Computer Sharing Device
CS231 / CS231TK User Manual
www.aten.com
CS231 / CS231TK User Manual
EMC Information
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT: This equipment has been tested and found to comply with the
limits for a Class B digital service, pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. Any changes or modifications made to
this equipment may void the user’s authority to operate this equipment. This
equipment generates, uses, and can radiate radio frequency energy. If not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate this
equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
KCC Statement
ii
RoHS
This product is RoHS compliant.
CS231 / CS231TK User Manual
iii
CS231 / CS231TK User Manual
User Information
Online Registration
Be sure to register your product at our online support center:
International http://eservice.aten.com
Telephone Support
For telephone support, call this number:
International 886-2-8692-6959
China 86-400-810-0-810
Japan 81-3-5615-5811
Korea 82-2-467-6789
North America 1-888-999-ATEN ext 4988
1- 949-428-1111
User Notice
All information, documentation, and specifications contained in this manual are
subject to change without prior notification by the manufacturer. The
manufacturer makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims any
warranties as to merchantability or fitness for any particular purpose. Any of the
manufacturer's software described in this manual is sold or licensed as is.
Should the programs prove defective following their purchase, the buyer (and
not the manufacturer, its distributor, or its dealer), assumes the entire cost of all
necessary servicing, repair and any incidental or consequential damages
resulting from any defect in the software.
The manufacturer of this system is not responsible for any radio and/or TV
interference caused by unauthorized modifications to this device. It is the
responsibility of the user to correct such interference.
The manufacturer is not responsible for any damage incurred in the operation
of this system if the correct operational voltage setting was not selected prior to
operation. PLEASE VERIFY THAT THE VOLTAGE SETTING IS CORRECT
BEFORE USE.
iv
Package Contents
Copyright © 2020 ATEN® International Co., Ltd.
Manual Date: 2020-10-15
Altusen and the Altusen logo are registered trademarks of ATEN International Co., Ltd. All rights reserved.
All other brand names and trademarks are the registered property of their respective owners.
CS231
1 CS231 Computer Sharing Device
1 USB KVM Cable
1 Power Adapter
1 Firmware Upgrade Cable
1 DIP Switch Sticker
1 User Instructions*
CS231TK
1 CS231 Computer Sharing Device
1 USB KVM Cable
1 Power Adapter
1 Firmware Upgrade Cable
CS231 / CS231TK User Manual
1 DIP Switch Sticker
1 2XRT-0018G KVM over IP Access Control Box
1 User Instructions*
Note: 1. * Features may have been added to the KVM over IP console station
since the user instructions were created. Please visit our website to
download the most up-to-date version of the user manual
2. Make sure that all of the components are present and in good order. If
anything is missing or was damaged in shipping, contact your dealer.
3. Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit, and/or any of
the devices connected to it.
v
CS231 / CS231TK User Manual
Table of Contents
EMC Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
RoHS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Online Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Telephone Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
User Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .viii
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Product Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
1. Introduction
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
CS231 / CS231TK. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
2XRT-0018G KVM over IP Access Control Box . . . . . . . . . . . . . . . . . .2
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Operating System:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
CS231 / CS231TK Front View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
CS231 / CS231TK Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2XRT-0018G KVM over IP Access Control Box Front View . . . . . . . . . 6
2. Hardware Setup
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
3. Basic Operation
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2XRT-0018G KVM over IP Access Control Box . . . . . . . . . . . . . . . . . . . . . 9
LED statuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4. Operation
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Auto Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Timeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Private Mode (Console 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Screen Saver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
DIP Switch Settings Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Manual Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Hotkey Setting Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
HSM Summary Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
vi
CS231 / CS231TK User Manual
Keyboard Emulation Mapping. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Apple Keyboard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5. The Firmware Upgrade Utility
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Starting the Upgrade. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Upgrade Succeeded . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Upgrade Failed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Appendix
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
International . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
North America . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
vii
CS231 / CS231TK User Manual
About this Manual
This user manual is provided to help you get the most from the CS231 /
CS231TK unit. It covers all aspects of installation, configuration, and operation.
An overview of the information found in the manual is provided below.
Chapter 1, Introduction,
Its purpose, features, and benefits are presented, and its front and back panel
components are described.
Chapter 2, Hardware Setup,
quickly and safely set up your installation.
