User’s manual

TL72108/TL72208/

TL72308/TL72408

5.8 GHz cordless

telephone/answering system

with caller ID/call waiting

Congratulations

on your purchase

of this AT&T product.

Before using this AT&T product, please

read the Important safety information

on pages 65-67 of this manual.

Please thoroughly read this user’s

manual for all the feature operations

and troubleshooting information necessary

to install and operate your new

AT&T product. You can also visit our

website at www.telephones.att.com or call

1 (800) 222-3111.

In Canada, dial 1 (866) 288-4268.

Model #: TL72108 (single handset)/TL72208 (two handsets)/

TL72308 (three handsets)/TL72408 (four handsets)

Type: 5.8 GHz cordless telephone/answering system

Serial #:

Purchase date:

Place of purchase:

Both the model and serial number of your AT&T product can be found on the bottom of the telephone base.

Save your sales receipt and original packaging in case it is necessary to return your telephone for warranty service.

© 2008 Advanced American Telephones. All rights reserved. AT&T and the AT&T logo are trademarks of AT&T Intellectual Property II, L.P. d/b/a AT&T Intellectual Property licensed to Advanced American Telephones. Printed in China.

Parts checklist

Save your sales receipt and original packaging in case it is necessary to ship your telephone for warranty service.

Your telephone package includes the following items.

User’s manual

TL72108/TL72208/

TL72308/TL72408

5.8 GHz cordless

telephone/answering system

with caller ID/call waiting

Quick start guide

TL72108/TL72208/

TL72308/TL72408

5.8 GHz cordless

telephone/answering system

with caller ID/call waiting

User's manual Quick start guide

Charger for cordless handset (One for TL72208) (Two for TL72308) (Three for TL72408)

Cordless handset (One for TL72108) (Two for TL72208) (Three for TL72308) (Four for TL72408)

Battery for cordless handset (One for TL72108) (Two for TL72208) (Three for TL72308) (Four for TL72408)

Telephone base with mounting bracket installed

Battery compartment cover (One for TL72108) (Two for TL72208) (Three for TL72308) (Four for TL72408)

telephone base

Power adapter for handset charger (One for TL72208) (Two for TL72308) (Three for TL72408)

Belt clip for cordless handset (One for TL72108) (Two for TL72208) (Three for TL72308) (Four for TL72408)

Telephone line cordPower adapter for

User’s manual

TL72108/TL72208/ TL72308/TL72408

5.8 GHz cordless telephone/answering system with caller ID/call waiting

Table of contents

Getting started

Quick reference guide

handset ..............................................2

telephone base ..............................3

Installation preparation ...................4

Telephone base & charger

installation .......................................5

Battery installation & charging ....6

Belt clip & optional headset ...............7

Installation options ...................................8

Telephone operation

Handset operation ...........................12

Options while on calls ................... 15

Chain dialing ...................................... 17

Intercom ............................................... 18

Call transfer using intercom ....... 19

Handset settings .............................. 20

Directory

Directory ............................................... 25

New directory entries .................... 26

Directory review ............................... 28

Directory search ............................... 29

To dial, delete or edit entries ........ 30

Caller ID operation

Caller ID operation .......................... 31

Caller ID history ................................ 34

Answering system operation

About the answering system ..... 36

Day & time announcement ......... 38

Answering system mode .............. 39

Outgoing announcements ........... 40

Answering system setup .............. 42

Message playback............................46

Recording & playing memos ...... 47

Message counter displays ........... 48

Remote access .................................. 49

Appendix

Screen icons, indicator

lights & tones ...................................51

Handset display screen

messages .............................................52

Adding and registering

handsets ...............................................54

Replacing a handset ....................... 55

Troubleshooting ................................ 56

Maintenance ....................................... 64

Important safety information ..... 65

FCC Part 68 and ACTA .................. 68

FCC Part 15.........................................70

Limited warranty .............................. 71

Technical specifications ................ 74

Index ....................................................... 75

Getting started

Quick reference guide - handset

CHARGE

On when the handset is charging in the telephone base or charger.

CID

Press to display caller ID information (page 34).

PHONE/FLASH

Press to make or answer a call. During a call, press to receive an incoming call if call waiting is activated (page 15).

REDIAL/PAUSE

Press to view redial memory (page 13). While entering numbers, press and hold to insert a dialing pause (page 26).

MUTE/REMOVE

During a call, press to mute microphone (page 16). While reviewing the caller ID history, press to delete an individual entry, or press and hold to clear the caller ID history (page 34). While predialing, press to delete digits (page 12).

SPEAKER

Press to turn on the handset speakerphone. Press again to resume normal handset use (page 12).

Press or to scroll up or down while in menus. While entering names or numbers, press or to move the cursor to the left or right.

MENU/SELECT

Press to enter the menu. While in the menu, press to select an item or save an entry or setting.

DIR

Press to display directory entries (page 28).

VOLUME

Press the volume key on the side of the handset to adjust listening volume. Each press of the button increases or decreases the volume.

OFF/CLEAR

During a call, press to hang up. While using menus, press to cancel an operation, back up to the previous menu, or exit the menu display.

INT

Press to begin an intercom conversation or to transfer a call (pages 18-19).

Feature menu

The > symbol shows a highlighted menu item.

<DIRECTORY

CALL LOG

Feature menu

DIRECTORY (page 25) CALL LOG (page 31) RINGER VOLUME (page 20) RINGER TONE (page 21) KEY TONE (page 21) LANGUAGE (page 22) CLR VOICE MAIL (page 23)

Using menus

Press or to scroll

through menu items. Press MENU/SELECT to select

or modify a highlighted item.

Press OFF/CLEAR to cancel an operation, back up to the previous menu, or exit the menu display.

Getting started

Quick reference guide - telephone base

IN USE

On when handset

• is in use, when the answering system is answering an incoming call or when you are registering a handset.

Flashes when another

• telephone is in use on the same line or when you are deregistering handset(s) from the telephone base.

Flashes quickly when

• there is an incoming call.

MESSAGE COUNTER

Number of messages (or during playback, message number currently playing).

/REPEAT

Press to repeat message. Press twice to play previous message (page 46).

ANSWER ON

Press to turn answering system on or off (page 39).

CLOCK

Press to review or set clock (page 38).

SETUP

Press to hear and change setup options (pages 42-45).

ANNC.

Press to review or record outgoing announcement. Press again to end announcement playback or recording (pages 40-41).

Answering System Functions

VOICEMAIL

Flashes when you have new voicemail. Voicemail is a service offered by your local telephone company, and is different from answering system messages (page 23).

HANDSET LOCATOR

Press so that handsets will beep to locate misplaced handsets (page 14).

PLAY/STOP

Press to start or stop message playback (page 46).

X/DELETE

Press to delete the message currently playing. When no messages are playing, press twice to delete all old messages (page 46).

/SKIP

Press to skip message (page 46).

VOLUME

Press to adjust playback volume (page 46).

RECORD

Press to record a memo (page 47) or, after pressing ANNC., to record an outgoing announcement (pages 40-41).

Getting started

Installation preparation

You must install and charge the battery before using the telephone.

If you subscribe to high-speed Internet service (Digital Subscriber Line - DSL) through your telephone lines, you must install a DSL filter between the telephone base and the telephone wall jack (see page 5). The filter will prevent noise and caller ID problems caused by DSL interference. Please contact your DSL service provider for more information about DSL filters.

Your product may be shipped with a protective sticker covering the handset or telephone base display - remove it before use.

For customer service or product information, visit our website at

STOP!

See page 6

for easy instructions.

www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

Avoid placing the telephone base too close to:

• Communication devices such as: television sets, VCRs, or other cordless telephones.

• Excessive heat sources.

• Noise sources such as a window with traffic outside, motors, microwave ovens, refrigerators, or fluorescent lighting.

• Excessive dust sources such as a workshop or garage.

• Excessive moisture.

• Extremely low temperature.

• Mechanical vibration or shock such as on top of the washing machine or work bench.

Getting started

WALL

DESK

Telephone base & charger installation

If you subscribe to high-speed Internet service (Digital Subscriber Line - DSL) through your telephone lines, you must install a DSL filter between the telephone base and the telephone wall jack. The filter will prevent noise and caller ID problems caused by DSL interference. Please contact your DSL service provider for more information about DSL filters.

Install the telephone base as shown below.

Telephone base installation

1. Plug the small

end of the larger power adapter into the power jack at the bottom of the telephone base.

DSL filter (not included) Required if you have DSL high-speed Internet service.

Telephone wall jack

5. Plug the other end

of the telephone line cord into a telephone jack.

Charger installation

1. Plug the small end

of the smaller power adapter into the jack on the underside of the charger, then route the cord through the slot as shown.

2. Plug one end of the

telephone line cord into the telephone jack at the bottom of the telephone base.

3. Route cords

through slots.

Telephone line cord

Power adapter

4. Plug the large end

of the larger power adapter into a power outlet not controlled by a wall switch.

2. Plug the large end

of the smaller power adapter into a power outlet not controlled by a wall switch.

IMPORTANT INFORMATION

Use only the power adapter supplied with this product. To order a replacement power adapter,

visit our website at www.telephones.att.com, or call

1 (800) 222-3111. In Canada dial 1 (866) 288-4268.

2. The power adapters are intended to be correctly oriented in a vertical or floor mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling, under-thetable or cabinet outlet.

Getting started

THIS SIDE UP

WARNING:DO NOT BURN OR

PUNCTURE BATTERIES

MADE IN CHINA

Battery Pack

BT5633/BT6823

3.6V 550mAh Ni-MH

THIS SIDE UP

WARNING:DO NOT BURN OR

PUNCTURE BATTERIES

MADE IN CHINA

Battery Pack

BT5633/BT6823

3.6V 550mAh Ni-MH

THIS SIDE UP

WARNING:DO NOT BURN OR

PUNCTURE BATTERIES

MADE IN CHINA

Battery Pack

BT5633/BT6823

3.6V 550mAh Ni-MH

THIS SIDE UP

WARNING:DO NOT BURN OR

PUNCTURE BATTERIES

MADE IN CHINA

Battery Pack

BT5633/BT6823

3.6V 550mAh Ni-MH

Battery installation & charging

Install the battery as shown below. After installing the battery, you can make and receive short calls, but replace the handset in the telephone base or additional charger when not in use. For optimal performance, charge the handset battery for at least 16 hours before use. When fully charged, the handset battery provides approximately five hours of talk time or three days of standby time.

If the battery is depleted, it may take approximately four minutes to charge the handset before it can resume screen display. The screen will continue to display LOW BATTERY until the battery has charged for approximately one hour.

Step 1

Plug the battery securely into the plug inside the handset battery compartment, matching the color-

Step 2

Insert the supplied battery with the label THIS SIDE UP facing up as indicated.

Step 3

Align the cover flat against the battery compartment cover, then slide it upwards until it clicks into place.

coded label.

