AT&T CL82859, CL82309, CL82409, CL82509, CL82609 User Manual

...

User’s manual

CL82109/CL82209/CL82309/ CL82359/CL82409/CL82509/ CL82609/CL82659/CL82859 DECT 6.0 corded/cordless telephone/answering system with caller ID/call waiting

Congratulations

t A

on your purchase of this AT&T product. Before using this AT&T product, please read the Important safety information on pages 62-63 of this manual. Please thoroughly read this user’s manual for all the feature operations and troubleshooting information necessary to install and operate your new AT&T product. You can also visit our website at

www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

Model #: CL82109 (one handset)

CL82209 (two handsets) CL82309/CL82359 (three handsets) CL82409 (four handsets) CL82509 (five handsets) CL82609/CL82659 (six handsets) CL82859 (eight handsets)

Type: DECT 6.0 cordless telephone/answering system

Serial #:

Purchase date:

Place of purchase:

Both the model and serial number of your AT&T product can be found on the bottom of the telephone base.

Save your sales receipt and original packaging in case it is necessary to return your telephone for warranty service.

Compatible with

Hearing Aid T-Coil

TIA-1083

he AT&T logo are trademarks of AT&T Intellectual Property licensed to

dvanced American Telephones, San Antonio, TX 78219. Printed in China.

Telephones identified with this logo have reduced noise and interference when used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083 Compliant Logo is a trademark of the Telecommunications Industry Association. Used under license.

The ENERGY STAR program® (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to mark this product with the ENERGY STAR® label indicating it meets the latest energy efficiency guidelines

Parts checklist

Your telephone package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary.

User’s manual

CL82109/CL82209/CL82309/ CL82359/CL82409/CL82509/ CL82609/CL82659/CL82859 DECT 6.0 corded/cordless telephone/answering system with caller ID/call waiting

User's manual

Quick start guide

Charger for cordless handset with power adapter installed (One for CL82209) (Two for CL82309/CL82359) (Three for CL82409) (Four for CL82509) (Five for CL82609/CL82659) (Seven for CL82859)

Quick start guide

CL82109/CL82209/CL82309/ CL82359/CL82409/CL82509/ CL82609/CL82659/CL82859 DECT 6.0 corded/cordless telephone/answering system with caller ID/call waiting

Cordless handset (One for CL82109) (Two for CL82209) (Three for CL82309/CL82359) (Four for CL82409) (Five for CL82509) (Six for CL82609/CL82659) (Eight for CL8359)

Battery for cordless handset (One for CL82109) (Two for CL82209) (Three for CL82309/CL82359) (Four for CL82409) (Five for CL82509) (Six for CL82609/CL82659) (Eight for CL82859)

Telephone base

Battery compartment cover (One for CL82109) (Two for CL82209) (Three for CL82309/CL82359) (Four for CL82409) (Five for CL82509) (Six for CL82609/CL82659) (Eight for CL82859)

Wall-mount bracket

Telephone line cord

Power adapter for telephone base

User’s manual

CL82109/CL82209/CL82309/ CL82359/CL82409/CL82509/ CL82609/CL82659/CL82859 DECT 6.0 cordless telephone/ answering system with caller ID/call waiting

Table of contents

Getting started

Quick reference guide - handset....... 1

Quick reference guide - telephone

base .................................................................. 3

Installation .................................................... 4

Telephone base & charger

installation..................................................... 5

Battery installation and charging...... 6

Installation options................................... 8

Auto off................................................. 20

Handset operation ..................................21

Speakerphone.................................... 21

Last number redial .......................... 21

Options while on calls ..........................22

Volume control.................................. 22

Call waiting ......................................... 22

Mute........................................................ 22

Chain dialing....................................... 23

Handset settings

Telephone settings................................. 10

Ringer volume.................................... 10

Ringer tone.......................................... 10

Key tone................................................ 11

LCD Language.................................... 11

Set date/time..................................... 12

Voicemail (visual message

waiting) indicator.............................. 13

Clear voicemail indication............ 13

Home area code ............................... 14

Answering system settings................ 15

Answer on/off.................................... 15

Announcement .................................. 16

Number of rings................................ 17

Remote access code....................... 18

Message alert tone.......................... 19

Telephone operation

Making, answering, and ending

calls ............................................................... 20

Making a call ...................................... 20

On-hook dialing (predialing)....... 20

Answering a call ............................... 20

Temporary ringer silencing.......... 20

Ending a call ....................................... 20

Multiple handset use

Multiple handset use .............................24

Handset locator ................................ 24

Join a call in progress ................... 24

Intercom.......................................................25

Call transfer using intercom ..............27

Directory

About the directory................................28

Shared directory ............................... 28

Capacity ................................................ 28

Exiting the directory ....................... 28

Create directory entries .......................29

To create a new directory

entry........................................................ 29

Review directory ......................................31

To review directory entries ......... 31

Search directory.......................................31

To search by name.......................... 31

To dial, delete or edit entries............32

Display dial.......................................... 32

To delete an entry........................... 32

To edit an entry ................................ 32

Caller ID

About caller ID......................................... 33

Information about caller ID with

call waiting .......................................... 33

Caller ID history....................................... 34

How the caller ID history

(call log) works.................................. 34

Caller ID operation................................. 35

Memory match................................... 35

Missed (new) calls indicator........ 35

To review the caller ID history.. 36 Make a call log entry ready to

dial........................................................... 36

Dial a call log entry......................... 37

Delete entries..................................... 37

Save a call log entry to the

directory................................................ 37

Reasons for missing caller ID

information................................................. 38

Answering system

About the answering system............ 39

Answering system and

voicemail............................................... 39

Message capacity ............................. 39

Turn the answering system on

or off at the telephone base...... 39

New message indication............... 40

Call screening at the telephone

base......................................................... 40

Call intercept...................................... 40

Base ringer .......................................... 40

Voice prompts..................................... 40

Temporarily turning off the

message alert tone ......................... 40

Message playback .................................. 41

Options during playback............... 42

To delete all old messages ......... 42

Recording & playing memos ............. 43

To play back a memo..................... 43

Base message counter displays...... 44

Remote access......................................... 45

Appendix A

Alert tones and lights........................... 47

Screen icons........................................ 47

Handset alert tones ........................ 47

Telephone base tone........................47

Lights...................................................... 47

Appendix B

Handset display screen

messages .....................................................48

Appendix C

Expansion handset..................................50

To register a handset to your

telephone base.................................. 51

To deregister all handsets........... 52

Appendix D

Troubleshooting .......................................53

Appendix E

Maintenance...............................................61

Appendix F

Important safety information.............62

Safety information ........................... 62

Especially about cordless

telephones........................................... 62

Precautions for users of implanted

cardiac pacemakers ........................ 63

Pacemaker patients ........................ 63

Especially about telephone

answering systems .......................... 63

Appendix G

FCC part 68 and ACTA..........................64

Appendix H

FCC part 15 ................................................65

Appendix I

Limited warranty......................................66

Appendix J

Technical specifications........................68

DECT 6.0 digital technology ....... 68

Telephone operating range......... 68

Redefining long range coverage

and clarity............................................ 68

Index ..............................................................69

Getting started

Quick reference guide - handset

CHARGE indicator

On when the handset is charging in the telephone base or charger.

TCID/-VOLUME

Press TCID to show caller ID history (page 36).

Press to scroll down while in menus.

While entering names or numbers, press to move the cursor to the left.

Press to decrease the listening volume when on a call.

PHONE/FLASH

Press to make or answer a call.

During a call, press to answer

an incoming call when you receive a call waiting alert

(page 22).

While reviewing a call log entry, press repeatedly to add or remove 1 in front of the telephone number before dialing or saving it in the directory.

MUTE/DELETE

During a call, press to mute the microphone (page 22).

While reviewing the caller ID history, the directory or the redial memory, press to delete an individual entry (page 37, page 32 and page 21 respectively).

While predialing, press to delete digits (page 20).

SPEAKER

Press to switch between speakerphone and handset.

MENU/SELECT

Press to show the menu. While in the menu, press to select an item or save an entry or setting.

DIRS/+VOLUME

Press DIRS to show directory entries (page 31).

Press to scroll up while in menus.

While entering names or numbers, press to move the cursor to the right.

Press to increase the listening volume when on a call.

OFF/CLEAR

During a call, press to hang up.

While in a menu, press to cancel an operation, back up to the previous menu, or exit the menu display.

Press and hold telephone is not in use to erase the missed calls indicator.

while the

Press repeatedly to display other dialing options when reviewing a call log entry.

REDIAL/PAUSE

Press repeatedly to view the last five numbers dialed (page 21).

While entering numbers, press and hold dialing pause (page 29).

Press to begin an intercom conversation (page 25) or to transfer a call (page 27).

to insert a

INT

Getting started

Quick reference guide - handset

Main menu

> Highlights a menu item

?!BOT/TZTUFN

EJSFDUPSZ

Main menu

ANS. SYSTEM (page 39) DIRECTORY (page 28) CALL LOG (page 33) RINGER VOLUME (page 10) RINGER TONE (page 10) KEY TONE (page 11) LCD LANGUAGE (page 11) SET DATE/TIME (page 12) CLR VOICEMAIL (page 13) HOME AREA CODE (page 14)

Using menus

Press MENU/

SELECT to show the first

menu item, ANS. SYSTEM.

Press TCID or DIRS to scroll through menu items.

Press

MENU/SELECT to select or save

changes to a highlighted menu item.

Press

OFF/CLEAR to cancel an

operation, back up to the previous menu, or exit the menu display.

Getting started

Quick reference guide - telephone base

VOICEMAIL indicator

Flashes when you have new voicemail. Voicemail service is offered by your local telephone company, and is different from answering system messages (page 13).

IN USE indicator

On when the handset is in use, when the answering system is answering an incoming call, or when you are registering a handset.

Flashes when another telephone is in use on the same line, or when you are deregistering handset(s) from the telephone base.

Flashes quickly when there is an incoming call.

HANDSET LOCATOR

Press to make handsets beep so you can locate them (page 24).

MESSAGE COUNTER

Number of messages (or during playback, message number currently playing).

XDELETE

Press to delete the message currently playing (page 42).

Press twice to delete all old messages when the phone is not in use (page 42).

ANSWER ON/OFF

Press to turn the answering system on or off (page 39).

VOLUME ST

During message playback, press to adjust the listening volume (page 42).

While in idle mode, press to adjust the base ringer volume (page 40).

PLAY/STOP

Press to start or stop message playback (page 41).

REPEAT

Press to repeat a message.

Press twice to play the previous message (page 42).

SKIP

Press to skip a message (page 42).

Getting started

Installation

You must install and charge the handset battery before using the cordless handset.

Install the telephone base close to a telephone jack and a power outlet not controlled by a wall switch. The telephone base can be placed on a flat surface or vertically mounted on the wall (see page 8). For optimum range and better reception, place the telephone base in a central and open location.

If you subscribe to high-speed Internet service (digital subscriber line - DSL) through your telephone line, you must install a DSL filter between the telephone line cord and the telephone wall jack (see the following page). The filter prevents noise and caller ID problems caused by DSL interference. Please contact your DSL service provider for more information about DSL filters.

Your product may be shipped with a protective sticker covering the handset or telephone base display - remove it before use.

For customer service or product information, visit our website at

STOP!

See pages 6-7 for easy instructions.

www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

Avoid placing the telephone base too close to:

• Communication devices such as: television sets, VCRs, or other cordless

telephones.

• Excessive heat sources.

• Noise sources such as a window with traffic outside, motors, microwave

ovens, refrigerators, or fluorescent lighting.

• Excessive dust sources such as a workshop or garage.

• Excessive moisture.

• Extremely low temperature.

• Mechanical vibration or shock such as on top of the washing machine or

workbench.

Getting started

Telephone base & charger installation

Install the telephone as shown below.

The telephone base is ready for tabletop use. If you want to change to wall mounting, see page 8 for details.

1. Plug one end of the telephone line cord into the telephone jack on the bottom of the telephone base.

7. Raise the antenna.

6. Plug the other end of the telephone line cord into a telephone jack or a DSL filter.

2. Route the power adapter cord through the slot.

Telephone line cord

If you have DSL high speed Internet service, a DSL filter (not included) is required.

3. Plug the small end of the telephone base power adapter into the power jack on the bottom of the telephone base.

4. Place the cords into the channels.

Power adapter

5. Plug the large end of the power adapter into a power outlet not controlled by a wall switch.

Charger installation

Plug the power adapter into an electrical outlet not controlled by a wall switch.

IMPORTANT INFORMATION

1. Use only the power adapter(s) supplied with this product. To order a replacement power

adapter, visit our website at

www.telephones.att.com, or call

1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

2. The power adapters are intended to be correctly oriented in a vertical or floor mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling, underthe-table or cabinet outlet.

