User’s manual

CL82101/CL82201/CL82301/ CL82351/CL82401/CL82451/ CL82501/CL82551/CL82601 DECT 6.0 cordless telephone/ answering system with caller ID/call waiting

Congratulations

Compatible with

Hearing Aid T-Coil

TIA-1083

on your purchase of this AT&T product. Before using this AT&T product, please read the Important safety information section on pages 73-74 of this manual. Please thoroughly read this user’s manual for all the feature operations and troubleshooting information necessary to install and operate your new AT&T product. You can also visit our website at

www.telephones.att.com or call 1 (800) 222-3111.

In Canada, dial 1 (866) 288-4268.

Model number:

CL82101 (one handset) CL82201 (two handsets) CL82301 (three handsets) CL82351 (three handsets) CL82401 (four handsets) CL82451 (four handsets) CL82501 (five handsets) CL82551 (five handsets) CL82601 (six handsets)

Type: DECT 6.0 cordless telephone/answering system with caller ID/call waiting

Serial number: __________________________________________________________

Purchase date: __________________________________________________________

Place of purchase: _______________________________________________________________

Both the model and serial numbers of your AT&T product can be found on the bottom of the telephone base.

Save your sales receipt and original packaging in case it is necessary to return your telephone for warranty service.

Telephones identified with this logo have reduced noise and interference when used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083 Compliant Logo is a trademark of the Telecommunications Industry Association. Used under license.

The ENERGY STAR® program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to supply this product with an ENERGY STAR® qualified power

© 2010-2011 Advanced American Telephones. All Rights Reserved. AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to Advanced American Telephones, San Antonio, TX 78219. Printed in China.

adapter meeting the latest energy efficiency guidelines.

Parts checklist

BY 1021

BT183342/BT283342

2.4V 400mAh Ni-MH

Your telephone package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary.

User’s manual

CL82101/CL82201/CL82301/ CL82351/CL82401/CL82451/ CL82501/CL82551/CL82601 DECT 6.0 cordless telephone/ answering system with caller ID/call waiting

User’s manual

Quick start guide Telephone base

Charger for cordless handset with power adapter installed (One for CL82201) (Two for CL82301 and CL82351) (Three for CL82401 and CL82451) (Four for CL82501 and CL82551) (Five for CL82601)

Quick start guide

CL82101/CL82201/CL82301/ CL82351/CL82401/CL82451/ CL82501/CL82551/CL82601 DECT 6.0 cordless telephone/ answering system with caller ID/call waiting

Cordless handset (One for CL82101) (Two for CL82201) (Three for CL82301 and CL82351) (Four for CL82401 and CL82451) (Five for CL82501 and CL82551) (Six for CL82601)

Battery for cordless handset (One for CL82101) (Two for CL82201) (Three for CL82301 and CL82351) (Four for CL82401 and CL82451) (Five for CL82501 and CL82551) (Six for CL82601)

Battery compartment cover (One for CL82101) (Two for CL82201) (Three for CL82301 and CL82351) (Four for CL82401) and CL82451) (Five for CL82501 and CL82551) (Six for CL82601)

Wall mount bracket

Telephone line cord

Power adapter for telephone base

User’s manual

CL82101/CL82201/CL82301/ CL82351/CL82401/CL82451/ CL82501/CL82551/CL82601 DECT 6.0 cordless telephone/ answering system with caller ID/call waiting

Table of contents

Getting started

Quick reference guide - handset ........1

Quick reference guide - telephone

base .............................................................3

Installation ..................................................... 4

Telephone base and charger

installation ..................................................... 5

Telephone base installation ............ 5

Charger installation .............................5

Battery installation and charging ....... 6

Installation options .................................... 8

Tabletop to wall mount

installation.............................................8

Wall mount to tabletop

installation.............................................9

Telephone settings

Handset settings ...................................... 10

Ringer volume ..................................... 11

Ringer tone ........................................... 11

Set date/time ...................................... 12

LCD language ...................................... 13

Caller ID announce ........................... 13

Voicemail (visual message

waiting) indicator ............................ 14

Clear voicemail indication

Rename handset ................................ 15

Key tone ................................................. 15

Use caller ID to automatically

set date and time ........................... 16

Home area code ................................. 16

............. 14

Dial mode

Website ...................................................17

Telephone operation

Handset operation...................................18

Making a call ........................................ 18

On hook dialing (predialing) ........ 18

Answering a call ................................ 18

Ending a call ........................................ 18

Auto off .................................................. 18

Temporary ringer silencing ........... 18

Speakerphone ..................................... 19

Last number redial ............................ 19

Equalizer ................................................. 20

Options while on calls .......................... 21

Volume control ................................... 21

Call waiting ........................................... 21

Mute ......................................................... 21

Chain dialing ........................................ 22

Temporary tone dialing .................. 23

Blind transfer ....................................... 23

Multiple handset use

Multiple handset use ............................. 24

Handset locator .................................. 24

Join a call in progress .....................24

Intercom ....................................................... 25

Answer an incoming call

during an intercom call ............... 25

Call transfer using intercom .............. 26

.............................................. 17

Push-to-talk (PTT) ................................... 27

Turn PTT on or off ............................. 27

PTT call to a single handset ...........27

PTT call to a group of handsets ...28

Answer a PTT call .............................. 29

Change a one-to-one PTT call

to an intercom call ........................ 29

Answer an incoming call during

PTT ......................................................... 30

Make an outgoing call during PTT ... 30

End or leave a PTT call ................... 30

Getting started

Quick reference guide - handset

CHARGE indicator

On when the handset is charging in the telephone base or charger.

qCID/VOLUME

Press qCID to show caller ID history (page 40).

Press to scroll down while in menus.

While entering names or numbers, press to move the cursor to the left.

Press to decrease the listening volume when on a call ( or to decrease the message playback volume (page 52).

MUTE/DELETE

During a call, press to mute the microphone (page 21).

While reviewing the caller ID history, the directory or the redial memory, press to delete an individual entry ( and page 19 respectively).

While predialing, press to delete digits (

page 18).

PHONE/FLASH

Press to make or answer a call. During a call, press to answer

an incoming call when you receive a call waiting alert (

page 21).

While reviewing a caller ID log entry, press repeatedly to add or remove 1 in front of the telephone number before dialing or saving it in the directory (page 41).

TONE

Press to switch to tone dialing temporarily during a call if you have pulse service (page 23).

/SPEA�ERSPEA�ER

Press to switch between the speakerphone and the handset (page 19).

page 21),

page 41, page 35

pDIR/VOLUME

Press pDIR to show directory entries (page 34).

Press to scroll up while in menus.

While entering names or numbers, press to move the cursor to the right.

Press to increase the listening volume when on a call (page 21), or to increase the message playback volume (page 52).

MENU/SELECT

Press to show the menu. While in the menu, press to

select an item or save an entry or setting.

OFF/CANCELOFF/CANCEL

During a call, press to hang up. While in a menu, press to

cancel an operation, back up to the previous menu, or exit the menu display, or press and hold this button to exit to idle mode.

Press and hold while the telephone is not in use to erase the missed call indicator.

# (pound key)

Press repeatedly to display other dialing options when reviewing a caller ID log entry (page 41).

During an outside call, intercom call, message or announcement playback, press to change the audio quality to best suit your hearing (page 20).

REDIAL/PAUSE

Press repeatedly to view the last 10 numbers dialed (page 19).

While entering numbers, press and hold dialing pause (page 32).

to insert a

Getting started

Quick reference guide - handset

PUSH TO TAL�

Press to initiate a one-to-one or one-to-group broadcast (page 27).

Press and hold handsets (page 28).

Main menu

Play messages (page 52)

to broadcast to a group of

Main menu

The > symbol highlights a menu item.

>Play messages

Answering sys

p q

Answering sys (

Directory (

Caller ID log (

Intercom (

Ringers (

page 11)

Set date/time (

Settings (

Website (

page 44)

page 31)

page 38)

page 25)

page 12)

page 13)

page 17)

Using menus:

Press MENU/SELECT to show the menu.

• Press q

• menu items.

•

Press changes to a highlighted menu item.

•

Press operation, back up to the previous menu, or exit the menu display.

CID or pDIR to scroll through

MENU/SELECT to confirm or save

OFF/CANCEL to cancel an

Getting started

Quick reference guide - telephone base

/ANSWER ON

Press to turn the built-in answering system on or off (page 45).

Message counter

Shows the number of messages or other answering system information (page 55).

/REPEAT

Press to repeat a message.

Press twice to play the previous message (

page 52).

IN USE indicator

On when the handset is in use, or when the answering system is answering an incoming call.

On when a handset is being registered. Flashes when there is an incoming call or

when a handset is being deregistered.

Flashes when another telephone is in use on the same line.

X/DELETE

Press to delete the message currently playing (page 52).

Press twice to delete all old messages when the phone is not in use (

page 53).

q/VOL/p

During message playback, press to adjust the listening volume (page 52).

While in idle mode, press to adjust the base ringer volume (

page 51).

/S�IP

Press to skip a message (page 52).

/PLAY/STOP

Press to start or stop message playback (page 52).

Getting started

Installation

You must install and charge the battery before using the telephone.

Install the telephone base close to a telephone jack and a power outlet not controlled by a wall switch. The telephone base can be placed on a flat surface or vertically mounted on the wall (see page 8). For optimum range and better reception, place the telephone base in a central and open location.

If you subscribe to high-speed Internet service (DSL - digital subscriber line) through your telephone line, you must install a DSL filter between the telephone line cord and the telephone wall jack (see the following page). The filter prevents noise and caller ID problems caused by DSL interference. Please contact your DSL service provider for more information about DSL filters.

Your product may be shipped with a protective sticker covering the handset or telephone base display - remove it before use.

For customer service or product information, visit our website at

STOP!

See pages 6-7 for easy instructions.

www.telephones.att.com or call 1 (800) 222-3111. In Canada,

dial 1 (866) 288-4268.

Avoid placing the telephone base too close to:

•

Communication devices such as television sets, VCRs, or other cordless telephones.

•

Excessive heat sources.

•

Noise sources such as a window with traffic outside, motors, microwave ovens, refrigerators, or fluorescent lighting.

•

Excessive dust sources such as a workshop or garage.

•

Excessive moisture.

•

Extremely low temperature.

•

Mechanical vibration or shock such as on top of a washing machine or workbench.

Getting started

Telephone base and charger installation

Install the telephone base and charger as shown below.

The telephone base is ready for tabletop use. If you want to change to wall mounting, see Installation options on

Telephone base installation

Plug the other end

•

of the telephone line cord into a telephone jack or a DSL filter.

•

Raise the antenna.

If you have DSL high-speed Internet service, a DSL filter (not included) is required.

page 8 for details.

Telephone line cord

Plug one end of the

•

telephone line cord into the telephone jack on the back of the telephone base.

Plug the small end of

•

the telephone base power adapter into the power adapter jack on the back of the telephone base.

Route the power

•

adapter cord and the telephone line cord through this slot.

Plug the large end

•

of the power adapter into a power outlet not controlled by a wall switch.

Charger installation

Plug the power adapter into an electrical outlet not controlled by a wall switch.

IMPORTANT INFORMATION

1. Use only the power adapter(s) supplied with this product. To order a replacement

power adapter, visit our website at www.telephones.att.com or call

1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

2. The power adapters are intended to be correctly oriented in a vertical or floor mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling, under-the-table or cabinet outlet.

Getting started

BY 1021

BT183342/BT283342

2.4V 400mAh Ni-MH

Battery installation and charging

Install the battery as shown below. Once you have installed the battery, the

screen indicates the battery status (see the table below). If necessary, place the handset in the telephone base or charger to charge the battery. For best performance, keep the handset in the telephone base or charger when not in use. The battery is fully charged after 10 hours of continuous charging. See

the table on page 79 for battery operating times.

If the screen shows Place in charger and flashes, you need to charge the handset without interruption for at least 30 minutes to give the handset

enough charge to use the telephone for a short time. The following table

summarizes the battery charge indicators and actions to take.

Battery indicators Battery status Action

The screen is blank, or shows Place in charger

(flashing).

and

The screen shows Low battery and (flashing).

The screen shows HANDSET X.

Battery has no or very little charge. The handset cannot be used.

Battery has enough charge to be used for a short time.

Battery is charged. To keep the battery charged,

Charge without interruption (at least 30 minutes).

place it in the telephone base or charger when not in use.

NOTE: If you are on a phone call in low battery mode, you hear four short beeps every minute.

Step 1

Plug the battery connector securely into the socket inside the handset battery compartment, matching

Step 2

Align the cover flat against the battery compartment, then slide it upwards until

it clicks into place. the color-coded label. Insert the supplied battery with the label THIS SIDE UP facing up as indicated.

Getting started

Battery installation and charging

CHARGE light

Step 3

Charge the handset by placing it face forward in the telephone base or charger. The CHARGE light on the top of the handset is on during charging.

After you install your telephone or power returns following a power outage, the handset will prompt you to set the date and time. For instructions, see Set date/time on page 12. To skip setting the date and time, press OFF/CANCEL.

SET DATE MM/DD/YY

SET TIME HH/MM/--

p q

IMPORTANT INFORMATION

1. Use only the supplied rechargeable battery or replacement battery (model BT166342)

To order, visit our website at www.telephones.att.com or call

1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

2. If you do not use the handset for a long time, disconnect and remove the battery to prevent possible leakage.

Getting started

Installation options

Your telephone base is ready for tabletop use. If you want to mount your telephone on a wall, use the provided wall mount bracket to connect with a standard dual-stud telephone wall mounting plate. If you do not have this mounting plate, you can purchase one from many hardware or consumer electronic retailers. You might need a professional to install the mounting plate.

Tabletop to wall mount installation

1. Plug the power cord and telephone line into the telephone base. If you are using a DSL filter, plug the other end of the telephone line into the filter. Route the telephone line cord (or DSL filter) through the wall mount bracket hole.

2. Position the telephone base as shown below. Insert the extended tabs (see below figure 2) of the wall mount bracket into the slots on the back of the telephone base (marked B). Push the telephone base down until it is securely in place.

