User’s manual
TL96151
DECT 6.0 cordless telephone/
answering system with
BLUETOOTH® wireless technology
Congratulations
on purchasing your new AT&T product. Before using this AT&T product,
please read Important safety information on pages 140-141 of this
user’s manual. Please thoroughly read the user’s manual for all the
feature operations and troubleshooting information you need to install
and operate your new AT&T product. You can also visit our website at
www.telephones.att.com or call 1 (800) 222-3111. In Canada,
dial 1 (866) 288-4268.
This telephone meets the California Energy Commission regulations for
energy consumption. Your telephone is set up to comply with the energyconserving standards right out of the box. No further action is necessary.
This telephone system is compatible with certain AT&T DECT 6.0 cordless
headsets. Visit www.telephones.att.com/headsets for a list of
compatible cordless headsets.
Model number: TL96151
Type: DECT 6.0 cordless telephone/answering system
with Bluetooth
Serial number:
Purchase date:
Place of purchase:
R
wireless technology
Both the model and serial numbers of your AT&T product can be found on the
bottom of the telephone base.
Telephones identified with this logo have reduced noise and
interference when used with most T-coil equipped hearing aids and
cochlear implants. The TIA-1083 Compliant Logo is a trademark of the
Telecommunications Industry Association. Used under license.
The Bluetooth® word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks by
Advanced American Telephones and its parent, VTech Holdings Limited, is under license. VTech Holdings Limited
is a member of Bluetooth SIG, Inc. Other trademarks and trade names are those of their respective owners.
© 2014-2015 Advanced American Telephones. All Rights Reserved. AT&T and
the AT&T logo are trademarks of AT&T Intellectual Property licensed to
Advanced American Telephones, San Antonio, TX 78219. Printed in China.
Parts checklist
THIS SIDE UP / CE
CÔ
TÉ
VERS LE HA
UT
Battery Pack / Bloc-piles
:
BT183342/BT283342 (2.4V 400mAh Ni-MH
)
WA
RNING /
AV
ERTISSEMENT
:
DO NOT BURN OR PUNCTURE BA
TTERIES.
NE PAS INCINÉRER OU PERCER LES PILES.
Made in China / Fabriqué en chine CR1349
Your telephone package contains the following items. Save your sales receipt
and original packaging in the event warranty service is necessary.
User’s manual
TL96151
DECT 6.0 cordless telephone/
answering system with
BLUETOOTH® wireless technology
Quick start guide
TL96151
This quick start guide provides you with basic instructions only.
For more complete instructions, refer to your user’s manual
provided in the package, or see the online user’s manual at
www.telephones.att.com/manuals.
Telephone base installation
Plug the power
adapter into a power
outlet not controlled
by a wall switch.
Route the power adapter
cord through this slot.
Raise the
antenna.
Caution: Use only the power adapter provided with this product. To obtain a replacement, visit
our website at www.telephones.att.com or call 1 (800) 222-3111. In
Canada, dial 1 (866) 288-4268.
Plug the power cord and
the telephone line cord
into the jacks.
Plug one end of the
telephone line cord
into a telephone
jack or a DSL filter.
A DSL filter (not
included) is required
if you have DSL
high-speed Internet
service.
The DSL filter must
be plugged into the
telephone wall jack.
Route the telephone line
cord through this slot.
Cordless handset User’s manual Quick start guide
Telephone base
with wall-mount
bracket attached
Battery for cordless
handset
Telephone line cord Power adapter for
telephone base
Battery compartment
cover
User’s manual
TL96151
DECT 6.0 cordless telephone/
answering system with
BLUETOOTH® wireless technology
Table of contents
Getting started
Quick reference guide - telephone
base ................................................................... 1
Quick reference guide - handset ........4
Telephone base main menu ..................7
Handset main menu .................................. 8
Installation ...................................................10
Telephone base installation ................11
Battery installation and charging .....12
Installation options ..................................14
Tabletop to wall-mount
installation .............................................14
Wall-mount to tabletop
installation .............................................15
Introducing Bluetooth ............................16
Glossary of terms .....................................17
Bluetooth setup ........................................18
Add a cell phone ................................18
Add a headset ......................................20
Bluetooth connection from idle
mode .........................................................21
Device list and connection ............22
Review the device list ......................22
Connect/disconnect an active
device .......................................................22
Remove a paired device ..................23
Rename a paired device..................24
Replace an active device ................25
Download directory ...........................26
Interruption to directory
download ................................................28
View the directory download
information ............................................28
Change PIN ............................................29
Telephone settings
Handset and telephone base
settings ..........................................................30
Ringer volume ......................................30
Ringer tone ............................................31
Set date and time ...............................32
Settings ....................................................33
LCD language .......................................33
Voice language ....................................34
Display alerts ........................................35
Missed call indicator .........................35
Voicemail indicator ............................36
No line .....................................................37
Download fail .......................................38
Use caller ID to automatically
set date and time ...............................39
Rename handset or the
telephone base ....................................40
Key tone ..................................................41
Dial mode ...............................................41
Caller ID announce ............................42
Website ....................................................43
Home area code ..................................43
Cell area code ......................................44
Telephone operation
Make, answer and end a call ..............45
Make, answer or end a
home call ................................................45
Call waiting on the home line .....46
Make, answer or end a cell
call ............................................................47
Call waiting on the cell line ..........48
Answer an incoming cell call
while on a home call ........................49
Answer a home call while on a
cell call ....................................................50
Conference calls .......................................51
Conference home and cell
calls ...........................................................51
Options while on calls ...........................52
Speakerphone ......................................52
Volume control ....................................52
Silencing the ringer ...........................52
Mute ..........................................................53
Temporary tone dialing ...................53
Hold ...........................................................54
Equalizer ..................................................54
Chain dialing .........................................55
Transfer a call .......................................55
Redial..............................................................57
Review the redial list ........................57
Dial a redial entry ...............................57
Save a redial entry to the
directory ..................................................58
Delete a redial entry .........................59
Handset locator .........................................60
Join a call in progress ...........................61
Intercom ........................................................62
Initiate an intercom call ..................62
Answer an incoming call during
an intercom call ..................................64
Call transfer using intercom ...............65
Push-to-talk (PTT) ....................................67
PTT on/off ..............................................67
PTT to a single device ......................68
PTT to a group of devices ..............70
Answer a PTT call ...............................72
Change a one-to-one PTT call
to an intercom call ............................73
End or leave a PTT call ....................74
Answer an incoming call during
PTT .............................................................74
Make an outgoing call during
PTT .............................................................75
Create and review entries ....................77
Create a new entry in the home
directory ..................................................77
Dialing keys ...........................................79
Add a predialed telephone
number to the directory ..................80
Review the directory .........................82
3-character alphabetical
search .......................................................83
Dial, edit or delete a directory ..........84
Dial a directory entry ........................84
Edit a directory entry ........................85
Edit the type of a directory
entry ..........................................................87
Delete a directory entry ..................87
Remove a downloaded
directory ..................................................88
Speed dial directory ................................89
Assign a speed dial directory
entry ..........................................................89
Review the speed dial
directory ..................................................90
Dial a speed dial entry.....................90
Reassign a speed dial entry ..........90
Delete a speed dial entry ...............91
Caller ID
About caller ID ..........................................92
Information about caller ID with
call waiting ............................................92
Caller ID operation ..................................93
How the caller ID log works .........93
Memory match .....................................93
Review the caller ID log ..................94
View dialing options ..........................96
Dial a caller ID log entry ................96
Save a caller ID log entry to
the directory .........................................97
Delete from the caller ID log .......99
Reasons for missing caller ID
information .........................................100
Directory
About the directory .................................76
Answering system
Answering system settings ...............101
Answer ON/OFF ...............................101
Announcement .................................102
Play your announcement ............102
Record your own
announcement ..................................103
Delete your announcement ........104
Call screening ....................................105
Number of rings ...............................106
Remote access code ......................107
Message alert tone .........................108
Temporarily turning off the
message alert tone .........................108
Recording time ..................................109
About the answering system...........110
Answering system and
voicemail ..............................................110
Using the answering system
and voicemail together ................110
Message capacity ............................111
Voice prompts ...................................111
Call screening at the telephone
base or handset ...............................111
Call intercept .....................................111
Message playback .................................112
Delete all old messages ...............114
Record and play memos ..............115
Remote access ........................................116
To remotely access the
answering system ............................116
Remote commands .........................116
Appendix
Handset screen icons ..........................117
Telephone base screen icons ..........118
Alert tones and lights .........................119
Handset alert tones ........................119
Telephone base alert tones ........119
Handset indicator lights ...............119
Telephone base indicator
lights ......................................................120
Screen messages ...................................121
Display screen messages .............121
Expand your telephone system ......124
Add and register handsets
(optional)..............................................124
Deregister handsets .............................125
Deregister all handsets .................125
Troubleshooting .....................................126
Maintenance.............................................139
Important safety information ..........140
Safety information ...........................140
Especially about cordless
telephones ..........................................141
Precautions for users of
implanted cardiac pacemakers ....
Pacemaker patients ........................141
Especially about telephone
answering systems ..........................141
For C-UL compliance ...........................142
Mesures de sécurité
importantes ........................................142
FCC Part 68 and ACTA........................145
FCC Part 15 ..............................................146
California Energy Commission
battery charging testing
instructions ...............................................147
Limited warranty ....................................148
Technical specifications .....................150
DECT 6.0 digital technology .......150
Telephone operating range ........150
Redefining long range coverage
and clarity ...........................................150
HD audio ..............................................150
141
Index
Index ............................................................151
Getting started
Quick reference guide - telephone base
REDIAL/PAUSE
Press repeatedly to view the last 10
numbers dialed (page 57).
While entering numbers, press and hold
to insert a dialing pause (page 78).
/HANDSET LOCATOR
Press the button to page
all system handsets
(page 60).
Press and hold to begin
handset deregistration
(page 125).
VOLUME
Press to adjust the volume during
message playback (page 112).
Press to adjust the volume during a call
(page 52).
When the phone is not in use, press
to adjust the telephone base ringer
volume for all lines (page 30).
DELETE/X
Press to delete the message currently playing
(page 112).
When the phone is not in use, press twice
to delete all previously reviewed messages
(page 114).
While entering names or numbers, press to
delete a digit or a character.
While reviewing the redial list, directory or
caller ID log, press to delete an individual
entry (pages 59, 87 and 99).
While predialing, press to delete a
digits (page 45).
1
While reviewing a caller ID log entry,
press repeatedly to add or remove
1 in front of the telephone number
before dialing or saving it in a directory
(page 96).
TONE
Press to switch to tone dialing
temporarily during a call if you have pulse
service (page 53).
PTT
Press to display the PT T menu to begin a
PTT call.
Press and hold to begin a one-to-group
broadcast when the handset is not in use.
/SKIP
During message playback, press
to skip to the next message
(page 112).
/REPEAT
Press to repeat a message or press
twice to play the previous message
(page 112).
/ANS ON
Press to turn the answering system
on or off (page 101).
/PLAY/STOP
Press to play messages
(page 112).
Press to stop message playback
(page 112).
1
Getting started
Quick reference guide - telephone base
FLASH
During a call, press to answer
an incoming call when you
receive a call waiting alert
(page 46).
MUTE
During a call, press to mute the
microphone (page 53).
While the telephone base is
ringing, press to silence the
ringer temporarily (page 52).
HOME (Speakerphone)
Press to make or answer a
home call (page 45).
Flashes quickly when there is an
incoming home call.
Flashes slowly when a home
call is on hold.
HEADSET
Press to transfer a call from the
telephone base to a connected
Bluetooth headset (page 46).
Press to use a connected Bluetooth
headset (page 46).
Press to end a call while you are using
the Bluetooth headset (page 46).
CANCEL
While in a menu, press to exit without
making changes or press and hold to
return to idle mode.
Press and hold while the telephone
is not in use to erase the displayed
messages (XX Missed calls and
Download fail, page 35 and page 38).
CID
Press to scroll down while in
a menu.
Press to review the caller ID
log when the telephone is
not in use (page 95).
While entering names or
numbers, press to move the
cursor to the left.
Softkeys (2)
Press to select the menu item
displayed above the key.
CELLULAR
Press to make or answer a cell call
(page 47).
During a cell call, press to answer an
incoming call when you hear a call
waiting alert (page 48).
Flashes quickly when there is an
incoming cell call.
Flashes slowly when a cell call is on hold.
DIR
Press to scroll up while in a
menu.
Press to show directory
entries when the telephone is
not in use (page 82).
While entering names or
numbers, press to move the
cursor to the right.
DEVICE 1/DEVICE 2 lights
On when the telephone
base is paired and
connected with a
Bluetooth device.
Flash alternately while
pairing a Bluetooth device.
2
Getting started
Quick reference guide - telephone base
Main menu
The selected menu item is highlighted.
Feature menu
Play messages (page 112)
Answering sys (page 101)
Directory (page 76)
Caller ID log (page 92)
Intercom (page 62)
Menu
Using menus
Press MENU in idle mode (when the telephone is not in use) to enter the
1.
main menu.
Bluetooth (page 16)
Ringers (page 30)
Set date/time (page 32)
Settings (page 33)
Website (page 43)
Use CID or DIR to scroll through menu items.
2.
Press SELECT to select or save the highlighted item.
3.
-OR-
Press CANCEL to cancel an operation, back up to the previous menu, or
exit the menu display.
-OR-
Press and hold CANCEL to return to idle mode.
NOTE: If no key is pressed, the telephone base automatically returns to idle mode after
30 seconds.
3
Getting started
Quick reference guide - handset
CHARGE light
On when the handset is charging in the
telephone base or charger.
Softkeys (2)
Press to select the menu item displayed above
the key.
While in a menu, press to select an item or
save an entry or setting.
CELLULAR
Press to make or answer a cell call (page 47).
During a cell call, press to answer an incoming
call when you hear a call waiting alert
(page 48).
Flashes quickly when there is an incoming
cell call.
Flashes slowly when a cell call is on hold.
HOME/FLASH
Press to make or answer a home call
(page 45).
During a home call, press to answer an
incoming call when you hear a call waiting
alert (page 46).
Flashes quickly when there is an incoming
home call or when the answering system is
recording a call.
Flashes slowly when a home call is on hold.
1
While reviewing a caller ID log entry, press
repeatedly to add or remove 1 in front of the
telephone number before dialing or saving it in
a directory (page 96).
TONE
Press to switch to tone dialing temporarily
during a call if you have pulse service
(page 53).
Press to toggle the name order when saving a
caller ID log entry into directory (page 97).
/SPEAKER
Press to make or answer a home or cell call
using the speakerphone.
Press to turn on the handset speakerphone.
Press again to resume normal handset use
(page 52).
REDIAL/PAUSE
Press repeatedly to view the last 10 numbers
dialed (page 57).
While entering numbers, press and hold to
insert a dialing pause (page 77).
4
Getting started
Quick reference guide - handset
DIR /VOLUME
Press to scroll up while in menus.
During a call or message playback, press to
increase the listening volume (page 52 and
page 113
Press to show directory entries when the
telephone is not in use (page 82).
While entering names or numbers in the
directory, press to move the cursor to the left
(page 77).
MUTE/DELETE
During a call, press to mute the microphone
(page 53).
While predialing, press to delete digits (page 45).
While reviewing the redial list, directory or
caller ID log, press to delete an individual entry
(pages 59, 87 and 99).
While entering or editing a directory entry, press
to erase a digit or character.
While the handset is ringing, press to silence the
ringer temporarily (page 52).
During message or announcement playback,
press to delete a message or announcement
(page 113 or page 104).
OFF/CANCEL
While using menus, press to cancel an operation,
back up to the previous menu, or exit the menu
display (page 6).
Press and hold to return to idle mode.
During a call, press to hang up (page 45).
Press and hold while the telephone is not in
use to erase all the Missed calls (page 35) or
Download fail messages (page 38).
While the handset is ringing, press to silence the
ringer temporarily (page 52).
CID /VOLUME
Press to scroll down while in menus.
During a call or message playback, press to
decrease the listening volume (page 52 and
page 113
Press to show the caller ID log when the
telephone is not in use (page 94).
While entering names or numbers in the
directory, press to move the cursor to the right
(page 77).
# (pound key)
Press repeatedly to display other dialing options
when reviewing a caller ID log entry (page 96).
EQ
During an outside call, intercom call, message
or announcement playback, press to change the
quality of the audio to best suit your hearing
(page 54).
).
).
5
Getting started
Quick reference guide - handset
Main menu
The selected menu item is
highlighted.
PUSH TO TALK
Press to display the PTT menu to begin a PTT
call (page 67).
Press and hold to begin a one-to-group
broadcast when the handset is not in
use. (page 70)
Feature menu
Play messages (page 113)
Answering sys (page 101)
Directory (page 76)
Caller ID log (page 92)
Intercom (page 62)
Ringers (page 30)
Set date/time (page 32)
Settings (page 33)
Website (page 43)
Menu
Using menus
Press MENU in idle mode (when the
1.
telephone is not in use) to enter the
main menu.
Use CID or DIR to scroll through
2.
menu items.
Press SELECT to select or save the
3.
highlighted item.
