Page 1

AT&T

MAP/5

Technical Job Aid

Document Number GBCS-1360-TJA

August, 1994

Page 2

Contents

About This Job Aid

Introduction to the MAP/5

1 Applications Supported

Installing the MAP/5

Choosing an Appropriate Location for the MAP/5

Unpacking the Components 10

Changing Desktop/Tower Orientation

Connecting the Components 13

Turning the System On and Running Diagnostics

Testing Remote Maintenance

Opening the System Unit

Installing Expansion Boards Identifying and Setting Expansion Boards

Maximum Supported Boards Board/Slot Locations

Identifying IVP Boards

Setting IVP Switches

IVP Address Switch Settings IFP2 Switch and Jumper Settings (MERLIN LEGEND)

IFP2 Switch and Jumper Settings (DEFINITY)

15 16 17 19 20

21 21 23 25 26 27 28

AT&T - Proprietary

Page i

Page 3

MAP/5 Technical Job Aid

Page ii

IFP4 Identification and Settings Identifying and Setting IVC6 (AYC10) Board for INTUITY™

Identifying and Setting General Purpose Synchronous Controller Board for INTUITY™ Identifying Multi-port Serial Board for INTUITY™ Identifying and Setting ACCX Networking (AYC22) Board for INTUITY™ Identifying DCP Boards

Identifying CMS Boards Identifying SatisFAXtion® Boards

Connecting the MAP/5 to the Voice Switch

MERLIN LEGEND Connection Diagrams System 25 Connection Diagrams DEFINITY/System 75 Connection Diagrams

IVP4 Connections (RJ11C with 884A) IVP6 Connections (RJ11C with 885A) IVP6 Connections (108B & 104A)

IFP Connections CMS Board Connections SatisFAXtion® Board Connections

MERLIN LEGEND: Integrated Solution Connection Overview

MERLIN LEGEND: UNIX Administration and/or SMDR Connection (Same AC Outlet)

MERLIN LEGEND: UNIX Administration (with/without SMDR) Connection (ADU)

MERLIN LEGEND: UNIX SMDR (with/without Administration) Connection (ADU)

MERLIN LEGEND: MS-DOS Administration Only Connection (Same AC Outlet)

MERLIN LEGEND: MS-DOS SMDR Only Connection (Same AC Outlet) MERLIN LEGEND: MS-DOS Administration Only Connection (ADU) MERLIN LEGEND: MS-DOS SMDR Only Connection (ADU)

29 30 31 32 33 34

35 36

37 38 39 40 41

42 43 44 45 46 47 48

49 50 51 52 53 54

Page 4

System 25: Integrated Solution Connection Overview System 25: UNIX Administration and/or SMDR Connection (Same AC Outlet) System 25: UNIX Administration (with/without SMDR) Connection (ADU, RMD) System 25: UNIX SMDR (with/without Administration) Connection (ADU) System 25: MS-DOS Administration Only Connection (Same AC Outlet) System 25: MS-DOS SMDR Only Connection (Same AC Outlet) System 25: MS-DOS Administration Only Connection (ADU, RMD) System 25: MS-DOS SMDR Only Connection (ADU) DEFINITY/System 75: Integrated Solution Connection Overview DEFINITY/System 75: DCP Board Connections DEFINITY/System 75: UNIX SMDR Connection (Under 1000 feet) DEFINITY/System 75: UNIX SMDR Data Connection (TN-726 Data Line Port) DEFINITY/System 75: UNIX SMDR Data Connection (7400A Data Module)

DEFINITY: INTUITY™ Connection Overview DEFINITY: IVC6 Board Connections (RJ11C with 885A) for INTUITY™ DEFINITY: GP-synch Board Connection Options for INTUITY™ DEFINITY: ACCX Networking Board Connection Options for INTUITY™ DEFINITY: ACCX Networking Board Connection to Breakout Box DEFINITY: Multi-port Serial Connection Options for INTUITY™ DEFINITY/System 75: MS-DOS SMDR Connection (Under 1000 Feet) DEFINITY/System 75: MS-DOS SMDR Data Connection (TN-726 Data Line Port)

DEFINITY/System 75: MS-DOS SMDR Data Connection (7400A Data Module)

55 56 57 58 59 60 61 62

63 64 65 66

75 76

Testing Basic Functionality

Reviewing System with Customer

AT&T - Proprietary

77 83

Page iii

Page 5

MAP/5 Technical Job Aid

Page iv

Troubleshooting.

Running the SETUP Utility

1a Basic System Configuration

1b Advanced System Configuration 1C Alternate SCSI Address 1d System Security Configuration (Disable Serial Port 2)

Running the AT&T MAP/5 Diagnostic Program

Recovering from Catastrophic Failure

Repair and Upgrade

Antistatic Precautions

Opening the System Unit/Installing Expansion Boards

Location of Internal Components of the System Unit

Identifying and Setting Expansion Boards

Non-SCSI Tape Controller Board Video Controller Board

85 86 89 92 93

97 97

99 100 101

Page 6

General Procedures

Removing/Replacing Auxiliary Housing. Removing/Replacing Hard Drive Housing.

Removing/Replacing Drive Housing

Removing/Replacing Card Guide

Connecting SCSI Cable

5f Installing or Replacing Memory 5g Upgrading the Processor 5h Replacing the Battery

102 103 104 105 106 107

108 109

110

Replacing the Main Board (Task List)

Removing/Reconnecting Small Cables

6a 6b

Removing/Reconnecting Power and Ribbon Cables

Removing/Replacing Main Board

Main Board Jumper Settings

Replacing the Power Supply

Replacing the First Hard Disk Drive

210/420 MB IDE Hard Disk Drive 250 MB IDE Hard Disk Drive 500 MB IDE Hard Disk Drive 540 MB IDE Hard Disk Drive 540 MB SCSI Hard Disk Drive, Model BCX23 540 MB SCSI Hard Disk Drive, Model BCX16

111 112 113 114 115

116

117 118 119 120 121

122 123

AT&T - Proprietary

Page v

Page 7

Map/5 Technical Job Aid

Page vi

Replacing the Floppy Diskette Drive

Installing or Replacing the Tape Drive 250 MB Tape Drive (non-SCSI) 525 MB SCSI Tape Drive

Adding or Replacing a Second Hard Disk Drive (Model 20X5ST only)

Comcodes

Documentation IS Training List Index

124 125

126 127

128

129

135 136

137

Page 8

Contents

About This Job Aid

Introduction to the MAP/5

Installing the MAP/5

Troubleshooting

Repair and Upgrade

Documentation

Why this job aid is important to you, how it ties in with the video, what training is available, what documentation is available, and

how to get help. Description of the basic components, models and storage

capacities, and applications supported.

Choosing a location, unpacking, identifying and installing circuit boards, connecting components, power up and POST

diagnostics, testing remote maintenance, connecting to the switch, connecting SMDR, connecting circuit boards, testing basic functionality, and reviewing the system with the customer.

