AT&T ISB7105 User Manual
Cisco
IPTV Receivers
Product Manual
ISB7105
For use with your AT&T U-verse TV service
2
Contents
Notice for Installers ..........................................................................................................4
IMPORTANT SAFETY INSTRUCTIONS..............................................................................4
Change the Way You Watch TV .......................................................................................7
What’s In the Carton? ......................................................................................................7
Safety First .......................................................................................................................7
Identify Your Receiver with the Serial Number .................................................................7
In This Manual ..................................................................................................................7
Protecting You and the Environment ................................................................................7
Front Panel .......................................................................................................................8
Back Panel ....................................................................................................................... 9
Connecting the Receiver ................................................................................................10
ISB7105 Wireless Network Connection .........................................................................11
Connecting the Wireless Access Point to the Gateway ....................................................... 12
Pairing the Wireless Access Point and Receiver ............................................................12
Connections for a High-De nition TV (HDTV) ................................................................13
Connections for a Standard-De nition TV (SDTV) .........................................................14
Connections for a VCR or DVD Recorder .......................................................................15
Connecting an Over-the-Air Converter Box ...................................................................15
Connecting to an HDTV with an HDMI Connector ..........................................................16
Connecting to an HDTV with a DVI Connector ...............................................................17
Connecting to an HDTV with Component (YPbPr) Connectors ......................................18
Connecting to an SDTV with Component (YPbPr) Connectors ......................................19
Connecting to an SDTV with an RCA-Type Connector ..................................................20
Connecting to a Home Theater System with Component (YPbPr) Connectors .............21
Connecting to a Stereo VCR or DVD Recorder (optional) ..............................................22
Troubleshooting .............................................................................................................23
Avoid Screen Burn-In .....................................................................................................23
Frequently Asked Questions ..........................................................................................24
Picture Formats ..............................................................................................................25
Index ..............................................................................................................................26
Compliance Information ................................................................................................. 28
3
Notice for Installers
Note to System Installer
WARNING
TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE.
For this apparatus, the cable shield/screen shall be grounded
as close as practical to the point of entry of the cable into the
bu ild ing .Fo r p rod u ct s s ol d i n th e U S an d C ana d a, t h is
reminder is provided to call the system installer's attention to
Article 800-93 and Article 800-100 of the NEC (or Canadian
Electrical Code Part 1), which provides guidelines for proper
grounding of the cable shield.
This symbol is intended to alert you that uninsulated voltage
within this product may have sufficient magnitude to cause
electric shock.Therefore, it is dangerous to make any kind of
contact with any inside part of this product.
Ce symbole a pour but d’alerter toute personne qu’un contact
avec une pièce interne de ce produit, sous tension et non isolée,
pourrait être suffisant pour provoquer un choc électrique. Il est
donc dangereux d’être en contact avec toute pièce interne de
ce produit.
Thi s symbol is inte nde d to ale rt you of the pr ese nce of impo rtant
operating and maintenance (servicing) instructions in the literature
accompanying this product.
Ce s ym b ol e a po ur bu t de vou s av e rt ir qu ’u n e do cu m en t at i on
importante sur le fonctionnement et l’entretien accompagne ce produit.
CAUTION: To reduce the risk of electric shock, do not remove cover (or
back). No user-serviceable parts inside. Refer servicing to qualified
service personnel.
The servicing instructions in this notice are for use by quali ed service personnel only. To reduce the risk of electric
shock, do not perform any servicing other than that contained in the operating instructions, unless you are quali ed
to do so.
20080814_Installer800
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
a c c o r d a n ce w i t h the ma nu fa ct ur er ’s
instructions.
8) Do not install near any heat sources such as
radia tors, heat regist ers, stoves, or other
apparatus (including ampli ers) that produce
heat.
9) Do not defeat the safety pur po se of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding-type plug has two blades
and a third grounding prong. The wide blade or
the third prong are provided for your safety. If
the provided plug does not t into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10) Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11) Only use attachments/accessories speci ed by
the manufacturer.
