Atlas IED ASP-MG24 Users Manual

ASP-MG24 / ASP-MG24TDB

Signal Processor / Masking Generator

2 Input x 4 Output

1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.

TELEPHONE: [phone]
[e-mail]

– 1 –

AtlasIED.com

ASP-MG24

Owner’s Manual

Table of Contents

Important Safety Instructions ................................................................................................................................................................................ 3

Introduction ........................................................................................................................................................................................................... 5

Key Features .......................................................................................................................................................................................................... 5

Front Panel Description .......................................................................................................................................................................................... 6

Rear Panel Description ........................................................................................................................................................................................... 7

Getting to Know the Software................................................................................................................................................................................ 8

Mic / Line Input ...................................................................................................................................................................................................... 9

Masking Generator Inputs .................................................................................................................................................................................... 13

Masking Generator Outputs ................................................................................................................................................................................. 16

File Import and Export .......................................................................................................................................................................................... 21

Specifications ....................................................................................................................................................................................................... 26

Warranty ............................................................................................................................................................................................................... 32

1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.

TELEPHONE: [phone]
[e-mail]

– 2 –

AtlasIED.com

ASP-MG24

Owner’s Manual

Important Safety Instructions

The lightning flash with arrowhead symbol within an equilateral triangle,
is intended to alert the user to the presence of uninsulated “dangerous
voltage “ within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.

WARNING: SHOCK HAZARD - DO NOT OPEN

AVIS: RISQUE DE CHOC ELÉCTRIQUE - NE PAS OUVRIR

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK

DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE

AVIS: NE PAS EXPOSER CE MATÉRIEL À LA PLUIE OU L’HUMIDITE

AFIN DE REDUIRE LE RISQUE D’INFLAMMATION OU DE CHOC ELÉCTRIQUE

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this device near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other devices that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A

grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided

plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the

device.

11. Only use attachments / accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the device. When a cart is used, use caution

when moving the cart / device combination to avoid injury from tip-over.

The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the product.

13. This product is equipped with a three-wire grounding-type plug, a plug having a third (grounding) pin. This plug will only fit into a grounding-type

power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do

not defeat the safety purpose of the grounding-type plug.

14. Unplug this device during lightning storms or when unused for long periods of time.

15. Refer all servicing to qualified service personnel. Servicing is required when the device has been damaged in any way, such as power-supply cord

or plug is damaged, liquid has been spilled, or objects have fallen into the device, the device has been exposed to rain or moisture, does not

operate normally, or has been dropped.

16. WARNING: To reduce the risk of fire or electric shock, this device should not be exposed to rain or moisture and objects filled with liquids, such as

a vase, should not be placed on this device.

17. To completely disconnect this equipment from the mains, disconnect the power supply cord plug from the receptacle.

18. The mains plug of the power supply cord shall remain readily operable.

19. Protective earthing terminal. The apparatus should be connected to a mains socket with a protective earthing connection.

1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.

TELEPHONE: [phone]
[e-mail]

AtlasIED.com

– 3 –

ASP-MG24

Owner’s Manual

WARNING - When The Device Is In Use

• WARNING: The terminals marked with symbol of may be of sufficient magnitude to constitute a risk of electric shock. The external wiring

connected to the terminals requires installation by an instructed person or the used of ready-made leads or cords.

• WARNING: The apparatus shall not be exposed to dripping or splashing and that objects filled with liquids, such as vases, shall not be placed on

apparatus.

• WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable.

• To prevent electric shock, do not remove the product cover as there are high voltage components inside. Refer all servicing to AtlasIED.

• Should any of the following irregularities occur during use, immediately switch off the power, disconnect the power cord from the AC outlet and

contact AtlasIED. Do not to attempt to continue operation with the product as this may cause fire or electric shock:

• Smoke or strange smell coming from the unit.

• If the product falls or the case is damaged.

• If water or any metallic objects falls into the product.

• If the power supply cord is damaged in any way.

• If the unit is malfunctioning.

• Do not insert or drop metallic objects or flammable materials into the ventilation holes of the product's cover, as this may result in electric shock or

fire.

• Do not place any containers with liquid or metallic objects on the top of the product. If any liquid spills into the unit, fire or electric shock may result.

• Never operate this product or touch the power supply cord during an electrical storm, electric shock may result.

• Never exceed the power rating on the product when connecting equipment. Fire and/or property damage may result.

• Operate the product only with the voltage specified on the unit. Fire and/or electric shock may result if a higher voltage is used.

• Do not modify, kink, or cut the power cord. Do not place the power cord in close proximity to heaters and do not place heavy

objects on the power cord, including the product itself, doing so may result in fire or electrical shock.

