ATT CL4940, CD4930 User Manual
Abridged user’s manual
CL4940/CD4930
Big button/big display telephone/
answering system with caller ID/
call waiting
This abridged user’s manual provides you with basic installation and
use instructions.
Please refer to the online user’s manual for a full set of installation and
operation instructions at www.telephones.att.com/manuals. Before
using this AT&T product, please read Important safety information on page
22 of this abridged user’s manual.
Parts checklist
Your package contains:
Telephone base with power adapter installed
Handset
Wall-mount bracket
Coiled handset cord
Telephone line cord
Abridged user’s manual
Basic steps to set up & operate your phone
Basic installation
1
Install telephone base
2
Wall-mount installation (optional)
Common settings
3
Set date and time
4
Set ringer volume
5
Set language
6
Set contrast
7
Set dial mode
8
Set area code
Common operations
9
Directory
10
Speed dial
11
Call waiting
12
Caller ID
13
Answering system
2
Install telephone base
1
1
Plug!
Plug!
2
Plug!
Plug!
If you have DSL high-speed
Internet service, a DSL lter
(not included) is required. The
DSL lter must be plugged
into the telephone wall jack.
Plug!
3
3
Adjust!
Wall-mount installation (optional)
2
1
Slide
upward!
Insert!
4
2
Insert tab A and tabs B into the corresponding grooves.
Insert tab A into its
A
corresponding slot.
B
Click tabs B into their
corresponding slots.
3
Plug!
Plug!
If you have DSL high-speed
Internet service, a DSL lter
(not included) is required.
The DSL lter must be
plugged into the telephone
wall jack.
5
4
Slide
downward!
Adjust
screen!
6
Set date and time
3
Press MENU -> press / to scroll to
1.
Set date/time -> press SELECT.
Use the dialing keys (0-9) to enter the month (MM),
2.
date (DD) and year (YY) -> Press SELECT.
Use the dialing keys (0-9) to enter the hour (HH)
3.
and minute (MM).
Press / to select AM or PM -> press SELECT to
4.
save your setting.
Set date
?M/DD/2015
p
q
Set time
?H:MM --
p
q
You can press CANCEL to go back to the previous
eld and make correction.
Set ringer volume
4
You can set the ringer volume level to one of four levels or turn the ringer o.
When the ringer is o, appears on the screen.
Press pVOLUMEq to adjust the ringer volume when the telephone is not
in use.
-OR-
Press MENU -> press / to scroll to Ringer volume -> press SELECT.
1.
Press / or pVOLUMEq to sample each volume level.
2.
Press SELECT to conrm.
3.
Set language
5
Press MENU -> press / to scroll to Language ->
1.
press SELECT.
Press / to choose from English, Français or
2.
Español -> press SELECT.
Press SELECT again to conrm.
3.
NOTE: If you accidentally change the LCD language to French or Spanish, you can reset it
back to English without going through the French or Spanish menus. Press MENU/SELECT in
idle mode, then enter 3645474#. There is a confirmation tone.
>English
Francais
q
7
Set contrast
6
Adjust the screen brightness to a comfortable level,
from 1 to 4.
Press MENU -> press / to scroll to
1.
LCD contrast -> press SELECT.
Press / to choose fromto choose from 1, 2, 3 or 4.
2.
Press SELECT to conrm.
3.
Set dial mode
7
The dial mode is preset to touch-tone dialing. If you
have pulse (rotary) service, you must change the dial
mode to pulse dialing before using the telephone.
Press MENU -> press / to scroll to Dial mode
1.
-> press SELECT.
Press / to choose from Touch tone or Pulse.
2.
Press SELECT to save your setting.
3.
Set area code
8
4
>3
p
q
>Touch tone
Pulse
q
You can set one home area code and four local
area codes.
Press MENU -> press
1.
Caller ID log -> press SELECT.
Press
/
2.
press SELECT.
Press
3.
Local area (1 - 4) -> press SELECT.
Enter the three-digit area code using the dialing keys,
4.
then press SELECT to save your setting.
to scroll to Set area code ->
/
to scroll to Home area code or
/
to scroll to
8
Local area 1
123
Directory
9
This telephone has a directory where you can store up to 25 telephone
numbers and names. Numbers can be up to 24 digits and names can be up to
15 characters.
To add a directory entry:
Press MENU -> press
1.
Press
/
2.
Enter the telephone number using dialing keys -> press SELECT.
3.
Enter the name using dialing keys -> press SELECT.
4.
to highlight Add contact -> press SELECT.
/
to scroll to Directory -> press SELECT.
To review and dial a directory entry:
Press DIRECTORY.
1.
Press
/
2.
SPEAKER to call.
to browse through the directory -> li the handset or press
To edit a directory entry:
When the desired directory appears -> press SELECT.
1.
Edit the number -> press SELECT.
2.
Edit the name -> press SELECT.
3.
To delete a directory entry:
When the desired directory appears -> press DELETE X.
1.
The screen displays Delete contact? -> press SELECT or DELETE X.
2.
10
This telephone has 10 speed dial memory locations (0-9) where you can store
telephone numbers you wish to dial more quickly.
Speed dial
To store a speed dial entry
Press SPEED DIAL -> press
1.
(0-9) -> press SELECT.
Press SELECT again -> enter the telephone number using dialing keys.
2.
Press SELECT -> enter the name using dialing keys -> press SELECT.
3.
/
to choose the desired speed dial location
9
To dial a speed dial entry
When the telephone is in idle mode, press and hold the dialing keys (0-9) to
dial the corresponding speed dial number.
To delete a speed dial entry
Press SPEED DIAL -> press
1.
(0-9).
Press DELETE X -> press SELECT.
2.
/
to choose the desired speed dial location
11
12
The telephone stores caller ID information about the last 50 incoming calls.
The screen displays XX Missed calls when you have incoming calls that have
not been answered.
Call waiting
Press FLASH to put your current call on hold and take the new call.
Press FLASH at any time to switch back and forth between calls.
Caller ID
To review the caller ID history
Press CALL LOG -> press / to scroll through the entries.
1.
Press CANCEL to exit.
2.
To dial a caller ID entry
Press / to browse -> li the handset or press SPEAKER to call.
To delete call records
Delete a single call record
Press DELETE X to delete the shown entry.
Delete all call records
Press MENU -> press / to scroll to Caller ID log -> press SELECT.
1.
Press / to select Del all calls -> press SELECT.
2.
When the screen shows Delete all calls?, press SELECT to conrm.
3.
10