3. Plug the telephone line cord (or DSL filter) into the wall jack. Plug the power adapter into a power outlet not controlled by a wall switch.

4. Align the holes on the wall mount bracket with the standard wall plate and slide the wall mount bracket down until it locks securely. Bundle the telephone line cord and power adapter cord neatly with twist ties.

Getting started

Installation options

Wall mount to tabletop installation

1. If the telephone line cord and power adapter cord are bundled, untie them first.

2. Push the telephone base up to detach it from the wall mount bracket. Unplug the telephone line cord (or DSL filter) from the wall. Unplug the power adapter from the power outlet.

3. Push the wall mount bracket up to remove it from the wall.

4. See Telephone base and charger installation on

page 5.

Telephone settings

Handset settings

Use the menu to change the telephone settings.

1. Press MENU/SELECT when in idle mode (when the phone is not in use) to enter the main menu.

>Play messages

Answering sys

p q

2. Press qCID or pDIR to scroll to the feature to be changed. When scrolling through the menu, the > symbol indicates the selected menu item.

3. Press MENU/SELECT to select the highlighted item.

NOTE: Press OFF/CANCEL to cancel an operation, back up to the previous menu or exit the menu display. Press and hold

OFF/CANCEL to return to idle mode.

Go to Answering system settings starting on page 44 for instructions on how to use a system handset to modify the answering system settings shown below.

Setting Page

Announcement (play, record and delete)

Answer on/off

Call screening

Number of rings

Remote access code

Message alert tone

Message recording time

44-45

46-47

Telephone settings

Handset settings

Ringer volume

You can set the ringer volume level (1-6) to one of six levels or turn the ringer off. When the ringer is off,

appears on the

screen.

1. Press MENU/SELECT in idle mode to enter the main menu.

2. Use qCID or pDIR to scroll to >Ringers, then press

MENU/SELECT.

3. Press MENU/SELECT again to select >Ringer volume.

4. Press qCID or pDIR to sample each volume level.

. Press MENU/SELECT to save your preference. There is a

confirmation tone and the screen returns to the previous menu.

NOTES:

The handset ringer volume also determines the ringer volume for

•

intercom calls.

If the ringer volume is set to off, that handset is silenced for all incoming calls.

• However, the handset still plays the paging tone when responding to the handset locator.

If the ringer volume is set to off, caller ID will not be announced and Caller ID won’t be announced

• displays briefly on the screen.

Intercom

>Ringers

p q

Ringer volume Ringer tone

p q

RINGER VOLUME

p q

Ringer tone

You can choose one of 10 ringer tones.

1. Press MENU/SELECT in idle mode to enter the main menu.

2. Use qCID or pDIR to scroll to >Ringers, then press

MENU/SELECT.

3. Press qCID or pDIR to scroll to >Ringer tone, then press

MENU/SELECT.

4. Press qCID or pDIR to sample each ringer tone.

5. Press MENU/SELECT to save your preference. There is a confirmation tone and the screen returns to the previous menu.

NOTE: If you turn off the ringer volume, you do not hear ringer tone samples.

Ringer volume

Ringer tone

p q

RINGER TONE

Tone 1

p q

Telephone settings

Handset settings

Set date/time

The answering system announces the day and time of each message prior to playing it. Before using the answering system, set the date and time as follows. If you subscribe to caller ID service, the day, month and time are set automatically with each incoming call. The year must be set so that the day of the week can be calculated from the caller ID information. You can turn off the date and time settings of the caller ID service and set the date and time manually (see Use caller ID to automatically set date and time on

page 16).

After a power failure or handset registration, the system reminds you to set the date and time.

Follow the steps below to set the month, day, year and time.

1. When the handset is in idle mode, press MENU/SELECT to enter the main menu.

2. Press qCID or pDIR to scroll to >Set date/time and then

Ringers >Set date/time

p q

press MENU/SELECT.

3. Press qCID or pDIR to select the month, then press

MENU/SELECT, or enter the number using the dialing keys.

4. Press qCID or pDIR to select the day, then press

MENU/SELECT, or enter the number using the dialing keys.

SET DATE MM/DD/YY

p q

5. Press qCID or pDIR to select the year, then press

MENU/SELECT, or enter the number using the dialing keys,

then press MENU/SELECT to move on to set the time.

6. Press qCID or pDIR to select the hour, then press

MENU/SELECT, or enter the number using the dialing keys.

SET TIME HH:MM --

p q

7. Press qCID or pDIR to select the minute, then press

MENU/SELECT, or enter the number using the dialing keys.

8. Press q

CID or pDIR to highlight AM or PM, or press 2 for AM or 7 for PM.

Then press MENU/SELECT to confirm. There is a confirmation tone and the screen returns to the previous menu.

NOTE: If the clock is not set when a message is recorded, the system announces, “Time and day not set,” before it plays the message.

Telephone settings

Handset settings

LCD language

You can select the language used for all screen displays.

1. Press MENU/SELECT in idle mode to enter the main menu.

2. Use qCID or pDIR to scroll to >Settings, then press

MENU/SELECT.

3. Press MENU/SELECT to choose >LCD language.

4. Press qCID or pDIR to highlight >English, >Français or >Español.

5. Press MENU/SELECT to save your preference. There is a confirmation tone and the screen returns to the previous menu.

Caller ID announce

The caller ID announce feature lets you know who’s calling without having to look at the display. When you have an incoming call, the handset and/or base speaks “Call from...” and the name of the caller based on the directory or caller ID information. If the caller’s name is private or unknown, the phone number up to the last 11 digits will be spoken. If the caller’s phone number is also private or unknown, no information will be spoken. By default, the caller ID announce feature is programmed On.

To turn on/off the caller ID announce on your handset or base:

1. Press MENU/SELECT in idle mode to enter the main menu.

2. Use qCID or pDIR to scroll to >Settings, then press

MENU/SELECT.

3. Use qCID or pDIR to scroll to >Caller ID annc, then press MENU/SELECT.

4. Use qCID or pDIR to highlight >HANDSET or >BASE, then press MENU/SELECT.

5. Use q

CID or pDIR to highlight >On or >Off, then press

MENU/SELECT. There is a confirmation tone and the screen

returns to the previous menu.

LCD language

Caller ID annc

LCD language >Caller ID annc

CALLER ID ANNC >HANDSET

HS CID ANNOUNCE >On

p q

LCD LANGUAGE

English

p q

NOTES:

To use the caller ID announce feature, you must subscribe to caller ID service from your

• telephone service provider.

When there are up to five handsets registered, the telephone system supports caller ID announce

• for all handsets. If six or more handsets are registered, the system supports caller ID announce for the first four registered handsets only.

This feature does not announce information for call waiting calls.

• It takes at least 2 rings for the phone to receive caller ID information and announce it. If the

• phone is answered before the end of the second ring, the phone won’t have time to announce the caller’s information.

Pronunciation of names may vary with this feature. Not all names may be pronounced correctly.

• Caller ID announce is available in English only.

•

Telephone settings

Handset settings

Voicemail (visual message waiting) indicator

If you subscribe to a voicemail service offered by your telephone service provider, this feature provides a visual indication when you have new voicemail messages.

HANDSET 1

New voicemail

New voicemail and the

NOTES:

This feature does not indicate new messages recorded on your phone’s built-in answering system.

• For more information about the difference between your answering system and voicemail, see

• page 49.

icon appear on the handset screen.

2/11

10:21

Clear voicemail indication

Use this feature when the telephone indicates there is new voicemail but there is none. For example, when you have accessed your voicemail while away from home. This feature only turns off the displayed New voicemail and the

icon;

Clr voicemail

Rename handset

p q

it does not delete your voicemail messages. As long as you have new voicemail messages, your telephone service provider continues to send the signal to turn on the indicators.

Turn off

indicator?

To manually turn off the new voicemail indicators:

1. Press MENU/SELECT when in idle mode to enter the main menu.

2. Use qCID or pDIR to scroll to >Settings, then press MENU/SELECT.

3. Use qCID or pDIR to scroll to >Clr voicemail, then press MENU/SELECT. The screen shows Turn off indicator?

. Press MENU/SELECT again to turn the voicemail indication off. There is a

confirmation tone and the screen returns to the previous menu.

NOTES:

•

Your telephone service provider voicemail might alert you to new messages with a stutter (broken) dial tone. Contact your telephone service provider for more details.

•

For information about using your voicemail service, contact your telephone service provider.

Telephone settings

Handset settings

Rename handset

You can create a handset name for each system handset.

1. When the handset is idle, press MENU/

SELECT.

2. Use qCID or pDIR to scroll to >Settings, then press

MENU/SELECT.

3. Use qCID or pDIR to scroll to >Rename handset, then press MENU/SELECT.

. Change the handset name when prompted.

Press q

•

CID or pDIR to move the cursor to the left

or right.

•

Use the dialing keys to enter a name (up to 11 characters). Each time you press a key, a character on that key appears. Additional key presses produce other characters on that key. See the chart on

•

Press

MUTE/DELETE to backspace and delete characters.

•

Press and hold

5. Press

MENU/SELECT to save the setting and return to the previous menu.

MUTE/DELETE to delete all characters.

There is a confirmation tone.

Clr voicemail

Rename handset

RENAME HANDSET

HANDSET_

page 33.

p q

�ey tone

The handset is set to beep with each key press. You can adjust the key tone volume or turn it off. If you turn off the key tone, there are no beeps when you press keys.

1. Press MENU/SELECT in idle mode to enter the main menu.

2. Use qCID or pDIR to scroll to >Settings, then press

MENU/SELECT.

Rename handset

Key tone

p q

3. Use qCID or pDIR to scroll to >�ey tone, then press

MENU/SELECT.

4. Use q

5. Press

CID or pDIR to select the desired volume or Off.

MENU/SELECT to save your preference. There is a

confirmation tone and the screen returns to the

KEY TONE

p q

previous menu.

Telephone settings

Handset settings

Use caller ID to automatically set date and time

Follow the steps below to turn the CID time sync feature on or off. The default setting is On.

1. When the handset is in idle mode, press MENU/SELECT to enter the main menu.

2. Press qCID or pDIR to scroll to >Settings, then press

MENU/SELECT.

3. Press qCID or pDIR to scroll to >CID time sync, then press

MENU/SELECT.

4. Press qCID or pDIR to highlight >On or >Off, then press

MENU/SELECT to save. There is a confirmation tone and the screen returns

to the previous menu.

Home area code

If you dial seven digits to make a local call (no area code required), enter your area code into the telephone as the home area code. When you receive a call from within your home area code, the caller ID history only displays the seven digits of the telephone number.

This feature makes it easy for you to place a call from the caller ID log. If you dial 10 digits to make a local phone call, do not use this home area code feature. If you do, you cannot place local calls from your caller ID log, as they will have only seven digits.

Key tone >CID time sync

p q

CID TIME SYNC >On

p q

CID time sync >Home area code

p q

To set the home area code:

HOME AREA CODE

___

1. Press MENU/SELECT in idle mode to enter the main menu.

2. Use qCID or pDIR to scroll to >Settings, then press

MENU/SELECT.

3. Use qCID or pDIR to scroll to >Home area code, then press MENU/SELECT. The screen briefly shows Only for 7digit dial from CID.

4. Use the dialing keys to enter a three-digit home area code.

Press MUTE/DELETE to delete a digit.

• Press and hold

•

MUTE/DELETE to delete all digits.

5. Press MENU/SELECT to save. There is a confirmation tone and the screen shows Area code will not show in CID briefly before returning to the previous menu.

NOTE: If in the future, your telephone service provider requires you to dial 10 digits to make a local call (area code plus telephone number), you need to delete your home area code and dial out locally from the caller ID log. With the home area code displayed, press and hold The home area code is now restored to its default setting of _ _ _ (empty).

MUTE/DELETE until the digits are deleted, and then press MENU/SELECT.

Telephone settings

Handset settings

Dial mode

The dial mode is preset to tone dialing. If you have pulse (rotary) service, you must change the dial mode to pulse dialing before using the telephone.

To set the dial mode:

1. Press MENU/SELECT in idle mode to enter the main menu.

2. Use qCID or pDIR to scroll to >Settings, then press

MENU/SELECT.

3. Use qCID or pDIR to scroll to >Dial mode, then press

MENU/SELECT.

4. Use qCID or pDIR to highlight >Tone or >Pulse, then press MENU/SELECT. There is a confirmation tone and the screen returns to the previous menu.

Website

Use this feature to view the AT&T website address.

1. Press MENU/SELECT in idle mode to enter the main menu.

2. Use qCID or pDIR to scroll to >Website, then press

MENU/SELECT.

Home area code >Dial mode

p q

DIAL MODE

>Tone

p q

Settings

Website

p q

www.telephones. att.com

Telephone operation

Handset operation

Making a call

Press

• telephone number.

The screen displays the elapsed time as you talk (in hours, minutes and seconds).

PHONE/FLASH or /SPEA�ERSPEA�ER, then enter the

Elapsed time

Phone 0:00:30

10/15

10:01

NOTE: Pressing PHONE/FLASH to access services from your telephone service provider does not affect the elapsed time.

Speaker 0:00:30

10/15

10:01

On hook dialing (predialing)

1. Enter the telephone number. Press MUTE/DELETE to make corrections when entering the phone number.

2. Press PHONE/FLASH or /SPEA�ERSPEA�ER to dial.

888-883-2445

Answering a call

Press

•

-OR-

Press any dialing key (0-9, TONE

•

PHONE/FLASH or /SPEA�ERSPEA�ER.

or #).

Incoming call

Ending a call

Press

OFF/CANCEL or return the handset to the telephone base or charger.

Auto off

A call ends automatically when you put the handset in the telephone base or charger.

Temporary ringer silencing

Press

OFF/CANCEL or MUTE/DELETE while the telephone is

ringing to silence the ringer temporarily on that handset only. This turns off the ringer without disconnecting the call. The next incoming call rings normally at the preset volume.

NOTE: Each handset rings when there is an incoming call unless the ringer volume is turned off on that handset.