-OR-
Press OFF/CANCEL to cancel an
operation, back up to the previous menu,
or exit the menu display.
-OR-
Press and hold OFF/CANCEL to
return to idle mode.
NOTE: If no key is pressed, the handset
automatically returns to idle mode after
30 seconds.
6
Getting started
Telephone base main menu
To enter the main menu:
Press MENU in idle mode to enter the main menu.
1.
Press CID or DIR to scroll through menu items listed below, then press
2.
SELECT to select the highlighted item.
Press CANCEL to cancel an operation, back up to the previous menu, or exit
the menu display.
To return to idle mode, press and hold CANCEL.
NOTE: If no key is pressed within 30 seconds, the telephone base automatically returns to
idle mode.
Play messages - play messages from the
message box.
Play messages
Answering sys
Directory
Caller ID log
BACK SELECT
Directory - store and search for names
and numbers.
Play messages
Answering sys
Directory
Caller ID log
BACK SELECT
Intercom - intercom call with a
system handset.
Answering sys
Directory
Caller ID log
Intercom
BACK SELECT
Ringers - set up ringers for the home and
cell lines.
Caller ID log
Intercom
Bluetooth
Ringers
BACK SELECT
Answering sys - play, record, and delete
your announcement and memos, and
change your answering system settings.
Play messages
Answering sys
Directory
Caller ID log
BACK SELECT
Caller ID log - review the caller ID log or
delete all caller ID log entries.
Play messages
Answering sys
Directory
Caller ID log
BACK SELECT
Bluetooth - set up and manage your
Bluetooth devices.
Directory
Caller ID log
Intercom
Bluetooth
BACK SELECT
Set date/time - set the date and time of
your telephone.
Intercom
Bluetooth
Ringers
Set date/time
BACK SELECT
Settings - change your telephone
base settings.
Bluetooth
Ringers
Set date/time
Settings
BACK SELECT
Website - view the AT&T website address.
Ringers
Set date/time
Settings
Website
7
BACK SELECT
Getting started
Handset main menu
To enter the main menu:
Press MENU in idle mode to enter the main menu.
1.
Press CID or DIR to select a handset feature menu, then press SELECT
2.
to enter that menu.
Press OFF/CANCEL to cancel an operation, back up to the previous menu,
or exit the menu display.
To return to idle mode, press and hold OFF/CANCEL.
NOTE: If no key is pressed within 30 seconds, the handset automatically returns to
idle mode.
Play messages - play messages from the
message box.
Play messages
Answe ring sys
Directory
Caller ID log
BACK
SELECT
Directory - store and search for names
and numbers.
Play messages
Answe ring sys
Directory
Caller ID log
BACK
SELECT
Intercom - intercom call with the
telephone base or a system handset.
Answering sys - play, record, and delete
your announcement and memos, and
change your answering system settings.
Play messages
Answe ring sys
Directory
Caller ID log
BACK
SELECT
Caller ID log - review the caller ID log or
delete all caller ID log entries.
Play messages
Answe ring sys
Directory
Caller ID log
BACK
SELECT
Ringers - set up ringers for the home and
cell lines.
Answe ring sys
Directory
Caller ID log
Intercom
BACK
SELECT
Directory
Caller ID log
Intercom
Ringers
BACK
SELECT
8
Getting started
Handset main menu
Set date/time - set the date and time of
your telephone.
Caller ID log
Intercom
Ringers
Set date/time
BACK
SELECT
Website - view the AT&T website address.
Ringers
Set date/time
Settings
Website
BACK
SELECT
Settings - change your handset settings.
Intercom
Ringers
Set date/time
Settings
BACK
SELECT
9
Getting started
Installation
You must install and charge
the handset battery before
using the handset.
See pages 12-13 for easy
instructions.
Install the telephone base close to a telephone jack and a power outlet not
controlled by a wall switch. The telephone base should be placed on a flat
surface. For optimum range and better reception, place the telephone base in
a central and open location.
You may hear interference if your cellular phone is too close to the
telephone base during a CELLULAR call. Make sure that your Bluetooth
enabled cellular phone is within 15 feet of the telephone base in order to
maintain a clear and consistent connection between your Bluetooth cell
phone, telephone base and cell tower.
If you subscribe to high-speed Internet service (DSL - digital subscriber line)
through your telephone line(s), you must install a DSL filter between each
telephone line cord and telephone wall jack (page 11). The filter prevents
noise and caller ID problems caused by DSL interference. Please contact your
DSL service provider for more information about DSL filters.
Your product may be shipped with a protective sticker covering the handset
or telephone base display - remove it before use.
For customer service or product information, visit our website at
www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial
1 (866) 288-4268.
Avoid placing the telephone base too close to:
Communication devices such as television sets, VCRs, or other cordless
•
telephones.
Excessive heat sources.
•
Noise sources such as a window with traffic outside, motors, microwave
•
ovens, refrigerators, or fluorescent lighting.
Excessive dust sources such as a workshop or garage.
•
Excessive moisture.
•
Extremely low temperature.
•
Mechanical vibration or shock such as on top of a washing machine or
•
work bench.
10
Getting started
Telephone base installation
Install the telephone base, as shown below.
The telephone base is ready for tabletop use. If you want to change to
wall-mounting, see Installation options on page 14 for details.
Telephone base installation
Plug the large end of
the power adapter into a
power outlet not controlled
by a wall switch.
Route the power adapter cord
through this slot.
Raise the antenna.
Plug one end of the
telephone line cord into
a telephone jack or a DSL
filter.
A DSL filter (not included)
is required if you have DSL
high-speed Internet service.
The DSL filter must be
plugged into the telephone
wall jack.
Telephone line cord
Route the telephone line
cord through this slot.
Plug the other end of the
telephone line cord into the
telephone jack on the back
of the telephone base.
Plug the small end of the
telephone base power adapter
into the power adapter jack on
the back of the telephone base.
IMPORTANT INFORMATION:
Use only the power adapter(s) provided with this product. To obtain a replacement, visit our
1.
website at www.telephones.att.com or call 1 (800) 222-3111. In
Canada, dial 1 (866) 288-4268.
The power adapters are intended to be correctly oriented in a vertical or floor mount
2.
position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling,
under-the-table or cabinet outlet.
11
Getting started
Battery installation and charging
Install the battery, as shown below.
1. Plug the battery connector securely into the socket inside the handset
battery compartment, matching the color-coded label. Insert the supplied
battery with the label THIS SIDE UP facing up, as indicated.
2. Align the cover flat against the battery compartment, then slide it upwards
until it clicks into place.
CHARGE light
3. Charge the handset by placing it face forward in the
telephone base or charger. The CHARGE light is on
when charging.
To replace the battery, press the tab and slide the
battery compartment cover downwards. Lift out the
old battery and disconnect it from the handset. Follow
the instructions to install and charge the new battery.
IMPORTANT INFORMATION:
Use only the supplied rechargeable battery or replacement battery (model BT183342/
•
BT283342). To order, visit our website at www.telephones.att.com or call
1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.
If you do not use the handset for a long time, disconnect and remove the battery to prevent
•
possible leakage.
12
Getting started
Battery installation and charging
Once you have installed the battery, the screen indicates the battery status
(see the following table). If necessary, place the handset in the telephone
base or charger to charge the battery. For best performance, keep the
handset in the telephone base or charger when not in use. The battery
is fully charged after 16 hours of continuous charging. See the table on
page 150 for battery operating times.
If the screen is blank, you need to charge the handset without interruption
for at least 30 minutes to give the handset enough charge to use the
telephone for a short time. When the battery is low, the handset shows
Low battery and a flashing . If you are on a call in low battery mode, the
handset beeps every minute.
The following table summarizes the battery charge indicators and actions
to take.
Battery indicators Battery status Action
The screen is blank or shows
Place in charger and flashes.
The screen shows
Low battery and flashes.
The screen shows
HANDSET X.
The battery has no or very
little charge. The handset
cannot be used.
Battery has enough charge to
be used for a short time.
Battery is charged. To keep the battery charged,
Charge without interruption
(at least 30 minutes).
Charge without interruption
(at least 30 minutes).
place it in the telephone
base or charger when not
in use.
NOTE: If you are on a phone call in low battery mode, you hear 4 short beeps
every minute.
After you install your telephone or power returns following
a power outage, the handset and telephone base will
prompt you to set the date and time. For instructions, see
Set date and time on page 32. To skip setting the date and
time, press OFF/CANCEL or BACK on the handset, or
press CANCEL or BACK on the telephone base.
13
SET DATE
--/--/--
MM/DD/YY
BACK
SET TIME
--:-- --
BACK
SET
SET
Getting started
Installation options
Your telephone base is ready for tabletop use. If you want to mount your
telephone on a wall, follow the steps to connect the telephone base with
a standard dual-stud telephone wall-mounting plate. You may need a
professional to install the wall-mounting plate.
Tabletop to wall-mount installation
Unplug the power adapter from the power outlet.
1.
Unplug the telephone line cord from the wall jack (or
DSL filter). Make sure the telephone line cord and the
power cord are routed through the grooves at the
bottom of the telephone base, accordingly.
Press down on the tabs of the wall-mount bracket,
2.
as indicated, to release it from tabletop orientation.
Rotate the wall-mount bracket down and push it into
3.
the telephone base until it clicks into place.
Plug the telephone line cord (or DSL filter) into
4.
the wall jack. Plug the power adapter into a
power outlet not controlled by a wall switch.
Align the slots on the back of the telephone
base with the studs of the wall-mounting
plate. Make sure the telephone line cord
does not get caught between the
wall-mount plate and the telephone base.
14
Getting started
Installation options
Slide the telephone base down until it locks securely.
5.
Bundle the telephone line cord and power adapter
cord neatly with twist ties.
Wall-mount to tabletop installation
To change the telephone base from the wall-mount position to tabletop
position, follow the steps.
If the telephone line cord and power adapter cord are bundled, untie
1.
them first.
Push the telephone base up to remove it from wall. Unplug the telephone
2.
line cord (or DSL filter) from the wall. Unplug the power adapter from the
power outlet.
Gently pull upward to release the wall-mount bracket. Rotate the
3.
wall-mount bracket up to tabletop position and push it into the telephone
base until it clicks into place.
See Telephone base installation on page 11.
4.
15
Bluetooth
Introducing Bluetooth
Your new AT&T TL96151 telephone system with Bluetooth wireless technology
has the following features:
Pair up to 4 Bluetooth enabled devices (cell phones or headsets) with the
•
telephone base.
Connect a maximum of 2 cell phones to make and receive cell calls. Only
•
one cell phone can be active on a call at a time.
Connect a Bluetooth enabled headset for making and receiving home calls.
•
Conference any combination of cell and home call.
•
Make and receive calls using your cell phone service with your telephone
•
base or system handsets.
IMPORTANT INFORMATION
After plugging in the telephone base, wait at least 20 seconds before
•
connecting a Bluetooth device. The screen shows Bluetooth system busy
if you try to connect too soon.
Refer to the user's manual of your Bluetooth enabled cell phone or
•
headset for more information about how that device uses Bluetooth
connectivity.
Bluetooth wireless technology operates within a short range (up to 30
•
feet) from the telephone base. Keep connected cell phones and headsets
within this range.
If your cell phone has poor reception in your home, the TL96151 cannot
•
improve the reception. However, if there is a location in your house with
better reception, you can leave your cell phone at that location while you
use the TL96151 cell line. For optimal performance, the cell phone must
be within 15 feet of the telephone base.
Charge your cell phone while it is connected to the telephone base.
•
Your cell phone's battery discharges faster while it is connected to the
telephone base via Bluetooth wireless technology.
Monitor your cell phone's usage because minutes may be deducted from
•
your cellular plan for the duration of all cell calls, depending on the terms
of your plan.
Refer to the Bluetooth setup section (pages 18-29) to learn how to set up
your Bluetooth device. Refer to the Telephone operation section
(pages 45-60) on how to operate your Bluetooth devices with your new AT&T
TL96151 telephone system with Bluetooth wireless technology. Refer to the
Troubleshooting section (pages 126-138) if you experience difficulty when
using the telephone system.
The Bluetooth® word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks by
Advanced American Telephones and its parent, VTech Holdings Limited, is under license. VTech Holdings
Limited is a member of Bluetooth SIG, Inc. Other trademarks and trade names are those of their
respective owners.
16
Bluetooth
Glossary of terms
Below are some terms used in this user’s manual to help you become familiar
with using your Bluetooth devices and your new AT&T telephone system.
Active devices - the Device list has two active slots for two cell phones, or
one cell phone and one headset. When a device in the list is active it will
have a D1: or D2: in front of the device name. In order to use a Bluetooth
device on a call, it must be in an active slot and be connected.
Bluetooth cell phone - refers to a mobile Bluetooth enabled cellular telephone.
CELLULAR line - the telephone line associated with your cell phone service.
On your TL96151, press CELLULAR on the handset or CELLULAR on
the base to use the cell line.
Connected - when you pair a Bluetooth device to the TL96151, it is placed
in an active slot and automatically connected. When a device is connected,
a 1 and/or 2 will display after on the handset screen. Also, the DEVICE 1
and/or DEVICE 2 light on the telephone base will be on. If a device loses its
connection to the telephone base, it must be reconnected before you can
use the device with the TL96151.
Device list - The list of devices connected to the telephone.
Disconnected - when a device is disconnected, 1 and/or 2 displays after
on the handset screen. The DEVICE 1 and/or DEVICE 2 light on the
telephone base is/are off.
Discoverable mode - before a Bluetooth enabled device can be paired, it
must be set to this mode. When pairing your cell phone, the telephone base
is set to this mode. Depending on the cell phone manufacturer, this mode is
sometimes referred to as Find Me or Visibility.
Paired devices - The Bluetooth enabled devices (cell phones or headsets)
that have shared registration information with the telephone base. A total
of four Bluetooth enabled devices can be paired to the telephone base.
However, only two paired devices can communicate with the base at a time.
Pairing - sometimes referred to as bonding. The process of sharing
registration information between two Bluetooth enabled devices. Your
Bluetooth enabled cell phone or headset must first be paired to the
telephone base in order to use it with this telephone system.
PIN - by default, the PIN is 0000 for the telephone base and for most
Bluetooth devices. PIN information may be exchanged between Bluetooth
devices before they can be used. This is also known as a Passkey
or Passcode.
/
/
17
Bluetooth
Bluetooth setup
To use a Bluetooth enabled cellular phone with your telephone, you must first
pair and connect your Bluetooth cellular phone with the telephone base. The
TL96151
Bluetooth wireless technology operates within a short range (up to 30 feet).
When you pair a Bluetooth cell phone or Bluetooth headset to the
telephone base, keep the device within 15 feet of the telephone base for
optimal performance.
Add a cell phone
Before you begin, make sure that you have cellular coverage and your
Bluetooth enabled cell phone is not connected to any other Bluetooth
device. Refer to your cell phone user's manual to learn how to search for or
add new Bluetooth devices.
To pair and connect a cell phone:
1.
2.
3.
4.
can then be used to make or answer calls on the cell phone line.
Press MENU on the telephone base in idle mode to enter the main menu.
Press CID or DIR to highlight Bluetooth, then
press SELECT .
Press SELECT to choose Add device.
Press CID or DIR to highlight Add cellular, then
press SELECT. The screen displays Please wait...
followed by 1. If cell is connected to BT device,
please disconnect it.
If there are already 4 paired devices on the device
•
list, the 4th one will be automatically removed,
regardless of whether the pairing of the new cell
phone is successful or not.
Directory
Caller ID log
Intercom
Bluetooth
BACK SELECT
BLUETOOTH
Add device
Device list
Download dir
BACK SELECT
ADD DEVICE
Add cellular
Add headset
If there are already 2 active devices on the
•
device list with prefix D1: or D2:, the telephone
base shows Only 2 devices can be ready for
connection. You are prompted to deactivate an
active device.
Press NEXT . The screen displays 2. Place cell phone
5.
BACK SELECT
Set cell to
search base:
AT&T DECT 6.0
discoverable
PIN:0000
next to base.
All devices that are connected to the telephone base are
•
disconnected until the pairing process completed.
Press NEXT to turn on the telephone base discoverable mode. The
6.
screen displays Set cell to search base: AT&T DECT 6.0 discoverable
PIN: 0000. Promptly turn on the Bluetooth feature of your cell phone
and search for or add new devices.
18
Bluetooth
Bluetooth setup
Your cell phone may require a passcode. In this case
7.
the telephone base displays Check cellular. ENTER
PASS CODE. Enter the cell phone passcode (typically
0000) into the telephone base and press SET to save.
Enter the PIN of the telephone base (the default PIN
8.
is 0000) into your cell phone to continue the pairing
process. The telephone base displays Adding Cell
Phone A to device list....
When a device is successfully connected, the telephone
9.
Adding
Cell Phone A
to device
list...
Cell Phone A
is added
and connected
to base.
base displays Cell Phone A is added and connected to base.. You hear a
confirmation tone. The corresponding status icon ( 1 or 2) displays. The
corresponding device light on the telephone base (DEVICE 1 or DEVICE 2)
turns on.
If you have trouble pairing your cell phone, it may not be compatible
with your TL96151. Check the Bluetooth compatibility list at
www.telephones.att.com.