Getting started

Battery installation and charging

Install the battery as shown on the next page. Once you have installed the battery, the screen indicates the battery status (see table below). If necessary, place the handset in the telephone base or charger to charge the battery. For best performance, keep the handset in the charger when not in use. The battery is fully charged after 16 hours of continuous charging. See the table on page 68 for battery operating times.

If the screen is blank, you need to charge the handset without interruption for at least 10 minutes to give the handset enough charge to use the telephone for a short time. The screen shows LOW BATTERY and the backlight is off until you have charged the battery without interruption for at least one hour. The following table summarizes the battery charge indicators and actions to take.

Battery indicators Battery status Action

The screen is blank. Battery has no charge and the

handset cannot be used.

The screen shows PLACE IN CHARGER and flashes.

The screen shows LOW BATTERY and flashes.

The screen shows HANDSET X.

Battery has very little charge and the handset cannot be used.

Battery has enough charge to be used for a short time.

Battery is charged. To keep the battery charged,

Charge without interruption until the screen shows LOW BATTERY

(at least 10 minutes).

Charge without interruption until the screen shows LOW BATTERY

(at least four minutes).

Charge until the screen shows

HANDSET X (about one hour).

place it in the telephone base or charger when not in use.

NOTE: If you are on a phone call in low battery mode, you hear four short beeps every minute.

Getting started

Battery installation and charging

Step 1

Plug the battery connector securely into the socket inside the handset battery compartment, matching the color-coded label. Insert the supplied battery with the

Align the cover flat against the battery compartment, then slide it upwards until it clicks into place.

Step 2

label THIS SIDE UP facing up as indicated.

CHARGE light

Step 3

Charge the handset by placing it face forward in the telephone base or charger. The CHARGE light on the top of the handset is on during charging.

IMPORTANT INFORMATION

1. Use only the supplied rechargeable battery or replacement battery (model BT8001). To order, visit our website at

www.telephones.att.com or call

1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

2. If you do not use the handset for a long time, disconnect and remove the battery to prevent possible leakage.

Getting started

Installation options

Your telephone base is ready for tabletop use. If you want to mount your telephone on a wall, use the provided wall mount bracket to connect with a standard dual-stud telephone wall mounting plate. If you do not have this mounting plate, you can purchase one from many hardware or consumer electronic retailers. You might need a professional to install the mounting plate.

Tabletop to wall mount installation

1. Position the telephone base as shown below. Insert the extended tabs (marked A) of the wall mount bracket into the slots on the back of the telephone base (marked A). Push the telephone base down until it is securely in place.

2. If you are using a DSL filter, plug the line cord into the filter now. Route the telephone line cord (or DSL filter) through the wall mount bracket hole. Route the power cord out of the bottom of the telephone.

3. Plug the telephone line cord (or DSL filter) into the wall jack. Plug the power adapter into a power outlet not controlled by a wall switch.

4. Align the holes on the wall mount bracket with the standard wall plate and slide the wall mount bracket down until it locks securely. Bundle the telephone line cord and power adapter cord neatly with a twist tie.

Getting started

Installation options

Wall mount to tabletop installation

1. If the telephone line cord and power adapter cord are bundled, untie them first.

2. Push the telephone base up to detach it from the wall mount bracket. Unplug the telephone line cord (or DSL filter) from the wall. Unplug the power adapter from the power outlet.

3. See Telephone base & charger installation on page 5.

Handset settings

Telephone settings

Use the menus to change the telephone’s settings.

1. Press MENU/

SELECT when in idle mode (when the phone is not in use) to

enter the main menu.

2. Press TCID or DIRS to scroll to the feature to be changed. When scrolling through the menu, the top

?BOT/!TZTUFN

EJSFDUPSZ

menu item is always highlighted with a > symbol.

3. Press

MENU/SELECT to select the highlighted item.

NOTE: Press OFF/CLEAR to cancel an operation, back up to the previous menu or exit the menu display. Press and hold

OFF/CLEAR to return to idle mode.

Ringer volume

You can set the ringer volume level (1-6), or turn the ringer off. When the ringer is off, appears on the handset screen.

1. Press MENU/

SELECT in idle mode to enter the main

?SJOHFS!WPMVNF

SJOHFS!UPOF

menu.

2. Use TCID or DIRS to scroll to >RINGER VOLUME, then press

MENU/SELECT.

3. Press TCID or DIRS to sample each volume level.

4. Press

MENU/SELECT to save your preference and return

SJOHFS!WPMVNF

to the main menu.

NOTE: The ringer volume also determines the ringer volume of the intercom calls (page

25) and the paging tone for the handset locator (page 24). If the handset ringer volume is set to off, that handset is silenced for all incoming calls and paging.

Ringer tone

You can choose one of 10 ringer tones.

1. Press MENU/

SELECT in idle mode to enter the main

?SJOHFS!UPOF

menu.

2. Use TCID or DIRS to scroll to >RINGER TONE, then press

MENU/SELECT.

3. Press TCID or DIRS to sample each ringer tone.

4. Press

MENU/SELECT to save your preference and return

SJOHFS!UPOF 2

to the main menu.

NOTE: If you turn off the ringer volume, you do not hear ringer tone samples.

LFZ!UPOF

Handset settings

Telephone settings

Key tone

The handset is factory programmed to beep with each key press. If you turn off the KEY TONE, there are no beeps when you press keys.

1. Press MENU/

SELECT in idle mode to enter the main

menu.

2. Use TCID or DIRS to scroll to >KEY TONE, then press

MENU/SELECT.

3. Press TCID or DIRS to select ON or OFF.

4. Press

MENU/SELECT to save your preference and return

to the main menu.

LCD Language

You can select the language used for all screen displays.

?LFZ!UPOF

MDE!MBOHVBHF

LFZ!UPOF

1. Press MENU/

SELECT in idle mode to enter the main

menu.

2. Use TCID or DIRS to scroll to >LCD LANGUAGE, then press

MENU/SELECT.

3. Press TCID or DIRS to select ENGLISH, FRANCAIS or ESPANOL.

4. Press

MENU/SELECT to save your preference and return

to the main menu.

?MDE!MBOHVBHF

TFU!EBUF0UJNF

MDE!MBOHVBHF FOHMJTI

Handset settings

Telephone settings

The answering system announces the day and time of the message prior to playing it. Before using the answering system, set the date and time as follows. If you subscribe to caller ID service, the day, month and time are set automatically with each incoming call. The year must be set so that the day of the week can be calculated from the caller ID information.

Set date/time

Follow the steps below to set the month, day, year and time.

1. When the handset is in idle mode, press MENU/

SELECT to enter the main

menu.

2. Press TCID or DIRS to scroll to >SET DATE/TIME, then press

MENU/SELECT.

3. Press TCID or DIRS to select the month, or enter the correct number using the dial pad, then press

MENU/SELECT to confirm.

4. Press TCID or DIRS to select the day, or enter the correct number using the dial pad, then press

MENU/SELECT to confirm.

5. Press TCID or DIRS to select the year, or enter the correct number using the dial pad, then press

MENU/SELECT to confirm.

6. Press TCID or DIRS to select the hour, or enter the correct number using the dial pad, then press

MENU/SELECT to confirm.

7. Press TCID or DIRS to select the minute, or enter the correct number using the dial pad, then press

MENU/SELECT to confirm.

8. Press TCID or DIRS to select the AM or PM, then press

MENU/SELECT to confirm. There is a confirmation tone.

?BOT/!TZTUFN

EJSFDUPSZ

?TFU!EBUF0UJNF

DMS!WPJDFNBJM

TFU!EBUF

..0..0..

TFU!UJNF

..;..!..

NOTE: If the clock is not set when a message is recorded, the system announces, "Time and day not set." before it plays the message.

Handset settings

Telephone settings

Voicemail (visual message waiting) indicator

If you subscribe to a voicemail service offered by your local telephone company, this feature provides a visual indication when you have new voicemail messages. The

VOICEMAIL light on the telephone base flashes, and NEW VOICEMAIL and the icon appear on the handset screen.

NOTES:

1. This feature does not indicate new answering system messages recorded on your phone.

2. For more information about the difference between your answering system and voicemail, see page 39.

Clear voicemail indication

Use this feature when the telephone indicates there is new voicemail but there is none. For example, when you have accessed your voicemail while away from home. This feature only turns off the displayed NEW VOICEMAIL message, icon, and VOICEMAIL light; it does not delete your voicemail messages. As long as you have new voicemail messages, your local telephone company continues to send the signal to turn on the indicator.

IBOETFU!2

OFX!WPJDFNBJM

21;32

3022

To manually turn off the new voicemail indicator:

1. Press MENU/

SELECT when in idle mode to enter the main

menu.

2. Use TCID or DIRS to scroll to >CLR VOICEMAIL, then

press

MENU/SELECT, the screen shows TURN OFF

INDICATOR?

3. Press

MENU/SELECT again to turn the voicemail

indication off, or press

OFF/CLEAR to cancel the

procedure.

NOTES:

1. Telephone company voicemail might alert you to new messages with a stutter (broken) dial tone. Contact your telephone company for more details.

2. For information about using your voicemail service, contact your telephone company for assistance.

?DMS!WPJDFNBJM

IPNF!BSFB!DPEF

UVSO!PGG

JOEJDBUPS@

Handset settings

Telephone settings

Home area code

If you dial seven digits to make a local call (no area code required), enter your area code into the telephone as the home area code. When you receive a call from within your home area code, the caller ID history only displays the seven digits of the telephone number.

This feature makes it easy for you to place a call from the caller ID log. If you dial 10 digits to make a local phone call, do not use this home area code feature. If you do, you cannot place calls from you caller ID log as they have only seven digits.

1. Press

MENU/SELECT in the idle mode to enter the main

menu.

?IPNF!BSFB!DPEF

2. Use TCID or DIRS to scroll to >HOME AREA CODE,

then press

MENU/SELECT.

3. Use the dial pad keys to enter a three-digit home area code. Press

MUTE/DELETE to delete digits while

IPNF!BSFB!DPEF

entering.

4. Press

MENU/SELECT to save and return to the main

menu.

NOTE: If, in the future, your telephone service provider requires you to dial 10 digits to make a local call (area code + phone number). With the home area code displayed, press and hold of _ _ _.

