Athena Technologies A88028 User Manual

ATHENA LF

Cat I G20 at 20mbar in GB and IE

FOR USE WITH NATURAL GAS ONLY

Installation & Servicing Instructions

G.C. No. 32 170 19 ÿ Product Code No. A88028

The Data Badge and Serial Number are located on the left hand side of the back panel.

PLEASE LEAVE THESE INSTRUCTIONS WITH THE USER

SERVICE AND INSTALLATION

CONTENTS LAYOUT

INTRODUCTION AND GENERAL INSTALLATION REQUIREMENTS

1.0 TECHNICAL DATA

2.0 CONDITIONS OF INSTALLATION

2.1 SITING GENERAL

2.2 FLUES AND CHIMNEYS

2.2.1 Brick Chimney, 178mm diameter (7 inch) Stone or Lined Flue and 125mm diameter (5 inch) Flue

2.2.2 Pre-Cast Flue

2.2.3 Metal Fluebox 125mm diameter (5 inch) Flues

2.3 SHELF HEIGHT AND SIDE CLEARANCES

2.3.1 Combustible Shelf

2.3.2 Non-Combustible Shelf

3.0 INSTALLATION OF FIRE

3.1 UNPACKING

3.2 PREPARATION OF FIRE

3.2.1 Spigot Restrictor

3.3 METHODS OF INSTALLATION

3.3.1 Fixing by Tension Cable

3.3.2 Fixing Directly onto Wall

3.4 GAS CONNECTION

3.4.1 Concealed Connection

3.4.2 Front Connection

3.5 TEST FOR GAS SOUNDNESS

4.0 COMMISSIONING

4.1 INSTALL FUEL EFFECT COMPONENTS

4.2 CHECK GAS PRESSURE

4.3 FIT TRIM AND FENDER

4.4 TEST FOR SPILLAGE

4.5 CHECK IGNITION

4.6 CHECK OPERATION OF FSD

5.0 INSTRUCT USER

6.0 SERVICING INSTRUCTIONS

6.1 REMOVE BURNER TRAY

6.2 MAIN BURNER INJECTOR

6.3 GAS TAP ASSEMBLY

6.4 PILOT ASSEMBLY

6.5 FUEL EFFECT COMPONENTS

6.6 MAIN BURNER

6.7 CONTROL KNOB

6.8 IGNITION UNIT

6.9 IGNITION BATTERY

6.10 IGNITION MICRO SWITCH

6.11 THERMOCOUPLE BREAK MICRO SWITCH

7.0 HINTS ON FAULT FINDING

8.0 SHORT LIST OF PARTS

INTRODUCTION

NO COMPONENT OF THIS FIRE IS MANUFACTURED FROM ASBESTOS OR ASBESTOS RELATED PRODUCTS.

The ATHENA L.F. is an open fronted inset live coal effect gas fire specially designed for Pre-Cast Flue application and is also suitable for use with Brick Chimneys, twin walled or insulated Metal/Pre-fabricated Flues of 125mm minimum diameter and Flueboxes conforming to the constructional requirements of BS 715. It is fitted with a combined flame supervision and oxygen depletion monitoring device. The fire is for hearth mounting only on a non-combustible hearth. The fire is for use on Natural Gas only.

GENERAL INSTALLATION REQUIREMENTS

In your own interest and that of safety, it is the law that all gas appliances are installed by competent persons in accordance with the current Gas Safety (Installation and Use) Regulations. Failure to install appliances correctly could lead to prosecution.

The installation MUST be in accordance with these installation instructions, all the relevant parts of the Local and National Building Regulations or Building Standards (Scotland) (Consolidation) Regulations and the relevant recommendations of the current editions of the following British Standards:

B.S. 5871 : Part 2 B.S. 5440 : Parts 1 & 2 B.S. 6891 B.S. 6461 : Parts 1 & 2 B.S. 715 B.S. 1251 B.S. 1289 : 1975 B.S. 1289 : Part 1 : 1986 B.S. 1289 : Part 2 : 1989

Any other relevant British Standard Code of Practice and/or Local Building Regulations and in accordance with the rules in force.

1.0 TECHNICAL DATA

1.1 DIMENSIONS

(Overall) mm

Height 682 Width 635 Depth 115 Forward Projection 100 Height to top of flue aperture 529 Weight 18 Kg

1.2 INPUTS AND PRESSURES Maximum Heat Input (Gross) 6.0 kW 20470 Btu/h Minimum Heat Input (Gross) 2.3 kW 7848 Btu/h Supply Pressure 20.0 mbar Setting Pressure Cold 13.0 mbar ± 1mbar Gas Rate Adjustment NONE

1.3 BURNER AND CONTROL DETAILS Main Burner ÿ 992174 Pilot Burner SIT OP 9063 Injector (Main Burner) Bray Cat 82/440 Ignition Battery Operated Electronic Ignition. Battery Size 9V MN1604 or 6LR61 Control Tap Concentric (with FSD) Model Number TESA 2762-025 Spark Gap 3.0mm to 5.0mm Control Knob Settings OFF, HIGH, MED, ECON, PILOT

2.0 CONDITIONS OF INSTALLATION

2.1 SITING GENERAL

This fire is suitable for hearth mounting only on a non-combustible hearth at least 13mm thick and measuring at least 630mm wide by 330mm deep. Its top surface should preferably be 50mm above the floor level in order to discourage the placing of carpets or rugs over it. It MUST NOT be fitted directly on a combustible wall. The fire should be installed so that no part of a combustible wall i.e. not part of the fire surround but a full wall at 90 to the fire is less than 500mm from the radiant source. If this is not possible the combustible side wall must be suitably protected.

