Built on the proven track record of the classic vbSeries® portable vibration analyzers and balancers, the all-new vbSeries data collectors, analyzers, and balancers have been re-engineered from the ground up to offer leading-edge reliability, accuracy and usability.
Improved ergonomics for walk
around data collection
Large, high resolution (HVGA) backlit LCD
True left- and right-handed operation
Multi-channel on route recordings
(collectors and analyzers only)
1 GB memory – virtually unlimited
spectra and waveform storage
10 hour battery life
Lightweight, rugged IP65 rated cases
DC coupled sensor support
12 800 lines of resolution (max)
40 kHz Fmax
Single, Dual or Four-channel
recordings depending on model
Triax. compatibility (vb6™ and
vb8™ instruments only)
CSA Class I, Division 2 Hazardous
Locations certication
USB host port for data transfer to
external USB memory
Choose the model most suitable for your needs.
Our tiered instrument range allows you to select an appropriate set of features at a cost effective price. Choose a model tailored to your requirements with the added peace of mind provided by our rock solid 5 year warranty.
Data Collectors Data Analyzers Balancers
Lean vb5 vb7 vbBalancer
Deluxe vb6 vb8 vbBalancer+
THE COMPLETE VIBRATION ANALYSIS PACKAGE
The vb8™ analyzer is a uniquely sophisticated and feature-packed instrument, yet it remains intuitive in operation and exible enough to suit every level of vibration analyst, from novice through to expert.
The included Ascent® software contains the collective experience of over 25 years of expert in-depth machine fault analysis.
1. Users with no prior experience or without previously recorded vibration history can now establish a measurement program utilizing proven baseline values from ISO standards and “The Proven Method” from Technical Associates.*
2. Experienced users can now generate meaningful spectral alarm bands automatically rather than just relying on basic overall alarms or spectral band guesswork.
3. Veteran analysts can now objectively evaluate and compare their ndings against a time-tested and proven historical foundation.
Ascent® Level 2 software:
• Fully automated measurement parameter and alarm setups based on “The Proven Method” from Technical Associates*
• ISO 2372 and 10816 standards
* The incorporation of The Proven Method is
available exclusively in Ascent® software
Enhanced instrument functionality
• 4 channel simultaneous recordings
• Triax. enabled
• 12 800 line FFT resolution
• 40 kHz Fmax
• 1 GB memory – virtually unlimited spectra storage
• Large, high resolution (HVGA) backlit LCD
• Comfortable, ergonomic case design
• Support for acceleration, velocity, displacement, DC coupled, current and voltage output sensors (both AC and DC coupled)
• 2 plane balancing with up to 4 sensors (simultaneous acquisition)
• Commtest’s unique 6Pack™ recording system: take up to 12 measurements simultaneously (HF, LF and Demodulation spectra and waveforms) across two channels
• Numeric parameter input via keypad with trend and alarm capability in Ascent® software
• Upgradeable using the ‘Proash’ system and free rmware updates for ve years
EASY AND EFFICIENT TWO CHANNEL CAPABILITY
The vb7™ analyzer offers the power and convenience of dual-channel measurement and dual-plane balancing. Its balancing functions enable the quick diagnosis and correction of dynamic unbalance, the most common form of unbalance. The vb7 instrument’s combination of accuracy, intuitive operation, ease of use and outstanding storage capacity ensures the vb7 analyzer delivers a premium return on investment. The vb7 instrument includes the powerful Ascent® software in the purchase price.
Ascent Level 2 enables you to program the instrument with thousands of separate machine denitions covering a number of route choices. A library of over 300 customizable parameter sets is also available enabling a vast array of measurement options.