MUTE/DELETE. The home area code is now restored to its default setting

BOT/!TZTUFN

```

Handset settings

Answering system settings

Use the answering system menu to turn on or off the answering system, setup the announcement message, or change the number of rings, remote access code or message alert tone.

1. When the handset is in idle mode, press MENU/

SELECT to enter the main

menu.

2. Press

MENU/SELECT again.

3. Press TCID or DIRS to scroll to >ANS SYS SETUP, then press

MENU/SELECT.

Answer on/off

Unless you change it, the answering system is on and ready to record messages. You can turn the answering system off, but if you do so, the answering system does not answer calls and record incoming messages.

To turn the answering system on or off from a handset:

1. When the handset is in idle mode, press MENU/

SELECT

?BOT!TZT!TFUVQ

QMBZ!NTHT

to enter the feature menu.

2. Press

3. Press TCID or DIRS to scroll to >ANS SYS SETUP,

4. Press

MENU/SELECT again.

then press

MENU/SELECT.

MENU/SELECT again to select >ANSWER ON/OFF.

?BOTXFS!PO0PGG

BOOPVODFNFOU

5. Press TCID or DIRS to select between ON and OFF, then press hear a confirmation tone.

MENU/SELECT to confirm the setting and you

BOTXFS!PO0PGG PO

If the answering system is on, the handset screen shows the ANS ON icon.

NOTE: If the answering system is off and there is an incoming call, the system answers after 10 rings and announces to the caller, “Please enter your remote access code.” For more information about remote access codes, see page 45.

Handset settings

Answering system settings

Announcement

Outgoing announcements play when calls are answered by the answering system.

The telephone has a prerecorded outgoing announcement, “Hello. Please leave a message after the tone.” You can use this announcement, or record your own announcement.

You can record an announcement up to 90 seconds. The system does not record any announcement shorter than one second.

To play your current outgoing announcement:

1. When the handset is in idle mode, press MENU/

SELECT

to enter the main menu.

2. Press

MENU/SELECT again.

3. Press TCID or DIRS to scroll to >ANS SYS SETUP, then press

MENU/SELECT.

4. Press TCID or DIRS to scroll to >ANNOUNCEMENT, then press

MENU/SELECT, the system announces, "To

play, press 2. To record, press 7."

5. Press 2 to play the current announcement.

To record a new outgoing announcement:

1. When the handset is in idle mode, press MENU/

SELECT

to enter the main menu.

2. Press

MENU/SELECT again.

3. Press TCID or DIRS to scroll to >ANS SYS SETUP, then press

MENU/SELECT.

4. Press TCID or DIRS to scroll to >ANNOUNCEMENT, then press

MENU/SELECT, the system announces, "To

play, press 2. To record, press 7."

5. Press 7 to record an announcement, the system announces, "Record after the tone, press 5 when you are done."

?BOT/!TZTUFN

EJSFDUPSZ

?BOT!TZT!TFUVQ

QMBZ!NTHT

?BOOPVODFNFOU

$!PG!SJOHT

3.QMBZ!4.EFMFUF

6.TUPQ!8.SFDPSE

SFDPSE!BOOD///

6.TUPQ

6. Press 5 when you finish the recording. Your recorded announcement plays.

To listen to the recorded announcement again, press 2 after playback is completed.

To record a new announcement, press 7 and follow the above steps.

Handset settings

Answering system settings

To delete your outgoing announcement:

1. When the handset is in idle mode, press MENU/

SELECT to enter the main

menu.

2. Press

MENU/SELECT again.

3. Press TCID or DIRS to scroll to >ANS SYS SETUP, then press

MENU/SELECT.

4. Press TCID or DIRS to scroll to >ANNOUNCEMENT, then press

MENU/SELECT, the system announces, "To play, press 2. To record,

press 7."

5. Press 3 to delete your recorded announcement.

When your announcement is deleted, the system answers calls with the prerecorded announcement described on the previous page.

Number of rings

You can set the answering system to answer an incoming call after two, four, or six rings. You can also select toll saver, which is explained below. Unless you change it, the answering system answers an incoming call after four rings.

To set the number of rings:

1. When the handset is in idle mode, press MENU/

SELECT

?BOT/!TZTUFN

EJSFDUPSZ

to enter the main menu.

2. Press

3. Press TCID or DIRS to scroll to >ANS SYS SETUP,

MENU/SELECT again.

then press

MENU/SELECT.

?BOT!TZT!TFUVQ

QMBZ!NTHT

4. Press TCID or DIRS to scroll to ># OF RINGS, then press

MENU/SELECT.

5. Press TCID or DIRS to scroll and choose among 2, 4, 6 or TOLL SAVER.

• Toll saver - the answering system answers a call

?$!PG!SJOHT

SFNPUF!DPEF

after two rings if you have new messages, and after four rings when there are no new messages. This feature allows you to check for new messages and avoid paying long distance charges when

$!PG!SJOHT 3

calling from out of your local area.

6. Press

MENU/SELECT to confirm your setting and you

hear a confirmation tone.

NOTE: If you subscribe to caller ID/call waiting service through your telephone service provider, see Answering system and voicemail on page 39.

Handset settings

Answering system settings

Remote access code

To access your answering system remotely from any touch tone phone, you need to enter a two-digit number (10-99). Unless you change it, the remote access code is 19.

To change the remote access code:

1. When the handset is in idle mode, press MENU/ to enter the main menu.

SELECT

?BOT/!TZTUFN

EJSFDUPSZ

2. Press

MENU/SELECT again.

3. Press TCID or DIRS to scroll to >ANS SYS SETUP, then press

MENU/SELECT.

4. Press TCID or DIRS to scroll to >REMOTE CODE, then press

MENU/SELECT.

5. Press TCID or DIRS to change the remote access code.

6. Press

MENU/SELECT to confirm your setting and you

hear a confirmation tone.

?BOT!TZT!TFUVQ

QMBZ!NTHT

?SFNPUF!DPEF

NTH!BMFSU!UPOF

SFNPUF!DPEF 2:

Handset settings

Answering system settings

Message alert tone

When the message alert tone is set to ON, and there is at least one new message, the telephone base beeps every 10 seconds. Unless you change it, the message alert tone is set to off.

There is no audible alert at the handset.

To change the setting:

1. When the handset is in idle mode, press MENU/

SELECT

to enter the main menu.

2. Press

MENU/SELECT again.

3. Press TCID or DIRS to scroll to >ANS SYS SETUP, then press

MENU/SELECT.

4. Press TCID or DIRS to scroll to >MSG ALERT TONE, then press

MENU/SELECT.

5. Press TCID or DIRS to choose between ON and OFF.

6. Press

MENU/SELECT to confirm your setting and you

hear a confirmation tone.

NOTES:

1. The message alert tone beeps only if all the conditions below are met:

- Answering system is on.

- Message alert tone setting is on.

- There are new messages.

2. To temporarily turn off the message alert tone, see page 40.

?BOT/!TZTUFN

EJSFDUPSZ

?BOT!TZT!TFUVQ

QMBZ!NTHT

?NTH!BMFSU!UPOF

BOTXFS!PO0PGG

NTH!BMFSU!UPOF PO

Telephone operation

Making, answering, and ending calls

Making a call

To make a call:

• Press PHONE

telephone number.

The screen displays the elapsed time as you talk (in hours, minutes and seconds).

NOTE: Pressing PHONE/FLASH to access services from your local telephone service provider does not affect the elapsed time.

On-hook dialing (predialing)

1. Enter the telephone number. Press make corrections when entering the phone number.

/FLASH or SPEAKER, then enter the

MUTE/DELETE or OFF/CLEAR to

QIPOF!!!1;11;41

Elapsed time

2. Press PHONE

/FLASH or SPEAKER to dial.

Answering a call

To answer a call:

• Press PHONE

/FLASH or SPEAKER.

-OR-

• Press any dial pad key (0-9, * or #).

Temporary ringer silencing

Press OFF/

CLEAR or MUTE/DELETE while the telephone is ringing to

silence the ringer temporarily on that handset only. This turns off the ringer without disconnecting the call. The next incoming call rings normally at the preset volume.

NOTE: Each handset rings when there is an incoming call unless the ringer volume is turned off on that handset.

Ending a call

Press OFF/

CLEAR or return the handset to the telephone base or charger.

Auto off

A call ends automatically when you put the handset in the telephone base or charger.

Telephone operation

Handset operation

Speakerphone

During a call, press SPEAKER to switch between hands-free speakerphone and normal handset use. Press OFF/

CLEAR to hang up.

NOTES:

1. If you use the speakerphone during LOW BATTERY mode, the handset is not lit except for the SPEAKER button.

2. The speakerphone uses more power than the normal handset. If the handset battery becomes very low while you are using the speakerphone, the call remains in speakerphone mode until you hang up or the battery becomes depleted. When the battery is very low, you cannot switch a call from normal handset use to speakerphone mode.

3. After installing the battery into the handset, the screen may show LOW BATTERY. If you use speakerphone at this time, the battery may become depleted. Follow the instructions in the Battery installation & charging section on pages 6-7.

Elapsed time

TQFBLFS!!!1;11;41!!

Last number redial

To view the five most recently dialed numbers:

• To display the most recently called number (up to 30

digits), press REDIAL/

PAUSE.

SFEJBM

999.994.3556

• To view up to five recently called numbers, press

REDIAL/ REDIAL/

PAUSE then TCID or DIRS, or press

PAUSE repeatedly.

The handset beeps twice at the beginning and at the end of the list.

Press OFF

/CLEAR to exit.

To redial a number:

• To dial the displayed number, press PHONE/FLASH or SPEAKER.

-OR-

• You can call the most recently called number by pressing

PHONE/FLASH or SPEAKER, then pressing REDIAL/

While reviewing the redial memory, press

MUTE/DELETE to delete the

PAUSE.

displayed number.

Telephone operation

Options while on calls

Volume control

While on a call, press VOLUME-/TCID to decrease or press VOLUME+/ DIRS to increase the listening volume.

NOTES:

1. Handset and speakerphone volume settings are independent.

2. When the volume reaches the minimum or maximum setting,

you hear two beeps.

Call waiting

If you subscribe to call waiting service with your local telephone service provider, you hear a beep if someone calls while you are already on a call.

VOLUME/TCID or VOLUME/DIRS

Press call. Press

PHONE/FLASH to put your current call on hold and take the new

PHONE/FLASH at any time to switch back and forth between

calls.

Mute

Use the mute function to turn off the microphone. You can hear the caller, but the caller does not hear you.

To mute a call:

• Press MUTE/

DELETE. When mute is on, the handset screen

shows MUTED for a few seconds and the MUTE icon appears until you turn off mute.

To un-mute a call:

• Press MUTE/

DELETE again. When mute is off,

MICROPHONE ON appears temporarily on the handset

screen.

DELETE/MUTE

QIPOF!!!1;11;41

NVUFE

MUTE

Telephone operation

Options while on calls

Chain dialing

Use this feature to initiate a dialing sequence from the numbers in the directory, caller ID history, or redial memory while you are on a call.

Chain dialing can be useful if you wish to access other numbers (such as bank account information or access codes) from the directory, caller ID history, or redial list.

To access the directory while on a call:

1. Press MENU/

SELECT.

2. Press

MENU/SELECT again enter >DIRECTORY.

3. Press TCID or DIRS to scroll to the desired number.

4. Press

MENU/SELECT to dial the number shown.

To access the caller ID history (call log) while on a call:

1. Press

2. Press TCID or DIRS to scroll to >CALL LOG, then press

MENU/SELECT.

3. Press TCID or DIRS to scroll to the desired number.

4. Press

MENU/SELECT to dial the number shown.

To access the last number redial while on a call: Press REDIAL/

you press REDIAL/

PAUSE to show and dial the most recently dialed number. If

PAUSE again within two seconds, the system does not dial

the number.

NOTES:

1. You cannot edit a directory entry while on a call. For more details about the

directory, see page 28.

2. You cannot copy a caller ID entry into the directory while on a call. For more details

about the caller ID history, see page 33.

3. If you press REDIAL/

and you cannot erase the entry. For more details about the redial memory, see page 21.

4. Press and hold

a call.

PAUSE while on a call, you can only view the most recent call,

OFF/CLEAR to exit redial, directory or caller ID history when on

Multiple handset use

Handset locator

The handset locator feature is useful if you misplace any handset.

To start the paging tone:

• Press HANDSET LOCATOR at the telephone base to

start the paging tone on all handsets for 60 seconds.

NOTE: If you press OFF/CLEAR or MUTE/DELETE on a handset, the ringer of the handset is off, but the page tone does not stop.

To stop the paging tone:

• Press PHONE

key (0-9, *, or #) on the handset(s).

–OR–

• Press HANDSET LOCATOR on the telephone base.

NOTE: The handset ringer volume also determines the volume of the paging tone. If the handset ringer volume level is set to off, that handset is silent for all calls and paging (page 10).

/FLASH, SPEAKER, or any dial pad

++QBHJOH++

Join a call in progress (not available on model CL82109)

You can conference with another system handset while on a call. If a handset is already on a call and you would like to join the call, press

PHONE

Press OFF/

/FLASH or SPEAKER on another system handset.

CLEAR or place the handset in the telephone base or charger

to end the call. The call does not terminate until all handsets hang up.

NOTE: You can only use two system handsets at the same time on an outside call.

Multiple handset use

Intercom

Use the intercom feature for conversations between handsets. This feature is not available for model CL82109 unless you have purchased additional handsets (CL80109).

You can buy additional expansion handsets (model AT&T CL80109) for this telephone base. You can register up to 12 handsets to the telephone base.

The first nine handsets that you register are named Handsets 1-9. Use the handset number to initiate intercom and transfer calls.

Although the names for handsets 10-12 appears in their displays as 10-12, when you intercom or transfer to one of them, you must use *0 for Handset 10, *1 for handset 11, and *2 for Handset 12.

1. Press INT on your handset when not in use.

• If you have a two-handset system, your handset

screen shows CALLING OTHER HANDSET.

• If you have more than two handsets, your screen

shows INTERCOM TO: Use the dialing keys to enter a handset number. Your handset screen shows CALLING HANDSET X.

The other handset rings and its screen shows either OTHER HANDSET IS CALLING or HANDSET X IS CALLING.

2. To answer the intercom call, press PHONE/FLASH,

JOUFSDPN

INT, SPEAKER or any dial pad keys (0-9, #, *) on the other handset. Both handsets now show INTERCOM.

3. To end an intercom call, press INT, OFF/

CLEAR, or

place the handset back in the telephone base or charger.

NOTES:

1. Be for e the inte rcom call is answer ed, you can cancel the intercom call by pressing

OFF/CLEAR or INT on the calling handset.

2. If the called handset is not answered within 100 seconds, or if it is in the directory

or call log mode, or is out of range, or is on a call, the calling handset shows the message UNABLE TO CALL TRY AGAIN.

3. Pressing OFF/

