area (e.g. in a tunnel, basement) or in a place with a poor reception.

◎ You cannot receive Emergency Rapid Mail that the

reception is failed.

◎ Reception of Emergency Rapid Mail is notified by a special

warning tone and vibration. It is not possible to change the warning tone.

* Reception of Earthquake Early Warning is notified by a special

warning tone, voice ("地震です" (An earthquake)) and vibration.

◎ Information from someplace other than your current location

may be received.

◎ KDDI is not liable for damages suffered by customers

resulting from the service's information, lack or delay in the

mation caused by transmission or system breakdowns,

infor or other events that are outside the responsibility of KDDI.

◎ Refer to the Japan Meteorological Agency web page for

details about distribution of Earthquake Early Warning.

（http://www.jma.go.jp/）

Earthquake Early Warning

◎ Earthquake Early Warning is sent to areas where strong

quakes (over 4 degrees) are expected when the earthquake whose the maximum seismic intensity 5 lower is anticipated occurs.

◎ Immediately after an earthquake occurs, quakes (P waves

and initial tremors) near the epicenter are detected and position, scale, and expected strength are automatically calculated and notification is sent as soon as possible within a few seconds to tens of seconds before the strong quakes (S waves and major tremors) caused by the earthquake start.

◎ Earthquake Early Warning may not arrive before strong

tremors in arrears near the epicenter.

◎ This deliver

Warning provided through TV, radio, or other communication procedures, which means that the time the Earthquake Early Warning arrives may vary.

y system is different from Earthquake Early

Tsunami Warning

◎ Tsunami Warning is a notification delivered from the

meteorological bureau (major tidal wave, seismic sea wave) to the area including target coast.

Disaster and Evacuation Information

◎ Disaster and Evacuation Information is a service that

distributes bulletins concerning residents' safety including evacuation advisories, evacuation orders and other warnings issued by the national and local governments.

Page 61

Using Disaster Voice Messaging Service

Disaster Voice Messaging Service is a service which allows you to record your voice and send someone you want to inform your well-being in case of a large-scale disaster.

au災害対策 (au Disaster Countermeasure)

menu screen → [災害用音声お届けサービス (Disaster Voice Messaging Service)]

Follow the onscreen instructions to register.

Sending voice (sending)

Select "声をお届け (Sending voice)", [①お届け先を選択 (Select delivery)*] → [②お届けしたい声を録音 (Record voice)]

* Alternatively, delivery address can be selected in Contacts.

Receiving voice (receiving)

Receiving voice messages is notified on a pop-up screen or SMS. To listen to voice messages, receive (download) and play it.

•When recipient uses a smartphone without au災害対策 (au Disaster Countermeasure) activated or au cell phone, SMS is sent.

•In case of receiving SMS, the information is not saved on au災害対策 (au Disaster Countermeasure).

◎ For use over Wi-Fi®, it is necessary to carry out initial setting

over 4G (LTE)/3G network.

◎ Voice message can be recorded for up to 30 seconds. ◎ Messages can be sent and received to or from au cell

phones, other network operators' cell phones and PHS.

◎ Voice message may be difficult to hear if the media volume

is low or Silent mode is set.

◎ Saving or playing Voice messages may fail if a phone does

not have available memory.

◎ Some cell phones do not support r

messages. For details, refer to au homepage.

eceiving voice

Using Disaster information

You can check history of Disaster and Evacuation Information delivered by local government, disaster information portal, etc.

au災害対策 (au Disaster Countermeasure)

menu screen → [災害情報 (Disaster information)]

Follow the onscreen instructions

au Disaster Countermeasure

Page 62

Safety Precautions

Exemptions

◎ The Company is not liable for any damages arising from

earthquakes, lightning, storms, floods or other natural disasters, as well as fires, actions by third parties, other accidents, intentional or mistaken misoperation by the customer, or use under other unusual conditions outside the responsibility of the Company.

◎ The Company is not liable for any incidental damage

Safety Precautions

(change/disappearance of described content, loss of business income, disruption of business, etc.) arising from use or inability to use the product.

◎ The Company is not liable for any damages arising from

failure to observe the described content of this manual.

◎ The Company is not liable for any damages arising, for

example, from malfunction caused by combination with connected devices or software not related to the Company.

◎ Captured image data or downloaded data may sometimes be

altered or lost due to faults, repair or other handling of the product. The Company is not liable for any damage or lost income resulting from recovery of these data.

◎ It is recommended you keep a copy of important data on your

PC's hard disk, etc. Whatever the cause of the defect or malfunction may be, the Company assumes no responsibility for alteration or loss of saved data.

* "The Company" as appears in this manual refers to the following companies: Sold by: KDDI CORPORATION, OKINAWA CELLULAR TELEPHONE

COMPANY

Manufactured by: KYOCERA Corporation

 Important

•Reproduction of the content of this manual in part or in whole is prohibited.

•The content of this manual is subject to change without notice.

•Every effort has been made in the preparation of this manual. Should you notice any unclear points, omissions, etc., feel free to contact us.

Page 63

Safety Precautions (Observe Strictly)

Before using this product, thoroughly read these safety precautions for proper use. After reading, store the precautions in a safe place.

● These "Safety Precautions" describe instructions that

should be observed to prevent damage to property or injury to the customer or others using the product.

● These instructions are divided into the following

categories.

Explanation of indications used in this

manual

This symbol indicates the

DANGER

WARNING

CAUTION

potential and imminent danger of death or serious injury a person.

This symbol indicates the possibility of death or serious

(*1)

injury

to a person.

This symbol indicates the possibility of personal minor

(*2)

injury

to a person or

physical damage

(*1)

(*3)

*1 Serious injury: This refers to loss of sight, injury, burns (high- and

*2 Minor injury: This refers to injuries, burns (high- and low-temperature),

*3 Physical damage: This refers to extended damage to buildings, furniture,

low-temperature), electric shock, broken bones, injuries with residual aftereffects from poisoning, etc., and injuries requiring hospital admission for treatment or long term hospital attendance as an outpatient.

electric shock, etc. that do not require hospital admission for treatment or long-term hospital attendance as an outpatient.

livestock, or pets.

Explanation of graphic symbols used in this manual

Indicates an action that is not allowed.

Indicates that handling with wet hands is not allowed.

Indicates that disassembly is not allowed.

Indicates that use in a place where the product is likely to get wet or allowing the product to get wet is not allowed.

Indicates an action that must be done.

Indicates that the power plug must be disconnected from the power outlet.

Safety Precautions

Page 64

Main unit, battery pack, back cover,

charging equipment, au Micro IC Card (LTE), peripheral devices

Be sure to read the following hazards before use.

Safety Precautions

DANGER

Be sure to use only the specified peripheral devices. Use of other devices might cause overheating, ignition, rupture, fault, or leakage of liquid.

Do not use, store or leave the product in hot places (e.g. by the fire, near a heater, under a kotatsu, in direct sunlight, in a car in the hot sun). Doing so might cause ignition, rupture, fault, fire or injury.

Before entering a gas station or other location where there is inflammable gas, always turn the product off and discontinue charging product if charging. Failure to observe these precautions might cause the gas to catch fire.

Do not put the product in a cooking apparatus such as microwave oven or a pressure vessel. Doing so might cause ignition, rupture, fault, fire or injury.

Do not throw the product into a fire or heat it. Doing so might cause fire, rupture or fire.

Do not short-circuit the connection terminal, earphone microphone terminal, etc. Do not allow conductive foreign objects (metal fragments, pencil leads, etc.) to come into contact with or get inside the connection terminal, earphone microphone terminal, etc. Doing so might cause a fire, burns, a fault due to heat generation.

