ATEN Technology CS-1708 User Manual
User Manual
CS-1708
CS-1716
2004-04-27
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device pursuant to Subpart J of Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cau s e harm ful in ter fer ence to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is enco uraged to
try to correct the interference by one or more of the following measures:
M Reorient or relocate the receiving antenna.
M Increase the separation between the equipmen t an d receiv er .
M Connect the equipment into an outlet on a circuit different from that
which the receiver is connected.
M Consult the dealer or an experienced radio/television technician for help .
2004-04-27
CS-1708 / CS-1716 User Manual
Packing List
The complete Master View CS-1708 / CS-1716 package consists of:
M 1 CS-1708 or CS-1716 KVM Switch
M 2 CS Custom 2-in-1 KVM Cables (1.8m)
M 1 Firmware Upgrade Cable
M 1 Power Adapter
M 1 Rack Mount Kit
M 1 User Manual
M 1 Quick Start Guide
Check to make sure that all the components are present and that nothing was
damaged in shipping. If you encounter a problem, contact your dealer.
Read this manual thoroughly and follow the installation and operation procedures
carefully to prevent any damage to the unit, and/or any of the devices that connect
to it.
©Copyright 2004 ATEN® International Co., Ltd.
Manual Part No. PAPE-0228-1AT
Printed in Taiwan 04/2004
All brand names and trademarks are the registered property of their respective owners.
2004-04-27
iii.
CS-1708 / CS-1716 User Manual
Contents
1. Introduction
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Hardware Requirements . . . . . . . . . . . . . . . . . . . . . . . . . 4
Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2. Installation
CS-1708 / CS-1716 Front View . . . . . . . . . . . . . . . . . . . . . 5
CS-1708 / CS-1716 Rear View . . . . . . . . . . . . . . . . . . . . . 7
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Before you Begin . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Single Stage Installation . . . . . . . . . . . . . . . . . . . . . . 9
Daisy Chaining . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Hot Plugging . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Port ID Numbering . . . . . . . . . . . . . . . . . . . . . . . . 14
Powering Off and Restarting . . . . . . . . . . . . . . . . . . . 14
3. Hotkey Operation
Invoking Hotkey Mode (HKM) . . . . . . . . . . . . . . . . . . . . 15
Hotkey Port Access . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Selecting the Active Port: . . . . . . . . . . . . . . . . . . . . . 16
Auto Scan Mode: . . . . . . . . . . . . . . . . . . . . . . . . . 17
Hotkey Configuration . . . . . . . . . . . . . . . . . . . . . . . . . 18
Alternate Hotkey Invocation Keys: . . . . . . . . . . . . . . . . 18
Alternate OSD Invocation Keys: . . . . . . . . . . . . . . . . . 18
Platform Setup: . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Miscellaneous Actions: . . . . . . . . . . . . . . . . . . . . . . 20
Keyboard Emulation . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Sun Keyboard: . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Mac Keyboard: . . . . . . . . . . . . . . . . . . . . . . . . . . 22
iv.
2004-04-27
CS-1708 / CS-1716 User Manual
4. OSD Operation
OSD Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
OSD Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
OSD Main Screen Headings . . . . . . . . . . . . . . . . . . . . . . 25
OSD Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
F1 GOTO: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
F2 LIST: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
F3 SET: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
F4 ADM: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
F5 SKP: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
F6 BRC: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
F7 SCAN: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
F8 LOUT: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
5. The Firmware Upgrade Utility
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Starting the Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Upgrade Succeeded . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Upgrade Failed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Firmware Upgrade Recovery . . . . . . . . . . . . . . . . . . . . . . 43
Appendix
Master View Connection Tables . . . . . . . . . . . . . . . . . . . . 45
CS-1716: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
CS-1708: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Clear Login Information . . . . . . . . . . . . . . . . . . . . . . . . 46
Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
OSD Factory Default Settings . . . . . . . . . . . . . . . . . . . . . 49
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . 50
2004-04-27
v.
CS-1708 / CS-1716 User Manual
Conventions
This manual uses the following conventions:
Courier Indicates text that you should key in.
[ ] Indicates keys you should press. For example, [Enter] means to
press the Enter key. If keys need to be chorded, they appear
together in the same bracket with a plus sign between them:
[Ctrl+Alt].
1. Numbered lists represent procedures with sequential steps.
M Bullet lists provide information, but do not involve sequential
steps.
→ Indicates movement through a series. For example, Start → Run
means to open the Start menu, and then select Run.
Indicates critical information.
vi.
2004-04-27
Chapter 1.
Introduction
Overview
The Master View CS-1708 and CS-1716 KVM Switches are control units that allow
access to multiple computers from a single console (keyboard, mouse, and monitor).
A single Master View can control up to eight (CS-1708) or 16 (CS-1716) computers.
As many as 31 additional switches can be added in a daisy chain configuration,
allowing up to 512 computers to be controlled from a single keyboard-monitor-mouse
console. A seven segment front panel LED displays each Station’s position for easy
identification. An auto-sensing function recognizes the position of each station
(switch) on the chain, eliminating the need to manually set the position with DIP
switches.