NOTES:
The pairing process may take up to one minute. If the pairing process fails, try again.
•
The steps for the pairing process may vary for different cell phones. If this happens,
•
follow the prompts on your cell phone and your TL96151 to complete the
pairing process.
Refer to the user’s manual of your cell phone on how to search for or add a new
•
Bluetooth device.
19
Bluetooth
Bluetooth setup
Add a headset
Before you begin, make sure that your Bluetooth enabled headset is not
connected to any other Bluetooth device. Refer to your headset user's
manual to learn how to search for or add new Bluetooth devices.
To pair and connect a headset:
Press MENU on the telephone base in idle mode to
1.
enter the main menu.
Press CID or DIR to highlight Bluetooth, then
2.
press SELECT .
Press SELECT to choose Add device.
3.
Press CID or DIR to highlight Add headset, then
4.
press SELECT . The screen displays Please wait...
followed by If headset is connected to cell, please
disconnect it.
If there are already 4 paired devices on the device
•
list, the 4th one will be automatically removed,
regardless of whether the pairing of the new
headset is successful or not.
If there is another headset already active, the screen
•
will show Only 1 headset in device list can be
ready for connection and prompts you to replace
an existing paired device.
Directory
Caller ID log
Intercom
Bluetooth
BACK SELECT
BLUETOOTH
Add device
Device list
Download dir
BACK SELECT
DEVICE LIST
Add cellular
Add headset
BACK SELECT
Pls set headset
to discoverable
mode
BACK NEXT
If there are already 2 active devices on the device
•
list with prefix D1: or D2:, the screen shows Only 2
devices can be ready for connection. The screen
Searching for
Bluetooth
headsets...
prompts you to deactivate an active device.
Press NEXT . The screen displays Pls set headset to
5.
discoverable mode. Set your headset to discoverable
FOUND DEVICES
Headset A
Headset B
mode (refer to the user’s manual of your headset),
then press NEXT .
All devices that are connected to the telephone base
•
are temporarily disconnected.
The screen displays Searching for Bluetooth headsets....
6.
When the screen displays the found devices, press
7.
BACK SELECT
ADD HEA DSET
ENTER PIN
Active d evices
BACK NEXT
CID or DIR to highlight your headset and then press SELECT .
Enter the PIN of your headset. The PIN for most Bluetooth devices is
8.
0000 (refer to the user’s manual of your headset). Then, press NEXT .
20
___ _
Bluetooth
Bluetooth setup
The screen displays Adding Headset A to
9.
device list... when the base is connecting to
your headset.
When a device is successfully connected, the
10.
telephone base displays Headset A is added and
connected to base. and the corresponding status
icon ( 1 or 2). You hear a confirmation tone. The
corresponding light on the telephone base (DEVICE 1
or DEVICE 2) turns on.
If you have trouble pairing your headset, it may not be compatible with
your TL96151. Check the Bluetooth compatibility list at
www.telephones.att.com.
NOTES:
The pairing process may take up to one minute. If the pairing process fails, try again.
•
When a connected headset is charging, it may disconnect from the telephone base and
•
the corresponding light on the telephone base (DEVICE 1 or DEVICE 2) turns off. For
some headset models, you may need to turn on the headset and reconnect it to the
telephone base again.
Auto connection
When an active device moves within Bluetooth range of the telephone base,
or is turned on within range, the telephone base tries to connect to the
device. When the device moves out of range, it is disconnected. Your device
might make a connect or disconnect sound.
Adding
Headset A
to device
list...
Headset A
is added
and connected
to base.
A connected device could also be disconnected by:
Turning off the Bluetooth device.
•
Turning off the Bluetooth feature of the device.
•
Disconnecting through the telephone base Device list. If you disconnect
•
through the Device list, the telephone base will not attempt to reconnect
until your device is moved out of range and then moves back in range again.
Bluetooth connection from idle mode
When you have active devices that are not connected, CONNECT appears
on the telephone base in idle mode. Press CONNECT to start connecting an
active device. When there are two active devices, the screen will prompt you
to choose one before connection.
21
Bluetooth
Bluetooth setup
Device list and connection
Up to 4 devices can be paired to the telephone base. All paired devices
are shown on the device list. To use a paired device, it must be in an active
slot (DEVICE 1 or DEVICE 2) on the device list and connected. Only one
Bluetooth cell phone or a headset can be on a call at a time.
Once you have paired a device with the telephone base, you do not need
to repeat the pairing procedure again unless you delete the device from the
device list.
NOTE:
When connecting a Bluetooth device to the device list, all connected devices will
be temporarily disconnected until the procedure is complete. It may take up to 2 minutes
to reconnect.
Review the device list
Press MENU on the telephone base in idle mode.
1.
Press CID or DIR to highlight Bluetooth, then press SELECT .
2.
Press CID or DIR to highlight Device list, then press SELECT .
3.
Connect/disconnect an active device
While in the device list menu, you may connect or disconnect your
active device.
Press MENU on the telephone base in idle mode.
1.
Press CID or DIR to highlight Bluetooth, then
2.
press SELECT .
Press CID or DIR to highlight Device list, then
3.
press SELECT .
Press CID or DIR to highlight a device, then
4.
press OPTION .
Press CID or DIR to highlight Connect/Disconnect
5.
(whichever is applicable), then press SELECT . The
telephone base displays Device connected/Device
disconnected. You hear a confirmation tone.
NOTE: When your active device is connected, you are prompted to
select Disconnect. When your active device is disconnected, you are
prompted to select Connect.
Directory
Caller ID log
Intercom
Bluetooth
BACK SELECT
BLUETOOTH
Add device
Device list
Download dir
BACK SELECT
DEVICE LIST
D1:Headset A
D2:Cell Phone A
Cell Phone B
BACK OPTION
HEADSET A
Connect
Remove
Rename
BACK SELECT
22
Bluetooth
Bluetooth setup
Remove a paired device
When you already have a maximum of 4 paired devices and you want to add
another device, you must first delete one from the device list.
To remove a paired device:
Press MENU on the telephone base in idle mode to
1.
enter the main menu.
Press CID or DIR to highlight Bluetooth, then
2.
press SELECT .
Press CID or DIR to highlight Device list, then
3.
press SELECT .
Press CID or DIR to highlight a selected device
4.
when necessary, then press DELETE/X.
-OR-
Press CID or DIR to highlight a device, then
•
press OPTION .
Press CID or DIR to highlight Remove, then
•
press SELECT .
The telephone base displays Remove Headset A?.
5.
Press YES to confirm. The telephone base displays
Device removed from device list and you hear a
confirmation tone.
BLUETOOTH
Add device
Device list
Download dir
BACK SELECT
DEVICE LIST
D1:Headset A
D2:Cell Phone A
Cell Phone B
BACK OPTION
Headset A
Connect
Remove
Rename
BACK SELECT
Remove
Headset A
?
NO YES
Device removed
from
device list
23
Bluetooth
Bluetooth setup
Rename a paired device
You can change the name of a paired device on the paired devices list.
Press MENU on the telephone base in idle mode to
1.
enter the main menu.
Press CID or DIR to highlight Bluetooth, then
2.
press SELECT .
Press CID or DIR to highlight Device list, then
3.
press SELECT .
Press CID or DIR to highlight a device, then
4.
press OPTION .
Press CID or DIR to highlight Rename, then press
5.
SELECT . The screen displays ENTER NEW NAME.
Use the dialing keys to edit the name (
6.
Press DELETE/X to erase a character.
•
Press and hold DELETE/X to erase all characters.
•
Press CID or DIR to move the cursor to the left
•
page 79
or right.
Press SAVE . The telephone base displays
7.
Device renamed. You hear a confirmation tone.
).
BLUETOOTH
Add device
Device list
Download dir
BACK SELECT
DEVICE LIST
D1:Headset A
D2:Cell Phone A
Cell Phone B
BACK OPTION
Headset A
Connect
Remove
Rename
BACK SELECT
ENTER NEW NAME
Headset A _
BACK SAVE
24
Bluetooth
Bluetooth setup
Replace an active device
If you already have 2 active devices on the device list and you want to
activate a different device, you must deactivate one of the 2 active devices.
To replace an active device:
Press MENU on the telephone base when it is not
1.
in use.
Press CID or DIR to highlight Bluetooth, then
2.
press SELECT .
Press CID or DIR to highlight Device list, then
3.
press SELECT .
Press CID or DIR to highlight the device you
4.
want to activate without a D1: or D2: prefix, then
press OPTION .
Press
5.
SELECT
CID
or DIR to highlight Connect, then press
.
The screen displays Only 2 devices can be ready
for connection and then a list of devices for deactivation.
Press CID or DIR to highlight the device to be
6.
deactivated, then press NEXT . The screen displays Cell
Phone A is deactivated and you hear a confirmation
tone. The screen then displays Connecting Cell Phone B
to the base...
Depending on your cell phone settings, you may
7.
.
need to press a key on your cell phone to confirm
the connection. When the new device is successfully
activated and connected, the screen displays
Device connected. You hear a confirmation tone.
BLUETOOTH
Add device
Device list
Download dir
BACK SELECT
DEVICE LIST
D1:Headset A
D2:Cell Phone A
Cell Phone B
BACK OPTION
DEACTIVATE
D1:Headset A
D2:Cell Phone A
BACK NEXT
Connecting
Cell Phone B
to the base...
DEVICE LIST
D1:Cell Phone B
D2:Cell Phone A
Headset A
BACK OPTION
NOTE: When adding, removing, or replacing a Bluetooth device on the active devices list, all
connected devices are temporarily disconnected until the procedure is complete. It may take
up to 2 minutes to reconnect.
25
Bluetooth
Bluetooth setup
Download directory
You can download up to 4 cell phone directories (phonebooks) to your
TL96151 telephone system via Bluetooth wireless technology. Each
downloaded directory can store up to 1,500 entries with up to 30 digits for
each phone number and 15 characters for each name.
Before downloading a directory, make sure the cell phone is paired, active,
and connected to your TL96151.
Place your cell phone next to the telephone base when you download a cell
phone directory to your TL96151.
To download a cell phone directory:
Press MENU on the telephone base in idle mode.
1.
Press CID
2.
or DIR
to highlight Bluetooth,
then press SELECT .
Press CID
3.
or DIR
to highlight Download dir,
then press SELECT .
Press CID
4.
or DIR
to highlight a device, then
press SELECT .
Press CID
5.
or DIR
to highlight one of the
following options:
Phone memory - download all contacts stored in
•
your phone memory.
SIM card only - download all contacts stored in your
•
SIM card.
Directory
Caller ID log
Intercom
Bluetooth
BACK SELECT
BLUETOOTH
Add device
Device list
Download dir
BACK SELECT
DOWNLOAD DIR
D1:Cell Phone A
D2:Cell Phone B
BACK SELECT
Phone and SIM - download all contacts stored in both your phone
•
memory and SIM card.
Press SELECT . During the download, the telephone base displays the
progress. All handsets display Downloading dir.
Your cell phone may require a passcode. In this case the screen
•
displays Check cellular. ENTER PASS CODE. Enter the cell phone
passcode into the telephone base and press SET to save.
Your cell phone may require you to press a key to confirm the
•
directory download.
26
Bluetooth
Bluetooth setup
If the selected device’s directory has already been
•
downloaded to TL96151 before, the telephone base
displays the last update date of your cell phone. The
directory stored on the TL96151 for that cell phone
will be erased and replaced with the current cell
phone directory. If you have edited the downloaded
entries (page 84), those changes will be lost. Press
NEXT to start the download, the screen displays
Erasing directory....
If you already have 4 downloaded directories, the
•
telephone base displays Memory is full. Replace
existing directory?. Press YES . Highlight the
cell phone directory to be replaced and press
SELECT. The screen displays Replace Cell Phone A
directory?. Press YES to confirm.
When the downloading process is complete, the telephone base displays
6.
Download ended XXXX entries saved. Press OK to return to the
Bluetooth menu.
NOTES:
With certain cell phones, downloading from the SIM card is not supported. If this is the
•
case, try transferring the contacts from your SIM card to your cell phone memory first, then
download from your cell phone memory. For more information on how to transfer contacts
from your SIM card to your cell phone memory, see your cell phone’s user’s manual.
If Phone memory is chosen but with no entries saved, the telephone base displays
•
No entries found. Download from SIM only?. Press YES to confirm. If SIM card only
is chosen but with no entries saved, the telephone base displays No entries found.
Download from Phone only?. Press YES to confirm. If Phone and SIM are chosen but
with no entries saved in either or both directories, the telephone base displays
No entries found. Download from Phone only?. Press YES to confirm.
When downloading the directory from your Bluetooth enabled cell phone, some data
•
may not transfer. For example, if you have home, mobile and work numbers for a
particular contact, the three category descriptions may not transfer to your TL96151.
DOWNLOAD FROM
Phone m emory
SIM card only
Phone a nd SIM
BACK SELECT
Cell Phone A
Downloading
entry #0001
STOP
Download ended
XXXX
entries saved
BACK OK
27
Bluetooth
Bluetooth setup
Interruption to directory download
If you are downloading a directory from a cell phone and the phone receives
a call, the download process stops and the telephone base and all handsets
display Download fail. When you try to view the downloaded directory, the
telephone base and handsets display Last download failed: MM/DD/YY. You
need to download the directory again (see page 26).
When you are downloading a directory from a cell phone and you wish
to stop the download process, you may press STOP . Then, the telephone
base displays Download directory cancelled. The telephone base displays
Download fail when it returns to idle mode. Refer to page 38 to reset the
download fail indication.
NOTE: During the download process, do not attempt to make changes to your cell phone
directory.
View the directory download information
Press MENU on the telephone base in idle mode to
1.
enter the main menu.
Press CID or DIR to highlight Directory, then
2.
press SELECT .
Press CID or DIR to choose the desired downloaded
3.
directory, then press OPTION .
Press CID or DIR to highlight Last update, then
4.
press SELECT .
The telephone base displays Cell phone A Last
•
update: MM/DD/YY Total #XXXX.
-OR-
The telephone base displays Cell phone A Last
•
download failed: MM/DD/YY if there was an
interruption during that directory download.
Press OK to exit.
5.
Play messages
Answering sys
Directory
Caller ID log
BACK SELECT
CELL PHONE A
Cell area code
Last update
Remove DIR
BACK SELECT
CELL PHONE A
Last update:
12/12/09
Total #0159
BACK OK
NOTE: If a handset tries to access the directory while a Bluetooth directory download is in
progress, the screen shows Not available at this time.
28
Bluetooth
Bluetooth setup
Change PIN
You are required to enter a PIN when establishing a
Bluetooth connection. The default PIN of your telephone
base is 0000.
To change the PIN:
Press MENU on the telephone base in idle mode to
1.
enter the main menu.
Press CID or DIR to highlight Bluetooth, then
2.
press SELECT .
Press CID or DIR to highlight Change PIN, then
3.
BLUETOOTH
Device list
Download dir
Change PIN
BACK SELECT
ENTER NEW PIN
BACK SET
press SELECT . The telephone base displays ENTER NEW PIN and the
existing PIN.
Use the dialing keys to enter a new 4-digit code.
4.
Press DELETE/X to erase a digit.
•
Press and hold DELETE/X to erase all digits.
•
Press CID or DIR to move the cursor to the left or right.
•
Press SET to save.
5.
0000
29
Telephone settings
Handset and telephone base settings
Ringer volume
You can select the ringer volume for incoming calls on the home line and
the cell line.
To adjust the ringer volume:
Press VOLUME on the telephone base to set the
1.
ringer volume while the telephone base is in idle mode to
set the ringer volume for all lines.
Press SET to confirm and you hear a confirmation tone.
2.
-OR-
Press OFF to turn off the ringer, then press SET to save.
You hear a confirmation tone.
-OR-
Press MENU in idle mode to enter the main menu.
1.
Press CID or DIR on handset, or press CID or
2.
DIR on the telephone base to highlight Ringers, then
press SELECT .
Press SELECT to choose Ringer volume.
3.
Press CID or DIR on handset, or press CID or DIR
4.
on the telephone base to highlight All lines, Home,
Cell-D1 or Cell-D2, then press SELECT to confirm.
Press CID or DIR on handset, or press CID or DIR
5.
on the telephone base to adjust the ringer volume. A
sample of each ringer volume plays as you scroll through
the choices.
-OR-
Press OFF to turn off the ringer. The handset displays
Ringer off.
Press SET to confirm, the screen displays Caller ID won’t
6.
be announced. You hear a confirmation tone.
NOTES:
Changing the handset ringer volume does not affect base
•
ringer volume.
When the ringer volume for all calls (home and cellular) is set
•
to off, a steady ringer off icon appears. When only one or
two of the ringer volume settings are set to off, a ringer off
icon flashes.
The ringer volume level also determines the ringer levels of
•
intercom calls (page 62).
For the handsets that support caller ID announce, when the ringer is set to off, caller ID
•
will not be announced and the screen displays Caller ID won’t be announced.