Step 4

Charge the handset by placing the handset face up in the telephone base or in the additional charger. The

CHARGE light will be on when charging.

IMPORTANT INFORMATION

Use only the battery supplied with this product. To order a replacement or spare battery (AT&T model 27910, part number 89-0099-00-00) or equivalent, visit our website at

www.telephones.att.com, or call 1 (800) 222-3111. In Canada dial 1 (866) 288-4268.

Getting started

Belt clip & optional headset

To attach the belt clip:

Snap the belt clip into the retaining tabs on both sides of the handset as shown in the figure.

To remove the belt clip:

Gently lift either of the belt clip retaining tabs, shown in the figure, outwards to remove the belt clip from the handset.

For handsfree headset conversations, use any industry standard 2.5 mm headset (purchased separately). For best results, use an AT&T 2.5 mm headset. To purchase a headset, visit our website at

www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

Lift the rubber flap here.

Plug a 2.5 mm headset into the jack on the side of the handset.

Side of handset.

WALL

DESK DESK

Getting started

Installation options

NOTE: The mounting bracket must be used for both tabletop and wall mounting positions.

The telephone base comes with the mounting bracket already installed for desktop use. If wall mounting is desired, a telephone outlet wall mounting plate with mounting studs is required. This mounting plate with studs is available for purchase from many handware or consumer electronics retailers and may require professional installation.

Desktop to wall mount installation

To install the telephone base in the wall mount position, make sure that you unplug all cords connected to the telephone base before you begin.

1. Push the top of the bracket towards the back of the telephone base.

With the top of the bracket

pushed up against the telephone base, the WALL labels will match.

Push down firmly on the

bracket until it clicks into place.

Side view

Desk mode

Wall mode

Getting started

DESK

DES

DESK

DES

DESK

Installation options

Desktop to wall mount installation (continued)

2. Plug the telephone line cord and power adapter into the telephone base. Bundle the telephone line cord and power adapter cord, and secure them with a twist tie before placing them in the bracket channels.

DSL filter (not included), required if you have DSL high-speed Internet service.

3. Place the bundled telephone line cord and power adapter cord into the cavity under the telephone base as shown below.

4. Plug the power adapter and telephone line cord into the wall outlets, then align the mounting studs on the telephone outlet plate with the mounting holes on the bracket.

DESK DESK

Getting started

Installation options

Wall mount to desktop installation

To change the telephone base from the wall mount position to desktop position.

1. Make sure that you unplug the power adapter and telephone line cord from the wall outlets before you begin.

2. Untie the bundled telephone cord and power adapter cord, and remove them from the telephone base.

3. Push the bottom of the bracket down towards the back of the telephone base.

With the bottom of the bracket pushed down against the telephone base,

the DESK labels will match.

Push down on the bracket until it clicks into place.

Side view

Wall mode

Desk mode

Getting started

WALL

DESK

Installation options

Wall mount to desktop installation (continued)

4. Plug the telephone line cord into the telephone base and telephone wall jack, then plug the power adapter plug into the telephone base and an electrical wall outlet not controlled by a wall switch (see page 5) and place the cords in the bracket channels.

DSL filter (not included) Required if you have DSL high-speed Internet service.

Telephone wall jack

Telephone line cord

Power adapter

Telephone operation

PHONE 0:00:30

NOTE:

Pressing

PHONE/FLASH to

access services from your local telephone service provider will not affect the elapsed time.

SPEAKER 0:00:30

Elapsed time

Handset operation

Making a call

To make a call:

• Press PHONE/FLASH or SPEAKER, then enter

the telephone number.

To end a call:

• Press OFF/CLEAR or return the handset to the

telephone base or charger.

The screen displays the elapsed time as you talk (in hours, minutes and seconds).

On-hook dialing (predialing)

• Enter the telephone number. Press

MUTE/REMOVE or OFF/CLEAR to make

corrections as you enter the phone number.

• Press PHONE/FLASH or SPEAKER to dial.

Handset speakerphone

During a call you can press SPEAKER to alternate between hands-free speakerphone and normal handset use. Press OFF/CLEAR to hang up.

NOTE: If a headset is plugged into the handset, you will

not be able to use the handset speakerphone.

Answering a call

To answer a call:

• Press PHONE/FLASH or SPEAKER. –OR–

• Press any dial pad key (0-9, * or #).

To end a call:

• Press OFF/CLEAR or return the handset to the

telephone base or charger.

Telephone operation

REDIAL

555-1234

Handset operation

Auto off

A call will be ended automatically when you put the handset in the telephone base or charger.

Last number redial

To view the five most recently dialed numbers:

• Press REDIAL/PAUSE to display the most

recently called number (up to 30 digits).

• Press , or REDIAL/PAUSE repeatedly to

view up to five recently called numbers.

The handset will beep twice at the beginning and end of the list.

Press OFF/CLEAR to exit.

To redial a number:

• Press PHONE/FLASH or SPEAKER to dial

the displayed number.

–OR–

• Press PHONE/FLASH or SPEAKER then REDIAL/PAUSE to call the most recently called

number (up to 30 digits).

Press MUTE/REMOVE to delete the displayed number from the redial memory.

Telephone operation

**PAGING**

Handset operation

Handset locator

The handset locator feature is useful if you misplace a handset.

To start the paging tone:

• Press HANDSET LOCATOR at the telephone

base. This starts the paging tone at the handset(s) for 60 seconds to help you locate the handset(s).

NOTE: When paging, if you press OFF/CLEAR or MUTE/REMOVE on a handset, the ringer of the handset

will be silent but the handset locator feature will not be canceled.

To stop the paging tone:

• Press PHONE/FLASH, SPEAKER, or any dial

pad key (0-9, *, or #) on the handset(s).

–OR–

• Press HANDSET LOCATOR on the telephone

base.

NOTE: The handset ringer volume also determines the level of the paging tone. If the handset ringer volume level is set to off, that handset will be silent for all calls and paging (page 20).

Telephone operation

Options while on calls

Volume control

Press the VOLUME keys on the side of the handset to adjust listening volume. Each press of the button increases or decreases the volume.

Volume control

NOTES:

1. All volume settings (normal handset, speakerphone and headset) are independent.

2. When the volume level has reached the minimum or maximum setting, you will hear two beeps.

Call waiting

If you subscribe to call waiting service with your local telephone service provider, you will hear a beep if someone calls while you are already on a call. Press PHONE/FLASH to put your current call on hold and answer the new call. You can press PHONE/FLASH at any time to switch back and forth between the calls.

Multiple handset use (not for model TL72108)

If you would like to join an ongoing call, press

PHONE/FLASH or SPEAKER on another system

handset. Press OFF/CLEAR or place the handset in the

telephone base or charger to exit the call. The call will not be terminated until all handsets hang up.

NOTE: A maximum of two handsets can be used at once on an outside (not an intercom) call.

Telephone operation

NOTE: You cannot press OFF/CLEAR

to exit redial, directory or caller ID access without ending the call.

Options while on calls

Mute

The mute function allows you to silence the microphone. You can hear the caller, but the caller will not be able to hear you.

To mute the call:

• Press MUTE/REMOVE to silence the

microphone. When mute is on, the handset screen will show MUTED for a few seconds and the MUTE icon will be shown until mute is turned off.

To un-mute the call:

• Press MUTE/REMOVE again and resume

speaking. When mute is turned off, MICROPHONE ON will display temporarily on the handset screen.

Telephone operation

NOTES:

1. While reviewing the directory on a call, editing an

entry is not allowed. For more details about the directory, see page 25.

While reviewing the caller ID history on a call, storing the caller ID number in the directory is not allowed. For more details about the caller ID history, see page 31.

3. While on a call, only the most recently called number can be reviewed, and erasing the entry is not allowed. For more details about the redial memory, see page 13.

Chain dialing

This feature allows you to initiate a dialing sequence from numbers stored in the directory, caller ID history or redial list while you are on a call.

Chain dialing can be useful if you wish to access numbers other than phone numbers (such as bank account information or access codes) from the directory, caller ID history or redial list.

Directory

While on a call, you can press DIR to review the directory. To dial the displayed number, press

MENU/SELECT.

Caller ID history (call log)

While on a call, you can press CID to review the caller ID history. To dial the displayed number, press MENU/SELECT.

Last number redial

If you have already pressed PHONE/FLASH or

SPEAKER, press REDIAL/PAUSE to display and

dial the most recently dialed number. If you press REDIAL/PAUSE again within two seconds, the number will not be dialed.

Telephone operation

NOTES:

1. Before the intercom call is answered, you can cancel the intercom call by pressing OFF/CLEAR or INT on the calling handset.

2. If the called handset is not answered within 100 seconds or if it is in the directory or call log mode, or on a call, or out of range, the calling handset will show the message UNABLE TO CALL TRY AGAIN.

3. Pressing OFF/CLEAR or MUTE/REMOVE will temporarily silence the intercom ringer.

4. A maximum of two handsets can be used at once on the same intercom call. For model TL72408, four handsets can be used for two different intercom calls at once.

5. During an intercom call, there will be an alert tone signaling an incoming call. Press PHONE/FLASH or INT to answer the incoming call. The intercom call will be ended automatically.

Intercom

Use the intercom feature for conversation between handsets. (This feature is not available on model TL72108.)

Models TL72208/TL72308/TL72408

1. Press INT. The screen will show INTERCOM TO:

2. Enter a handset number. The screen will show

CALLING HANDSET X. The called handset will ring, and its screen will show HANDSET Y IS CALLING.

3. On the ringing handset, press PHONE/FLASH, INT, SPEAKER, or any dial pad key (0-9, * or #) to answer the intercom call.

To end the intercom call:

• Press OFF/CLEAR or INT on either handset.

-OR-

• Place either handset in the charger or telephone base.

To make an intercom call while on a call:

If you are on an external call and you wish to intercom another system handset without disconnecting the external call:

1. During a conversation with an outside call, press INT. The outside call is automatically placed on hold and TRANSFER TO: is displayed on the screen.

2. Enter a handset number. The screen will show CALLING HANDSET X. The called handset will ring, and its screen will show HANDSET Y IS CALLING.

3. On the ringing handset, press PHONE/FLASH, INT, SPEAKER, or any dial pad key (0-9, * or #) to answer the intercom call. You can now talk without the outside caller hearing the conversation.

4. Press INT repeatedly on the calling handset to alternate between the external (outside) call and the intercom call.

Telephone operation

Call transfer using intercom

Use the intercom feature to transfer an outside call from one handset to another. (This feature is not available on model TL72108.)

Models TL72208/TL72308/TL72408

1. During a conversation with an outside call,

press INT. The outside call is automatically placed on hold and TRANSFER TO: is displayed on the screen.

2. Enter a handset number. The screen will show

CALLING HANDSET X. The called handset will ring, and its screen will show HANDSET Y IS CALLING.

3. On the ringing handset, press PHONE/FLASH, INT, SPEAKER, or any dial pad key (0-9, * or #) to answer the intercom call. You can now talk without the outside caller hearing the conversation.