When using a metal accessory etc., make sure not to allow the metal part come in contact with the connection terminal, earphone microphone terminal or power outlet. Doing so might cause electric shock, ignition, injury or a fault.

Do not expose the camera lens to direct sunlight for an extended period. Doing so might cause ignition, rupture or fire by the light-collecting mechanism of the lens.

The customer is not allowed to disassemble, modify or repair the product. Doing so might

cause a fault, ignition, electric shock, or injury. The Company is not liable even in the event of any nonconformities arising on the product or peripheral devices as a result of modification, etc. Modification of the product is in violation of the Wireless Telegraphy Act.

Page 65

WARNING

Do not drop or subject to strong impact, such as throwing. Doing so might cause rupture, overheating, ignition, or a fault.

Do not use outside when you can hear thunder. Doing so might risk lightning strikes and electric shock.

Do not let your hands, fingers and other parts of the body touch the connection terminals. Doing so might cause electric shock, injury or a fault.

If the product is damaged because it is dropped or something, and its display is cracked or internal parts are exposed, do not touch the cracked display or exposed parts with your hands. Doing so might cause electric shock or injury from damaged parts. Contact an au shop or Keitai Guarantee Service Center.

If the wet product is charged, electric shock, short circuit, or corrosion may occur and overheating may cause fire, malfunction or burns.

Be sure to read the following warnings before use.

Although this product model is water-resistant,

stop use if water or other liquid enters the product

from the external connection terminal, earphone

microphone terminal, back cover, etc. Continued

use of the product in this state might cause

overheating, fire or a fault.

Do not forcefully remove the back cover. Doing so

might cause the battery pack to fly out, causing

injury or malfunction.

Do not operate the product while driving an

automobile or motorized bicycle, riding a bicycle

or walking. Doing so may compromise traffic

safety and cause an accident.

If charging is not completed after the specified

charging time, stop charging. Failure to do so

might cause leakage of liquid, overheating,

rupture or ignition.

Do not leave in places within the reach of small

children. Small children might swallow small parts, etc. by mistake and choke on them, or might drop them by mistake and cause accidents or injury.

Safety Precautions

Page 66

Safety Precautions

CAUTION

Do not store the product in places subject to direct sunlight (e.g. in automobiles), places that get hot, places that get extremely cold, and in humid or dusty places. Doing so might cause overheating, fire, deformation or a fault.

Do not leave on unstable places such as rocky stands or tilting surfaces. Dropping the product may cause injury or damage. Pay careful attention while vibrator is set. Also, pay sufficient attention to impact, etc.

Do not cover or wrap the product with bedding, etc. while using or charging the product. Doing so might cause fire, fault or injury.

Do not touch the product or specified charger for a long time while power is being supplied from an external source. Doing so might cause low-temperature burns.

The product may become hot by prolonged use especially in high-temperature environment. Be careful when using the product touching your skin for a long time, as it might cause low-temperature burns.

Be sure to read the following cautions before use.

Do not use power outlets or wiring apparatus

beyond its rating. Also, exceeding rating, for

example, by connecting multiple devices to a

single power strip might cause overheating and

fire.

Do not use product with the back cover removed.

Do not place near corrosive chemicals or in

places where corrosive gas is generated. Doing

so might cause a fault or loss of internal data.

Do not store or leave product with back cover

removed from main unit. Dust or other foreign

particles entering the product may cause

malfunction.

Do not use if there is smoke, abnormal odor or

noise, excessive overheating, or other

abnormalities. If an abnormality occurs,

disconnect the specified charging equipment

from the power outlet or socket if you are charging

the battery, make sure that the product is not

overheating before turning the power off, remove

the battery pack, and contact an au shop or Keitai

Guarantee Service Center. Also, if you have

dropped or damaged the product, do not continue

to use it in that state, and contact an au shop or

Keitai Guarantee Service Center.

Page 67

When inserting an earphone, etc. into the product, adjust the volume to the proper level. Setting too loud a volume or using the earphone continuously for a long period of time might adversely affect your ears. Also, raising the volume too high might prevent you from hearing sounds around you, which might in turn lead to a traffic accident at a railroad crossing or pedestrian crossing.

When adjusting the volume with an earphone, etc. inserted into the product, raise the volume a little at a time. If you raise the volume too much from the outset, sudden loud noise from the earphone, etc. might adversely affect your ears.

When using an AC adapter or external device, insert/remove the connector straight to/from the terminal. Make sure the orientation of the connector. Unless it's correct, it may cause damage or a fault.

Main unit

DANGER

Do not puncture the product with a nail, hit with a

hammer or step on the product. Doing so might

cause fire or damage.

Do not let pets bite product. Doing so might cause

leakage of battery fluid, overheating, rupture,

ignition, fire, injury, etc.

Be sure to read the following hazards before use.

Safety Precautions

Page 68

Safety Precautions

WARNING

Do not use a cell phone while driving a car or riding a motorbike or bicycle. It might cause a traffic accident. Use of a cell phone while driving a car or motorbike is prohibited by law. Use of a cell phone while riding a bicycle may be punishable by some regulations.

Follow the instructions of each medical facility for the use of cell phones on their premises. Power off the product in a place where the use is prohibited. Failure to do so may affect electronic equipment and electronic medical equipment.

Turn off the product or put it in Airplane mode before boarding an airplane. Use of cell phones on board is restricted. Follow the instructions of each airline. Failure to do so may adversely affect on-board electronic equipment. Prohibited acts related to cell phone usage on an airplane may be punished by law.

Be sure to read the following warnings before use.

When using the product near an implanted

pacemaker, implanted cardioverter-defibrillator or

other electronic medical device, radio waves

might affect these units and devices. So, please

observe the following.

1. Those with an implanted pacemaker or implanted cardioverter-defibrillator should carry or use the product at least 15cm away from the pacemaker or cardioverter-defibrillator.

2. Turn the product off or set "Airplane mode" when it may be difficult to keep at least 15cm away such as in a situation you cannot move freely, since there may be people with a cardiac pacemaker or implanted cardioverterdefibrillator nearby.

3. When a medical institution has laid down designated areas where use of the product is prohibited or is not allowed to be brought in, abide by the instructions of that medical institution.

4. When using electronic medical devices other than an implanted pacemaker and implanted cardioverter-defibrillator outside a medical institution (e.g. home medical treatment), check individually with the manufacturer of the electronic medical device regarding the influence of radio waves.

Page 69

Stay alert to your surroundings when calling, messaging, browsing the Internet, shooting photos, playing games or listening to music. Failure to do so might cause a fall or traffic accident.

Do not light the photo light/simple light in front of a person's eyes. Do not gaze at the photo light/ simple light emitting part when the photo light is lighted. Doing so might cause impairment of eyesight, etc. Be especially careful not to shoot small children from a very close distance.

Do not light the photo light/simple light toward a driver of a car, motorbike or bicycle. If dazzled by the light, the driver might become unable to drive and cause an accident.

Sometimes, very rarely some people demonstrate symptoms such as temporary muscle spasms, loss of consciousness, etc. by watching repeatedly flickering screens. Those with a past history of this should consult with a physician beforehand.

Chemical hardened glass is used for the display of the product. In case it is broken, do not touch the broken part. Doing so might cause injury by the broken part. Contact an au shop or Keitai Guarantee Service Center.

Do not hold speaker portion close to ears. Doing so might allow large-volume sound to impair hearing.

Safety Precautions

Page 70

Be sure to read the following cautions before use.