4. You can use a maximum of four handsets at a time. When you use two handsets on

an intercom call, others can use two other system handsets for an outside call.

CLEAR or MUTE/DELETE temporarily silences the intercom ringer.

DBMMJOH

PUIFS!IBOETFU

JT!DBMMJOH

Multiple handset use

Intercom

Answer an incoming call during an intercom call

If you receive an incoming outside call during an intercom call, there is an alert tone.

• To answer the call, press PHONE

/FLASH. The intercom call ends

automatically.

• To end the intercom call without canceling the incoming call, press

OFF/

CLEAR.

Multiple handset use

Call transfer using intercom

Use the intercom feature to transfer an outside call to another system handset. This feature is not available for model CL82109 unless you have purchased additional handsets (CL80109).

1. During a call, press INT.

• If you have a two-handset system, the outside call is put on hold and your handset screen shows CALLING OTHER HANDSET. The other handset rings and its screen shows OTHER HANDSET IS CALLING.

• If you have more than two handsets, your screen shows TRANSFER TO: Use the dialing keys to enter a handset number. The outside call is put on hold

and your handset screen shows CALLING

HANDSET X. The other handset rings and its screen shows HANDSET X IS CALLING.

2. To answer the call on the other handset, press

PHONE/

FLASH, INT, SPEAKER or any dial pad

keys (0-9, #, *). The outside call is still on hold and both handsets now show INTERCOM. You can now have a private conversation between the system handsets.

NOTES:

1. To cancel the transfer and return to the external call before the intercom call is answered, press and hold handset.

2. If the other handset does not answer the intercom call within 100 seconds, or if the other handset is in the directory or call log mode, or is out of range, the calling handset shows UNABLE TO CALL TRY AGAIN on its screen and automatically returns to the external call.

OFF/CLEAR, or press PHONE/FLASH or INT on your

USBOTGFS!UP;

DBMMJOH

IBOETFU!Y

JT!DBMMJOH

JOUFSDPN

3. From this intercom call, you have the following options:

• You can let the other handset join you on the outside call in a threeway conversation. Press and hold

• You can transfer the call. Press OFF/ place your handset back in the telephone base or

INT on the calling handset.

CLEAR, or

DBMM!USBOTGFSFE

charger. Your screen shows CALL TRANSFERED. The other handset automatically connects to the outside call.

• You can alternate between the outside call (OUTSIDE CALL appears on the screen) and the intercom call (INTERCOM appears on the screen). Press INT on your handset to alternate.

• The other person can end the intercom call by pressing

OFF/

CLEAR, or by placing the other handset back in the

telephone base or charger. The outside call continues with the original system handset.

Directory

About the directory

Shared directory

The directory is in the telephone base and is common for all handsets. Changes made to the directory from any handset apply to all.

NOTE: Only one handset can review the directory at a time. If another handset tries to enter the directory, the screen shows

NOT AVAILABLE AT THIS TIME.

Capacity

The directory can store up to 50 entries, with a maximum of 15 alphanumeric characters (including spaces) for names and 30 digits for telephone numbers. A convenient search feature can help you find and dial numbers quickly (page

31).

If there are already 50 entries, the screen shows LIST FULL. You cannot store a new number until you delete one.

Exiting the directory

Press OFF/CLEAR to cancel an operation, back up to the previous menu, or exit the menu display. Press and hold

OFF/CLEAR to return to the idle

mode.

SPCFSU!CSPXO

999.994.3556

If you pause for too long while creating or reviewing an entry, the procedure times out and you have to begin again.

Directory

Create directory entries

To create a new directory entry

1. Press MENU/

SELECT in idle mode to enter the main menu.

2. Press TCID or DIRS to scroll to >DIRECTORY, then

press

MENU/SELECT.

> EJSFDUPSZ

DBMM!MPH

3. Press TCID or DIRS to highlight STORE.

4. Press

5. Enter the telephone number when prompted.

MENU/SELECT.

• Use the dial pad to enter up to 30 digits.

> SFWJFX

TUPSF

– Press TCID or DIRS to move the cursor to the left or right.

– Press

– Press and hold

MUTE/DELETE to erase digits.

MUTE/DELETE to erase all digits.

REDIAL/PAUSE to enter a three-

> TUPSF

SFWJFX

second dialing pause.

-OR-

• Copy a number from the redial list by pressing

6. Press

REDIAL/ REDIAL/

copy. Press

MENU/SELECT to save the number in the display.

PAUSE then TCID or DIRS, or pressing PAUSE repeatedly to locate the number to

MENU/SELECT to copy the number.

FOUFS!OVNCFS

999.994.3556`

The display shows ALREADY SAVED if the number is already in the directory. You cannot save the same number twice.

Directory

Create directory entries

7. Enter the name when prompted.

• Use the dial pad to enter a name (up to 15 characters). Each time you press a key, a character

FOUFS!OBNF Spcfsu!Cspxo`

on that key appears. Additional key presses produce other characters on that key. See the chart below.

– Press TCID or DIRS to move the cursor to the left or right.

– Press – Press and hold

NOTE: The first letter of every word is a capital letter. The remaining letters in a word start as lower case letters as in the chart below.

Dial Key

12345678 9

1# ‘ , - .& ABC2 abc

DEF3 de f

GH I 4 g h i

JKL5 jk l

MNO 6 mn o

PQRS 7 pq r s

TUV8 t uv

WX Y Z 9wx y z

*?! / ()@

space

MUTE/DELETE to erase characters.

MUTE/DELETE to erase all characters.

Characters by number of key presses

8. Press

MENU/SELECT to store your new directory entry.

The name and the telephone number appear. To change them later, see page 32.

SPCFSU!CSPXO

999.994.3556

Directory

Review directory

To review directory entries

1. Press DIRS when in idle mode to show the first entry in the directory. DIRECTORY EMPTY appears if there are no directory entries.

-OR-

You can also show the first entry in the directory by pressing

MENU/ >DIRECTORY, then press

SELECT when in idle mode, then press TCID or DIRS to scroll to

MENU/SELECT twice.

2. Press TCID or DIRS to browse through the directory. Entries appear alphabetically by the first letter in the name.

NOTE: If the telephone number in the directory exceeds 15 digits, <* appears in front of the telephone number. Press * to move towards the end of the telephone number or press # to move towards the beginning of the telephone number.

Search directory

To search by name

1. Press DIRS in idle mode to show the first listing in the directory. DIRECTORY EMPTY appears if there are no directory entries.

2. When a name entry appears, press the dial pad keys (2-9) to start a name search.

The directory shows the first name beginning with the first letter

associated with the dial pad key if there is an entry in the directory beginning with that letter.

3. To see other names starting with the letters on the same dial pad key, keep pressing the key. The names appear in alphabetical order.

For example, if you have the names Jennifer, Jessie, Kevin and Linda in your directory:

• If you press 5 (JKL) once, you see Jennifer.

• If you press 5 (JKL) twice, you see Jessie.

• If you press 5 (JKL) three times, you see Kevin.

• If you press 5 (JKL) four times, you see Linda.

• If you press 5 (JKL) five times, you see Jennifer again.

NOTES:

1. If there is no name matching the first letter of the key you press, the directory shows a name matching the following letters of the key.

2. If you press a key (2-9) and no name starts with the letters on that key, the directory shows the entry matching the next letter in the directory.

Directory

To dial, delete or edit entries

To dial, delete or edit a directory entry (name and number), the entry must be on the handset. Use the directory review or search (page 31) to show an entry.

Display dial

To dial a displayed number from the directory, press PHONE SPEAKER.

To delete an entry

When a directory entry appears, press

MUTE/DELETE to delete the displayed

entry from the directory. You cannot retrieve a deleted entry.

To edit an entry

When a directory entry appears:

1. Press

MENU/SELECT to modify the entry. You need to EDIT NUMBER.

• Press the dial pad keys to add digits.

• Press TCID or DIRS to move the cursor to the

left or right.

• Press

• Press and hold

MUTE/DELETE to erase digits.

MUTE/DELETE to erase all digits.

REDIAL/PAUSE to add a three-

second pause, if desired.

• Copy a number from the redial list by pressing

REDIAL/ REDIAL/

copy. Press

PAUSE then TCID or DIRS, or pressing PAUSE repeatedly to locate the number to

MENU/SELECT to copy the selected

number.

2. Press

MENU/SELECT. You need to EDIT NAME.

• Press the dial pad keys to add characters (page

30).

/FLASH or

Boesfx

999.5:1.3116

FEJU!OVNCFS

999.994.3556

FEJU!OBNF Boez`

• Press TCID or DIRS to move the cursor to the

left or right.

• Press

• Press and hold

MUTE/DELETE to erase characters.

MUTE/DELETE to erase all

characters.

3. Press

MENU/SELECT to confirm.

Boez

999.994.3556

Caller ID

About caller ID

This product supports caller ID services that most local telephone service companies provide. Depending on your service subscription, you might see the caller’s number, or the caller’s name and number from the telephone company after the first or second ring. Caller ID allows you to see the name, number, date, and time of calls.

Information about caller ID with call waiting

Caller ID with call waiting lets you see the name and telephone number of the caller before answering the telephone, even while on another call.

It might be necessary to change your telephone service to use this feature. Contact your telephone company if:

• You have both caller ID and call waiting, but as separate services (you might need to combine these services).

• You have only caller ID service, or only call waiting service.

• You don't subscribe to caller ID or call waiting services.

There are fees for caller ID services. In addition, services may not be available in all areas.

DISJTUJOF!TNJUI

999.833.8813

NEW

21;12

:036

This product can provide information only if both you and the caller are in areas offering caller ID service and if both telephone companies use compatible equipment. The time and date are from the telephone company along with the call information.

Caller ID information might not be available for every incoming call. Callers may intentionally block their names and/or telephone numbers. To view call log entries with numbers between 16 and 23 digits, you must save the entry to the directory (see page 37).

NOTE: You can use this product with regular caller ID service, or you can use this product’s other features without subscribing to caller ID or combined caller ID with call waiting service.

Caller ID

Caller ID history

How the caller ID history (call log) works

The telephone stores caller ID information about the last 50 incoming calls in the telephone base. Entries are stored in reverse chronological order. The phone deletes the oldest entry when the log is full to make room for new calls. This information is common to all handsets, so changes made using any handset are reflected in all other handsets. If you answer a call before the information appears on the screen, it does not show in the caller ID history.

Review the caller ID history to find out who called, to easily return the call, or to copy the caller’s name and number into your directory.

XX MISSED CALL(S) appears if there are new call log entries (including missed and unreviewed calls). CALL LOG EMPTY appears if there are no records in the call log.

NOTES:

1. Only one handset can review the caller ID history at a time. If another handset tries to enter the directory or caller ID history, it shows NOT AVAILABLE AT THIS TIME.

2. Each entry can have up to 24 digits for the phone number and 15 characters for the name.

DISJTUJOF!TNJUI

999.833.8813

NEW

21;12

:036

Caller’s name

DISJTUJOF!TNJUI

999.833.8813

21;12

Time of call

NEW

:036

Date of call

Caller’s number

Appears when there are missed and unreviewed calls.

Caller ID

Caller ID operation

Memory match

If the incoming telephone number exactly matches a telephone number in your directory, the name that appears on the screen matches the corresponding name in your directory.

For example, if Christine Smith calls, her name appears as Chris if this is how you entered it into your directory.

NOTE: The number you see on your caller ID is in the format from the phone company. The phone company usually delivers ten-digit phone numbers (area code plus phone number). If the telephone number of the caller does not exactly match a number in your directory, the name appears the same from the phone company. For example, if the phone company includes the area code and the directory number does not, the name is the one which the phone company sends.

Disjt

999.833.8813

21;12

:036

NEW

Missed (new) calls indicator

When a handset is in idle mode and has unreviewed calls, its screen shows XX MISSED CALLS.

All unreviewed entries are counted as missed calls. Each time you review a call log entry with the icon NEW, the number of missed calls decreases by one.

IBOETFU!2

7!NJTTFE!DBMMT!

If you do not want to review the missed calls one by one, but you still want to keep them in the caller ID history, you can press and hold

OFF/CLEAR for four seconds when

the handset is idle. All the entries in the caller ID history become old (have been reviewed), and the missed calls counter shows 0.

21;12

Spcfsu!Cspxo

999.994.3556

1:;12

:036

NEW

Caller ID

Caller ID history

To review the caller ID history

1. When a handset is in idle mode, press TCID to review

the caller ID history in reverse chronological order starting with the most recent call.

-OR-

You can also review the caller ID history by pressing

MENU/SELECT, then press TCID or DIRS to scroll to

>CALL LOG, then press

2. Press TCID or DIRS to scroll through the list.

3. Press OFF/

CLEAR to exit the caller ID history.

You hear a double beep when the list reaches the beginning or end of the call log.

MENU/SELECT twice to REVIEW.

IBOETFU!2

7!NJTTFE!DBMMT!

:036

21;12

:036

TCID

Spcfsu!Cspxo

999.994.3556

:;12

Dibsmjf!Kpiotpo

911.333.4222

:036

9;12

:036

Make a call log entry ready to dial

Although the incoming call log entries have 10 digits (the area code plus the seven-digit number), in some areas, you might need to dial only the seven digits, 1 plus the seven digits, or 1 plus the area code plus the seven digits. You can change and store the number of digits that you dial in the call log.

While reviewing the call log, press # repeatedly to show different dialing options for local and long distance numbers before dialing or saving the telephone number in the directory.

Press 1 repeatedly if you need to add or remove 1 in front of the telephone number before dialing or saving

994.3556

2.994.3556

999.994.3556

2.999.994.3556

994.3556

2.994.3556

999.994.3556

2.999.994.3556

Press #

Press

it in the directory.

When the number shows in the correct format for dialing, press PHONE/