4. Press OFF/CLEAR on the calling handset or place it in the telephone base or handset charger to complete the transfer. The calling handset’s screen will show CALL TRANSFERED and the other handset will automatically be connected to the outside call.

NOTES:

1. Before the intercom call is answered, you can cancel the transfer and return to the outside call by pressing

OFF/CLEAR, PHONE/FLASH, or INT.

2. If the called handset does not answer the intercom call within 100 seconds, or if the other handset is in the directory or call log mode, or out of range, the calling handset will show UNABLE TO CALL TRY AGAIN on its screen and will automatically return to the outside call.

3. You can switch between the intercom call and the outside call by pressing INT on the calling handset. The display will change between INTERCOM and OUTSIDE CALL to indicate which party is active.

4. You can end the intercom call and return to the outside call by pressing PHONE/FLASH on the calling handset.

Telephone operation

DIRECTORY CALL LOG

RINGER VOLUME RINGER TONE

RINGER VOLUME

Handset settings

Using the feature menu, you can change settings to customize how the telephone works.

1. Press MENU/SELECT in idle mode (when the

phone is not in use) to enter the feature menu.

2. Use or to scroll to the feature to be changed. When scrolling through the menu, the top menu item is always highlighted with a > symbol.

3. Press MENU/SELECT to select the highlighted item.

NOTE:

To cancel an operation, back up to the previous

menu or exit the menu display, press OFF/CLEAR. Press and hold OFF/CLEAR to return to idle mode.

Ringer volume

Using this menu, you can set a ring volume level (1-6), or turn the ringer off. When the ringer is turned off, the will appear on the handset screen.

To adjust the RINGER VOLUME:

1. Press MENU/SELECT in idle mode to enter the feature menu.

Use VOLUME menu, then press MENU/SELECT.

3. Press or to sample each volume level.

4. Press MENU/SELECT to save your preference and return to the feature menu.

-OR-

When the handset is in idle mode, press the VOLUME buttons on the right side of the handset to change ringer volume.

to scroll to the >RINGER

NOTE: The ringer volume level also determines the

ringer levels of intercom calls (pages 18-19) and the handset locator paging tone (page 14). If the handset ringer volume level is set to off, that handset is silenced for all incoming calls and paging.

Telephone operation

DIRECTORY

CALL LOG

Handset settings

Ringer tone

This feature allows you to choose one of 10 ringer tones.

To choose a ringer tone:

1. Press MENU/SELECT in idle mode to enter the

feature menu.

RINGER TONE

KEY TONE

RINGER TONE

DIRECTORY

CALL LOG

KEY TONE

LANGUAGE

KEY TONE ON

2. Use

to scroll to the >RINGER

TONE

menu, then press MENU/SELECT.

3. Press or to sample each ringer tone.

4. Press MENU/SELECT to save your preference and

return to the feature menu.

Key tone

The handset is factory programmed to beep with each key press. If you turn off the KEY TONE, there will be no beeps when keys are pressed.

To turn the KEY TONE on or off:

1. Press MENU/SELECT in idle mode to enter the

feature menu.

2. Use or to scroll to the >KEY TONE menu, then press MENU/SELECT.

3. Press or to select ON or OFF.

4. Press MENU/SELECT to save your preference and return to the feature menu.

Telephone operation

DIRECTORY

CALL LOG

Handset settings

Language

In this menu, you can select the language used for all screen displays.

To select a language:

1. Press MENU/SELECT in idle mode to enter the

feature menu.

LANGUAGE

CLR VOICE MAIL

LANGUAGE ENGLISH

2. Use or to scroll to the >LANGUAGE menu, then press MENU/SELECT.

3. Press or to select ENGLISH, FRANCAIS or ESPANOL.

4. Press MENU/SELECT to save your preference and return to the feature menu.

Telephone operation

DIRECTORY

CALL LOG

CLR VOICE MAIL DIRECTORY

TURN INDICATOR

OFF?

Handset settings

Visual message waiting (voicemail) indicator

If you subscribe to a voicemail service offered by your local telephone company, the voicemail waiting indicator feature will provide visual indication when you have new voicemail messages. The VOICEMAIL light on the telephone base will flash, and NEW VOICE MAIL and the icon will appear on the handset screen(s).

NOTES:

1. This feature does not indicate new answering system messages recorded on your phone.

2. For more information about the difference between your answering system and voicemail, see page 36.

To clear voicemail indication

Use this feature when the telephone indicates that there is new voicemail but there is none (for example, when you have accessed your voicemail from a different telephone line while away from home). This feature only turns off the displayed

NEW VOICE MAIL message, the icon and the VOICEMAIL light; it does not delete your voicemail

message(s). If there actually are new voicemail messages, your local telephone company will continue to send the signal to turn on the visual message waiting indication.

To manually turn off the new voicemail indication:

NOTES:

1. Telephone company voicemail may alert you to new messages with stutter (broken) dial tone. Contact your telephone company for more details.

2. For information about using your voicemail service contact your telephone company for assistance.

1. Press MENU/SELECT in idle mode to enter the

feature menu.

2. Use or to scroll to the >CLR VOICE MAIL menu, then press MENU/SELECT.

3. Press MENU/SELECT again to turn the voicemail indication off, or press OFF/CLEAR to cancel the procedure.

Telephone operation

Handset settings

Temporary ring silencing

Press OFF/CLEAR or MUTE/REMOVE while the telephone is ringing to silence the ringer temporarily. This will silence the ringer without disconnecting the call. The next incoming call will ring normally at the preset volume.

NOTE: If more than one handset is installed, each handset will ring when there is an incoming call unless

the volume is turned off. Pressing OFF/CLEAR or

MUTE/REMOVE on one handset will only silence the

ringer of that particular handset.

Directory

Pat Williams

555-1234

Directory

Shared directory

The directory is stored in the telephone base, and is shared by all handsets. Changes made to the directory on any one handset will apply to all.

NOTE: Only one handset can review the directory at a

time. If another handset attempts to use the directory, the screen will display NOT AVAILABLE AT THIS TIME.

Memory capacity

The directory can store up to 50 entries, with a maximum of 15 alphanumeric characters (including spaces) for the names and 30 digits for the telephone numbers. A convenient search feature can help you find and dial numbers quickly (page

29).

If all memory locations are in use, the screen will display LIST FULL. You will not be able to store a new number until an existing one is deleted.

Exiting the directory

Press OFF/CLEAR to cancel an operation, back up to the previous menu, or exit the menu display. Press and hold OFF/CLEAR to return to the idle mode.

If you pause for too long while creating or reviewing an entry, the procedure will time out and you will have to begin again.

Directory

DIRECTORY CALL LOG

REVIEW STORE

New directory entries

To create and store a new directory entry

1. Press MENU/SELECT in idle mode to enter the

feature menu.

2. Press MENU/SELECT again to enter the

>DIRECTORY menu.

3. Press to highlight STORE.

4. Press MENU/SELECT.

5. Enter the telephone number when prompted.

• Use the dial pad to enter up to 30 digits.

STORE REVIEW

ENTER NUMBER

555-1234_

– Press or to move the cursor to the

left or right.

– Press MUTE/REMOVE to erase numbers.

– Press and hold MUTE/REMOVE to erase

all numbers.

– Press and hold REDIAL/PAUSE to enter a

three-second dialing pause.

-OR-

• Copy a number from redial by pressing

REDIAL/PAUSE then press or

to locate the number to copy. Press

MENU/SELECT to copy the number.

6. Press MENU/SELECT to save the number in the display. The display will show ALREADY SAVED if the number is already in the directory, then you will need to enter another number before pressing MENU/SELECT to continue.

Directory

Dial Key

Characters by number of key presses

3 4 5 6 7 8 9 0 0

# , .- &‘

? ! / ( )

1 1 A B C 2

a b c 3 d e f 4 g h i 5 j k l 6 m n o S 7 p q 8

t u v

Z 9 w xrysz

D E F G H

J K

L M N O P Q R T U V

space

X Y

3 4 5 6 7 8 9

ENTER NAME Pat Williams_

NOTE: The first letter of every word will be capitalized. The remaining letters in a word will be lowercase as shown in the chart on the right.

New directory entries

7. Enter the name when prompted.

• Use the dial pad to enter a name (up to 15 characters). Each time a key is pressed, the character on that key will be displayed. Additional key presses will produce other characters on that key. See the chart below.

– Press or to move the cursor to the left or right.

– Press MUTE/REMOVE to erase letters.

– Press and hold MUTE/REMOVE to erase

all letters.

Pat Williams

555-1234

8. Press MENU/SELECT to store your new directory entry. The name and the telephone number will then be shown on the screen. To change it later, see page 30.

Directory

555-6789

Andrew

Directory review

To review directory entries

1. Press DIR in idle mode to display the first listing in the directory. DIRECTORY EMPTY will be displayed if there are no directory entries.

-OR- You can also display the first listing in the directory by first pressing MENU/SELECT twice, then press MENU/SELECT again to choose

>REVIEW.

Barbara

555-9876

2. Press or to browse through the directory. Entries will be displayed alphabetically by the first letter in the name.

Directory

Directory search

To search by name

1. Press DIR in idle mode to display the first listing in the directory. DIRECTORY EMPTY will be displayed if there are no directory entries.

2. When a name entry is displayed, press the dial pad keys (2-9) to start a name search.

The directory will display the first name

beginning with the first letter associated with the dial pad key, if there is an entry in the directory that begins with that letter.

3. To see other names that start with the letters on the dial pad key, keep pressing the key. The names will be shown in alphabetical order.

For example, if you have name entries Jennifer, Jessie, Kevin and Linda in your directory:

• If you press 5 (JKL) once, you will see Jennifer.

• If you press 5 (JKL) twice, you will see Jessie.

• If you press 5 (JKL) three times, you will see Kevin.

• If you press 5 (JKL) four times, you will see Linda.

• If you press 5 (JKL) five times, you will see Jennifer again.

NOTES:

1. If there is no name entry matching the first letter of the key you press, you will see a name entry that matches the second letter of the key.

2. If you press a key (2-9) and there is no name entry to match those letters, the directory will show the entry that matches the next letter in the directory.

Directory

To dial, delete or edit entries

To dial, delete or edit a directory entry (name and number), the entry must be displayed on the handset. Use directory search or review (pages 28-29) to display an entry.

Display dial

To dial a displayed number from the directory, press PHONE/FLASH or SPEAKER.

To delete an entry

When a directory entry is displayed, press

MUTE/REMOVE to delete the displayed entry from

the directory. Once deleted, an entry cannot be retrieved.

To edit an entry

When a directory entry is displayed:

1. Press MENU/SELECT to modify the entry. You will be prompted to EDIT NUMBER.

Andrew

555-6789

EDIT NUMBER

555-1234

EDIT NAME Andy

Andy

555-1234

• Press the dial pad keys to add digits.