Safety Precautions

CAUTION

Use of the main unit in an automobile sometimes affects on-vehicle electronic devices, though this rarely happens. If this happens, stop use since this may impair safe travel.

If you feel any abnormality with your skin, immediately consult a dermatologist. Itching, rashes, eczema, etc. sometimes occurs depending on your physical constitution and condition. The materials of parts used on the product are as follows.

Main unit of miraie

Part Material Surface

Exterior case, Back cover, Power key, Volume up/down key, Personal alarm, Camera periphery parts Display Chemical

Lens for the camera PMMA resin Hard coating Earphone terminal PA resin －

PC resin Acrylic UV hard

hardened glass

treatment

coating

Antifouling treatment

Battery pack

Part Material/Surface treatment Exterior PC resin Labeling PET Terminals Gold plating

Do not bring the product close to magnetized objects such as cash cards, floppy disks, credit cards, and prepaid cards. Doing so might result in

loss of recorded information.

Do not allow liquids, metal objects, burnable items, and other foreign matter to get inside the earphone microphone terminal, the external connection terminal, the microSD memory card slot or the au Micro IC Card (LTE) slot. Failure to do so might cause fire, electric shock, injure or a fault.

Do not swing the product around by holding the earphone or the hand strap, etc. Doing so might cause an accident or damage.

If you have a weak heart, be careful when setting the incoming vibration and ringtone volume to prevent adverse effects on your heart.

Page 71

Do not place the product directly on sand at a beach, etc. Sand or other small particles might get inside the microphone or speaker, causing the volume to drop. If sand gets inside the product, it might cause overheating or a fault.

When using the product for calling or data communication, be careful not to keep the product in direct contact with your skin for a prolonged period, or not to cover the product with paper, cloth, bedding, etc. The main unit might get hot, causing fire, injure, burns or a fault.

Do not let the personal alarm sound close to ears. Doing so might impair hearing.

Battery pack

(The battery pack is a lithium-ion battery)

The battery pack is not fully charged at the time of purchase. Charge before using the product.

DANGER

Do not short-circuit the plus (+) and minus (-) terminals on the battery pack.

Install the battery pack in the product in the correct orientation. Installing in an incorrect orientation might cause rupture, fire, or overheating. If you have difficulty connecting the battery pack, do not force it, and confirm the location of the contacts before connecting.

Do not nail, hammer, or step on battery pack. Doing so might cause ignition or damage.

Do not insert tweezers or other metal objects in gaps to remove battery pack. Doing so might cause battery pack ignition, rupture, overheating, or leakage.

Be sure to read the following hazards before use.

Safety Precautions

Page 72

Safety Precautions

When carrying or storing, ensure that terminals do not contact with anything metal (necklace, hairpins, etc.). Short-circuiting might cause overheating, ignition, fire, leakage, or malfunction.

Do not disassemble, alter, or directly solder. Doing so might cause battery fluid to spurt, causing blindness if entering eyes, etc., or overheating, ignition, rupture, or injury.

Do not use a battery pack that has been dropped, stepped on, damaged, or that has leaked. Doing so might cause overheating, ignition, leakage, malfunction, or injury. Immediately distance battery from any source of flame if battery is leaking or emitting an odor. Failure to do so might cause the leaked liquid to catch fire resulting in fire, liquid leakage, injure or rupture.

Do not expose battery pack to water/seawater, pet urine, etc. Exposure of battery pack might cause overheating, rupture, ignition, malfunction, or injury. If accidentally dropped in water or other liquid, immediately turn the power off, remove the battery pack, and contact an au shop or Keitai Guarantee Service Center. Do not charge an exposed battery pack.

If the leaked liquid gets on your skin or clothes, immediately rinse it off with water to avoid injury. If the liquid gets into your eyes, do not rub, but after wash your eyes with water, and immediately consult a doctor to avoid the risk of losing your eyesight. If the liquid gets on a device, wipe it off without touching it.

The battery pack is a consumable item. If the performance of the battery pack does not recover (e.g. the usable time after each charge has become extremely short), the battery is at the end of service life, so stop use. Replace with a specified battery pack. Failure to do so might cause overheating, fire, rupture or leakage. The life time of the internal battery depends on the usage etc.

Do not let pets bite battery pack. Doing so might cause leakage of battery fluid, overheating, rupture, ignition, fire, injury, etc.

Page 73

Charging equipment

WARNING

Do not use at other voltages than the specified power supply voltage. Doing so might cause ignition, fire, overheating, electric shock or injury.

•AC adapter (sold separately) that can be charged overseas: 100 VAC to 240 VAC

•Common DC Adapter 03 (sold separately): 12/24 VDC (for negative grounded vehicles only)

Firmly insert a power plug of specified charger into the power outlet or cigarette lighter socket down to the base of its pins. Incomplete insertion of the power plug might result in electric shock, overheating, ignition, fire or injury. Do not use when a specified charger is damaged, or a power outlet or a cigarette lighter socket is loose.

If the fuse in the common DC Adapter 03 (sold separately) blows, replace it with a fuse of the specified type (250 V, 1 A). Replacing with a different type of fuse might cause overheating or ignition. (For information about fuse replacement, carefully read the manual for the common DC Adapter 03 (sold separately).)

Be sure to read the following warnings before use.

Do not damage, modify, twist, pull or place a heavy object on the cable of the specified charger. Do not use a damaged cable. Doing so might cause an electric shock, short circuit, fire or injury.

Do not let your hands, fingers and other parts of the body touch the connection terminals or the earphone microphone terminal. Doing so might cause electric shock, injury or a fault.

If you hear thunder, do not touch the power plug. Doing so might cause an electric shock as a result of a lightning strike.

Before cleaning the specified charging equipment, unplug its power plug from the outlet or cigarette lighter socket. If the plug remains plugged in when you clean the equipment, it might cause a short circuit.

Wipe off dust on the power plug. Failure to do so might cause fire, burns or electric shock.

Install and position in-car devices where they do not hinder driving or safety equipment such as airbags. It might cause a traffic accident. Install in-car devices following the instructions of their manuals.

Safety Precautions

Page 74

Safety Precautions

When the AC adapter is not to be used for a long time, disconnect the specified charger's power plug from the power outlet. Doing so might cause fire or a fault.

Do not use in places subject to direct splashing with water, pet urine or other liquids. Doing so might result in faults and injure resulting from overheating, fire, electric shock, or short-circuiting of electronic circuits. In the event that the product is splashed with liquid, immediately disconnect the specified charger's power plug.

CAUTION

Do not use in humid places such as bath areas, or connect/disconnect the specified charger with wet hands. Doing so might cause electric shock, injure or a fault.

Charge the battery in a stable place. If placed on

an inclined surface or wobbly stand, the product

might fall causing injury or damage. Pay careful

attention while vibrator is set. In addition, do not

cover or wrap the product with a cloth or bedding.

Doing so might cause a fire, injure or a fault.

When unplugging the specified charging

equipment's power plug from the outlet or

cigarette lighter socket, hold and pull the power

plug. If you pull the cable, the cable might be

damaged.

Do not use the common DC Adapter 03 (sold

separately) with the car engine stopped. Doing so

might result in draining of the car battery.

Do not leave the product connected to specified

charging equipment while the battery pack is

removed. Doing so might cause ignition, electric

shock, or injury.

Be sure to read the following cautions before use.

Page 75

If you feel any abnormality with your skin, immediately consult a dermatologist. Itching, rashes, eczema, etc. sometimes occurs depending on your physical constitution and condition.

au Micro IC Card (LTE)

WARNING

Do not put the au Micro IC Card (LTE) in a cooking

apparatus such as a microwave oven or a

pressure vessel. Doing so might cause melting,

overheating, fuming, loss of data or a fault.