Ascent Level 2 software:
• Route enabled - build routes in Ascent software and send to the instrument
• CBDb - Commtest Bearing Database with over 30 000 bearings
• Orbit and Bode plots
• Waveform analysis tools - perfect for the power user
• User-designable SQL/HTML reports - unlimited reporting exibility
• Statistical alarm creation and adjustment
Enhanced instrument functionality
• Improved ergonomics for walk around data collection
• 2 channel simultaneous recordings
• True left- and right-handed operation
• Wide measurement range: 1000 g, 25 000 mm/s, 2500mm
• 2 plane balancing
95 dB dynamic range
• 6400 line FFT resolution
• 40 kHz Fmax
• 1 GB memory – virtually unlimited spectra and waveform storage
• Laser speed sensor for automatic capture of machine running speed
• Keyphasor® tach mode
• 5 year warranty on the instrument hardware
HIGH RESOLUTION, FOUR CHANNEL MEASUREMENTS FOR PROACTIVE MAINTENANCE PROFESSIONALS
The vb6™ data collector is a four channel, route­enabled product that provides everything needed for advanced, high resolution data collection. This instrument includes a wide range of recording and measurement types at up to 12 800 lines of resolution. The vb6 includes the powerful Ascent® software in the purchase price.
Ascent Level 1 enables you to program the instrument with thousands of separate machine denitions covering a number of route choices. A library of over 300 customizable parameter sets is also available enabling a vast array of measurement options.
Ascent Level 1 software:
• Route enabled - build routes in Ascent software and send to the instrument
• CBDb - Commtest Bearing Database with over 30 000 bearings
Enhanced instrument functionality
• 4 channel simultaneous recordings
• 12 800 line FFT resolution
• 40 kHz Fmax
• Laser speed sensor for automatic capture of machine running speed
• 1 GB memory – virtually unlimited spectra storage
95 dB dynamic range
• Large, high resolution (HVGA) backlit LCD
• Voltage output sensor support
• User-dened recordings for Temperature, Pressure, Mass Flow, Force and Power
• 5 year warranty on the instrument hardware
THE ECONOMICAL SOLUTION FOR THE PROACTIVE MAINTENANCE PROFESSIONAL
The vb5™ data collector is a single channel, route­enabled product that provides everything needed for cost effective data collection and analysis. Using this instrument maintenance professionals are able to easily take recordings with up to 6400 lines of resolution and greater than 95 dB of dynamic range, and all at a low price that represents exceptional value for money. The vb5 instrument includes the powerful Ascent® software in the purchase price.
Ascent Level 1 enables you to program the instrument with thousands of separate machine denitions covering a number of route choices. A library of over 300 customizable parameter sets is also available enabling a vast array of measurement options.
Ascent Level 1 software:
• Route enabled - build routes in Ascent software and send to the instrument
• CBDb - Commtest Bearing Database with over 30 000 bearings
Enhanced instrument functionality
• 1 channel recordings
• 6400 line FFT resolution
• 40 kHz Fmax
• 1 GB memory – virtually unlimited spectra storage
95 dB dynamic range
• Spectrum and Waveform recordings
• Large, high resolution (HVGA) backlit LCD
• 5 year warranty on the instrument hardware
FOUR CHANNEL UNBALANCE CORRECTION PACKAGE
Lightweight and extremely portable, the vbBalancer+™ 4 channel and vbBalancer™ 2
channel instruments are easily carried on site to
any problematic machine. Their 10 hour battery life and 1 GB of internal memory ensure progress is uninterrupted, practically eliminating the need to pause in order to connect to a PC or power supply.
The vbBalancer instruments also carry Commtest’s
legendary 5 year warranty and free lifetime support as standard.
Unbalance causes high levels of mechanical stress and vibration that are transferred directly to the bearings resulting in a proportional reduction in normal bearing life. With a few basic parameters the vbBalancer instruments calculate acceptable unbalance levels to ensure machinery operates within international ISO 1940 guidelines.
Setup vbBalancer instrument setup is minimal, quick and
easy. Only a few calibration runs are required, with or without removing your trial weight.
Memory
The vbBalancer instrument stores your previous balance run data. No need to waste valuable time performing calibration runs on repetitive or routine balance jobs.
Balance
Unbalance is computed quickly and the large backlit LCD display and user-friendly graphical interface indicate the angular position for weight correction.
