DATA SHEET > UCS 500N5E > 20130322

UCS 500N5E

EFT/BURST GENERATOR UP TO 5.5KV, IEC/EN 61000-4-4

FOR TESTS ACCORDING TO ...

> EN 300329
> EN 300340
> EN 300342-1
> EN 300386 V1.3.2
> EN 301489-1
> EN 301489-17
> EN 301489-24
> EN 301489-7
> EN 50121
> EN 55024
> EN 61000-4-4
> EN 61000-6-1
> EN 61000-6-2
> IEC 60255-22-5
> IEC 61000-4-4
> IEC 61326

UCS 500N5E - EFT/BURST GENERATOR THAT GOES BEYOND STANDARD REQUIREMENTS

The UCS 500N5E is a new dedicated EFT/Burst generator based on the successful UCS 500N series of ultra-compact
simulators. Offering all the benefits of the well-known UCS 500N5 it is designed as a Burst generator only. This makes it the
full performing Burst tester as per IEC/EN 61000-4-4 with the best benefit-to-cost ratio yet upgradeable to include other test
abilities such as Combination Wave Surge and PowerFail.
Apart from its built-in single phase test capability it is extendable for testing three-phase DUTs by means of automatically
controlled external coupling networks up to 100A. EM TEST supplies a large range of accessories for various applications.

HIGHLIGHTS

> Fully compliant to IEC 61000-4-4 Am1 Ed.2

APPLICATION AREAS

INDUSTRY

COMPONENTS

> Test voltage up to 5.5kV
> Up to 10,000 pulses per second

MEDICAL

BROADCAST

> Up to 1,000 pulses per burst

RESIDENTIAL

RENEWABLE ENERGY

> Built-in single phase coupler 300V/16A
> Manual operation from front panel

TELECOM

> USB and GPIB-Bus for remote control

www.emtest.com © EM TEST > PAGE 1/4

DATA SHEET > UCS 500N5E > 20130322

TECHNICAL DETAILS

EFT/BURST GENERATOR

UCS 500N5E

As per EN/IEC 61000-4-4 and
EN 61000-6-1, -6-2

Test voltage 200V - 5,500V ± 10%;

100V - 2,750V ± 10% into 50ohm
Pulse shape 5/50ns into 50ohm and 1,000ohm
Rise time tr 5ns ± 30% into 50ohm;

5ns ± 30% into 1,000ohm
Pulse width td 50ns ± 30% into 50ohm;

50ns -15/+100ns into 1,000ohm
Source impedance 50ohm
Polarity Positive/negative

TRIGGER CIRCUIT

Trigger of bursts Automatic, manual, external
Synchronization 0° - 360°, resolution 1° (16 - 500Hz)
Burst duration td = 0.10ms - 999ms

EFT/BURST GENERATOR

TEST ROUTINES

Quick Start On-line adjustable parameters,

easy-to-use

Standard Test
routines

User Test routines Synchronous burst release

As per IEC 61000-4-4, Levels 1 - 4
As per EN 61000-6-1, -6-2
Manual Standard Test routine

Random burst release
Change voltage after T
Frequency sweep within one burst
Frequency sweep with constant
number of pulses
Frequency sweep with constant
burst duration
Change polarity after T

Repetition rate tr = 10ms - 9,999ms
Spike frequency f = 0.1kHz - 1,000kHz
Test duration T = 0:01min - 99:59min

T > 99:59min --> endless

OUTPUTS

Direct Via 50ohm coaxial connector
Coupling mode L, N, PE; all combinations
DUT supply AC: 300V/16A; 50/60Hz

DC: 300V/16A
CRO trigger 5V trigger signal for oscilloscope

www.emtest.com © EM TEST > PAGE 2/4

DATA SHEET > UCS 500N5E > 20130322

TECHNICAL DETAILS

GENERAL DATA

INTERFACES

Serial interface USB
Parallel interface IEEE 488, addresses 1 - 30
Analog output 0 - 10VDC to control an external

transformer
CN interface 15pin SubD connector to control an

external coupling network
Fail inputs DUT monitoring via Fail1 and Fail2

input (one each)

DIMENSIONS

Dimensions 19", 3HU
Weight approx. 14kg

MAINS

Supply voltage 115V/230VAC +10%/-15%
Power approx. 75W
Frequency 50/60Hz
Fuses 2 x T 2AT (230V) or 2 x T 4AT (115V)

OPTIONS

OPTIONAL ACCESSORIES

HFK Capacitive coupling clamp as per

IEC 61000-4-4
KW50 100:1 divider, 50ohm
KW1000 500:1 divider, 1,000ohm
CA EFT kit Kit for burst pulse verification

consisting of KW50, KW1000 and

adapter for DUT port in a plastic case

for storage
A6dB 6dB attenuator, 50ohm
ITP Immunity test probes (electrical field

generation)
ITP/H Immunity test probe (magnetic field

generation)
iec.control 1 Remote control and documentation

software, including standard test

routines and reporting capabilities.

OPTIONAL EQUIPMENT

CNI 503Ax 3-phase coupling/decoupling

networks as per IEC 61000-4-4 and

-4-5 up to 100A per phase

ACCESSORIES INCLUDED

Mains supply Plug depends on the country of use
DUT supply Plug depends on the country of use
DUT adapter Socket depends on the country of

use
Operation manual,

Calibration certificate,
iec.control remote control software

CNE 503x Coupling/decoupling networks for

special EFT/Burst test applications,

e.g. for energy meters, as per

IEC 60255-22-5

www.emtest.com © EM TEST > PAGE 3/4

DATA SHEET > UCS 500N5E > 20130322

COMPETENCE WHEREVER