The CS-1708 and CS-1716 improve on previous models by providing USB ports
for the console Keyboard and Mouse, and by transferring keyboard and mouse
data to the computers via the faster, more reliable USB bus rather than the
traditional PS/2 connection and in providing Multimedia keyboard support.
The CS-1708 and CS-1716 also utilize a custom ASIC (patent pending) for
increased reliability and enhanced performance. By incorporating high density 15
pin CPU port connectors instead of the usual 25 pin connectors, a full, 16 port
switch can be installed in a 1U system rack.
An included Firmware Upgrade Utility allows you can stay current with new
improvements in switch functionality by downloading the latest firmware files
from our website and using the utility to quickly and conveniently perform the
upgrade.
Setup is fast and easy; simply plug cables into their appropriate ports. There is no
software to configure, no installation routines, and no incompatibility problems.
Since the CS-1708 / CS-1716 intercepts keyboard input directly, it works on
multiple operating platforms (PC compatible, Mac, Sun).
Access to any computer on the installation is easily accomplished either by
entering Hotkey combinations from the keyboard, or by means of a powerful menu
1.
2004-04-27
CS-1708 / CS-1716 User Manual
driven OSD (On Screen Display) system. A convenient Auto Scan feature also
permits automatic scanning and monitoring of the activities of all computers
running on the installation one by one.
Since a single console manages all of the computers on your installation, a
CS-1708 / CS-1716 KVM switch setup: (1) eliminates the expense of having to
purchase a separate keyboard, monitor, and mouse for each computer; (2) saves
all the space those extra components would take up; (3) saves on energy costs;
and (4) eliminates the inconvenience and wasted effort involved in constantly
moving from one computer to another.
Features
w A single KVM console (USB Keyboard, Monitor, and USB Mouse)
controls 8 (CS-1708 ) or 16 (CS-1716 ) computers - daisy chain up to 31
additional units - control up to 256 or 512 computers from a single console
w Easy installation - no software required
w Hot pluggable - add or remove computers for maintenance without
powering down the switch - port names are automatically reconfigured
when the station sequence is changed
w LED Display For Easy Status Monitoring
w Auto Scan feature for monitoring user-selected computers
w Convenient computer selection via Hotkeys and intuitive OSD menus
w OSD is mouse-driven for quick and efficient menu navigation - OSD port
list automatically expands when stations are added - OSD screen
automatically adjusts to resolution changes
w OSD or hotkey selection of the OS and keyboard language
w Keyboard and mouse emulation - computers boot even when the console
focus is elsewhere
w Supports Microsoft IntelliMouse and the scrolling wheel on most mice -
Supports Logitech and Microsoft wireless keyboards and mice
2.
2004-04-27
Introduction
w Multimedia keyboard support
w Administrator/User password authorization for enhanced security (PSP);
administrator synchronized confirmation between master an d slav e statio ns
w Two types of logout - manual and timed
w Superior video quality - 2048 x 1536; DDC2B
w DDC emulation - video settings of each computer is automatically adju s ted
for optimum output to the monitor
w Upgradable firmware - all switches upgraded at the same time via the daisy
chain bus
w Backward compatible with the Master View CS-1216A KVM switch series
w Compatible with multiple operating platforms: PC, Mac, and Sun
w Supports: Windows 98 or higher; Mac OS8.6 or higher; Sun Blade
2000/100 (Solaris 8); Linux Red Hat 7.1 or higher
w Rack mountable in 19" system rack (1U)
2004-04-27
3.
CS-1708 / CS-1716 User Manual
Hardware Requirements
Console
w A VGA, SVGA, or Multisync monitor capable of the highest resolution that
you will be using on any computer in the installation.
w A USB mouse
w A USB keyboard
Computer
The following equipment must be installed on each computer :
w A VGA, SVGA or Multisync card.
w Type A USB port.
Cables
Substandard cables may damage the connected devices or degrade overall performance. For optimum signal integrity and to simplify the layout, we strongly
recommend that you use the high quality CS Custom Cable sets described below:
Cable Type Length Part Number
Daisy Chain
Daisy Chain
USB KVM
USB KVM
USB KVM
0.6m
1.8m
1.2m
1.8m
3.0m
2L-1700
2L-1701
2L-5201U
2L-5202U
2L-5203U
To purchase CS Custom KVM cable sets, contact your dealer.
4.
2004-04-27
CS-1708 / CS-1716 Front View
Chapter 2.
Installation
2 314
2004-04-27
2 314
5.
CS-1708 / CS-1716 User Manual
1. Port LEDs:
The Port LEDs provide status information about their corresponding CPU
Ports. There is one pair of LEDs for each Port. The one on th e lef t is th e On
Line LED; the one on the right is the Selected Port LED:
w An On Line LED lights ORANGE to indicate that the computer attached
to its corresponding port is up and running.
w A Selected LED lights GREEN to indicate that the computer attached to
its corresponding port is the one that has the KVM focus. The LED is
steady under normal conditions, but flashes when its port is accessed
under Auto Scan Mode (see p. 35).
w When the CS-1708 is first powered on, the On Line and Selected LEDs
blink in sequence as the Switch performs a self-test.