Chapter 3, Basic Operation,
in operating the CS231 / CS231TK.
introduces you to the CS231 / CS231TK system.
describes the steps that are necessary to
explains the fundamental concepts involved
Chapter 4, Operation, explains the CS231 / CS231TK’s operating and
hotkey settings mode as well as the EDID selection feature.
Chapter 5, The Firmware Upgrade Utility, explains how to use this
utility to upgrade the CS231 / CS231TK firmware to the latest available
version.
An Appendix, provides a list of safety instructions and precautions, contact
information for ATEN technical support, product specifications, and other
technical information.
Note:
Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit or any connected
devices.
ATEN regularly updates its product documentation for new features and
fixes. For an up-to-date CS231 / CS231TK documentation, visit
......................... http://www.aten.com/global/en/
viii
Conventions
This manual uses the following conventions:
Monospaced Indicates text that you should key in.
[ ] Indicates keys you should press. For example, [Enter] means to
press the Enter key. If keys need to be chorded, they appear
together in the same bracket with a plus sign between them:
[Ctrl+Alt].
1. Numbered lists represent procedures with sequential steps.
♦ Bullet lists provide information, but do not involve sequential steps.
→ Indicates selecting the option (on a menu or dialog box, for
example), that comes next. For example, Start
open the Start menu, and then select Run.
Indicates critical information.
Product Information
CS231 / CS231TK User Manual
→
Run means to
For information about all ATEN products and how they can help you connect
without limits, visit ATEN on the Web or contact an ATEN Authorized Reseller.
Visit ATEN on the Web for a list of locations and telephone numbers:
International http://www.aten.com
North America http://www.aten-usa.com
ix
CS231 / CS231TK User Manual
This Page Intentionally Left Blank
x
Chapter 1
Introduction
Overview
The CS231 / CS231TK is a powerful, micro-processor controlled computer
sharing device. It is a multi-user, single-tasking device that enables two users
to share the use of a single USB or PS/2 computer from two separate consoles
(USB keyboard, USB mouse, and monitor).
The CS231 / CS231TK is ideal for small office and home office (SOHO)
environments. All programs, files and resources on the computer can be easily
accessed and shared by both users without the bother and expense of setting up
a costly network environment.
CS231TK is CS231 that bundled with KVM over IP Access Control Box. The
2XRT-0018G KVM over IP Access Control Box allows users to enable or
disable remote over IP control privilege by simply pressing a control button.
It’s fast and easy to set up the 2XRT-0018G. Simply plug the 2XRT-0018G’s
cables to the CS231 / CS231TK. There is no need to install software or
configure devices - just plug and play,.
In addition, the cable length of the 2XRT-0018G reaches 5 meters, enabling
connection to the transmitter over longer distances for more flexible
installation.
1
Chapter 1. Introduction
Features
CS231 / CS231TK
Single computer shared by two USB consoles
Supports USB and PS/2 computers
Multiplatform support (Windows, Mac, Unix, and Linux)
Manual or Auto console selection
Control the system with Hotkeys
Firmware upgradable
Private Mode for a privileged user
Screen Saver function
Choose from four Timeout settings
Supports VGA, SVGA, and MultiSync monitors
No software required
2XRT-0018G KVM over IP Access Control Box
Users at the Tx local console can enable / disable Rx control privilege by
simply pressing a control button
Plug and play - no software installation required on either side
USB bus-powered design - no external power adapter required
Easy to operate
Cable length reaches 5m for more flexible installation
Note: 2XRT-0018G KVM over IP Access Control Box only comes in the
CS231TK package.
2
CS231 / CS231TK User Manual
System Requirements
Operating System:
Microsoft® Windows® 98SE, ME, 2000, XP, 2003 or later
Red Hat Linux 7.1, 7.2, 7.3, 8.0 or later
Mandriva Linux 9.0 or later
SUSE 8.2 or later
FreeBSD 4.2, 4.3, 4.5 or later
Netware 6.0 or later
Netware 5.0 (PS/2 computers only)
Mac OS 8.6, 9.0, 9.1, X, 10.1, 10.2, 10.3, 10.4 or later
Cables
Use ATEN's high-quality, custom cables to ensure reliable switching among
consoles. To purchase ATEN’s custom cables contact your dealer.
