W

hether deploying cable modems,
rolling out digital TV, or maintain-

ing the analog spectrum, the SDA­4040D delivers precision "find and fix"
measurement tools that will reduce critical
test time when analyzing and qualifying
broadband network performance. Priced for
virtually any system budget, the SDA­4040D brings unmatched measurement
performance to the network technician in a
rugged "One Box" solution. And with a ver­satile upgrade program, the SDA-4040D
can be updated as technician skill levels
and system requirements expand.

Digital services testing is the centerpiece
of the SDA-4040D platform. Detecting and
eliminating return path noise is confronted
with a fast spectrum analyzer (detects sig­nals down to a 5µs duration), and the
industry unique PathTrak Field View
option. A Zero Span spectrum provides
accurate, in-service power and carrier-to­noise measurements of cable modems.
And the new QAM View digital analysis
option adds forward path digital signal
testing including constellation, pre/post
FEC BER, MER, and exclusive QAM Ingress
feature that reveals noise under an active
carrier. Of course, analog signal measure­ments are addressed with standard fea­tures like RF level, fast-scan, tilt, in-service
C/N and HUM, and FCC and CENELEC
compliant auto testing.

WWG also offers comprehensive technical
training programs to make sure that net­work field technicians become experts on
the SDA-4040D. WWG training provides
detailed instruction on the time saving and
practical SDA-4040D applications related
to the latest broadband technology.

Preparing the Network
for Digital Services

QAM View Option Ensures Quality
Forward Path Digital Services. For mea-

surement and analysis of digital TV and
forward modem signals, the new QAM View
option provides a full complement of digi­tal quality measurements. Included is a
64/256 QAM constellation display with
zoom, average digital power level, Bit Error
Rate (BER), 21 to 35 dB Modulation Error
Ratio (MER) and noise margin "cliff effect"
parameter. An equalizer display shows
equalizer stress and distance to fault.

! Constellation display with MER and pre/post

FEC BER.

In addition, an exclusive QAM ingress
noise mode allows technicians to see
ingress/noise under an active digital carri­er. This tool is invaluable for detecting for­ward path ingress otherwise hidden by
conventional spectrum views!

! QAM ingress feature shows noise/ingress

under an active carrier.

SDA-4040D

HFC Signal Analysis Meter

• Fast, Sensitive
Spectrum Analyzer

• Full In-Service
Proof-of-Performance
Analyzer with Level,
Carrier-to-Noise,
HUM and Modulation
Measurements

• Cable Modem
Analysis Using Zero
Span Mode Provides
Accurate, In-service,
Power and C/N
Measurements

• QAM View Option
Provides Complete
Analysis of Digital TV
and Forward Cable
Modem Signals

> Pre/Post FEC BER
> MER
> Constellation
> Exclusive "Ingress

Under the Carrier"

• PathTrak Field View
Option Quickly
Pinpoints Return Path
Noise/Ingress

• Automated 24 Hour
Proof-of-Performance
According to FCC and
CENELEC Standards

• Technical Training
Programs

• International
Language

• Rugged, Weather
Resistant and
Lightweight

Measuring the Behavior of
DOCSIS/DAVIC Compatible Cable
Modem Signals in the Cable Plant. For

"bursty" digital signals, such as TDMA
technologies used on cable modems for
reverse services, the SDA-4040D uses the
advanced Zero Span capabilities to make
the measurement. Time domain displays of
TDMA signals allow power measurement,
D/U (desired/undesired measurements),
and detection of packet collisions, all while
the modem is in service. Technicians can
measure the level of interference in the
actual channel being used.

!Time domain view of ingress in the Zero Span

mode captures elusive ingress.

! Cable modem analysis using Zero Span mode

provides accurate, in-service, power and C/N
measurements.

Fast-Update Spectrum Display for
Detecting Ingress in the Field. The spec-

trum mode has the speed and versatility
to effectively troubleshoot difficult system
problems. A programmable dwell time
allows the meter to stay on each frequen­cy longer to catch more ingress. Peak hold
mode captures and saves transient bursts
(like evasive return path electrical noise).
The SAM4040D detects signals as fast as
5µs, in both Zero Span and continuous
modes. The pre-amp and low-pass filter
on the SDA-4040D assures that ingress
can be measured on devices with bi-direc­tional testpoints or testpoint values of
30dB or more.