RINGERS
Ringer volume
Ringer tone
BACK
RINGER VOLUME
All lines
Home
Cell-D1
BACK
RINGER VOLUME
OFF
Ringer volume
Ringer tone
BACK SELECT
RINGER VOLUME
All lines
Home
Cell-D1
BACK SELECT
RINGER VOLUME
Active d evices
OFF SET
RINGERS
SELECT
SELECT
SET
30
Telephone settings
Handset and telephone base settings
Ringer tone
You can select the ringer tones for incoming home and cell calls.
To select a ringer tone:
Press MENU in idle mode to enter the main menu.
1.
Press CID or DIR on the handset, or press CID or
2.
DIR on the telephone base on the telephone base to
highlight Ringers, then press SELECT .
Press CID or DIR on the handset, or press CID or
3.
DIR on the telephone base to highlight Ringer tone,
then press SELECT .
Press CID or DIR on the handset, or press CID or
4.
DIR on the telephone base to highlight All lines, Home,
Cell-D1 or Cell-D2, then press SELECT .
Press CID or DIR on the handset, or press CID or
5.
DIR on the telephone base to sample each ringer tone.
The current ringer tone is checked. A sample of each
ringer tone plays as you scroll through the choices.
Press SET to select and save your choice. You hear a
6.
confirmation tone.
NOTE: When you turn off the ringer volume, you will not hear
ringer tone samples.
Ringer volume
Ringer tone
All lines
Home
Cell-D1
Tone 1
Tone 2
Tone 3
Ringer volume
Ringer tone
BACK SELECT
All lines
Home
Cell-D1
BACK SELECT
RINGERS
BACK
BACK
BACK
RINGER TONE
SELECT
RINGER TONE
SELECT
RINGER TONE
SET
RINGERS
31
RINGER TONE
Tone 1
Tone 2
Tone 3
BACK SET
Telephone settings
Handset and telephone base settings
Set date and time
The answering system announces the day and time of each message prior to
playing it. If you subscribe to caller ID service, the day, month and time are
set automatically with each incoming call. If you do not want to set the date
and time automatically with caller ID information, turn this feature off (see
Use caller ID to automatically set date and time on page 39). However, the
year must be correct so that the day of the week can be calculated from the
caller ID information. Before using the answering system, set the date and
time as follows.
After handset registration or a power failure, the handset or telephone base
will prompt you to set the date and time (see page 13).
To set the date and time:
Press MENU in idle mode to enter the main menu.
1.
Press CID or DIR on the handset, or press CID or
2.
DIR on the telephone base to highlight Set date/time,
then press SELECT .
Press CID or DIR on the handset, or press CID or
3.
DIR on the telephone base to select the month, then
press SET ., or enter the 2-digit number (01-12) using the
dialing keys (0-9).
Press
4.
5.
CID or DIR on the handset, or press CID or
DIR on the telephone base
press SET .
dialing keys (0-9)
, or enter the 2-digit number (01-31) using the
.
to select the day,
then
Press CID or DIR on the handset, or press CID or
DIR on the telephone base to select the year, then press
SET, or enter the 2-digit number (00-99) using the dialing
keys (0-9), then press SET .
Press CID or DIR on the handset, or press CID or
6.
DIR on the telephone base to select the hour, then
press SET ., or enter the 2-digit number (01-12) using
the dialing keys (0-9).
Press CID or DIR on the handset, or press CID or
7.
DIR on the telephone base to select the minute, then
press SET ., or enter the 2-digit number (00-59) using
the dialing keys (0-9).
Press CID or DIR on the handset, or press CID or
8.
DIR on the telephone base to highlight AM or PM, or
press 2 for AM or 7 for PM. Press SET to save. You hear
a confirmation tone.
Caller ID log
Intercom
Ringers
Set date/time
BACK
SET DATE
BACK
SET TIME
BACK
Intercom
Bluetooth
Ringers
Set date/time
BACK SELECT
SET DATE
Active d evices
BACK SET
SET TIME
Active d evices
BACK SET
SELECT
09/30/10
MM/DD/YY
05:41 PM
01/01/11
MM/DD/YY
06:08 PM
SET
SET
NOTE: If the date and time are not set when a message is recorded, the system announces,
“Time and day not set,” before each message plays.
32
Telephone settings
Handset and telephone base settings
Settings
In the settings menu, you can change and edit the settings for LCD language,
voice language, display alerts, CID time synchronization, handset name, key
tone, dial mode and caller ID announce.
LCD language
You can select English, Français or Español to be used in all
screen displays.
To select a language:
Press MENU in idle mode to enter the main menu.
1.
Press CID or DIR on the handset, or press CID or
2.
DIR on the telephone base to highlight Settings, then
press SELECT .
Press SELECT to choose LCD language.
3.
Press CID or DIR on the handset, or press CID or
4.
DIR on the telephone base to choose from English,
Français or Español, then press SET to save. You hear
a confirmation tone.
SETTINGS
LCD language
Voice la nguage
Display alerts
BACK
LCD LANG UAGE
English
Fran
Espanol
BACK
LCD Language
Voice language
Display alerts
BACK SELECT
LCD LANGUAGE
English
Francais
Espanol
BACK SET
SELECT
c
,
ais
SETTINGS
,
SET
33
Telephone settings
Handset and telephone base settings
Voice language
You can select the voice language (English or French) to be used for the
voice prompts in your answering system or caller ID announce.
1. Press
2.
MENU in idle mode to enter the main menu.
Use CID or DIR to highlight Settings, then press
SELECT.
3.
Use CID or DIR to highlight Voice language, then
press SELECT.
4. Press
SELECT to highlight Answering sys, then press
SELECT.
-OR-
Use CID or DIR to highlight Caller ID annc, then
press SELECT.
5. Press
CID or DIR to choose English or Français,
then press SET to confirm your selection. You hear a
confirmation tone.
SETTINGS
LCD language
Voice la nguage
Display alerts
BACK
VOICE LANGUAGE
Answe ring sys
Caller ID Annc
BACK
ANS SYS LANG
English
Fran
BACK
LCD Language
Voice language
Display alerts
BACK SELECT
VOICE LANGUAGE
Answering sys
Caller ID Annc
BACK SELECT
SELECT
SELECT
c
,
ais
SETTINGS
SET
34
ANS SYS LANG
English
Francais
,
BACK SET
Telephone settings
Handset and telephone base settings
Display alerts
In the display alerts menu, you can change and edit the settings for display
of alerts on the idle screen.
Missed call indicator
When there are missed calls that have not been reviewed in the caller ID log,
the screens show XX Missed calls.
Each time you review a caller ID log entry marked NEW, the number of
missed calls decreases by one. When you have reviewed all the missed calls,
the missed calls indicator goes away.
If you do not want to review the missed calls one by one, you can reset the
missed call indicator. All the entries are then considered old and kept in the
caller ID log.
To reset the missed call indicator:
Press MENU in idle mode to enter the main menu.
1.
Press CID or DIR on the handset, or press CID or
2.
DIR on the telephone base to highlight Settings, then
press SELECT .
Press CID or DIR on the handset, or press CID or
3.
DIR on the telephone base to highlight Display alerts,
then press SELECT .
Press CID or DIR on the handset, or press CID or
4.
DIR on the telephone base to highlight Home line or
Cell line, then press SELECT .
Press CID or DIR on the handset, or press CID
5.
or DIR on the telephone base to highlight Missed
calls, press SELECT . The screen displays Reset missed
call indication?. Press YES to confirm. You hear a
confirmation tone.
You can also press and hold OFF/CANCEL on the
handset or CANCEL on the telephone base to erase the
missed call indicator when the telephone is not in use.
SETTINGS
Voice la nguage
Display alerts
CID time sync
BACK
Missed calls
Voicemail
No line
BACK
Voice Language
Display alerts
CID time sy nc
BACK SELECT
HOME ALERTS
Missed calls
Voicemail
No line
BACK SELECT
SELECT
HOME ALERTS
SELECT
SETTINGS
35
Telephone settings
Handset and telephone base settings
Voicemail indicator
If you subscribe to voicemail service offered by your telephone service
provider, New voicemail and
new voicemail messages. Contact your telephone service provider for more
information and assistance about using your voicemail service.
After you have listened to all new voicemail messages, the indicators on the
handsets turn off automatically.
Reset the voicemail indicators when the telephone indicates that there is
new voicemail but there is none (for example, when you have accessed your
voicemail while away from home). Clearing the voicemail waiting indicators
only turns off the indicators; it does not delete your voicemail messages. As
long as you have new voicemail messages, your telephone service provider
continues to send the signal to turn on the indicators.
To reset the voicemail indicator:
Press MENU in idle mode to enter the main menu.
1.
Press CID or DIR on the handset, or press CID or
2.
DIR on the telephone base to highlight Settings, then
press SELECT .
Press CID or DIR on the handset, or press CID or
3.
DIR on the telephone base to highlight Display alerts,
then press SELECT .
Press CID or DIR on the handset, or press CID or
4.
DIR on the telephone base to highlight Home line, then
press SELECT .
Press CID or DIR on the handset, or press CID or
5.
DIR on the telephone base to highlight Voicemail,
then press SELECT .
The screen displays Reset voicemail indication?. Press
6.
YES to confirm. You hear a confirmation tone.
NOTES:
Your telephone service provider might alert you to new
•
voicemail messages with a stutter (broken) dial tone. Contact
your telephone service provider for more details.
For more information about the difference between your answering system and
•
voicemail, see page 110.
appear on the handsets when you have
DISPLAY ALERTS
Home line
Cell line
BACK
Missed calls
Voicemail
No line
BACK
DISPLAY ALERTS
Home line
Cell line
BACK SELECT
HOME ALERTS
Missed calls
Voicemail
No line
BACK SELECT
SELECT
HOME ALERTS
SELECT
36
Telephone settings
Handset and telephone base settings
No line
If there is no telephone line connected to the telephone base, the screens
show No home line. If you do not want to display this message on the
screens (for example, if you use the cell line only), you can turn off the no
line alert.
To reset the missed call indicator:
Press MENU in idle mode to enter the main menu.
1.
Press CID or DIR on the handset, or press CID or
2.
DIR on the telephone base to highlight Settings, then
press SELECT .
Press CID or DIR on the handset, or press CID or
3.
DIR on the telephone base to highlight Display alerts,
then press SELECT .
Press CID or DIR on the handset, or press CID or
4.
DIR on the telephone base to highlight Home line,
then press SELECT .
Press CID or DIR on the handset, or press CID or
5.
DIR on the telephone base to highlight No line, then
press SELECT .
Press CID or DIR on the handset, or press CID or
6.
DIR on the telephone base to choose On or Off, then
press SET to save. When you choose Off the handset
displays If the line is not connected, an alert will not
appear. You hear a confirmation tone.
HOME ALERTS
Missed calls
Voicemail
No line
BACK
NO LINE ALERT
On
Off
BACK
HOME ALERTS
Missed calls
Voicemail
No line
BACK SELECT
NO LINE ALERTS
On
Off
BACK SET
SELECT
SET
37
Telephone settings
Handset and telephone base settings
Download fail
If the directory download process is interrupted, the telephone base and
handset screens display Download fail. You can reset the download fail
indication on the handset.
To reset the voicemail indicator:
Press MENU on the handset when it is not in use.
1.
Press CID or DIR on the handset, or press CID or
2.
DIR on the telephone base to highlight Settings, then
CELL ALERTS
Missed calls
Download fail
BACK
press SELECT .
Press CID or DIR on the handset, or press CID or
3.
DIR on the telephone base to highlight Display alerts,
then press SELECT .
Press CID or DIR on the handset, or press CID or
4.
DIR on the telephone base to highlight Cell line, then
press SELECT .
Press CID or DIR on the handset, or press CID or
5.
DIR on the telephone base to highlight Download fail,
then press SELECT .
The screen displays Reset download failure indication?.
6.
Press YES to confirm. You hear a confirmation tone.
You can also press and hold OFF/CANCEL on the
Missed calls
Download fail
Reset
download
failure
indication?
YES
CELL ALERTS
BACK SELECT
Reset
download
failure
indication?
YES NO
handset or CANCEL on the telephone base to erase the download fail
indicator when the telephone is not in use.
SELECT
NO
38
Telephone settings
Handset and telephone base settings
Use caller ID to automatically set date and time
If you subscribe to caller ID service, the date and time
will be set automatically by the caller ID information. You
can turn off this feature if you want to set the date and
time manually.
Press MENU in idle mode to enter the main menu.
1.
Press CID or DIR on the handset, or press CID or
2.
DIR on the telephone base to highlight Settings, then
press SELECT .
Press CID or DIR on the handset, or press CID or
3.
DIR on the telephone base to highlight CID time sync,
then press SELECT .
Press CID or DIR on the handset, or press CID or
4.
DIR on the telephone base to highlight On or Off,
then press SET to save. You hear a confirmation tone.
SETTINGS
LCD language
Voice la nguage
CID time sync
BACK
CID TIME SYNC
On
Off
BACK
LCD language
Voice language
CID time sy nc
BACK SELECT
CID TIME SYNC
On
Off
BACK SET
SELECT
SETTINGS
SET
39
Telephone settings
Handset and telephone base settings
Rename handset or the telephone base
You can change the name of each device. The new name of each device
cannot exceed 11 characters.
To rename a handset or telephone base:
Press MENU on the handset when it is not use.
1.
Press CID or DIR on the handset, or press CID or
2.
DIR on the telephone base to highlight Settings, then
press SELECT .
Press CID or DIR on the handset, or press CID or
3.
DIR on the telephone base to highlight Rename
handset, then press SELECT . The screen displays
RENAME HANDSET.
Use the dialing keys to edit the name.
4.
Press MUTE/DELETE on the handset, or DELETE/X on
5.
the telephone base to erase a character.
Press and hold MUTE/DELETE on the handset,
•
or DELETE/X on the telephone base to erase
all characters.
Press CID or DIR on the handset to move the
•
cursor to the left or right, or press CID or DIR
on the telephone base to move the cursor to the
left or right.
Press SAVE . You hear a confirmation tone.
6.
SETTINGS
Display alerts
CID time sync
Rename handset
BACK
RENAME HANDSET
Room A _ _ _ _ _
BACK
Display alerts
CID time sy nc
Rename base
BACK SELECT
RENAME BASE
ROOM A_ _ _ _ _
BACK SAVE
SELECT
SETTINGS
SAVE
40
Telephone settings
Handset and telephone base settings
Key tone
The handset is set to beep with each key press. If you turn
off the key tone, there are no beeps when you press keys.
To change the setting:
Press MENU in idle mode to enter the main menu.
1.
Use CID or DIR on the handset, or press CID or
2.
DIR on the telephone base to scroll to Settings, then
press SELECT .
Press CID or DIR on the handset, or press CID or
3.
DIR on the telephone base to scroll to Key tone, then
press SELECT .
Press CID or DIR on the handset, or press
4.
CID or DIR on the telephone base to adjust the key
tone volume. You hear a sample of each volume while
adjusting. Press SET to save your preference.
SETTINGS
CID time sync
Rename handset
Key tone
BACK
KEY TONE VOLUME
OFF
CID time sy nc
Rename base
Key tone
BACK SELECT
SELECT
SETTINGS
SET
-OR-
Press OFF to turn off, then press SET to save. You hear
a confirmation tone.
Dial mode
The dial mode is preset to tone dialing. If you have pulse
(rotary) service, you must change the dial mode to pulse
dialing before using the telephone.
To change the setting:
Press MENU in idle mode to enter the main menu.
1.
Press CID or DIR on the handset, or press CID or
2.
DIR on the telephone base to highlight Settings, then
press SELECT .
Press CID or DIR on the handset, or press CID or
3.
DIR on the telephone base to highlight Dial mode,
then press SELECT .
Press CID or DIR on the handset, or press CID or
4.
DIR on the telephone base to choose Tone or Pulse,
then press SET to save. You hear a confirmation tone.
KEY TONE VOLUME
Active d evices
OFF SET
SETTINGS
Rename handset
Key tone
Dial mode
BACK
Tone
Pulse
BACK
Rename base
Key tone
Dial mode
BACK SELECT
Tone
Pulse
SELECT
DIAL MODE
SETTINGS
DIAL MODE
SET
41
BACK SET
Telephone settings
Handset and telephone base settings
Caller ID announce
The caller ID announce feature lets you know who’s calling
without having to look at the display. When you have an
incoming call, the handset and/or base speaks “Call from...”
and the name of the caller based on the directory or caller
ID information. If the caller’s name is private or unknown, the
phone number up to the last 11 digits will be announced.
If the caller’s phone number is also private or unknown,
no information will be announced. By default, the caller ID
announce feature is programmed On.
To change the setting:
Press MENU on the handset or telephone base in idle
1.
mode to enter the main menu.
Press CID or DIR on the handset, or press CID or
2.
DIR on the telephone base to highlight Settings, then
press SELECT .
Press CID or DIR on the handset, or press CID or
3.
DIR on the telephone base to highlight
Caller ID Annc, then press SELECT .
If you are changing the setting on the telephone base,
4.
skip to Step 5.
-OROn the handset, press CID or DIR to highlight
Handset or Base, then press SELECT .
Press CID or DIR on the handset, or press CID or
5.
DIR on the telephone base to choose On or Off, then press SET to save.
You hear a confirmation tone.