Ringer muted

Telephone operation

Handset operation

Speakerphone

During a call, press

/SPEA�ERSPEA�ER to switch between handsfree

speakerphone and normal handset use. Press OFF/CANCEL to hang up.

NOTES:

When you use the speakerphone, the key pad of the handset and the

•

/SPEA�ER button are lit.

The speakerphone uses more power than the normal handset. If the handset battery becomes

• very low while you are using the speakerphone, the call remains in speakerphone mode until you hang up or the battery becomes depleted.

After installing a battery into the handset, the screen may show Low battery. If you use the

• speakerphone at this time, the battery may become depleted. Follow the instructions in the

Battery installation and charging section on pages 6-7.

Last number redial

Each handset stores the last 10 telephone numbers dialed (up to 30 digits).

To view the 10 most recently dialed numbers:

To display the most recently called number, press

•

REDIAL/

To view up to 10 recently called numbers, press REDIAL/

•

PAUSE.

or pDIR, or press REDIAL/PAUSE repeatedly.

The handset beeps twice at the end of the list. Press

OFF/CANCEL to exit.

Elapsed time

Speaker 0:00:30

10/15

PAUSE then qCID

10:01

To redial a number:

To dial the displayed number, press

•

/SPEA�ERSPEA�ER.

PHONE/FLASH or

Redial #1/10

888-883-2445

p q

-OR-

•

Press

PHONE/FLASH or /SPEA�ERSPEA�ER, then press

REDIAL/PAUSE repeatedly to view the redial memory. Press MENU/SELECT

to dial the displayed number.

To delete a number:

While the screen displays the desired number, press

•

MUTE/DELETE to

delete the number from the redial memory.

Telephone operation

Handset operation

Equalizer

The equalizer feature on the handset enables you to change the quality of the audio to best suit your hearing.

While on a call or intercom call, or listening to a message or announcement, press EQ setting Treble 1, Treble 2, Bass or Natural (the default setting). The current setting is shown on the handset screen for two seconds.

NOTES:

If you switch the call between the handset and the speakerphone by

• pressing /SPEA�ER, the audio setting remains unchanged.

The current equalizer setting remains unchanged until a new setting

• is selected.

to select the equalizer

Treble 1

8/06

Treble 2

8/06

Bass

6:30

8/06

Natural

8/06

6:30

Telephone operation

Options while on calls

Volume control

While on a call, press increase the listening volume. You can set the listening volume to one of

six levels.

NOTES:

•

Handset and speakerphone volume settings are independent.

•

When the volume reaches the minimum or maximum setting, you hear two beeps.

Call waiting

If you subscribe to call waiting service from your telephone service provider, you hear two beeps if someone calls while you are already on a call. Press

PHONE/FLASH to put your current call on hold and take the new call.

Press PHONE/FLASH at any time to switch back and forth between calls.

NOTE: Missed call waiting calls are not counted as missed calls.

qCID/VOLUME to decrease or press pDIR/VOLUME to

pDIR/VOLUME

CID/VOLUME

Mute

Use the mute function to turn off the microphone. You can hear the caller, but the caller cannot hear you.

To mute a call:

• While on a call, press MUTE/DELETE. When mute is on, the handset screen shows Muted for a few seconds and MUTE displays until you turn off mute.

To end mute a call:

• Press MUTE/DELETE again. When mute is off, Microphone ON appears temporarily on the

handset screen.

MUTE/DELETE

Muted

10/15

Phone 0:00:30

Microphone ON

10/15

p q

10:01

MUTE

Telephone operation

Options while on calls

Chain dialing

Use this feature to initiate a dialing sequence from the numbers in the directory, caller ID history or redial memory while you are on a call.

Chain dialing is useful when you wish to access other numbers (such as bank account numbers or access codes) from the directory, caller ID history or redial list.

To access the directory while on a call:

1. Press MENU/SELECT.

2. Press qCID or pDIR to scroll to >Directory and then press

MENU/SELECT.

3. Press qCID or pDIR to scroll to the desired number.

4. Press MENU/SELECT to dial the number shown.

To access the caller ID log while on a call:

1. Press MENU/SELECT.

2. Press qCID or pDIR to scroll to >Caller ID log, then press

MENU/SELECT.

3. Press qCID or pDIR to scroll to the desired number.

4. Press MENU/SELECT to dial the number shown.

Intercom >Directory

Charlie Johnson

888-883-2445

p q

Phone 0:01:20 Charlie Johnson

To access the redial list while on a call:

1. Press REDIAL/PAUSE to show the most recently

REDIAL #1/10

800-360-4121

dialed number.

2. Press qCID or pDIR to scroll to the desired number, or press

REDIAL/PAUSE to show the last 10 recently dialed numbers.

Then press MENU/SELECT to dial the number shown.

NOTES:

•

You cannot edit a directory entry while on a call. For more details about the directory, see page 31.

•

You cannot copy a caller ID entry into the directory while on a call. For more details about the caller ID history, see

•

If you press REDIAL/ numbers and you cannot erase the entries. For more details about the redial memory, see page 19.

•

Press

OFF/CANCEL to exit redial, directory or caller ID history when on a call.

page 38.

PAUSE while on a call, you can only view the 10 most recently dialed

p q

Telephone operation

Options while on calls

Temporary tone dialing

If you have pulse (rotary) service only, you can switch from pulse to touch-tone dialing temporarily during a call. This is useful if you need to send touch-tone signals to access your telephone banking or long

distance services.

1. During a call, press TONE .

2. Use the dialing keys to enter the desired number. The telephone sends touch-tone signals.

3. The telephone automatically returns to pulse dialing after you end the call.

Blind transfer

While on an outside call, you can transfer it to a specific handset or any

handset. This feature is not available for model CL82101 unless you purchase an accessory handset (AT&T model CL80101).

To transfer an outside call directly without notifying the desired handset:

1. During the call, press MENU/

2. Press

MENU/SELECT to choose >Transfer.

If you have a two-handset system, the outside call is put

•

on hold and your handset screen shows Transferring

call... The other handset rings and its screen shows Transfer from other handset.

If you have more than two handsets, your screen shows

•

TRANSFER TO:

Use the dialing keys to eenter a specific

handset number (1-9 for handsets 1-9, TONE and 0 for

handset 10, TONE and 1 for handset 11, TONE and 2 for handset 12, or TONE and # for all handsets), or

press qCID or pDIR to scroll to the desired handset

and press MENU/SELECT. The outside call is put on hold

and your handset screen shows Transferring call... or Transferring call to all... The other handset(s) rings and

shows Transfer from HANDSET X (HANDSET represents

the handset name, X represents the handset number).

To answer the call on the destination handset, press, press PHONE/FLASH or

/SPEA�ERSPEA�ER. The original handset shows Call transferred and goes to

idle mode.

NOTES:

•

To cancel the transfer and return to the external call before the blind transfer call is answered, press OFF/CANCEL on your handset.

•

If the other handset does not answer the transfer within 30 seconds, the transfer ends and the original handset rings while showing No response to transfer. If it does not pick up within 30 seconds, the handset returns to idle mode and the outside call ends.

SELECT.

Phone 0:00:12

10/15

>Transfer Intercom

TRANSFER TO: >Handset 2

10:01

p q

Multiple handset use

Handset locator

The handset locator feature is useful if you misplace any handsets.

To start the paging tone:

Press

• to start the paging tone on all handsets for 60 seconds.

To stop the paging tone:

Press

• (0-9, TONE , or #) on the handset(s).

-OR-

Press

•

Join a call in progress

When a handset is already on a call and you would like to join the call, press

PHONE/FLASH or /SPEA�ERSPEA�ER on your handset.

/HANDSET LOCATOR on the telephone base

NOTE: If you press OFF/CANCEL or MUTE/DELETE on a handset, the ringer of that handset stops, but the paging to the rest of the handsets continues.

PHONE/FLASH, /SPEA�ERSPEA�ER, or any dialing key

/HANDSET LOCATOR on the telephone base.

**Paging**

Press

OFF/CANCEL or place the handset in the telephone base or charger to

end the call. The call does not end until all handsets hang up.

NOTE: You can use up to four system handsets at the same time on an outside call.

Multiple handset use

Intercom

Use the intercom feature for conversations between two handsets. This feature is only available if you have at least two system handsets. Intercom is not available for the CL82101 model. You can buy accessory handsets (AT&T model CL80101) to expand your system.

Use a handset to initiate intercom calls and transfer calls.

1. Press MENU/SELECT in idle mode to enter the main menu.

Press qCID or pDIR to scroll to >Intercom, then press

MENU/SELECT. Choose from the options below.

If you have a two-handset system, your handset screen

•

shows Calling other handset.

•

If you have more than two handsets, your screen shows

INTERCOM TO: handset number (1-9 for handsets 1-9, TONE

handset 10, TONE for handset 12, or TONE

Use the dialing keys to eenter a specific

and 0 for

and 1 for handset 11, TONE and 2

and # for all handsets), or

press qCID or pDIR to scroll to the desired handset and

press MENU/SELECT. Your handset screen shows Calling HANDSET X or Calling all handsets.

The other handset(s) rings and shows either Other handset is calling or HANDSET X is calling (HANDSET represents the handset name, X

represents the handset number).

2. To answer the intercom call, press PHONE/FLASH, /SPEA�ERSPEA�ER or any dialing key (0-9, TONE , or #) on any called handset. Both handsets now show Intercom.

3. To end the intercom call, one party presses OFF/CANCEL, or places the handset back in the telephone base or charger. The other party hears four beeps. Both handsets display Intercom ended.

Calling

other handset

Other handset

is calling

Intercom

12/02 11:35AM

NOTES:

Before the intercom call is answered, you can cancel it by pressing OFF/CANCELCANCEL.

• If the called handset is not answered within 100 seconds, or if it is in the directory or caller ID

• log, or is on a call, or is out of range, the calling handset shows No answer. Try again.

Pressing

•

You can only use one pair of handsets to make intercom calls at a time.

OFF/CANCEL or MUTE/DELETE temporarily silences the intercom ringer.

Answer an incoming call during an intercom call

If you receive an incoming outside call during an intercom call, there is a two-beep call waiting tone.

To answer the call, press

•

PHONE/FLASH. The intercom call ends

automatically. The party on the intercom call hears four beeps. Other system

handsets can also answer the incoming call by pressing

To end the intercom call without answering the incoming call, press

•

PHONE/FLASH.

OFF/CANCEL.

Multiple handset use

Call transfer using intercom

Use the intercom feature to transfer an outside call to another system handset. You can also share an outside call with another system handset. This feature is available only if you have two or more handsets.

>Transfer Share call

p q

To transfer or share an outside call using intercom:

1. During the call, press MENU/

2. Press q

CID or pDIR to scroll to >Intercom and press MENU/SELECT.

SELECT.

3. Choose the handset(s) you would like to transfer the call to using the options from Step 1 of the previous page.

4. When the destination handset(s) picks up, your handset shows Intercom and the outside call is put on hold. Then you have the following options:

You can transfer the call. Press MENU/SELECT

•

twice to select

>Transfer on the calling handset. Your screen shows Call transferred.

The other handset automatically connects to the outside call.

•

You can let the other handset join you on the outside call in a three-way conversation. Press MENU/

SELECT. Press qCID or pDIR to

highlight >Share call on the calling handset, then press MENU/SELECT.

•

You can end the intercom call and continue the outside call with your handset. Press

PHONE/FLASH on your handset (the ended

intercom call party hears four beeps), or the other person can press

OFF/CANCEL on the other system handset.

Multiple handset use

Push-to-talk (PTT)

You can directly broadcast messages to the speakerphone of any handset. Any handset you call can respond by pressing the PUSH TO TAL� key to begin two-way communication.

Only one handset can talk at a time. To do so, press and hold

• PUSH TO TAL�.

You must release

•

Only one PTT session can be active at a time.

•

While PTT is in use between two handsets, other handsets cannot use the intercom feature but can access the answering system.

•

When you attempt to place a PTT call to another handset which is accessing the answering system or on an intercom call or outside call, your handset screen shows Not available at this time.

Turn PTT on or off

1. Press

PUSH TO TAL� when the handset is not in use. The

PUSH TO TAL� menu displays.

2. Press q

MENU/SELECT.

3. Press q

MENU/SELECT.

CID or pDIR to highlight

CID or pDIR to choose

PUSH TO TAL�, so the other person can respond.

PUSH TO TALK

PTT On/Off, then press

>On

>Off

, then press

>PTT On/Off

p q

PTT

PTT call to a single handset

1. There are a few ways to begin a PTT call to a single handset. When the handset is not in use:

•

If you have a two-handset system, press and hold PUSH TO TAL�.

•

If you have more than two handsets, press PUSH TO TAL�. Then use the dialing keys to enter the destination handset number.

-OR-

Press q

CID or pDIR to highlight the destination handset

number and then press MENU/SELECT or PUSH TO TAL�.

Your handset screen shows Connecting to HANDSET X...

(HANDSET represents the handset name, X represents the

destination handset number)

for a few seconds. When

the connection is made, both your and the destination handset screens display Press and hold [PTT] to talk.

PUSH TO TALK

>Handset X

p q

Connecting to

Handset X...

Press and hold

[PTT] to talk

Multiple handset use

Push-to-talk (PTT)

2. Press and hold PUSH TO TAL� on your handset. A chirp indicates your microphone is on. Speak towards the handset. Your voice is broadcast to the destination handset.

While you are speaking, your handset screen shows

PTT To

handset: X

PTT To handset: X.

3. Release

PUSH TO TAL� after speaking. Both handsets beep once again.

After the handsets beep, you can press and hold PUSH TO TAL� to

continue speaking or the destination handset can respond (see

Answer a PTT call on page 29).

4. To end the PTT call, press

OFF/CANCEL or place the handset in the

telephone base or charger. The handset screen shows Push to talk Ended for a few seconds.

PTT call to a group of handsets

When there are multiple handsets registered to the phone system, PTT supports one-to-group calls. PTT supports a maximum of one-to-four calls when two to five handsets are registered, and a maximum of one-to-three calls when six or more handsets are registered. The first four registered handsets will be able to use this feature. Other handsets can only use PTT for one-to-one calls.