! Reverse digital modem signal.

PathTrak Field View Option.

When your network is equipped

with the PathTrak Performance
Monitoring System, system technicians can
benefit from the ultimate ingress fighting
tool—the PathTrak Field View option for
the SDA-4040D. With Field View, the SDA­4040D receives a return path headend
spectrum broadcast from the PathTrak unit,
and then compares it with a return path
spectrum at any field testpoint. The side­by-side spectrum comparison instantly
reveals to the technician whether the
ingress source is originating at his current
testpoint or at a different location. The
comparative spectrum technique slashes
noise/ingress troubleshooting time, since
the technician can immediately verify
whether corrective action performed in the
field (local trace) results in improvement in
the headend spectrum (remote trace).

! PathTrak Field View option compares headend

node spectrum with field test-point spectrum.

Sweepless Sweep® Provides Non­Intrusive Frequency Response.

The trade­marked Sweepless Sweep® passively pro­vides frequency response information
about a network by measuring active carri­ers. The SAM404D stores the levels of all
active carriers at one reference point in the
network, and then compares the relative
levels to another point within the network;
just like referenced sweep, but without the
need for a transmitter!

! Sweepless Sweep® Display.

Powerful Graphic
Displays and Common
User Interface Allows
Technicians to Learn Fast.

The results of all measurements
are presented to the user in

clear, highly informative, sum­mary displays. The graphics present the
information the way the technician wants
to see the results – no further interpreta­tion required. For example, testpoint com­pensation values are entered at the start of
testing. Displays then calculate actual lev­els automatically, minimizing field errors.

! Graphical reverse testpoint compensation.

With SDA series products, all levels of
instruments are familiar to the technician,
regardless of which is learned first,
because the same user interface conven­tions are used across all product families.
The learning curve for a progressing techni­cian is considerably shorter than alterna­tive test equipment. This means urgent
upgrade projects make the most efficient
use of limited resources when SDA series
products are used.

! The Navigator user interface, common on all

WWG meters.

Comprehensive Testing

The SDA-4040D provides an extensive set of
signal analysis features designed for prov­ing, and improving, network quality. All
tests utilize a practical user interface, nor­mally requiring only a one-button keystroke.

Level Measurement. The SDA
instruments provide a comprehen-

sive single-channel display with
tuned channel, video frequency and level,
audio frequency and level, and the difference
between video and audio carrier levels.

! The single-channel level display shows

both video and audio levels (either single
or dual sound/NICAM) and the difference
between the two.

! Digital channel average power measurements

can be made using the digiCheck™ feature.

Making accurate digital average power
measurements are addressed with the
digiCheck™ measurement function. The
digiCheck™ feature is compatible with
most "non-bursty" digital modulations in
use today (i.e., 16, 32, 64, and 256 QAM,
QPR, QPSK, VSB, CAP16, etc.).

Analog and Digital Signal

Limits.

Analog signal threshold

limits have always been a techni­cian’s favorite feature of WWG instruments.
Automatic limit checks provide a quick
go/no-go status for audio and video levels.
The SDA series extends this capability with
a dedicated digital limit set that can be
applied exclusively to the forward digital
carriers defined in a channel plan. By
assigning separate analog and digital limits,
test time is reduced since no calculation is
necessary to determine if analog and digital
level relationships are within system specifi­cations. Analog and digital limit capability
is available in both the scan and autotest
modes (available July 2000).

WWG "One Box"
Solutions

The SDA-4040D signal
analysis meter delivers a
“One-Box" solution to
help deploy and maintain
quality video and data ser­vices in the HFC network.
With the same durability
and measurement accura­cy as its venerable SAM
predecessor, the SDA­4040D is designed with
the speed, spectrum and
advanced QAM analysis to
test both traditional ana­log video and the latest
digital formats. The versa­tile combination of stan­dard features and avail­able options allow the
meter to be customized,
or upgraded to the SDA­5000, to meet virtually any
system requirements.

Analog Testing

• Non-Intrusive
Sweepless Sweep®

• RF Level, Fast Scan, Tilt

• In-service Carrier to

Noise, HUM, Depth
of Mod.

