Terminator
Far End Terminating Device
The bottom line? By reducing failure
The CopperProTMfamily of loop testers
from Fluke Networks packs a full com-
plement of test and troubleshooting
capabilities into one rugged, integrated
tool for OSP technicians. Now we’ve
expanded its capabilities even further
with Terminator – an accessory module
to the 990DSL CopperProTMthat lets you
perform terminated transmission test-
ing quickly. Easily. Single-handedly.
Together, the CopperPro and
Terminator are a major advance in
qualifying and troubleshooting copper
access network circuits, including
HDSL2/4. Nothing else on the market
offers a more complete and effective
solution for reducing failure frequency,
repeats, and chronic problems with
special services circuits.
“Terminate” wasted time,
money and dispatches
Just attach the battery-powered
Terminator to the far end of a cable pair.
Together with a single 990 CopperPro,
Terminator provides VF and WB termina-
tions and tones for terminated transmis-
sion testing. It also supports the 990DSL’s
composite tone generation capability for
high-speed ADSL, special services, and
wideband longitudinal balance tests.
frequency, repeats and chronic problems,
erminator puts an end to unnecessary
T
dispatches and fines.
Save time and money. Gain
higher performance.
• Saves money and optimizes your workforce
with “one tech out” terminated testing of
out-of-service pairs
• High-speed acceptance/qualification tests,
including loop attenuation – a must for
HDSL2/4
• Robust error checking at start-up
eliminates time-consuming false starts
and assures reliable communication with
the CopperPro
• High-speed testing makes technicians
more efficient; the CopperPro’s unique
composite tone capability can sweep
thousands of frequencies in seconds
Terminator: one add-on
module; 13 testing advantages
1. Loop termin
or testing on either of two pairs
es f
ton
(Pair 1 and 2)
g/splittin
gin
d
2. Bri
d Pair 3 (CO Pair)
an
3. Composite VF and WB tones for greatly
eased testin
cr
in
TMF signaling control on both Pair 1 and
4. D
air 2 (P
P
alin
gn
5. Si
(either Pair 1 or 2)
ely low-power m
em
6. Extr
ed o
turn
7. DTMF transceiver switchable via relay to
er P
eith
TM
s and VF/WB single
on
ati
g access between P
g speed
, if power
air 1 alon
g an
ff
air 1 (d
e
d testing on the same pair
e wh
od
ault) or P
ef
air 2, or
ed d
en
air 1
own)
removed from both for a preset time
interval whenever its input impedance
would affect the 990 CopperPro measure-
ment from the far end (i.e., shorts and
grounds, or opens)
8. Operable from a standard butt-set, when
line powering is present (i.e., idle
POTS line)
9. DTMF command protocol allows for
ack” closed-loop feedback
ck/N
A
“
se to con
espon
r
increasing reliability
g T
acin
r
10. T
al)
gn
si
11. Powered by a standard, off-the-shelf
9 VDC alk
12. Battery cover r
a tool
ates fr
13. Oper
power sour
power cords provided with the
990 CopperPr
g the internal battery when
ectin
n
plugged in
trol commands,
e (TR metallic 577 Hz
od
e m
on
g
echar
on-r
e n
alin
ovable with
em
al 12-15 VDC
xtern
om an e
, such as the AC and DC
ce
cally discon-
o, autom
ati
eable battery
out using
Technical Data
Team up Terminator with the 990 CopperPro – and see what
a difference Fluke Networks’ SuperVision makes.
Why Terminator and CopperPro
990 CopperPro
(Testing Unit)
TN2100
Terminator Remote
SPAN Section
SHEATH
together are the only proven
way to qualify HDSL
Advances in DSL (digital subscriber line)
technologies have had a dramatic impact on
e availability and deployment of broad-
th
band service. High-speed links carrying
voice, data and video services can be
deployed quickly over existing outside plant
copper cable. While some circuits turn up
with minimal effort, many suffer problems
from the outset.
Traditional testing methods will no longer
do the job. HDSL2 and HDSL4 don’t use
repeating signals that can be replicated with
BERT and Nyquist tests used in the past.