The vbBalancer+ instrument allows full 4-sensor monitoring of both horizontal and vertical axes on each bearing. This ability provides condence that a balance on any one axis has not worsened vibrations on the other.
DATA COLLECTORS DATA ANALYZERS BALANCERS
SPECIFICATIONS vb5 vb6 vb7 vb8 vbBalancer vbBalancer+ REMARKS
Sensor Input
Channels (simultaneous)
1 4 2 4 2 4 Simultaneous sampling
Sensors
Accelerometer
Accelerometer, Velocity, Displacement, Current, Voltage
Accelerometer, Velocity, Displacement, Current
Accelerometer, Velocity, Displacement, Current, Voltage
Accelerometer
Accelerometer, Velocity, Displacement
AC coupled range
16 V peak-peak 16 V peak-peak 16 V peak-peak 16 V peak-peak 16 V peak-peak 16 V peak-peak
Allows for ± 8 V sensor output swing (± 80 g)
DC coupled range
0 V to 20 V, -10 V to 10 V,
-20 V to 0 V
0 V to 20 V, -10 V to 10 V,
-20 V to 0 V
0 V to 20 V, -10 V to 10 V,
-20 V to 0 V
e.g. for reading prox-probe gap
Connectors
BNC BNC, LEMO 2x BNC BNC, LEMO 2x BNC BNC, LEMO Safety feature: Break-free inline connector
Analog to digital conversion
24-bit ADC 24-bit ADC 24-bit ADC 24-bit ADC 24-bit ADC 24-bit ADC
Sensor excitation current
0 mA or 2.2 mA (congurable), 24 V maximum
0 mA or 2.2 mA (congurable), 24 V maximum
0 mA or 2.2 mA (congurable), 24 V maximum
0 mA or 2.2 mA (congurable), 24 V maximum
0 mA or 2.2 mA (congurable), 24 V maximum
0 mA or 2.2 mA (congurable), 24 V maximum
2.2 mA required for ICP®-type accelerometer
Sensor detection
Warns if short circuit or not connected
Warns if short circuit or not connected
Warns if short circuit or not connected
Warns if short circuit or not connected
Warns if short circuit or not connected
Warns if short circuit or not connected
Tachometer
Sensor
Laser sensor with reective tape included in kit
Laser sensor with reective tape included in kit
Laser sensor with reective tape included in kit
Laser sensor with reective tape included in kit
Sensor triggers on beam reection
Laser sensor range
10 cm to 2 m nominal 10 cm to 2 m nominal 10 cm to 2 m nominal 10 cm to 2 m nominal 10 cm to 2 m nominal 10 cm to 2 m nominal Dependent on size of reective tape
Other Sensor types supported
Contact, TTL pulse
Contact, TTL pulse, Keyphasor®
Contact, TTL pulse, Keyphasor®
Contact, TTL pulse, Keyphasor®
Contact, TTL pulse
Contact, TTL pulse, Keyphasor®
Optically isolated input
Power supply to sensor
5 V, 50 mA 5 V, 50 mA 5 V, 50 mA 5 V, 50 mA 5 V, 50 mA 5 V, 50 mA
TTL Pulse rating
3.5 V (4 mA) min, 28 V (6 mA) max, off-state 0.8 V
3.5 V (4 mA) min, 28 V (6 mA) max, off-state 0.8 V
3.5 V (4 mA) min, 28 V (6 mA) max, off-state 0.8 V
3.5 V (4 mA) min, 28 V (6 mA) max, off-state 0.8 V
3.5 V (4 mA) min, 28 V (6 mA) max, off-state 0.8 V
3.5 V (4 mA) min, 28 V (6 mA) max, off-state 0.8 V
Keyphasor® threshold
13 V ± 1 V 13 V ± 1 V 13 V ± 1 V 13 V ± 1 V
Speed range
30 RPM to 300 000 RPM (0.5 Hz to 5 kHz)
