2.4 GHz Expansion Handset E262

For use with AT&T model E2562 / E2662B

91-5676-10-00_E262Manual_R0FEB2704.qxd 2/27/2004 12:41 PM Page 1

AT&T and the Globe Design are trademarks of AT&T Corp.,

licensed to Advanced American Telephones.

STOP!

See pages 2-3

for easy instructions.

You must charge the battery and register the handset before use.

For customer service or product information, visit our web site at

www.telephones.att.com

or call 1-800-222-3111.

Please also read

Important Product Information

Enclosed in product package.

Before you begin........................................1

Parts checklist.............................................1

Battery installation & charging................2

Registering the handset............................3

Belt clip & optional headset ....................4

Quick reference guide..............................5

91-5676-10-00_E262Manual_R0FEB2704.qxd 2/27/2004 12:41 PM Page 2

Before you begin

This cordless telephone operates with the maximum power allowed by the Federal Communications Commission (FCC). Even so, this handset and E2562 / E2662B base can communicate over only a certain distance — which can vary with the locations of the base and handset, the weather, and the construction of your home or office.

If you receive a call while you are out of range, the handset might not

ring — or if it does ring, the call might not connect when you press L1/L2. Move closer to the base, then press

L1/L2 to answer the call.

If you move out of range during a phone conversation, you might hear

noise or interference. To improve reception, move closer to the base.

If you move out of range without pressing OFF, your phone will be left

“off the hook.” To hang up properly, walk back toward the telephone base, periodically pressing OFF until the call is disconnected.

Parts checklist

Remember to save your sales receipt and original packaging in case you ever need to ship your telephone for warranty service. Check to make sure the telephone package includes the following:

Handset charger

Telephone handset

Power adapter

Belt clip

Battery pack

91-5676-10-00_E262Manual_R0FEB2704.qxd 2/27/2004 12:41 PM Page 1

Light remains on while battery is charging.

LOW BATTERY

RDL MEMMENU

Battery & charger installation

After installation, place the handset in the charger and allow the battery to charge for 12 hours before use. You can keep the battery charged by returning the handset to the charger after each use. When battery power is fully depleted, a full recharge takes about 8 hours.

Press coin into slot on base of handset to release latch, then remove cover.

Insert supplied battery.

Place handset in charger for 12 hours before first use.

Low battery indicator

Return handset to charger when this symbol flashes. (Handset will beep when battery is low.)

Insert top tab first.

Press down to click in place.

Plug power cord into jack on underside of charger, then plug transformer into electrical outlet.

Caution: Use only the supplied NiCd battery (model 2403) or AT&T NiMH replacement battery (model 2401).

91-5676-10-00_E262Manual_R0FEB2704.qxd 2/27/2004 12:41 PM Page 2

Registering the handset

Before using your new handset, you must register it with the E2562 / E2662B base. During registration, you must enter the 15-digit ID number of the telephone base. To find this number, go to the base, press MENU, scroll down to select DISPLAY BASE ID, then press OK.

The handset provided with your telephone is automatically registered as Handset 1. Additional handsets will be assigned numbers in the order they are registered (2, 3, 4, etc.) up to a maximum of eight.

ENTER BASE ID

123456789012345

Enter base ID, then press OK.

HANDSET 2

Handset 1 Handset 2 Handset 3

REDIAL MEMMENU

91-5676-10-00_E262Manual_R0FEB2704.qxd 2/27/2004 12:41 PM Page 3

Belt clip & optional headset

Install belt clip as shown below if desired.

For hands-free telephone conversations, you can use any industry standard 2.5 mm headset (purchased separately). For best results use an AT&T 2.5 mm headset.

Plug 2.5 mm headset into jack on side of handset (beneath small rubber cap).

Snap belt clip into notches on side of handset. Rotate and pull to remove.

91-5676-10-00_E262Manual_R0FEB2704.qxd 2/27/2004 12:41 PM Page 4

Quick reference guide

For complete instructions, please refer to the manual provided with your

E2562 / E2662B telephone.

Off/Clear

During a call, press to hang up.

While using menus, press to cancel an operation, back up to the previous menu, or exit the menu display.

Speaker

Press to activate handset speakerphone. Press again to resume normal handset use (earpiece).

Softkeys

Press a softkey to select a menu item displayed just above the key.

L1/Flash, L2/Flash

Press L1 to make or answer a call on line 1. Press L2 to make or answer a call on line 2.

During a call, press to receive an incoming call, if Call Waiting is activated.

Volume

Press to adjust listening volume.

Xfer/Intercom

Press to transfer a call or initiate an intercom conversation.

Redial Log

Phonebook

Screen menus

Item 1 Item 2 Item 3

HANDSET 2

RDL MEM

Menus

Main Menu

Play New MSG

Call History

Mailboxes

Handset Settings

Ringers

Low Batt Tone

Range Tone

Keypad Tone

Contrast

Enhanced Mode

Rename

91-5676-10-00_E262Manual_R0FEB2704.qxd 2/27/2004 12:41 PM Page 5

Copyright © 2004 Advanced American Telephones. All Rights Reserved. AT&T and the Globe Design are trademarks of AT&T Corp., licensed to Advanced American Telephones. Printed in China. Issue 1 AT&T 02/04. 91-5676-10-00