FLASH or SPEAKER to call the number.

Caller ID

Caller ID history

Dial a call log entry

1. When in the call log, press TCID or DIRS to browse.

2. Press PHONE/

Delete entries

• Press

MUTE/DELETE to delete the shown entry from the caller ID history.

• Follow the steps below to delete all caller ID history.

1. Press MENU/

2. Press TCID or DIRS to scroll to >CALL LOG, then press

3. Press TCID or DIRS to scroll to >DEL ALL CALLS, then press

MENU/SELECT.

4. When the screen shows DELETE ALL CALLS? press clear the caller ID history of all entries, or press OFF/CLEAR to exit and leave all entries in the caller ID history intact.

Save a call log entry to the directory

1. When in the call log, press TCID or DIRS to browse.

2. Press

MENU/SELECT to select an entry. The screen displays EDIT NUMBER.

3. Use the dialing keys to edit the number.

• Press TCID or DIRS to move the cursor to the left or right.

• Press

MUTE/DELETE to backspace and erase a digit.

• Press and hold

• Copy a number from the redial list by pressing REDIAL/ TCID or DIRS, or pressing REDIAL/ number. Press

4. Press

MENU/SELECT to move to the name. The screen displays EDIT NAME.

• Use the dial pad keys (page 30) to add characters.

• Press TCID or DIRS to move the cursor to the left or right.

• Press

MUTE/DELETE to erase characters.

• Press and hold

5. Press

MENU/SELECT when done and the handset shows SAVED.

• If the entry is already saved in the directory, the handset shows ALREADY SAVED.

• If there is no caller ID information, the handset shows UNABLE TO

SAVE.

FLASH or SPEAKER to dial the entry.

SELECT when in idle mode.

MENU/SELECT.

MENU/SELECT to

MUTE/DELETE to erase the entire entry.

REDIAL/PAUSE to insert a dialing pause (p appears).

PAUSE then

PAUSE repeatedly to select a

MENU/SELECT to copy the number.

MUTE/DELETE to erase all characters.

NOTES:

1. You might need to change how a caller ID number is dialed if the entry does not appear in the correct format. Caller ID numbers might appear with an area code that might not be necessary for local calls, or without a 1 that might be necessary for long distance calls (page 36).

2. If neither the name nor number is available, UNABLE TO SAVE appears.

Caller ID

Reasons for missing caller ID information

There are also occasions when other information or no information shows for various reasons:

On-screen

message

QSJWBUF! OVNCFS

QSJWBUF! OBNF

QSJWBUF! DBMMFS

VOLOPXO! OVNCFS

VOLOPXO! OBNF

VOLOPXO! DBMMFS

Reason

The caller prefers not to show the phone number.

The caller prefers not to show the name.

The caller prefers not to show the phone number and name.

Your local telephone company cannot determine the caller's number.

Your local telephone company cannot determine the caller's name.

Your local telephone company cannot determine the caller's name and telephone number. Calls from other countries may also generate this message.

Answering system

About the answering system

Answering system and voicemail

Your telephone has both a digital answering system and voicemail indication. Most telephone companies offer voicemail services (fees may apply). Your telephone’s answering system and voicemail indication are independent features. Each alerts you to new messages differently. For more information on the voicemail indicators, see page 13. To listen to your voicemail, you typically follow the instructions that your voicemail service provider provides. To listen to messages on your digital answering system, press PLAY button on the telephone base.

If you subscribe to caller ID/call waiting service through your telephone service provider, you can use your telephone answering system and voicemail together. Set your answering system to answer calls at least two rings earlier than your voicemail is set to answer. For example, set your voicemail to answer calls after six rings and set your answering system to answer after four rings.

NOTE: Some voicemail providers may program the delay before answering calls in seconds instead of rings; in this case, allow six seconds per ring when determining the appropriate setting. By doing this, if you are on a call, or if the answering system is busy recording a message and you receive another call, the second caller can leave a voicemail message.

/STOP

Message capacity

The answering system can record up to 99 messages, depending on the length of each message. Individual messages can be up to four minutes, and the maximum recording time is approximately 14 minutes. The actual recording time depends on individual message characteristics. Messages remain available for replay until you delete them.

When there are new messages (including memos) on the answering system, the number of messages stored flashes in the message counter.

If the number of messages and F are flashing alternatively in the message

counter, the memory is full. You must delete some messages before recording new ones.

Turn the answering system on or off at the telephone base

Press ANSWER ON/OFF to turn the answering system on or off. If the answering system is turned on, it announces, “Calls will be answered.” If the answering system is turned off, it announces, “Calls will not be

answered.”

Answering system

About the answering system

New message indication

The message window on the telephone base flashes and shows on the handset when there are new answering system messages.

If the new message alert tone is turned on, the telephone base beeps every 10 seconds when there are unreviewed messages.

IBOETFU!2

NOTE: If the answering system has less than five minutes of recording time left, it announces the remaining time.

21;32

Call screening at the telephone base

If the answering system is on and the telephone base volume is not off (set to 1 or higher), you hear the announcement and the incoming message when receiving a call. If you want the telephone base to be silent while recording messages, make sure you set the telephone base volume to 0.

Call intercept

While screening a call, you can stop recording and speak to the caller by pressing PHONE

/FLASH or SPEAKER on the handset.

22024

Base ringer

Press VOLUMEST on the telephone base to adjust the ringer volume when the telephone is not in use.

You hear a sample of the ringer while adjusting the volume. The telephone base announces, “Base ringer is off.” when you set the volume to 0.

Voice prompts

The system provides voice prompts to guide you through remote access and recording outgoing announcements.

Temporarily turning off the message alert tone

Pressing any telephone base key (except HANDSET LOCATOR) temporarily silences the message alert tone.

If you press XDELETE when in idle mode, there is a voice prompt to direct you to press XDELETE again to delete all old messages, and the message alert tone is temporarily off.

The message alert tone is re-activated with the next incoming message.

Answering system

Message playback

If you have new messages, you hear only the new messages (oldest first). If there are no new messages, the system plays back all the messages (oldest first).

When playback begins, the total number of messages is announced. Before each message, you hear the day and time of the recording. After the last message, you hear, “End of messages.” If the system has less than five minutes of recording time left, you hear the remaining time.

To listen to messages at the telephone base:

Press PLAY/ system announces the number of messages, then begins playback. Press PLAY/

To listen to messages on the handset:

1. When the handset is in idle mode, press MENU/

to enter the main menu.

STOP on the telephone base to listen to the messages. The

STOP again to end the message playback.

SELECT

?BOT/!TZTUFN

EJSFDUPSZ

2. Press

3. Press

MENU/SELECT again to select >ANS. SYSTEM.

MENU/SELECT to select >PLAY MSGS.

The system announces the number of messages, then begins playback. The message sequence is shown on the handset's screen. If there is no message in the answering system, the screen shows NO MESSAGES.

?QMBZ!NTHT

EFM!BMM!PME

6.TUPQ!4.EFMFUF

5.SFQFBU!7.TLJQ

MSG#

!203

Answering system

Message playback

Options during playback

When a message is playing, you can adjust the playback volume, skip, repeat, or delete the message.

When messages are playing on the telephone base:

• Press VOLUMEST button to adjust the message playback volume.

• Press SKIP to skip to the next message.

• Press REPEAT to repeat the message. Press twice to hear the previous

message.

• Press XDELETE to delete the message.

• Press

When messages are playing on the handset:

• Press TCID or DIRS to adjust the message playback volume.

• Press 6 to skip to the next message.

• Press 4 to repeat the message. Press twice to hear the previous message.

• Press 3 to delete the message.

• Press 5 to stop the playback.

• Press SPEAKER to switch between speakerphone mode and handset

mode.

PLAY/STOP to stop the playback.

To delete all old messages

You can only delete old (reviewed) messages. You cannot delete new messages until you review them. You cannot retrieve deleted messages.

To delete all old messages at the telephone base:

1. Press XDELETE on the telephone base. The system

announces, "To delete all old messages, press DELETE

again."

2. Press XDELETE again. The system announces, "All old

messages deleted."

To delete all old messages at the handset:

1. Press MENU/

SELECT when in idle mode to enter the

main menu.

2. Press

MENU/SELECT again.

3. Press TCID or DIRS to select >DEL ALL OLD, then

press

MENU/SELECT, the screen shows DELETE ALL

OLD MSGS?

4. Press

MENU/SELECT again to confirm. The screen

displays ALL OLD MSGS DELETED! and you hear a confirmation tone.

?BOT/!TZTUFN

EJSFDUPSZ

?EFM!BMM!PME

SFDPSE!NFNP

EFMFUF!BMM

PME!NTHT@

BMM!PME!NTHT

!EFMFUFE"

Answering system

Recording & playing memos

Memos are messages you record at a handset. You can save, play back or delete them like incoming messages. You can record a memo as a reminder to yourself, or leave a message for others who use the answering system.

To record a memo:

1. When the handset is in idle mode, press MENU/

menu.

SELECT to enter the main

2. Press

MENU/SELECT again.

3. Press TCID or DIRS to select >RECORD MEMO, press then

MENU/SELECT. The system announces, “Record after the tone. Press 5

when you are done.” You can record a memo for up to four minutes. The

system does not save memos shorter than two seconds.

4. Speak facing the handset to record the memo.

5. Press 5 to stop recording. The system announces, "Recorded."

To play back a memo

Play memos the same way as messages. See Message playback on page 41.

Answering system

Base message counter displays

The base message counter shows the total number of answering system messages. See the table below for other message counter displays.

Message counter displays

1 No messages.

(flashing)

2.::! Total number of old messages and memos, or message number currently

(flashing) Total number of messages and memos. The number flashes when there

2.::

2.::!

(alternating)

.. The system is answering a call, or someone is trying to reach it remotely.

1.7 Shows for two seconds while adjusting the telephone base speaker

You need to set the clock (page 12).

playing during old message playback.

are new (unreviewed) messages.

After a power failure, the number in the message counter flashes to indicate that you need to set the clock.

Memory is full. You must delete some messages before recording new messages.

The system is in program mode.

volume.

Answering system

Remote access

You can reach your answering system remotely by dialing your home telephone number from any touch-tone telephone.

To remotely reach your answering system:

1. Dial your telephone number from any touch-tone telephone.

2. When the system answers, enter the two digit remote access code (19 is

the default code, see page 18 to change it).

• The system automatically announces the number of messages (new and/or old) if there are any, and then begins to play them.

3. You can also enter the following remote commands.

Remote commands

Press to listen to all messages.

Press to listen to new messages only.

Press to delete the current message (during playback).

Press twice to delete all old messages.

Press to repeat the current message (during playback).

Press twice to listen to the previous message.

Press to stop any operation (including recording).

Press to listen to a list of remote commands.

Press to skip to the next message (during playback).

Press to record a new announcement.

Press to turn the answering system on or off.

Press to end remote access (the call will be terminated).

4. Hang up to end the call and save all undeleted messages.

Cut out and carry the remote access wallet card at the back of this user’s manual for quick reference.

Answering system

NOTES:

1. If you do not enter a valid remote access code, the system answers the call automatically.

2. If you pause for more than four seconds during remote access, you hear a help menu listing all features and commands. If there is no command for another 20 seconds, the call ends automatically.

3. If you want to delete all the old messages remotely, press 3 twice in remote standby mode.

4. If the memory is full, the answering system answers after 10 rings and announces, "Memory is full. Enter the remote access code." Enter your remote access code to reach the messages and announcements.

Appendix A

Alert tones and lights

Screen icons

Battery status - battery is charging (animated display).

Battery status - low battery (flashing); place handset in

telephone base or charger to recharge.

SPEAKERPHONE - the speakerphone is in use.

Ringer off - the handset ringer is off.

NEW VOICEMAIL - there are new voicemail from the local

21;32

ANS ON

MUTE

telephone company.

ANS ON Answering system is on.

Message - new message in the answering system.

NEW Missed and unreviewed calls.

MUTE Microphone is off.

MSG#

!203

Message counter - number of messages playing.

Handset alert tones

Two short beeps You are pressing the TCID or DIRS keys when the volume is already

at its highest or lowest setting.

Four short beeps Low battery warning.

Three beeps Out of range while the handset is on a call.

Three rising tones The system has completed the command successfully.

Telephone base tone

Beeps every 10 seconds Message alert.

Lights

ANSWER ON

On when the answering system is on and ready to receive calls.

VOICEMAIL

Flashes when you have new voicemail. Voicemail service is from your local telephone company, and is different from answering system messages.

IN USE

On when the handset is in use, when the answering system is answering an incoming call or when you are registering a handset.

Flashes when another telephone is in use on the same line, or when you are deregistering handset(s) from the telephone base.

Flashes quickly when there is an incoming call.

CHARGE

On when the handset is charging in the telephone base or charger.

Lighted display

Lighted dial pad

SPEAKER

On when the speakerphone is on.

MSG#

!203

NEW

Appendix B

Handset display screen messages

Screen display messages

BMSFBEZ!TBWFE The telephone number you have entered is already in the