Be sure to read the following warnings before use.

CAUTION

Be careful when attaching/removing the au Micro

IC Card (LTE). Doing so might injure your hands

or fingers.

Use only the devices specified by the Company to

insert the au Micro IC Card (LTE) in. Using a

device not specified by the Company might cause

loss of data or a fault.

For the specified devices, contact an au shop or

the Customer Service Center.

Do not disassemble or modify the au Micro IC

Card (LTE). Doing so might cause loss of data or

a fault.

Be sure to read the following cautions before use.

Safety Precautions

Page 76

Safety Precautions

Do not use or leave the au Micro IC Card (LTE) in hot places such as by the fire or a heater. Doing so might cause melting, overheating, fuming, loss of data or a fault.

Do not throw the au Micro IC Card (LTE) into a fire or heat it. Doing so might cause melting, overheating, fuming, loss of data or a fault.

Do not touch the IC (metal) part of the au Micro IC Card (LTE) or short-circuit it. Doing so might cause loss of data or a fault.

Do not drop the au Micro IC Card (LTE) or subject it to strong impact. Doing so might cause a fault.

Do not fold, bend or place a heavy object on the au Micro IC Card (LTE). Doing so might cause a fault.

Do not wet the au Micro IC Card (LTE). Doing so might cause a fault.

Do not scratch the IC (metal) part of the au Micro IC Card (LTE). Doing so might cause a fault.

Do not store the au Micro IC Card (LTE) in dusty places. Doing so might cause a fault.

Do not store the au Micro IC Card (LTE) in places exposed to direct sunlight or hot and humid places. Doing so might cause a fault.

Store the au Micro IC Card (LTE) out of reach of

small children. Failure to do so might cause injury,

etc. if they accidentally swallow and choke on it.

Page 77

Handling precautions

These precautions are provided to ensure that performance can be fully demonstrated. Thoroughly read these precautions to ensure correct use.

Precautions common to the main unit, battery pack, back cover, charging equipment, au Micro IC Card (LTE), peripheral devices

● Do not apply excessive force to the product during use.

Be sure not to put the product into a tightly packed bag or place a heavy object on the product in a bag. Sitting on the product in your pocket might damage the display or internal circuit board resulting in a malfunction. Keeping an external device connected to the external connection terminal or earphone microphone terminal might damage the connector resulting in a malfunction. Such damage and malfunction are not covered by the warranty, even if there is no external damage.

● To ensure the water resistance (equivalent to IPX5 and

IPX7) of the product, use the product with a specified back cover tightly closed. Note that water resistance is not guaranteed in every usage condition. Do not allow water to get inside the product or splash water on the battery pack, charging equipment, or optional accessories. Do not open/close the back cover in the rain or with any water on the surface of the product. Doing so might allow water intrusion resulting in inter Malfunction determined to be caused by such water intrusion are not covered by the warranty.

● Do not use the product in extremely hot, cold or humid

places. (Use within an ambient temperature range of 5℃ to 35℃ and humidity range of 35% to 85%.)

•Charging equipment

•Peripheral devices

● Do not use the product in extremely hot, cold or humid

places. (Use within an ambient temperature range of 5℃ to 35℃ and humidity range of 35% to 90%. Temporary use at 36℃ to 40℃ is allowed.)

•Main unit

•Battery pack/au Micro IC Card (LTE) (attached to the main unit)

● Do not use in places subject to lots of dust or vibration.

nal corrosion.

Safety Precautions

Page 78

● Clean the connection terminals and earphone

microphone terminal with dry cotton swabs, etc. every now and then. Soiled terminals might cause poor connection. Do not exert a strong force to clean the connection terminals or earphone microphone terminal to prevent deformation.

● Clean the product with a dry soft cloth (such as the type

used for eyeglasses). Do not rub it roughly with a dry cloth. The display may be damaged. Drops of water or dirt left on the display may cause stains. Wiping the product using alcohol, thinner, benzine, detergent, etc. might erase the printing on the outer casing or cause

Safety Precautions

discoloration.

● Use as far away as possible from land-line phones, TVs

and radios. Use nearby might affect them.

● The product may become warm while charging or during

other operations, depending on the situation, but this is not abnormal.

● When the product is used by a child, parents or

guardians should thoroughly read the "Basic Manual" (this manual) and teach the child how to use it.

● Turn off the power of the product before removing the

battery pack. If you remove the battery pack with the power on, saved data might be altered or lost.

● The personal alarm is not an absolute guarantee of crime

prevention or safety. The Company takes not responsibility for damages resulting from theft, accident, trouble, etc.

● The personal alarm sounds at a volume of approximately

95 dB (decibels) when at a distance of about 10 cm from the speaker. Surroundings may prevent the personal alarm from being audible to other nearby persons.

● Do not put stickers on the product. Sound may not be

emitted or voice sound may not be delivered to the party.

Main unit

● Before use, be sure to confirm that the personal alarm

will sound.

● Do not forcefully press, tap or intentionally subject the

display to strong impact. Doing so might cause scratching or damage.

● Do not forcefully press your fingernails, sharp objects or

hard objects against keys or display surface. Doing so might cause scratching or damage. The touch panel is designed to be lightly touched by fingers. Do not apply strong pressure with your fingers or sharp-pointed objects (such as fingernails, ballpoint pens and pins) on the touch panel. Touching the panel may not work in the following cases. Note that it may cause malfunction.

•Operation with gloved hands

•Operation with fingernails

•Operation with foreign object on the screen

•Operation with protective sheet or seal on the screen

•Operation with a water drops or dew condensation attached on the touch panel

•Operation with wet or sweaty fingers

•Operation under water

Page 79

● Never use modified au cell phones. Use of a modified

device violates the Radio Law. This product has acquired the certification of conformity with technical regulations for the specified radio station based on the Radio Law, and the "Technical Conformity Mark " is checkable on the product as a certificate. Home screen → [Settings] → [About phone] → [Compliance information] If the screws of the product are removed and modifications are made to the internal components, the certification of conformity with technical regulations will become invalid. Do not use the product with the certification invalid, as it is a violation of the Radio Law.

● To prevent unlawful modification, the product has been

designed so that it cannot be easily disassembled. Modifying the product is prohibited by the Radio Law.

● Contents saved in the product, such as contacts, mails

and favorites, might be altered or lost in an accident, fault, repair or mishandling. Be sure to keep a copy of important contents. Note that Company assumes no responsibility for any damages or lost profits resulting from altered or lost contents.

● Note that content data (both charged or free content)

saved with the product cannot be returned to the customer when the product is replaced for repair of a fault, for example.

● The product uses liquid crystal for its display. The display

response speed may become slow when the ambient temperature is low, which is due to the property of liquid crystal and not a malfunction. Display response speed will return to normal at room temperature.

● Although the display used on the product is made using

high-precision technology, some pixels (dots) might be lit or out at all times. This is not a malfunction.

● Take care not to inconvenience people around you when

you use the product in a public place.

● You are recommended to store copies of individual data

such as photos you took, videos and music on your PC by sending each file as mail attachment, etc. Note, however, that you may not be able to make copies of any copyrighted data even by the above-mentioned means.

● Take care not to place magnetized items such as

magnetic cards, speakers and TV sets near the product, as it might cause malfunction. Putting a strong magnetism close to the product might cause false operation.

● Although the earphone microphone terminal is water-

resistant, you may not be able to use it by inserting a plug when water remains. Swing the product to remove water so that water does not remain in the earphone microphone terminal, then dry it before using.