Running diagnostics, BIOS setup, application problems.

Antistatic precautions, opening the system unit, replacing or

installing components, and ordering parts (Comcodes). List of related technical documentation.

2 4

86 98

135

IS Training List

Index

AT&T - Proprietary

List of related Job Aids and Training Courses.

136 137

Page 1

Page 9

MAP/5 Technical Job Aid

Page 2

About This Job Aid

This job aid makes it easy to find the information you need for installing and repairing the Multi-Application

Platform/5 (MAP/5). This job aid contains the following types of information:

an introduction to the hardware components of the MAP/5 and to applications that run on it.

☎

connection diagrams and procedures for installation

☎

troubleshooting procedures

☎

illustrated procedures for replacing or adding components inside the system unit

☎

MAP/5 Video AT&T also provides a MAP/5 hardware video progam that accompanies this Job Aid. lcons (little pictures, shown

below) with section numbers corresponding to sections in the Job Aid appear in the lower right comer of the video. When you see one of the icons in the video, it means that there is additional detail in the Job Aid.

Job Aid

Introduction

Installation

Troubleshooting

Repair/Upgrade

Page 10

In addition to the video, the following resources are available to assist you:

Complete hardware documentation is provided in the MAP/5 User's Guide and the AT&T MAP/5

☎

Diagnostic Program User's Guide, which are shipped with the system unit Application-specific documentation (including diagnostics for application-specific hardware) is provided

☎

with applications.

For information about other training programs and materials, please refer to pages 135 and 136 of this

☎

document.

And remember, for technical assistance, you can call for assistance:

☎

Communications System

MERLIN LEGEND

System 25

DEFINITYSystem 75

Service Organization

National Service Assistance Center (NSAC)

Technical Service Center (TSC)

Telephone Number

1-800-552-3293

1-800-248-1234

AT&T - Proprietary

Page 3

Page 11

MAP/5 Technical Job Aid

Introduction to the MAP/5

The MAP/5 consists of a keyboard, a monitor, and a system unit. The system unit may be placed either on the desktop or beside the desk (tower orientation) by orienting the "feet" in the correct position. The system unit includes the system board, the

power supply, a 3.5-inch floppy disk drive, Random Access Memory (RAM), a hard

drive, an optional tape drive, and any expansion boards required by the applications

installed. The MAP/5 may have either 4, 8, or 20 MB of RAM and a 210, 250, 420, 500, or 540

MB hard disk.* The exact configuration depends on the requirements of the

applications installed in the MAP/5. The initially offered MAP/5 configurations include the following models:

Page 4

Hard Disk

Model

4X1I 8X1IT 8X2IT

8X5IT

20X5ST

* Other sizes may be offered for upgrade.

Memory Size

4 MB 8 MB

8 MB

20 MB

Size and Type

210 MB IDE 210 MB IDE 250 MB IDE or

420 MB IDE 500 MB IDE or

540 MB IDE 540 MB SCSI

Tape Drive Size and Type

None 250 MB QIC 250 MB QIC

250 MB QIC

525 MB SCSI

Operating System

MS-DOS UNIX 3.2.2 UNIX 3.2.2

UNIX 3.2.2 UNIX 4.2

Page 12

1 Applications Supported

The MAP/5 supports the following AT&T applications:

MERLIN LEGEND

Application

AUDIX Voice Power R2.1.1 (Integrated Solution)

AUDIX Voice Power 2.1.1 (Stand Alone) CMS

CAS Plus V3 CAS for Windows Call Accounting System (CAS)

Integrated Solution CAS (IS CAS) Advanced Administration System (AAS)

System Programming and Maintenance (SPM)

INTUITY

Separate technical training is available for each of these applications.

UNIX

Y Y

MS-DOS

Y Y Y

System 25

UNIX

Y Y Y

MS-DOS

Y Y Y

DEFINITY/System 75

UNIX

MS-DOS

Y Y

Note: MAP/5 supports Integrated Solution III or later.

AT&T - Proprietary

Page 5

Page 13

MAP/5 Technical Job Aid

Page 6

Installing the MAP/5

This section includes details on the following steps in the installation process. More complete information can be found in the AT&T Multi-Application Platform/5 User's Guide and the AT&T Map/5 Diagnostic Program User's

Guide.

Topic

Choosing an Appropriate Location

1. Unpacking the Components

2. Changing Desktop/Tower Orientation

3. Connecting the Components

4. Turning the System On and Running Diagnostics

5. Testing Remote Maintenance

6. Opening the System Unit

Installing Expansion Boards

Identifying and Setting Expansion Boards

10.

Connecting the MAP/5 to the Voice Switch

11.

Testing Basic Functionality

12.

Reviewing System with Customer

Page #

7 10 11 13 15 16 17 19 20 37 77 83

Page 14

1 Choosing an Appropriate Location for the MAP/5

General Requirements:

Temperature: 41° - 95° F (5° - 35° C)

☎

Humidity: 20 - 80% non-condensing

☎

Power: 115/230 VAC, 50 - 60 Hz, 200 Watts, grounded, non-switched outlet

☎

Use the following table to determine whether the location the customer has chosen requires additional

☎

cooling or ventilation.

Component

System unit Monitor

System 25 MERLIN LEGEND

DEFINITY (single-carrier cabinet) DEFINITY (4-cabinet average) DEFINITY (fully loaded multi-carrier cabinet)

DEFINITY (fully loaded multi-carrier average)

BTUs

640

290.7 1700 per carrier

500 per carrier

1700

6700 8000 5000

AT&T - Proprietary

Page 7

Page 15

MAP/5 Technical Job Aid

General Requirements (continued):

Requires the total number of 115 VAC sockets outlined in the following table.

☎

Page 8

Component

Optional Surge Protector: a power strip is usually used with the surge protector to provide all necessary outlets (except for DEFINITY). Depending on the configuration of the sockets, the surge protector might block another socket.

System unit (plugs into optional surge protector/power strip).

Monitor (plugs into system unit). Optional RMD. Depending on the configuration of the sockets, the RMD’s

transformer might block another socket. (Can use power strip.)

Printer (can use power strip). For each ADU on switch side (maximum 2). Depending on the configuration of the

sockets, the ADU’S transformer might block another socket. Can use power strip. 0, 1 or 2* each

System 25 (can use power strip). MERLIN LEGEND (can use power strip). Up to 3 DEFINITY (single-carrier cabinet) Requires separate circuit. 1 per cabinet

DEFINITY (multi-carrier cabinet) Requires separate circuit. 7400A Data Module (used optionally with SMDR). Depending on the configuration

of the sockets, the Data Module transformer might block another socket. Can use power strip.

# of sockets

1 or 2* 1

0, 1 or 2*

Up to 3

0, 1 or 2*

* Uses one socket (outlet), but may block an additional socket.

