AT&T MDC 9000 User Manual

AT&T 555-230-769

Issue 1, May 1994

DEFINITY Communications System Generic 1, 2, and 3 and System 75 and System 85

MDC 9000 Wireless Telephone User’s Guide

b b

Notice

While reasonable effort was made to ensure that the information in this document was complete and accurate at the time of printing, AT&T cannot assume responsibility for any errors. Changes and/or corrections to the information contained in this document may be incorporated into future issues.

Your Responsibility for Your System’s Security

You are responsible for the security of your system. AT&T does not warrant that this product is immune from or will prevent unauthorized use of common-carrier telecommunication services or facilities accessed through or connected to it. AT&T will not be responsible for any charges that result from such unauthorized use. Product administration to prevent unauthorized use is your responsibility and your system administrator should read all documents provided with this product to fully understand the features available that may reduce your risk of incurring charges.

Federal Communications Commission (FCC) Statement

This equipment generates, uses, and can radiate radio-frequency energy and, if not installed and used in accordance with the instruction manual, may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A computing device pursuant to Subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment.

Operation of this equipment in a residential area is likely to cause interference, in which case the user at his/her own expense will be required to take whatever measures

b b

may be required to correct the interference.

TRADEMARK NOTICE

DEFINITY is a registered trademark of AT&T.

ORDERING INFORMATION Call: AT&T Customer Information Center

1 800 432-6600 In Canada: 1 800 255-1242

Write: AT&T Customer Information Center

2855 North Franklin Road P.O. Box 19901 Indianapolis, IN 46219-1385

Order: Document No. AT&T 555-230-500ADD2

Issue 1, January 1993

Published by GBCSystems Product Documentation Development Group AT&T Bell Laboratories Middletown, NJ 07748-0076

ffffffffffffffffffffffffffffffffffffffffffffff

Contents

Your MDC 9000 Cordless Telephone What the Features Do

Phone Features ……………………………………………………………6 System Features …………………………………………………………7

How to Use the Features

Special Instructions for General Use …………………………………9 Conventions Used in Procedure Descriptions ………………………9 Quick Reference Lists …………………………………………………10

Phone Features

Answering and Placing a Call …………………………………………11 Conference…………………………………………………………………12 Drop…………………………………………………………………………12 Hold…………………………………………………………………………12 Message ……………………………………………………………………13 Status ………………………………………………………………………13 Test (Local Test) …………………………………………………………14 Transfer ……………………………………………………………………14

…………………………………………………………………6

……………………………………………………………9

………………………………………………………………………11

………………………………………………1

b b

System Features

Special Instructions ……………………………………………………15

Abbreviated Dialing………………………………………………………15 Automatic Callback………………………………………………………17 Call Forwarding All Calls (for G1 & G3)) ……………………………18 Call Forwarding — Busy/Dont Answer (for G2) ……………………19 Call Forwarding — Follow Me (for G2) ………………………………20 Call Park …………………………………………………………………21 Call Pickup ………………………………………………………………22 Consult (for G1 & G3) ……………………………………………………23 Intercom……………………………………………………………………23 Last Number Dialed ……………………………………………………24 Leave Word Calling………………………………………………………24 Priority Calling……………………………………………………………25

Tones and Their Meanings

Ringing Tones ……………………………………………………………26 Handset Tones……………………………………………………………26

……………………………………………………………………15

…………………………………………………………26

Key Words to Know Quick Reference Lists

…………………………………………………………………27

………………………………………………………………29

NOTICE

While reasonable efforts were made to ensure that the information in this document was complete and accurate at the time of printing, AT&T can assume no responsibility for any errors. Changes or corrections to the information contained in this document may be incorporated into future issues.

TO ORDER COPIES OF THIS DOCUMENT

Contact:AT&T Customer Information Center

2855 North Franklin Road P.O. Box 19901 Indianapolis, IN 46219 1 800 432-6600 In Canada: 1 800 255-1242

Order: Document No. AT&T 555-230-769

Issue 1, May 1994

For more information about AT&T documents, see Business Communications Systems Publications Catalog, 555-000-010.