Safety Precautions

Page 80

● When you put the product in your pocket or bag, take

care so that the display does not come in contact with metal objects or other hard objects. Doing so might cause scratching or damage. Also, be careful not to scratch or damage the display by using a strap whose metal or other hard part comes in contact with the display.

● When suddenly brought into a warm place from a cold

place, or when in a humid location, or when used where temperature suddenly changes (e.g. near the air discharge port of an air conditioner), water droplets (i.e. condensation) sometimes are formed inside the product.

Safety Precautions

Note that when used under conditions such as this, the humidity might cause corrosion or a fault.

● When wiping the display, wipe with a soft, dry cloth. Use

of a moistened cloth, glass cleaner or other similar liquid might cause a fault.

● When connecting/disconnecting the external device to/

from the external connection terminal or the earphone microphone terminal, make sure that the connector or plug of external device is straight with the external connection terminal.

● Note that applying unnecessary force with the external

connection terminal or the earphone microphone terminal connected to the external device might cause damage.

● Do not discard the product together with regular trash.

Please cooperate in the collection of the product when it is no longer needed to protect the environment and effectively use resources. Old product is collected at au shops and other places.

● Insert only a microSD memory card into the memory card

slot on the product.

● Do not exert excessive force when attaching/removing a

microSD memory card. Doing so might injure your hands or fingers.

● While writing/reading data to/from a microSD memory

card, do not subject the product to vibration or impact, remove the battery pack, or turn off the power. Doing so might cause loss of data or malfunction.

● Take care not to cover the microphone with your fingers

during a call. The other party may not be able to hear your voice clearly.

● When using handsfree call, note that the speaker may

emit loud sound. Take care to keep the speaker at a safe distance from your ears.

● Do not cover the sensor with your finger or put a sticker

on it. Doing so may hinder the sensor for detecting the ambient light level and functioning correctly.

● Do not put a sticker, etc. on the proximity sensor. Doing

so may cause the sensor to malfunction and make the display always turned off while receiving a call or during a call.

Page 81

Touch Panel

● Use your finger to operate the touch panel. Do not use

ballpoint pens, pencils or other sharp-pointed objects. Using such objects does not only hinder correct operation of the touch panel, but also might cause scratching or damage to the display.

● Do not put stickers or sheets (e.g. commercially available

protective films, peep prevention sheets) on the display. Doing so might hinder correct operation of the touch panel.

● Do not operate the touch panel with fingernails. Doing so

might result in split nails or jammed fingers.

● If the display surface is dirty or wet with sweat or water, it

may not function correctly. In such case, wipe the display surface with a dry, soft cloth.

● When carrying the product in your pocket or bag, take

care not to put the touch panel close to metals or other conductive materials, as it might cause false operation of the touch panel.

Battery pack

● Leaving the product in extremely high-temperature or

low-temperature conditions, such as in a closed automobile in the summer, lowers battery pack capacity and shortens usable time. Battery life is also shorter. Use the product at room temperature as much as possible.

● If not using the product for an extended period, remove

the back cover from the product and remove the battery pack and store in a place free from high temperature and humidity.

● Charge the battery before using the product for the first

time after purchase, or if you have not used the product for a long time.

● The battery pack is a consumable item. If the

performance of the battery pack does not recover even after charging, the battery is at the end of service life. Replace with a specified battery pack. Service life depends on conditions of use, etc.

● Do not dispose of with ordinary waste. Cooperate with

collection of old battery packs for environmental conservation and effective use of resources. Old battery packs are collected at au shops and other places.

● Battery packs may bulge at the end of their service life

depending on conditions of use. This is a characteristic of lithium-ion batteries and is not a safety hazard.

Safety Precautions

Page 82

Charging equipment

● When the charging equipment is not to be used, unplug

the power plug of the specified charger from the outlet or cigarette lighter socket.

● Do not wrap the power cord of specified charger around

the adapter unit. Doing so might cause electric shock, fault, injure, overheating or fire.

● Do not forcibly bend the charging equipment's plug or

the connection between the connector and power cord. Doing so might cause electric shock, fault, injure, overheating or fire.

Safety Precautions

au Micro IC Card (LTE)

● The au Micro IC Card (LTE) is lent to you by au. In case

of loss or damage, the card will be replaced at your expense. When a malfunction is suspected, or in case of theft or loss, contact an au shop or PiPit.

● Do not forcibly remove or insert the au Micro IC Card

(LTE). Be careful not to exert excessive force when inserting the card into your au cell phone.

● You are responsible for any damage caused by inserting

your au Micro IC Card (LTE) into some other IC card reader, etc.

● Keep the IC (metal) part of your au Micro IC Card (LTE)

clean. Wipe the card with a dry, soft cloth (such as for cleaning eyeglasses) for cleaning.

● Do not put stickers, etc. on the au Micro IC Card (LTE).

● Do not insert the IC card held in a card adapter. Doing

so may cause malfunction.

Camera

● When using the camera, follow common rules of etiquette

regarding camera use.

● Image data might be altered or lost due to malfunction,

repair or mishandling of this product. The Company takes no responsibility for recovery of altered or lost data, damages resulting from altered or lost data, and lost profits.

● When photographing important occasions (such as a

wedding), take a trial shot and check the shot image to make sure it is correctly shot.

● Do not use the camera for recording commercially

available books or information of which photographing is not allowed.

● Do not leave the camera lens exposed to direct sunlight.

Imaging elements might be discolored or burnt.

Page 83

Music and videos

● Do not listen to music or watch videos while driving a car

or motorbike, or riding a bicycle. Use of cell phones while driving a car or motorbike is prohibited by law. (Use of cell phones while riding a bicycle may also be punishable by law.) In addition, stay alert to the traffic around you even when walking. Surrounding sounds may not be heard clearly, and gazing at the screen might distract your attention causing a traffic accident. Be especially careful at railroad crossings, on a platform, and at pedestrian crossings.

● Take care not to listen at ear-splitting volume for a long

time, as it might affect hearing.

● Be careful of sound leakage from earphones in trains or

other places with many people around you.

Copyrights and rights of portrait

● You are not allowed to copy, distribute, publish, modify or

edit the data you shot, recorded or downloaded using this product without the consent of the copyright holder, except for personal use, under the copyright law. In addition, do not use or modify portraits or names of other individuals without their consent, as it might infringe on rights of portrait. Note that shooting and recording may be restricted at some live performances, shows and exhibitions even for personal use.

● Be careful about the copyright and portrait right when

posting photos you shot, etc. on Internet homepages.

Backup content on the product

● Please back up important content registered to the

product or downloaded for the product from an outside source. Content recorded to memory on the product sometimes disappears or is altered by unexpected factors, such as static electricity or a fault, repair, mishandling, etc.

* How to make backups: Store important data such as contacts data,

music, shot photos and videos on microSD memory cards. You can also send files as mail attachment or transfer to your PC. Note, however, that there are some data that cannot be copied by using these means.

Safety Precautions

Page 84

Available Security Codes

The product has various security codes that you can use. The available security codes are as follows. Do not forget the various security codes that are set as they are necessary for various operations and contracts.

Security code

Example of usage

Safety Precautions

Initial value A four digit number chosen by the

Security setting on the start screen

Example of usage Initial value Slide

PIN code

Example of usage Initial value 1234

① To do remote operation of voice mail

and call forwarding services from a landline phone

② To use the Customer Service Center

and to do various inquiries, applications, and modifications on the au homepage

customer and noted on the application form

To set and disable security

To prevent unauthorized use of the au Micro IC Card (LTE) by third parties

PIN code

PIN code

To prevent unauthorized use of the au Micro IC Card (LTE) by a third party, you can set the product to require PIN code entry every time the power is turned on. You also need to enter PIN code when setting whether the PIN code entry is required. If the PIN code is incorrectly entered three times consecutively, the PIN code will be locked. You can unlock the PIN code using PUK code.