Page 16

General Requirements (continued):

For MERLIN LEGEND and System 25, the system unit should be plugged into the same grounded circuit

☎

as the voice switch if possible. If that is not possible, you may have to use ADUs (Asynchronous Data Units) when connecting the MAP/5 to the switch. The system unit requires 4 inches of clearance for ventilation slots and cables on the back and side of the

☎

system unit. Avoid placing the system unit or monitor in direct sunlight.

☎

AT&T - Proprietary

Page 9

Page 17

MAP/5 Technical Job Aid

2 Unpacking the Components

Confirm that you have the following items:

System unit with:

☎

●

two keys

●

power cord (2) monitor and system unit

●

AT&T MAP/5 Diagnostic Program diskette,

AT&T MAP/5 Diagnostic Program User's Guide,

blank “scratch” diskette (for use in the floppy disk drive test)

●

AT&T Multi-Application Platform/5 User's Guide

●

9 to 25-pin adapter (optional)

Color monitor with power cord, cable, and guide.

☎

Keyboard with coiled cable (attached) and guide.

☎

Surge protector and power strip (for IS and CAS configurations only)

☎

For System 25 and DEFINITY, an optional Remote Maintenance Device (RMD) with power transformer,

☎

modular cord, instruction guide, and data cables (RMD is required for IS configurations) Optional 80-column or 132-column AT&T Applications Parallel Printer, or optional laser printer.

☎

Two blank 6525 type tapes for configurations with tape drives.

☎

Page 10

Page 18

3 Changing Desktop/Tower Orientation

Use these drawings as a guide for setting up the MAP/5 for desktop or tower orientation.

Steps shown convert from desktop orientation to tower orientation. Reverse procedure to convert from tower orientation to desktop orientation.

View from Bottom

Front

Press inner

edge and

slide outwards

Rear

1. Remove feet (Feet extend underneath)

Continued on next page.

View from Top

Front

Push outwards

Rear

2. Remove tabs.

AT&T - Proprietary

Page 11

Page 19

MAP/5 Technical Job Aid

Setting Desktop/Tower Orientation

Continued from previous page.

Page 12

Front

Rear

3. Insert feet in base of tower. (Feet extend outward.)

Put tabs from

top back in holes on new

side (was

Bottom)

Rear

Front

4. Insert tabs in remaining holes.

5. Rotate Keyboad/Mouse connectors

Page 20

4 Connecting the Components

Use this drawing as a guide for connecting the MAP/5 components (desktop orientation).

Plug monitor's power cord into monitor then into this Monitor Power Connector.

Plug system power cord into this AC Power Connector, then into surge protector or AC power outlet.

Set Voltage Selector Switch

to 115 VAC or 230 VAC.

Serial Port 1 connects according to voice switch

If there is a parallel printer, connect it

here.

Serial Port 2 connects according to application.

Plug in monitor video cable here. Then plug monitor’s power cord into monitor and into the Monitor Power Connector.& application.

Plug in optional mouse here.

External SCSI Port (Optional)

Tape Controller Board (Connection not used)

Plug in keyboard here.

AT&T - Proprietary

Page 13

Page 21

MAP/5 Technical Job Aid

Use this drawing as a guide for connecting the MAP/5 components (tower configuration).

Page 14

Plug system power cord into this AC

Power connector, then into surge

protector or AC power outlet.

Serial Port 2 connects

according to application.

Plug in keyboard here.

Plug in optional mouse here.

Side

Set Voltage Selector Switch to 115 VAC or 230 VAC.

Plug monitor’s power cord into monitor

then into this Monitor Power Connector. Serial Port 1 connects according to

voice switch & application. If there is a parallel printer, connect it here.

External SCSI Port (Optional)

Plug in monitor video cable here. Then plug monitor’s power cord into monitor and into the Monitor Power Connector.

Tape Controller Board (Connection not used)

Page 22

Turning the System On and Running Diagnostics

Insert the diagnostic diskette in the floppy drive. Turn the monitor and system unit on. The MAP/5 runs a series of self-tests ending with:

Video ROM BIOS

If the lights don’t come on and/or you don’t hear the fan, turn everything off and check that the power cord is connected and the outlet is live. If the system still doesn’t come on, call for assistance.

You have 60 seconds to make the following choice: press 1 for IDE, or 2 for SCSI system.

Press [ Enter Press [ F10 ] to select all tests at once, then press [ F2 ] to begin the first test. Follow the directions on each

5. screen.

At the end of all tests, press [ ESC

Use the right-arrow key to highlight

Details on all the tests are in the AT&T MAP/5 Diagnostic Program User's Guide. If any of the tests fails, call for assistance:

] at the next menu screen to display the Test Item menu.

] to return to the Main Menu.

EXIT,

then press [ Enter ]

Communications System

MERLIN LEGEND/System 25

DEFINITY/System 75

AT&T - Proprietary

Service Organization

National Service Assistance

Center (NSAC) Technical Service Center (TSC)

Telephone Number

1-800-552-3293

1-800-248-1234

Page 15

Page 23

MAP/5 Technical Job Aid

6 Testing Remote Maintenance

The following applications support remote maintenance:

Integrated Solution applications (all)

☎

CAS for Windows

☎

If your application includes a remote maintenance facility, test it as follows:

MERLIN LEGEND and System 25:

☎

Call the NSAC (1-800-552-3293) and Iisten for the prompt that leads you to the software application group. Give them the telephone number of the remote maintenance device so they can call it. They will perform the test and inform you of any problem.

DEFINITY/System 75:

☎

Call the TSC (1-800-248-1234) and provide the customer's remote maintenance phone number and access information. Ask the TSC representative to dial in and inform you of any problem.

Page 16

Page 24

7 Opening the System Unit

CAUTION:

See Antistatic Precautions on page 97 before proceeding.

It is necessary to open the system unit to replace or install expansion boards, and to replace components. Use these drawings as a guide for opening the system unit.

1. Slide cover to center so both latches are accessible

2. Press and push up Front Panel Latches.

Front

View from bottom

4. Rotate front panel up and remove.

AT&T - Proprietary

Continued on next page.

Page 17

Page 25

MAP/5 Technical Job Aid

Opening the System Unit

Continued from previous page.

4. Unlock Case Lock

Locking Tabs

Lift cover upwards

6. to remove.

Page 18

4. Push locking tabs outward

while...

. . . sliding top back-

5. ward about 1/2 inch.

Page 26

8 Installing Expansion Boards

Use this drawing as a guide for installing expansion boards.

Retaining Screw

Mounting Bracket

Expansion Board

Local Bus Connectors

AT&T - Proprietary

Page 19

Page 27

MAP/5 Technical Job Aid

Page 20

9 Identifying and Setting Expansion Boards

New (not replacement) systems are shipped with all necessary expansion boards installed. It is necessary to

identify and set expansion boards when they are beng transferred from an older system to a newer system, or when they are being added to a system. The following table identifies the expansion boards used by each application.