• Fast Spectrum Display
with CTB/CSO

• Auto Testing/24 Hour
Testing (FCC & CENELC
Compliant)

Return Path Testing

• PathTrak Field
View Option Pinpoints
Return Path Noise

• Zero Span
Spectrum Mode

• DOCSIS/DAVIC
Compatible Cable
Modem Analysis

Advanced Digital Testing

• DigiCheck™
Average Power

• QAM View Digital
Analysis Option with
MER, Pre/Post FEC BER,
Constellation, and
Exclusive Noise/Ingress
Under the Carrier
Measurement

Tilt Measurement. Tilt is the
easiest and most efficient tool

for balancing amplifiers. For
cable plants requiring multiple tilt mea­surements, such as comparing today’s tilt
measurement with a historical record, and
then making an additional measurement
for a new wider channel plan, the user sim­ply uses markers to indicate the tilt chan­nels that define the new limits.

! Tilt mode performs automatic tilt calculations

between any 2 of 9 designated carriers.

The CTB/CSO mode is used for

automatically making intermod-

ulation measurements.

Scan Measurement. Scan

mode provides a quick graphical

view of the entire channel plan
with bars representing the video level for
each channel. Both video and audio may
be displayed.

! Limit checks can be instantly viewed after

identifying channel of interest with a marker in
scan mode display.

Carrier-to-Noise Measurement:

In-Service. Carrier-to-noise

measurement (on non-scram-

bled channel) is just as easy,
and there is no need to remove modula­tion from the video carrier. No tunable pre­selector filter is needed.

! In-service carrier-to-noise.

Hum Measurement: In-Service.

Measuring hum on a channel

(non-scrambled) is as simple as
pressing the "HUM" key. And since the
instrument is battery powered, the measure­ment is independent of ground loops, there­fore isolated from the line (mains). Hum
reveals itself as either single (60 Hz) or dou­ble (120 Hz) horizontal bars across the video
screen. The level of either can be measured.

! In-service HUM (PAL & NTSC compatible).

Modulation Measurement.

Includes NTSC, PAL and SECAM

formats. Demodulation of the
audio is done for both AM and FM. FM is
used to hear audio distortion on the FM
radio channels or the sound of the TV pro­gram. AM is used to recognize short-wave
interference signals in the reverse band.

! Depth of modulation.

Other SDA
Materials Available:

The following WWG
materials are available.
Inside the U.S., please call
toll-free at 800-622-5515
or 317-788-9357. For
faster service, please visit
our website at
www.wwgsolutions.com.

•

Wavelengths newsletter

• SDA-5000 Data Sheet

• PathTrak Field View
Option “How It Works”

• App Note #1, Forward

Sweep and Balance

• App Note #2, Reverse
Sweep and Balance

• App Note #3, Return
Path Troubleshooting

• SDA-5000 Sweep
Training CD-ROM

Extensive Automated
Test Capability

Automated tests can be scheduled to per­form either 24-hour FCC compliance tests,
or initiated immediately to log performance
at individual nodes, amplifiers, or other
testpoints. A wide range of tests can be
performed automatically, including signal
levels, C/N, hum, and depth of modulation.
The operator designates which tests to per­form on which channels. Because these
tests are non-intrusive, it is easy to test all
parameters on all channels at anytime.

After a test is performed, the results can be
displayed on the SDA screen. A pass/fail
indication on a variety of limits can be set
for FCC/CENELEC or other government
standards, or to system preferences. Data
taken during any automated test, or
sequence of automated tests, can be
viewed immediately with a pass/fail indica­tion for each of the limits. Specific stored
measurement results may be viewed on
demand. Automated test results can be
printed directly to a serial printer or
uploaded to a PC using StealthWare to
store and include in custom reports.

! The detailed scan graph offers user-adjustable

marker, scale reference level and tilt for maxi­mum signal evaluation.

Data Analysis with StealthWare. Any
stored SDA measurement information can
be up-loaded to a PC using StealthWare, a
Windows™ based data management pack­age. Stored sweep, scan, or spectrum
screens can be viewed on the PC and ana­lyzed with marker movement and readout
information just the same as on the actual
unit. A sweep graph overlay function
allows comparison of multiple RF response
variations over time. StealthWare also
allows the operator to build channel plans
and edit site locations, which can be
downloaded to multiple SDA instruments.
Additionally, channel plans can be
uploaded to the PC, modified in
StealthWare, and then downloaded back to
the SDA instrument.