FIREPLACE OPENING

The front opening of the fireplace must be between 305mm and 457mm wide and between 560mm and 585mm high (see Section

2.2). If the opening is greater it must be bricked up until the opening is a maximum of 585mm high and 457mm wide, alternatively a non-combustible infill panel may be used to achieve the required dimensions.

DO NOT USE THE BACK OF A FIRE SURROUND OR MARBLE TO ACHIEVE THE ABOVE DIMENSIONS.

There must be a minimum flat surface area around the fireplace opening shown by the dotted lines in fig. 1 to ensure a good seal between the fireplace and the fire. This area should be sound enough to take the wall plugs and screws supplied for front fixing. Ensure that the base of the fireplace is level with the hearth and reasonably flat to prevent the fire rocking. Purpose built ventilation bricks or additional air vents are not normally required in the room in which the fire is fitted unless specified by the rules in force.

IMPORTANT: When fitting any heating appliance or wallpapering a room in which one is fitted, soft wall coverings such as heat sensitive wallpapers may become heat damaged or discoloured especially in the area above the fire. Please bear this in mind when installing or decorating.

IMPORTANT NOTE

Plaster Applied Directly to Pre-cast Flue Blocks.

Some Pre-cast flues built to B.S. 1289:1975 may have plaster applied directly to the flue blocks. A recommendation was made, in the revision B.S. 1289 part 1:1986, NOT to apply plaster directly to the flue blocks, otherwise cracking of the plaster could occur. It is not recommended to install this fire into such installations, unless remedial action is taken.

2.2 FLUES AND CHIMNEYS

2.2.1 SITE REQUIREMENTS FOR 228mm BY 228mm (9in BY 9in) BRICK CHIMNEY/178mm (7in) STONE OR LINED CHIMNEY AND 125MM (5in) DIAMETER FLUE

The minimum dimensions for the fireplace opening for a brick chimney are as shown in Fig. 1. It will not normally be necessary to remove any chair brick provided the minimum depth is obtained. A chimney previously used to burn solid fuel must be swept prior to installation.

The chimney must be inspected to ensure that:

(a) It serves only one fireplace.

(b) It is properly sealed so that combustion products do not escape from the flue into the room.

(d) Any restriction such as damper, register plate, etc. must be removed or secured in the fully open position.

(e) Any underdraught ventilation or additional air supply

entering the fireplace or on the hearth must be sealed off.

635 mm MIN

(f) It must have at least 3 metre effective flue height.

(g) It must have a positive updraught.

CHECK THE FLUE FOR GOOD DRAUGHT Apply a lighted paper or smoke match to the top of the opening in the fireplace. Observe if there is a definite flow into the chimney and if so proceed with fitting the fire. If no flow is indicated, warm the chimney for several minutes and then re-check. If downdraught is observed a suitable terminal must be fitted and the chimney re-checked. If persistent no-flow or downdraught condition is observed

DO NOT FIT THE FIRE, SEEK EXPERT ADVICE.

686 mm MIN

Fig. 1

2.2.2 PRE-CAST FLUE OF MINIMUM SIZE (Fig. 2)

This fire can be installed into a properly constructed pre-cast flue conforming to B.S. 1289 : 1975 or B.S. 1289 : Part 1 : 1986 or B.S. 1289 : Part 2 : 1989 of at least 3 metres effective height and having flueways of at least 198mm by 67mm or equivalent cross-sectional area with no dimension less than 63mm. The fireplace opening width must be between a maximum 457mm and a minimum 305mm. The fireplace opening height must be between a maximum of 585mm and a minimum 560mm and a depth of at least 120mm above the hearth level.

NOTES:

1. The minimum dimensions for the flat area around the

opening are 686 mm high x 635 mm wide.

2. The flue spigot restrictor MUST NOT be fitted.

Ensure that any mortar fangs between the blocks do not protrude into the flueways and if raking blocks are used they are fitted according to the manufacturers instructions and mortar is not allowed to drop down and accumulate in the raked portions.

CHECK THE FLUE FOR GOOD DRAUGHT AS DETAILED IN SECTION 2.2.1.

PRECAST FLUE INSTALLATION

5 MI

*63

0mm

MAX

MIN

615 MAX

560 MIN

Fig. 2

686 MIN*686 MIN*