Description Part Number
PS/2 KVM Cables 2L-5202P (1.8 m)
2L-5203P (3 m)
2L-5206P (6 m)
USB KVM Cables 2L-5201U (1.2 m)
2L-5202U (1.8 m)
2L-5203U (3 m)
2L-5205U (5 m)
3
Chapter 1. Introduction
Components
CS231 / CS231TK Front View
No. Component Description
1 MANUAL/AUTO
Selection Button
This button is used to switch between Manual and Auto
Modes. The default is Auto Mode. Repeatedly pressing the
button cycles through the modes in the following order: Auto
Mode -> Console 1 (Manual) -> Console 2 (Manual) -> Auto
Mode.
2 C1 LED* Lights when Console 1 accesses the computer. Turns off
when Console 2 accesses the computer.
3 C2 LED* Lights when Console 2 accesses the computer. Turns off
4 MANUAL LED Lights to indicate that the CS231 / CS231TK is set to
when Console 1 accesses the computer.
Manual Mode. In Auto Mode the LED does not illuminate.
* In Auto Mode, when neither console is accessing the computer, both Console
LEDs are illuminated.
4
CS231 / CS231TK User Manual
CS231 / CS231TK Rear View
No. Component Description
1 Firmware Upgrade Port The firmware upgrade cable connects here and to
2 DIP Switch This is a 4-pin DIP switch. Use it to set the Timeout,
3 Reset Button Press this semi-recessed button to reset the system.
4 Console 2 Ports The cables from the VGA monitor and USB keyboard
5 Console 1 Ports The cables from the VGA monitor and USB keyboard
6 Power Jack The power adapter cable plugs in here.
7 PC Port* The 15-pin SPHD connector on the provided KVM
the administrator's computer to upgrade the firmware
(
see The Firmware Upgrade Utility
Private Mode, and Screen Saver functions (see DIP
Switch Settings Table, page 13).
and mouse of Console 2 plug in here.
and mouse of Console 1 plug in here.
cable plugs in here. At the other end of the cable, the
HDB-15 and USB connector plug into the
corresponding ports on the computer. If the computer
does not have an available USB port, a KVM cable
with PS/2 keyboard and mouse connectors may be
purchased separately.
, page 17).
* The shape and pin assignment of this 15-pin SPHD connector has been
specifically modified so that only KVM cables designed to work with this
switch may be used. Do NOT attempt to use a cable with ordinary 15-pin
VGA connectors to link this port to the computer.
5
Chapter 1. Introduction
4
2
3
5
1
2XRT-0018G KVM over IP Access Control Box
No. Component Description Indication
1 Control Button / LED Press the button to enable or disable
2 USB Connector Connects to a USB port to power on
3 PS/2 Connector Connects to the PS/2 port for control
4 RJ-11 Connector Connects to the RJ-11 port for
5 RJ-232 Connector Connects to the RS-232 port for
remote over IP control access.
the device.
access.
control access.
control access.
Front View
Lights red
Note: 2XRT-0018G KVM over IP Access Control Box only comes in the
CS231TK package.
6
Chapter 2
1. To prevent damage to your installation from power surges or
static electricity. It is important that all connected devices are
properly grounded.
2. Make sure that power to all the devices you will be connecting
up have been turned off. You must unplug the power cords of
any computers that have the Keyboard Power On function.
Hardware Setup
Before You Begin
Installing your new CS231 / CS231TK involves the following seven steps
(refer to the diagram on the following page):
1. Connect the 15-pin SPHD connector on the KVM cable to the PC port on
the CS231 / CS231TK.
2. Connect the VGA video connector on the KVM cable to the VGA video
output port on the computer. Plug the USB connector into any available
USB port.
3. Plug the keyboard, mouse and monitor for the console that you want to
designate as Console 1 into the Console 1 ports.
4. Plug the keyboard, mouse and monitor for the console that you want to
designate as Console 2 into the Console 2 ports.
5. Set the DIP switch (see DIP Switch Settings Table, page 13, for details).
6. Plug the RJ-11 connector of the 2XRT-0018G to the Firmware Upgrade
Port on the rear side of the CS231TK.
Note: This step is only for CS231TK that includes 2XRT-0018G KVM
over IP Access Control Box in the CS231TK package. If your
package is CS231, you can omit this step.
7. Plug the power adapter into an AC power source; plug the power adapter
cable into the power jack on the CS231 / CS231TK.