Expansion Board

IVP (voice)

IFP (fax) IVC (voice) GP-synch Multi-port Serial ACCX Networking

DCP (DEFINITY/ System 75 switch integration)

CMS SatisFAXtion®

Applications Page

Board/Slot Locations AUDIX Voice Power (all)

Fax Attendant System (all) FAX Attendant System (all) INTUITY™ AUDIX® INTUITY™ AUDIX® INTUITY™ AUDIX® INTUITY™ AUDIX® AUDIX Voice Power (all)

FAX Attendant System (all) CMS HackerTracker for either CAS Plus V3 (MS-DOS

only) or CAS for Windows (Windows only)

23 27 30

31 32

34 35

Page 28

Maximum Supported Boards

Board

IVP 4 IVP 6 IFP2 IFP4

DCP

Max

3 2 5 3

Intuity

Board

IVC6 GP-synch

Multi-port Serial

ACCX

Max Board

DOS/Windows

CMS SatisFAXtion

Max

Board/Slot Locations

Use this illustration to identify slot numbers on the MAP/5. The table on the following page shows the locations of expansion boards.

AT&T - Proprietary

87654321

Page 21

Page 29

MAP/5 Technical Job Aid

Use this table to determine the correct locations for expansion boards.

Integrated Solution

Page 22

Integrated Voice Power -4 Integrated Voice Power -6 Integrated Fax Processing -2 Integrated Fax Processing -4 Tape Controller Video Board*

By convention, IVP Boards are installed in tower-oriented machines from top

☎

to bottom, and in desktop machines from inside out. IFP Boards are

installed in tower-oriented machines bottom to top and in desktop machines

from outside in.

IFP2 cannot be used on System 25 IS III.

☎

For DEFINITY IS III, slot 8 is used for the DCP board. If the DCP board is

☎

installed and you are using the maximum number of IVP boards, the last board will be installed in the next lower slot.

INTUITY™

GP Synch ACCX

Multi-port serial Video Controller* IVC6 (AYCI0) First Card IVC6 (AYC10) Second Card

Slots 8, 7 and 6 Slots 8 and 7 Slots 1, 3, 4, 6 and 7 Slots 1, 3 and 4 Slot 2 Slot 5

Slot 1 Slot 3 Slot 4 Slot 5 Slot 6

Slot 7

Always slot 5 in all configurations.

Page 30

Identifying IVP Boards

Use this table and the following drawing as a guide to identifying the five types of IVP4 boards and two types of IVP6 boards. Illustrations are provided in the following pages.

Board Type

IVP4 (A)

IVP4 (B & C)

IVP4 (D)

IVP4 (E)

IVP6 (C)

IVP6 (D)

Characteristics

Old layout (two switch banks),

rocker switches, 4 repeated sets

of chips Old layout (two switch banks)

slide switches, 4 repeated sets of chips

New layout (one switch bank), with

audio jacks, 4 repeated sets of

chips

New layout (one switch bank), audio jacks, 4 repeated sets of chips

Old layout (two switch banks), slide switches, 6 repeated sets of chips

New layout (one switch bank), with

audio jacks, 6 repeated sets of

chips

Components

2 groups of 2

3 groups of 2

3 groups of 2 Channels may exhibit noise in MAP/5.

Comments

Switches are reversed on layouts B & C with the open and closed positions not

marked. Determine board type by existing switch settings or by testing. (B & C cannot be visually distinguished.)

DO NOT use in MAP/5.

AT&T - Proprietary

Page 23

Page 31

MAP/5 Technical Job Aid

Identifying IVP Boards

Page 24

Old Layout IVP4 Style A (Rocker Switches)

Style B or C (Slide Switches)

New Layout IVP4 Style D (With Audio Jacks)

Style E (No Audio Jacks)

Audio Jacks

Old Layout IVP6

Style C (Slide Switches)

New Layout IVP6 Style D (With Audio Jacks)

Audio Jacks

Page 32

Setting IVP Switches

If space allows, up to three IVP boards (maximum of 12 ports) can be installed in the MAP/5 for use with AUDIX Voice Power or FAX Attendant System.

On old layout IVP4 and IVP6 boards, switch bank 1.1 (on the left) sets line equalization. Initially set all switches as shown below.

IVP4 Port

IVP6 Port

Rocker Style A

1 2 3 4 1 2 3 4 5 6

Slide Style B

1 2 3 4 1 2 3 4 5 6

Slide Style C

1 2 3 4 1 2 3 4 5 6

The illustration above correlates the port number with the switch number.

If there are touch-tone recognition problems, change the switches for the affected port to the opposite position.

The illustration above correlates the port number with the switch numbers. The new layout IVP4 and IVP6 boards have automatic equalization, so there are no line equalization switches.

Note:

Style Band C boards cannot be visually distinguished on the actual board, and neither the "open" nor "on" positions are marked on the switches. If the address switches on an existing board do not match any of the shown address switch settings for style B or C boards, set the board for style C and test it using the IVP board diagnostics (see page 77). If the test fails, try the style B setting.

Use the following drawings as a guide for setting address switches (bank 12.1 on the right on old layout boards or

the only switch bank on new layout boards), or for identifying the board type for style B or C boards.

AT&T - Proprietary

Page 25

Page 33

MAP/5 Technical Job Aid

Page 26

IVP Address Switch Settings

On old layout IVP4 andIIVP6 boards, the right bank of switches (12.1) sets the board address. On new layout boards, there is only one bank of switches and it sets the board address.

First

Board

Second

Board

Third

Board

Rocker Style A

OPEN

Old Layout

Slide Style B

OPEN

Slide Style C

OPEN

New Layout

Rocker Style D Rocker Style E (IVP4)

OPEN

Page 34

IFP2 Switch and Jumper Settings (MERLIN LEGEND)

Use this drawing as a guide to identifying the IFP2 board and for setting jumpers and switches (for MERLIN LEGEND; DEFINITY is on the next page). The IFP4 Board is on the following page.

Note: Mixed IFP2 and IFP4 configurations are not allowed.

Note: MERLIN LEGEND can support up to 5 IFP2 boards AT&T - Proprietary

Page 27

Page 35

MAP/5 Technical Job Aid

IFP2 Switch and Jumper Settings (DEFINITY)

Page 28

Note: DEFINITY can support up to 4 IFP2 boards.

Page 36

IFP4 Identification and Settings

Use this drawing as a guide for identifying IFP4 boards and setting IFP4 switches and jumpers.

AT&T - Proprietary

Page 29

Page 37

MAP/5 Technical Job Aid

Page 30

Identifying and Setting IVC6 (AYC10) Board for INTUITY™

Use this drawing as a guide for identifying and setting IVC6 tip/ring boards for INTUITY™ applications. Note: 2

boards (12 ports) maximum per MAP/5.