• Press MUTE/REMOVE to erase digits.

• Press or to move the cursor.

• Press and hold REDIAL/PAUSE to add a

three-second pause if desired.

• Press REDIAL/PAUSE, then or to

scroll to a previously dialed number. Press MENU/SELECT to add the redial number to the entry.

2. Press MENU/SELECT. You will be prompted toYou will be prompted to

EDIT NAME.

• Press the dial pad keys to add characters (page 27).

• Press MUTE/REMOVE to erase characters.

• Press or to move the cursor.

3. Press MENU/SELECT to confirm.

Caller ID operation

CHRISTINE SMITH

908-555-0100

10:01

NOTE: Caller ID features will work only if both you and the caller are in areas offering caller ID service, and if both telephone companies use compatible equipment. The time and date are sent by the telephone company along with the call information.

NEW

11/23

Caller ID operation

Information about caller ID with call waiting

This product has caller ID with call waiting feature that works with your local telephone company service.

This product can be used with regular caller ID service, or this product’s other features can be used without subscribing to either caller ID or combined caller ID with call waiting service.

There are fees for caller ID services. In addition, services may not be available in all areas.

Depending on your service, caller ID with call waiting lets you see the name and telephone number of the caller before answering the telephone, even while on another call.

It may be necessary to change your telephone service to use this feature. Contact your telephone company if:

• You have both caller ID and call waiting, but as separate services (you may need combined service).

• You have only caller ID service, or only call waiting service.

• You do not have any caller ID or call waiting services and would like to use this feature.

Caller ID operation

CHRISTINE SMITH

908-555-0100

10:01

11/23

NEW

Caller ID operation

How the caller ID history (call log) works

The caller ID history stores information about the last 50 incoming calls. Review the caller ID history to find out who called, to easily return the call, or to copy the caller’s name and number into your directory.

The caller ID history deletes the oldest entry when the log is full to make room for new incoming calls.

If you answer a call before the information appears on the screen, it will not be saved in the caller ID history.

The caller ID history is stored in the telephone base, and is shared by all handsets. Changes made at any one handset will be reflected in all.

NOTE: Only one handset can review the caller ID

history at a time. If another handset attempts to enter the directory or caller log, it will display NOT AVAILABLE AT THIS TIME.

Caller’s name

CHRISTINE SMITH

908-555-0100

NEW

10:01

Time of call

11/23

Caller’s number

Appears when the call is missed and un-reviewed

Date of call

Caller ID operation

Chris

908-555-0100

10:01

HANDSET 1

6 MISSED CALLS

Pat Williams

555-1234

NEW

10:31

11/23

NEW

11/23

Caller ID operation

Memory match

If the incoming telephone number exactly matches a telephone number in your directory, the name that appears on the screen will match the corresponding name in your directory.

For example, if Christine Smith calls, her name will appear as Chris if this is how you entered it into your directory.

NOTE: The number shown by your caller ID will be in

the format sent by the phone company. The phone company usually delivers ten-digit phone numbers (area code plus phone number). If the telephone number of the person calling does not exactly match a number in your directory, the name will appear as delivered by the phone company. For example if the phone company includes the area code and the directory number does not, the name will appear as delivered by the phone company.

Missed (new) call indicator

When a handset is in idle mode and has calls that have not been reviewed, its screen will show XX MISSED CALLS.

All entries which have not been reviewed will be counted as missed calls when the phone is idle. Each time an entry from the caller ID history marked NEW is reviewed, the number of missed calls decreases by one.

If you do not want to review all the missed calls one by one, but you still want to keep all the missed calls in the caller ID history, you can press and hold OFF/CLEAR for four seconds when the handset is idle. All the entries in the caller ID history will be considered old (have been reviewed), and the missed calls counter is reset to 0.

Caller ID operation

HANDSET 1

6 MISSED CALLS

Pat Williams

555-1234

10:31

Jeffrey Adams

555-9876

10:21AM11/23

Chris Thompson

908-555-0100

10:11

The various dialing options are:

555-555-5555

1-555-555-5555

1-555-5555

NEW

11/23

NEW

11/23

555-5555

Caller ID history

To review caller ID history

1. Press CID to review the caller ID history. The

caller ID history displays the caller ID entries in reverse chronological order starting with the most recent call.

-OR- You can also review the caller ID history by

pressing MENU/SELECT, then use or to scroll to the >CALL LOG, then press

MENU/SELECT.

2. Press or to scroll through the list as

shown on the left.

To dial from caller ID history

While reviewing an entry in the caller ID history:

• Press PHONE/FLASH or SPEAKER to call

the number as it is displayed in the caller ID history.

-OR-

• Press # repeatedly to see the various dialing

options (you can choose to dial with or without an area code, or with or without the

1), then press PHONE/FLASH or SPEAKER to place the call.

NOTE: You may need to change how a caller ID

number will be dialed if the entry is not displayed in the correct format. Caller ID numbers may appear with an area code which may not be required for local calls, or without a 1 which may be needed for long distance calls.

Other options

• Press MUTE/REMOVE to delete the displayed

entry from the caller ID history.

• With an entry from the caller ID history

displayed, press and hold MUTE/REMOVE to delete all entries from the caller ID history. When asked to confirm, press MENU/SELECT to clear the caller ID history of all entries, or press OFF/CLEAR to exit and leave all entries in the caller ID history intact.

Caller ID operation

NOTE: If both the name and number are not provided, UNABLE TO SAVE will be displayed.

Caller ID history

• Press MENU/SELECT to copy this entry into your directory. You will be given the opportunity to edit the name or the number (page 30) if they are not provided.

• Press OFF/CLEAR to exit the caller ID history.

Answering system operation

About the answering system

Answering system and voicemail

Your telephone has both a digital answering system and voicemail indication. Voicemail is offered by your telephone service provider (fees may apply). Your telephone’s answering system and voicemail indication are independent features. Each alerts you to new messages differently. For more information on the voicemail indicators, see page 23. To listen to your voicemail, you typically dial an access number provided by your telephone company, followed by a security code or PIN. To listen to messages recorded on your digital answering system, press telephone base.

If you subscribe to caller ID/call waiting service through your telephone service provider, you can use your telephone answering system and voicemail together. Set your answering system to answer calls at least two rings earlier than your voicemail is set to answer. For example, set your voicemail to answer calls after six rings and set you answering system to answer after four rings. Some voicemail providers may program the delay before answering calls in seconds instead of rings; in this case allow six seconds per ring when determining the appropriate setting. By doing this, if you are on a call, or if the answering system is busy recording a message and you receive another call, the second caller can leave a voicemail message.

PLAY/STOP button on the

Answering system operation

About the answering system

The answering system can record up to 99 messages, depending on the length of each message. Individual messages can be up to four minutes long, and the total maximum recording time is 14 minutes. Messages will remain available for replay until you delete them.

If F is flashing in the message window, memory is full. You will have to delete some messages before new ones can be recorded.

When there are new messages (including memos) on the answering system, the number of message stored will flash in the message counter.

To play answering system messages, press

PLAY/STOP. Press VOLUME to adjust theto adjust the

playback volume when playing messages.

Voice prompts

The system provides voice prompts to guide you through setup.

Answering system operation

NOTE: If the clock was not set when a message was recorded, the system will announce

"Time and day not set"

before the message is played back.

Day & time announcement

To check day & time

You can press CLOCK when the system is idle to hear the current day and time.

If you subscribe to caller ID service from your local telephone company, the time will automatically be set with every incoming call. You must set the year so that the day of the week can be calculated from the caller ID information.

If you do not hear the correct time, day, and year, follow the steps below.

To set day & time

Before playing each message, the answering system announces the day and time the message was received.

Follow the steps below to set the year, time and day, so the day and time are correct. Each time you press SKIP or REPEAT, the year, hour, minute or day increases or decreases by one. Press and hold SKIP or REPEAT to increase or decrease the minutes or year by increments of ten. When you hear the correct setting, press CLOCK to move to the next setting.

1. Press CLOCK, the system will announce the

current clock setting, and then announce “To set the clock, press CLOCK.”

2. Press CLOCK, The system will announce the

current year setting, and then announce “To

change the year, press SKIP or REPEAT, to change the hour, press CLOCK.”

3. Press CLOCK, The system will announce the

current hour setting, and then announce “To

change the hour, press SKIP or REPEAT, to change the minute, press CLOCK.”

4. Press CLOCK, The system will announce the

current minute setting, and then announce “To

change the minute, press SKIP or REPEAT, to change the day, press CLOCK.”

5. Press CLOCK, The system will announce the

current day setting, and then announce “To

change the day, press SKIP or REPEAT, press CLOCK when you are done.”

6. Press CLOCK. The system announces the

current clock setting.

Answering system operation

Answering system mode

Unless you change it, the answering system will be on, that is, ready to record messages. You can turn the answering system off, but if you do so, the answering system will not answer calls and record incoming messages.

To turn the answering system on or off:

• Press ANSWER ON to turn off your answering system. The system will announce “Calls will not be answered” and then beep to confirm the system is off. The ANSWER ON light will be off.

• To turn the system back on, press ANSWER

ON. The system will announce “Calls will be answered” and then beep to confirm the

system is on. The ANSWER ON light will be on.

NOTE: If the answering system is off, and there is an incoming call, the system will answer after 10 rings and announce to the caller “Please enter your remote access code.” For more information about remote access, see pages 49-50.

Call screening at the telephone base

If the answering system is on and the base volume is not off, you will hear the announcement and the incoming message when a call comes in.

Call intercept

While you are screening a call, you can stop recording and speak to the caller by pressing

PHONE/FLASH or SPEAKER on the handset.

Answering system operation

Outgoing announcements

Outgoing announcements are the messages callers hear when calls are answered by the answering system.

The telephone has a prerecorded outgoing announcement: “Hello. Please leave a message after the tone.” You can use this announcement, or replace it with your own recording.

To play your current outgoing announcement

1. Press ANNC., you will hear "Announcement.

Press PLAY or press RECORD."

2. Press PLAY/STOP to hear the outgoing

announcement, press again to replay the announcement.

Press ANNC. at anytime to exit the announcement menu.

To record a new outgoing announcement

1. Press ANNC. You will hear "Announcement.

Press PLAY or press RECORD."

2. Press RECORD and begin speaking after you

hear "Record after the tone. Press STOP when you are done."

3. Speak facing the telephone base from approximately nine inches away.

4. Press Your recorded announcement will be played back.

To listen to the recorded announcement again, press

To record a new announcement, press RECORD and follow the above steps. Press ANNC. at anytime to exit the announcement menu.

Elapsed time (in seconds) will be shown in the message window when recording. You can record an announcement up to 90 seconds long. An announcement shorter than two seconds long will not be recorded.

PLAY/STOP when you are done.

PLAY/STOP.

Answering system operation

Outgoing announcements

To delete your outgoing announcement

1. Press ANNC. You will hear “Announcement.

Press PLAY or press RECORD."