directory.

DBMM!MPH!FNQUZ You are trying to reach an empty caller ID history.

DBMM!USBOTGFSFE You are transferring an outside call from one handset to another

handset.

DBMMJOH! IBOETFU!Y

(For systems with three or more handsets)

DBMMJOH! PUIFS!IBOETFU

(For system with two handsets)

DIBSHJOH A handset with a low battery is in the telephone base or charger.

DPOOFDUJOH/// The handset has lost communication with the telephone base.

EJSFDUPSZ!FNQUZ There are no directory entries.

FOEFE You have just ended a call.

IBOETFU!Y! JT!DBMMJOH!

(For systems with three or more handsets)

IBOETFU!Y! SFHJTUFSFE

JODPNJOH!DBMM There is a call coming in.

JOUFSDPN The handset is on an intercom call.

JOUFSDPN!FOEFE The intercom call has just ended.

The handset is calling the other handset (for intercom calls).

The handset is going to transfer an outside call to another handset.

Another system handset is calling.

The handset registration is successful, with X being the handset number.

JOUFSDPN!UP;

(For systems with three or more handsets)

MJOF!JO!VTF An extension phone or one of the handsets is in use.

MJTU!GVMM The directory is full. You cannot save any new entries unless you

MPX!CBUUFSZ You should charge the battery.

NJDSPQIPOF!PO Mute is off so the other party can hear your voice.

YY!NJTTFE!DBMMT There are new calls in the caller ID history.

You have started the intercom process, and need to enter the number of the handset you wish to call.

delete some current entries.

Appendix B

NVUFE The microphone is off.

OFX!WPJDFNBJM! There are new voicemail messages.

OP!MJOF There is no telephone line connection.

OP!TJHOBM-!DBMM! FOEFE

OPU!BWBJMBCMF BU!UIJT!UJNF

PUIFS!IBOETFU! JT!DBMMJOH!

(For system with two handsets)

PVUTJEF!DBMM You are on the external call during call transfer.

++!QBHJOH!++ The telephone base is paging handset(s).

QIPOF The handset is in use.

QMBDF!JO! DIBSHFS

SJOHFS!NVUF The ringer is off temporarily during an incoming call.

TBWFE The entry in caller ID history is now in the directory.

TQFBLFS The handset speakerphone is in use.

USBOTGFS!UP;

(For systems with three or more handsets)

VOBCMF!UP!DBMM! USZ!BHBJO

The handset is out of range while on a call.

Someone else is already using the directory or caller ID history.

The other handset is calling.

The battery is very low. The handset should be in the telephone base or charger.

You have started transferring a call, and need to enter the desired handset number.

Failed intercom or conference call (there are already two handsets being used).

VOBCMF!UP!TBWF You are trying to save an entry with no name and number from

the caller ID history.

Appendix C

Expansion handset

Your new AT&T CL82109/CL82209/CL82309/CL82359/CL82409/CL82509/ CL82609/CL82659/CL82859 telephone system can accommodate up to 12 handsets. You can add new handsets (AT&T CL80109, available separately) to your telephone system, you must register each device with the telephone base before use. To register a new handset, see page 51.

The handset with the CL82109 comes as HANDSET 1. You can register up to 11 additional handsets to the telephone base, and the handset numbers are in numerical order (HANDSET 2, HANDSET 3, HANDSET 4 and so on).

The handsets that come with the CL82209 are HANDSET 1, HANDSET 2. You can register up to 10 additional handsets to the telephone base, and they are assigned numbers in sequential order (HANDSET 3, HANDSET 4, HANDSET 5 and so on).

The handsets that come with the CL82309/CL82359 are HANDSET 1, HANDSET 2 and HANDSET 3. You can register up to nine additional handsets to the telephone base, and they are in sequential order (HANDSET 4, HANDSET 5, HANDSET 6 and so on).

The handsets that come with the CL82409 are HANDSET 1, HANDSET 2, HANDSET 3 and HANDSET 4. You can register up to eight additional handsets to the telephone base, and they are in sequential order (HANDSET 5, HANDSET 6, HANDSET 7 and so on).

The handsets that come with the CL82509 are HANDSET 1, HANDSET 2, HANDSET 3, HANDSET 4 and HANDSET 5. You can register up to seven additional handsets to the telephone base, and they are in sequential order (HANDSET 6, HANDSET 7, HANDSET 8 and so on).

The handsets that come with the CL82609/CL82659 are HANDSET 1, HANDSET 2, HANDSET 3, HANDSET 4, HANDSET 5 and can register up to six additional handsets to the telephone base, and they are in sequential order (HANDSET 7, HANDSET 8, HANDSET 9 and so on).

The handsets that come with the CL82859 are HANDSET 1, HANDSET 2,

HANDSET 3, HANDSET 4, HANDSET 5, HANDSET 6, HANDSET 7 and HANDSET 8. You can register up to four additional handsets to the telephone base, and they are in sequential order (HANDSET 9, HANDSET 10, HANDSET 11 and HANDSET 12).

HANDSET 6. You

Appendix C

Expansion handset

Adding and registering handsets (optional)

Handsets purchase separately (AT&T CL80109) need to be

OPU!SFHJTUFSFE

registered to the telephone base before use. When first purchased, all expansion handsets show NOT REGISTERED on the screen. New handset may need to be charged without interruption for at least 10 minutes before registering to the telephone base.

To register a handset to your telephone base

1. Make sure the handset is out of the telephone base or charger and shows

NOT REGISTERED before you begin registration.

2. Press and hold

HANDSET LOCATOR on the

OPU!SFHJTUFSFE

telephone base for about four seconds (until the red IN USE light on the telephone base is on) and then release

the button. The IN USE light remains on while the telephone base attempts to register a handset.

QSFTT!IOETU!MPD

5!TFD!PO!CBTF

3. Place the unregistered handset into the telephone base

or charger, PRESS HNDST LOC 4 SEC ON BASE shows on the handset screen. The handset is now registering with the telephone base. The handset then shows

QMFBTF!XBJU///

PLEASE WAIT... and it takes up to 60 seconds to complete the registration. There is a beep sound when the registration is successful. The handset shows HANDSET X REGISTERED, with X being the handset number (1-12).

IBOETFU!Y

SFHJTUFSFE

NOTES:

1. If the registration is not successful, the screen shows NOT REGISTERED. To reset the handset, remove the handset from the telephone base or charger, then start again from step 2 above.

2. You cannot register a handset if any other system handset is in use.

Appendix C

Expansion handset

Deregistering a handset

You can deregister handsets. You may need to deregister your handsets if:

You have twelve registered handsets and need to replace a handset.

-OR-

You wish to change the designated handset number of your registered handsets.

You must first deregister ALL the handsets, and then re-register each handset you wish to use.

Please read carefully through all the instructions on this page before beginning the deregistration process.

To deregister all handsets

1. Press and hold

10 seconds (until the IN USE light starts to flash), then release the HANDSET LOCATOR button.

2. Immediately press and release HANDSET LOCATOR again. You must press HANDSET LOCATOR while the IN USE light is still flashing. (The light flashes for about seven seconds. If the light stops flashing, pick up the handset and place it back into the telephone base, then start again with step one above.)

HANDSET LOCATOR on the telephone base for about

3. The handset(s) shows CONNECTING... and it takes about 10 seconds to complete the deregistration process. ALL handsets show NOT REGISTERED when deregistration is successful.

4. To re-register the handset(s) to the telephone base, follow the registration instructions on page 51.

NOTES:

1. If the deregistration process is not successful, you might need to reset the system

and try again. To reset: pick up the handset and press the PHONE/ then press the OFF/ base. You can also reset by unplugging the power from the telephone base and plugging it back in.

2. You cannot deregister the handset(s) if any other system handset is in use.

3. Even if the battery is depleted, you can still deregister the handset by following the steps above. After the handset is charged for at least 10 minutes, the screen shows

NOT REGISTERED.

CLEAR button and place the handset back into the telephone

FLASH button,

Appendix D

Troubleshooting

If you have difficulty with your phone, please try the suggestions below. For Customer Service, visit our website at

1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

www.telephones.att.com or call

My phone doesn’t work at all.

• Make sure the power cord is securely plugged in.

• Make sure you plug the battery connector securely into the cordless handset.

• Make sure you plug the telephone line cord securely and firmly into the telephone base and the telephone wall jack.

• Charge the battery in the cordless handset for at least 16 hours. For optimum daily performance, return the cordless handset to the telephone base or charger when not in use.

• If the battery is depleted, it might take approximately 10 minutes to charge the handset before it shows LOW BATTERY, refer to the table on page 6 for details.

• Reset the telephone base. Unplug the electrical power. Wait for approximately 15 seconds, then plug it back in. Allow up to one minute for the cordless handset and telephone base to reset.

• You may need to purchase a new battery. Please refer to Battery installation & charging in this user’s manual on pages 6-7.

I cannot get a dial tone.

• First try all the suggestions above.

• Move the cordless handset closer to the telephone

base. You might have moved out of range.

• If the previous suggestions do not work, disconnect

the telephone base from the telephone jack and connect to a different phone. If there is no dial tone on that phone either, the problem is in your wiring or local service. Contact your local telephone company.

• Your line cord might be malfunctioning. Try installing

a new line cord.

Appendix D

Troubleshooting

I cannot dial out.

My cordless handset isn’t performing normally.

• First try all the suggestions above.

• Make sure you have a dial tone before dialing. The cordless handset might take a second or two to find the telephone base and produce a dial tone. This is normal. Wait an extra second before dialing.

• Eliminate any background noise. Noise from a television, radio or other appliances might cause the phone to not dial out properly. If you cannot eliminate the background noise, first try muting the cordless handset before dialing, or dialing from another room with less background noise.

• If the other phones in your home are having the same problem, contact your local telephone company (charges might apply).

• Make sure you plug the power cord securely into the telephone base. Plug the power adapter into a different, working electrical outlet without a wall switch.

• Move the cordless handset closer to the telephone base. You might have moved out of range.

• Reset the telephone base. Unplug the electrical power. Wait for 15 seconds then plug it back in. Allow up to one minute for the cordless handset and telephone base to reset.

• Other electronic products can cause interference to your cordless phone. Try installing your phone as far away from these types of electronic devices as possible: television sets, VCRs, or other cordless telephones.

The handset registration is unsuccessful.

Follow the steps below to re-register the handset.

1. Make sure the handset is out of the telephone base

or charger and shows NOT REGISTERED before you begin registration.

2. Press and hold

four seconds (until the red IN USE light on the telephone base is on) and then release the button.

3. Place the unregistered handset into telephone base or charger.

Refer to the handset registration section on page 51 for details.

HANDSET LOCATOR for about

Appendix D

Troubleshooting

The handset screen shows

PRESS HNDST LOC 4 SEC ON BASE and the

handset is out of the telephone base or charger.

Unplug the battery from the handset and plug it back in (page 6). The screen should now show NOT REGISTERED and you can follow the registration instructions on page 51.

CONNECTING...

appears on my cordless handset.

The batteries do not hold a charge.

• Ensure you plug the telephone base in properly and the power is on.

• Place the cordless handset in the telephone base for one minute to allow the cordless handset and base to synchronize.

• Move the cordless handset closer to the telephone base. You might have moved out of range.

• Reset the telephone base. Unplug the electrical power. Wait for 15 seconds then plug it back in. Allow up to one minute for the cordless handset and telephone base to reset.

• Other electronic products can cause interference with your cordless phone. Try installing your phone as far away from these types of electronic devices as possible: television sets, VCRs, or other cordless telephones.

• If the cordless handset is in the telephone base or charger and the charge light is not on, refer to The charge light is off (page 58) in this Troubleshooting guide.

• Charge the battery in the cordless handset for at least 16 hours. For optimum daily performance, return the cordless handset to the telephone base or charger when not in use.

• If the battery is depleted, it might take approximately 10 minutes to charge the handset before it shows LOW BATTERY, refer to the table on page 6 for details.

• You might need to purchase a new battery. Please refer to Battery installation & charging in this user’s manual on pages 6-7.

Appendix D

Troubleshooting

I get noise, static, or weak signals even when I’m near the telephone base.

• If you subscribe to high-speed Internet service (digital subscriber line - DSL) through your telephone lines, you must install a DSL filter between the telephone base and the telephone wall jack (see page 5). The filter prevents noise and caller ID problems as a result of DSL interference. Please contact your DSL service provider for more information about DSL filters.

• You may be able to improve the performance of your cordless phone by installing your new telephone base as far as possible from any other existing cordless telephone system that may already be installed.

• Other electronic products can cause interference to your cordless phone. Try installing your phone as far away from the following electronic devices as possible: television sets, VCRs, or other cordless telephones.

• Do not install this phone near a microwave oven or on the same electrical outlet. You might experience decreased performance while the microwave oven is operating.

• If you plug your phone in with a modem or a surge protector, plug the phone (or modem/surge protector) into a different location. If this does not solve the problem, re-locate your phone or modem farther apart from one another, or use a different surge protector.

• Relocate your phone to a higher location. The phone might have better reception in a high area.

• If the other phones in your home are having the same problem, contact your local telephone company (charges may apply).

I experience poor sound quality when using the speakerphone.

• For increased sound quality while using the speakerphone, place the handset on a flat surface with the dial pad facing up.

Appendix D

Troubleshooting

I hear other calls while using my phone.