SETTINGS
Key tone
Dial mode
Caller ID Annc
BACK
CALLER ID ANNC
Handset
Base
BACK
CALLER ID ANNC
On
Off
BACK
SETTINGS
Key tone
Dial mode
Caller ID Annc
BACK SELECT
CALLER ID ANNC
On
Off
BACK SET
SELECT
SELECT
SET
NOTES:
To use the caller ID announce feature, you must subscribe to caller ID service from your
•
telephone service provider.
When there are up to 5 handsets registered, the telephone system supports caller ID
•
announce for the telephone base and all handsets. If six or more handsets are registered, the
system supports caller ID announce for the first four registered handsets only.
This feature is not supported with headsets.
•
This feature does not announce information for call waiting calls.
•
If both home and cell lines are ringing, only the caller ID information of the first ringing
•
line will be announced.
Caller ID announce is available in English and French.
•
It takes at least 2 rings for the phone to receive caller ID information and announce it.
•
If the phone is answered before the end of the second ring, the phone won’t have time
to announce the caller’s information.
Pronunciation of names may vary with this feature. Not all names may be
•
pronounced correctly.
42
Telephone settings
Handset and telephone base settings
Website
You can use this feature to view the AT&T website address.
Press MENU on the handset in idle mode to enter the
1.
main menu.
Use CID or DIR on the handset, or press CID or DIR
2.
on the telephone base to highlight Website, then press
SELECT . The screen shows the AT&T website address.
Press OK to exit.
3.
www.telephones.
att.com
OK
www.telephones.
att.co m
Home area code
OK
If you dial 7 digits to make a local call (area code not
required), enter your area code into the telephone as the
HOME AREA CODE
home area code. When you receive a call from within your
home area code, the caller ID log only displays the
7 digits of the telephone number.
BACK
---
SET
This feature makes it easy for you to place a call from the caller ID log. If you
dial 10 digits to make a local phone call, do not use this home area code
feature. If you do, you cannot place local calls from your caller ID log, as they
will have only 7 digits.
To set the home area code:
Press MENU in idle mode to enter the main menu.
1.
Press CID or DIR on the handset, or press CID or DIR on the
2.
telephone base to highlight Directory, then press SELECT .
Press OPTION to choose Home.
3.
Press CID or DIR on the handset, or press CID or DIR on the
4.
telephone base to highlight Home area code, then press SELECT . The
screen displays Only for 7 digits dialing from Caller ID log.
Use the dialing keys to enter the desired home area code.
5.
Press MUTE/DELETE on the handset, or DELETE/X on the telephone
•
base to erase a digit.
Press and hold MUTE/DELETE on the handset, or DELETE/X on the
•
telephone base to erase all digits.
Press CID or DIR to move the cursor to the right or left, or press
•
CID or DIR on the telephone base to move the cursor to the left or
right.
Press SET to save. The handset displays Area code will not show in
6.
Caller ID log. You hear a confirmation tone.
NOTE: If, in the future, your telephone service provider requires you to dial 10 digits to
make a local call (area code + telephone number), you will need to delete your home area
code. With the home area code displayed, press and hold MU TE/DELETE on the handset,
or DELETE/X on the telephone base and then press SET . The home area code is now
restored to its default setting of _ _ _ (empty).
43
Telephone settings
Handset and telephone base settings
Cell area code
Most cell phone entries are stored in a 10-digit format. If all of your cell
phone entries are stored this way, you do not need to program your cell
area code.
If your cell phone stores entries in a 7-digit format, we recommend that you
program your cell area code so that your 7-digit directory entries can be
dialed correctly using your home line.
To set the cell area code:
Press MENU on the handset in idle mode to enter the main menu.
1.
Press CID or DIR on the handset, or press CID or DIR on the
2.
telephone base to highlight Directory, then press SELECT .
Press CID or DIR on the handset, or press CID or DIR on the
3.
telephone base to highlight a desired downloaded directory, then
press OPTION .
Press SELECT to choose Cell area code. The handset displays Only for 7
4.
digits dialing from Caller ID log.
Use the dialing keys to enter the desired cell area code.
5.
Press MUTE/DELETE on the handset, or DELETE/X on the telephone
•
base to erase a digit.
Press and hold MUTE/DELETE on the handset, or DELETE/X on the
•
telephone base to erase all digits.
Press CID or DIR on the handset to move the cursor to the right or
•
left, or press CID or DIR on the telephone base to move the cursor to
the left or right.
Press SET to save. The handset screen displays Area code will not show in
6.
Caller ID log. You hear a confirmation tone.
44
Telephone operation
Make, answer and end a call
Make, answer or end a home call
Using a handset:
To make a home call:
Press HOME/FLASH or /SPEAKER, then enter the telephone number.
•
To predial a home call:
Enter the telephone number, then press HOME/FLASH or /SPEAKER.
•
To answer a home call:
Press HOME/FLASH or /SPEAKER.
•
To end a home call:
Press OFF/CANCEL, or put the handset in the telephone base or charger.
•
NOTES:
The screen shows the elapsed time as you talk (in hours, minutes and seconds).
•
When predialing (preview numbers before dialing), press MUTE/DELETE to backspace
•
and delete; press and hold RED IAL/PAUSE to insert a dialing pause (a p appears).
You cannot answer a home call using your connected cell phone.
•
Using the telephone base:
To make a home call:
Press HOME on the telephone base, then enter the telephone number.
•
To predial a home call:
Enter the telephone number, then press HEADSET or HOME.
•
To answer a home call:
Press HEADSET or HOME.
•
To end a call a home call:
Press HOME.
•
NOTES:
The screen shows the elapsed time as you talk (in hours, minutes and seconds).
•
When predialing (preview numbers before dialing), press DELETE/X to backspace and
•
delete; press and hold R EDI AL/PAUSE to insert a dialing pause (a p appears).
45
Telephone operation
Make, answer and end a call
Using a Bluetooth headset:
You can use a Bluetooth headset for home calls. However, you need to keep
the device within 15 feet of the telephone base for optimal performance.
Please see the user’s manual of your Bluetooth headset for more information.
To answer a home call using a Bluetooth headset:
Press HEADSET on the telephone base or the call key on your headset.
•
To end a home call:
Press HEADSET , or the call key on your headset.
•
To transfer a call from the telephone base to a Bluetooth headset:
Press HEADSET , then press SELECT or HEADSET again to choose the
•
headset. The telephone base displays Transferring audio to Headset A.
To transfer a call from the Bluetooth headset back to the telephone base:
Press HOME.
•
NOTES:
If you are on a call using a Bluetooth headset, and you lose the Bluetooth connection
•
or the battery becomes depleted, the call is lost.
When you try to use a Bluetooth headset that is not connected to the base, the
•
telephone base displays Headset not connected!. Press CONNECT to connect your
headset to the telephone system. Refer to Bluetooth connection from idle mode on
page 21 and Connect/disconnect an active device on page 22.
While using the cell line, you cannot use the Bluetooth headset.
•
Call waiting on the home line
If you subscribe to call waiting service from your telephone service provider,
and someone calls while you are already on a call, you hear a tone.
Press HOME/FLASH on the handset, or press FLASH on the telephone
•
base to put your current call on hold and take the new call.
Press the same key at any time to switch back and forth between calls.
•
46
Telephone operation
Make, answer and end a call
Make, answer or end a cell call
The TL96151 can be used to make or answer calls on the cell line. You can
connect a maximum of 2 Bluetooth enabled cell phones to the telephone
base, but only one cell phone can be used on a cell call at a time.
Using a handset:
To make a cell call:
Press CELLULAR. Enter the telephone number, then press DIAL .
•
To predial a cell call:
Enter the telephone number, then press CELLULAR.
•
If you have only one cell phone connected to the telephone base, it is
automatically selected to make cell calls. If you have two cell phones
connected to the telephone base, the telephone system prompts you to select
a cell phone before you make a cell call.
To answer a cell call:
Press CELLULAR.
•
To end a cell call:
Press OFF/CANCEL, or put the handset in the telephone base or charger.
•
NOTES:
You can also use your cell phone to answer the call.
•
If you do not want to answer the call, press REJECT . The screen displays Call rejected
•
and then returns to the idle mode.
When you try to make a cell call but your cell phone is not connected to the base, the
•
handset displays No cellular is ready for connection. Press CONNECT to connect your
cell phone to the telephone system. Refer to Bluetooth connection from idle mode on
page 21 and Connect/disconnect an active device on page 22.
47
Telephone operation
Make, answer and end a call
Using the telephone base:
To make a cell call:
Press CELLULAR, then enter the telephone number.
1.
Press DIAL .
2.
To predial a cell call:
Enter the telephone number, then press CELLULAR.
•
If you have only one cell phone connected to the telephone base, it is
automatically selected to make cell calls. If you have two cell phones
connected to the telephone base, the telephone system prompts you to select
a cell phone before you make a cell call.
To answer or end a cell call:
Press CELLULAR.
•
NOTES:
You can also use your cell phone to answer the call. If you answer with your cell phone,
•
it disconnects from the telephone base.
If you do not want to answer the call, press REJECT . The screen displays Call rejected
•
and then returns to the idle mode.
When you try to make a cell call but your cell phone is not connected to the base, the
•
telephone base displays Cellular phone not connected. Press CONNECT to connect
your cell phone to the telephone system. Refer to Bluetooth connection from idle
mode on page 21 and Connect/disconnect an active device on page 22.
Call waiting on the cell line
If you subscribe to call waiting service from your cell phone service provider,
and someone calls while you are already on a call, you hear a beep.
Using a handset:
Press CELLULAR on the handset to put your current call on hold and
•
take the new call.
Press CELLULAR on the handset at any time to switch back and forth
•
between calls.
-OR-
Press SWAP to switch. To switch back, press OPTION . Press CID or DIR
to highlight Swap, then press SELECT .
Using the telephone base:
Press SWAP on the telephone base. The original call is put on hold and
•
you take the new call.
Press OPTION on the telephone base. Press CID or DIR to highlight
•
Swap. Press SELECT to resume the original call. The other incoming cell
call is put on hold.
48
Telephone operation
Make, answer and end a call
Answer an incoming cell call while on a home call
If you are on a home call and you receive an incoming cell call, you hear a
beep and 1 or 2 displays on the handset or telephone base you are
using. The telephone base and all other handsets ring.
To answer the incoming cell call:
Using a handset:
Press CELLULAR on the handset. The home call is automatically
•
placed on hold. All other handsets and the telephone base display
Home call on hold and Cell line in use, alternately.
Using the telephone base:
Press CELLULAR on the telephone base. The home call is automatically
•
placed on hold and all other handsets display Home call on hold and
Cell line in use, alternately.
To end the cell call:
Using a handset:
Press OFF/CANCEL on the handset. The home line is still on hold. All
•
other handsets and the telephone base display Home call on hold.
Using the telephone base:
Press CELLULAR on the telephone base. The home line is still on hold.
•
All handsets display Home call on hold.
To resume the home call on hold:
Using a handset:
Press HOME/FLASH on the handset off hold.
•
Using the telephone base:
Press HOME on the telephone base.
•
NOTE: If you have voicemail service active on your cell phone, and you do not answer the
incoming cell call, the call is answered by your cell phone’s voicemail. Contact your cell
phone service provider for more information about voicemail service.
49
Telephone operation
Make, answer and end a call
Answer a home call while on a cell call
If you are on a cell call and you receive an incoming home call, you hear a
beep and displays on the handset or telephone base you are using. The
telephone base and all other handsets ring.
To answer the incoming home call:
Using a handset:
Press HOME/
•
on hold and all other handsets display Cell call on hold and Home line
in use, alternately.
Using the telephone base:
Press HOME on the telephone base. The cell call is automatically
•
placed on hold. All handsets display
in use
, alternately.
To end the home call:
Using a handset:
Press OFF/CANCEL on the handset. The cell line is still on hold. The
•
telephone base and all handsets display Cell call on hold.
Using the telephone base:
Press CELLULAR on the telephone base. The cell line is still on hold.
•
The telephone base and all handsets display Cell call on hold.
FLASH
on the handset. The cell call is automatically placed
Cell call on hold and Home line
To resume the cell call on hold:
Using a handset:
Press CELLULAR on the handset.
•
Using the telephone base:
Press CELLULAR on the telephone base.
•
NOTE: If you have turned on your answering system and you do not answer the incoming
home call, the call is answered by your answering system.
50
Telephone operation
Conference calls
Conference home and cell calls
When you have calls established on the home and cell lines, you can create
a 3-way conference.
To conference both home and cell calls:
1.
Press OPTION on the handset or telephone base.
2.
Press CID or DIR to highlight Conference.
3.
Press SELECT . The conferencing device’s screen displays
Lines now in conference.
To select an option while on a conference call:
1.
Press
OPTION
2.
Press CID or DIR to highlight one of the following options:
•
End Home line
•
End Cell line
•
End Conference
•
Directory
•
Caller ID log
3.
Press SELECT .
on the handset or telephone base.
To end a conference call:
•
Press OFF/CANCEL or put the handset back in the telephone base
or charger.
-OR-
•
Press OPTION on the handset or telephone base. Then, press CID or
DIR on the handset or telephone base to highlight End Conference.
Press SELECT to end the conference.
Using the home and cell lines together:
•
You can be on two different calls at the same time using the cell line and
home line and two handsets.
•
You cannot be on a call using the cell line and a Bluetooth headset via the
home line at the same time. These are both Bluetooth devices and only
one can be used at a time.
•
If you are on a call using the cell line, you cannot join the call using your
paired cell phone. However, you can join the call using another TL96151
device. Your cell phone is being used for the phone call so only features
that are normally available during a call can be used.
51
Telephone operation
Options while on calls
Speakerphone
Using a handset:
During a call, press /SPEAKER on the handset to switch between the
speakerphone and normal handset use.
Using the telephone base:
The speakerphone is the only audio option for the telephone base. Press
HOME
telephone base.
Volume control
While on a call, you can adjust the listening volume on the handset or
telephone base.
If it is a cell call and the volume is too loud, too quiet or drops out, try
changing the volume on your cell phone. On some cell phones, changing
the volume on the cell phone affects your cell call volume on the TL96151
handset or telephone base.
To adjust the listening volume of a handset:
•
To adjust the listening volume of the telephone base:
•
or CELLULAR to place, answer, and to end calls from the
Press VOLUME on the handset while on a call.
Press VOLUME on the telephone base while on a call.
NOTE: The handset earpiece volume setting (1-6) and speakerphone volume setting
(1-6) are independent. The speakerphone volume setting of the telephone base (1-8) is
also independent.
Silencing the ringer
When the telephone is ringing, you can temporarily silence the ringer of the
handset or telephone base without disconnecting the call. The next call rings
normally at the preset volume.
To silence the handset ringer:
Press SILENCE , OFF/CANCEL or MUTE/DELETE on the handset and
•
Ringer muted appears.
To silence the base ringer:
Press SILENCE .
•
-OR-
Press MUTE.
•
The telephone base displays Ringer muted.
52
Telephone operation
Options while on calls
Mute
Use the mute function to turn off the microphone. You can hear the caller,
but the caller cannot hear you.
To mute a call:
While on a call, press MUTE/DELETE on the handset, or press MUTE on the
•
telephone base. When mute is on, the handset and telephone base show
Microphone off for a few seconds and the MUTE icon appears until the
mute function is turned off.
To take a call off mute:
Press MUTE/DELETE on the handset, or press MUTE on the telephone
•
base and resume speaking. When mute is off, Microphone on appears
temporarily on the handset and telephone base.
Mute is automatically canceled when you end the call.
Temporary tone dialing
If you have pulse (rotary) service only, you can switch from pulse to touch-tone
dialing temporarily during a call. This is useful if you need to send touch-tone
signals to access your telephone banking or long distance services.
During a call:
Press TONE on the handset or telephone base.
1.
Use the dialing keys to enter the relevant number. The telephone sends
2.
touch-tone signals.
The telephone automatically returns to pulse dialing mode after you end
3.
the call.
53
Telephone operation
Options while on calls
Hold
You can place any call on hold. You hear an alert tone at the telephone base
if you have not taken the call off of hold after 14 minutes. You hear another
alert tone at the telephone base 30 seconds later. At 15 minutes on hold, the
call on hold automatically disconnects.
To place a home call on hold:
Press HOLD on the handset or telephone base. Home call on hold
•
appears on the handsets and telephone base. HOME/FLASH flashes on
the handsets and HOME flashes on the telephone base.
To resume a home call on hold:
Press HOME/FLASH on handsets or HOME on the telephone base.
•
To place a cell call on hold:
Press HOLD on the handset or telephone base. Cell call on hold appears
•
on the handsets and telephone base. CELLULAR on the handsets and
on the telephone base flash.
To resume a cell call on hold:
Press CELLULAR on the handset or telephone base.
•
Equalizer
The equalizer feature on the handset enables you to change
the quality of the handset audio to best suit your hearing.
While on a call, or listening to a message or announcement,
press EQ to select the equalizer setting Treble 1, Treble 2,
Bass or Natural (the default setting) for the handset. The
current setting shows on the handset for 2 seconds.
NOTES:
The equalizer feature does not apply to the speakerphone on the telephone base or the
•
connected Bluetooth headset.
If you switch the call between the handset and speakerphone by pressing /SPEAKER,
•
the audio setting remains unchanged.