2. Press PLAY/STOP to begin playback.

3. Press DELETE during playback to delete

your announcement, "Announcement deleted." will be announced.

Press ANNC. to exit the announcement menu.

When your announcement is deleted, calls will be answered with the pre-set announcement described on page 40.

Answering system operation

NOTE: To adjust the voice prompt volume, press VOLUME .

Answering system setup

You can change the number of rings, telephone base ringer volume, remote access code and message alert tone.

To change the answering system setup:

1. Press SETUP repeatedly to hear the settings for different features.

2. When you hear the feature you want to change, press SKIP or REPEAT to change the setting.

• Number of rings - set the number of rings

before the answering system answers an incoming call.

• Base ringer - set the volume of the

telephone base ringer.

• Remote access code - change the code

required to access your answering system from another telephone.

• Message alert tone - set the message

alert tone to On so that it will beep when you have a new answering system message.

3. Press SETUP to save your selection and move to the next menu option.

-OR-

Press

PLAY/STOP to save your selection

and exit the menu.

Answering system operation

Answering system setup

Number of rings

You can set the answering system to answer an incoming call after two, four, or six rings. You can also select toll saver, which is explained below. Unless you change it, the answering system answers an incoming call after four rings.

To set the number of rings:

1. Press SETUP. The system will announce

"Number of rings," followed by the current setting, and then "To change the setting press

SKIP or REPEAT; to continue setup, press SETUP."

2. Press SKIP or REPEAT to change to two,

four, or six rings, or toll saver.

• Toll saver - the answering system answers a call after two rings when there are new messages, and after four rings when there are no new messages. This allows you to check for new messages without paying for a toll call.

3. Press SETUP to save your selection and move

to the next menu option.

-OR- Press

PLAY/STOP to save your selection

and exit the menu.

NOTE: If you subscribe to caller ID/call waiting and voicemail service through your telephone service provider, you can use your telephone answering system and voicemail together. Set your answering system to answer calls at least two rings earlier than your voicemail is set to answer. For example, set your voicemail to answer calls after six rings and set you answering system to answer after four rings. By doing this, if you are on a call, or if the answering system is busy recording a message and you receive another call, the second caller can leave a voicemail message.

Answering system operation

Answering system setup

Base ringer volume

You can set the volume to high or low, or turn the base ringer off. Unless you change it, the telephone base ringer volume is set to low.

To change the setting:

1. Press SETUP twice. The system will announce

“Base ringer,” followed by the current setting, and then “To change the setting press SKIP

or REPEAT; to continue setup, press SETUP.”

2. Press SKIP or REPEAT to change among

off, low or high.

3. Press SETUP to save your selection and move

to the next menu option.

-OR- Press

and exit the menu.

Remote access code

To access your answering system remotely from any touch tone phone, you need to enter a twodigit number (10-99). Unless you change it, the remote access code is 19.

To change the remote access code:

1. Press SETUP three times. The system will

announce "Remote access code," followed by the current setting, and then "To change the

setting press SKIP or REPEAT; to continue setup, press SETUP."

2. Press SKIP or REPEAT to increase or

decrease the remote access code number by one. Press and hold SKIP or REPEAT to increase or decrease the remote access code number by 10.

3. Press SETUP to save your selection and move

to the next menu option.

-OR- Press

and exit the menu.

PLAY/STOP to save your selection

Answering system operation

NOTE:

The message alert tone will beep only if all the conditions below are met:

Answering system is on.

Message alert tone setting

is on.

There are new messages.

Answering system setup

Message alert tone

When the message alert tone is set to On, and there is at least one new message, the telephone base will beep every 10 seconds. Unless you change it, the message alert tone is set to off.

To change the setting:

1. Press SETUP four times. The system will

announce "Message alert tone," followed by the current setting, and then "To change the

setting press SKIP or REPEAT; to continue setup, press SETUP."

2. Press SKIP or REPEAT to change between

on and off.

3. Press SETUP to save your selection and move

to the next menu option.

-OR-

Press

and exit the menu.

PLAY/STOP to save your selection

Temporarily turning off the message alert tone

Pressing any telephone base key (except

HANDSET LOCATOR) will temporarily silence

the message alert tone. If you press DELETE in idle mode, there will be

a voice prompt to direct you to press DELETE again to delete all old messages, and the message alert tone will be temporarily silenced.

The message alert tone will be re-activated with the next incoming message.

Answering system operation

Message playback

Press

PLAY/STOP to hear messages. The

system announces the number of messages, then begins playback.

If you have new messages, you will hear only the new messages (oldest first). If there are no new messages, the system will play back all messages (oldest first).

Before each message, you will hear the day and time it was received. After the last message, you will hear “End of messages.” If the system has less than five minutes of recording time left, you will hear the remaining time.

1. Press

PLAY/STOP. Message playback

begins.

2. Press

PLAY/STOP again to end message

playback.

Options during playback

When a message is playing, you can adjust the playback volume, and skip, repeat, or delete the message.

When playing messages:

• Press VOLUME button to adjust the

message playback volume.

• Press SKIP to skip to the next message.

• Press REPEAT to repeat the message. Press

twice to hear the previous message.

• Press DELETE to delete the message.

• Press

PLAY/STOP to stop playback.

To delete all old messages

You can only delete old (reviewed) messages. New messages must be played before you can delete them. Deleted messages cannot be retrieved again.

To delete all old messages:

1. Press DELETE when the telephone is in idle

mode. The system will announce "To delete all old messages, press DELETE again."

2. Press DELETE again. The system will

announce "All old messages deleted."

Answering system operation

Microphone

Recording & playing memos

Memos are messages you record yourself. They are saved, played back and deleted exactly like incoming messages. You can record a memo as a reminder to yourself, or leave a message for someone else who uses the answering system.

To record a memo:

1 Press RECORD. The system will announce

“Record after the tone. Press STOP when you are done.”

The message window will show the elapsed time (in seconds) as you record. You can record a memo up to four minutes long. Memos less than one second long will not be saved.

2. Speak facing the MIC (microphone) at the

bottom front of the telephone base from approximately nine inches away.

3. Press PLAY/STOP to stop recording.

The system will announce "Recorded" and a confirmation tone.

To play back a memo

Press PLAY/STOP to hear messages and memos (see page 46 for other options).

Answering system operation

Message counter

Message counter displays

The message counter usually displays the total number of answering system messages. See the table below for other message counter displays.

Message counter displays

0 No messages.

0 (flashing)

1-99 Total number of messages and memos,

1-99 (flashing) Total number of messages and memos.

After a power failure, the number in the

10-99 Current remote access code while

1-99 (counting) Elapsed time while recording a memo

99 (flashing) A memo recording is more than 99

F (flashing) Memory is full. Messages must be

-- System is answering a call, being

-- (flashing) System is being setup, initialized or

02, 04, 06, tS Displayed while setting the number of

1-8 Displayed for two seconds while

HI, LO, OF Displayed for two seconds while the

The clock needs to be set (page 38).

or message number currently playing.

The number flashes when there are new (un-reviewed) messages.

message counter will flash to indicate the clock needs to be set.

setting (page 44).

(page 47) or announcement up to 90 seconds (pages 40-41).

seconds.

deleted before new messages can be recorded.

accessed remotely, or the clock is being set.

messages are being deleted.

rings (page 43).

telephone base speaker volume is being adjusted.

telephone base ringer volume is being adjusted.

Answering system operation

NOTES:

1. If a valid remote access code is not entered, the call will be ended automatically.

2. If you pause for more than four seconds during remote access, you will hear a help menu listing all features and commands. If there is no command for another 20 seconds, the call will end automatically.

3. If you want to delete all your old messages remotely, you can press 3 twice in remote standby mode to delete them.

4. If memory is full, after 10 rings the answering system will answer and announce "Memory is full, enter the remote access code." Enter your remote access code for access to messages and announcements.

Remote access

You can access your answering system remotely by dialing your home telephone number from any touch-tone telephone.

To remotely access your answering system:

1. Dial your telephone number from any touchtone telephone.

2. When the system answers, enter the two digit remote access code (19 is the default code, see page 44 to change it).

• If you have new messages, the system will automatically announce the number of new messages and then begin to play them.

3. You can also enter the following remote commands.

Remote commands

Command Description

1 Press to hear all messages.

2 Press to hear only new

messages.

3 Press to delete the current

message (during playback).

3 3 Press twice to delete all old

messages.

4 Press to repeat the current

message (during playback).

4 4 Press twice to hear the previous

message.

5 Press to stop any operation

(including recording).

* 5 Press to hear a list of remote

commands.

6 Press to skip to the next

message (during playback).

Answering system operation

Remote access

* 7 Press to record a new

announcement.

system on or off.

Press to turn the answering

8 Press to end remote access (the

call will be terminated).

4. Hang up to end the call and save all undeleted messages.

Cut out the remote access wallet card at the back of this user’s manual for quick reference.

Appendix

Screen icons, indicator lights & tones

Screen icons & alert tones

Screen icons

Speakerphone is in use.

New voicemail messages have been received.

Ringer off.

HANDSET 1

25 MISSED CALLS

10:21

MUTE

11/23

Indicator lights

IN USE

On when handset

• is in use, when the answering system is answering an incoming call or you are registering a handset.

Flashes when

• another telephone is in use on the same line, or you are deregistering a handset from the telephone base.

Flashes quickly

• when there is an incoming call.

NEW

Handset alert tones

Two short beeps

Four short beeps

Two beeps

Confirmation tone

Telephone base tones

One beep every 10 seconds

A series of beeps

ANSWER ON

On when answering system is on and ready to receive calls.

Microphone is muted.

Missed and un-reviewed calls.

Battery charging (animated display).

Low battery (flashing); place handset in telephone base or charger to recharge.

VOLUME keys are pressed when the volume is already at its highest or lowest setting.

Low battery warning.

Out of range while the handset is on a call.

Command completed successfully.

Message alert.

VOLUME keys are pressed when the volume is already at its highest or lowest setting.

SPEAKER

On when speakerphone is in use.

VOICEMAIL

Flashes when you have new voicemail. Voicemail is a service offered by your local telephone company, and is different from answering system messages.

CHARGE

On when the handset is charging in the telephone base or charger

Blue lighted display

Blue lighted keypad

Appendix

Handset display screen messages

Screen display messages

PHONE

ENDED

CALL LOG EMPTY

DIRECTORY EMPTY

LIST FULL

MUTED

SPEAKER

LOW BATTERY

INCOMING CALL

NEW VOICE MAIL

XX MISSED CALLS

CONNECTING ...

** PAGING **

HANDSET X IS CALLING

(For TL72208/TL72308/

TL72408)

The handset is in use.

You have just ended a call.

You are accessing an empty caller ID history.

You are accessing an empty directory.

The directory is full. No new entries can be saved.

The microphone is muted.

The handset speakerphone is in use.

The battery needs to be recharged.

There is a call coming in.