IVC6-IU T/R 0 First card installed

IVC6-IU T/R 1 Second card installed

8-pin

modular

jacks

Audio input

Audio

output

Page 38

Identifying and Setting General Purpose Synchronous Controller (GP-synch) Board for INTUITY™

Use this drawing as a guide for identifying and setting the GP-synch board for INTUITY™ applications. Do not use

Jumper switches J1 to J5. The board is also referred to as the GPSC-AT/E board.

AT&T - Proprietary

RS-232C

25-pin

connector

Page 31

Page 39

MAP/5 Technical Job Aid

Identifying Multi-port Serial Board for INTUITY™

Use this drawing as a guide for identifying the Multi-port Serial board for INTUITY™ applications.

Do not use

jumpers

Page 32

Each port is a 6 wire RJ-11 jack

ttysaa

ttysab ttysac ttysad

ttysae

ttysaf

ttysag

ttysah

Page 40

Identifying and Setting ACCX Networking (AYC22) Board for INTUITY™

Use this drawing as a guide for identIfying and setting the ACCX Networking board for INTUITY™ applications.

Base I/O address = 140 hex

ACCX (AYC22) Card

AT&T - Proprietary

78 pin D-Sub connector

Page 33

Page 41

MAP/5 Technical Job Aid

Page 34

Identifying DCP Boards

Use this drawing as a guide for identifying new and old DCP boards and verifying jumper settings. Older systems

rnay have an earlier DCP board that does not have the bridged pins shown in the drawing. Those older boards will not function properly if used with the MAP/5.

NOTE: pins may be bridged on either the front

(component side) or the

back (solder side) of the

Phone

Line

Other

board. If pins are not

bridged on the front of the board, note the location of component IC18 and turn

the board over to check the

back side.

If pins are bridged on the back (solder side) of the board, it will look like this:

If pins are bridged on the front (component side) of the board, component IC18 will look like this:

Page 42

Identifying CMS Boards

Use this drawing as a guide for identifying and setting jumpers on CMS boards. Note: Settings based on version of CMS.

AUX

CU1

CU2

AT&T - Proprietary

D2000 RAM ADDRESS

MERLIN II CMS R2.2 System 25 CMS R1.2 MERLIN LEGEND CMS (all releases)

IRQ2

IRQ3

MERLIN II CMS R2.0 (& earlier) System 25 CMS R1.0

C0000 RAM ADDRESS

Page 35

Page 43

MAP/5 Technical Job Aid

Identifying SatisFAXtion® Boards

Use this drawing as a guide for identifying SatisFAXtion® boards.

Page 36

Phone Line

Intel SatisFAXtion® Modem Board/200

Note: All board settings done automatically by software (no physical settings required).

Page 44

10 Connecting the MAP/5 to the Voice Switch

Use the tables below to determine which diagrams to use as guides for connecting the MAP/5 to the

communications system. Complete documentation accompanies each application and the switch itself.

All Systems Connection Type IVP4 (RJ11C/884A)

IVP6 (RJ11C/885A) IVP6 (108B/104A) IFP CMS Board SatisFAXtion® Board

Diagram Contents IVP4 Connections (RJ11C with 884A) IVP6 Connections (RJ11C with 885A) IVP6 Connections (108B & 104A) IFP Connections CMS Board Connections SatisFAXtion® Board Connections

Page

41 42 43 44

45 46

continued on next page

AT&T - Proprietary

Page 37

Page 45

MAP/5 Technical Job Aid

MERLIN LEGEND Connection Diagrams

MERLIN LEGEND Communications System

Page 38

System

UNIX (IS) N/A

MS-DOS Same Outlet

Distance

Same Outlet ADU

ADU

Connection Type

Overview Admin & SMDR Admin (w/wo SMDR)

SMDR (w/wo Admin) Admin Only SMDR Only Admin Only

SMDR Only

Diagram Contents

Integrated Solution Connection Overview Administration and/or SMDR Connection Administration (with/without SMDR) Connection SMDR (with/without Administration) Connection Administration Only Connection

SMDR Only Connection

Administration Only Connection

SMDR Only Connection

continued on next page

Page

47 48

49 50 51 52 53 54

Page 46

System 25 Connection Diagrams

System 25 Communications System

System

UNIX (IS)

MS-DOS

Distance

N/A Same Outlet ADU

Same Outlet

ADU

Connection Type

Overview Admin & SMDR Admin (w/wo SMDR)

SMDR (w/wo Admin)

Admin Only

SMDR Only

Admin Only

SMDR Only

Diagram Contents

Integrated Solution Connection Overview Administration and/or SMDR Connection Administration (with/without SMDR) Connection

SMDR (with/without Administration) Connection Administration Only Connection

SMDR Only Connection

Administration Only Connection

SMDR Only Connection

continued on next page

Page

55 56 57 58 59 60 62

AT&T - Proprietary

Page 39

Page 47

MAP/5 Technical Job Aid

DEFINITY/System 75 Connection Diagrams

DEFINITY/System 75 Communications System

Page 40

System

UNIX (IS)

INTUITY™

MS-DOS

Distance

N/A Under 5000 Under 1000 Under 2000 Under 5000 N/A N/A

N/A N/A N/A

Under 1000 Under 2000

Connection Type

Overview AVP

SMDR

IVC6

GP-synch ACCX Networking ACCX Networking

Multi-port Serial

SMDR

Diagram Contents

Integrated Solution Connection Overview DCP Board Connections SMDR Connection (Under 1000 Feet) SMDR Connection (TN-726 Data Line Port)

SMDR Connection (7400A Data Module)

INTUITY™ Connection Overview

IVC6 Connections (RJ11C with 885A) GP-synch Connection to DEFINITY Options ACCX Networking Connection Options ACCX Networking Connection to Breakout Box

Multi-port Serial Connection Options

SMDR Connection (Under 1000 Feet)

SMDR Connection (TN-726 Data Line Port)

Page

63 64 65 66

69 70 71

72 73 74 75

Under 5000

SMDR Connection (7400A Data Module)

Page 48

IVP4 Connections (RJ11C with 884A)

884A Adapter

D4BU-29

RJ14C

IVP4

1-2

RJ11C

Line A RJ11C Line B

RJ14C

IVP4

3-4

RJ11C Line C RJ11C

Line D

D4BU-29

AT&T - Proprietary

Page 41

Page 49

MAP/5 Technical Job Aid

IVP6 Connections (RJ11C with 885A)

Page 42

Page 50

IVP6 Connections (108B & 104A)

Note: The numbers in the circles represent the punch down connector positions on the jacks.