The current equalizer setting remains unchanged until you select a new setting.
•
54
Telephone operation
Options while on calls
Chain dialing
Use this feature to initiate a dialing sequence from numbers stored in the
directory, caller ID log or redial list while you are on a call.
Chain dialing can be useful if you wish to access other numbers (such as
bank account numbers or access codes) from the directory, caller ID log or
redial list.
To access a number in the directory while on a call:
Using a handset:
Press OPTION .
1.
Press CID or DIR to highlight Directory, then press SELECT .
2.
Press CID or DIR to highlight the desired directory, then press REVIEW .
3.
Press CID or DIR to highlight to the desired entry or perform an
4.
alphabetical search (page 83).
Press DIAL to dial the displayed number.
5.
Using the telephone base:
Press OPTION .
1.
Press CID or DIR to highlight Directory, then press SELECT .
2.
Press CID or DIR to highlight the desired directory, then press REVIEW .
3.
Press CID or DIR to highlight to the desired entry or perform an
4.
alphabetical search (page 83).
Press DIAL to dial the displayed number.
5.
Transfer a call
While on an outside call, you can transfer the call from one device to another.
Press OPTION, then press SELECT to highlight Transfer.
1.
Your handset or the telephone base displays TRANSFER TO: and a list
•
of registered devices.
Press CID or DIR on the handset or CID or DIR on the
–
telephone base to highlight the destination device and then
press SELECT.
Your handset or telephone base displays Transferring call to HANDSET X,
Transferring call to BASE 0 or Transferring call to all... when you choose
Group. The destination device(s) rings.
Your handset or telephone base displays Call transferred when the other
2.
device picks up the call. You hear a confirmation tone.
NOTE: If the destination device does not answer within 30 seconds, the caller device
displays No response to transfer and rings. If the caller device does not answer the call on
hold within 30 seconds, the call will end automatically.
55
Telephone operation
Options while on calls
To access a number in the caller ID log while on a call:
Using a handset:
Press OPTION .
1.
Press CID or DIR to highlight Caller ID log, then press SELECT .
2.
Press CID or DIR to highlight the desired directory, then press REVIEW .
3.
Press CID or DIR to scroll to the desired entry.
4.
Press DIAL to dial the displayed number.
5.
Using the telephone base:
Press OPTION .
1.
Press CID or DIR to highlight Caller ID log, then press SELECT .
2.
Press CID or DIR to highlight the desired directory, then press REVIEW .
3.
Press CID or DIR to scroll to the desired entry.
4.
Press DIAL to dial the displayed number.
5.
To access the redial list while on a call:
Using a handset:
Press REDIAL/PAUSE.
1.
Press CID , DIR, or REDIAL/PAUSE until the desired number displays.
2.
Press DIAL to dial the displayed number.
3.
Using the telephone base:
Press REDIAL/PAUSE.
1.
Press CID, DIR or REDIAL/PAUSE until the desired number displays,
2.
Press DIAL to dial the displayed number.
3.
NOTES:
You can only view the numbers in the directory, caller ID log or redial list move to front
•
and cannot edit, delete or save entries.
You cannot copy a caller ID log entry into the directory while on a call. For more details
•
about the caller ID log, see page 92.
Press BACK or OFF/CANCEL on the handset, or BACK or CANCEL on the telephone
•
base to exit the redial list, directory or caller ID log while on a call.
56
Telephone operation
Redial
The telephone base and each handset store the last 10 dialed numbers (up
to 30 digits each) in the redial list. The redial entries of each handset and the
telephone base are independent.
Review the redial list
To review the redial list of a handset:
Press REDIAL/PAUSE in idle mode.
1.
Press
2.
browse the list. The handset beeps twice at the end
of the list.
Press OFF/CANCEL to exit.
To review the redial list of the telephone base:
Press REDIAL
1.
Press
2.
telephone base beeps twice at the end of the list.
Press CANCEL to exit.
Dial a redial entry
To dial a redial entry on a handset:
Press
1.
redial list.
Press
2.
number displays.
Press DIAL
3.
CID, DIR
CID, DIR
HOME/FLASH, or /SPEAKER to use the home line, or
CELLULAR
CID, DIR
or REDIAL/PAUSE repeatedly to
/PAUSE
in idle mode.
or REDIAL/PAUSE repeatedly to browse the list. The
to use the cell line. Then, press
or REDIAL/PAUSE repeatedly to browse until the desired
The handset beeps twice at the end of the list.
to dial the number displayed.
REDIAL/PAUSE
to enter the
You can also select a redial entry before dialing.
Press REDIAL/PAUSE in idle mode.
1.
Press
2.
number displays. The handset beeps twice at the end of the list.
Press
3.
CID, DIR
HOME/FLASH, or /SPEAKER to use the home line,
CELLULAR to use the cell line.
or REDIAL/PAUSE repeatedly to browse until the desired
57
or
Telephone operation
Redial
To dial a redial entry on the telephone base:
Press
1.
REDIAL/PAUSE
Press
2.
to browse and then press
number displayed.
You can also select a redial entry before dialing.
Press REDIAL in idle mode.
1.
Press
2.
number displays. The telephone base beeps twice at the end of the list.
Press HOME to dial using the home line, or CELLULAR to dial using
3.
the cell line.
Save a redial entry to the directory
Using a handset:
Press REDIAL/PAUSE in idle mode.
1.
Press
2.
number displays.
Press SAVE .
3.
The screen displays EDIT NUMBER. Use the dialing keys to edit the
4.
number, if necessary.
•
•
•
•
Press NEXT .
5.
Press CID or DIR to highlight one of the following types:
6.
•
•
•
•
Press NEXT . The screen displays ENTER NAME. Use the dialing keys
7.
(page 79) to enter a name.
•
•
•
Press SAVE . Saved displays and you hear a confirmation tone.
8.
HOME to use the home line, or
CELLULAR
Press MUTE/DELETE to erase a digit.
Press and hold MUTE or MUTE/DELETE to erase all digits.
Press CID or DIR to move the cursor to the right or left.
Press and hold REDIAL/PAUSE to insert a dialing pause (a p appears).
Home
Cell
Work
Other
Press MUTE/DELETE to erase a character.
Press and hold MUTE/DELETE to erase all characters.
Press CID or DIR to move the cursor to the right or left, or press
CID or DIR on the telephone base to move the cursor to the left
or right.
to use the cell line. Then, press
to enter the redial list.
CID, DIR
CID, DIR
CID, DIR
or REDIAL/PAUSE repeatedly
DIAL
or REDIAL/PAUSE repeatedly to browse until the desired
or REDIAL/PAUSE repeatedly to browse until the desired
to dial the
58
Telephone operation
Redial
Using the telephone base:
Press REDIAL/PAUSE in idle mode.
1.
Press
2.
number displays.
Press SAVE .
3.
The screen displays EDIT NUMBER. Use the dialing keys to edit the
4.
number, if necessary.
•
•
•
•
Press NEXT .
5.
Press CID or DIR to highlight one of the following types:
6.
•
•
•
•
Press NEXT . The screen displays ENTER NAME. Use the dialing keys
7.
(page 79) to enter a name.
•
•
•
Press SAVE . Saved displays and you hear a confirmation tone.
8.
CID, DIR
Press X/DELETE to erase a digit.
Press and hold X/DELETE to erase all digits.
Press CID or DIR to move the cursor to the left or right.
Press and hold REDIAL/PAUSE to insert a dialing pause (a p appears).
Home
Cell
Work
Other
Press DELETE/X to erase a character.
Press and hold DELETE/X to erase all characters.
Press CID or DIR to move the cursor to the left or right.
or REDIAL/PAUSE repeatedly to browse until the desired
Delete a redial entry
Using a handset:
Press REDIAL/PAUSE when the handset is not in use.
1.
Press CID , DIR or REDIAL/PAUSE repeatedly to browse until the desired
2.
number displays.
Press MUTE/DELETE to delete the displayed number. You hear a
3.
confirmation tone.
Using the telephone base:
Press REDIAL/PAUSE when the handset is not in use.
1.
Press CID, DIR or REDIAL/PAUSE repeatedly to browse until the desired
2.
number displays.
Press DELETE/X to delete the displayed number. You hear a
3.
confirmation tone.
59
Telephone operation
Handset locator
This feature helps you find a misplaced handset.
To start paging:
Press /HANDSET LOCATOR on the telephone base when it is not in use. All
idle handsets ring and display ** Paging **.
To end paging:
Press /HANDSET LOCATOR on the telephone base.
-OR-
Press HOME/FLASH, /SPEAKER, CELLULAR, PUSH TO TALK,
REDIAL/PAUSE, EQ
the handset.
NOTES:
If the handset ringer volume is set to off, the handset still rings when paged.
•
While the telephone base is paging, you may press MUTE/DE LETE , OFF/CANCEL or
•
SILENCE on the handset to mute the paging tone.
If there is no response after 60 seconds, paging ends.
•
or any dialing key (0-9, # (pound key),
TONE
) on
60
Multiple handset use
Join a call in progress
Join a call in progress
Another handset can join you on an outside call. That call continues until all
people hang up. You can share an outside call with telephone base and up to
4 system handsets.
Using a handset:
Press HOME/FLASH or /SPEAKER on another handset to join the call.
•
Using the telephone base:
Press HOME on telephone base to join the call.
•
61
Multiple handset use
Intercom
Use the intercom feature for conversations between two handsets, or a
handset and the telephone base.
You can buy additional expansion handsets (AT&T model TL90031/TL90041/
TL90051/TL90061, sold separately) for this telephone system. You can
register up to 12 handsets to the telephone base.
Initiate an intercom call
Using a handset:
Press MENU on the handset in idle mode.
1.
Press CID or DIR to highlight Intercom, then
2.
press SELECT .
Your handset displays INTERCOM and a list of devices.
•
Press CID or DIR to highlight a destination device
–
and then press SELECT . Your handset displays
Calling HANDSET X, Calling BASE 0 or Calling
all devices .
-OR-
Press 0 for BASE 0, 1-9 for handset 1-9, TONE and 0 for
–
handset 10, TONE and 1 for handset 11, or TONE and 2
for handset 12. Your handset displays Calling HANDSET X or
Calling BASE 0, or Calling all devices The other device rings and
displays HANDSET X is calling.
-OR-
Press TONE and then # (pound key) to call all devices.
–
The destination device(s) rings and displays HANDSET X is calling, or
HANDSET X is calling all.
Answe ring sys
Directory
Caller ID log
Intercom
BACK
BASE 0
HANDSET 1
HANDSET 2
BACK
SELECT
INTERCOM
SELECT
62
Multiple handset use
Intercom
Using the telephone base:
Press MENU on the telephone base in idle mode.
1.
Press CID or DIR to highlight Intercom, then
2.
press SELECT .
The telephone base displays INTERCOM and a list
•
of registered handsets.
Press CID or DIR to highlight a destination
–
handset or All handsets, and then press SELECT .
-OR-
Press 1-9 for handset 1-9, TONE and 0 for
–
Answering sys
Directory
Caller ID log
Intercom
BACK SELECT
INTERCOM
Handset 2
Handset 3
All handsets
BACK SELECT
handset 10, TONE and 1 for handset 11, or TONE and 2 for
handset 12.
-OR-
Press TONE and then # (pound key) to call all handsets.
–
The telephone base displays Calling HANDSET X, or Calling all handsets.
The destination handset(s) rings and displays BASE 0 is calling.
To answer an intercom call at the destination device:
•
Press
HOME/FLASH or
HOME
on the telephone base.
/SPEAKER
on the destination
Both screens show Intercom.
handset, or press
To silence an intercom call:
Press OFF/CANCEL, MUTE/DELETE or SILENCE on the destination
•
handset, or press MUTE or SILENCE on the telephone base. The screen
displays Ringer muted for a few seconds.
To mute while on an intercom call:
Press MUTE/DELETE on the handset, or MUTE on the telephone base. The
•
screen displays Microphone off for a few seconds.
To end an intercom call at the destination handset:
Press OFF/CANCEL, END or place either handset back in the telephone
•
base or charger. Both screens display Intercom ended.
To end an intercom call at the telephone base:
Press END or CANCEL. Both screens display Intercom ended.
•
NOTES:
You can cancel the intercom call before it is answered by pressing CANCEL or END on
•
the telephone base, or pressing OFF/CANCEL or END on your originating handset.
If you are calling all devices, only the first handset to pick up can answer the intercom call.
•
If the destination device does not answer the intercom call within 100 seconds, or if it
•
is in use, on a call or out of range, the initiating device displays No answer. Try again.
63
Multiple handset use
Intercom
Answer an incoming call during an intercom call
When you receive an incoming home call during an intercom call, the two
handsets on the intercom call hear an alert tone, and their screens display
Home Incoming call and then the caller ID. The telephone base and all other
handsets ring.
To answer a home call during an intercom call:
Using a handset:
Press HOME/FLASH to answer the home call. The intercom call
•
ends automatically.
Press OFF/CANCEL to end the intercom call without answering the
•
incoming call. The telephone continues to ring.
Using the telephone base:
Press HOME to answer the home call and the intercom call
•
ends automatically.
Press CANCEL to end the intercom call without answering the incoming
•
call. The telephone continues to ring.
To answer a cell call during an intercom call:
When you receive an incoming cell call during an intercom call, the two
handsets on the intercom call hear an alert tone, and their screens display
Cell Incoming call and then the caller ID. The telephone base rings and all
other handsets ring.
Using a handset:
Press CELLULAR to answer the cell call and the intercom call
•
ends automatically.
Press OFF/CANCEL to end the intercom call without answering the
•
incoming call. The telephone continues to ring.
Using the telephone base:
Press CELLULAR to answer the cell call. The intercom call
•
ends automatically.
Press CANCEL to end the intercom call without answering the incoming
•
call. The telephone continues to ring.
64
Multiple handset use
Call transfer using intercom
Use the intercom feature to transfer an outside call to another system
handset or the telephone base.
To transfer an outside call:
Using a handset:
When on an outside call, press OPTION .
1.
Press CID or DIR to highlight Intercom, then
2.
press SELECT .
Your handset displays INTERCOM plus a list of devices.
•
Press CID or DIR to highlight a destination device
–
and then press SELECT .
-OR-
Press 0 for BASE 0, 1-9 for handset 1-9, TONE
–
and 0 for handset 10, TONE and 1 for handset 11,
or TONE and 2 for handset 12.
-OR-
Press TONE and then # (pound key) to call all devices.
–
The call is automatically put on hold. Your handset displays Calling
HANDSET X, Calling BASE 0 or Calling all devices. The destination device
rings and displays HANDSET X is calling, or HANDSET X is calling all.
To answer the call on the other device, press HOME/FLASH or
3.
/SPEAKER on the handset, or press HOME on the telephone base.
The outside call is still on hold and both devices now show Intercom.
From this intercom call, you have the following options:
4.
You can transfer the call. Press OPTION and then press SELECT to select
•
Transfer on the calling handset. Your screen shows Call transferred. The
other device automatically connects to the outside call.
You can let the other device join you on the outside call in a 3-way
•
conversation. Press OPTION, highlight Share call, and press SELECT.
You can end the intercom call and continue the outside call with your
•
handset. Press
You can press OFF/CANCEL or END to hang up the intercom call
•
HOME/FLASH or
CELLULAR on your handset.
(the outside call will automatically go off hold and reconnect with
your handset).
NOTES:
If you want to cancel an intercom call and reconnect to the outside call before the
•
destination handset answers, press OFF/CANCEL or END on the originating handset.
If the other handset does not answer the intercom call within 100 seconds, or if the
•
other handset is in use, on a call or out of range, the calling handset shows No answer.
Try again. and returns to the outside call.
Tra nsfer
Intercom
Directory
Caller ID log
BACK
INTERCOM
BASE 0
HANDSET A 2
Group
BACK
SELECT
SELECT
65
Multiple handset use
Call transfer using intercom
Using the telephone base:
When on an outside call, press OPTION .
1.
Press CID or DIR to highlight Intercom, then
2.
press SELECT .
Your screen displays INTERCOM plus a list of handsets.
•
Press CID or DIR to highlight a destination
–
handset or All handsets and then press SELECT .
-OR-
Press 1-9 for handset 1-9, TONE and 0 for
–
handset 10, TONE and 1 for handset 11, or
TONE and 2 for handset 12.
-OR-
Press TONE and then # (pound key) to call all handsets.
–
The call is automatically put on hold. The telephone base displays
Calling HANDSET X or Calling all handsets. The destination handset(s)
rings and displays BASE 0 is calling.
Transfer
Intercom
Directory
Caller ID log
BACK SELECT
Handset 2
Handset 3
All handsets
BACK SELECT
INTERCOM
To answer the call on any destination handset, press
3.
HOME/FLASH
outside call is still on hold while both the handset and the telephone base
now show Intercom. You can now have a private conversation between
the handset and the telephone base.
From this intercom call, you have the following options:
4.
You can transfer the call. Press OPTION and then SELECT to select
•
Transfer on the telephone base. The telephone base displays Call
transferred. The destination handset automatically connects to the
outside call.
You can let the handset join you on the outside call in a 3-way
•
conversation. Press OPTION ., highlight Share call, and press SELECT .