• Ensure that the safety ground terminal is connected to a proper ground. Never connect the ground to a gas pipe as a catastrophic disaster may

result.

• Be sure the installation of the product is stable, avoid slanted surfaces as the product may fall and cause injury or property damage.

CAUTION - When Installing The Product

• Plugging in or unplugging the power cord with wet hands may result in electric shock.

• Never move the unit with the power cord plugged into the wall, as damage to the power cord may result.

• When unplugging the cord from the wall, grasp the plug, NOT the cord.

• Never install this product in humid or dusty locations, nor in direct sunlight, near sources of heat, or in areas where sooty smoke or steam are

present. Fire and electric shock may result.

• Keep all sides of the unit at least 31/2" away from objects that may obstruct air flow to prevent the unit's internal temperature rise.

CAUTION - When The Product Is In Use

• Never place heavy objects on the product, causing it to fall and/or break, resulting in personal injury and property damage. In addition, the product

itself may fall and cause injury and property damage.

• Contact AtlasIED for instructions on cleaning the inside of the unit. Large accumulations of dust inside the unit may result in heat buildup and fire.

• Ensure that the power supply plug is securely plugged into the wall outlet. Never allow dust to accumulate on the power plug or inside the wall

outlet.

• When cleaning the unit or the unit is not to be operated for an extended period, unplug the power cord from the wall.

1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.

TELEPHONE: [phone]
[e-mail]

– 4 –

AtlasIED.com

ASP-MG24

Owner’s Manual

Introduction

The AtlasIED ASP-MG24 is a 2 input by 4 output digital loudspeaker management system and masking generator designed for fixed sound installation

markets. The ASP-MG24 features the latest in available technology utilizing 32-bit (40-bit extended) floating point processors and high performance

24-bit analog converters. Both balanced inputs are mic / line selectable with rear panel mounted trim adjustments, along with 4 independent masking

generator input sources. Inputs and outputs can be routed or mixed in multiple configurations to meet even the most complex system designs.

Control parameters include I/O levels, delay, polarity, parametric EQ, crossover selections, 31 band EQ, white / pink noise, auto ramp, routing, mixing

and compressor / limiters. The ASP-MG24 can be controlled or configured in real time with the intuitive PC GUI, accessed via the RS-232 or USB

interface. Software upgrade for CPU and DSP via PC always keeps the ASP-MG24 current.

Key Features

• 2 Mic / Line Inputs and 4 Outputs

• Rear Mounted Input Trim Adjustments

• System Routing and Mixing Flexibility

• 4 Independent Random Pink or White Noise Generators

• 8 Parametric Filters for Each Input and Output

• Multiple Crossover Types up to 48dB

• Full Function Compressor Limiters

• Four 1/3 Octave Graphic Equalizers for Masking

• User Set Masking Auto Ramp

• Precise Level, Polarity and Delay

• Full 5-segment LED’s on Every Input and Output

• Storage of up to 30 Program Setups

• 14 Program Setups

• RS-232 & USB Interface for PC Control and Configuration

• CPU and DSP Upgrade via PC

• User Programmable Ramp Up / Down of Inputs and Outputs (-TDB Version)

• Factory Masking 1/3 Octave Pre-sets for Most Installation Situations

1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.

TELEPHONE: [phone]
[e-mail]

– 5 –

AtlasIED.com

ASP-MG24

Owner’s Manual

Front Panel

54 123

1. LED Power Indicator

The Power LED will illuminate blue when the external power supply is plugged into the power socket on the rear of the unit and into an AC source.

2. Level LED Indicators

5 LEDs per channel indicate the status of the signal level: Signal, -12dB, -6dB, -3dB, Over / Limit. A dual use LED indicates maximum headroom and

limiter threshold.

3. RS232 Connector

Standard female DB9 socket. A straight through cable is required for PC connection.

4. USB Connector

Standard female USB socket. A straight through cable is required for PC connection.

5. LED Data Indicator

The Data LED will illuminate green when there is connection made between the ASP-MG24 and the computer.

1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.

TELEPHONE: [phone]
[e-mail]

– 6 –

AtlasIED.com

ASP-MG24

Owner’s Manual

Rear Panel

2 351 64

1. Power Supply Socket

An external UL rated 120V AC power supply has been included with the ASP-MG24. Only use the provided power supply due to the specific DC

voltages required to operate the unit.

2. Input Connectors

There are two removable 3 Pin Phoenix type connectors for providing input signal to the unit. They can accept either a balanced or unbalanced signal.