To call a group of handsets:

1. You have three ways to call a group of handsets. When the handset is not in use:

Press and hold

•

PUSH TO TAL� until your handset screen shows

Connecting to group...

Press

•

PUSH TO TAL�. Press qCID or pDIR to choose Group. Press

MENU/SELECT or press and hold PUSH TO TAL� until your handset

screen shows Connecting to group...

•

Press

PUSH TO TAL�. Press TONE and # (pound key). The screen

shows Connecting to group...

When the connection is made, both the caller and the destination parties

hear a beep. The speakerphones on all other handsets automatically activate.

2. You need to press and hold

PUSH TO TAL� when you want to speak.

Speak towards the handset. Your voice is broadcast to all eligible handsets.

3. Release PUSH TO TAL� after speaking.

4. Any extension can reply (see Answer a PTT call on page 29).

NOTE: After PUSH TO TAL� is released, the PTT call remains open for a short time. If no one presses PUSH TO TAL� within 10 seconds, the PTT call ends automatically.

Multiple handset use

Push-to-talk (PTT)

Answer a PTT call

You can respond to a PTT call whenever the speakerphone light is off, as described below.

When your handset receives a PTT call, the handset beeps and the screen

shows Press and hold [PTT] to talk. When the other party is speaking, your speakerphone light is on, and

your handset shows PTT From HS X To HS X (the first X represents the initiating handset number, the second X represents your handset number; a maximum of four handset numbers appear).

When your speakerphone light is off (the screen shows

Press and hold [PTT] to talk), press and hold handset. You will hear a chirp. Speak towards the handset.

While you are speaking, your handset screen shows PTT To handset: X

•

(X represents the handset numbers of one or more destination handsets; a maximum of four handset numbers appear).

Your voice is broadcast to all destination handsets.

• After speaking, release

PUSH TO TAL�. Your handset will beep.

After the beep, if your speakerphone light is off, you can press and hold PUSH TO TAL� to continue speaking, or the destination handset can respond.

PUSH TO TAL� on your

Change a one-to-one PTT call to an intercom call

You can convert a one-to-one PTT session to an intercom call.

When your handset screen shows Press and hold [PTT] to talk, press

MENU/SELECT. The screen shows

MENU/SELECT. Your handset displays Calling other handset or

Press

Intercom.

Calling HANDSET X. The destination handset screen briefly shows Push to talk Ended and then Other handset is calling or HANDSET X is calling. The destination handset rings.

On the destination handset, press

PHONE/FLASH or any of the dialing

keys (0-9, #, TONE or ) to answer the intercom call. Both handsets now show Intercom.

To end the intercom call, press

OFF/CANCEL or place the handset in the

telephone base or charger. Both screens show Intercom ended.

Multiple handset use

Push-to-talk (PTT)

Answer an incoming call during PTT

When you receive an incoming outside call during PTT, there is an alert tone.

During a one-to-one PTT, press

•

PHONE/FLASH on the initiating or

destination handset. The PTT call ends automatically and the outside call is answered.

During a one-to-group PTT, press

•

PHONE/FLASH on the initiating handset.

The PTT call ends automatically and the outside call is answered.

•

During a one-to-group PTT, press

PHONE/FLASH on any one of the

destination handsets and that handset answers the outside call. The PTT call continues for the rest of the PTT participants.

•

To leave the PTT call without answering the incoming call, press

OFF/CANCEL. The telephone continues to ring.

Make an outgoing call during PTT

•

During a one-to-one PTT, press

PHONE/FLASH to get a dial tone. The PTT

call ends automatically.

•

During a one-to-group PTT, press

PHONE/FLASH on the initiating handset.

The PTT call ends automatically and you get a dial tone.

•

During a one-to-group PTT, press

PHONE/FLASH on any one of the

destination handsets and that handset gets a dial tone. The PTT call continues for the rest of the PTT participants.

End or leave a PTT call

For one-to-one PTT calls, both initiating and destination handsets can end PTT. For PTT calls to a group of handsets, the initiating handset can end the PTT call for the group of handsets on the PTT call. If any one of the destination handsets leaves the PTT call, the call continues until all participants or the initiator hangs up.

Press

OFF/CANCEL or place the handset in the telephone base or charger.

The handset screen shows Push to talk Ended.

NOTE: After PUSH TO TAL� is released, the PTT call remains open for a short time. If no one presses PUSH TO TAL� within 10 seconds, the PTT call ends automatically.

Caller ID

About caller ID

This product supports caller ID services offered by most telephone service providers. Caller ID allows you to see the name, number, date and time of calls. The available caller ID information will appear after the first or second ring.

Information about caller ID with call waiting

Caller ID with call waiting lets you see the name and telephone number of the caller before answering the call, even while on another call.

It might be necessary to change your telephone service to use this feature. Contact your telephone service provider if:

You have both caller ID and call waiting, but as separate

• services (you might need to combine these services).

You have only caller ID service, or only call waiting service.

• You don’t subscribe to caller ID or call waiting services.

•

CHRISTINE SMITH

888-883-2445

NEW

10/15

10:01

There are fees for caller ID services. In addition, services may not be available in all areas.

This product can provide information only if both you and the caller are in areas offering caller ID service and if both telephone service providers use compatible equipment. The time and date, along with the call information, are from the telephone service provider.

Caller ID information might not be available for every incoming call. Callers may intentionally block their names and/or telephone numbers. To view caller ID log entries with numbers between 16 and 24 digits, you must save the entry to the directory (see

NOTE: You can use this product with regular caller ID service, or you can use this product’s other features without subscribing to caller ID or combined caller ID with call waiting service.

page 42).

Caller ID

Caller ID history

How the caller ID history (caller ID log) works

The telephone stores caller ID information about the last 50 incoming calls in the telephone base. Entries are stored in reverse chronological order. The phone deletes the oldest entry when the log is full to make room for new calls. This information is common to all handsets, so changes made using any handset are reflected in all other handsets. If you answer a call before the information appears on the screen, it does not show in the caller ID history.

NOTE: Each entry may have up to 24 digits for the phone number and 15 characters for the name.

Missed (new) call indicator

When a handset is in idle mode and has new or missed calls, its screen shows XX Missed calls.

All new or missed entries are counted as missed calls. Each time you review a new caller ID log entry (indicated by NEW on the handset screen), the number of missed calls decreases by one.

If you do not want to review the missed calls one by one, but still want to keep them in the caller ID history, you can press and hold handset is idle. All the entries in the caller ID history become old (reviewed already), and the missed calls message goes away.

OFF/CANCEL for four seconds when the

CHRISTINE SMITH

888-883-2445

10/15

HANDSET 1

6 Missed calls

10/15

Robert Brown

888-883-2445

10/15

10:01

p q

10:01

NEW

Caller ID

Caller ID operation

Memory match

If the incoming telephone number matches the last seven digits of a telephone number in your directory, the name that appears on the screen matches the corresponding name in your directory.

For example, if Christine Smith calls, her name appears as Chris if this is how you entered it into your directory.

NOTE: The number shown in the caller ID log will be in the format sent by the telephone service provider. The telephone service provider usually delivers 10-digit phone numbers (area code plus telephone number). If the telephone number of the caller does not match a number in your directory, the name will appear as it is delivered by the telephone service provider.

Review the caller ID history

Review the caller ID history to find out who called, to return the call, or to copy the caller’s name and number into your directory. Caller ID log empty appears if there are no records in the caller ID log.

1. When a handset is in idle mode, press qCID to review the caller ID history in reverse chronological order starting with the most recent call.

-OR-

Review the caller ID history by pressing MENU/SELECT.

Press qCID or pDIR to scroll to >Caller ID log, then press

MENU/SELECT twice to select >Review.

2. Press qCID or DIRp to scroll through the list.

3. Press OFF/CANCEL to exit the caller ID history.

You hear a double beep when the list reaches the beginning or end of the caller ID log.

Chris

888-883-2445

NEW

p q

10/15

10:01

HANDSET 1

6 Missed calls

NEW

10/15

10:01

qCID

View dialing options

Although the incoming caller ID log entries have 10 digits (the area code plus the seven-digit number), in some areas, you might need to dial only the seven digits, 1 plus the seven digits, or 1 plus the area code plus the seven digits. You can change and store the number of digits that you dial in the caller ID log.

883-2445

While reviewing the caller ID log, press # (pound key) repeatedly to show different dialing options for local

1-883-2445

888-883-2445

1-888-883-2445

and long distance numbers before dialing or saving the telephone number in the directory.

Press 1 repeatedly if you need to add or remove 1

883-2445

1-883-2445

in front of the telephone number before dialing or saving it in the directory.

888-883-2445

1-888-883-2445

When the number is in the correct format for dialing, press

PHONE/FLASH or /SPEA�ERSPEA�ER to call the number.

To save the number to the directory, see Save a caller ID log entry to the directory on the next page.

Press #

Press 1

Dial a caller ID log entry

1. When in the caller ID log, press q

2. Press

PHONE/FLASH or /SPEA�ERSPEA�ER to dial the displayed entry.

CID or DIRp to browse.

Delete caller ID log entries To delete an entry:

Press

•

MUTE/DELETE to delete the shown entry.

To delete all entries:

Review

>Del all calls

p q

1. Press MENU/SELECT when in idle mode.

2. Press qCID or pDIR to scroll to >Caller ID log, then press MENU/SELECT.

3. Press qCID or pDIR to scroll to >Del all calls, then press MENU/SELECT.

4. When the screen shows Delete all calls?, press MENU/SELECT to confirm.

There is a confirmation tone and the screen returns to the previous menu.

Caller ID

Caller ID operation

Save a caller ID log entry to the directory

1. When in the caller ID log, press q

2. Press

MENU/SELECT to select an entry. The screen displays EDIT NUMBER.

3. Use the dialing keys to edit the number.

Press q

• Press

•

Press and hold

•

Press and hold

CID or pDIR to move the cursor to the left or right.

MUTE/DELETE to backspace and erase a digit.

MUTE/DELETE to erase the entire entry. REDIAL/PAUSE to insert a three-second dialing pause

(a p appears).

4. Press

MENU/SELECT to move to the name. The screen displays EDIT NAME.

Use the dialing keys (page 33) to edit the name.

•

Press q

•

Press

•

Press and hold

•

Press # (pound key) to move the last word to the front. For example,

CID or pDIR to move the cursor to the left or right.

MUTE/DELETE to erase a character.

MUTE/DELETE to erase all characters.

Johnson Charlie becomes Charlie Johnson when you press # (pound key).

Press MENU/SELECT when done. The handset shows Saved.

CID or pDIR to browse.

NOTES:

You might need to change how a caller ID number is dialed if the entry does not appear in the

• correct format. Caller ID numbers might appear with an area code that might not be necessary for local calls, or without a 1 that might be necessary for long distance calls (see View dialing options on page 41).

If the name you received from the telephone service provider is all in capital letters, the first

• letter of every word remains a capital letter, while other letters become lowercase. However, the next letter after the prefix “Mac”, “Mc”, or “O’”, is kept as a capital letter. For example, the “D” in “MacDonald” is kept as a capital letter. Another exception is that “VAN DER” will be changed to “Van der”.

If the entry is already saved in the directory, Number already saved displays.

•

Caller ID

Reasons for missing caller ID information

There are occasions when other information or no information shows for various reasons:

On-screen message Reason

PRIVATE NUMBER

The caller prefers not to show the phone number.

PRIVATE NAME

PRIVATE CALLER

UNKNOWN NUMBER

UNKNOWN NAME

UNKNOWN CALLER

The caller prefers not to show the name.

The caller prefers not to show the phone number and name.

Your telephone service provider cannot determine the caller’s number.

Your telephone service provider cannot determine the caller’s name.

Your telephone service provider cannot determine the caller’s name and telephone number.

Calls from other countries may also generate this message.

Answering system

Answering system settings

Use the answering system menu of a system handset to set up the announcement message, turn on or off the answering system or message alert tone, activate call screening, or change the number of rings, message recording time, or

Play messages >Answering sys

p q

remote access code. If you turn off the answering system and you change any setting in the answering system setup menu, the answering machine automatically turns on again.

1. When the handset is in idle mode, press MENU/SELECT to enter the main menu.

2. Press qCID or pDIR to scroll to >Answering sys, then press MENU/SELECT.

Announcement

Your outgoing announcement plays when calls are answered by the answering system.

The telephone has a default outgoing announcement, “Hello. Please leave a message after the tone.” You can use this announcement, or record your own.

You can record an announcement up to 90 seconds. The system does not record any announcement shorter than two seconds.

To play your current outgoing announcement:

1. When the handset is in idle mode, press MENU/SELECT to enter the main menu.

2. Press qCID or pDIR to scroll to >Answering sys, then

MENU/SELECT.

press

3. Press MENU/SELECT again to select >Announcement.

4. Press MENU/SELECT to select >Play annc and play the announcement.

Announcement

Delete all old

p q

To record a new outgoing announcement:

1. When the handset is in idle mode, press MENU/SELECT to enter the main menu.

2. Press qCID or pDIR to scroll to >Answering sys, then press

MENU/SELECT.

3. Press

MENU/SELECT again to select >Announcement.

Play annc >Record annc

p q

4. Scroll to >Record annc and press MENU/SELECT. The system announces,

“Record after the tone. Press 5 when you are done.”

5. Facing the handset, record your announcement and press 5 to end recording. Your recorded announcement plays.

To listen to the recorded announcement again, wait after playback is completed, then scroll to >Play annc and press

MENU/SELECT.

Answering system

Answering system settings

To delete your outgoing announcement:

1. When the handset is in idle mode, press MENU/SELECT to enter the main menu.

2. Press qCID or pDIR to scroll to >Answering sys, then press MENU/SELECT.

3. Press

4. Press

5. While the announcement is playing, press MUTE/DELETE to delete the

When your announcement is deleted, the system answers calls with the default announcement described on the previous page. You cannot delete the default announcement.