You can end the intercom call and continue the outside call on the
•
telephone base. Press CANCEL or END on the telephone base. The
destination handset displays Intercom ended.
You can press CANCEL or END to hang up the intercom call (the
•
outside call will automatically go off hold and reconnect with
your telephone base).
NOTES:
To cancel the transfer and return to the external call before the intercom call is
•
answered, press CANCEL on the telephone base.
If the other handset does not answer the intercom call within 100 seconds, or if the
•
other handset is in use, on a call or out of range, the calling handset shows No answer.
Try again. and returns to the outside call.
. The
66
Multiple handset use
Push-to-talk (PTT)
You can directly broadcast messages from one handset or
telephone base to the speakerphone of one or a group of
other devices. Any handset called can respond by pressing
PUSH TO TALK or PTT on the telephone base to begin a
2-way communication.
Only one handset can talk at a time. To do so, press and hold
•
the PUSH TO TALK button.
You must release PUSH TO TALK, so the other person
•
can respond.
Only one PTT can be active at a time.
•
While PTT is in use between handsets or telephone base,
•
other handsets cannot use the intercom feature but can
access the answering system.
When you attempt to place a PTT call to another handset which is
•
accessing the answering system, your handset displays Not available at
this time.
PTT on/off
You can turn PTT on or off on each device.
When on, the handset can begin and receive PTT calls.
•
When off, the handset can begin PTT calls but will not receive PTT calls
•
from other handsets. The idle handset displays No Incoming PTT.
When you attempt to place a PTT call to another handset that has the PTT
•
feature turned off, your handset displays Not available at this time.
To turn PTT on or off:
Using a handset:
Press PUSH TO TALK when the handset is not in use. The
1.
PUSH TO TALK menu displays.
Press CID or DIR to highlight PTT On/Off, then
2.
PUSH TO TALK
HANDSET B 3
Group
PTT On/O ff
BACK
press SELECT .
Press CID or DIR to highlight On or Off, then press
3.
SELECT to save. You hear a confirmation tone.
67
INCOMING PTT
On
Off
BACK
SELECT
SELECT
Multiple handset use
Push-to-talk (PTT)
Using the telephone base:
Press PTT when the telephone base is not in use.
1.
The PUSH TO TALK menu displays.
Press CID or DIR to highlight PTT On/Off, then
2.
press SELECT .
Press CID or DIR to highlight On or Off, then press
3.
SELECT to save. You hear a confirmation tone.
PUSH TO TALK
HANDSET B 3
Group
PTT On/Off
BACK SELECT
INCOMING PTT
On
Off
BACK SELECT
PTT to a single device
Using a handset:
To begin a PTT call to a single device:
1.
Press PUSH TO TALK when the handset is not in use. Use the dialing
•
keys to enter a device number (0 for telephone base, 1-9 for handsets
1-9, TONE and 0 for handset 10, TONE and 1 for handset 11, or
TONE and 2 for handset 12) to create the push-to-talk session.
-OR-
Press PUSH TO TALK when the handset is not in use. Then, press
•
CID or DIR to scroll to the desired handset or the telephone base.
Press SELECT or PUSH TO TALK to create the push-to-talk session.
Your handset displays Connecting to HANDSET X... or Connecting to
2.
BASE 0... for a few seconds. When the connection is made, both yours
and the destination handsets display Press and hold [PTT] to talk and
beep once.
Press and hold PUSH TO TALK on your handset. A chirp indicates your
3.
microphone is on. Speak towards the handset. Your voice is broadcast
to the destination handset. While you are speaking, the handset displays
PTT To HANDSET X (X represents the destination handset number) or
PTT To BASE 0.
Release PUSH TO TALK after speaking. Both handsets beep once again.
4.
After the handsets beep, you can press and hold PUSH TO TALK to continue
speaking or the destination device can respond (see Answer a PTT call on
page 72).
To end the PTT call, press OFF/CANCEL or END . The handset displays
5.
Push to talk Ended for a few seconds.
-OR-
Place the handset in the telephone base or charger to end the PTT call.
NOTE: After PUSH TO TALK is released, the PTT call remains open for a short time. If no
one presses PUSH TO TALK within 10 seconds, the PT T call ends automatically.
68
Multiple handset use
Push-to-talk (PTT)
Using the telephone base:
To begin a PTT call to a single device:
1.
Press PTT when the telephone base is not in use. Use the dialing keys
•
to enter a handset number (1-9 for handsets 1-9, TONE and 0 for
handset 10, TONE and 1 for handset 11, or TONE and 2 for
handset 12) to create the push-to-talk session.
-OR-
Press PTT when the telephone base is not in use. Then, press CID or
•
DIR to scroll to the desired handset. Press SELECT or PTT to create
the push-to-talk session.
The telephone base displays Connecting to HANDSET X... for a few
2.
seconds. When the connection is made, both screens display Press and
hold [PTT] to talk and beep once.
Press and hold PTT on the telephone base. A chirp indicates your
3.
microphone is on. Speak towards the MIC. Your voice is broadcast to the
destination handset. While you are speaking, the telephone base displays
PTT To HANDSET X (X represents the destination handset number).
Release PUSH TO TALK after speaking. The telephone base and the
4.
destination handset beep once again. After the handset beeps, you can
press and hold PUSH TO TALK to continue speaking or the destination
handset can respond (see Answer a PTT call on page 72).
To end the PTT call, press CANCEL or END . The telephone base displays
5.
Push to talk Ended for a few seconds.
NOTE: After PTT is released, the PTT call remains open for a short time. If no one
presses PTT within 10 seconds, the PTT call ends automatically.
69
Multiple handset use
Push-to-talk (PTT)
PTT to a group of devices
When there are multiple handsets registered to the phone system, PTT
supports one-to-group calls. PTT supports a maximum of one-to-four calls
when two to five handsets are registered, and a maximum of one-to-three
calls when six or more handsets are registered. The first three or four
registered handsets and the telephone base will be eligible to use this
feature. Other handsets can only use PTT for one-to-one calls.
Using a handset:
To begin a PTT call to a group of devices:
1.
Press and hold PUSH TO TALK when the handset is not in use.
•
-OR-
Press PUSH TO TALK when the handset is not in use, then press
•
TONE and # (pound key).
-OR-
Press PUSH TO TALK when the handset is not in use. Press CID or
•
DIR to highlight Group, then press SELECT or PUSH TO TALK.
Your handset displays Connecting to group... for a few seconds. When
the connection is made, both your and the destination devices display
Press and hold [PTT] to talk and beep once.
Press and hold PUSH TO TALK on your handset. A chirp indicates your
2.
microphone is on. Speak towards the handset. Your voice is broadcast to
the destination devices. While you are speaking, the handset displays
PTT To base & handset X (X represents the destination device numbers).
Release PUSH TO TALK after speaking. All eligible devices beep once
3.
again. After the handsets beeps, you can press and hold PUSH TO TALK to
continue speaking or the destination devices can respond (see
Answer a PTT call on page 72).
Press OFF/CANCEL or END to end the PTT call. The handset displays
4.
Push to talk Ended for a few seconds.
-OR-
Place the handset in the telephone base or charger to end the PTT call.
NOTE: After PUSH TO TALK is released, the PTT call remains open for a short time. If no
one presses PUSH TO TALK within 10 seconds, the PTT call ends automatically.
70
Multiple handset use
Push-to-talk (PTT)
Using the telephone base:
To begin a PTT call to a group of devices:
1.
Press and hold PTT when the telephone base is not in use.
•
-OR-
Press PTT when the telephone base is not in use, then press TONE
•
and # (pound key).
-OR-
Press PTT when the telephone base is not in use. Press CID or
•
DIR to highlight Group, then press SELECT or PTT.
Your screen displays Connecting to group... for a few seconds. When the
connection is made, both screens display Press and hold [PTT] to talk
and beep once.
Press and hold PTT on the telephone base. A chirp indicates your
2.
microphone is on. Speak towards the microphone. Your voice is broadcast
to the destination handsets. While you are speaking, the screen displays
PTT To handset X (X represents the destination handset numbers).
Release PTT after speaking. All eligible handsets beep once again. After
3.
the telephone base beeps, you can press and hold PTT to continue
speaking or the destination handsets can respond (see Answer a PTT call
on page 72).
Press CANCEL or END to end the PTT call. The telephone base displays
4.
Push to talk Ended for a few seconds.
NOTE: After PTT is released, the PTT call remains open for a short time. If no one presses
PTT within 10 seconds, the PTT call ends automatically.
71
Multiple handset use
Push-to-talk (PTT)
Answer a PTT call
You can respond to a PTT call whenever the speakerphone light is off, as
described below.
Using a handset:
When your handset receives a PTT call, the handset beeps, and you hear the
other caller’s voice. The speakerphone light is on, and the handset displays
PTT From BASE 0 To handset: Y or PTT From HANDSET X To handset: Y
(X represents the initiating handset number and Y represents your handset
number and other destination device numbers if any; a maximum of 4 device
numbers appear).
When the caller finishes, the handset beeps and displays Press and hold
[PTT] to talk, and the speakerphone light turns off.
Press and hold PUSH TO TALK on your handset. When you hear a chirp,
speak towards the handset.
While you are speaking, your handset displays PTT To BASE 0 or
•
PTT To HANDSET X, or PTT To base & handset: X.
Your voice is broadcast to all destination devices.
•
The speakerphone light is off.
•
Release PUSH TO TALK when you finish speaking. Your handset beeps. After
the beep, if your speakerphone light is off, you can press and hold
PUSH TO TALK to continue speaking or the destination devices can respond.
Using the telephone base:
When the telephone base receives a PTT call, the telephone base beeps,
and you hear the other caller’s voice, the speakerphone light is on, and the
telephone base displays PTT From HANDSET X To Base 0 or PTT From
HANDSET X To base & HS: Y (X represents the initiating handset number
and Y represents other handset numbers; a maximum of 4 handset
numbers appear).
When the caller finishes, the telephone base beeps and displays Press and
hold [PTT] to talk, and the speakerphone light is off.
Press and hold PTT on the telephone base. When you hear a chirp, speak
towards the handset.
While you are speaking, the telephone base displays PTT To HANDSET X.
•
Your voice is broadcast to all destination handsets.
•
The speakerphone light is off.
•
Release PTT when you finish speaking. The telephone base beeps. After the
beep, you can press and hold PTT to continue speaking or the destination
handsets can respond.
72
Multiple handset use
Push-to-talk (PTT)
Change a one-to-one PTT call to an intercom call
You can convert a one-to-one PTT conversation to an intercom call.
Using a handset:
When your handset displays Press and hold [PTT] to talk, press INTCOM .
1.
Your handset displays Switch to Intercom?. Press SELECT to confirm.
Your handset then displays Calling HANDSET Y (Y represents the
•
destination handset number) or Calling BASE 0. The destination
handset temporarily displays Push to talk Ended and then HANDSET X
is calling (X represents the originating handset number).
On the destination device, press HOME/FLASH or /SPEAKER on the
2.
handset or HOME on the telephone base to answer the intercom call.
Both devices now display Intercom.
To end the intercom call, press OFF/CANCEL , END or place the handset
3.
in the telephone base or charger. Both devices display Intercom ended.
Using the telephone base:
When the telephone base displays Press and hold [PTT] to talk, press
1.
INTCOM . The telephone base displays Switch to Intercom?. Press SELECT .
The telephone base then displays Calling HANDSET Y (Y represents
•
the destination handset number). The destination handset temporarily
displays Push to talk Ended and then BASE 0 is calling.
On the destination handset, press HOME/FLASH or /SPEAKER to
2.
answer the intercom call. Both screens now display Intercom.
To end the intercom call, press CANCEL or END on the telephone base.
3.
Both screens display Intercom ended.
73
Multiple handset use
Push-to-talk (PTT)
End or leave a PTT call
For a one-to-one PTT call, both the originating and destination devices
can end the PTT call. For one-to-group PTT calls, the initiating devices
can end the PTT call for the group of devices on that PTT call. If any one
of the destination devices leaves the PTT call, the call continues until all
participants or the initiator hangs up.
To end or leave PTT:
Using a handset:
Press OFF/CANCEL , END or place the handset in the telephone base or
charger. The handset displays Push to talk Ended. After PUSH TO TALK
is released, the PTT call remains open for a short time. If no one presses
PUSH TO TALK within 10 seconds, the PTT call ends automatically.
NOTES: After PUSH TO TALK is released, the PTT call remains open for a short time. If no
one presses PUSH TO TALK within 10 seconds, the PTT call ends automatically.
Using the telephone base:
Press CANCEL or END . The telephone base displays Push to talk Ended.
Answer an incoming call during PTT
When you receive an incoming outside call during PTT, there is a call waiting
tone. The caller ID displays alternately with the PTT screen.
During a one-to-one PTT call, press HOME/FLASH or CELLULAR on
•
your originating or destination handset, or press HOME or CELLULAR
on the telephone base. The PTT call ends automatically and the outside
call is answered.
During a one-to-group PTT call, press HOME/FLASH or CELLULAR
•
on the originating handset
originating
telephone base.
, or press HOME or CELLULAR on the
The PTT call ends automatically and the
outside call is answered.
During a one-to-group PTT call, press HOME/FLASH or CELLULAR on
•
any one of the destination handsets, or press HOME or CELLULAR on
the destination telephone base. That handset or telephone base answers
the outside call. The PTT call continues for the rest of the PTT participants.
To leave the PTT call without answering the incoming call, press
•
OFF/CANCEL on the handset, or press CANCEL on the telephone base.
The telephone continues to ring.
74
Multiple handset use
Push-to-talk (PTT)
Make an outgoing call during PTT
During a one-to-one PTT call, press HOME/FLASH or CELLULAR on the
•
handset, or press HOME or CELLULAR on the telephone base to get a
dial tone. The PTT call ends automatically.
During a one-to-group PTT call, press HOME/FLASH or CELLULAR
•
on the originating handset
originating
dial tone.
During a one-to-group PTT call, press HOME/FLASH or CELLULAR on
•
any one of the destination devices, or press HOME or CELLULAR on
the destination telephone base. That device gets a dial tone. The PTT call
continues for the rest of the PTT participants.
telephone base.
, or press HOME or CELLULAR on the
The PTT call ends automatically and you get a
75
Directory
About the directory
The home directory stores up to 200 entries with up to 30 digits for each
phone number and 15 characters for each name. Each of the downloaded
directories stores up to 1,500 entries with up to 30 digits for each phone
number and 15 characters for each name.
Directory entries are stored at the telephone base and shared by all
•
system handsets. Any changes made on one device apply to all.
Only one device can review the directory at a time. If another device tries
•
to enter the directory, its screen shows Not available at this time.
When there are no records in the directory, the screen shows
•
Directory empty.
When the directory is full and you try to save an entry, the screen shows
•
Directory full.
When you try to save a number already stored in the directory, the screen
•
shows Already saved.
All of the instructions on pages 77-91 for the directories apply to the home
directory and all downloaded directories. Creating a new entry on page 77
only applies to the home directory.
You cannot create new entries in your downloaded directories with a
TL96151 handset or telephone base. Entries must be downloaded from your
cell phone (see Download directory on pages 26-27).
76
Directory
Create and review entries
Create a new entry in the home directory
Using a handset:
Press MENU on the handset in idle mode to enter the main menu.
1.
Press CID or DIR to highlight Directory, then press SELECT .
2.
Press OPTION to select Home.
3.
Press SELECT to choose Add contact. The screen displays
4.
ENTER NUMBER.
Use the dialing keys to enter a telephone number.
5.
Press MUTE/DELETE to erase a digit.
•
Press and hold MUTE/DELETE to erase all digits.
•
Press CID or DIR to move the cursor to the right or left.
•
Press and hold REDIAL/PAUSE to insert a dialing pause (a p appears).
•
-OR-
Copy a number from the redial list.
Press REDIAL/PAUSE and then CID , DIR or REDIAL/PAUSE
•
repeatedly to browse for a number. Press INSERT to copy the
displayed number.
Press NEXT .
6.
Press CID or DIR to highlight one of the following types:
7.
Home
•
Cell
•
Work
•
Other
•
Press NEXT . The screen displays ENTER NAME.
8.
Use the dialing keys (see page 79) to enter the name.
9.
Press MUTE/DELETE to erase a character.
•
Press and hold MUTE/DELETE to erase all characters.
•
Press CID or DIR to move the cursor to the right or left.
•
Press SAVE to confirm and the screen shows Saved. You hear a
10.
confirmation tone.
NOTE: You cannot create new entries in your downloaded directories from your TL96151
handsets. Entries must be downloaded from your cell phone (see Download directory on
pages 26-27).
77
Directory
Create and review entries
Using the telephone base:
Press MENU on the telephone base in idle mode to enter the main menu.
1.
Press CID or DIR to highlight Directory, then press SELECT .
2.
Press OPTION to select Home.
3.
Press SELECT to choose Add contact. The screen displays
4.
ENTER NUMBER.
Use the dialing keys to enter a telephone number.
5.
Press DELETE/X to erase a digit.
•
Press and hold DELETE/X to erase all digits.
•
Press CID or DIR to move the cursor to the right or left.
•
Press and hold REDIAL/PAUSE to insert a dialing pause (a p appears).