AT&T - Proprietary

Page 43

Page 51

MAP/5 Technical Job Aid

IFP CONNECTIONS

Page 44

IFP2 Board

IFP4 Board

Page 52

CMS Board Connections

Analog Operator (ATL) Ports

CMS Announcement Unit

D7R-87

D8W-87

AT&T - Proprietary

Page 45

Page 53

MAP/5 Technical Job Aid

SatisFAXtion® Board Connections

Tip/Ring Analog Port

Page 46

Page 54

MERLIN LEGEND: Integrated Solution Connection Overview

AT&T - Proprietary

Page 47

Page 55

MAP/5 Technical Job Aid

Page 48

MERLIN LEGEND: UNIX Administration and/or SMDR Connection (Same AC Outlet)

MAP/5

Serial Port 2 (tty01)

Serial Port 1 (tty00)

DB-9S to DB-25P Adapter Cable

355AF

Adapter

355AF Adapter

Z200A EMI Filter

Long End

Modular Cord

Max 50 Feet

Short End

D8W-87

SMDR Port

ADMIN

Port

Page 56

MERLIN LEGEND: UNIX Administration (with/without SMDR) Connection (ADU)

AT&T - Proprietary

Page 49

Page 57

MAP/5 Technical Job Aid

Page 50

MERLIN LEGEND: UNIX SMDR (with/without Administration) Connection (ADU)

Page 58

MERLIN LEGEND: MS-DOS Administration Only Connection (Same AC Outlet)

MAP/5

Serial Port 1

(tty00)

AT&T - Proprietary

355AF Adapter

D8W-87

Modular Cord

Max 50 Feet

ADMIN

Port

Page 51

Page 59

MAP/5 Technical Job Aid

MERLIN LEGEND: MS-DOS SMDR Only Connection (Same AC Outlet)

MAP/5

Page 52

Serial Port 1 (tty00)

355AF Adapter

Long End

Z200A EMI Filter

Max 50 Feet

Short End

SMDR

Port

Page 60

MERLIN LEGEND: MS-DOS Administration Only Connection (ADU)

AT&T - Proprietary

Page 53

Page 61

MAP/5 Technical Job Aid

MERLIN LEGEND: MS-DOS SMDR Only Connection (ADU)

Page 54

Page 62

System 25: Integrated Solution Connection Overview

AT&T - Proprietary

Page 55

Page 63

MAP/5 Technical Job Aid

Page 56

System 25: UNIX Administration and/or SMDR Connection (Same AC Outlet)

Page 64

System 25: UNIX Administration (with/without SMDR) Connection (ADU, RMD)

AT&T - Proprietary

Page 57

Page 65

MAP/5 Technical Job Aid

System 25: UNIX SMDR (with/without Administration) Connection (ADU)

Page 58

Page 66

System 25: MS-DOS Administration Only Connection (Same AC Outlet)

System 25

MAP/5

Serial Port 1

(tty00)

355AF

Adapter

Admin Port

Plug 1 on Octopus Cable or Jack 1 on 110 Cross

D8W-87 Connect from Processor Module of System 25

50 feet max

AT&T - Proprietary

Page 59

Page 67

MAP/5 Technical Job Aid

System 25: MS-DOS SMDR Only Connection (Same AC Outlet)

Page 60

System 25

MAP/5

Serial

Port 1 (tty00)

D8W-87

50 feet max

SMDR Port

Plug 2 on Octopus Cable or

Jack 2 on 110 Cross Connect

from Processor Module of System 25

Page 68

System 25: MS-DOS Administration Only Connection (ADU, RMD)

AT&T - Proprietary

Page 61

Page 69

MAP/5 Technical Job Aid

System 25: MS-DOS SMDR Only Connection (ADU)

Page 62

Page 70

DEFINITY/System 75: Integrated Solution Connection Overview

AT&T - Proprietary

Page 63

Page 71

MAP/5 Technical Job Aid

DEFINITY/System 75: DCP Board Connections

D8W-87

Page 64

To TN 754B Digital Line Plan

Note: DCP board required with AVP and FAS.

Page 72

DEFINITY/System 75: UNIX SMDR Connection (Under 1000 Feet)

DEFINITY/System 75 Communications System

Connect to DCE Socket

355A Adapter

D8W-87

Wall Jack

Building Wire Up To 1000 Feet

Wall Jack

D8W-87

355AF

Adapter

MAP/5

Serial Port 2

(tty01) DB-9S to DB-25P Adapter Cable

AT&T - Proprietary

Page 65

Page 73

MAP/5 Technical Job Aid

Page 66

DEFINlTY/System 75: UNIX SMDR Data Connection (TN-726 Data Line Port)

Building Wire to

TN 726

Data Line Port

(up to 2000 feet)

D8W-87

Modular Cord.

Z3A2 ADU

DB-9S to

DB-25P Adapter Cable

MAP/5

Serial Port 2 (tty01)

Page 74

DEFINITY/System 75: UNIX SMDR Data Connection (7400A Data Module)

Building wire to

TN 754

Digital Line Port

(up to 5000 feet)

D8W-87

Modular Cord

7400 A

Data Module

Power

Supply

355A Adapter

D8W-87

Modular Cord.

(up to 50 feet)

355AF Adapter

DB-9S to DB-25P

Adapter Cable

MAP/5

Serial Port 2 (tty01)

AT&T - Proprietary

Page 67

Page 75

MAP/5 Technical Job Aid

DEFINITY: INTUITY™ Connection Overview

Page 68

Page 76

DEFINITY: IVC6 Board Connections (RJ11C with 885A) for INTUITY™

AT&T - Proprietary

Page 69

Page 77

MAP/5 Technical Job Aid

DEFINlTY: GP-synch Board Connection Options for INTUITY™

Page 70

Page 78

DEFINITY: ACCX Networking Board Connection Options for INTUITY™

AT&T - Proprietary

Page 71

Page 79

MAP/5 Technical Job Aid

DEFINITY: ACCX Networking Board Connection to Breakout Box

ACCX Cable

ACCX Networking

Board

Page 72

Breakout

Box

Page 80

DEFINITY: Multi-port Serial Connection Options for INTUITY™

AT&T - Proprietary

Page 73

Page 81

MAP/5 Technical Job Aid

DEFINITY/System 75: MS-DOS SMDR Connection (Under 1000 Feet)

Page 74

DEFINITY/System 75 Communications System

Connect to DCE Socket

355A

Adapter

D8W-87

Wall Jack

Building Wire Up To 1000 Feet

Wall Jack

D8W-87

355AF Adapter

MAP/5

Serial Port 1 (tty00)

Page 82

DEFINITY/System 75: MS-DOS SMDR Data Connection (TN-726 Data Line Port)

Building Wire to TN726

Data Line Port (up to 2000 feet)

D8W-87

Modular Cord.

Z3A2 ADU

MAP/5

Serial Port 1 (tty00)

AT&T - Proprietary

Page 75

Page 83

MAP/5 Technical Job Aid

Page 76

DEFINITY/System 75: MS-DOS SMDR Data Connection (7400A Data Module)

Building wire to TN 754

Digital Line Port (up to 5000 feet)

D8W-87

Modular Cord.