Answer on/off

Unless you change it, the answering system is on and ready to record messages. You can turn the answering system off, but if you do so, the answering system does not answer calls and record incoming messages.

To turn the answering system on or off:

Using the telephone base:

•

Using a handset:

1. When the handset is in idle mode, press MENU/SELECT to

2. Press qCID or pDIR to scroll to >Answering sys, then

3. Press qCID or pDIR to scroll to >Answer ON/OFF, then

4. Press qCID or pDIR to highlight >On or >Off, then press

When the answering system is on, the handset screen shows ANS ON.

MENU/SELECT again to select >Announcement. MENU/SELECT again to select >Play annc and play the announcement.

announcement. The system announces “Announcement deleted”.

Press

/ANSWER ON to turn the answering system on

or off. If the answering system is turned on, it announces, “Calls will be answered.” If the answering system is turned

Play messages >Answering sys

off, it announces, “Calls will not be answered.”

Record memo >Answer ON/OFF

enter the main menu.

press MENU/SELECT.

MENU/SELECT to save the setting. You hear a confirmation

ANSWER ON/OFF >On

tone. Press OFF/CANCEL to cancel.

p q

NOTE: If the answering system is off and there is an incoming call, the system answers after 10 rings and announces, “Please enter your remote access code.” For more information about remote access codes, see

page 56.

Answering system

Answering system settings

Call screening

Use this feature to choose whether incoming messages can be heard over the telephone base speaker when they are being recorded. If you turn call screening on, you hear the incoming message. While monitoring an incoming message, you can answer the call by pressing on the handset.

To change the setting:

1. When the handset is in idle mode, press MENU/ enter the main menu.

2. Press qCID or pDIR to scroll to >Answering sys, then press MENU/SELECT.

3. Press qCID or pDIR to scroll to >Ans sys setup, then press MENU/SELECT.

4. Press MENU/SELECT to select >Call screening.

5. Press qCID or pDIR to choose >On or >Off.

6. Press MENU/SELECT to save the setting. You hear a confirmation tone. Press OFF/CANCEL to cancel.

PHONE/FLASH or /SPEA�ERSPEA�ER

Play messages >Answering sys

p q

SELECT to

Answer ON/OFF

>Ans sys setup

p q

Call screening

# of rings

p q

NOTE: For more information on call screening, see page 50.

CALL SCREENING >On

p q

Number of rings

You can set the answering system to answer an incoming call after two, three, four, five or six rings. You can also select toll saver, which is explained below. Unless you change it, the answering system answers an incoming call after four rings.

Call screening

># of rings

p q

To set the number of rings:

1. When the handset is in idle mode, press MENU/SELECT to enter the main menu.

2. Press qCID or pDIR to scroll to >Answering sys, then press

# OF RINGS

p q

MENU/SELECT.

3. Press qCID or pDIR to scroll to >Ans sys setup, then press MENU/SELECT.

4. Press qCID or pDIR to scroll to ># of rings, then press MENU/SELECT. You hear a confirmation tone. Press OFF/CANCEL to cancel.

Answering system

Answering system settings

5. Press qCID or pDIR to scroll and choose among 2, 3, 4, 5, 6 or Toll saver.

Toll saver - the answering system answers a call after two rings if

•

you have new messages, and after four rings when there are no new messages. This feature allows you to check for new messages and avoid paying long distance charges when calling from out of your local area.

6. Press MENU/SELECT to save the setting. You hear a confirmation tone. Press OFF/CANCEL to cancel.

NOTES:

If you subscribe to voicemail service through your telephone service provider, see Answering

• system and voicemail indicators on

If you set the number of rings for the answering system as 2 or 3 rings, the caller ID announce

• feature may not have enough time to announce the caller’s full information.

Remote access code

To access your answering system remotely from any touchtone phone, you need to enter a two-digit number (00-99). Unless you change it, the remote access code is 19.

To change the remote access code:

1. When the handset is in idle mode, press MENU/SELECT to enter the main menu.

2. Press qCID or pDIR to scroll to >Answering sys, then press MENU/SELECT.

3. Press qCID or pDIR to scroll to >Ans sys setup, then press MENU/SELECT.

4. Press qCID or pDIR to scroll to >Remote code, then press

MENU/SELECT.

5. Use the dialing keys to enter a two-digit number. Use

MUTE/DELETE to backspace and delete a digit.

6. Press MENU/SELECT to save the setting. You hear a confirmation tone. Press

OFF/CANCEL to cancel.

page 49.

Play messages >Answering sys

p q

Answer ON/OFF >Ans sys setup

p q

REMOTE CODE

Answering system

Answering system settings

Message alert tone

When the message alert tone is set to On, and there is at least one new message, the telephone base beeps every 10 seconds. Unless you change it,

the message alert tone is set to off.

There is no audible alert at the handset.

To change the setting:

1. When the handset is in idle mode, press MENU/SELECT to enter the main menu.

2. Press qCID or pDIR to scroll to >Answering sys, then press MENU/SELECT.

3. Press qCID or pDIR to scroll to >Ans sys setup, then press MENU/SELECT.

4. Press qCID or pDIR to scroll to >Msg alert tone, then press MENU/SELECT.

5. Press qCID or pDIR to choose >On or >Off.

6. Press MENU/SELECT to save the setting. You hear a confirmation tone. Press OFF/CANCEL to cancel.

NOTES:

The message alert tone beeps only if all the conditions below are met:

•

- Answering system is on.

- Message alert tone setting is on.

- There are new messages. To temporarily turn off the message alert tone, see

•

page 51.

Remote code

Msg alert tone

p q

MSG ALERT TONE >On

p q

Message recording time

You can set the recording time allowed for incoming messages. The message length is three minutes by default.

To change the setting:

Msg alert tone

>Recording time

p q

1. When the handset is in idle mode, press MENU/SELECT to enter the main menu.

2. Press qCID or pDIR to scroll to >Answering sys, then press MENU/SELECT.

RECORDING TIME >3 minutes

p q

3. Press qCID or pDIR to scroll to >Ans sys setup, then press MENU/SELECT.

4. Press qCID or pDIR to scroll to >Recording time, then press MENU/SELECT.

5. Press q

CID or pDIR to choose >3 minutes, >2 minutes, or >1 minute, then

press MENU/SELECT to save the setting. You hear a confirmation tone. Press

OFF/CANCEL to cancel.

Answering system

About the answering system

Answering system and voicemail indicators

Your telephone has separate indicators for two different types of voice messages: those left on its built-in digital answering system and those left at your telephone service provider’s voicemail

(fees may apply). Your telephone’s built-in digital answering system messages and voicemail messages are separate. Each alerts you to new messages differently.

•

and XX New messages show on the handset

and the message window on the telephone base flashes, there are new messages in the built-in answering system. To listen to messages recorded on

your digital

answering system, press /PLAY/STOP

on the telephone base (page 52). If

•

and New voicemail display on the handset, your telephone service

provider is indicating that it has new voicemail for you. To listen to your voicemail, you typically dial an access number provided by your telephone service provider, followed by a security code or PIN.

Some telephone service providers bundle or combine multiple services like voicemail and call waiting, so you may not be aware that you have voicemail. To check what services you have and how to access them, contact your telephone service provider.

HANDSET 1

1 New message

ANS ON

10/15

10:01

To use your voicemail service rather than your answering system, turn off your answering system. To use your answering system rather than your voicemail service, contact your telephone service provider to deactivate your voicemail service.

NOTE: After reviewing all new messages, the number of old messages appears on the message window.

Using the answering machine and voicemail together

You can also use your telephone answering system and voicemail together by setting your built-in answering system to answer before voicemail answers as described below. To learn how to program your voicemail settings, contact your telephone service provider. Then, if you are on a call, or if the answering system is busy recording a message and you receive another call, the second caller can leave a voicemail message.

Set your answering system to answer calls at least two rings earlier than your voicemail is set to answer. For example, if your voicemail answers after six rings, set your answering system to answer after four rings. Some voicemail providers may program the delay before answering calls in seconds instead of rings. In this case, allow six seconds per ring when determining the appropriate setting.

Answering system

About the answering system

Message capacity

The answering system can record up to 99 messages, depending on the length

of each message. Individual messages can be up to three minutes, and the maximum recording time is approximately 14 minutes. The actual recording time depends on individual message characteristics. Messages remain available for replay until you delete them.

When there are new messages (including memos) on the answering system, the number of messages stored flashes in the message counter.

If the answering system has less than three minutes of recording time left, it announces, “Less than three minutes to record,” before message playback at the handset or the telephone base. Rec mem low displays on the handset screen in idle mode. When you turn on the answering system at the telephone base, it announces, “Calls will be answered. Less than three minutes to record.”

If the memory is full, the answering system announces, “Memory is full,” before message playback. The handset screen displays Rec mem full in idle mode and the number of messages and F flash alternately in the message counter at the telephone base. You cannot turn on the answering system and record new messages until old ones have been deleted. Memory full displays if you want to turn on the answering system on the handset but there is no memory.

Voice prompts

The system provides voice prompts to guide you through the setup procedures at the telephone base, message playback, remote access and recording outgoing announcements.

Call screening at the telephone base

If the answering system and call screening are on, the announcement and the incoming message broadcast at the telephone base when a call is answered at the telephone base.

You can turn call screening on or off using the handset (see

call screening is off, you can temporarily turn on call screening by pressing

p/VOL on the telephone base. Call screening will be off for the next

incoming call.

If call screening is on and you want to silence the telephone base while it is

recording messages, press

/PLAY/STOP.

page 46). When

Answering system

About the answering system

Call intercept

While screening a call, you can stop recording and speak to the caller by

pressing

Base ringer

Press q/VOL/p on the telephone base to adjust the ringer volume when

the telephone is not in use.

You hear a sample of the ringer while adjusting the volume. The telephone

base announces, “Base ringer is off,” when you set the volume to 0.

Temporarily turning off the message alert tone

If the new message alert tone is turned on, the telephone base beeps every

10 seconds when there are new or missed messages. Pressing any telephone

base key (except

alert tone.

If you press X/DELETE when in idle mode to temporarily turn off the

message alert tone, there is a voice prompt directing you to press X/DELETE

again to delete all old messages. The message alert tone is temporarily off.

Only press X/DELETE a second time if you wish to erase all old messages in

your answering system.

PHONE/FLASH or /SPEA�ERSPEA�ER on the handset.

/HANDSET LOCATOR) temporarily silences the message

The message alert tone resumes when you receive another message.

Answering system

Message playback

If you have new messages, you hear only the new messages in chronological

order. If there are no new messages, the system plays back all the messages

(in chronological order).

When playback begins, the total number of messages is announced. Before

each message, you hear the day and time of the recording. If the date and time

are not set, you hear, “Time and date not set,” before playback. After the last

message, you hear, “End of messages.” If the recording time is less than three

minutes, you hear, “Less than three minutes to record,” (see Message capacity

page 50).

To listen to messages at the telephone base:

Press

/PLAY/STOP on the telephone base to listen to the

messages. The system announces the number of messages,

then begins playback. Press

/PLAY/STOP again to end the

message playback.

To listen to messages on a cordless handset:

1. When the handset is in idle mode, press MENU/SELECT to

enter the main menu.

2. Press MENU/SELECT again to select >Play messages.

If there are new and old messages, press q

•

CID or pDIR

to select >Play new msgs or >Play old msgs, then press

MENU/SELECT.

•

If there are only new messages, they will play automatically.

The system announces the number of messages, then begins

playback. The message sequence is shown on the handset

screen. If there are no recorded messages, the handset

screen shows No message and you hear, “You have no message.”

>Play messages

Answering sys

p q

>Play new msgs

Play old msgs

3 New messages

ANS ON

MSG#

1/3

ANS ON

10:01

10/15

Charlie Johnson 4-Repeat 6-Skip

Options during playback

When a message is playing, you can adjust the playback volume, skip, repeat or

delete the message.

When messages are playing on the telephone base:

Press q/VOL/p to adjust the message playback volume.

•

Press

•

Press

/S�IP to skip to the next message. /REPEAT to repeat the message. Press twice to hear the

previous message.

•

Press X/DELETE to delete the message.

•

Press

/PLAY/STOP to stop the playback.

Answering system

Message playback

When messages are playing on the handset:

•

Press press MENU/SELECT, PHONE/FLASH, or /SPEA�ERSPEA�ER to call back the caller.

•

Press if available. From here, you can press OFF/CANCEL to resume playback

or press PHONE/FLASH or /SPEA�ERSPEA�ER to call back the caller. If you do not call back within 10 seconds, message playback resumes automatically.

•

Press qCID/VOLUME or pDIR/VOLUME to adjust the message playback volume.

•

Press EQ

•

Press 6 to skip to the next message.

•

Press 4 to repeat the message. Press twice to hear the previous message.

•

Press

•

Press 5 to stop the playback.

•

Press

PHONE/FLASH to stop playback. The screen shows Call back?, then

MENU/SELECT to pause playback and show the caller ID information

to adjust the message playback audio quality.

MUTE/DELETE to delete the message.

/SPEA�ERSPEA�ER to switch between speakerphone mode and handset mode.

NOTE: The equalizer stays on the same settings until you change it by pressing EQ .

Delete all old messages

You can only delete old (reviewed) messages. You cannot delete new messages

until you review them. You cannot retrieve deleted messages.

To delete all old messages on the telephone base:

1. When the telephone is idle, press X/DELETE. The system

announces, “To delete all old messages, press

Announcement >Delete all old

p q

DELETE again.”

2. Press X/DELETE again. The system announces, “All old

messages deleted.”

To delete all old messages on the handset:

Delete all

old messages?

1. Press MENU/SELECT when in idle mode to enter the

main menu.

2. Press qCID or pDIR to scroll to >Answering sys. Press

MENU/SELECT.

Deleting...

3. Press qCID or pDIR to highlight Delete all old, then press

MENU/SELECT. The screen shows Delete all old messages?

4. Press MENU/SELECT again to confirm. The screen displays Deleting... then All old msgs deleted! There is a confirmation tone.