There are new voicemail messages.

There are new calls in the caller ID history.

The handset has lost communication with the telephone base.

The telephone base is paging handset(s).

Another handset is calling.

LINE IN USE

NO LINE

ALREADY SAVED

SAVED

PLACE IN CHARGER

CHARGING

An extension phone or one of the handsets is in use.

No telephone line is connected.

The telephone number you have entered is already stored in the directory.

The entry in the caller ID history is saved to the directory successfully.

The battery is very low. The handset should be placed in the telephone base or charger.

A handset with a low battery has been placed in the telephone base or charger.

Appendix

Handset display screen messages

Screen display messages

UNABLE TO CALL

TRY AGAIN

NOT AVAILABLE AT THIS TIME

MICROPHONE ON

INTERCOM TO:

(For TL72208/TL72308/ TL72408)

INTERCOM ENDED

CALLING

HANDSET X

(For TL72208/TL72308/

TL72408)

TRANSFER TO:

(For TL72208/TL72308/ TL72408)

CALL TRANSFERED

Failed intercom or conference call (there are already two handsets being used).

Someone else is already using the directory or call log when you try to do so.

Mute has just been turned off so your voice is again being sent out.

You have started the intercom process, and need to enter the handset number you want to call.

The intercom call has just been ended by you or the receiver of the call.

The handset is intercomming another handset.

You have started the call transfer using intercom process, and need to enter the handset number to which you want to transfer the call.

You have transferred an outside call to another handset.

Appendix

Adding and registering handsets

Your telephone can accommodate up to four cordless handsets. You can add new handsets (TL70008, sold separately) to the TL72108/TL72208/TL72308 at any time, but each new handset must be registered with the telephone base before use. Each handset must be registered separately.

The handset provided with your TL72108 is automatically registered as handset 1. Additional handsets will be assigned numbers in the order they are registered (handset 2, handset 3 and handset 4). You can register a maximum of four handsets.

The TL72208 has two handsets automatically registered as handset 1 and handset 2. You can register two additional handsets, which will be assigned as handset 3 and handset 4.

The TL72308 has three handsets automatically registered as handset 1, handset 2 and handset 3. You can register one additional handset, which will be assigned as handset 4.

The TL72408 has four pre-registered handsets, so you cannot register any additional handset to it.

Handsets purchased separately need to be registered to

NOT REGISTERED

the telephone base before use. When first purchased, all optional accessory handsets will show NOT REGISTERED on the screen. The new handset may need to be charged for five minutes before registering to the main telephone base.

PRESS HNDST LOC

4 SEC ON BASE

PLEASE WAIT...

HANDSET X

REGISTERED

To register a handset to your telephone base

1. Place the unregistered handset into the telephone base.

If PRESS HNDST LOC 4 SEC ON BASE does not appear on the handset screen after a few seconds, remove the handset and place it in the telephone base again.

2. On the telephone base, press and hold HANDSET

LOCATOR for about four seconds (until the red IN USE

light on the telephone base turns on) and then release the button. The handset will show PLEASE WAIT... and it will take about 10 seconds to complete the registration. The handset will show HS X REGISTERED and will beep if the registration is successful.

NOTES:

1. If the registration is not successful, the display will show NOT REGISTERED. To reset the handset, remove the handset from the telephone base and place it back in. Try the registration process again.

2. You cannot register a handset if any other system handset is in use.

Appendix

Replacing a handset

You may need to de-register your handsets if:

You have four registered handsets and need to replace a handset.

-OR-

You wish to change the designated handset number of your registered handsets.

You must first de-register ALL the handsets, and then re-register each handset you wish to use.

Please read carefully through all the instructions on this page before beginning the de-registration process.

To de-register all handsets

1. Press and hold HANDSET LOCATOR on the telephone base for about 10

seconds (until the IN USE light turns on and starts to flash), then release the HANDSET LOCATOR button.

2. Immediately press and release HANDSET LOCATOR again. You must press HANDSET LOCATOR while the IN USE light is still flashing. (The light flashes for about seven seconds. If the light stops flashing, pick up the handset and place it back into the telephone base, then repeat step one above.)

3. The handset(s) will show CONNECTING... and it will take about 10 seconds to complete de-registration. ALL handsets will show NOT REGISTERED if de-registration was successful.

NOT REGISTERED

4. To re-register the handset(s) to the telephone base, follow the registration instructions on page 54.

NOTES:

1. If the de-registration process was not successful, you may need to reset the system and try again. To reset: pick up the handset and press the PHONE/FLASH button, then press the OFF/CLEAR

button and place the handset back into the telephone base. You may also reset by unplugging the power from the telephone base and plugging it back in.

2. You cannot de-register the handset(s) if any other system handset is in use.

3. You will need to reset the system clock after de-registering handset(s), refer to page 38 for details.

Appendix

Troubleshooting

If you have difficulty with your telephone, please try the suggestions below. For Customer Service, visit our website at www.telephones.att.com, or call

1 (800) 222–3111. In Canada dial 1 (866) 288-4268.

My phone doesn’t work at all.

I cannot get a dial tone.

• Make sure the power cord is securely plugged in.

• Make sure that the battery connector is securely plugged into the cordless handset.

• Make sure the telephone line cord is securely and firmly plugged into the telephone base and the telephone wall jack.

• Charge the battery in the cordless handset for at least 16 hours. For optimum daily performance, return the cordless handset to its base when not in use.

• If the battery is depleted, it may take approximately fourIf the battery is depleted, it may take approximately four minutes to charge the handset before it can resume screen display.

• Reset the telephone base. Unplug the unit’s electrical power. Wait for approximately 15 seconds, then plug it back in. Allow up to one minute for the cordless handset and telephone base to reset.

• You may need to purchase a new battery, please refer to page 6 of this user’s manual.

• First try all the suggestions above.

• Move the cordless handset closer to the telephone base. You might have moved out of range.

• If the previous suggestions don’t work, disconnect the telephone base from the telephone jack and connect to a different phone. If there is no dial tone on that phone either, the problem is in your wiring or local service. Contact your local telephone company.

• Your line cord might be malfunctioning. Try installing a new line cord.

I cannot dial out.

• First try all the suggestions above.

• Make sure you have a dial tone before dialing. The cordless handset may take a second or two to find the telephone base and produce a dial tone. This is normal. Wait an extra second before dialing.

Appendix

Troubleshooting

• Eliminate any background noise. Noise from a television,

• If the other phones in your home are having the same

radio or other appliances may cause the phone to not dial out properly. If you cannot eliminate the background noise, first try muting the cordless handset before dialing, or dialing from another room in your home with less background noise.

problem, the problem is in your wiring or local service. Contact your local telephone company (charges may apply).

My cordless handset isn’t performing normally.

CONNECTING...

displays on my cordless handset.

• Make sure the power cord is securely plugged into the telephone base. Plug the unit into a different, working electrical outlet not controlled by a wall switch.

• Move the cordless handset closer to the telephone base. You might have moved out of range.

• Reset the telephone base. Unplug the unit’s electrical power. Wait for 15 seconds then plug it back in. Allow up to one minute for the cordless handset and telephone base to reset.

• Other electronic products can cause interference to your cordless phone. Try installing your phone as far away from these types of electronic devices as possible: television sets, VCRs, or other cordless telephones.

• Ensure that the telephone base is powered up.

• Place the cordless handset in the telephone base for one minute to allow the cordless handset and base to resynchronize channels.

• Move the cordless handset closer to the telephone base. You might have moved out of range.

• Reset the telephone base. Unplug the unit’s electrical power. Wait for 15 seconds then plug it back in. Allow up to one minute for the cordless handset and telephone base to reset.

Appendix

Troubleshooting

• Other electronic products can cause interference with your cordless phone. Try installing your phone as far away from these types of electronic devices as possible: television sets, VCRs, or other cordless telephones.

The batteries will not hold a charge.

I get noise, static, or weak signal even when I’m near the telephone base.

• If the cordless handset is in its telephone base or charger and the charge light does not come on, refer to The charge light is off in this Troubleshooting guide.

• Charge the battery in the cordless handset for at least 16 hours. For optimum daily performance, return the cordless handset to its base when not in use.

• If the battery is depleted, it may take approximately fourIf the battery is depleted, it may take approximately four minutes to charge the handset before it can resume screen display.

• You may need to purchase a new battery, please refer to the Battery installation and charging section of this user’s manual.

• Your phone might be malfunctioning. Please refer to the Limited warranty section of this user’s manual for further instruction.

•

If you subscribe to high-speed Internet service (Digital Subscriber Line - DSL) through your telephone line, you must install a DSL filter between the telephone base and the telephone wall jack (see page 5). The filter will prevent noise and caller ID problems caused by DSL interference. Please contact your DSL service provider for more information about DSL filters.

• You may be able to improve the performance of your cordless phone by installing your new telephone base as far as possible from any other existing cordless telephone system that may already be installed.

• Other electronic products can cause interference to your cordless phone. Try installing your phone as far away from the following electronic devices as possible: television sets, VCRs, or other cordless telephones.

• Do not install this phone near a microwave oven or on the same electrical outlet. You may experience decreased performance while the microwave oven is operating.

Appendix

Troubleshooting

• If your phone is plugged in with a modem or a surge

• Relocate your phone to a higher location. The phone will

• If the other phones in your home are having the same

protector, plug the phone (or modem/surge protector) into a different location. If this doesn’t solve the problem, re-locate your phone or modem farther apart from one another, or use a different surge protector.

likely have better reception when not installed in a low area.

problem, the problem is in your wiring or local service. Contact your local telephone company (charges may apply).

I hear other calls while using my phone.

My cordless handset does not ring when I receive a call.

• Disconnect the telephone base from the telephone jack, and plug in a different telephone. If you still hear other calls, the problem is probably in your wiring or local service. Call your local telephone company.

• Make sure that the ringer is not turned off. Refer to the section(s) on ringer selection in this user’s manual.

• Make sure the telephone line cord is plugged securely into the telephone base and the telephone jack. Make sure the power cord is securely plugged in.

• The cordless handset may be too far from the telephone base.

• Charge the battery in the cordless handset for at least 16 hours. For optimum daily performance, return the cordless handset to its base when not in use.

• You may have too many extension phones on your telephone line to allow all of them to ring simultaneously. Try unplugging some of the other phones.

• The layout of your home or office might be limiting the operating range. Try moving the telephone base to another location, preferably on an upper floor.

Appendix

Troubleshooting

• If the other phones in your home are having the same

• Test a working phone at the phone jack. If another

• Other electronic products can cause interference with

• Re-install the battery, and place cordless handset in the

• Your line cord might be malfunctioning. Try installing a

problem, the problem is in your wiring or local service. Contact your local telephone company (charges may apply).

phone has the same problem, the problem is the phone jack. Contact your local telephone company (charges may apply).

your cordless phone. Try installing your phone as far away as possible from electronic devices like television sets, VCRs, or other cordless telephones.

telephone base. Wait for the cordless handset to reestablish its connection with the telephone base. Allow up to one minute for this to take place.

new line cord.