8. Power on the computer and monitors.
7
Chapter 2. Hardware Setup
Installation Diagram
8
Chapter 3
Basic Operation
Overview
For CS231TK that comes with the CS231 package including the 2XRT-0018G
KVM over IP Access Control Box. The 2XRT-0018G KVM over IP Access
Control Box allows users to enable or disable remote over IP control privilege
by simply pressing a control button.
2XRT-0018G KVM over IP Access Control Box
Note: 2XRT-0018G KVM over IP Access Control Box only comes in the
CS231TK package.
2XRT-0018G KVM over IP Access Control Box is a control button accessory
to enable / disable remote KVM over IP access.
LED statuses
Button Status LED Function
Pressed Red Light Disable remote access
Released Dim Enable remote access
9
CS231 / CS231TK User Manual
This Page Intentionally Left Blank
10
Chapter 4
Operation
Overview
The CS231 / CS231TK features two operation modes: Auto Mode and Manual
Mode.
Auto Mode
Auto Mode operates according to the following rules:
1. When the CS231 / CS231TK is turned on it starts in Auto Mode, and
operates on a first-come-first-served basis. B oth Console LEDs are On; the
Manual LED is Off.
2. The first user to strike the keyboard or move the mouse gains control of
the computer. As soon as this occurs:
The Console LED that corresponds to the user's console turns On.
The Console LED for the other console turns Off.
The CS231 / CS231TK locks onto that user's console.
A message appears on the other user’s monitor indicating that the
system is in use. After 10 seconds, the message disappears and the user
can view the computer display. If the user strikes the keyboard or moves
the mouse, the OSD message is displayed again.
The user who has control of the computer can prevent the other user
from viewing the computer display by entering the following Hotkey
combination:
[Num Lock]+[-],[D]
If the other user strikes the keyboard or moves the mouse, a message
appears indicating that the system is in use. After 10 seconds, the
message disappears and the monitor displays a black background. If the
user strikes the keyboard or moves the mouse, the OSD message is
displayed again.
3. If the user who has access does not strike the keyboard or move the mouse
before the Timeout Period (set with DIP switch pins 1 and 2) elapses:
The CS231 / CS231TK unlocks from that user's console;
Then, the CS231 / CS231TK switches to Auto Mode;
Both Console LEDs turn On;
The Manual LED is Off (since the CS231 / CS231TK is in Auto Mode);
Either console may take control of the computer.
11
Chapter 4. Operation
4. To terminate Auto Mode access, repeatedly press the MANUAL/AUTO
Button until the desired console controls the device.
Timeout
In Auto Mode, the setting of DIP switch pins 1 and 2 determines the amount of
time that passes from the last input by the controlling console to when the
console lock is released. Refer to the DIP Switch Settings Table, page 13 for
the pin settings and their corresponding Timeout lengths. (See page 11 for
more information about Auto Mode.)
Note: For best results, set the DIP switch pins BEFORE turning on either the
CS231 / CS231TK or the computer.
Private Mode (Console 1)
Private Mode operates within Auto Mode. In Private Mode, the Console 1 user
can control the computer, while preventing the Console 2 user from viewing
and controlling the computer. The Timeout Period does not apply in Private
Mode.
To enter Private Mode:
1. Make sure that the device is in Auto Mode and that DIP switch pin 3 is set
to the On position.
2. Wait for the Timeout period to expire.
3. From the keyboard of Console 1, press the Shift key six times within two
seconds.
After the Timeout Period expires, Console 1 will display the computer
desktop and have control of the computer. A message appears on the
monitor of Console 2 indicating that the system is in use. After 10 seconds,
the message disappears and the monitor displays a black background. If
the Console 2 user strikes the keyboard or moves the mouse, the OSD
message is displayed again.
To exit Private Mode:
1. From the keyboard of Console 1, press the Shift key six times within 2
seconds; or, press the MANUAL/AUTO Button.
Screen Saver
To protect the screen phosphors, when the CS231 / CS231TK is in Auto Mode
and no one is accessing the computer, a stripe image can scroll down the screen.
To enable this function, set DIP switch pin 4 to the On position.
12
CS231 / CS231TK User Manual
DIP Switch Settings Table
DIP Switch Pins Function
1 2 3 4
On On X X 5 Second Timeout
Off On X X 60 Second Timeout
On Off X X 125 Second Timeout
Off Off X X 255 Second Timeout
X X On X Private Mode Enabled
X X Off X Private Mode Disabled
X X X On Screen Saver Enabled
X X X Off Screen Saver Disabled
Note: Press a DIP switch pin down to turn it on, up to turn it off.