Answering system

Recording and playing memos

Memos are messages you record at a handset. You can record, playback and delete them like incoming messages. You can record a memo as a reminder to yourself, or leave a message for others who use the answering system.

Record a memo

1. When the handset is in idle mode, press MENU/SELECT to enter the main menu.

2. Press qCID or pDIR to scroll to >Answering sys. Press

MENU/SELECT.

3. Press qCID or pDIR to highlight Record memo, then press

MENU/SELECT. The system announces, “Record after the

tone. Press 5 when you are done.” You can record a memo

for up to four minutes.

4. Speak facing the handset to record a memo.

5. Press 5 to stop recording. The system announces, “Recorded.” The system does not save memos shorter than two seconds.

Play back a memo Play memos the same way as messages. See Message playback on

Play messages >Answering sys

p q

Delete all old >Record memo

p q

Record memo... 5-Stop

page 52.

Answering system

Base message counter displays

The base message counter shows the total number of answering system messages. See the table below for other message counter displays.

Message counter displays

0 (flashing)

1-99

1-99 (flashing)

1-99 & F (alternating)

- -

0-6

1-8

No messages.

You need to set the clock (page 12).

Total number of old messages and memos, or message number currently playing during old message playback.

Total number of messages and memos. The number flashes when there are new or missed messages.

After a power failure, the number in the message counter flashes to indicate that you need to set the clock.

Memory is full. You must delete some messages before recording new messages.

The system is answering a call, or someone is trying to reach it remotely.

The system is in program mode.

Shows for two seconds while adjusting the telephone base ringer volume.

Shows for two seconds while adjusting the telephone base speaker volume.

Answering system

Remote access

You can reach your answering system remotely by dialing your home telephone number from any touch-tone telephone.

To remotely reach your answering system:

1. Dial your telephone number from any touch-tone telephone.

2. When the system answers, enter the two-digit remote access code (19 is the default code. See page 47 to change it).

The system automatically announces the number of new and/or old

•

messages (if any), and then begins to play them.

3. You can also enter the following remote commands:

Remote commands

Press to listen to all messages.

Press to listen to new messages only.

Press to delete the current message (during playback).

4. Hang up or press 8 to end the call and save all undeleted messages.

Press twice to delete all old messages.

Press to repeat the current message (during playback).

Press twice to listen to the previous message.

Press to stop any operation (including recording).

Press to listen to a list of remote commands.

Press to skip to the next message (during playback).

Press to record a new announcement.

Press to end remote access (the call will be terminated).

Press to turn the answering system on or off.

Answering system

Remote access

Cut out and carry the remote access wallet card at the back of this user’s manual for quick reference.

NOTES:

•

If you do not enter a valid remote access code, the system answers the call automatically.

•

If you pause for more than four seconds during remote access, you hear a help menu listing all features and commands. If there is no command for another 20 seconds, the call ends automatically.

•

If the memory is full, the answering system answers after 10 rings and announces, “Memory is full. Enter the remote access code.” Enter your remote access code to access the messages and announcements.

Appendix

Adding and registering handsets

Your telephone can support up to 12 cordless handsets (AT&T model CL80101, sold separately). The handset must be registered to the telephone base before use. You must

Put HS on BASE

to register

The handsets provided within your product box are already registered as HANDSET 1 and so forth. Additional handsets are assigned numbers in the sequential order they are registered (up to HANDSET 12).

Register a handset to your telephone base

1. Make sure the handset is out of the telephone base or charger and shows Put HS on BASE to register before you begin registration.

Put the handset you wish to register on the telephone

Registering...

Please wait

base cradle.

3. The screen shows Registering... Please wait and the IN USE light turns on. It takes up to 90 seconds to complete registration. Then HANDSET X Registered

HANDSET X

Registered

appears on the screen, with HANDSET being the handset name and X being the handset number (1-12). The handset beeps and the IN USE light turns off. The handset is now registered with the telephone base.

If registration fails, the system will automatically try to register again. If registration fails after the third try, Registration failed appears on the screen for a few seconds, and then Put HS on BASE to register. This may take up to five minutes to occur. Please start again from Step 1 above.

Appendix

Deregistering handsets

You may need to deregister your handsets if:

•

You have 12 registered handsets and need to replace a handset.

-OR-

•

You wish to change the designated handset number of your registered handsets.

You must first deregister ALL the handsets, and then register each handset you wish to use again, one at a time.

Please read carefully through all the instructions on this page before beginning the deregistration process.

Deregister all handsets from your telephone base

1. Make sure that all handsets are out of the telephone base and chargers before you begin deregistraton.

2. Press and hold /HANDSET LOCATOR on the telephone base for about 10 seconds (until the IN USE light starts to flash), then release the

/HANDSET LOCATOR button.

3. Immediately press /HANDSET LOCATOR while the IN USE light is still flashing. (The light flashes for about seven seconds. If the light stops flashing, start again with Step 1 above.)

4. It takes up to 10 seconds to complete the deregistration process. Wait for the cordless handset screen to display Put HS on BASE to register before registering the handset again.

5. To register the handset(s) to the telephone base again, follow the registration instructions on the previous page.

NOTES:

If the deregistration process is not successful, you might need to reset the system and try again. To

• reset, unplug the power from the telephone base and plug it back in.

You cannot deregister the handset(s) if any other system handset is in use.

• Even if the battery is depleted, you can still deregister the handset by following the steps above.

• After the handset is charged for at least 10 minutes, the screen shows Put HS on BASE to register.

Appendix

Alert tones and lights

Screen icons

Battery status - battery is charging (animated display).

Battery status - low battery (flashing); place handset in

telephone base or charger to recharge.

Speakerphone - the speakerphone is in use.

1/2

ANS ON

MSG #

10:21

Ringer off - the handset ringer is off.

New voicemail - you have new voicemail from your

telephone service provider.

ANS ON

Answering system on - the answering system is turned on

to answer calls.

Message - new message in the built-in answering system.

NEW

MUTE

MSG #

1/2

New caller ID log - new or missed calls.

MUTE - the handset microphone is off.

Message counter - number of message playing/total

number of messages.

Handset alert tones

One short beep Tone of each key press, if key tone is turned on.

One long beep Indication to begin recording a message, memo or announcement.

Two short beeps

Confirmation tone (three rising tones)

Four beeps The other party has ended your intercom call.

Four short beeps Low battery warning.

You are pressing qCID or pDIR on a cordless handset when the volume is already at its highest or lowest setting.

-OR-

Call waiting tone.

-OR-

Error tone.

The system has completed the command successfully.

-OR-

The handset has gone out of range from the base during a call.

NEW MUTE

Telephone base tones

Beeps every 10 seconds Message alert.

Fast ringer tone

Long beep Indicates the start of message recording during call screening or

Four short beeps Registration failure tone.

You are setting the ringer volume by pressing the q/VOL/p keys on the telephone base.

the end of a message playback session.

Appendix

Alert tones and lights

Lights

/ANSWER ON

On when the answering system is on.

IN USE

On when the handset is in use, or when the answering system is answering an incoming call.

On when a handset is being registered. Flashes when there is an incoming call or when a handset is

being deregistered.

Flashes when another telephone is in use on the same line.

CHARGE

On when the handset is charging in the telephone base or charger.

Lighted display

Lighted key pad

/SPEA�ERSPEA�ER

On when the speakerphone is on.

Appendix

Handset display screen messages

Screen display messages

Caller ID log empty

Call transferred

Calling HANDSET X

(for systems with three or more handsets)

Calling other handset

(for systems with two handsets)

Contact deleted

Directory empty

Directory full

Ended

HANDSET X is calling

(for systems with three or more handsets)

Incoming call

Intercom

Intercom ended

INTERCOM TO:

(for systems with three or more handsets)

Line in use

Low battery

Microphone ON

Muted

New voicemail

No battery

No line

No answer. Try again

There are no entries in the caller ID history.

You have transferred an outside call to another cordless handset.

The handset is calling another handset (for intercom calls).

The handset is transferring an outside call to another handset.

The handset is calling the other handset (for intercom calls).

The handset is transferring an outside call to the other handset.

A directory entry is deleted.

There are no directory entries.

The directory is full. You cannot save any new entries unless you delete some current entries.

You have just ended a call.

Another system handset is calling.

There is a call coming in.

The handset is on an intercom call.

The intercom call has just ended.

You have started the intercom process, and need to enter the number of the handset you wish to call.

An extension phone, or one of the handsets is in use.

The battery is low. You should charge the battery.

Mute is off so the other party can hear your voice.

The microphone is off. The other party cannot hear you.

There are new voicemail messages from your telephone service provider.

The handset in the charger has no battery installed.

There is no telephone line connection.

The handset(s) you are trying to transfer a call to is out of range, off hook, or has no power.

Appendix

Handset display screen messages

Screen display messages

Number already saved

Not available at this time

Other handset is calling

(for systems with two handsets)

Out of range OR No pwr at base

** Paging **

Phone

Place in charger

Put HS on BASE to register

Rec mem full

Rec mem low

Registering... Please wait

Registration failed

Ringer off

Ringer muted

Saved

Speaker

TRANSFER TO:

(for systems with three or more handsets)

Unable to call. Line in use

Unable to call. Try again

XX Missed calls

XX New messages

The telephone number you have entered is already in the directory.

Someone else is already using the directory or caller ID history.

The other handset is calling.

The telephone base has lost power, or the handset is out of range.

The cordless handset is paged by the telephone base.

The handset is on a call.

The battery is very low. The handset should be charged.

Screen display before handset registration.

The system recording time is full.

The system recording time is low.

The handset is registering to the telephone base.

The handset registration is not successful.

The ringer is turned off.

The ringer is off temporarily while the handset is ringing.

An entry has been successfully saved in the directory.

The handset speakerphone is in use.

You have started transferring a call, and need to enter the desired handset number or choose all handsets.

Failed phone call (the telephone line is in use).

You try to join a call when there are already four handsets on that call.

You try to make an outside call when another handset is transferring a call with the intercom feature.

There are new calls in the caller ID history.

There are new messages in the answering system.

Appendix

Troubleshooting

If you have difficulty with your phone please try the suggestions below. For Customer Service, visit our website at www.telephones.att.com or call

1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

My telephone doesn’t work at all.

•

Make sure the power cord is securely plugged in.

•

Make sure you plug the battery connector securely into the cordless handset.

•

Make sure you plug the telephone line cord securely and firmly into the telephone base and the telephone wall jack.

•

Charge the battery in the cordless handset for at least 10 hours. For optimum daily performance, return the cordless handset to the telephone base or charger when not in use.

•

If the battery is depleted, it might take approximately 30 minutes to charge the handset before it shows Low battery. See

•

Reset the telephone base. Unplug the electrical power. Wait for approximately 15 seconds, then plug it back in. Allow up to one minute for the cordless handset and telephone base to reset.

•

You may need to purchase a new battery. Please refer to Battery installation and charging in this user’s manual on pages 6-7.

page 6 for details.

I cannot get a dial tone.

•

Try all the suggestions above.

•

Move the cordless handset closer to the telephone base. You might have moved out of range.

•

If the previous suggestions do not work, disconnect the telephone base from the telephone jack and connect to a different phone. If there is no dial tone on that phone either, the problem is in your wiring or telephone service. Contact your telephone service provider.

•

Your line cord might be malfunctioning. Try installing a new line cord.

I cannot dial out.

•

Try all the suggestions above.

•

Make sure you have a dial tone before dialing. The cordless handset might take a second or two to find the telephone base and produce a dial tone. This is normal. Wait an extra second before dialing.

•

Eliminate any background noise. Noise from a television, radio or other appliances might cause the phone to not dial out properly. If you cannot eliminate the background noise, first try muting the cordless handset before dialing, or dialing from another room with less background noise.

•

If other phones in your home are having the same problem, contact your telephone service provider (charges might apply).

Appendix

Troubleshooting

My cordless handset isn’t performing normally.

•

Make sure you plug the power cord securely into the telephone base. Plug the power adapter into a different, working electrical outlet without a wall switch.

•

Move the cordless handset closer to the telephone base. You might have moved out of range.

•

Reset the telephone base. Unplug the electrical power. Wait for 15 seconds then plug it back in. Allow up to one minute for the cordless handset and telephone base to reset.

•

Other electronic products such as HAM radios and other DECT phones can cause interference with your cordless phone. Try installing your phone as far away as possible from these types of electronic devices.

Out of range OR No pwr at base appears on my cordless handset.

•

Ensure you plug the telephone base in properly and the power is on.

•

Place the cordless handset in the telephone base for one minute to allow the cordless handset and base to synchronize.

•

Move the cordless handset closer to the telephone base. You might have moved out of range.

•

Reset the telephone base. Unplug the electrical power. Wait for 15 seconds then plug it back in. Allow up to one minute for the cordless handset and telephone base to reset.

•

The batteries do not hold a charge.

•

If the cordless handset is in the telephone base or charger and the charge light is not on, refer to The charge light is off or blinking (

•

Charge the battery in the cordless handset for at least 10 hours. For optimum daily performance, return the cordless handset to the telephone base or charger when not in use.

•

If the battery is depleted, it might take approximately 30 minutes to charge the handset before it shows Low battery. Refer to the table on page 6 for details.

•

You might need to purchase a new battery. Please refer to Battery installation and charging in this user’s manual on pages 6-7.

page 68).

Appendix

Troubleshooting

I get noise, static, or weak signals even when I’m near the telephone base.

•

If you subscribe to high-speed Internet service (DSL - digital subscriber line) through your telephone line, you must install a DSL filter between the telephone line cord and the telephone wall jack (see prevents noise and caller ID problems as a result of DSL interference. Please contact your DSL service provider for more information about DSL filters.

•

You may be able to improve the performance of your cordless phone by installing your new telephone base as far as possible from any other existing cordless telephone system that may already be installed.

•

Do not install this phone near a microwave oven or on the same electrical outlet. You might experience decreased performance while the microwave oven is operating.

•

If you plug your phone in with a modem or a surge protector, plug the phone (or modem/surge protector) into a different location. If this does not solve the problem, relocate your phone or modem farther apart from one another, or use a different surge protector.