12) Use only with the cart, stand, tripod,
13) Unplug this apparatus during lightning storms
14) Refer all servicing to quali ed service personnel.
br acke t, or ta bl e specif ied by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving
the cart/apparatus combination to avoid injury
from tip-over.
or when unused for long periods of time.
Servicing is required when the apparatus has
been damaged in any way, such as a powersupply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
Power Source Warning
A label on this product indicates the correct power
source for this product. Operate this product only from an
electrical outlet with the voltage and frequency indicated
on the product label. If you are uncertain of the type of
power supply to your home or business, consult your
service provider or your local power company.
The AC inlet on the unit must remain accessible and
operable at all times.
4
WARNING: Avoid electric shock and fire
hazard! If this product connects to cable wiring,
be sure the cable system is grounded (earthed).
Grounding provides some protection against
voltage surges and built-up static charges.
Protect the Product from Lightning
In addition to disconnecting the AC power from the wall
outlet, disconnect the signal inputs.
Verify the Power Source from the
On/O Power Light
When the on/off power light is not illuminated, the
apparatus may still be connected to the power source.
The light may go out when the apparatus is turned o ,
regardless of whether it is still plugged into an AC power
source.
Eliminate AC Power/Mains Overloads
WARNING: Avoid electric shock and fire
ha za rd ! Do not overload AC powe r/ ma ins,
outlets, extension cords, or integral convenience
receptacles. For products that require battery
power or other power sources to operate them,
refer to the operating instructions for those
products.
Provide Ventilation and
Select a Location
• Remove all packaging material before applying power
to the product.
• Do not place this apparatus on a bed, sofa, rug, or
similar surface.
• Do not place this apparatus on an unstable surface.
• Do not place this apparatus in excessive heat or
moisture.
• Do not install this apparatus in an enclosure, such as
a bookcase or rack, unless the installation provides
proper ventilation.
• Do not place entertainment devices (such as VCRs
or DVDs), lamps, books, vases with liquids, or other
objects on top of this product.
• Do not block ventilation openings.
Operating Environment
This product is designed for operation indoors with a
temperature range from 32° to 104° F (0° to 40°C).
Each product should have adequate spacing on all
sides so that the cooling air vents on the chassis are
not blocked.
Protect from Exposure to Moisture
and Foreign Objects
WARNING: Avoid electric shock and fire
hazard! Do not expose this product to dripping or
splashing liquids, rain, or moisture. Objects lled
with liquids, such as vases, should not be placed
on this apparatus.
WARNING: Avoid electric shock and fire
hazard! Unplug this product before cleaning. Do
not use a liquid cleaner or an aerosol cleaner. Do
not use a magnetic/static cleaning device (dust
remover) to clean this product.
WARNING: Avoid electric shock and fire
hazard! Never push objects through the openings
in th is product. For eign objec ts can cause
electrical shorts that can result in electric shock
or re.
Service Warnings
WARNING: Avoid electric shock! Do not open
the cover of this product. Opening or removing
the cover may expose you to dangerous voltages.
If you open the cover, your warranty will be void.
This product contains no user-serviceable parts.
Check Product Safety
Upon completion of any service or repairs to this product,
the service technician must perform safety checks
to determine that this product is in proper operating
condition.
Protect the Product When Moving It
Always disconnect the power source when moving the
apparatus or connecting or disconnecting cables.
20110316_IP_No Tuner_Safety
IMPORTANT SAFETY INSTRUCTIONS, continued
Ground the Product
5
6
Change the Way You Watch TV
Welcome to Internet Protocol TV (IPTV). The ISB7105 device, known as an IPTV receiver,
brings a rich, new set of interactive services directly to you through your TV and your
in-home IP network. The receiver uses wireless technology 802.11n to connect to the
network.
The ISB7105 receiver allows for easy and secure connection to IPTV services. The signal
strength indicator on the front panel of the receiver identi es the strength of the wireless
connection and aids in the proper placement of the receiver.
What’s In the Carton?
In addition to this product manual, the receiver carton contains the following items:
• An ISB7105 Receiver - A wireless receiver
• A power cord and power adapter
To support the wireless functionality of the ISB7105 receiver, you will also need a
wireless access point that is packaged separately from your receiver. See page 12 of
this guide for more information on the wireless access point.