Manual Mode
Manual Mode is used to access the computer for a longer period of time. It is
invoked by repeatedly pressing the MANUAL/AUTO Button to bring the
focus to the desired console as follows:
Auto Mode > Console 1 > Console 2 > Auto Mode
When Manual Mode is invoked, the CS231 / CS231TK switches to the
selected console and prohibits the other console from controlling the
computer. The selected console retains control until the MANUAL/AUTO
Button is pressed again.
A message appears on the other user’s monitor indicating that the system is
in use. After 10 seconds, the message disappears and the user can view the
computer display. If the user strikes the keyboard or moves the mouse, the
OSD message is displayed again.
The user who has control of the computer can prevent the other user from
viewing the computer display by entering the following Hotkey
combination:
[Num Lock]+[-],[D]
If the other user strikes the keyboard or moves the mouse, a message
appears indicating that the system is in use. After 10 seconds, the message
disappears and the monitor displays a black background. If the user strikes
the keyboard or moves the mouse, the OSD message is displayed again.
13
Chapter 4. Operation
To switch to the other console, repeatedly press the Manual/Auto Mode Button
until the desired console controls the device, or enter the following hotkey
combination:
[Scroll Lock], [Scroll Lock], [Enter]
Note: 1. This hotkey combination is for CS231 only.
2. If using the Scroll Lock key conflicts with other programs running on
the computer, the Ctrl key can be used instead. See HSM Summary
Table, page 14, for details.
Hotkey Setting Mode
Hotkey Setting Mode is used to configure your CS231 / CS231TK switch. All
operations begin with invoking Hotkey Setting Mode (HSM).
Invoking HSM
To invoke HSM do the following:
1. Press and hold down the Num Lock key.
2. Press and release the minus [-] key.
3. Release the Num Lock key.
Note: 1. The minus key must be released within one-half second, otherwise
Hotkey invocation is canceled.
2. There is an alternate key combination to invoke HSM. See HSM
Summary Table, page 14, for details.
HSM Summary Table
After invoking HSM (see page 14), key in one of the following keys to perform
the corresponding function:
Key Function
[F1] Sets the PC keyboard layout.
[F2] Sets the Apple keyboard layout. (Set this before turning on the Mac
[F4] Lists the current hotkey settings via the Paste function of a text
[F5] Performs a USB reset.
14
computer.)
editor.
CS231 / CS231TK User Manual
[D] Turn the other console's monitor off or on. (This setting applies until
changed or until the device is powered off.)
[H] Toggles between the default and alternate HSM invocation keys. The
[R], [Enter] Restores the default Hotkey settings.
[T] Toggles between the default and alternate console switching keys.
[upgrade],
[Enter]*
alternate HSM invocation keys are [Ctrl] + [F12].
The default console switching keys are [Scroll Lock] [Scroll Lock]
[Enter]. The alternate console switching keys are [Ctrl] [Ctrl] [Enter].
Invokes Firmware Upgrade Mode.
* Key in the letters u-p-g-r-a-d-e, and then press [Enter].
Keyboard Emulation Mapping
Apple Keyboard
The PC compatible (101/104 key) keyboard can emulate the functions of the
Apple keyboard. The corresponding functions are shown in the table below.
Note: When using hotkey combinations, press and release the first key, then
press and release the second one.
PC Keyboard Mac Keyboard
[Shift] Shift
[Ctrl] Ctrl
[Ctrl], [1]
[Ctrl], [2]
[Ctrl], [3]
[Ctrl], [4]
[Alt] Alt
[Print Screen] F13
[Scroll Lock] F14
=
15
Chapter 4. Operation
[Enter] Return
[Backspace] Delete
[Insert] Help
[Ctrl],
F15
16
Chapter 5
The Firmware Upgrade Utility
Introduction
The Windows-based Firmware Upgrade Utility (FWUpgrade.exe) provides a
smooth, automated process for upgrading the computer sharing device’s
firmware.
The Utility comes as part of a Firmware Upgrade Package that is specific for
each device. New firmware upgrade packages are posted on our Website as
new firmware revisions become available. Check our Website regularly to find
the latest packages and information relating to them.