7400 A

Data Module

Power

Supply

D8W-87

Modular Cord

355A 355AF

Adapter

(up to 50 feet)

Adapter

MAP/5

Serial Port 1 (tty00)

Page 84

11 Testing Basic Functionality

Verify that the applications are installed and that you have connected all the hardware correctly. The applications cannot be customized until the system is functional.

Application

AVP under Integrated Solution To test whether you can get dial tone through the IVP connections:

Test

2. Select

Select

The system searches for dial tone and loop current on the boards, then reports whether each board passes the test. If dial tone or

loop current is not found, check phone line connections using a

telephone set.

Note:

NO DIAL TONE

chip in socket that is not soldered), and reconnect. Also, check the address switch settings.

Exit the menus.

Technician Maintenance.

Maintenance Log. IVP Board Diagnostics.

If you run diagnostics and get the message

check for a loose chip on the voice board (the only

IN SERVICE.

AT&T - Proprietary

Page 77

Page 85

MAP/5 Technical Job Aid

Page 78

Application

Stand-Alone AVP

Test

To test whether you can get dial tone through the IVP connections:

Select

The system searches for dial tone and loop current on the boards,

then reports whether each board passes the test. If dial tone or

loop current is not found, check phone line connections. Note: If you run diagnostics and get the message

NO DIAL TONE

chip in socket that is not soldered), and reconnect. Also, check the address switch settings.

Exit the menus.

Voice System Administration. Configuration Management.

System Control. Diagnose Equipment.

IN SERVICE.

check for a loose chip on the voice board (the only

Page 86

Application

Test

Call Accounting System under

Integrated Solution Integrated Solution Call Accounting

System

CAS Plus V3 CAS for Windows

To test whether CAS is collecting calls and can produce a report:

Note:

Make sure

ACTIVATED

(Windows). Make sure the port is

(UNIX and Windows), or just physically Make several calls on the switch. Wait at least 10 minutes. Generate any Selection Report. Be sure to use today’s date.

Make sure the calls you made are on the report. If the report is printed, this process also tests the printer

connection.

COSTING

(MS-DOS), or

CONNECTED

(UNIX),

RATING CALLS

CALL PROCESSING

and

STARTED

ENABLED

CONNECTED

via software

(MS-DOS).

AT&T - Proprietary

Page 79

Page 87

MAP/5 Technical Job Aid

Page 80

Application

AAS (System 25)

Test

To test whether AAS is installed and connected:

Under Integrated Solution (UNIX), if AAS is installed, it will appear on the IS II or IS III Maintenance Menu. For MS-DOS, AAS starts from the C:> prompt.

To see if AAS is connected, select it from the IS main menu or

start it from the C:> prompt. If it is not connected, you will get the following message:

There is no response from the switch.

Page 88

Application

Test

SPM (MERLIN LEGEND)

To test whether SPM is installed and connected:

Under Integrated Solution (UNIX), if SPM is installed, SPM will appear on the IS II or IS III Main Menu. For MS-DOS, SPM starts from the C:> prompt.

If the software is loaded, the "Welcome to SPM" screen will appear.

To see if it is connected, press any key to continue. If it is not

connected, you will get one of the following messages:

Warning:

communication with switch. Please check connection between PC and switch. spm getty not responding

On the MERLIN LEGEND, the Access Log screen will also show

link down

If it is connected, the SPM Main Menu will appear after the "Welcome to SPM" screen.

SPM process is unable to establish

if the connection is not established.

AT&T - Proprietary

Page 81

Page 89

MAP/5 Technical Job Aid

Page 82

Application

CMS

Test

To test whether CMS is installed and connected:

CMS creates its own that CMS starts automatically when PC is turned on. Therefore, if installed correctly, the CMS Main Menu should automatically

appear.

Additional testing is covered in the CMS Installation & System

Programming Guide. The 5 tests are: startup, line status, agent status, voice announcement unit and intraflow. NOTE: CMS requires some customization before running these tests.

auto exec bat

and

config.sys

files so

Page 90

12 Reviewing System with Customer

As part of the System Manager's training, be sure to include the following points:

Stress importance of regular backups.

☎

Show customer where to find information in documentation.

☎

Point out connections for monitor, keyboard, and power source.

☎

Demonstrate power switches, lights on system unit and monitor, and contrast control on monitor. (Let

☎

customer know monitor can be off during operation.)

Explain that customer must not press the [ RESET ] button unless prompted by the system (during the

☎

shutdown process), or told to do so by the NSAC, TSC, or by an AT&T authorized dealer.

☎

Be sure customer knows phone number of remote maintenance access. (Customer will have to give

number to NSAC or TSC if remote maintenance is needed.) Give NSAC (1-800-628-2888) or TSC (1-800-562-8349 for AUDIX Voice Power/FAX Attendant System

☎

and INTUITY, 1-800-422-6622 for CAS) Helpline #. (Note that this is not the same number that you use.) Tell customer that tape drive requires DC6525 (QIC) or DC6525 (SCSI) tapes.

☎

Warn customer not to leave a bootable diskette in the floppy drive because a power outage or unintentional reboot could cause the system to boot from the floppy and accidentally delete information or boot the wrong application.

Stress the need for periodic, systematic system shutdown. Recommend that system be shutdown

☎

monthly. If the system is equipped with a surge protector, explain that the "good ground" LED should be lit.

☎

AT&T - Proprietary

Page 83

Page 91

MAP/5 Technical Job Aid

Troubleshooting

Page 84

If:

If you encounter errors during system startup, or are prompted to run the Setup Utility

If you need to:

●

Change memory or hard disk drive size Change from DOS to UNIX operating system or

●

upgrade to SCSI

●

SCSI Address conflict Disable Serial Port 2

●

If you suspect hardware problems

If the system experiences a catastrophic failure (loss of the hard drive)

Do:

Running the SETUP Utility

Basic System Configuration

1a.

Advanced System Configuration

1b.

Alternate SCSI Address

1c. 1d.

System Security Configuration

(Disable Serial Port 2)

Running the AT&T MAP/5 Diagnostic

Program Recovering from Catastrophic Failure

Page

86 89

92 93

Page 92

1 Running the SETUP Utility

If you encounter errors during system startup, you may be prompted to run the SETUP Utility, which allows you to reconfigure the system unit. To run the utility at any time:

Exit any application using the application shutdown procedure.

1. For UNIX systems, stop the voice system if it is running. Then, shut down the system using

SHUTDOWN

the

For MS-DOS, exit all applications or close windows until you reach a DOS prompt.

When you get the message to reboot the system, (UNIX only) or from the DOS prompt, press the [ RESET ] button on the system unit. This is one of the few times you can safely use the [ RESET

potential file damage.

When you see the screen that says:

Video ROM BIOS

immediately press and hold the [ CTRL ] and [ ALT ] keys, then press the [ ESC ] key.

menu selection.