2. Reset Switch:
Pressing this switch in performs a system reset. The switch is recessed and
must be pushed with a thin object - such as the end of a paper clip, or a ball
point pen.
3. Power LED:
The Power LED lights to indicate that the CS-1708 is powered up and ready
to operate.
4. Station ID LED:
The CS-1708’s Station ID is displayed here. If this is a Single Station
installation (see p. 9), or the First Station on a Daisy Chained installation
(see p. 11), the CS-1708 has a Station ID of 01.
On a Daisy Chained installation, the CS-1708 auto-senses its position and
displays the Station ID that corresponds to its place in the chain. (see Port
ID Numbering, p. 14 for details).
6.
2004-04-27
CS-1708 / CS-1716 Rear View
Installation
3 65
4
3 65
4
1
7
1
7
2
2
2004-04-27
7.
CS-1708 / CS-1716 User Manual
1. Daisy Chain Ports:
When Daisy Chaining Units, the cables plug in here. The port on the left is
the Chain In port; the one on the right is the Chain Out port.
2. CPU Port Section:
The cables that link to the computers plu g in her e. T he s h ap e of th es e
connectors has been specifically modified so that only cables designed to
work with this switch can plug in.
3. Cable Tie Slot:
If you want to use a cable tie to gather the cables together, you can run it
through this slot to attach it to the unit.
4. Power Jack:
The power adapter cable plugs in here.
5. Firmware Upgrade Port:
The Firmware Upgrade Cable that transfers the firmware upgrade data
from the administrator’s computer to the CS-1708 / CS-1716 (see p. 37),
plugs into this RJ-11 socket.
6. Firmware Upgrad e Reco very S wit ch :
During normal operation and while performing a firmware upgrade, this
switch should be in the NORMAL position. See p. 43 for details about the
use of this switch.
7. Console Port Section:
If this is a Single Station installation, or if this is the First Station unit of a
daisy chained installation, your USB keyboard, monitor, and USB mouse
plug in here.
8.
2004-04-27
Installation
Installation
Before you Begin
1. Make sure that power to all the devices you will be connecting up
have been turned off. You must unplug the power cords of any
computers that have the Keyboard Power On function. Otherwise,
the switch will receive power from the computer.
2. To prevent damage to your installation make sure that all devices on
the installation are properly grounded.
Single Stage Installation
Refer to the installation diagrams on the next page as you perform the following
steps. The numbers in the diagrams correspond to the steps:
1. Plug your USB keyboard, monitor, and USB mouse into the Console Ports
located on the unit’s rear panel.
2. Use KVM cable sets to connect an y av ailab le CP U Port to th e vid eo an d
USB ports of the computers you are connecting up.
Note: 1. Two cable sets are supplied with this package; additional sets
require a separate purchase. See the Cables section on p. 4 for
details.
2. The shape of th e 15-pin CP U Port co nnectors has been
specifically modified so that only KVM cables designed to work
with this switch can plug in.
3. Plug the power adapter cable into the switch’s Power Jack, then plug the
power adapter into an AC power source.
This completes the single stage installation, and you can turn on the power to the
computers.
9.
2004-04-27
CS-1708 / CS-1716 User Manual
3
2
1
2
2
10.
2004-04-27
Installation
Daisy Chaining
To control even more computers, up to 31 additional switches can be daisy chained
down from the first unit. As many as 512 computers can be controlled from a single
console in a complete installation. Tables showing the relation between the
number of computers and the number of Master View CS-1708 / CS-1716 units
needed to control them are provided on p. 45 in the Appendix.
To set up a daisy chained installation, do the following:
1. Make sure that power to all the devices you will be connecting up has been
turned off.
2. Use a daisy chain cab le s et (des cr ib ed in th e Cables section, p. 4), to
connect the Chain Out port of the parent switch to the Chain In port of the
child switch (First Station Out to Second Station In, Second Station Out to
Third Station In, etc.).
Note: You cannot use the Chain In port of the First Station Master View,
since it is the highest level parent.
3. Use KVM cable sets (des cr ib ed in th e Cables sectio n, p. 4), to co nnect an y
available CPU Port on the CS-1708 / CS-1716 installation to the Keyboard,
Video and Mouse ports of the computers you are installing.
4. Repeat the above steps for any additional CS-1708 / CS-1716 units you
wish to add to the chain.
5. Power up the installatio n acco rdin g to th e followin g proced ure:
a) Plug in the power adapter for the First Station.
Wait for the unit to ascertain its Station ID and display it on the Station ID
LED. (The Station ID for the First Stage unit is 01, the ID for the Second
Stage unit is 02, the ID for the Third Stage unit is 03, etc.).
b) Plug in the power adapters for each Station on the installation in turn
(Second Station, then Third Station, etc.).
In each case, wait for the Station ID to be ascertained and displayed on the
current Station before plugging in the next one.
c) After all the Stations are up, power on the computers.
11.
2004-04-27
Loading...