•PIN code is "1234" and PIN code entry was set to not be required at the time of purchase. You can change PIN code to any four- to eight-digit number, and set the PIN code entry to be required as necessary.

PUK code

In case the PIN code is locked, you can unlock it by entering the PUK code.

•PUK code is an eight-digit number given at the time of purchase, which is printed on the back side of the plastic card on which your au Micro IC Card (LTE) is attached.

•After entering the PUK code, you need to set a new PIN code.

•If the PUK code is incorrectly entered ten times consecutively, contact an au shop, PiPit or the Customer Service Center.

•PIN code is not reset by initializing the product.

Page 85

【Password entry ﬁeld】

au ID account ID

au ID account password

Security (start screen) Lock: Lock No.

Security (start screen) Lock: Pattern

Security (start screen) Lock: Password

Parental password

Safety Precautions

Page 86

Notes on water, dust, and shock resistance

This product has water resistance equivalent to IPX5*1 and IPX7*2, as well as dust resistance equivalent to IP5X*3 on the condition that a specified back cover is securely attached. This product has a shock-resistant property conforming to the MIL standard*4 (based on in-house testing). Specifically, you can make calls holding the product with wet hands in the rain (less than 20 mm per hour) without an

Safety Precautions

umbrella, as well as use the product in a place with water such as a bathroom or kitchen. Before using the product, thoroughly read "Important items to remember before use" and "Tips for comfortable use" to ensure correct use. Failure to follow the contents described in these sections may cause the intrusion of water, sand or other foreign material, resulting in overheating, ignition, electric shock, injury or a fault.

*1 IPX5 equivalent means that the product will maintain its operability as a

phone even if it is sprayed with water from a 6.3 mm diameter nozzle at a distance of about 3 meters for more than 3 minutes at a rate of about 12.5 liters per minute from any direction.

*2 IPX7 equivalent means that the product will maintain its operability as a

phone with no water getting inside the main unit even if it is gently submerged in a tank of still tap water at room temperature to a depth of 1 meter for about 30 minutes.

*3 IP5X equivalent means that the product will securely maintain its

operability as a phone even after it has been placed in an apparatus with grit and dust of diameters of 75 μm or less and shaken for 8 hours.

*4 MIL standard conformity: Drop testing (in which the product is dropped in

26 directions from a height of 1.22 m) was conducted in accordance with MIL-STD-810G Method 516.6-Shock defined by the U.S. Depar Defense. Shock-resistant property of this product is based on the assumption that it is used in everyday life. Therefore, the product might break if it receives an excessive impact such as being thrown or dropped forcibly. Note also that the product gets scratches, etc. by falling impact even though its functionality of the main unit remains intact.

Since operation of the product on each usage scene was

tment of

confirmed based on the above assumption, proper operation of the product in every possible condition during actual use is not guaranteed. Malfunctions determined to be caused by mishandling by the customer are not covered by the warranty.

Page 87

Important items to remember before use

● Close the specified back cover firmly.

•Water resistance is only effective when the covers are securely closed.

•Just a small particle (a hair, a grain of sand, etc.) on the seals can cause water leak.

•Never open/close the specified back cover if your hands or the product are wet. Do not insert an earphone (sold separately) when water remains in the earphone microphone terminal.

Attaching the specified back cover

Attach the specified back cover on the main unit, then press along the back cover in the direction from ① to ② following the arrows leaving no gaps, and then press at ③ firmly.

①

③

②

● Do not immerse the product in water with soap,

detergent or bath salts in it.

● Do not immerse the product in seawater, a swimming

pool or hot spring.

● Do not immerse the product in any liquid (alcohol, etc.)

other than water.

● Do not place the product directly on the sand at a

beach, etc. Sand or other small particles might get inside the microphone, speaker, earphone microphone terminal, or external connection terminal, causing the volume to drop. If sand or other particles get inside the product, it might cause overheating or malfunction.

● Do not use the product underwater.

Safety Precautions

Page 88

● Do not leave the product in a humid place such as a

bathroom or kitchen for an extended period of time.

Soap/ detergent/ bath salts

Safety Precautions

Seawater Swimming pool Hot spring Sand/mud

Tips for comfortable use

● Water may still remain in gaps in the product after

draining water. Shake well to drain water. In particular, be sure to drain water from around keys, the specified back cover, earphone microphone terminal, and external connection terminal.

● Even after the water is drained, the inner parts might be

still wet. Although you can use the product, do not place it near things that must not get wet. Take care not to wet your clothes, bag or contents of the bag.

● Drain water if it becomes temporarily hard to hear the

sound due to water remaining in the microphone.

Notes on various usage scenes

You can make calls holding the product with wet hands in the rain without an umbrella.

•The rain in this case means a moderately-heavy rain (less than 20 mm per hour).

•Water drops on the display might cause errors in the touch panel operation.

•Never open/close the specified back cover if the product is exposed to rain, or your hands ar

You can make calls holding the product with wet hands after a shower.

•Avoid spraying the product with high-pressure water, as the product is not designed to withstand high water pressure.

e wet.

Page 89

You can wash the product under a mild flow (up to 6 liters per minute) of tap water at room temperature (5℃ to 35℃) at a distance of about 10 cm from the faucet or showerhead.

•Do not spray the product with high-pressure water or submerge it in water for extended periods of time, as the product is not designed to withstand high water pressure.

•Wash the product with your hands making sure that the specified back cover is firmly closed. Do not use a brush or sponge.

•Do not wash the product in a washing machine or ultrasound bath.

•Do not splash the product with or immerse it in soap water, detergent water, etc. other than tap water.

You can use the product in a bathroom.

•Although you can make calls with wet hands, do not immerse the product into a bathtub. The product is not resistant to hot temperatures.

•Do not use the product in a bathroom for an extended period of time. The product is not moistureproof.

•Do not immerse the product in hot spring water, soap water, detergent water, or water with bath salts in it. Also, do not use the product underwater. Doing so might cause a fault.

•Extreme changes in temperature cause condensation. Wait until the product reaches room temperature before you bring the product from a cold place into a warm bathroom.

•If condensation occurs inside the display, leave the product at room temperature for a while until the condensation is cleared.

•Do not splash the product with hot water. The product is not resistant to hot temperatures.

•Do not immerse or drop the product in pool water. Also, do not use the product underwater.

•If the product gets splashed with pool water

, immediately rinse it off with tap water* in room temperature, because pool water contains chlorine for disinfection. To wash the product, do not use a brush, etc.

* Mild flow (6 liters per minute or less)

Safety Precautions

Page 90

You can use the product in the kitchen and other places where water is used.

•Do not splash the product with or immerse it in soap water, detergent water, seasonings, juices, etc. other than tap water.

•Do not immerse the product in or splash it with boiling water. The product is not resistant to hot temperatures.

•Do not place the product where it gets extremely hot or cold such as near a stove or in a refrigerator.

Safety Precautions

Common precautions

Specified back cover

Make sure that the specified back cover is firmly closed. Just a small particle (a hair, a grain of sand, etc.) on the contact surfaces can allow intrusion of water. Do not remove/attach the specified back cover with gloved hands. Just a small particle (a hair, a grain of sand, etc.) on the contact surfaces can allow intrusion of water. Wipe off any minuscule droplets of water or dirt with a clean dry cloth before closing the cover. If the specified back cover is deteriorated or damaged, the water resistance cannot be maintained. In such case, contact an au shop near you.