Upgrading the SDA-4040D to SDA-5000.

Your test equipment investment is protect­ed with the WWG upgrade program. As sys­tem requirements change, the SDA-4040D
can be upgraded to the SDA-5000 for for­ward and reverse sweep capabilities at any
of the WWG worldwide service centers. And
if you own a model SAM-4040D, you can
upgrade to the SDA-4040D with an in-the­field firmware change only!

Start with any

SAM 4040 or 4040D

Optional:

PathTrak FieldView

(4040D)

a) Firmware b) Hardware & Firmware

Upgrade to SDA-4040D
Standard: Optional:

DigiCheck PathTrak
ZeroSpan FieldView
Dig Spectrum

Add Option 4 for:

QAM View

Any Stealth can upgrade
to SDA-5000 for:

5 x faster sweep
256 QAM compatible sweep
Improved TP Comp setup
for reverse sweep

a) Firmware b) Hardware & Firmware

SDA-5000 units can be
purchased with, or
upgraded to:

QAM View
PathTrak Field View

WWG SDA-4040D

WWG SDA-5000

3SR

SAM 4040D SAM 4040

WWG SDA-5500

WWG SDA-5510

3ST

3HRV

Any 3ST can be upgraded
to SDA-5500 for faster
forward sweep and digital
signal sweep compatibility

Any 3HRV can be upgraded
to SDA-5510.

Stealth to SDA Series – Product Upgrade/Replacement Guide

Stealth Model SDA Replacement

3SR SDA-5000
3SR + 3SRV option SDA-5000 with Option 1
3SR + 3SRT option SDA-5000 with Option 2
3ST SDA-5500
3HRV SDA-5510
SSA-1000 SDA-5000 with Option 1 (firmware only)
SAM 4040 SDA-4040D
SAM-4040D SDA-4040D (firmware only)

OR

OR

SSA-1000

a

b

a

b

QAM View option

QAM View option

Additional
Customer Support

Wavetek Wandel
Goltermann offers quali­ty, cost-effective support
programs that address all
of your technical support
needs. With over 20 fully
equipped CATV accredit­ed service centers world­wide, WWG provides
local product mainte­nance, calibration and
upgrades, along with
technical training services.

CarePlanSMCustomer
Support Package

The WWG CarePlan is a
proactive technical sup­port program designed
to safeguard your invest­ment throughout its
complete life-cycle.
Key benefits of the
CarePlan include:

• Cost-effective
product mainte­nance support

• Annual calibration
certification
program

• Proactive hardware
and software
upgrades

• Technical support

Technology Training

WWG provides a compre­hensive CATV technology
training program
designed to help you and
your teams understand
the changing needs of
today's advanced
networks. Training
seminars include:

• HFC Basics

• Understanding

Digital

• Sweep and Balance

Forward and Return

• Mastering the

Forward Path

• Mastering the

Return Path

• Sweep 101

“Bootcamp”

Hum Measurement

In-service measurement. Carrier > 0 dBmV. Non-scrambled chan­nels only

Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 to 10%

Resolution. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <0.2%

Accuracy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +/- 0.7%

Depth of Modulation

Assumes presence of white reference on any VITS line. Non­scrambled channels only. Audio demodulation of AM and FM
carriers

Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80 to 100%

Resolution. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <0.5% at 85%

Audio Demodulation . . . . . . . . . . . . . . . . . . . AM and FM Carriers

Tilt Measurement

Up to 9 pilot carriers or video channels with tilt and level measure­ments on the highest and lowest.

Hi-Lo ∆ Resolution. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.1dB

Scan Mode

All video, audio, pilot carrier, and digital channel levels displayed.

Specifications

Frequency

Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 to 1,000 MHz

Accuracy . . . . . . . . . ± 10 ppm at 25°C; ± 10 ppm drift over temp.;

± 3 ppm/year aging

Resolution Bandwidths . . . . . . . . . . . . . . . 30, 280 kHz and 2MHz

(30 kHz for CTB/CSO only)

Tuning Resolutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 kHz

Sweep Resolution . . . . . . . . . . . . . . . . . . . . . . 250 kHz maximum

Level Measurement

Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40 to +60 dBmV

Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.1 dB

Accuracy . . . . . . . . . . . . . . . . . . . . . ±1.0 dB from -20 to +50°C

1,2

Log Linearity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±0.5 dB

1

Flatness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±0.5 dB

3

Signal Types . . . . . . . . . . . . . . . . . . . . . . CW, single carrier, video

