Attwood Push/Pull Switch Three-Position User Manual

(+)

Post #2

Brass

Post #1 (Head)

Terminal Screw

Washer

(Bat.)

Brass

Nut

(+)

Fuse

(-)

12V Battery

Wire

Power Source

Switched Wire

(+)(-)

Switched Wire

(-)

Figure 1

OFF

Basic Operation

Post #1-(ON)

Panel:

3/8"

(10mm) Dia.

1" (25mm) Max

2nd Position:

Accessory #2

Chrome

Nut

Chrome

Handle

(+)

1st Position:

Accessory #1

1016 N. Monroe Street, Lowell, MI 49331-0260 www.attwoodmarine.com

Three-Position Pull Switch

7594

Installation Instructions

for quality replacement parts and marine accessories.

best-known boat manufacturers as original equipment. Look to Attwood

marine accessories are specified more than any other brand by America’s

Attwood marine hardware, navigational lighting, bilge pumps, and other

SAVE THESE INSTRUCTIONS

Form Number 69408 Rev. A 03-01

REQUIRED FOR INSTALLATION

• Drill with ³⁄₈" (10mm) dia. bit

• Slotted or phillips screwdriver

after installation.

• Pliers / or adjustable end wrench

• Requires minimum 2" (50mm) clearance behind mounting panel

APPLICATION

• Install switch in dashboards or panels up to 1" (25mm) thick.

• Rated load is 20 amps.

to terminal screws. Figure 1

MOUNTING INSTRUCTIONS

1. Bring power source wire and switched wires to panel. Attach wires

inside panel, insert shaft through hole.

tighten brass nut and washer against panel.

2. Remove chrome handle and chrome nut from shaft.

4. Tighten chrome nut and handle onto end of shaft. From inside,

3. In desired location, drill ³⁄₈" (10mm) dia. hole through panel. From