Safety First
Before using the receiver, read the Important Safety Instructions section of this manual.
Identify Your Receiver with the Serial Number
At times your service provider may ask for the serial number. To nd the serial number
for your receiver, look on the bottom of the receiver for the label. The serial number is a
9-digit numeric code to the right of the letters “S/N” on the label.
Use the space provided here to record the serial number:
___________________________________
In This Manual
This manual covers the information you need to connect your receiver to both your
in-home IP network and your entertainment system. The manual also outlines certain
safeguards and installation information. The safety information contained in this manual
was developed and provided solely by the receiver manufacturer, Cisco Systems, Inc.
Protecting You and the Environment
Cisco addresses the environmental impact of networking products throughout their lifecycle,
from product development, manufacturing, and use to service and end-of-life. Integrating
environmental policies into Cisco engineering and manufacturing practices results in socially
accountable business practices that help reduce the environmental impact associated with
networking products.
7
Front Panel
POWER
LINK HD REC
OK
MENU
ISB7105
T15768
1 102 3 4 5 6 7 8 119
AT&T U-verse
1 Power Turns the receiver on or places it in standby. To restart the
receiver, press and hold the POWER button for 10 seconds. The
LED is green
2 Model Number Identi es the model number of your receiver as ISB7105
3 Signal Strength Identi es the strength of the wireless connection
Indicator
4 Link Indicates network link status. The LED is green
5 HD Indicates the receiver is set to a resolution of 720p, 1080i, or
1080p. The LED is blue
6 Record Indicates that a recording is in progress. The LED is red
7 IR Sensor Receives the infrared signal from the remote control. The sensor
is behind the front panel
8 Menu Accesses the on-screen menu
9 Arrow Keys Accesses on-screen services (such as the on-screen guide,
video-on-demand, or pay-per-view) and navigates menus
10 OK Selects the current item
11 USB Port USB connector. (Reserved for future use)
Note: This illustration may vary from the actual product.
8
Back Panel
NETWORK
L R
Pr Pb Y VIDEO
OUT
AUDIO
OUT
OPTICALHDMI POWER
®
T15874
1 32 4 5 6 7
1 Network Connect to the Ethernet (CAT-5) network at your home, if
applicable
2 YPbPr Connect the receiver to the component video input (YPbPr) on
the HDTV. See pages 13 and 14 for more information
3 Video Out Connect to composite input on your HDTV or SDTV
4 Audio Out (L/R) Connect RCA-type cables to Audio Out to send analog audio
signals (left and right) to a TV with stereo inputs or to a stereo
ampli er
5 HDMI Connect an HDTV HDMI (High-De nition Multimedia Interface)
cable from the HDTV to the HDMI port. HDMI supports both
digital audio and video. See page 13 for more information
6 Optical Connect an optical cable to send a digital audio signal to a
surround-sound receiver or other digital audio device
7 Power Connect the DC output of the AC power adapter (provided) to
deliver power to the receiver
Note: This illustration may vary from the actual product.
9
Connecting the Receiver
1
2
4
3
D
Home Theater
Other
DVDVCR
9
16 4
3
or
To connect your receiver to your network and home entertainment devices, complete
these steps.
Because the connections
for a high-de nition (HD)
or standard-de nition (SD)
TV are di erent, you must
determine if your TV is HD
or SD. Your TV must
receive HD signals for
you to enjoy the bene ts of HDTV. Refer to the manual that came with your TV
for more information. See page 25 for more information on picture formats.
Make the connections for your TV, VCR, and DVD recorder as follows:
• If you are using an HDTV, see page 13 and the connection diagrams in
this manual.
• If you are using a standard-de nition TV, see page 14 and the
connection diagrams in this manual.
• If you want to record some programs on VCR tape or DVD, see page 15
and the connection diagrams in this manual.
Identify the additional
consumer electronic devices
you will connect to the
receiver and TV. See pages
16 through 22 and refer to
the owner’s manual for the
device.
10
Plug the receiver and the TV into an AC power source that is not
controlled by a switch. For further instructions on completing your setup,
contact your service provider.
Loading...