(single or dual audio/NICAM), audio, digital

Uncertainty for Digital Carrier . . . . . . . . . . . . . . . . . . . . . . . . . . . .

additional ±0.5 dB (digital types 16/32/64/256 QAM,

QPR, QPSK, VSB, CAP-16, DVB/ACTS and TDMA

using zero-span spectrum mode) @280 kHz RBW

Carrier-to-Noise

4

In-service measurement. Non-scrambled channels only. No prese­lection required for 78 channels or less. Best dynamic range at
+10dBmV or higher input.

Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ≥ 52 dB

1

Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . < 0.5 dB

Model SDA-4040D Signal Analysis Meter:

Digital / Analog HFC Analyzer. Includes: Extended-life nickel metal hydride battery, universal charger/AC adapter, canvas
carrying case and operators manual.

Options:

SDA-OPT3A: PathTrak Field View Interoperation for model SDA-4040D (requires PathTrak HCU)
SDA-OPT4A/B: QAM View digital analysis including 64/256 Constellation, MER, Pre/Post FEC BER, and exclusive QAM
ingress under the carrier feature. Please specify OPT version 4A or 4B when ordering.

SDA-OPT4A: 64/256 QAM, DVB-C, ITU-T J.83 Annex A (8 MHz)

SDA-OPT4B: 64/256 QAM, DVS-031, ITU-T J.83 Annex B (6 MHz)
SDA-OPT5: BNC connectors replace standard F type connectors
StealthWare: Windows™ Compatible Data Management Software for all SDA, Stealth, MicroStealth, and CLI products.

Optional Accessories:

SDA-CASE1: Replacement soft carrying case for all SDA instruments without QAM View option installed. Compatible with
standard and extended life batteries.
SDA-CASE2: Replacement soft carrying case for all SDA instruments with QAM View option installed.
SDA-NIMH: Spare extended life battery.
SDA-NIMCA: Universal charger/AC adapter for extended-life nickel metal hydride battery.
SDA-NIMK: Extended life battery kit. Includes extended life battery, universal charger/AC adapter and soft carrying case
(SDA-CASE1).

Ordering Information

General

Display. . . . . . . . . . 320x240 dot matrix LCD, selectable back light

Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . 15.2 x 27.9 x 8.9cm

(6"x11"x3.5")

Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.3 kg (5.1lbs)

Temperature Range Operating . . . . . . . -20 to +47°C (-4 to 117°F)

Power Sources

Battery . . . . . . . . . . . . . . . . Extended-life replaceable nickel metal

hydride, 12V/3.5A-hr 4 hours cont. use on a single charge

Notes

1) Typical Specifications

2) Relative to 25°C

3) @25°C and +20dBmV

PathTrak Field View (OPT 3 required)

Update Rate . . . . . . . . . . . . . . . . . . . . . 2x/second (remote trace)

~1x/second (local trace)

Display Scaling . . . . . . . . . . . . . . . . . . . . . . .5/1/2/5/10/20dB/div.

Selectable Nodes . . . . . . . . . . . 14 (selectable via PathTrak HCU)

Sweepless Sweep® Mode

Frequency Range . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1000 MHz

Display Span. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . user definable

Display Scale/Range . . 6 vertical divisions 1, 2, 5, or 10dB/division

Sweep Pulse Occupied Bandwidth. . . . . . . . . . . . . . . . . . . 30 kHz

Stability. . . . . . . . . . . . . . . . . . . . . . . . . . . . +/- 0.5 dB, normalized

(dependent on stability of referenced carriers)

Sweep Rate. . . . . . . . . . . . . . . ~1 second (78 Channels, including

scrambled and digital signal types)

Channel Plan Templates (user editable) . . . . . . . . . . . . . . . . . . . .

China-1; China-2; France; HDTP-NL; Ireland; Japan;

Jerold; Jerold-HRC; Jerold-IRC; NCTA; NCTA-HRC; NCTA-SUB

NCTA-IRC; NTSC-Broadcast; OIRT-D/K; PL-B/G; PAL-UK

Spectrum Mode

Spans . . . 3, 5, 10, 20, and 50 MHz (0.3, 0.5, 1, 2, and 5 MHz/div.)