] button without any

AT&T - Proprietary

Page 85

Page 93

MAP/5 Technical Job Aid

1a Basic System Configuration

From the main menu, choose

applicable to any of the supported MAP/5 configurations, and may be ignored. From the System Configuration submenu, choose the illustration below. The values in the fields may change for different MAP/5 models as shown in the table on the following page.

System Configuration.

Basic System Configuration.

Fixed Disk 0, Extended Memory,

The warning message on the screen is not

Page 86

The next screen should look like

and

Total Memory

Basic System Configuration

Date Time Diskette Drive A Diskette Drive B

Fixed Disk 0 (

202 MB)

Fixed Disk 1 (

Base Memory Extended Memory

Total Memory Math Coprocessor Video Display

0 MB)

[xx/xx/xx] [xx/xx/xx] [1.44 MB 3.5 inch] [None

[ 46]

Cylinder

683

] Head /Track

[None] [ 640]KB

[ 3328]KB [ 3968]KB

[Not Installed] [VGA/EGA]

Sector

Page 1

Landing Write

Zone Precomp None

continued on next page

None

Page 94

Memory and Disk Information by MAP/5 Model:

Item

Fixed Disk 0 Size (formatted capacity*)

Fixed Disk 0 Type

Extended Memory Total Memory

* Disk size is "formatted" capacity, which is always less than "quoted" capacity.

To change values on the

[ ← ] or [ → ] key to toggle to the correct type. The other values on the match the type automatically. (See screen illustration on previous page.)

The values for memory are automatically determined. If they do not match the amount of memory that

3. should be installed, visually verify that the memory is installed and test its operation using the AT&T

MAP/5 Diagnostic Program.

4X1I

202 MB 202 MB

3328 KB 3968 KB

FIXED DISK 0

8X1IT

7424 KB

8096 KB

line, press the [ ↑ ] or [ ↓ ] key to highlight the line, then use the

240 MB

7424 KB 8096 KB

8X2IT

406MB

7424 KB

8096 KB

486 MB

49 7424 KB

8096 KB

FIXED DISK 0

8X5IT

504 MB

7424 KB 8096 KB

line are filled in to

continued on next page

20X5ST

0 MB

None

19456 KB 20096 KB

AT&T - Proprietary

Page 87

Page 95

MAP/5 Technical Job Aid

Go to the next screen by pressing the [ PAGE DOWN ] key. The values you see should match the ones in the following screen illustration. If they don’t, you can change the values with the arrow keys as described in

Step 2.

When you are finished, press [ ESC ]. A confirmation box will ask if you want to save the settings you have changed. Move the highlight to

[ Yes ]

Page 88

and press [ ENTER ].

Basic System Configuration

Communications Settings

Baud Rate Parity

Stop Bits Data Length

Memory Test

Page 2

[9600] BPS

[None] [1] Bits [7] Bits

[Enabled]

Page 96

1b Advanced System Configuration

You get to Advanced System Configuration by:

1. Run the SETUP utility. See page 85.

2. Select

The variations on each page by MAP/5 model are shown in the following four screen illustrations.

Advanced System Configuration

Model 4X1I Only, Page 1

on the System Configuration menu.

Advanced System Configuration

Shadow RAM

F0000h-FFFFFh (System BIOS)

C0000h-C7FFFh (Video BIOS) C8000h-CFFFFh D0000h-D7FFFh D8000h-DFFFFh E0000h-E7FFFh E8000h-EFFFFh

System Cache

F0000h-FFFFFh (System BIOS) C0000h-C7FFFh (Video BIOS)

System Speed

Memory at 15MB-16MB Reserved for

Page 1

[Enabled ] [Enabled ] [Disabled] [Disabled] [Disabled] [Disabled] [Disabled]

[Enabled ] [ Cacheable ] [ Cacheable ]

[High]

[ System ] Use

AT&T - Proprietary

Page 89

Page 97

MAP/5 Technical Job Aid

Page 90

All Models Except

Model 4X1I, Page 1

Advanced System Configuration

Shadow RAM

F0000h-FFFFFh C0000h-C7FFFh

(System BIOS)

(Video BIOS) C8000h-CFFFFh D0000h-D7FFFh

D8000h-DFFFFh E0000h-E7FFFh E8000h-EFFFFh

System Cache

F0000h-FFFFFh (System BIOS) C0000h-C7FFFh (Video BIOS)

System Speed

Memory at 15MB-16MB Reserved for

Page 1

[Enabled ] [Enabled ] [Disabled] [Disabled] [Disabled] [Disabled] [Disabled]

[Enabled ] [Noncacheable ] [Noncacheable ]

[High]

[ System ] Use

Page 98

Model 20X5ST (SCSI Hard Drive),

Page 2

Advanced System Configuration

SCSI BIOS BASE Address

SCSI Synchronous Negotiation SCSI IRQ Channel

SCSI IO Address

All Non-SCSI Models,

Page 2

Advanced System Configuration

SCSI BIOS BASE Address SCSI Synchronous Negotiation

Page 2

[0D8000H ] [Enabled]

[IRQ 11]

[340H]

Page 2

[Disabled]

[Enabled]

SCSI IRQ Channel SCSI IO Address

AT&T - Proprietary

[IRQ 11]

[340H]

Page 91

Page 99

MAP/5 Technical Job Aid

Page 92

1c Alternate SCSI Address

The SCSI I/O address is assigned even on non-SCSI systems. If an alternate SCSI I/O address is ever

required because of a conflict with another expansion board, see the documentation for the application that requires the expansion board, and follow these steps:

Change the SCSI address jumper JP6 on the main board from open to closed, as indicated by the "Without SCSI (alternate address)" callout on page 115.

Run the SETUP utility. See page 85.

2. Select

On Page 2 of

parameter to

Change the

Advanced System Configuration.

Advanced System Configuration,

[0D8000H ]. SCSI I/O Address SCSI BIOS BASE Address

This enables SCSI so that the I/O address can be changed.

parameter to

See page 89.

change the

[140H].

[Disabled].

SCSI BIOS BASE Address

Page 100

1d System Security Configuration (Disable Serial Port 2)

Some applications, such as HackerTracker with the SatisFAXtion board, require that Serial Port 2 be disabled. To disable Serial Port 2, follow these steps:

Run the SETUP Utility. See page 85. The port configuration parameters are accessed through the

2. Utility main menu. See page 93.

Disable Serial Port 2. Note that this may change the value for serial port 1.

Verify that Serial Port 1 has the correct value as shown in the following screen illustration.

System Security

Security Utility

Disk Drive Control

Diskette Drive

Fixed Disk Drive System Boot Drive

[ Normal ] [ Normal ]

[AUTO]

On Board Communication Ports

Serial Port 1 Serial Port 2

Parallel Port

Setup Password Power On Password

[Enable (COM1)] [Disable [Enable (378h)]

[ None ] [ None ]

(25 Pin)

]

( 9 Pin)

choice on the SETUP

Page 1

AT&T - Proprietary

Page 93