30 RPM to 300 000 RPM (0.5 Hz to 5 kHz)
30 RPM to 300 000 RPM (0.5 Hz to 5 kHz)
30 RPM to 300 000 RPM (0.5 Hz to 5 kHz)
30 RPM to 300 000 RPM (0.5 Hz to 5 kHz)
30 RPM to 300 000 RPM (0.5 Hz to 5 kHz)
Parameter Indication
Maximum levels
›1000 g (10 000 m/s2), ›1000 in/sec (25 000 mm/s), ›100 in (2500 mm)
›1000 g (10 000 m/s2), ›1000 in/sec (25 000 mm/s), ›100 in (2500 mm), ›10 000 Amps
›1000 g (10 000 m/s2), ›1000 in/sec (25 000 mm/s), ›100 in (2500 mm), ›10 000 Amps
›1000 g (10 000 m/s2), ›1000 in/sec (25 000 mm/s), ›100 in (2500 mm), ›10 000 Amps
›1000 g (10 000 m/s2), ›1000 in/sec (25 000 mm/s), ›100 in (2500 mm)
›1000 g (10 000 m/s2), ›1000 in/sec (25 000 mm/s), ›100 in (2500 mm)
Effective limit is sensor sensitivity and output voltage
Dynamic signal range
›95 dB ›95 dB ›95 dB ›95 dB ›95 dB ›95 dB
Harmonic distortion
Less than -70 dB typical Less than -70 dB typical Less than -70 dB typical Less than -70 dB typical Less than -70 dB typical Less than -70 dB typical Other distortions and noise are lower
Units
g or m/s2, in/s or mm/s, mil or mm or μm adB, vdB
g or m/s2, in/s or mm/s, mil or mm or μm adB, vdB, amps and user-dened
g or m/s2, in/s or mm/s, mil or mm or μm adB, vdB, amps
g or m/s2, in/s or mm/s, mil or mm or μm adB, vdB, amps and user-dened
g or m/s2, in/s or mm/s, mil or mm or μm adB, vdB
g or m/s2, in/s or mm/s, mil or mm or μm adB, vdB
0-peak, peak-peak or RMS. Auto-scale by 1000x when required US & SI options for both adB & vdB
Magnitude & Cursors
Overall RMS value, dual cursors, harmonics
Overall RMS value, dual cursors, harmonics
Overall RMS value, dual cursors, harmonics
Overall RMS value, dual cursors, harmonics
Overall RMS value, dual cursors, harmonics
Overall RMS value, dual cursors, harmonics
Digital readouts on chart
Accuracy
± 1% (0.1 dB) ± 1% (0.1 dB) ± 1% (0.1 dB) ± 1% (0.1 dB) ± 1% (0.1 dB) ± 1% (0.1 dB) For DC level (%F.S.) & AC measured at 100 Hz
Frequency response
± 0.1 dB from 10 Hz to 15 kHz; ± 3 dB from 1 Hz to 40 kHz
± 0.1 dB from 10 Hz to 15 kHz; ± 3 dB from 1 Hz to 40 kHz
± 0.1 dB from 10 Hz to 15 kHz; ± 3 dB from 1 Hz to 40 kHz
± 0.1 dB from 10 Hz to 15 kHz; ± 3 dB from 1 Hz to 40 kHz
± 3 dB from 1 Hz to 5 kHz ± 3 dB from 1 Hz to 5 kHz
Acceleration and velocity. From value measured at 100 Hz
Spectrum Display
Fmax possible ranges
25, 50, 100, 125, 150, 200, 300, 400, 500, 600, 800, 1000, 1200, 1600, 2000, 2500, 3000, 4000, 5000, 6000, 8000, 10 000, 15 000, 20 000, 30 000, 40 000 Hz
25, 50, 100, 125, 150, 200, 300, 400, 500, 600, 800, 1000, 1200, 1600, 2000, 2500, 3000, 4000, 5000, 6000, 8000, 10 000, 15 000, 20 000, 30 000, 40 000 Hz
25, 50, 100, 125, 150, 200, 300, 400, 500, 600, 800, 1000, 1200, 1600, 2000, 2500, 3000, 4000, 5000, 6000, 8000, 10 000, 15 000, 20 000, 30 000, 40 000 Hz
25, 50, 100, 125, 150, 200, 300, 400, 500, 600, 800, 1000, 1200, 1600, 2000, 2500, 3000, 4000, 5000, 6000, 8000, 10 000, 15 000, 20 000, 30 000, 40 000 Hz