Sweep Rates. . . . . . . . . ~1 second updates with spans of 50, 20,

10 & 5 MHz ~1.7 second updates with 3 MHz span

Display Scaling and Range. . . . . . . . . . 0.5, 1, 2, 5, and 10 dB/div.

6 vertical divisions

Dwell. . . . . . . . . . . . . . . . . . . . . . . . . . . . . programmable 0-25 ms

Spurious Free Dynamic Range . . . . . . . . . . . . . . . . . . . . . 60 dB

3

Sensitivity Without Preamp. . . . . . . . . . . . -40 dBmV 5 - 550 MHz

-35 dBmV 550 - 1000 MHz

Sensitivity With Preamp . . . . . . . . . . . . . . -50 dBmV 5 - 550 MHz

-45 dBmV 550 – 1000 MHz

Max. Level With Preamp . . . . . . . . . . . . . . . . . . . . . . . +50 dBmV

Zero-Span Mode

Video BW . . . . . . . . . . . . . . . . . >1MHz, 100 kHz, 10 kHz, 100 Hz

Resolution BW . . . . . . . . . . . . . . . . . . . . 2 MHz, 280 kHz, 30 kHz

Measurement BW Compensation . . programmable 1 kHz-99 MHz

Pulse Measurement Accuracy . . . . . . . . . . nominal level in 10 µs

+/- 2 dB from nominal in 5 µs

(>1 MHz VBW, 280 kHz RBW)

Sweep Times . . . . . . . . . . . . . . . . . 100 µs to 20 s (1,2,5 settings)

Intermodulation Distortion (CSO/CTB)

Range5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ≥ 60 dB

Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.1 dB

Data Storage

Files stored: Autotests, tilt, channel plans, scan and Sweepless
Sweep‚. Spectrum mode (regular with max hold and CSO/CTB).
Allocated on demand. The storage capability is simultaneous- more
of one file type can be "traded" for less of another. All files stored
as database, not as screen picture. Typical mix of files for 78-chan­nel plan 8 channel plans, 16 sweep references 80 sweep traces;
40 scan files 20 spectrum displays; 20 autotests

Serial Interface

RS232; Epson, IBM, Seiko and Diconix Printers

Input Configuration

Connector Type . . . . . . . . . . . . . . . . . . . . . . . 75Ω Type F Female

(Optional 75Ω Type BNC Female)

Maximum Sustained Voltage . . . . . . . . . . . . . . AC 100V DC 140V

Specifications

4)

5)

Carrier to Noise Range (dB)

Carrier to Noise Ratio

Depth of Measurement Characteristics

60
50
40
30
20
10

0

Out of Measurement Range

ccuracy

A

.0 dB

– 3

+

-10 0 10 14 24

Video Carrier Level (dBmV)

+ – 2.0 dB Accuracy

1

CSO / CTB Characteristics

60

Out of Measurement Range

50
40
30
20
10

0

Depth of Measurement (dB)

(without preamplification / with preselection)

-20-100 102030

– 3 dB Accuracy

+

Video Signal Level (dBmV)

1

+ – 2.5 dB Accuracy

© 2000 Wavetek Wandel Goltermann, Inc. • Specifications subject to change without notice.
CNIN01660300AE

North America

1030 Swabia Court
P.O. Box 13585
Research Triangle Park, NC
27709-3585
Tel. [phone]
Fax [phone]

Latin America

Av. Eng. Luis Carlos Berrini,
936-8/9. andar
04571-000 Sao Paulo, SP
Brazil
Tel. [phone]
Fax [phone]

Asia-Pacific

PO Box 141
South Melbourne, Victoria
3205
Australia
Tel. [phone]
Fax [phone]

West Europe

Arbachtalstrasse 6
D-72800 Eningen u.A.
Germany
Tel. [phone]
Fax [phone]

Internet Address

www.wwgsolutions.com

East Europe

Postfach 13
Elisabethstrasse 36
A-2500 Baden
Austria
Tel. [phone]
Fax [phone]

CIS Countries

1st Neopalimovskiy per.
15/7 (4th floor)
119121 Moscow
Russia
Tel. [phone]
Fax [phone]

Wavetek Wandel Goltermann Sales Offices

Local Sales Office:

For more detailed information about using the SDA-4040D, call for your
free CATV “Find & Fix” Guide at 800-851-1202 or [phone].