•

Move your phone to a higher location. The phone might have better reception in a high area.

•

If other phones in your home are having the same problem, contact your telephone service provider (charges may apply).

page 5). The filter

I experience poor sound quality when using the speakerphone.

•

For increased sound quality while using the speakerphone, place the handset on a flat surface with the dial pad facing up.

I hear other calls while using my phone.

•

Disconnect the telephone base from the telephone jack, and plug in a different telephone. If you still hear other calls, call your telephone service provider.

My cordless handset does not ring when I receive a call.

•

Make sure that the ringer is not off. Refer to Ringer volume on this user’s manual.

•

Make sure you plug in the telephone line cord securely into the telephone base and the telephone jack. Make sure you plug in the power cord securely.

•

The cordless handset may be too far from the telephone base.

page 11 in

Appendix

Troubleshooting

•

Charge the battery in the cordless handset for at least 10 hours. For optimum daily performance, return the cordless handset to the telephone base or charger when not in use.

•

You may have too many extension phones on your telephone line to allow all of them to ring simultaneously. Try unplugging some of the other phones.

•

The layout of your home or office might be limiting the operating range. Try moving the telephone base to another location, preferably to a higher location.

•

If other phones in your home are having the same problem, contact your telephone service provider (charges might apply).

•

Test a working phone at the phone jack. If another phone has the same problem, contact your telephone service provider (charges might apply).

•

Other electronic products can cause interference with your cordless phone. Try installing your phone as far away as possible from electronic devices such as television sets, VCRs, or other cordless telephones.

•

Completely remove the battery. Install the battery again and place the cordless handset into the telephone base. Wait for the cordless handset to reestablish its connection with the telephone base. Allow up to one minute for this to take place.

•

Your line cord might be malfunctioning. Try installing a new line cord.

My calls cut in and out while I’m using my cordless handset.

•

Do not install this phone near a microwave oven or on the same electrical outlet. You might experience decreased performance while the microwave oven is operating.

•

If you plug your phone in with a modem or surge protector, plug the phone (or modem/surge protector) into a different location. If this does not solve the problem, relocate your phone or modem farther apart from one another, or use a different surge protector.

•

Move your telephone base to a higher location. The phone might have better reception when installed in a high area.

•

If other phones in your home are having the same problem, contact your telephone service provider (charges may apply).

Appendix

Troubleshooting

The charge light is off or blinking.

Make sure you plug the power and line cords in correctly and securely.

•

Unplug the electrical power. Wait for 15 seconds, then plug it back in. Allow

•

up to one minute for the cordless handset and telephone base to reset.

•

Clean the cordless handset, charger and telephone base charging contacts each month with a pencil eraser or cloth.

•

A blinking CHARGE light is an indication that the battery is not connected to the handset or is missing completely. Ensure that the battery is installed properly.

My caller ID isn’t working.

Caller ID is a subscription service. You must subscribe to this service from

•

your telephone service provider for this feature to work on your phone. The caller must be calling from an area that supports caller ID.

•

Both your and your caller’s telephone service providers must use caller ID compatible equipment.

•

If you subscribe to high-speed Internet service (DSL - digital subscriber line) through your telephone line, you must install a DSL filter between the telephone line cord and the telephone wall jack ( noise and caller ID problems resulting from DSL interference. Please contact your DSL service provider for more information about DSL filters.

page 5). The filter prevents

System does not receive caller ID when on a call.

•

Make sure you subscribe to caller ID with call waiting features from your telephone service provider. Caller ID features works only if both you and the caller are in areas offering caller ID service, and if both telephone service providers use compatible equipment.

Incomplete messages.

•

If a caller leaves a very long message, part of it may be lost when the system disconnects the call after the maximum recording time you have set.

•

If the caller pauses for longer than seven seconds, the system stops recording and disconnects the call.

•

If the system’s memory becomes full during a message, the system stops recording and disconnects the call.

•

If the caller’s voice is very soft, the system may stop recording and disconnect the call.

Difficulty hearing messages.

•

Press VOL/p to increase the telephone base speaker volume.

•

Press p

DIR/VOLUME to adjust the message playback volume on a handset.

Appendix

Troubleshooting

System does not answer after the correct number of rings.

• Make sure that the answering system is on. ANS ON should show on the handset and the /ANSWER ON light on the telephone base should be on.

• If toll saver is activated, the number of rings changes to two when you have new messages stored (pages 46-47).

• If the memory is full or the system is off, the system will answer after 10 rings.

•

In some cases, the answering system is affected by the ringing system used by your telephone service provider.

•

If you subscribe to voicemail service, change the number of rings so that your answering system answers before your voicemail answers (pages 46-47). To determine how many rings activate your voicemail, contact your telephone service provider.

•

If there is a fax machine connected to the same telephone line, try disconnecting the fax machine. If that solves the problem, consult your fax machine documentation for information on compatibility with answering systems.

System does not respond to remote commands.

• Make sure to enter your remote access code correctly (page 47).

• Make sure you are calling from a touch-tone phone. When you dial a number, you should hear tones. If you hear clicks, the phone is not a touch-tone telephone and cannot activate the answering system.

• The answering system may not detect the remote access code while your announcement is playing. Try waiting until the announcement is over before entering the code.

• There may be interference on the phone line you are using. Press dialing keys firmly.

System does not record messages.

• Make sure the answering system is on. ANS ON should show on the handset and the /ANSWER ON light on the telephone base should be on.

• Make sure the memory of the answering system is not full.

•

Appendix

Troubleshooting

System announces, “Time and day not set.”

• You need to reset the system clock (page 12).

Outgoing announcement is not clear.

• When you record your announcement, make sure you speak in a normal tone of voice, about nine inches from the handset.

• Make sure there is no background noise (TV, music, etc.) while recording.

New voicemail and show on the handset display, and I don’t know why.

•

Your telephone has both a built-in answering system and voicemail indication. If New voicemail and appear on the handset display, then your telephone has received a signal from your telephone service provider that you have a voicemail message waiting for you to retrieve from them. Contact your telephone service provider for more information on how to access your voicemail.

I cannot retrieve voicemail messages.

•

Your telephone has both a built-in answering system and voicemail indication. They are independent features and each alerts you to new messages differently (page 49). If you subscribe to voicemail service from your telephone service provider, contact your telephone service provider for more information on how to access your voicemail.

I subscribe to a nontraditional telephone service that uses my computer to establish connections, and my telephone doesn’t work.

Make sure your computer is powered on.

•

Make sure your Internet connection is working properly.

•

Make sure that the software is installed and running for your nontraditional

•

telephone service.

Make sure to plug your USB telephone adapter into a dedicated USB

•

port on your computer. Do not plug it into a multiple port USB hub (USB splitter) that is not powered.

In a few rare instances, the USB port on your computer may not have

•

enough power. Try using a USB hub with its own external power supply.

If you are using a firewall, it may prevent access to your nontraditional

•

telephone service provider. Contact your service provider for more information.

Appendix

Troubleshooting

Common cure for electronic equipment.

If the telephone does not seem to be responding normally, try putting the cordless handset in the telephone base or charger. If it does not fix the problem, do the following (in the order listed):

Disconnect the power to the telephone base.

Disconnect the cordless handset battery.

Wait a few minutes.

Connect power to the telephone base.

Completely remove the battery. Replace the battery and place the

cordless handset into the telephone base or charger.

Wait for the cordless handset to reestablish its connection with the

telephone base. Allow up to one minute for this to take place.

Appendix

Maintenance

Taking care of your telephone

•

Your cordless telephone contains sophisticated electronic parts, so you must treat it with care.

•

Avoid rough treatment.

•

Place the handset down gently.

•

Save the original packing materials to protect your telephone if you ever need to ship it.

Avoid water

•

You can damage your telephone if it gets wet. Do not use the handset in the rain, or handle it with wet hands. Do not install the telephone base near a sink, bathtub or shower.

Electrical storms

•

Electrical storms can sometimes cause power surges harmful to electronic equipment. For your own safety, take caution when using electric appliances during storms.

Cleaning your telephone

•

Your telephone has a durable plastic casing that should retain its luster for many years. Clean it only with a soft cloth slightly dampened with water or mild soap.

•

Do not use excess water or cleaning solvents of any kind.

Remember that electrical appliances can cause serious injury if used when you are wet or standing in water. If the telephone base should fall into water, DO NOT RETRIEVE IT UNTIL YOU UNPLUG THE POWER CORD AND TELEPHONE LINE CORDS FROM THE WALL. Then pull the unit out by the unplugged cords.

Appendix

Important safety information

This symbol is to alert you to important operating or servicing instructions that may appear in this user’s manual. Always follow basic safety precautions when using this product to reduce the risk of injury, fire, or electric shock.

Safety information

Read and understand all instructions in the user’s manual. Observe all markings on the product.

•

Avoid using a telephone during a thunderstorm. There may be a slight chance of electric

•

shock from lightning.

•

Do not use a telephone in the vicinity of a gas leak. Under certain circumstances, a spark may be created when the adapter is plugged into the power outlet, or when the handset is replaced in its cradle. This is a common event associated with the closing of any electrical circuit. The user should not plug the phone into a power outlet, and should not put a charged handset into the cradle, if the phone is located in an environment containing concentrations of flammable or flame-supporting gases, unless there is adequate ventilation. A spark in such an environment could create a fire or explosion. Such environments might include: medical use of oxygen without adequate ventilation; industrial gases (cleaning solvents; gasoline vapors; etc.); a leak of natural gas; etc.

•

Do not use this product near water, or when you are wet. For example, do not use it in a wet basement or shower, or next to a swimming pool, bathtub, kitchen sink, or laundry tub. Do not use liquids or aerosol sprays for cleaning. If the product comes in contact with any liquid, unplug any line or power cord immediately. Do not plug the product back in until it has dried thoroughly.

•

Install this product in a protected location where no one can trip over any line or power cords. Protect cords from damage or abrasion.

•

If this product does not operate normally, see the Troubleshooting section on pages 64-71 of this user’s manual. If you cannot solve the problem, or if the product is damaged, refer to the Limited warranty section on pages 77-78. Do not open this product except as directed in your user’s manual. Opening the product or reassembling it incorrectly may expose you to hazardous voltages or other risks.

•

Replace batteries only as described in your user’s manual (pages 6-7). Do not burn or puncture batteries — they contain caustic chemicals.

•

This power adapter is intended to be correctly oriented in a vertical or floor mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling or an under-the-table/cabinet outlet.

Caution: Use only the power adapter provided with this product. To obtain a replacement, visit our website at

1 (800) 222-3111.

www.telephones.att.com or call

In Canada, dial 1 (866) 288-4268.

Appendix

Important safety information

Especially about cordless telephones

Privacy: The same features that make a cordless telephone convenient create some limitations.

•

Telephone calls are transmitted between the telephone base and the handset by radio waves, so there is a possibility that your cordless telephone conversations could be intercepted by radio receiving equipment within range of the cordless handset. For this reason, you should not think of cordless telephone conversations as being as private as those on corded telephones.

•

Electrical power: The telephone base of this cordless telephone must be connected to a working electrical outlet which is not controlled by a wall switch. Calls cannot be made from the handset if the telephone base is unplugged, switched off or if the electrical power is interrupted.

•

Potential TV interference: Some cordless telephones operate at frequencies that may cause interference to TVs and VCRs. To minimize or prevent such interference, do not place the telephone base of the cordless telephone near or on top of a TV or VCR. If interference is experienced, moving the cordless telephone farther away from the TV or VCR will often reduce or eliminate the interference.

•

Rechargeable batteries: This product contains nickel-metal hydride rechargeable batteries. Exercise care in handling batteries in order not to create a short circuit with conductive material such as rings, bracelets and keys. The battery or conductor may overheat and cause harm. Observe proper polarity between the battery and the battery charger.

•

Nickel-metal hydride rechargeable batteries: Dispose of these batteries in a safe manner. Do not burn or puncture. Like other batteries of this type, if burned or punctured, they could release caustic material which could cause injury.

The RBRC™ Seal means that the manufacturer is voluntarily participating in an industry program to collect and recycle nickel-metal hydride rechargeable batteries when taken out of service within the United States. These batteries may be taken to a participating local retailer of replacement batteries or recycling center. Or you may call 1 (800) 8-BATTERY for locations accepting spent Ni-MH batteries.

Precautions for users of implanted cardiac pacemakers

Cardiac pacemakers (applies only to digital cordless telephones):

Wireless Technology Research, LLC (WTR), an independent research entity, led a multidisciplinary evaluation of the interference between portable wireless telephones and implanted cardiac pacemakers. Supported by the U.S. Food and Drug Administration, WTR recommends to physicians that:

Pacemaker patients

Should keep wireless telephones at least six inches from the pacemaker.

Should NOT place wireless telephones directly over the pacemaker, such as in a breast pocket, when it is turned ON.

Should use the wireless telephone at the ear opposite the pacemaker.

WTR’s evaluation did not identify any risk to bystanders with pacemakers from other persons using wireless telephones.

Especially about telephone answering systems

Two-way recording: This unit does not sound warning beeps to inform the other party that the call is being recorded. To ensure that you are in compliance with any federal or state regulations regarding recording a telephone call, you should start the recording process and then inform the other party that you are recording the conversation.

SAVE THESE INSTRUCTIONS

Appendix

FCC Part 68 and ACTA

This equipment complies with Part 68 of the FCC rules and with technical requirements adopted by the Administrative Council for Terminal Attachments (ACTA). The label on the back or bottom of this equipment contains, among other things, a product identifier in the format US:AAAEQ##TXXXX. This identifier must be provided to your telephone service provider upon request.

The plug and jack used to connect this equipment to premises wiring and the telephone network must comply with the applicable Part 68 rules and technical requirements adopted by ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. An RJ11 jack should normally be used for connecting to a single line and an RJ14 jack for two lines. See the installation instructions in the user’s manual.