Before You Begin
To prepare for the firmware upgrade, do the following:
1. From a computer that is not part of your installation, go to our Website and
choose the model name that relates to your device (CS231 / CS231TK) to
get a list of available Firmware Upgrade Packages.
2. Choose the Firmware Upgrade Package you want to install (usually the
most recent) and download it to your computer.
3. Shut down the computer(s) on your CS231 / CS231TK installation.
4. Connect the provided firmware upgrade cable to the firmware upgrade
port on the CS231 / CS231TK and to a COM port on the computer you
used to download the Firmware Upgrade Package.
5. From the console connected to the CS231 / CS231TK, invoke HSM (see
page 14). Key in the letters u-p-g-r-a-d-e, and then press [Enter]. When in
firmware upgrade mode the front panel LEDs flash in unison.
Starting the Upgrade
To upgrade your firmware:
1. Run the downloaded Firmware Upgrade Package file - either by double
clicking the file icon, or by opening a command line and entering the full
path to it.
The Firmware Upgrade Utility Welc om e screen appears:
17
CS231 / CS231TK User Manual
2. Read and Agree to the License Agreement (enable the I Agree radio
button).
3. Click Next to continue. The Firmware Upgrade Utility main screen
appears:
The Utility inspects your installation. All the devices capable of being
upgraded by the package are listed in the Device List panel.
4. As you select a device in the list, its description appears in the Device
Description panel.
5. After you have made your device selection(s), Click Next to perform the
upgrade.
18
Chapter 5. The Firmware Upgrade Utility
If you enabled Check Firmware Version, the Utility compares the device's
firmware level with that of the upgrade files. If it finds that the device's
version is higher than the upgrade version, it brings up a dialog box
informing you of the situation and gives you the option to Continue or
Cancel.
If you did not enable Check Firmware Version, the Utility installs the
upgrade files without checking whether or not they are a higher level.
As the Upgrade proceeds, status messages appear in the Status Messages
panel, and the progress toward completion is shown on the Progress bar.
Upgrade Succeeded
After the upgrade has completed, a screen appears to inform you that the
procedure was successful:
Click Finish to close the Firmware Upgrade Utility.
After a successful completion, the switches exit Firmware Upgrade Mode.
19
CS231 / CS231TK User Manual
Upgrade Failed
If the Upgrade Succeeded screen does not appear, then the upgrade failed to
complete successfully. You should repeat the upgrade procedure from the
beginning.
20
Appendix
Safety Instructions
General
This product is for indoor use only.
Read all of these instructions. Save them for future reference.
Follow all warnings and instructions marked on the device.
Do not place the device on any unstable surface (cart, stand, table, etc.). If
the device falls, serious damage will result.
Do not use the device near water.
Do not place the device near, or over, radiators or heat registers.
The device cabinet is provided with slots and openings to allow for
adequate ventilation. To ensure reliable operation, and to protect against
overheating, these openings must never be blocked or covered.
The device should never be placed on a soft surface (bed, sofa, rug, etc.) as
this will block its ventilation openings. Likewise, the device should not be
placed in a built in enclosure unless adequate ventilation has been provided.
Never spill liquid of any kind on the device.
Unplug the device from the wall outlet before cleaning. Do not use liquid
or aerosol cleaners. Use a damp cloth for cleaning.
The device should be operated from the type of power source indicated on
the marking label. If you are not sure of the type of power available,
consult your dealer or local power company.
To prevent damage to your installation it is important that all devices are
properly grounded.
Do not allow anything to rest on the power cord or cables. Route the
power cord and cables so that they cannot be stepped on or tripped over.
Position system cables and power cables carefully; Be sure that nothing
rests on any cables.
Never push objects of any kind into or through cabinet slots. They may
touch dangerous voltage points or short out parts resulting in a risk of fire
or electrical shock.
21
Appendix
Do not attempt to service the device yourself. Refer all servicing to
qualified service personnel.
If the following conditions occur, unplug the device from the wall outlet
and bring it to qualified service personnel for repair.
The power cord or plug has become damaged or frayed.
Liquid has been spilled into the device.
The device has been exposed to rain or water.
The device has been dropped, or the cabinet has been damaged.
The device exhibits a distinct change in performance, indicating a need
for service.
The device does not operate normally when the operating instructions
are followed.
Only adjust those controls that are covered in the operating instructions.
Improper adjustment of other controls may result in damage that will
require extensive work by a qualified technician to repair.