HEARING AID COMPATIBILITY

This equipment is compatible with the inductively coupled hearing aids as required by the Federal Communications Commission (FCC).

b b

YOUR RESPONSIBILITY FOR YOUR SYSTEM´S SECURITY

You are responsible for the security of your system. AT&T does not warrant that this product is immune from or will prevent unauthorized use of common-carrier telecommunication services or facilities accessed through or connected to it. AT&T will not be responsible for any charges that result from such unauthorized use. Product administration to prevent unauthorized use is your responsibility and your system manager should read all documents provided with this product to fully understand the features available that may reduce your risk of incurring charges.

bbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbb c

COMMENT CARD

cbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbbc

bbb c

cbbbc

1 How would you rate this document for COMPLETENESS? (Please circle)

Excellent Adequate Poor

2 Identify any information you feel should be included or removed.

3 How would you rate this document for ACCURACY of information? (Please circle)

Excellent Adequate Poor

4 Specify page and nature of any error(s) found in this document.

How 5 (Please circle)

Excellent Adequate Poor

b b

Recommended wording change(s): (Use additional paper if necessary)

7 Reason for recommended change(s):

Document Title: AT&T DEFINITY Communications System

Generic 1, 2, and 3 and System 75 and System 85 MDC 9000 Wireless Telephone User’s Guide

Document Number: 555-230-769, Issue 1, May 1994 Your

Name Phone No.

Company Address City &

State Zip Code

ffffffffffffffffffffffffffffffffffffffffffffff

Your MDC 9000 Cordless Telephone

The MDC 9000 Cordless Telephone has two basic parts, the handset (see Figure 1) and the charging base (see Figure 2). The handset has:

User instructions

Directory card

Flexible antenna

Headset jack

Headset On/Off button

Battery charging contacts

Earpiece volume control switch

Line/programmable feature/intercom buttons/Drop button

LCD display

Status button

Handset On/Off button

Hold button

Dial pad

b b

Conference button

Transfer button

Feature button

Handset extension label

The charging base has:

Battery charging contacts

Handset hook

Ringer volume controls

Talk indicator

Charge indicator

Message indicator

Base ringer

Base extension label

This portable, cordless telephone is designed to help you use the many features of the AT&T DEFINITY Communications System Generic 1, Generic 2, and Generic 3, System 75, and System 85.

In order to provide you with the freedom of mobility, the MDC 9000 is not connected physically (by a line cord or wire from the handset) to the DEFINITY system (or System 75 or System 85). Instead, the MDC 9000 handset communicates by way of a radio link to its radio base, which connects to the telephone system.

See Figure 1 to view the handset and Figure 2 to see its charging base. Then read the explanations of this telephone’s many features following the figures.

b b

User Instructions (pull-up)

Headset On/Off Button

Directory Card (behind)

Headset Jack Battery Charging

Contacts Earpiece Volume

Control Switch

Stat (Status) Button On/Off Button

Conf (Conference) Button

Trans (Transfer) Button

To Update Display

Press

Stat

P STAT

MSG

RANGE

BATT

On/Off Hold

Stat

ABC

2 3

JKL MNOGHI

4 5 6

TUV

7 8 9

Oper

Conf Trans Feat

MDC 9000

Ext.

HANDSET

Antenna

Handset Display

P STAT

MSG

RANGE

BATT

Dual Purpose Outside Line/

Drop

Programmable Buttons (ﬁve)

Drop Button

DEF

Hold Button Dial Pad

WXYZPQRS

Feat (Feature) Button

Handset Extension Label

Figure 1. MDC 9000 Telephone, Top View of Handset,

including Enlarged Display Area

Battery Charging Contacts

Handset Hook

Base Ringer

Base Extension Label

Ringer Volume

Ext. 14

BASE

MDC 9000

Talk

Charge

Message

Talk Indicator

Charge Indicator

Message Indicator

Ringer Volume Controls

Figure 2. MDC 9000 Telephone, Top View of Charging Base

b b

The handset of the MDC 9000 has the following features as shown in Figure 1, Top View of Handset (the list begins with the antenna and then continues clockwise around the handset drawing):

Antenna For receiving the transmissions from the radio module.

This antenna is flexible and is permanently attached to the handset.

LCD Display Provides information on the status of lines and range,

battery power, etc.