My calls fade out or cut in and out while I’m using my cordless handset.

•

Other electronic products can cause interference with your cordless phone. Try installing your phone as far away from the following electronic devices as possible: television sets, VCRs, or other cordless telephones.

• Do not install this phone near a microwave oven or on the same electrical outlet. You may experience decreased performance while the microwave oven is operating.

• If your phone is plugged in with a modem or surge protector, plug the phone (or modem/surge protector) into a different location. If this doesn’t solve the problem, re-locate your phone or modem farther apart from one another, or use a different surge protector.

• Relocate your telephone base to a higher location. The phone will have better reception when not installed in a low area.

• If the other phones in your home are having the same problem, the problem is in your wiring or local service. Contact your local telephone company (charges may apply).

Appendix

Troubleshooting

The charge light is off.

My caller ID isn’t working.

• Make sure the power and line cords are plugged in correctly and securely.

• Unplug the unit’s electrical power. Wait for 15 seconds, then plug it back in. Allow up to one minute for the cordless handset and telephone base to reset.

• Clean the cordless handset and telephone base charging contacts each month using a pencil eraser or cloth.

• Your phone might be malfunctioning. Please refer to the Limited warranty section of this user’s manual for further instruction.

• Caller ID is a subscription service. You must subscribe to this service from your local telephone company for this feature to work on your phone.

• If you subscribe to high-speed Internet service (Digital Subscriber Line - DSL) through your telephone line, you must install a DSL filter between the telephone base and the telephone wall jack (see page 5). The filter will prevent noise and caller ID problems caused by DSL interference. Please contact your DSL service provider for more information about DSL filters.

• Your caller must be calling from an area that supports caller ID.

• Both you and your caller’s telephone companies must use caller ID compatible equipment.

System does not receive caller ID when on a call.

• Make sure you subscribe to caller ID with call waiting features services provided by your local telephone company. Caller ID features will work only if both you and the caller are in areas offering caller ID service, and if both telephone companies use compatible equipment.

Appendix

Troubleshooting

Incomplete messages.

Difficulty hearing messages.

System does not answer after correct number of rings.

• If a caller leaves a very long message, part of it may

be lost when the system disconnects the call after four minutes.

• If the caller pauses for more than seven seconds, the

system stops recording and disconnects the call.

• If the system’s memory becomes full during a message,

the system stops recording and disconnects the call.

• If the caller's voice is very soft, the system may stop

recording and disconnects the call.

• Press VOLUME to increase speaker volume.

• Make sure that the answering system is on (see page

39).

• If toll saver is activated, the number of rings changes to

two when you have new messages stored (see page 43).

• If the memory is full or the system is off, the system will

answer after 10 rings.

System announces “Time

and day not set.”

• You need to reset the answering system clock (page 38).

Appendix

Troubleshooting

System does not respond to remote commands.

System does not record message.

Outgoing announcement is not clear.

• Make sure to enter your remote access code correctly (see pages 49-50).

• Make sure you are calling from a touch-tone phone. When you dial a number, you should hear tones. If you hear clicks, the phone is not a touch-tone telephone and cannot activate the answering system.

• The answering system may not detect the remote access code while your announcement is playing. Try waiting until the announcement is over before entering the code.

• There may be noise or interference on the phone line you are using. Press dial pad keys firmly.

• Make sure answering system is on (see page 39).

• Make sure the memory of the answering system is not full.

• When you record your announcement, make sure you speak in a normal tone of voice, about nine inches from the telephone base.

• Make sure there is no background noise (TV, music, etc.) while you are recording.

Common cure for electronic equipment.

If the unit does not seem to be responding normally, try putting the cordless handset in its base. If it does not seem to respond, do the following (in the order listed):

• Disconnect the power to the telephone base.

• Disconnect the cordless handset battery, and spare battery, if applicable.

• Wait a few minutes.

• Connect power to the telephone base.

• Re-install the battery, and place the cordless handset into the telephone base.

• Wait for the cordless handset to re-establish its connection with the telephone base. Allow up to one minute for this to take place.

Appendix

Maintenance

Taking care of your telephone

Your cordless telephone contains sophisticated electronic parts, so it must

• be treated with care.

Avoid rough treatment.

• Place the handset down gently.

• Save the original packing materials to protect your telephone if you ever

• need to ship it.

Avoid water

Your telephone can be damaged if it gets wet. Do not use the handset

• outdoors in the rain, or handle it with wet hands. Do not install the telephone base near a sink, bathtub or shower.

Electrical storms

Electrical storms can sometimes cause power surges harmful to electronic

• equipment. For your own safety, take caution when using electric appliances during storms.

Cleaning your telephone

Your telephone has a durable plastic casing that should retain its luster for

• many years. Clean it only with a soft cloth slightly dampened with water or a mild soap.

Do not use excess water or cleaning solvents of any kind.

•

Remember that electrical appliances can cause serious injury if used when you are wet or standing in water. If the telephone base should fall into water, DO NOT RETRIEVE IT UNTIL YOU UNPLUG THE POWER CORD AND TELEPHONE LINE CORDS FROM THE WALL. Then pull the unit out by the unplugged cords.

Appendix

Important safety information

This symbol is to alert you to important operating or servicing instructions that may appear in this user’s manual. Always follow basic safety precautions when using this product to reduce the risk of injury, fire, or electric shock.

Safety information

Read and understand all instructions in the user’s manual. Observe all

•

markings on the product. Avoid using a telephone during a thunderstorm. There may be a slight

•

chance of electric shock from lightning.

Do not use a telephone in the vicinity of a gas leak. If you suspect a gas

•

leak, report it immediately, but use a telephone away from the area where gas is leaking. If this product is a cordless model, make sure the telephone base is also away from the area.

Do not use this product near water, or when you are wet. For example,

•

do not use it in a wet basement or shower, or next to a swimming pool, bathtub, kitchen sink, or laundry tub. Do not use liquids or aerosol sprays for cleaning. If the product comes in contact with any liquids, unplug any line or power cord immediately. Do not plug the product back in until it has dried thoroughly.

Install this product in a protected location where no one can trip over

•

any line or power cords. Protect cords from damage or abrasion.

If this product does not operate normally, see the Troubleshooting

•

section on pages 56-63 of this user’s manual. If you cannot solve the

problem, or if the product is damaged, refer to the Limited warranty on pages 71-73. Do not open this product except as may be directed in your user’s manual. Opening the product or reassembling it incorrectly may expose you to hazardous voltages or other risks.

Replace batteries only as described in your user’s manual. Do not burn

•

or puncture batteries — they contain caustic chemicals.

This power adapter is intended to be correctly oriented in a vertical

•

or floor mount position. The prongs are not designed to hold the plug in

place if it is plugged into a ceiling or an under-the-table/cabinet outlet.

Caution: Use only the power adapter provided with this product. To obtain a

replacement, visit our website at www.telephones.att.com or call 1 (800)

222-3111. In Canada dial 1 (866) 288-4268.

Appendix

Important safety information

Especially about cordless telephones:

Privacy: The same features that make a cordless telephone convenient

•

create some limitations. Telephone calls are transmitted between the telephone base and the handset by radio waves, so there is a possibility that your cordless telephone conversations could be intercepted by radio receiving equipment within range of the cordless handset. For this

reason, you should not think of cordless telephone conversations as being as private as those on corded telephones.

Electrical power: The telephone base of this cordless telephone must be

•

connected to a working electrical outlet which is not controlled by a wall switch. Calls cannot be made from the handset if the telephone base is

unplugged, switched off, or if the electrical power is interrupted. Potential TV interference: Some cordless telephones operate at

•

frequencies that may cause interference to TVs and VCRs. To minimize or prevent such interference, do not place the telephone base of the cordless telephone near or on top of a TV or VCR. If interference is experienced, moving the cordless telephone farther away from the TV or VCR will often reduce or eliminate the interference.

Rechargeable batteries: This product contains either nickel-cadmium

•

or nickel-metal hydride rechargeable batteries. Exercise care in handling batteries in order not to create a short circuit with conductive material such as rings, bracelets, and keys. The battery or conductor may overheat and cause harm. Observe proper polarity between the battery and the battery charger.

• Nickel-metal-hydride rechargeable batteries: Dispose of these batteries

in a safe manner. Do not burn or puncture. Like other batteries of this type, if burned or punctured, they could release caustic material which could cause injury.

The RBRC™ Seal means that the manufacturer is voluntarily participating in an industry program to collect and recycle nickel-metal hydride rechargeable batteries when taken out of service within the United States. These batteries may be taken to a participating local retailer of replacement batteries or recycling center. Or you may call 1-800-8-BATTERY for locations accepting spent Ni-MH batteries.

Appendix

Important safety information

Precautions for users of implanted cardiac pacemakers

Cardiac pacemakers (applies only to digital cordless telephones): Wireless Technology Research, LLC (WTR), an independent research entity, led

a multidisciplinary evaluation of the interference between portable wireless telephones and implanted cardiac pacemakers. Supported by the U.S. Food and Drug Administration, WTR recommends to physicians that:

PACEMAKER PATIENTS

Should keep wireless telephones at least six inches from the pacemaker.

• Should NOT place wireless telephones directly over the pacemaker, such as

• in a breast pocket, when it is turned ON. Should use the wireless telephone at the ear opposite the pacemaker.

•

WTR’s evaluation did not identify any risk to bystanders with pacemakers from other persons using wireless telephones.

Especially about telephones answering systems

Two-way recording: This unit does not sound warning beeps to let the other party know that the call is being recorded. To ensure that you are in compliance with any federal or state regulations regarding recording a telephone call, you should start the recording process and then inform the other party that you are recording the conversation.

SAVE THESE INSTRUCTIONS

Appendix

FCC Part 68 and ACTA

This equipment complies with Part 68 of the FCC rules and with technical requirements adopted by the Administrative Council for Terminal Attachments (ACTA). The label on the back or bottom of this equipment contains, among other things, a product identifier in the format US:AAAEQ##TXXXX. This identifier must be provided to your local telephone company upon request.

The plug and jack used to connect this equipment to premises wiring and the telephone network must comply with applicable Part 68 rules and technical requirements adopted by ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. An RJ11 jack should normally be used for connecting to a single line and an RJ14 jack for two lines. See Installation Instructions in the user’s manual.

The Ringer Equivalence Number (REN) is used to determine how many devices you may connect to your telephone line and still have them ring when you are called. The REN for this product is encoded as the 6th and 7th characters following the US: in the product identifier (e.g., if ## is 03, the REN is 0.3). In most, but not all areas, the sum of all RENs should be five (5.0) or less. For more information, please contact your local telephone company.

This equipment may not be used with Party Lines. If you have specially wired alarm dialing equipment connected to your telephone line, ensure the connection of this equipment does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualified installer.