25, 50, 100, 125, 150, 200, 300, 400, 500, 600, 800,1000, 1200, 1600, 2000, 2500, 3000, 4000, 5000 Hz
25, 50, 100, 125, 150, 200, 300, 400, 500, 600, 800,1000, 1200, 1600, 2000, 2500, 3000, 4000, 5000 Hz
Or equivalent CPM values Or orders-based from 1X to 999X
Fmin possible range
0 to Fmax 0 to Fmax 0 to Fmax 0 to Fmax 0 to Fmax 0 to Fmax
vb instrument zeroes all spectral lines below Fmin
Resolution
400, 800, 1600, 3200, 6400 lines
400, 800, 1600, 3200, 6400, 12 800 lines
400, 800, 1600, 3200, 6400 lines
400, 800, 1600, 3200, 6400, 12 800 lines
800 lines 800 lines
3200 lines max. for dual channel measurements
Frequency scale
Hz, CPM, Orders Hz, CPM, Orders Hz, CPM, Orders Hz, CPM, Orders Hz, CPM Hz, CPM Linear scale with zooming
Amplitude scale
Acceleration, velocity, displacement
Acceleration, velocity, displacement, current or user dened
Acceleration, velocity, displacement or current
Acceleration, velocity, displacement, current or user dened
Acceleration, velocity or displacement
Acceleration, velocity or displacement
Linear or log scales, auto or manual scaling
Window shapes
Hanning, rectangular Hanning, rectangular Hanning, rectangular Hanning, rectangular Hanning Hanning
Overlap
(0, 12.5, 25, 37.5, 50, 62.5, 75, 87.5) %
(0, 12.5, 25, 37.5, 50, 62.5, 75, 87.5) %
(0, 12.5, 25, 37.5, 50, 62.5, 75, 87.5) %
(0, 12.5, 25, 37.5, 50, 62.5, 75, 87.5) %
50% 50% Dependent on Fmax and number of lines
Number of averages
1, 2, 4, 8, 16, 32, 64, 128 1, 2, 4, 8, 16, 32, 64, 128 1, 2, 4, 8, 16, 32, 64, 128 1, 2, 4, 8, 16, 32, 64, 128 4 4
Increases sampling time proportionally
Averaging types
Linear, exponential, peak hold
Linear, exponential, peak hold
Linear, exponential, peak hold, synchronous
Linear, exponential, peak hold, synchronous
Linear Linear
Demodulation bandwidths
21 bandwidth options 21 bandwidth options 21 bandwidth options 21 bandwidth options
Waveform Display
Number of samples
1024, 2048, 4096, 8192, 16 384
1024, 2048, 4096, 8192, 16 384, 32 768
1024, 2048, 4096, 8192, 16 384
1024, 2048, 4096, 8192, 16 384, 32 768
2048 2048
Time scale
10 ms to 640 seconds 10 ms to 640 seconds 10 ms to 640 seconds 10 ms to 640 seconds 160 ms to 32 seconds 160 ms to 32 seconds Or orders based from 1 to 999 revs
Time synchronous averages
Long time waveform
Up to 40 kHz Fmax (28 M samples)
Up to 40 kHz Fmax (28 M samples)
1, 2, 4, 8, 16, 32, 64, 128 1, 2, 4, 8, 16, 32, 64, 128 Only available when tachometer triggered
DATA COLLECTORS DATA ANALYZERS BALANCERS
SPECIFICATIONS vb5 vb6 vb7 vb8 vbBalancer vbBalancer+ REMARKS
Logging Features
Data storage 1 GB 1 GB 1 GB 1 GB 1 GB 1 GB
Data storage structure
Direct print reports
Folders / machines / points / locations /routes
10 000 measurement locations
Folders / machines / points / locations /routes
10 000 measurement locations
Folders / machines / points / locations /routes
10 000 measurement locations
Via Ethernet to PCL-enabled printer