•
-OR-
Copy a number from the redial list.
Press
•
REDIAL/PAUSE
repeatedly to browse for a number. Press INSERT to copy the
displayed number.
Press NEXT .
6.
Press CID or DIR to highlight one of the following types:
7.
Home
•
Cell
•
Work
•
Other
•
Press NEXT . The screen displays ENTER NAME.
8.
Use the dialing keys (see page 79) to enter a name.
9.
Press DELETE/X to erase a character.
•
Press and hold DELETE/X to erase all characters.
•
and then CID, DIR or
REDIAL/PAUSE
Press CID or DIR to move the cursor to the left or right.
•
Press SAVE to confirm and the screen shows Saved. You hear a
10.
confirmation tone.
NOTE: You cannot create new entries in your downloaded directories from your TL96151.
Entries must be downloaded from your cell phone (see Download directory on
pages 26-27).
78
Directory
Create and review entries
Dialing keys
Diali ng
key
1 1 . -
2 A B C a b c 2
3 D E F d e f 3
4 G H I g h i 4
5 J K L j k l 5
6 M N O m n o 6
7 P Q R S p q r s 7
8 T U V t u v 8
9 W X Y Z w x y z 9
0
*
#
NOTE: When entering a name in the directory, the first letter of each word is
automatically capitalized.
1 2 3 4 5 6 7 8 9 10 11
Space
0
Chara cter s by nu mber of key pre sses
,
( ) * # & / ,
79
Directory
Create and review entries
Add a predialed telephone number to the directory
You can save a predialed telephone number to the directory.
To add a predialed telephone number:
Using a handset:
Enter the telephone number in idle mode (see Step 5 in
1.
Create a new entry in the home directory on page 78).
Press SAVE to move on to edit the number (see Step 3 in
2.
Edit a directory entry on page 85) and then press NEXT .
Press CID or DIR to highlight one of the following
3.
types:
Home
•
Cell
•
Work
•
Other
•
Press NEXT . The screen displays ENTER NAME.
4.
Use the dialing keys (see page 79) to enter the name.
5.
Press MUTE/DELETE to erase a character.
•
Press and hold MUTE/DELETE to erase all characters.
•
Press CID or DIR to move the cursor to the right
•
or left.
Press SAVE and the screen shows Saved. You hear a
6.
confirmation tone.
888-883-2445
--:-- --/--
BACK
EDIT NUMBER
888-883-2445
BACK
SELECT LABEL
Home
Cell
Work
BACK
ENTER NAME
-
BACK
Saved
SAVE
NEXT
NEXT
SAVE
80
Directory
Create and review entries
Using the telephone base:
Enter the telephone number in idle mode (see Step 5 in
1.
Create a new entry in the home directory on page 77).
Press SAVE to move on to the number (see Step 3 in
2.
Edit a directory entry on page 85) and then press NEXT.
Press CID or DIR to highlight one of the following
3.
types:
Home
•
Cell
•
Work
•
Other
•
Press NEXT . The screen displays ENTER NAME.
4.
Use the dialing keys (see page 79) to enter a name.
5.
Press DELETE/X to erase a character.
•
Press and hold DELETE/X to erase all characters.
•
Press CID or DIR to move the cursor to the left
•
or right.
Press SAVE and the screen shows Saved. You hear a
6.
confirmation tone.
888-883-2445
BACK SAVE
EDIT NUMBER
888-883-2445
BACK NEXT
SELECT LABEL
Home
Cell
Work
BACK NEXT
ENTER NAME
_
SAVE
Saved
81
Directory
Create and review entries
Review the directory
Entries are sorted alphabetically.
To review the directory:
Using a handset or telephone base:
Press DIR in idle mode.
1.
Press CID or DIR on handset, or CID or DIR on the telephone base
2.
to highlight a directory, then press REVIEW .
Press CID or DIR on handset, or CID or DIR on the telephone base
3.
to browse.
-OR-
Press MENU in idle mode.
1.
Press CID or DIR on handset, or CID or DIR on the telephone base
2.
to highlight Directory, then press SELECT .
Press CID or DIR on handset, or CID or DIR on the telephone base
3.
to highlight a directory, then press REVIEW .
Press CID or DIR on handset, or CID or DIR on the telephone base
4.
to browse.
-OR-
Press OPTION while on call.
1.
Press CID or DIR on handset, or CID or DIR on the telephone base
2.
to highlight Directory, then press SELECT .
Press CID or DIR on handset, or CID or DIR on the telephone base
3.
to highlight a directory, then press REVIEW .
Press CID or DIR on handset, or CID or DIR on the telephone base
4.
to browse.
NOTE: When the desired entry displays, press # (pound key) on the handset or telephone
base repeatedly to show different dialing options.
82
Directory
Create and review entries
3-character alphabetical search
You can use the enhanced 3-character search to find your contacts quickly
and efficiently.
To start the search:
Follow the steps in Review the directory on the previous page to enter
1.
the directory.
When an entry appears, use the dialing keys to enter the letters associated
2.
with the name (see page 79). You can enter up to 3 letters for the search.
The letters will show at the top left hand corner of the screen. After you
have entered one to three letters, the system starts searching in the
directory. If there is no name matching the letter(s) entered, the next
closest match in alphabetical order appears. If necessary, press CID or
DIR on the handset, or CID or DIR on the telephone base to browse.
NOTE: The cursor automatically moves to the next position 2 seconds after you enter
a letter. If you do not enter another letter in the coming 2 seconds, the system starts
searching in the directory.
83
Directory
Dial, edit or delete a directory
Dial a directory entry
You can dial a directory entry on any line.
To dial a directory entry:
Search for the desired entry in the directory (see
1.
Review the directory and 3-character alphabetical
search on pages 82 and 83).
When the desired entry appears, press # (pound key)
2.
repeatedly on the handset or telephone base to show
different dialing options.
When the displayed number is in the correct format, press HOME/FLASH
3.
or /SPEAKER on the handset, or press HOME on the telephone base to
use the home line. Press CELLULAR on the handset or on the telephone
base to use the cell line.
888-883-2445
1-888-883-2445
883-2445
1-883-2445
84
Directory
Dial, edit or delete a directory
Edit a directory entry
You can edit any directory entry. However, be aware that if you download a
directory from a cell phone again, the directory is erased and replaced with
the current cell phone directory. If you have edited the downloaded entries
on the TL96151, those changes are lost. To avoid losing changes made to
the downloaded directory, we suggest that you edit numbers in your cell
phone, then download the directory.
Using a handset:
Search for the desired entry in the directory (see Review the directory or
1.
3-character alphabetical search on pages 82 or 83).
When the desired entry appears, press EDIT . The handset shows
2.
EDIT NUMBER.
Use the dialing keys to edit the number.
3.
Press MUTE/DELETE to erase a digit.
•
Press and hold MUTE/DELETE to erase all digits.
•
Press CID or DIR to move the cursor to the right or left.
•
Press and hold REDIAL/PAUSE to insert a dialing pause (a p appears).
•
Press NEXT .
4.
Press CID or DIR to highlight one of the following types:
5.
Home
•
Cell
•
Work
•
Other
•
Press NEXT . The screen displays EDIT NAME.
6.
Use the dialing keys (see page 79) to enter the name.
7.
Press MUTE/DELETE to erase a character.
•
Press and hold MUTE/DELETE to erase all characters.
•
Press CID or DIR to move the cursor to the right or left.
•
Press SAVE to confirm and the handset shows Saved.
8.
85
Directory
Dial, edit or delete a directory
Using the telephone base:
Search for the desired entry in the directory (see Review the directory or
1.
3-character alphabetical search on pages 82 or 83).
When the desired entry appears, press EDIT . The telephone base shows
2.
EDIT NUMBER.
Use the dialing keys to edit the number.
3.
Press DELETE/X to erase a digit.
•
Press and hold DELETE/X to erase all digits.
•
Press CID or DIR to move the cursor to the right or left.
•
Press and hold REDIAL/PAUSE to insert a dialing pause (a p appears).
•
Press NEXT.
4.
Press CID or DIR to highlight one of the following types:
5.
Home
•
Cell
•
Work
•
Other
•
Press NEXT. The screen displays EDIT NAME.
6.
Use the dialing keys (see page 79) to edit the name.
7.
Press DELETE/X to erase a character.
•
Press and hold DELETE/X to erase all characters.
•
Press CID or DIR to move the cursor to the left or right.
•
Press SAVE to confirm and the handset shows Saved.
8.
86
Directory
Dial, edit or delete a directory
Edit the type of a directory entry
If you only want to edit the type of a directory entry:
Search for the desired entry in the directory (see Review
1.
the directory or 3-character alphabetical search on
pages 82 or 83).
When the desired entry appears, press LABEL . Enter the
2.
corresponding shortcut keys shown on the screen.
-OR-
Press CLEAR to erase the assigned label.
Delete a directory entry
To delete an entry:
Search for the desired entry in the directory (see Review the directory or
1.
3-character alphabetical search on pages 82 or 83).
When the desired entry appears, press MUTE/DELETE on the handset or
2.
DELETE/X on the telephone base. The screen displays Delete contact?
and the name of the entry. Press YES to confirm.
The screen displays Contact deleted and then the next alphabetical entry
3.
in the directory. You hear a confirmation tone.
SELECT LABEL
1:Home 2:Cell
3:Work 4:Other
CLEAR
SELECT LABEL
1:Home 2:Cell
3:Work 4:Other
CLEAR
NOTE: Once a directory entry is deleted, it cannot be retrieved.
87
Directory
Dial, edit or delete a directory
Remove a downloaded directory
Using a handset:
Search for the desired downloaded directory in the directory menu (see
1.
Review the directory on page 82).
When the desired downloaded directory is chosen, press OPTION , then
2.
press CID or DIR to highlight Remove dir.
Press SELECT . The screen displays Directory Cell Phone A will be erased.
3.
Press YES to confirm. The handset displays Erasing directory... and then
4.
Directory removed. You hear a confirmation tone.
Using the telephone base:
Search for the desired downloaded directory in the directory menu (see
1.
Review the directory on page 82).
When the desired downloaded directory is chosen, press OPTION , then
2.
press CID or DIR to highlight Remove dir.
Press SELECT . The screen displays Directory Cell Phone A will be erased.
3.
Press YES to confirm. The handset displays Erasing directory... and then
4.
Directory removed. You hear a confirmation tone.
88
Directory
Speed dial directory
Assign a speed dial directory entry
You can assign 10 of your directory entries to a speed dial slot (0-9). The
speed dial entries are shared by all handsets.
Up to 10 speed dial entries can be stored. The speed dial number must be
created from an existing entry in the Home directory or a Bluetooth directory.
Using a handset or telephone base:
Press MENU in idle mode.
1.
Press CID or DIR on the handset, or CIDor DIR on the telephone
2.
base to highlight Directory, then press SELECT .
Press CID or DIR on the handset, or CIDor DIR on the telephone
3.
base to highlight Speed dial, then press REVIEW .
Press CID or DIR on the handset, or CIDor DIR on the telephone
4.
base to highlight an empty slot, then press ASSIGN .
Press CID or DIR on the handset, or CIDor DIR on the telephone
5.
base to highlight the desired directory, then press REVIEW .
Search for the desired entry in the directory (see Review the directory or
6.
3-character alphabetical search on pages 82 or 83). When the desired
entry appears, press ASSIGN . You hear a confirmation tone.
89
Directory
Speed dial directory
Review the speed dial directory
Using a handset or telephone base:
Press MENU in idle mode.
1.
Press CID or DIR on the handset, or CIDor DIR on the telephone
2.
base to highlight Directory, then press SELECT .
Press CID or DIR on the handset, or CIDor DIR on the telephone
3.
base to highlight Speed dial, then press REVIEW .
Press CID or DIR on the handset, or CIDor DIR on the telephone
4.
base to browse.
Dial a speed dial entry
Using a handset:
Press and hold the dialing key (0-9) corresponding to the assigned entry
1.
you wish to call.
Press HOME/FLASH or /SPEAKER to dial with the home line, or
2.
CELLULAR to dial with the cell line.
Using the telephone base:
Press and hold the dialing key (0-9) corresponding to the assigned entry
1.
you wish to call.
Press HOME to dial with the home line, or CELLULAR to dial with the
2.
cell line.
Reassign a speed dial entry
Using a handset or telephone base:
Press MENU in idle mode.
1.
Press CID or DIR on the handset, or CIDor DIR on the telephone
2.
base to highlight Directory and then press SELECT .
Press CID or DIR on the handset, or CIDor DIR on the telephone
3.
base to highlight Speed dial, then press REVIEW .
Press CID or DIR on the handset, or CIDor DIR on the telephone
4.
base to highlight the desired slot.
Press ASSIGN . The screen displays the directory at the current
5.
assigned entry.
Search for the desired entry in the directory (see Review the directory or
6.
3-character alphabetical search on pages 82 or 83). When the desired
entry appears, press ASSIGN .
The screen displays Entry B replaces Entry A Accept?. Press YES to
7.
confirm. You hear a confirmation tone.
90
Directory
Speed dial directory
Delete a speed dial entry
Using a handset or telephone base:
Press MENU in idle mode.
1.
Press CID or DIR on the handset, or CIDor DIR on the telephone
2.
base to highlight Directory and then press SELECT .
Press CID or DIR on the handset, or CIDor DIR on the telephone
3.
base to highlight Speed dial, then press REVIEW .
Press CID or DIR on the handset, or CIDor DIR on the telephone
4.
base to highlight assigned slot, then press MUTE/DELETE on the handset
or DELETE/X on the telephone base.
The screen displays Delete Entry A speed dial assignment?. Press YES to
5.
confirm. You hear a confirmation tone.
NOTE: Deleting a speed dial entry does not affect the directory entry.
91
Caller ID
About caller ID
This product supports caller ID services provided by most telephone service
providers. Caller ID allows you to see the name, number, date and time of
calls. The available caller ID information will appear after the first or
second ring. Caller ID from the home line and cell line allows you to see the
name, number, date and time of the incoming calls. The caller ID may appear
differently if the caller is matched to a directory entry (see Memory match
on page 93).
Information about caller ID with call waiting
Caller ID with call waiting lets you see the name and telephone number of
the caller before answering the telephone, even while on another call.
It may be necessary to change your telephone service to
use this feature. Contact your telephone service provider if:
You have both caller ID and call waiting, but as separate
•
services (you may need to combine these services).
You have only caller ID service, or only call waiting service.
•
You don’t subscribe to caller ID or call waiting services.
•
There are fees for caller ID services. In addition, services
may not be available in all areas.
Caller ID information is available only if both you and the
CHARLIE JOHNSON
888-883-2445
5:32am 8/06
NEW
CHARLIE JOHNSON
888-883-2445
5:32am 8/06
NEW
SAVE
SAVE
caller are in areas offering caller ID service, and if both telephone service
providers use compatible equipment.
The caller ID information may not be available for every incoming call. The
callers may intentionally block their names and/or telephone numbers. A
caller ID log entry can show a maximum number of 15 digits.
NOTE: You can use this product with regular caller ID service, or you can use this
product’s other features without subscribing to caller ID or combined caller ID with call
waiting service.
92
Caller ID
Caller ID operation
How the caller ID log works
The telephone stores caller ID information about the last 50 incoming calls
in the telephone base. Entries are stored in reverse chronological order. The
phone deletes the oldest entry when the log is full to make room for new
calls. This information is common to the telephone base and all handsets, so
changes made using any handset or the telephone base are reflected in all
other handsets. If you answer a call before the information appears on the
screen, it does not show in the caller ID log.
NOTE: If the phone number has more than 15 digits, only the last 15 digits will be saved or
shown in the caller ID log.
Memory match
If the incoming telephone number matches the last 7 digits of a telephone
number in your directory, the name that appears on the screen matches the
corresponding name in your directory.
For example, if Christine Smith calls, her name appears as Chris if this is how
you entered it into your directory.
NOTE:
The number you see on your caller ID is in the format sent by the telephone service
provider. It usually delivers 10-digit telephone numbers (area code plus telephone number). If
the last 7 digits of the incoming telephone number do not match a number in your directory,
the name appears as it is delivered by the telephone service provider.
93
Caller ID
Caller ID operation
Review the caller ID log
Review the caller ID log to find out who called, to easily
return a call, or to copy the caller’s name and number into
your directory. Caller ID log empty appears if there are no
records in the caller ID log.
Using a handset:
When a handset is in idle mode, press CID to review the
1.
caller ID log in reverse chronological order starting with
the most recent call.
-OR-
HANDSET 1
6 Missed calls
7:45am 8/06
BACK
MENU
You can also review the caller ID log by pressing MENU .
Press
CID or DIR
to scroll to Caller ID log, then press
SELECT .
Press CID or DIR to highlight the desired line (home
2.
or cell), then press REVIEW .
Press CID or DIR to browse.
3.
Caller’s name
NEW
Caller’s number
Charlie Johnson
888-883-2445
7:45am 8/06
Time of call
SAVE
Play messages
Answe ring sys
Directory
Caller ID log
BACK
Charlie Johnson
888-883-2445
7:45am 8/06
BACK
SELECT
SAVE
Appears when there
are new or missed
calls.
Date of call
94
Loading...