Outside Line or Intercom/ Programmable Feature Buttons

Drop Button For disconnecting from a call or dropping the last person

When labeled with an extension number, these buttons indicate lines used for incoming and outgoing calls (call appearances) and for using the telephone as an intercom; when programmed and labeled with feature names, these buttons access features (feature buttons). In use, the light next to that button is lit; when a call is on hold, it winks.

you added to a conference call. The Drop button is NOT labeled. It is located in the lower right corner of the LCD display.

Hold Button For placing a call on hold.

Dial Pad The standard 12-button pad for dialing telephone

numbers and accessing features.

Feature Button The Feature button (labeled Feat) is NOT used.

Handset Extension Label For writing the extension number (using a pencil or

ballpoint pen only). Do not use a felt-tip pen.

Transfer Button The Transfer button (labeled Trans) enables you to

transfer calls to other extensions or numbers.

Conference Button The Conference button (labeled Conf) is used to set up

conference calls.

On/Off Button For turning the handset on and off. (This button can

also turn the headset on and off.)

Status Button The Status button (labeled Stat) is used to update all

handset visuals if pressed when the STAT indicator appears (the handset is on), and to turn on the display when the handset is off.

b b

Earpiece Volume Control Switch

Battery Charging Contacts For charging the handset when contact is made with the

Headset Jack For connecting the headset to the handset.

Directory Card For manually inserting names of frequently dialed

Headset (On/Off Button) For turning the headset on and off.

User Instructions A quick reference that you can pull up to review basic

For sliding between the two earpiece volume control positions, Normal and High.

charging base.

telephone numbers or extensions. It is located on the bottom of the handset cover.

procedures for using this telephone’s features.

Figure 2, Top View of Charging Base, shows the following features (the list begins with the Talk indicator and continues clockwise around the drawing of the charging base):

Talk Indicator This indicator is lit when the handset is off-hook.

(The ON icon on the handset is also lit.)

Charge Indicator This indicator is lit when the battery is charging

and the handset is properly placed on the base.

Message Indicator This indicator is lit when you have a message.

(MSG also appears on handset display.)

Ringer Volume Controls For adjusting the base’s ringing volume. Press the

left button to decrease the ringer volume; press the right button to increase the ringer volume.

Note: When the handset is on the base, only the base rings. Both ring when the handset is out of the base.

Base Extension Label For writing the extension number (using a pencil or

ballpoint pen only). Do NOT use a felt-tip pen.

b b

Base Ringer This is the ringer located in the base.

Handset Hook For hanging up the handset in the base.

Battery Charging Contacts For charging the handset when contact is made

with the charging base.

Power Cord Jack (not shown in the figure)

For connecting the power cord to your telephone. This cord is then plugged into a wall outlet. This jack is located on the other side of the base.

ffffffffffffffffffffffffffffffffffffffffffffff

The following section lists the many voice features that you can use with your MDC 9000 and briefly explains what each one does and how you might want to use it.

The features in this guide have been divided into two categories:

Phone Features — Those telephone features that you can use immediately

regardless of which communications system your telephone is behind.

System Features — Those features that you can use only with a DEFINITY Communications System or System 75 or System 85. Some system features may not be available for all system types. If a feature is not supported by all systems, the systems that do support that feature are identified in this document by boldface type for the system name. Most of the system features must be assigned to your telephone by the system manager. Check with your system manager to see which of these features you can use.

What the Features Do

b b

Phone Features

ffffffffffffffffffffffffffffffffffffffffffffff

The following features can be used immediately. They do not need to be administered on your telephone.

Conference Allows you to include up to five parties, including yourself (with a

DEFINITY G1 or G3 or System 75), or three parties, including yourself (with DEFINITY G2 or System 85) on a conference call, without losing voice quality. Note: If you have both an active call and a call on hold, you must terminate one of

them before you can use Conference. Display Information Provides visual call and telephone status information through

the following set of icons:

bbb

cbbbc

rectangle both appear, you are using that line; if only the rectangle appears, the line is in use.

ON appears when the handset is on. RANGE flashes to indicate that you are out of range and appears steadily when

you have lost communication. P is not used with DEFINITY or System 75 or System 85.

bbb cbbbc

bb b

shows the status of the adjacent button. If the triangle and

cbbbc

STAT appears when the status mode is active, refreshing the icons and indicating that you should move closer to the base.

MSG appears when there is a message waiting for you.