QAM View Option (OPT 4)—PRELIMINARY

The QAM Analyzer Option (QAM View) can be factory installed in
any new or existing SDA-4040D instrument. The specifications and
features are in addition to the standard measurement features of
the SDA-4040D. When ordering, please specify OPT 4A for 8MHz,
DVB-C, ITU-T J.83 Annex A, or OPT 4B for 6MHz, DVS-031, ITU-T
J.83 Annex B.

Modulation Type

. . . . . . . . . . . 64/256 QAM, DVB-C, ITU-T J.83 Annex A(OPT 4A)

. . . . . . . . . 64/256 QAM, DVS-031, ITU-T J.83 Annex B (OPT 4B)

Measurable Input Range (Lock Range)

64 QAM. . . . . . . . . . . . . . . . . . . . . . . . . -20 to +50 dBmV (typical)

256 QAM . . . . . . . . . . . . . . . . . . . . . . . . -15 to +50 dBmV (typical)

Frequency T uning

50 to 860 MHz (Digital QAM mode)

Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 kHz

MER (Modulation Error Ratio)

64 QAM/OPT 4A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-35 dB

256 QAM/OPT 4A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-35 dB

64 QAM/OPT 4B. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21-35 dB

256 QAM/OPT 4B. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-35 dB

Accuracy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ± 1.5dB

EVM (Error Vector Magnitude)

64 QAM/OPT 4A . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2% - 5.2%

256 QAM/OPT 4A . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1% - 2.0%

64 QAM/OPT 4B . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2% - 5.2%

256 QAM/OPT 4B . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1% - 2.5%

Accuracy 64 QAM/OPT 4A and 4B . . . . . . . ± 0.4% (1.2% - 2.0%)

± 1.0% (2.1% - 5.2%)

Accuracy 256 QAM/OPT 4A and 4B. . . . . . . ± 0.5% (1.1% - 2.5%)

BER (Bit Error Rate)

64 QAM Pre-FEC/OPTs 4A and 4B . . . . . . . . . . . . . . 10-4 to 10-9

64 QAM Post-FEC/OPTs 4A and 4B. . . . . . . . . . . . . . 10-4 to 10-9

256 QAM Pre-FEC/OPT 4A . . . . . . . . . . . . . . . . . . . . 10-4 to 10-6

256 QAM Post-FEC/OPT 4A . . . . . . . . . . . . . . . . . . . 10-4 to 10-9

256 QAM Pre-FEC/OPT 4B . . . . . . . . . . . . . . . . . . . . 10-4 to 10-8

256 QAM Post-FEC/OPT 4B . . . . . . . . . . . . . . . . . . . 10-4 to 10-9

Measurable QAM Ingress

-25 to -40 dBc

Accuracy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ± 1.5 dB

Channel Bandwidth

8 MHz (OPT 4A); 6 MHz (OPT 4B)

Zero Span Spectrum

(Standard Feature - See SDA-4040D specifications)

Graphic Display

Digital summary (including MER/EVM, Pre/Post FEC BER,
Equalizer Stress, Carrier Offset, Symbol Rate) with limit/margin test
results. IQ constellation with zoom. Adaptive Equalizer Display (8
feed forward/24 feedback), Frequency Response, Group Delay.
Ingress/Noise Under the Carrier.

Power Source

Note: Option powered from SDA-4040D nickel metal hydride bat­tery. Operating time is specified for continuous use in QAM View
mode. Option includes high output charger.

Charge Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ~4 hours

Operating Time. . . . . . . . . . . . . 2.5 hours continuous use (typical)

Universal AC Charger/Adapter

Input . . . . . . . . . . . . . . . . . . . . . 100-250 VAC, 50-60 Hz, 0.5A

Output. . . . . . . . . . . . . . . . . . . . . . . . . . Charge15V @ 750 ma

Physical

Dimensions (total SDA-4040D size after option installation) . . . . . .

15.2 x 26.7 x 10.8 cm
6" x 10.5" x 4.25"

Weight (total SDA-4040D weight after option installation) . . . . . . .

Approx. 3.5 kg (7.7 lbs)

Operating Temperature Range . . . . . . . . -20 to 45°C (-4 to 113°F)