If this equipment is malfunctioning, it must be unplugged from the modular jack until the problem has been corrected. Repairs to this telephone equipment can only be made by the manufacturer or its authorized agents. For repair procedures, follow the instructions outlined under the Limited Warranty.

If this equipment is causing harm to the telephone network, the telephone company may temporarily discontinue your telephone service. The telephone company is required to notify you before interrupting service. If advance notice is not practical, you will be notified as soon as possible. You will be given the opportunity to correct the problem and the telephone company is required to inform you of your right to file a complaint with the FCC. Your telephone company may make changes in its facilities, equipment, operation, or procedures that could affect the proper functioning of this product. The telephone company is required to notify you if such changes are planned.

If this product is equipped with a corded or cordless handset, it is hearing aid compatible.

Appendix

FCC Part 68 and ACTA

If this product has memory dialing locations, you may choose to store emergency telephone numbers (e.g., police, fire, medical) in these locations. If you do store or test emergency numbers, please:

Remain on the line and briefly explain the reason for the call before hanging up.

Perform such activities in off-peak hours, such as early morning or late evening.

Industry Canada

Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference, including interference that may cause undesired operation.

The term ‘’IC:‘’ before the certification/registration number only signifies that the Industry Canada technical specifications were met.

The Ringer Equivalence Number (REN) for this terminal equipment is 0.1. The REN is an indication of the maximum number of devices allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the RENs of all the devices does not exceed five.

This product meets the applicable Industry Canada technical specifications.

Appendix

FCC Part 15

This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications to this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this telephone.

To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with the FCC criteria. The handset may be safely held against the ear of the user. The telephone base shall be installed and used such that parts of the user’s body other than the hands are maintained at a distance of approximately 20 cm (8 inches) or more. If you choose to use a clipping device, please make sure to only use the supplied AT&T belt clip.

This Class B digital apparatus complies with Canadian ICES-003.

Appendix

Limited warranty

The AT&T brand is used under license - any repair, replacement or warranty service, and all questions about this product should be directed to: In the United States of America, visit www.telephones.att.com or call 1 (800) 222-

3111. In Canada, call 1 (866) 288-4268.

What does this limited warranty cover?

1. The manufacturer of this AT&T-branded product warrants to the holder of

a valid proof of purchase (“CONSUMER” or “you”) that the product and all accessories provided in the sales package (“PRODUCT”) are free from defects in material and workmanship, pursuant to the following terms and conditions, when installed and used normally and in accordance with the PRODUCT operating instructions. This limited warranty extends only to the CONSUMER for products purchased and used in the United States of America and Canada.

What will be done if the PRODUCT is not free from defects in materials and

2. workmanship during the limited warranty period (“materially defective PRODUCT”)?

During the limited warranty period, the manufacturer’s authorized service representative will repair or replace at the manufacturer’s option, without charge, a materially defective PRODUCT. If the manufacturer repairs the PRODUCT, they may use new or refurbished replacement parts. If the manufacturer chooses to replace the PRODUCT, they may replace it with a new or refurbished PRODUCT of the same or similar design. The manufacturer will retain defective parts, modules, or equipment. Repair or replacement of the PRODUCT, at the manufacturer’s option, is your exclusive remedy. The manufacturer will return repaired or replacement products to you in working condition. You should expect the repair or replacement to take approximately 30 days.

How long is the limited warranty period?

3. The limited warranty period for the PRODUCT extends for ONE (1) YEAR from

the date of purchase. If the manufacturer repairs or replaces a materially defective PRODUCT under the terms of this limited warranty, this limited warranty also applies to repaired or replacement PRODUCT for a period of either (a) 90 days from the date the repaired or replacement PRODUCT is shipped to you or (b) the time remaining on the original one-year limited warranty; whichever is longer.

Appendix

Limited warranty

What is not covered by this limited warranty?

This limited warranty does not cover:

PRODUCT that has been subjected to misuse, accident, shipping or other

•

physical damage, improper installation, abnormal operation or handling, neglect, inundation, fire, water, or other liquid intrusion; or

PRODUCT that has been damaged due to repair, alteration, or modification by

•

anyone other than an authorized service representative of the manufacturer; or PRODUCT to the extent that the problem experienced is caused by signal

•

conditions, network reliability or cable or antenna systems; or PRODUCT to the extent that the problem is caused by use with non-AT&T

•

accessories; or PRODUCT whose warranty/quality stickers, PRODUCT serial number plates or

•

electronic serial numbers have been removed, altered or rendered illegible; or PRODUCT purchased, used, serviced, or shipped for repair from outside the

•

United States of America or Canada, or used for commercial or institutional purposes (including but not limited to products used for rental purposes); or

PRODUCT returned without valid proof of purchase (see item 6 below); -or-

•

Charges for installation or setup, adjustment of customer controls, and

•

installation or repair of systems outside the unit.

How do you get warranty service?

To obtain warranty service in the United States of America, visit

www.telephones.att.com or call 1 (800) 222-3111. In Canada, call 1 (866) 288-4268. NOTE: Before calling for service, please review the user’s

manual; a check of the PRODUCT controls and features may save you a service call. Except as provided by applicable law, you assume the risk of loss or damage during transit and transportation and are responsible for delivery or handling charges incurred in the transport of the PRODUCT(s) to the service location. The manufacturer will return repaired or replaced PRODUCT under this limited warranty to you. Transportation, delivery or handling charges are prepaid. The manufacturer assumes no risk for damage or loss of the PRODUCT in transit. If the PRODUCT failure is not covered by this limited warranty, or proof of purchase does not meet the terms of this limited warranty, the manufacturer will notify you and will request that you authorize the cost of repair prior to any further repair activity. You must pay for the cost of repair and return shipping costs for the repair of products that are not covered by this limited warranty.

Appendix

Limited warranty

What must you return with the PRODUCT to get warranty service? You

6. must:

Return the entire original package and contents including the

a. PRODUCT to the service location along with a description of the malfunction or difficulty; and

Include “valid proof of purchase” (sales receipt) identifying the

b. PRODUCT purchased (PRODUCT model) and the date of purchase or receipt; and

Provide your name, complete and correct mailing address, and

c. telephone number.

Other limitations

This warranty is the complete and exclusive agreement between you and the manufacturer of this AT&T branded PRODUCT. It supersedes all other written or oral communications related to this PRODUCT. The manufacturer provides no other warranties for this PRODUCT. The warranty exclusively describes all of the manufacturer’s responsibilities regarding the PRODUCT. There are no other express warranties. No one is authorized to make modifications to this limited warranty and you should not rely on any such modification. State/Provincial Law rights: This warranty gives you specific legal rights, and you may also have other rights which vary from state to state or province to province. Limitations: Implied warranties, including those of fitness for a particular purpose and merchantability (an unwritten warranty that the PRODUCT is fit for ordinary use) are limited to one year from date of purchase. Some states/ provinces do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. In no event shall the manufacturer be liable for any indirect, special, incidental, consequential, or similar damages (including, but not limited to lost profits or revenue, inability to use the PRODUCT or other associated equipment, the cost of substitute equipment, and claims by third parties) resulting from the use of this PRODUCT. Some states/provinces do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

Please retain your original sales receipt as proof of purchase.

Index

Technical specifications

RF frequency band (handset to telephone base)

RF frequency band (telephone base to handset)

Channels 95

Operating temperature 32°F — 122°F

Telephone base voltage (AC voltage, 60Hz)

Telephone base voltage (AC adapter output)

Handset voltage 3.2 — 4.7 VDC 550mAh

Charger voltage (AC adapter output)

Replacement battery

2400 MHz — 2483.5 MHz

5725 MHz — 5850 MHz

0°C — 50°C

96 — 130 Vrms

9VDC @600mA

9VDC @200mA

3.6V 600mAH

5.8 GHz digital spread spectrum frequency hopping technology

This technology digitally transmits your voice across multiple channels in both the 5.8GHz and 2.4GHz frequencies to provide enhanced range, ultimate sound clarity and advanced privacy against eavesdropping on your calls, while not interfering with wireless routers.

Telephone operating range

This cordless telephone operates within the maximum power allowed by the Federal Communications Commission (FCC). Even so, this handset and telephone base can communicate over only a certain distance — which can vary with the locations of the telephone base and handset, the weather, and the construction of your home or office.

Index

AC adapter, 5 Alert tones, 51 Answering calls, 12 Answering system, 36-50 Auto off, 13

Battery charging, 6 Battery installation, 6 Belt clip, 7

Call intercept, 39 Call screening, 39 Call transfer using intercom, 19 Call waiting, 15 Caller ID (CID), 31 add entries to phone directory, 35 delete entries, 34 dial entries, 34 review history, 34 Charger installation, 5 Clear voicemail indication, 23

Delete caller ID history entries, 34 Delete redial entries, 13 Dialing, from a caller ID record, 34 directory dialing, 30 Directory, 25 dial number, 30 edit entries, 30 name search, 29 new entries, 26-27 Display dial, 30 DSL, 4, 5, 58, 61

Elapsed time, 12 Ending calls, 12

Flash (switchhook flash), 15

Handset speakerphone, 12 Handset locator, 14 Handset settings, 20-24 Headset, 7

Intercom, 18 Incoming caller ID history, 34 Incoming calls, answering, 12 Indicator lights, 51

Language, 22 Last number redial, 13

Making calls, 12 Memory match, 33 Missed calls indicator, 33 Mute, 16

Names, enter into directory, 27 search for, 29

On-hook dialing, 12

Quick reference guide, 2-3

Receiving calls, 12 Recharging, 6 Redial, 13 Remote access, 49-50 Review caller ID history, 50 Ring silencing, 24 Ringer tone options, 21 Ringer volume, 20

Search for names, 29 Speakerphone, 12 Switchhook flash, 15

Index

Technical specifications, 74 Telephone base installation, 5 Telephone operating range, 74 Troubleshooting, 56-63

Voicemail, 3, 51 Voicemail waiting indicator, 22 Voice prompts, 37 Volume controls, 15, 20

Appendix

Remote access wallet card

Use the wallet card below to help you remember commands to control your answering system from any touch tone telephone.

Cut along dotted line.

Call your phone number, then enter your two-digit access code (preset to 19).

Fold here.

Action Remote command

Play all messages ..................1

Play new messages ...............2

Delete the message ..............3

Delete all old messages .....33

Repeat or go back .................4

Stop ...............................................5

Help menu .................................*5

Skip the message ...................

Record announcement ........

Turn system off or on ........

End remote access call ......8 (or hang up)

Model name: TL72108/TL72208/TL72308/TL72408 Type: 5.8 GHz cordless telephone/answering system with caller ID/call waiting

6 *7 0

www.telephones.att.com

AT&T and the AT&T logo are trademarks of AT&T Intellectual Property II, L.P. d/b/a

AT&T Intellectual Property licensed to Advanced American Telephones.

Printed in China. Issue 5 AT&T 10/08.

AT&T TL72408 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