Folders / machines / points / locations /routes
10 000 measurement locations
Via Ethernet to PCL-enabled printer
Folders / Machines Folders / Machines No limits are applied, 50 character names
10 000 measurement locations
Via Ethernet to PCL-enabled printer
10 000 measurement locations
Via Ethernet to PCL-enabled printer
Balance reports
Balancing
Planes 2 planes, 2 sensors 2 planes, 4 sensors 2 planes, 2 sensors 2 planes, 4 sensors
Speed range 30 to 60 000 RPM 30 to 60 000 RPM 30 to 60 000 RPM 30 to 60 000 RPM
Measurement type
Weight modes
Remove trial weights Yes, No Yes, No Yes, No Yes, No Removed weight automatic recalculation
Manual data entry Allows re-entry of previous balance jobs
Storage
Channel selection Single or dual channel
Acceleration, velocity, displacement
Angle 0° to 360°, xed position, circumference arc
Against machines in data structure
Acceleration, velocity, displacement
Angle 0° to 360°, xed position, circumference arc
Against machines in data structure
Up to 4 channels simultaneous
Acceleration, velocity, displacement
Angle 0° to 360°, xed position, circumference arc
Against machines in data structure
Single or dual channel
Acceleration, velocity, displacement
Angle 0° to 360°, xed position, circumference arc
Against machines in data structure
Up to 4 channels simultaneous
e.g. weights on fan blades, linear dist around circumference
No limits are applied
Display & Communications
Resolution
Viewing area 4.6” x 3.1” (117 x 79) mm 4.6” x 3.1” (117 x 79) mm 4.6” x 3.1” (117 x 79) mm 4.6” x 3.1” (117 x 79) mm 4.6” x 3.1” (117 x 79) mm 4.6” x 3.1” (117 x 79) mm
Backlight White LED, 4V, 100 Cd/m2 White LED, 4V, 100 Cd/m2 White LED, 4V, 100 Cd/m2 White LED, 4V, 100 Cd/m2 White LED, 4V, 100 Cd/m2 White LED, 4V, 100 Cd/m2
Communications with PC USB and Ethernet USB and Ethernet USB and Ethernet USB and Ethernet USB and Ethernet USB and Ethernet
USB host port Save folders to USB ash drive
480 x 320 pixels (HVGA) Graphic Greyscale LCD
480 x 320 pixels (HVGA) Graphic Greyscale LCD
480 x 320 pixels (HVGA) Graphic Greyscale LCD
480 x 320 pixels (HVGA) Graphic Greyscale LCD
480 x 320 pixels (HVGA) Graphic Greyscale LCD
480 x 320 pixels (HVGA) Graphic Greyscale LCD
Route/Measurement transfer and Proash rmware upgrade
Battery & Charger
Battery Type
Operating time 10 hours 10 hours 10 hours 10 hours 10 hours 10 hours Backlight on (60 second timeout)
Charger type
Charge rate 3 A nominal 3 A nominal 3 A nominal 3 A nominal 3 A nominal 3 A nominal 3 hours for complete charge
Custom Lithium Ion pack,
7.4 V, 4500 mAh
Internal charging, automatic control
Custom Lithium Ion pack,
7.4 V, 4500 mAh
Internal charging, automatic control
Custom Lithium Ion pack,
7.4 V, 4500 mAh
Internal charging, automatic control
Custom Lithium Ion pack,
7.4 V, 4500 mAh
Internal charging, automatic control
Custom Lithium Ion pack,
7.4 V, 4500 mAh
Internal charging, automatic control