The Ringer Equivalence Number (REN) is used to determine how many devices you may connect to your telephone line and still have them ring when you are called. The REN for this product is encoded as the 6th and 7th characters following the US: in the product identifier (e.g., if ## is 03, the REN is 0.3). In most, but not all areas, the sum of all RENs should be five (5.0) or less. For more information, please contact your telephone service provider.

This equipment may not be used with Party Lines. If you have specially wired alarm dialing equipment connected to your telephone line, ensure the connection of this equipment does not disable your alarm equipment. If you have questions about what will disable the alarm equipment, consult your telephone service provider or a qualified installer.

If this equipment is malfunctioning, it must be unplugged from the modular jack until the problem has been corrected. Repairs to this telephone equipment can only be made by the manufacturer or its authorized agents. For repair procedures, follow the instructions outlined under the Limited warranty.

If this equipment is causing harm to the telephone network, the telephone service provider may temporarily discontinue your telephone service. The telephone service provider is required to notify you before interrupting service. If advance notice is not practical, you will be notified as soon as possible. You will be given the opportunity to correct the problem and the telephone service provider is required to inform you of your right to file a complaint with the FCC. Your telephone service provider may make changes in its facilities, equipment, operation, or procedures that could affect the proper functioning of this product. The telephone service provider is required to notify you if such changes are planned.

If this product is equipped with a corded or cordless handset, it is hearing aid compatible.

If this product has memory dialing locations, you may choose to store emergency telephone numbers (e.g., police, fire, medical) in these locations. If you do store or test emergency numbers, please:

Remain on the line and briefly explain the reason for the call before hanging up.

Perform such activities in off-peak hours, such as early morning or late evening.

Industry Canada

Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference, including interference that may cause undesired operation.

The term ‘’IC:‘’ before the certification/registration number only signifies that the Industry Canada technical specifications were met.

The Ringer Equivalence Number (REN) for this terminal equipment is 0.1. The REN is an indication of the maximum number of devices allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the RENs of all the devices does not exceed five.

This product meets the applicable Industry Canada technical specifications.

Appendix

FCC Part 15

This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications to this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this telephone.

To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with the FCC criteria. The handset may be safely held against the ear of the user. The telephone base shall be installed and used such that parts of the user’s body other than the hands are maintained at a distance of approximately 20 cm (8 inches) or more.

This Class B digital apparatus complies with Canadian ICES-003.

Appendix

Limited warranty

The AT&T brand is used under license - any repair, replacement or warranty service, and all questions about this product should be directed to our website at www.telephones.att.com or

call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

What does this limited warranty cover?

The manufacturer of this AT&T branded product warrants to the holder of a valid proof of purchase (“CONSUMER” or “you”) that the product and all accessories provided in the sales package (“PRODUCT”) are free from defects in material and workmanship, pursuant to the following terms and conditions, when installed and used normally and in accordance with the PRODUCT operating instructions. This limited warranty extends only to the CONSUMER for products purchased and used in the United States of America and Canada.

What will be done if the PRODUCT is not free from defects in materials and workmanship

2. during the limited warranty period (“materially defective PRODUCT”)?

During the limited warranty period, the manufacturer’s authorized service representative will repair or replace at the manufacturer’s option, without charge, a materially defective PRODUCT. If the manufacturer repairs the PRODUCT, they may use new or refurbished replacement parts. If the manufacturer chooses to replace the PRODUCT, they may replace it with a new or refurbished PRODUCT of the same or similar design. The manufacturer will retain defective parts, modules, or equipment. Repair or replacement of the PRODUCT, at the manufacturer’s option, is your exclusive remedy. The manufacturer will return repaired or replacement products to you in working condition. You should expect the repair or replacement to take approximately 30 days.

How long is the limited warranty period?

The limited warranty period for the PRODUCT extends for ONE (1) YEAR from the date of purchase. If the manufacturer repairs or replaces a materially defective PRODUCT under the terms of this limited warranty, this limited warranty also applies to repaired or replacement PRODUCT for a period of either (a) 90 days from the date the repaired or replacement PRODUCT is shipped to you or (b) the time remaining on the original one-year limited warranty; whichever is longer.

What is not covered by this limited warranty?

This limited warranty does not cover:

PRODUCT that has been subjected to misuse, accident, shipping or other physical damage,

•

improper installation, abnormal operation or handling, neglect, inundation, fire, water, or other liquid intrusion; or

•

PRODUCT that has been damaged due to repair, alteration, or modification by anyone other than an authorized service representative of the manufacturer; or

•

PRODUCT to the extent that the problem experienced is caused by signal conditions, network reliability or cable or antenna systems; or

•

PRODUCT to the extent that the problem is caused by use with non-AT&T accessories; or

•

PRODUCT whose warranty/quality stickers, PRODUCT serial number plates or electronic serial numbers have been removed, altered or rendered illegible; or

•

PRODUCT purchased, used, serviced, or shipped for repair from outside the United States of America or Canada, or used for commercial or institutional purposes (including but not limited to products used for rental purposes); or

•

PRODUCT returned without valid proof of purchase (see item 6 below); or

•

Charges for installation or setup, adjustment of customer controls, and installation or repair of systems outside the unit.

Appendix

Limited warranty

5. How do you get warranty service?

To obtain warranty service, visit our website at

www.telephones.att.com or call

1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

NOTE: Before calling for service, please review the user’s manual; a check of the PRODUCT’s controls and features may save you a service call.

Except as provided by applicable law, you assume the risk of loss or damage during transit and transportation and are responsible for delivery or handling charges incurred in the transport of the PRODUCT(s) to the service location. The manufacturer will return repaired or replaced PRODUCT under this limited warranty to you. Transportation, delivery or handling charges are prepaid. The manufacturer assumes no risk for damage or loss of the PRODUCT in transit. If the PRODUCT failure is not covered by this limited warranty, or proof of purchase does not meet the terms of this limited warranty, the manufacturer will notify you and will request that you authorize the cost of repair prior to any further repair activity. You must pay for the cost of repair and return shipping costs for the repair of products that are not covered by this limited warranty.

6. What must you return with the PRODUCT to get warranty service?

You must:

•

Return the entire original package and contents including the PRODUCT to the service location along with a description of the malfunction or difficulty; and

•

Include a “valid proof of purchase” (sales receipt) identifying the PRODUCT purchased (PRODUCT model) and the date of purchase or receipt; and

•

Provide your name, complete and correct mailing address, and telephone number.

7. Other limitations

This warranty is the complete and exclusive agreement between you and the manufacturer of this AT&T branded PRODUCT. It supersedes all other written or oral communications related to this PRODUCT. The manufacturer provides no other warranties for this PRODUCT. The warranty exclusively describes all of the manufacturer’s responsibilities regarding the PRODUCT. There are no other express warranties. No one is authorized to make modifications to this limited warranty and you should not rely on any such modification.

State/Provincial Law rights: This warranty gives you specific legal rights, and you may also have other rights which vary from state to state or province to province.

Limitations: Implied warranties, including those of fitness for a particular purpose and merchantability (an unwritten warranty that the PRODUCT is fit for ordinary use) are limited to one year from date of purchase. Some states/provinces do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. In no event shall the manufacturer be liable for any indirect, special, incidental, consequential, or similar damages (including, but not limited to lost profits or revenue, inability to use the PRODUCT or other associated equipment, the cost of substitute equipment, and claims by third parties) resulting from the use of this PRODUCT. Some states/provinces do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

Please retain your original sales receipt as proof of purchase.

Appendix

Technical specifications

RF frequency band 1921.536MHz - 1928.448MHz

Channels 5

Operating temperature 32°F - 122°F

0°C - 50°C

Telephone base voltage

(AC voltage, 60Hz)

Telephone base voltage

(AC adapter output)

Handset voltage 2.4VDC - 3.2VDC

Charger voltage

(AC adapter output)

Operation Operating time*

Talk time (cordless handset) Up to seven hours

Talk time (cordless handset speakerphone) Up to five hours

Standby Up to seven days

* Operating times vary depending on your actual use and the age of the battery.

96Vrms - 130Vrms

6VDC @ 400mA

6VAC @ 300mA

DECT 6.0 digital technology

The AT&T DECT 6.0 products offer unsurpassed range performance and sound clarity. This is achieved through a unique antenna design and advances in noise-filtering technology. An independent laboratory has confirmed that AT&T DECT 6.0 products perform up to 45% better in range competitions. Now calls can be taken in the basement, backyard and garage with exceptional sound quality.

Telephone operating range

This cordless telephone operates within the maximum power allowed by the Federal Communications Commission (FCC). Even so, this handset and telephone base can communicate over only a certain distance — which can vary with the locations of the telephone base and handset, the weather, and the construction of your home or office.

Redefining long range coverage and clarity

This telephone base comes with an antenna which gives much better clarity and covers a longer range than before.

HD audio

HD audio improves sound quality by expanding and rebuilding frequencies that are lost with traditional phone calls. There is no additional telephone service requirement to use HD audio. It is designed to work with standard telephone service. Your system will automatically enhance all received sound with HD audio.

Index

Alert tones, 60 Answer an incoming call

during an intercom call, 25

during PTT, 30 Answering calls, 18 Answering system, 44–57 Assign a speed dial number, 36 Auto off, 18

Battery charging, 6–7 Battery installation, 6–7 Blind transfer, 23

Caller ID (CID),

add entries to phone directory, 42

delete entries, 41

dial entries, 41

review entries, 40 Caller ID, 38 Caller ID announce, 13 Call transfer, 23

using intercom, 26 Call waiting, 21 Chain dialing, 22 Charger installation, 5 Clear voicemail indication, 14 Clock, 12

Day and time, 12 Delete a speed dial number, 37 Delete entries in the caller ID history, 41 Dialing,

from a record in the caller ID

history, 41

from the directory, 35

Directory,

Dial numbers, 35 Edit entries, 35 Name search, 34

New entries, 32 Display dial, 35 DSL, 4,5

Elapsed time, 18 Ending calls, 18

Flash (switch hook flash), 21

Handset,

Handset locator, 24

Quick reference guide, 1–3

Ringer tone, 11

Ringer volume, 11

Screen display messages, 62-63

Screen icons, 60

Speakerphone, 19

Temporary ringer silencing, 18

Voicemail indicator, 14 HD audio, 79

Important safety information, 73–74 Incoming caller ID history, 40 Installation, 4–7 Intercom, 25

Last number redial, 19 LCD language, 12 Lights, 61

Limited warranty, 77–78

Index

Maintenance, 72 Make an outgoing call during PTT, 30 Making calls, 18 Memory match, 40 Memos, 54 Message,

Alert tone, 48 Counter display, 55 Playback, 52

Mute, 21

Names,

Enter into directory, 32 Search for, 34

Number of rings, 46

On-hook dialing (predialing), 18 Outgoing announcement, 44

Paging tone, 24 Phonebook, see directory, 31 Power adapter, 5 Predialing, 18 Push-to-talk, 27–30

Quick reference guide, 1–3

Ringer silencing, 18 Ringer volume,

Base, 51

Handset, 11 Ring tone options, 11

Safety information, 73–74 Search by name, 34 Speakerphone, 19 Speed dial, 36–37

Technical specifications, 79 Telephone operating range, 79 Temporary ringer silencing, 18 Time setting, 12 Transfer (blind), 23 Troubleshooting, 64–71

Visual message waiting indicator, 14 Voice announce caller ID, 13 Voicemail, 14, 49 Voice prompts, 50 Volume control,

Base, 51

Handset, 11

Wall mount installation, 8 Warranty, 77–78

Reassign a speed dial number, 36 Receiving calls, 18 Recharging, 6 Redial, 19 Remote access, 47, 56–57

Remote access wallet card

Use the wallet card below to help you remember commands to control your answering system from any touch-tone telephone.

Cut along dotted line.

Call your phone number, then enter your two- di gi t access code (preset to 19).

Fold here.

Action Remote command

Play all messages ..................1

Play new messages ...............2

Delete the message ..............3

Delete all old messages .....33

Repeat or go back .................4

Stop ...............................................5

Help menu .................................TONE

Skip the message ...................6

Record announcement ......TONE

End remote access call ......8 (or hang up)

Turn system off or on ..........

Models: CL82101/CL82201/CL82301/CL82351/CL82401/CL82451 CL82501/CL82551/CL8601 Type: DECT 6.0 cordless telephone/answering system withDECT 6.0 cordless telephone/answering system with

caller ID/call waiting

www.telephones.att.com

AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to

Advanced American Telephones, San Antonio, TX 78219.

Printed in China. Issue 5 AT&T 02/11.

AT&T CL82401, CL81301 User Manual 2

Specifications and Main Features

Frequently Asked Questions

User Manual

Getting started

Quick reference guide - handset

Quick reference guide - telephone base

Installation

Telephone base and charger installation

Telephone base installation

Charger installation

Battery installation and charging

Installation options

Tabletop to wall mount installation

Wall mount to tabletop installation

Telephone settings

Handset settings

Ringer volume

Ringer tone

Set date/time

LCD language

Voicemail (visual message waiting) indicator

Clear voicemail indication

Rename handset

Key tone

Use caller ID to automatically set date and time

Home area code

Dial mode

Website

Making a call

On hook dialing (predialing)

Answering a call

Ending a call

Auto off

Temporary ringer silencing

Speakerphone

Last number redial

Equalizer

Options while on calls

Volume control

Call waiting

Mute

Chain dialing

Temporary tone dialing

Blind transfer

Multiple handset use

Multiple handset use

Handset locator

Join a call in progress

Intercom

Answer an incoming call during an intercom call

Call transfer using intercom

Push-to-talk (PTT)

Turn PTT on or off

PTT call to a single handset

Answer a PTT call

Change a one-to-one PTT call to an intercom call

Answer an incoming call during PTT

Make an outgoing call during PTT

End or leave a PTT call

Directory

About the directory

Shared directory

Capacity

Create directory entries

Create a new directory entry

Add a predialed telephone number to the directory

Review the directory

Review directory entries

Search by name

Dial, delete or edit directory entries

Display dial

Delete a directory entry

Edit a directory entry

Speed dial

Assign a speed dial number

Reassign a speed dial number

Delete a speed dial number

Make a call using speed dial

Caller ID