Instead, they use complex TCPAM
technology, which requires a different
testing procedure.
The 990DSL CopperPro and Terminator
feature automatic tests designed specifically
to address this problem. CopperPro and
Terminator prequalify pairs for HDSL2 or
HDSL4 in less than two minutes, and help
locate facilities problems that generate
errors or cause circuits to fail.
• Metallic noise, power influence and longi-
tudinal balance at voice band and data
frequencies to assess how well the pair
can “self-shield” itself from the effects
of noise from the environment or in
the cable
• Wideband circuit noise and level across
the entire frequency range (spectral noise)
to make sure ambient noise in the HDSLx
pass band are below acceptable levels
• Loop resistance and resistive balance and
length to assure that splices, gauge
changes or other impairments don’t com-
promise the long-term reliability of the
circuit
Loop attenuation with pass/fail PSD
•
(power spectr
eam and downstream to assure
upstr
e performance of the TCPAM encoded
th
al density) masks for
transmission.
CopperPro Reporter Software
CopperPro Reporter Software allows you to
document and report test results quickly and
easily using Microsoft Excel on your com-
puter. It is available as a free download to
all CopperPro customers. Simply visit
www.flukenetworks.com/copperprosoftware
HDSL2/4 tests include:
eign voltage to uncover facility damage
For
•
• Shorts and grounds to identify any short
, failed insulation or
ctors
u
ossed con
or cr
water in th
• Opens, capacitive length and balance,
ch, alon
whi
elp determine if water, split pairs or
can h
an unknown bridge tap is present
al loss an
gn
Si
•
to help detect bridge taps and other
anomalies
d
e cable
g with th
d slope in th
e r
esistan
ce tests,
e voice band
Fluke Networks delivers
SuperVision solutions for the
outside plant
Fluke Networks products enable you to cor-
rect local loop database errors, qualify lines
or DSL service, test and document cable
f
conformance and install and troubleshoot
voice and data services. Our telecom solu-
tions allow you to maintain and manage
your outside plant more efficiently and cost
effectively so you can increase revenue,
profitability and customer satisfaction.
For more information, or to contact your
local Fluke Networks representative, call
(800) 283-5853 or email
copperpro@flukenetworks.com
Specifications
Powering
Source Internal: replaceable 9 VDC alkaline battery
al: 9-18 VDC AC power adapter or DC auto power cord
Extern
Shelf life 2 months (battery installed)
Operating life 40 hours (typical usage )
oltage Protection
Input V
Test lead inputs ± 350 VDC and 250 VAC, TG and RG
VF Transmit Frequencies
Amplitude, single tones 0.0 dBm ± 0.5 dB
Amplitude, composite SmartTone -13 dBm composite*
Frequency range 300 Hz to 20 kHz, ± 0.1%
Transmit impedance 600 or 900 ohms
WB Transmit Frequencies
Amplitude, single tones 0.0 dBm ± 0.5 dB
Amplitude, composite tone-sets Variable, depending on tone-set*
Frequency range 10 kHz to 1200 kHz
Frequency resolution Multiples of 508.626 Hz
Impedance 100 or 135 ohms
Tracing Tone
Frequencies 577.5 Hz : 500 ms on, 500 ms off, Metallic (TR)
Amplitude > 3.5 Vpp
* Composite SmartTone available only on TN2100 model.
Ordering information
Model Description
c Terminator Far End Device
TN2000
TN2100 Enhanced Terminator Far End Device
TN-LEADS-P
TN-LEADS-B Test Lead Set, Bed-Of-Nail Clip
TN-LEADS-S Test Lead Set, Spike Clip
TN-LEADS-SB
Basi
est Lead Set, Plain Clip
T
est Lead Set, Spik
T
e + Bed-Of-Nail Clip
NETWORKSUPERVISION
Fluke Networks
P.O. Box 777, Everett, WA USA 98206-0777
Fluke Networks operates in more than 50 countries
worldwide. To find your local office contact details,
www.flukenetworks.com/contact.
go to