If any liquid other than plain water gets on the product

If any liquid other than plain water (e.g. seawater, detergent, alcohol) gets on the product, immediately rinse it with plain water. You can wash the product under a mild water flow (up to 6 liters per minute) from a tap or shower at room temperature (5℃ to 35℃) at a distance of about 10 cm from the faucet or showerhead. If the product gets dirty, wash it with your hands holding the specified back cover so that it does not open. Do not use a brush.

Page 91

After the product gets wet

If the product gets wet, drain water, and without removing the specified back cover, wipe the main unit and specified back cover with a clean dry cloth. In cold climates, water on the product may freeze. Using the product with frozen water on it may cause malfunction. Do not leave the product without wiping off the water. (No special measures against condensation have been implemented in this product.)

Rubber seals

The rubber seal around the specified back cover is important for maintaining water resistance. Do not damage or remove the rubber seal. When closing the specified back cover, take care not to get the rubber seal caught. Forcibly closing the cover with the rubber seal caught may damage it resulting in loss of water resistance. Just a small particle (a hair, a grain of sand, etc.) on the seal can allow intrusion of water. If any liquid other than plain water (e.g. alcohol) gets on the rubber seal, it may cause deterioration in durability. Do not insert sharp objects into gaps around the specified back cover. Doing so might damage or deform the product or damage the rubber seal, allow intrusion of water. It is recommended to replace parts used for maintaining water resistance once every two years regardless of whether any abnormality is present. For information on part replacement, contact an au shop near you.

Charging

Never charge the battery if the product is wet. The supplied and optional accessories are not waterresistant.

Water resistance

Do not use the product in places where it may be sprayed with high-pressure water (e.g. near a faucet or showerhead) or submerge it in water for extended periods of time, as the product is not designed to withstand high water pressure. Also, do not expose the product to a water flow stronger than the specified flow rate (i.e. 6 liters per minute from a faucet or showerhead, at which you might even feel pain in the skin). Doing so might cause a fault, even though the product has water resistance equivalent to IPX5. Do not wash the product in a washing machine or ultrasound bath. The product does not float on water.

Heat resistance

Do not use the product in places where boiling water may splash on it, in saunas or near hot air (e.g. hairdryer). The product is not resistant to hot temperatures.

Safety Precautions

Page 92

Draining water after wetting the product

As some parts of this product are not watertight, if you use the product after it gets wet, water remaining in those parts might wet your clothes or bag, or the sound might become hard to hear. Follow the steps below to drain water.

Wipe water thoroughly on the surface of the

product with a clean dry cloth without waste textiles

Safety Precautions

Shaking the product

① Hold the product firmly and shake it in the direction

of arrows until water does not come out.

hen shaking the product, stay alert to your surroundings.

* W

* Be careful not to have the product pop out, and hold it firmly to

drain water.

From earphone microphone terminal/

external connection terminal:

20 times or more

② Wipe drained water.

* The microphone, speaker, earphone microphone terminal, and the

external connection terminal are particularly hard to drain water from. Hold the product so that these parts are downward and press to wipe off.

③ Place the product on a dry towel or cloth and leave it

From speaker:

20 times or more

at room temperature.

Press the product gently to clean dry cloth

without waste textiles, and wipe off water remained in the gaps in the microphone, speaker, earphone microphone terminal, external connection terminal, etc.

Page 93

Leave the product for one hour or more at

room temperature to dry after removing drained water thoroughly

If water is not adequately removed, the volume of the personal alarm may be affected. Even after you take these procedures, water may remain on the product. Do not place the product near things that you do not want to wet. Also, take care not to wet your clothes, bag, etc.

Precautions on charging

The supplied and optional accessories are not waterresistant/dust-resistant. Be sure to check the following points before and after charging.

•Never charge the battery if the product is wet. Doing so might cause electric shock or short circuit resulting in a fire, burns or a fault.

•Check that the product is not wet. If you are charging the battery just after the product gets wet, drain water well and wipe the remaining water off with a clean dry cloth before connecting a microUSB plug in the external connection terminal.

•Do not touch the specified charging equipment with wet hands. Doing so might cause electric shock.

•Do not splash water over the specified charging equipment. Do not use it near water, such as in a bathroom, shower room, kitchen or washroom. Doing so might cause fire, electric shock, injure or a fault. Do not bring it into a bathroom, etc. even when you are not charging with them. Doing so might cause fire, electric shock, injure or a fault.

Safety Precautions

Page 94

Notes on using Bluetooth®/ Wireless LAN (Wi-Fi®) function

•The 2.4 GHz band used by Wireless LAN (Wi-Fi®) and Bluetooth® devices is operated by various other devices. For this reason, the communication speed and connectable range may be decreased, or disconnection may occur, due to interference from other devices.

•Do not use this product in places where electromagnetic waves are generated or near electric products, AV and OA equipment, or other magnetized devices.

Safety Precautions

•Subjecting this product to magnetic or electrical noise might increase noise and prevent it from performing communications. (This product is particularly susceptible to noise when it used near a microwave oven.)

•Using this product near a TV, radio or similar appliance might cause reception interference and disrupt TV images.

•The searching might not be successful if there are multiple Wireless LAN (Wi-Fi®) access points near to the product or the same channel is being used.

•Use of cell phones on board is restricted. Follow the instructions of each airline.

•The communication speed and connectable range vary depending on the distance between communication devices, obstacles and the devices used.

Cautions on using 2.4 GHz band

The frequencies used by the Bluetooth® and/or Wireless LAN (Wi-Fi®) function of this product are in the 2.4 GHz band. In this frequency band, other similar wireless stations, in-plant wireless stations for mobile unit identification that require a license to use, such as factory production lines, specific small power wireless stations that do not require licenses, amateur wireless stations (collectively called "other wireless stations" from here on) are operated in addition to home electrical appliances such as microwave ovens, devices for industrial, scientific and medical devices.

1. Before using the product, make sure that "other wireless stations" are not in operation nearby.

2. In the event that instances of radio wave interference have occurred between the product and "other wireless stations", immediately either relocate the product or stop operation of the device (stop the emission of radio waves).

3. If you are unclear on any points or are troubled by anything, contact an au shop or the Customer Service Center.

•The connections between this product and all other Bluetooth® and Wireless LAN (Wi-Fi®) devices have not been confirmed. Therefore, connections with all Bluetooth® and Wireless LAN (Wi-Fi®) devices are not guaranteed.

Page 95

•This product supports security features for wireless communications that are compliant with the Bluetooth® and Wireless LAN (Wi-Fi®) standard specifications, but the security may not be sufficient depending on the usage environment and configuration. Be careful when making data communication using Bluetooth® or Wireless LAN function (Wi-Fi®).

•Wireless LAN (Wi-Fi®) has the advantage that it can be freely connected anywhere within the radio wave range, as it uses radio waves for exchanging information. At the same time, there is a risk that a malicious third party may obtain unauthorized access if security settings have not been configured. You are recommended to configure security settings before use at your decision and responsibility.

•The Company assumes no responsibility for leakage of data or information that may occur during Bluetooth®/ Wireless LAN (Wi-Fi®) communication.

•Since Bluetooth® and Wireless LAN (Wi-Fi®) functions use the same frequency band, using the both functions at the same may cause radio wave interference resulting in decreased communication speed or disconnection from the network. If connection fails, stop using either of the Bluetooth® and Wireless LAN (Wi-Fi®) functions.

Bluetooth® and Wireless LAN (Wi-Fi®) functions of this product use frequencies in the 2.4 GHz band.