My cordless handset does not ring when I receive a call.

• Disconnect the telephone base from the telephone jack, and plug in a different telephone. If you still hear other calls, call your local telephone company.

• Make sure that the ringer is not off. Refer to Ringer volume on page 10 in this user’s manual.

• Make sure you plug in the telephone line cord securely into the telephone base and the telephone jack. Make sure you plug in the power cord securely.

• The cordless handset may be too far from the telephone base.

• Charge the battery in the cordless handset for at least 16 hours. For optimum daily performance, return the cordless handset to the telephone base or charger when not in use.

• You may have too many extension phones on your telephone line to allow all of them to ring simultaneously. Try unplugging some of the other phones.

• The layout of your home or office might be limiting the operating range. Try moving the telephone base to another location, preferably on an upper floor.

• If the other phones in your home are having the same problem, contact your local telephone company (charges might apply).

• Test a working phone at the phone jack. If another phone has the same problem, contact your local telephone company (charges might apply).

• Other electronic products can cause interference with your cordless phone. Try installing your phone as far away as possible from electronic devices such as television sets, VCRs, or other cordless telephones.

• Re-install the battery, and place the cordless handset in the telephone base. Wait for the cordless handset to re-establish its connection with the telephone base. Allow up to one minute for this to take place.

• Your line cord might be malfunctioning. Try installing a new line cord.

Appendix D

Troubleshooting

My calls cut in and out while I’m using my cordless handset.

• Other electronic products can cause interference with your cordless phone. Try installing your phone as far away from the following electronic devices as possible: television sets, VCRs, or other cordless telephones.

• Do not install this phone near a microwave oven or on the same electrical outlet. You might experience decreased performance while the microwave oven is operating.

• If you plug your phone in with a modem or surge protector, plug the phone (or modem/surge protector) into a different location. If this does not solve the problem, re-locate your phone or modem farther apart from one another, or use a different surge protector.

• Relocate your telephone base to a higher location. The phone might have better reception when installed in a high area.

• If the other phones in your home are having the same problem, contact your local telephone company (charges may apply).

The charge light is off.

My caller ID isn’t working.

• Make sure you plug the power and line cords in correctly and securely.

• Unplug the electrical power. Wait for 15 seconds, then plug it back in. Allow up to one minute for the cordless handset and telephone base to reset.

• Clean the cordless handset and telephone base charging contacts each month with a pencil eraser or cloth.

• Caller ID is a subscription service. You must subscribe to this service from your local telephone company for this feature to work on your phone.

• The caller must be calling from an area that supports caller ID.

• Both you and your caller’s telephone companies must use caller ID compatible equipment.

Appendix D

Troubleshooting

• If you subscribe to high-speed Internet service (digital subscriber line - DSL) through your telephone lines, you must install a DSL filter between the telephone base and the telephone wall jack (page 5). The filter prevents noise and caller ID problems resulting from DSL interference. Please contact your DSL service provider for more information about DSL filters.

System does not receive caller ID when on a call.

Incomplete messages.

Difficulty hearing messages.

System does not answer after correct number of rings.

• Make sure you subscribe to caller ID with call waiting features from your local telephone company. Caller ID features works only if both you and the caller are in areas offering caller ID service, and if both telephone companies use compatible equipment.

• If a caller leaves a very long message, part of it may be lost when the system disconnects the call after four minutes.

• If the caller pauses for longer than seven seconds, the system stops recording and disconnects the call.

• If the system’s memory becomes full during a message, the system stops recording and disconnects the call.

• If the caller's voice is very soft, the system may stop recording and disconnects the call.

• Press VOLUMEST to increase speaker volume.

• Make sure that the answering system is on (page 15 or page 39).

• If toll saver is on, the number of rings changes to two when you have new messages stored (page 17).

• If the memory is full or the system is off, the system answers after 10 rings.

System announces

“Time and day not set.”

• You need to reset the answering system clock (page 12).

Appendix D

Troubleshooting

System does not respond to remote commands.

System does not record message.

Outgoing announcement is not clear.

• Make sure you enter your remote access code correctly (page 18).

• Make sure you are calling from a touch-tone phone. When you dial a number, you should hear tones. If you hear clicks, the phone is not a touch-tone telephone and cannot activate the answering system.

• The answering system might not detect the remote access code while your announcement is playing. Try waiting until the announcement is over before entering the code.

• There may be interference on the phone line you are using. Press dial pad keys firmly.

• Make sure the answering system is on (page 15 or page 39).

• Make sure the memory of the answering system is not full.

• When you record your announcement, make sure you speak in a normal tone of voice, about nine inches from the telephone base.

• Make sure there is no background noise (TV, music, etc.) while recording.

Common cure for electronic equipment.

If the telephone does not seem to be responding normally, try putting the cordless handset in the telephone base or charger. If it does not seem to respond, do the following (in the order listed):

• Disconnect the power to the telephone base.

• Disconnect the cordless handset battery, and spare battery, if applicable.

• Wait a few minutes.

• Connect power to the telephone base.

• Re-install the battery, and place the cordless handset into the telephone base.

• Wait for the cordless handset to re-establish its connection with the telephone base. Allow up to one minute for this to take place.

Appendix E

Maintenance

Taking care of your telephone

• Your cordless telephone contains sophisticated electronic parts, so you must treat it with care.

• Avoid rough treatment.

• Place the handset down gently.

• Save the original packing materials to protect your telephone if you ever need to ship it.

Avoid water

• You can damage your telephone if it gets wet. Do not use the handset in the rain, or handle it with wet hands. Do not install the telephone base near a sink, bathtub or shower.

Electrical storms

• Electrical storms can sometimes cause power surges harmful to electronic equipment. For your own safety, take caution when using electric appliances during storms.

Cleaning your telephone

• Your telephone has a durable plastic casing that should retain its luster for many years. Clean it only with a soft cloth slightly dampened with water or a mild soap.

• Do not use excess water or cleaning solvents of any kind.

Remember that electrical appliances can cause serious injury if you use it when wet or standing in water. If the telephone base should fall into water, DO NOT RETRIEVE IT UNTIL YOU UNPLUG THE POWER CORD AND TELEPHONE LINE CORDS FROM THE WALL. Then pull the telephone out by the unplugged cords.

Appendix F

Important safety information

This symbol is to alert you to important operating or servicing instructions that may appear in this user’s manual. Always follow basic safety precautions when using this product to reduce the risk of injury, fire, or electric shock.

Safety information

• Read and understand all instructions in the user’s manual. Observe all markings on the product.

• Avoid using a telephone during a thunderstorm. There may be a slight chance of electric shock from lightning.

• Do not use a telephone in the vicinity of a gas leak. If you suspect a gas leak, report it immediately, but use a telephone away from the area where the gas is leaking. If this product is a cordless model, make sure the telephone base is also away from the area.

• Do not use this product near water, or when you are wet. For example, do not use it in a wet basement or shower, or next to a swimming pool, bathtub, kitchen sink, or laundry tub. Do not use liquids or aerosol sprays for cleaning. If the product comes in contact with any liquid, unplug any line or power cord immediately. Do not plug the product back in until it has dried thoroughly.

• Install this product in a protected location where no one can trip over any line or power cords. Protect cords from damage or abrasion.

• If this product does not operate normally, see the Troubleshooting section on pages 53-60 of this user’s manual. If you cannot solve the problem, or if the product is damaged, refer to the Limited warranty section on pages 66-67. Do not open this product except as directed in your user’s manual. Opening the product or reassembling it incorrectly may expose you to hazardous voltages or other risks.

• Replace batteries only as described in your user’s manual, see pages 6-7. Do not burn or puncture batteries — they contain caustic chemicals.

• This power adapter is intended to be correctly oriented in a vertical or floor mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling or an underthe-table/cabinet outlet.

Caution: Use only the power adapter provided with this product. To obtain a replacement, visit

our website at Canada, dial

Especially about cordless telephones

• Privacy: The same features that make a cordless telephone convenient create some limitations. Telephone calls are transmitted between the telephone base and the handset by radio waves, so there is a possibility that your cordless telephone conversations could be intercepted by radio receiving equipment within range of the cordless handset. For this

reason, you should not think of cordless telephone conversations as being as private as those on corded telephones.

• Electrical power: The telephone base of this cordless telephone must be connected to a working electrical outlet which is not controlled by a wall switch. Calls cannot be made from

the handset if the telephone base is unplugged, switched off or if the electrical power is interrupted.

www.telephones.att.com or call 1 (800) 222-3111. In

1 (866) 288-4268.

Appendix F

Important safety information

• Potential TV interference: Some cordless telephones operate at frequencies that may cause

interference to TVs and VCRs. To minimize or prevent such interference, do not place the telephone base of the cordless telephone near or on top of a TV or VCR. If interference is experienced, moving the cordless telephone farther away from the TV or VCR will often reduce or eliminate the interference.

• Rechargeable batteries: This product contains nickel-metal hydride rechargeable batteries. Exercise care in handling batteries in order not to create a short circuit with conductive material such as rings, bracelets, and keys. The battery or conductor may overheat and cause harm. Observe proper polarity between the battery and the battery charger.

• Nickel-metal hydride rechargeable batteries: Dispose of these batteries in a safe manner. Do not burn or puncture. Like other batteries of this type, if burned or punctured, they could release caustic material which could cause injury.

The RBRC™ Seal means that the manufacturer is voluntarily participating in an industry program to collect and recycle nickel-metal hydride rechargeable batteries when taken out of service within the United States. These batteries may be taken to a participating local retailer of replacement batteries or recycling center. Or you may call 1 (800) 8-BATTERY for locations accepting spent Ni-MH batteries.

Precautions for users of implanted cardiac pacemakers

Cardiac pacemakers (applies only to digital cordless telephones):

Wireless Technology Research, LLC (WTR), an independent research entity, led a multidisciplinary evaluation of the interference between portable wireless telephones and implanted cardiac pacemakers. Supported by the U.S. Food and Drug Administration, WTR recommends to physicians that:

Pacemaker patients

Should keep wireless telephones at least six inches from the pacemaker.

Should NOT place wireless telephones directly over the pacemaker, such as in a breast pocket, when it is turned ON.

Should use the wireless telephone at the ear opposite the pacemaker.

WTR’s evaluation did not identify any risk to bystanders with pacemakers from other persons using wireless telephones.

Especially about telephone answering systems

Two-way recording: This unit does not sound warning beeps to inform the other party that the call is being recorded. To ensure that you are in compliance with any federal or state regulations regarding recording a telephone call, you should start the recording process and then inform the other party that you are recording the conversation.

SAVE THESE INSTRUCTIONS

Appendix G

FCC part 68 and ACTA

This equipment complies with Part 68 of the FCC rules and with technical requirements adopted by the Administrative Council for Terminal Attachments (ACTA). The label on the back or bottom of this equipment contains, among other things, a product identifier in the format US:AAAEQ##TXXXX. This identifier must be provided to your local telephone company upon request.

The plug and jack used to connect this equipment to premises wiring and the telephone network must comply with the applicable Part 68 rules and technical requirements adopted by ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. An RJ11 jack should normally be used for connecting to a single line and an RJ14 jack for two lines. See Installation Instructions in the user’s manual.

The Ringer Equivalence Number (REN) is used to determine how many devices you may connect to your telephone line and still have them ring when you are called. The REN for this product is encoded as the 6th and 7th characters following the US: in the product identifier (e.g., if ## is 03, the REN is 0.3). In most, but not all areas, the sum of all RENs should be five (5.0) or less. For more information, please contact your local telephone company.

This equipment may not be used with Party Lines. If you have specially wired alarm dialing equipment connected to your telephone line, ensure the connection of this equipment does not disable your alarm equipment. If you have questions about what will disable the alarm equipment, consult your telephone company or a qualified installer.