Do not connect the RJ-11 connector marked “UPGRADE” to a public
telecommunication network.
22
CS231 / CS231TK User Manual
Technical Support
International
For online technical support – including troubleshooting, documentation,
and software updates: http://support.aten.com
For telephone support, see Telephone Support, page iv:
North America
Email Support support@aten-usa.com
Online Technical
Support
Telephone Support 1-888-999-ATEN ext 4988
When you contact us, please have the following information ready beforehand:
Product model number, serial number, and date of purchase
Your computer configuration, including operating system, revision level,
expansion cards, and software
Any error messages displayed at the time the error occurred
The sequence of operations that led up to the error
Any other information you feel may be of help
Troubleshooting
Documentation
Software Updates
http://www.aten-usa.com/support
23
Appendix
Specifications
Function CS231
Computer Connections 1
Console Connections 2
Console Selection Hotkey, Pushbutton
Connectors Console
Switches Mode Selection 1 x Pushbutton
LEDs Manual 1 (Orange)
Video 1920x1440@60Hz; DDC2B
Timeout Settings 5, 60, 125, 255 Seconds
Power Consumption DC 5.3V, 1.6W, 16BTU
Environment Operating Temp. 0–50° C
Physical
Properties
Port
Computer Port 1 x SPHD-15 Female (Green)
F/W Upgrade 1 x RJ-11 Female (Black)
Power 1 x DC Jack (Black)
Reset 1 x Semi-recessed Pushbutton
DIP 1 x 4-pin
Selected 2 (Green)
Storage Temp. -20–60° C
Humidity 0–80% RH, Non-condensing
Housing Metal
Weight 0.56 kg (1.23 lb)
Dimensions (L x W x H) 14.00 x 8.80 x 5.55 cm
Keyboard 2 x USB Type A Female (White)
Video 2 x HDB-15 Female (Blue)
Mouse 2 x USB Type A Female (White)
(5.51 x 3.46 x 2.19 in.)
Function 2XRT-0018G
Connectors
Link USB, PS/2, RJ-11, RS-232
24
CS231 / CS231TK User Manual
Function 2XRT-0018G
LEDs
Status Pressed: Red Light
Physical Properties
Housing Plastic
Weight 0.43 kg (0.95 lb)
Dimensions (L x W x H)
Released: Dim
7.2 x 10.39 x 11.00 cm
(2.83 x 4.09 x 4.33 in.)
Note: 2XRT-0018G KVM over IP Access Control Box only comes in the
CS231TK package.
Troubleshooting
Problem Solution
Nothing happens when I
move the mouse or
press keys on the
keyboard.
I am using two monitors
with differing screen
resolutions. Why can’t I
see the entire desktop
on the monitor with the
higher resolution?
After setting a PC
keyboard to emulate the
Apple keyboard layout, it
still is not emulating the
Mac keyboard.
1. Ensure that the KVM cable connectors are firmly
secured to the computer port on the CS231 / CS231TK
and to the keyboard and mouse ports on the computer
before connecting the power cable or turning on the
computer.
2. Press the Manual/Auto Mode Button to switch the console.
The monitor with the lowest screen resolution sets the
maximum screen resolution that can be used. Choose a
screen resolution in the computer’s graphics card that is
supported by both monitors.
Restart the computer.
25
Appendix
Limited Warranty
ATEN warrants its hardware in the country of purchase against flaws in
materials and workmanship for a Warranty Period of two [2] years (warranty
period may vary in certain regions/countries) commencing on the date of
original purchase. This warranty period includes the LCD panel of ATEN LCD
KVM switches. Select products are warranted for an additional year (see A+
Warranty for further details). Cables and accessories are not covered by the
Standard Warranty.
What is covered by the Limited Hardware Warranty
ATEN will provide a repair service, without charge, during the Warranty
Period. If a product is detective, ATEN will, at its discretion, have the option
to (1) repair said product with new or repaired components, or (2) replace the
entire product with an identical product or with a similar product which fulfills
the same function as the defective product. Replaced products assume the
warranty of the original product for the remaining period or a period of 90 days,
whichever is longer. When the products or components are replaced, the
replacing articles shall become customer property and the replaced articles
shall become the property of ATEN.
To learn more about our warranty policies, please visit our website:
http://www.aten.com/global/en/legal/policies/warranty-policy/