•Bluetooth® function: 2.4FH1/XX1

2.4FH1/XX1

This product uses the 2.4 GHz band. FH-SS is used as the modulation scheme. The interference distance is about 10 m or less. Bands of mobile unit identification devices cannot be avoided.

•Wireless LAN (Wi-Fi®) function: 2.4DS4/OF4

This product uses the 2.4 GHz band. DS-SS and OFDM are used as the modulation schemes. The interference distance is about 40 m or less. This means that all bandwidths are used, and that band of mobile unit identification devices can be avoided. For use in an airplane, check with the airline company in advance.

Safety Precautions

Page 96

Notes on packet communication charge

•Since a constant Internet connection is possible with this product, packet communication may be performed automatically by some apps, resulting in high packet communication charges. Therefore, subscription to a packet flat-rate service/packet communication charge discount service is recommended.

•To browse homepages, download apps, communicate using apps, send/receive e-mails and configure various

Safety Precautions

settings, connection to the Internet is required, to which packet communication charge applies.

* Packet communication charge does not apply to Wireless LAN (Wi-Fi®)

connection.

Notes on applications

•Be sure to check the security of the app, then install it at your own risk. Some apps might cause virus infection, damage various data, and send out your location information, usage history or personal information stored in your cell phone via the Internet.

•The Company assumes no responsibility for any failures that might be caused by apps you have installed. Repair costs in this case may be charged even during the warranty period.

•The Company assumes no responsibility for any disadvantage brought to you or any third party by the apps you have installed.

•Insertion of a microSD memory card is necessary to use some apps.

•Some apps prohibit the product from entering sleep mode while they are active, or rapidly drain the battery while running in the background.

•Operational procedures and screen appearances of the apps preinstalled in this product and those installed by you are subject to change without notice as a result of version upgrade. In addition, operating procedures described in this manual may differ from the actual procedures.

Page 97

Appendix

Introduction of related accessories

Battery Pack (KYL23UAA) Back cover (KYL23TPA/KYL23TWA/KYL23TLA) 

Common AC Adapter 05 (0501PWA) (sold separately) 

Common AC Adapter 03 (0301PQA) (sold separately) 

Common AC Adapter 03 Navy (0301PBA) (sold separately) 

Common AC Adapter 03 Green (0301PGA) (sold separately) 

Common AC Adapter 03 Pink (0301PPA) (sold separately) 

Common AC Adapter 03 Blue (0301PLA) (sold separately) 

AC Adapter JUPITRIS (White) (L02P001W) (sold separately) 

AC Adapter JUPITRIS (Red) (L02P001R) (sold separately) 

AC Adapter JUPITRIS (Blue) (L02P001L) (sold separately) 

AC Adapter JUPITRIS (Pink) (L02P001P) (sold separately) AC Adapter JUPITRIS (Champagne) (L02P001N)

(sold separately) Common DC Adapter 03 (0301PEA) (sold

separately)



au Carrying Case F Black (0105FCA) (sold separately) 

au Carrying Case G Black (0106FCA) (sold separately)



au Carrying Case H Black (0107FCA) (sold separately) Portable charger 02 (0301PFA) (sold separately) microUSB cable 01 (0301HVA) (sold separately) 

microUSB cable 01 Navy (0301HBA) (sold separately) 

microUSB cable 01 Green (0301HGA) (sold separately) 

microUSB cable 01 Pink (0301HPA) (sold separately) 

microUSB cable 01 Blue (0301HLA) (sold separately)

◎ For the latest information on accessories, visit the au

homepage (http://www.au.kddi.com/english) or contact the Customer Service Center.

◎ Accessories on this page can be purchased from au Online

Shop (http://auonlineshop.kddi.com/). Purchase is subject

to stock availability.

Appendix

Page 98

How do I . . .? Q&A

When unsure what to do, or before you assume that the product is malfunctioning, check the following:

How do I . . .

How do I . . . What you should set/check Page Change settings as a parent Restrict applications that can be used Prevent inappropriate webpages from being displayed

Appendix

Allow use of specific webpages

Restrict exchange with contacts the child has been adding

Change settings with the parental settings menu. Set use restrictions with "Restrict apps".

Set the "Restrict access to website" filtering list. You can also restrict access to webpages based on the child's age. Set the "Restrict access to website" filtering list. You can allow access to individual URLs. Use "Restrict call/mail" to allow calling/e-mailing/SMS texting only with Contacts entries that have been allowed.

P. 27

P. 32

P. 34

. 31

How do I . . . What you should set/check Page Limit the child's overuse of the smartphone Prevent too much time gaming Prevent the child from using the smartphone at night Only allow connection to specific Wi-Fi networks Not allow inappropriate language to be entered

Confirm the child's current location Set restrictions when the smartphone is lost, etc.

Use "Available time per day"/ "Call time per day" to limit usage time and call time. Use "Available time per day"/ "Call time per day" to limit usage time and call time. Use "Restricted period for use" to set usable times of day.

Use "Restrict Wi-Fi" to restrict available Wi-Fi® access points.

Use "Detect the unsuitable word" to cause a confirmation to be displayed when inappropriate language is entered. Use 安心ナビ (Security Navi).

Use Lookout for au.

P. 33

P. 34

P. 35

－

Page 99

How do I . . . What you should set/check Page Cancel use restrictions temporarily in the event of a disaster, etc.

From a device (phone number) registered as an emergency contact, send an SMS to the product with "制限解除 (Cancel restriction)" entered in the text body.

* 安心ナビ（探す）(Security Navi (search for device)) and Lookout for au

require a fee.

P. 39

Troubleshooting

Symptoms What you should check Page Cannot turn on power

Cannot charge the battery pack

The power goes

off The power is going of the activation logo is displaying

Is the battery pack charged? P. 19 Is F pressed and held? P. 21 Is the charger connected correctly? Is the temperature of the product or battery pack high or low? Charging may stop due to the temperature of the product or battery pack. Are the specified accessories (adapter, etc.) used to charge? Is the battery pack fully charged? Is the battery pack fully

f while

charged?

P. 19

－

P. 19

Appendix

Page 100

Symptoms What you should check Page Cannot make calls

Is the power turned on? P. 21 Is your au Micro IC Card (LTE) inserted? Was the number entered correctly? (Was the area code entered?) After entering the number, was "Call" tapped? Are contacts restricted for calling or mailing?

Is call time restricted? P. 33 Cannot receive calls

Is signal strong enough? P. 47

Is the product out of the serv

area?

Is the power turned on? P

Appendix

Is your au Micro IC Card (LTE)

inserted?

Are contacts restricted for calling

or mailing?

Is call time restricted? P. 33 "

" (out of service area) appears

Is the product out of the service area or in an area where the signal is weak? Is the built-in antenna covered with finger etc.?

ice

P. 16

P. 49

P. 31

P. 47

. 21

P. 16

P. 31

P. 47

P. 9

Symptoms What you should check Page Cannot send/ receive e-mail/

Are contacts restricted for calling

or mailing? SMS Cannot connect by

Wi-Fi

Is there an adequate Wi-Fi®

signal?

Is the product or battery warm?

Functionality is sometimes

stopped by the temperature.

Are Wi-Fi

access points

restricted? The display/

Is Silent mode set? P. 48 incoming light lights/blinks but there is no ringtone Cannot operate key/ touch panel

Is the power turned on? P. 21

urn off the power and then turn it on again. Is usage time restricted? P. 33

" appears Is your au Micro IC Card (LTE)

inserted?

A message

The battery is almost dead. P. 19

such as charge the battery appears

P. 31

P. 47

－

P. 34

P. 21

P. 16