For balanced signals connect ground to (GND), positive signal to (+) and negative signal to (–). For unbalanced signals connect the (–) to the (GND) and

the positive signal to (+).

3. Mic / Line Level Selection

Each input has the capability to accept either a microphone or line level signal. Prior to connecting the inputs make sure the software input gain that

applies to the channel routing is set to -10dB, and the limiters are set to +20dB for gain setup. Prior to applying signal to the input, set the analog gain

switch to match the type of input being used. The Line position gain is calibrated for 0dBu or unity gain within the DSP software. The Mic position gain

is calibrated for -30dBu when the DSP gain is set for unity or 0dB. If more gain is needed, carefully increase the appropriate channel DSP gain in the

software. If using a microphone, it is recommended to start with the input gain set to -40dB and slowly increase the input gain to the desired level.

4. Output Connectors

There are four removable 3 Pin Phoenix type connectors for providing output signal. They can deliver either a balanced or unbalanced signal. For

balanced signals connect ground to (GND), positive signal to (+) and negative signal to (–). For unbalanced signals connect the (–) to the (GND) and the

positive signal to (+).

5. RJ45 Port

This port allows remote configuration of the GUI via a LAN connection. A fixed IP address is needed to access the control software. Note: This port is

only active with the ASP-MG24TDB.

6. Input Gain Trim Pots

Channel 1 & 2 input gain pots have an adjustment range of +6dB to -40dB. The center of pot travel is 0 gain or cut.

1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.

TELEPHONE: [phone]
[e-mail]

– 7 –

AtlasIED.com

ASP-MG24

Owner’s Manual

Getting to Know the Software

Loading the Software

1. Load the software onto the computer by following the Quick Start Guide and Software Installation Guide.

2. Note: It is important to have the computer screen resolution set to the highest viewing setting or a minimal setting of 1280 x 1240 pixels. Failure

to do may cause the dialog boxes to appear outside the viewing area. To find a window that should appear use the master screen curser Up / Down

arrows. All screens can be moved by clicking and holding the selected screen for personal viewing preferences.

3. After the software is loaded and the proper screen resolution is set, open the software and follow the steps below: Note: It is not necessary to

have the computer connected to the ASP-MG24 for viewing and program purposes.

Opening the Software

1. The screen should look like the view below. If not, close the software and restart.

2. If the ASP-MG24 is connected to the computer click “Yes “ to connect, or click “No” to work in Off Line mode.

3. To enter the control panel screen, click on the “Device 1” button. Note: A password can be inserted at any time. Click “Start” and then “Log On”.

Open the Device panel by clicking on “Device 1”. Note: An ASP-MG24 is also known as a “Device”. Multiple ASP-MG24 units can be controlled via

one GUI interface. If only one ASP unit is connected to the computer click on Device 1 and the main control window will appear.

1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.

TELEPHONE: [phone]
[e-mail]

AtlasIED.com

– 8 –

ASP-MG24

Owner’s Manual

Mic / Line Input

Input Meter

The bar graph meter illustrates the level of the input signal POST the channel’s gain control and is PRE input filters and compressor settings.

Gain

For convenience both Mic / Line inputs and the four masking generators levels are shown. Controlling the gain can be accomplished by dragging the

fader, using the up / down buttons or by typing in the number viewing text box. Channel Mute can be accomplished by clicking on the Mute tab. The

tab will illuminate red indicating the channel is in Mute. Input Polarity can be set by clicking on the Polarity tab.

1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.

TELEPHONE: [phone]
[e-mail]

– 9 –

AtlasIED.com

ASP-MG24

Owner’s Manual

Compressor

Inputs 1 & 2 have fully adjustable compressor limiters. When clicking on the compressor tab, two sub viewing screens will appear. Note: All control

boxes can be dragged for desired positioning of the screen. Screen 1 is an indicator screen showing the compressor / limiter operation. The second is

the settings screen. This screen controls Threshold, Attack, Release and Ratio. Adjustment can be made using the up / down arrows or by typing into

the data viewing text box.

• Threshold - Limit threshold. Ranges from -20dBu to +20dBu in 0.5dB steps.

• Attack - Attack time. Ranges from 0.3ms to 1ms in 0.1ms steps, and ranges from 1ms to 100ms in 1ms steps.

• Release - Release time. Can be set at 2X, 4X, 8X, 16X or 32X the attack time.

• Ratio - The Ratio control allows adjustment to the amount of Input vs. Output level with signals exceeding the set threshold limit.

Example: When set at “2”, a 2dB input signal increase yields 1dB output gain.

1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.

TELEPHONE: [phone]
[e-mail]

– 10 –

AtlasIED.com