If this equipment is malfunctioning, it must be unplugged from the modular jack until the problem has been corrected. Repairs to this telephone equipment can only be made by the manufacturer or its authorized agents. For repair procedures, follow the instructions outlined under the Limited Warranty.

If this equipment is causing harm to the telephone network, the telephone company may temporarily discontinue your telephone service. The telephone company is required to notify you before interrupting service. If advance notice is not practical, you will be notified as soon as possible. You will be given the opportunity to correct the problem and the telephone company is required to inform you of your right to file a complaint with the FCC. Your telephone company may make changes in its facilities, equipment, operation, or procedures that could affect the proper functioning of this product. The telephone company is required to notify you if such changes are planned.

If this product is equipped with a corded or cordless handset, it is hearing aid compatible.

If this product has memory dialing locations, you may choose to store emergency telephone numbers (e.g., police, fire, medical) in these locations. If you do store or test emergency numbers, please:

Remain on the line and briefly explain the reason for the call before hanging up.

Perform such activities in off-peak hours, such as early morning or late evening.

Industry Canada

Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference, including interference that may cause undesired operation.

The term ‘’IC:‘’ before the certification/registration number only signifies that the Industry Canada technical specifications were met.

The Ringer Equivalence Number (REN) for this terminal equipment is 0.1. The REN is an indication of the maximum number of devices allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the RENs of all the devices does not exceed five.

This product meets the applicable Industry Canada technical specifications.

Appendix H

FCC part 15

This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications to this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this telephone.

To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with the FCC criteria. The handset may be safely held against the ear of the user. The telephone base shall be installed and used such that parts of the user’s body other than the hands are maintained at a distance of approximately 20 cm (8 inches) or more.

This Class B digital apparatus complies with Canadian ICES-003.

Appendix I

Limited warranty

The AT&T brand is used under license - any repair, replacement or warranty service, and all questions about this product should be directed to: In the United States of America, visit

www.telephones.att.com or call 1 (800) 222-3111. In Canada, call 1 (866) 288-4268.

1. What does this limited warranty cover?

The manufacturer of this AT&T-branded product warrants to the holder of a valid proof of purchase (“CONSUMER” or “you”) that the product and all accessories provided in the sales package (“PRODUCT”) are free from defects in material and workmanship, pursuant to the following terms and conditions, when installed and used normally and in accordance with the PRODUCT operating instructions. This limited warranty extends only to the CONSUMER for

products purchased and used in the United States of America and Canada.

2. What will be done if the PRODUCT is not free from defects in materials and workmanship during the limited warranty period (“materially defective PRODUCT”)?

During the limited warranty period, the manufacturer’s authorized service representative will repair or replace at the manufacturer’s option, without charge, a materially defective PRODUCT. If the manufacturer repairs the PRODUCT, they may use new or refurbished replacement parts. If the manufacturer chooses to replace the PRODUCT, they may replace it with a new or refurbished PRODUCT of the same or similar design. The manufacturer will retain defective parts, modules, or equipment. Repair or replacement of the PRODUCT, at the manufacturer’s option, is your exclusive remedy. The manufacturer will return repaired or replacement products to you in

working condition. You should expect the repair or replacement to take approximately 30 days.

3. How long is the limited warranty period?

The limited warranty period for the PRODUCT extends for ONE (1) YEAR from the date of purchase. If the manufacturer repairs or replaces a materially defective PRODUCT under the terms of this limited warranty, this limited warranty also applies to repaired or replacement PRODUCT for a period of either (a) 90 days from the date the repaired or replacement PRODUCT is shipped to you or (b) the time remaining on the original one-year limited warranty; whichever

is longer.

4. What is not covered by this limited warranty?

This limited warranty does not cover:

• PRODUCT that has been subjected to misuse, accident, shipping or other physical damage, improper installation, abnormal operation or handling, neglect, inundation, fire, water, or other liquid intrusion; or

• PRODUCT that has been damaged due to repair, alteration, or modification by anyone other than an authorized service representative of the manufacturer; or

• PRODUCT to the extent that the problem experienced is caused by signal conditions, network reliability or cable or antenna systems; or

• PRODUCT to the extent that the problem is caused by use with non-AT&T accessories; or

• PRODUCT whose warranty/quality stickers, PRODUCT serial number plates or electronic serial numbers have been removed, altered or rendered illegible; or

• PRODUCT purchased, used, serviced, or shipped for repair from outside the United States of America or Canada, or used for commercial or institutional purposes (including but not limited to products used for rental purposes); or

Appendix I

Limited warranty

• PRODUCT returned without valid proof of purchase (see item 6 below); or

• Charges for installation or setup, adjustment of customer controls, and installation or repair of systems outside the unit.

5. How do you get warranty service?

To obtain warranty service in the United States of America, visit

www.telephones.att.com or call 1 (800) 222-3111. In Canada, call 1 (866) 288-4268. NOTE: Before calling for service, please review the user’s manual; a

check of the PRODUCT controls and features may save you a service call.

Except as provided by applicable law, you assume the risk of loss or damage during transit and transportation and are responsible for delivery or handling charges incurred in the transport of the PRODUCT(s) to the service location. The manufacturer will return repaired or replaced PRODUCT under this limited warranty to you. Transportation, delivery or handling charges are prepaid. The manufacturer assumes no risk for damage or loss of the PRODUCT in transit. If the PRODUCT failure is not covered by this limited warranty, or proof of purchase does not meet the terms of this limited warranty, the manufacturer will notify you and will request that you authorize the cost of repair prior to any further repair activity. You must pay for the cost of repair and return shipping costs for the repair of products that are not covered by this limited warranty.

6. What must you return with the PRODUCT to get warranty service? You must:

• Return the entire original package and contents including the PRODUCT to the service location along with a description of the malfunction or difficulty; and

• Include “valid proof of purchase” (sales receipt) identifying the PRODUCT purchased (PRODUCT model) and the date of purchase or receipt; and

• Provide your name, complete and correct mailing address, and telephone number.

7. Other limitations

This warranty is the complete and exclusive agreement between you and the manufacturer of

this AT&T branded PRODUCT. It supersedes all other written or oral communications related to this PRODUCT. The manufacturer provides no other warranties for this PRODUCT. The warranty exclusively describes all of the manufacturer’s responsibilities regarding the PRODUCT. There are no other express warranties. No one is authorized to make modifications to this limited warranty and you should not rely on any such modification.

State/Provincial Law rights: This warranty gives you specific legal rights, and you may also have other rights which vary from state to state or province to province.

Limitations: Implied warranties, including those of fitness for a particular purpose and merchantability (an unwritten warranty that the PRODUCT is fit for ordinary use) are limited to one year from date of purchase. Some states/provinces do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. In no event shall the manufacturer be liable for any indirect, special, incidental, consequential, or similar damages (including, but not limited to lost profits or revenue, inability to use the PRODUCT or other associated equipment, the cost of substitute equipment, and claims by third parties) resulting from the use of this PRODUCT. Some states/provinces do not allow the exclusion or limitation of

incidental or consequential damages, so the above limitation or exclusion may not apply to you.

Please retain your original sales receipt as proof of purchase.

Appendix J

Technical specifications

RF frequency band 1921.536 MHz — 1928.448 MHz

Channels 5

Operating temperature

Telephone base voltage (AC voltage, 60Hz)

Telephone base voltage (AC adapter output)

Handset voltage 2.4 — 3.2 VDC

Charger voltage (AC adapter output)

Operation Operating time*

Talk time (handset) Up to eight hours

Talk time (speakerphone) Up to five hours

Standby Up to six days

* Operating times varies depending on your actual use and the age of the battery.

DECT 6.0 digital technology

The AT&T DECT 6.0 products offer unsurpassed range performance and sound clarity. This is achieved through a unique antenna design and advances in noise-filtering technology. An independent laboratory has confirmed that AT&T DECT 6.0 products perform up to 45% better in range competitions. Now calls can be taken in the basement, backyard and garage with exceptional sound quality.

Telephone operating range

This cordless telephone operates within the maximum power allowed by the Federal Communications Commission (FCC). Even so, this handset and telephone base can communicate over only a certain distance — which can vary with the locations of the telephone base and handset, the weather, and the construction of your home or office.

Redefining long range coverage and clarity

This telephone base comes with an antenna which gives much better clarity and covers a longer range than before.

32°F — 122°F 0°C — 50°C

96 — 130 Vrms

6VDC @400mA

6VAC @300mA

Index

Alert 47 Alert tones, 47 Answering calls, 20 Answering system, 39 Auto off, 20

Battery charging, 6 Battery installation, 6

Call intercept, 40 Call screening, 40 Call transfer using intercom, 27 Call waiting, 22 Caller ID (CID),

add entries to phone directory, 37 delete entries, 37 dial entries, 37

review entries, 36 Caller ID, 33 Chain dialing, 23 Charger installation, 5 Clear voicemail indication, 13 Clock, 12

Day and time, 12 Delete entries in the caller ID history, 37 Delete redial entries, 21 deregistration, 52 Dialing,

Directory dialing, 32

From a record in the caller ID

history, 37 Directory,

Dial number, 32

Edit entries, 32

Name search, 31

New entries 29 Display dial, 32 DSL, 4, 5

Elapsed time, 20 Ending calls, 20 Expansion handset, 50

Flash (switch hook flash), 22

Handset,

deregistration, 52 Expansion, 50 Key tone, 11 Language, 11 Locator, 24 Quick reference guide, 1 Registration, 51 Ringer tone, 10 Ringer volume, 10 Screen display message, 48 Settings, 10 Speakerphone, 21 Status icons, 47 Temporary ringer silencing, 20 Voicemail indicator, 13

Important safety information, 62 Incoming caller ID history, 36 Incoming calls, answering, 20 Installation, 4 Intercom, 25

Key tone, 11

Language, 11 Last number redial, 21 Lights, 47 Limited warranty, 66-67

Maintenance, 61

Making calls, 20 Memory match, 35 Memos, 43 Message,

Alert tone, 19

Counter display, 40

Playback, 41 Mute, 22

Names,

Enter into directory, 30

Search for, 31 Number of rings, 17

On-hook dialing, 20 Outgoing announcement, 16

Paging tone, 24 Power adapter, 5 Predialing, 20

Quick reference guide, 1-3

Temporary ringer silencing, 20 Time, setting, 12 Troubleshooting, 53-60

Visual message waiting indicator, 13 Voice prompts, 40 Voicemail, 13 Volume controls,

Base ringer, 40 Handset, 10

Wall-mount installation, 8 Warranty, 66

Receiving calls, 20 Recharging, 7 Redial, 21 Registration, 51 Remote access, 18, 45 Ring tone options, 10 Ringer silencing, 20 Ringer volume,

Base, 40

Handset, 10

Safety information, 62 Search by name, 31 Speakerphone, 21

Technical specifications, 68 Telephone operating range, 68

Remote access wallet card

Use the wallet card below to help you remember commands to control your answering system from any touch tone telephone.

Cut along dotted line.

Call your phone number, then enter your two-digit access code (preset to 19).

Action Remote command

Play all messages......................1

Play new messages...................2

Delete the message ..................3

Delete all old messages ...........33

Repeat or go back.....................4

Stop ............................................5

Help menu..................................*5

Skip the message ..................... 6

Record announcement ............ *7

Turn system off or on .............. 0

End remote access call............ 8 (or hang up)

Model name: CL82109/CL82209/CL82309/CL82359/CL82409/

Type: DECT 6.0 cordless telephone/answering system with

© 2008-2009 Advanced American Telephones. All Rights Reserved. AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to Advanced American Telephones, San Antonio, TX 78219. Printed in China.

CL82509/CL82609/CL82659/CL82859

caller ID/call waiting

www.telephones.att.com

AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to

Advanced American Telephones, San Antonio, TX 78219.

Printed in China. Issue 6 AT&T 09/09.

AT&T CL82859, CL82309, CL82409, CL82509, CL82609 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Quick reference guide - handset

Quick reference guide - telephone base

Installation

Telephone base & charger installation

Battery installation and charging

2. If you do not use the handset for a long time, disconnect and remove the battery to prevent possible leakage.

Installation options

Telephone settings

Answering system settings

Making, answering, and ending calls

Handset operation

Options while on calls

Options while on calls

Multiple handset use

Intercom

Call transfer using intercom

About the directory

Create directory entries

Review directory

Search directory

To dial, delete or edit entries

About caller ID

Caller ID history

Caller ID operation

Reasons for missing caller ID information

About the answering system

Message playback

Recording & playing memos

Base message counter displays

Remote access

Alert tones and lights

Handset display screen messages

Expansion handset

Troubleshooting

Maintenance

Important safety information

FCC part 68 and ACTA

FCC part 15

Limited warranty

Technical specifications

Index