Custom Lithium Ion pack,
7.4 V, 4500 mAh
Internal charging, automatic control
External Power pack 12 V DC, 3 A output, included in kit
Mechanical
Size
Weight
9.9” W x 5.8” L x 2.4” H (252 x 148x 60) mm
2.7 lb (1.2 kg) including battery
Environmental
Operating Temp 14 °F to 122 °F (-10 to 50) °C 14 °F to 122 °F (-10 to 50) °C 14 °F to 122 °F (-10 to 50) °C 14 °F to 122 °F (-10 to 50) °C 14 °F to 122 °F (-10 to 50) °C 14 °F to 122 °F (-10 to 50) °C
Storage Temp & Humidity
EMC EN61326 EN61326 EN61326 EN61326 EN61326 EN61326
Ruggedness
Hazardous Locations
Certication
-4 °F to 140 °F (-20 to 60) °C, 95% RH
IP65 / 4’ (1.2 m) drop onto concrete / MIL-STD-810F-IV
CSA Class I, Division 2 (Groups A, B, C, D)
9.9” W x 5.8” L x 2.4” H (252 x 148x 60) mm
2.7 lb (1.2 kg) including battery
-4 °F to 140 °F (-20 to 60) °C, 95% RH
IP65 / 4’ (1.2 m) drop onto concrete / MIL-STD-810F-IV
CSA Class I, Division 2 (Groups A, B, C, D)
9.9” W x 5.8” L x 2.4” H (252 x 148x 60) mm
2.7 lb (1.2 kg) including battery
-4 °F to 140 °F (-20 to 60) °C, 95% RH
IP65 / 4’ (1.2 m) drop onto concrete / MIL-STD-810F-IV
CSA Class I, Division 2 (Groups A, B, C, D)
9.9” W x 5.8” L x 2.4” H (252 x 148x 60) mm
2.7 lb (1.2 kg) including battery
-4 °F to 140 °F (-20 to 60) °C, 95% RH
IP65 / 4’ (1.2 m) drop onto concrete / MIL-STD-810F-IV
CSA Class I, Division 2 (Groups A, B, C, D)
9.9” W x 5.8” L x 2.4” H (252 x 148x 60) mm
2.7 lb (1.2 kg) including battery
-4 °F to 140 °F (-20 to 60) °C, 95% RH
IP65 / 4’ (1.2 m) drop onto concrete / MIL-STD-810F-IV
CSA Class I, Division 2 (Groups A, B, C, D)
9.9” W x 5.8” L x 2.4” H (252 x 148x 60) mm
2.7 lb (1.2 kg) including battery
-4 °F to 140 °F (-20 to 60) °C, 95% RH
IP65 / 4’ (1.2 m) drop onto concrete / MIL-STD-810F-IV
CSA Class I, Division 2 (Groups A, B, C, D)
DATA COLLECTORS DATA ANALYZERS BALANCERS
SPECIFICATIONS vb5 vb6 vb7 vb8 vbBalancer vbBalancer+
Recording Types
Route enabled
Spectrum/Waveform
6Pack
Keypad entry
Average value √*
Time Synchronous Averaging
Bump test
Coast-down/Run-up
Cross-channel phase
* Acceleration, Velocity, Displacement and Current units only.
Ascent®, vbSeries®, vbOnline® and Commtest® are registered trademarks and vb5™, vb6™, vb7™, vb8™, vbBalancer™, vbBalancer+™ and 6Pack™ are trademarks of Commtest Instruments Ltd.
All product specications are subject to change without notice. Last revised 1 September 2008.
© Commtest Instruments Ltd. All rights reserved. Rev A04
CTI20414 SEPT08
Commtest, Inc.
6700 Baum Drive Suite 12 Knoxville, Tennessee 37919 Telephone 865 588-2946 Facsimile 865 588-2949 USA Toll Free 877 582-2946 americas@commtest.com
Commtest Instruments Ltd
Level 2, 22 Moorhouse Ave PO Box 9297 Christchurch New Zealand Telephone +64 3 374 2337 Facsimile +64 3 374 2339 sales@commtest.com www.commtest.com
Commtest Instruments Ltd
PO Box 502689 Dubai Internet City Dubai, United Arab Emirates middleeast@commtest.com
Loading...
