R&S®FSW
Signal and

SpectrumAnalyzer

Specifications

Data Sheet | 05.01

Test & Measurement

Version 05.01, December 2012

CONTENTS

Definitions ....................................................................................................................................................................... 3

Specifications .................................................................................................................................................................. 4

Frequency ............................................................................................................................................................................................... 4

Sweep time ............................................................................................................................................................................................. 5

Resolution bandwidths ............................................................................................................................................................................ 6

Level ....................................................................................................................................................................................................... 7

Adjacent channel power dynamic range ............................................................................................................................................... 14

Measurement speed ............................................................................................................................................................................ 14

Trigger functions ................................................................................................................................................................................... 15

Audio demodulator ................................................................................................................................................................................ 15

I/Q data ................................................................................................................................................................................................. 15

Inputs and outputs ................................................................................................................................................................................ 17

General data ......................................................................................................................................................................................... 20

Options .......................................................................................................................................................................... 22

R&S®FSW-B13 highpass filters ............................................................................................................................................................ 22

R&S®FSW-B17 digital baseband interface ........................................................................................................................................... 22

R&S®FSW-B21 LO/IF connections for external mixers (for R&S®FSW43 only) ................................................................................... 22

R&S®FSW-B24 RF preamplifier ............................................................................................................................................................ 23

R&S®FSW-B25 electronic attenuator .................................................................................................................................................... 23

R&S®FSW-B71 analog baseband inputs, R&S®FSW-B71E 80 MHz analysis bandwidth for analog baseband inputs ........................ 24

Ordering information .................................................................................................................................................... 26

Options .................................................................................................................................................................................................. 26

Upgrades .............................................................................................................................................................................................. 28

Service options ..................................................................................................................................................................................... 28

Recommended extras ........................................................................................................................................................................... 29

Power sensors supported .................................................................................................................................................................... 30

Probes supported by option R&S®FSW-B71/-B71E ............................................................................................................................. 30

2 Rohde & Schwarz R&S

®

FSW Signal and Spectrum Analyzer

Version 05.01, December 2012

Definitions

General

Product data applies under the following conditions:

 Three hours storage at ambient temperature followed by 30 minutes warm-up operation
 Specified environmental conditions met
 Recommended calibration interval adhered to
 All internal automatic adjustments performed, if applicable

Specifications with limits

Represent warranted product performance by means of a range of values for the specified parameter. These specifications are
marked with limiting symbols such as <, , >, , ±, or descriptions such as maximum, limit of, minimum. Compliance is ensured by
testing or is derived from the design. Test limits are narrowed by guard bands to take into account measurement uncertainties, drift
and aging, if applicable.

Specifications without limits

Represent warranted product performance for the specified parameter. These specifications are not specially marked and represent
values with no or negligible deviations from the given value (e.g. dimensions or resolution of a setting parameter). Compliance is
ensured by design.

Typical data (typ.)

Characterizes product performance by means of representative information for the given parameter. When marked with <, > or as a
range, it represents the performance met by approximately 80 % of the instruments at production time. Otherwise, it represents the
mean value.

Nominal values (nom.)

Characterize product performance by means of a representative value for the given parameter (e.g. nominal impedance). In contrast to
typical data, a statistical evaluation does not take place and the parameter is not tested during production.

Measured values (meas.)

Characterize expected product performance by means of measurement results gained from individual samples.

Uncertainties

Represent limits of measurement uncertainty for a given measurand. Uncertainty is defined with a coverage factor of 2 and has been
calculated in line with the rules of the Guide to the Expression of Uncertainty in Measurement (GUM), taking into account
environmental conditions, aging, wear and tear.

Typical data as well as nominal and measured values are not warranted by Rohde & Schwarz.

Rohde & Schwarz R&S

®

FSW Signal and Spectrum Analyzer 3

Version 05.01, December 2012

–

–

–

–

–

–

Specifications

Frequency

Frequency range R&S®FSW8

DC coupled 2 Hz to 8 GHz
AC coupled 10 MHz to 8 GHz

R&S®FSW13

DC coupled 2 Hz to 13.6 GHz
AC coupled 10 MHz to 13.6 GHz

R&S®FSW26

DC coupled 2 Hz to 26.5 GHz

AC coupled 10 MHz to 26.5 GHz
R&S®FSW43
DC coupled 2 Hz to 43.5 GHz
AC coupled 10 MHz to 43.5 GHz

Frequency resolution 0.01 Hz

Reference frequency, internal

Accuracy ±(time since last adjustment × aging rate

+ temperature drift + calibration accuracy)

±3 × 10

±1 × 10

±5 × 10

7

8

7

9

8

9

Aging per year standard ±1 × 10

with R&S®FSW-B4 OCXO precision
frequency reference option

Temperature drift (0 °C to +50 °C) standard ±1 × 10

with R&S®FSW-B4 OCXO precision
frequency reference option

Achievable initial calibration accuracy standard ±1 × 10

with R&S®FSW-B4 OCXO precision
frequency reference option

Frequency readout

Marker resolution 1 Hz
Uncertainty ±(marker frequency × reference accuracy

+ 10 % × resolution bandwidth +
½ (span/(sweep points – 1)) + 1 Hz)

Number of sweep (trace) points default value 1001

range 101 to 32001

Marker tuning frequency step size marker step size = sweep points span/(sweep points – 1)

marker step size = standard span/(default sweep points – 1)

Frequency counter resolution 0.001 Hz
Count accuracy ±(frequency × reference accuracy +

½ (last digit))
Display range for frequency axis 0 Hz, 10 Hz to max. frequency
Resolution 0.1 Hz
Max. span deviation ±0.1 %

Spectral purity

SSB phase noise frequency = 1000 MHz, carrier offset

10 Hz, without R&S®FSW-B4 option –80 dBc (1 Hz) (nom.)
10 Hz, with R&S®FSW-B4 option –90 dBc (1 Hz) (nom.)
100 Hz < –100 dBc (1 Hz)
1 kHz < –125 dBc (1 Hz)
10 kHz < –134 dBc (1 Hz)
100 kHz < –136 dBc (1 Hz)
1 MHz < –145 dBc (1 Hz)
10 MHz –155 dBc (1 Hz) (nom.)

Residual FM frequency = 1000 MHz, RBW = 1 kHz,

< 0.1 Hz (nom.)

sweep time = 100 ms

®

4 Rohde & Schwarz R&S

FSW Signal and Spectrum Analyzer

Version 05.01, December 2012

SSB phase noise in dBc(1 Hz)

-40

-60

-80

-100

Center frequency

40 GHz

25 GHz

10 GHz

2 GHz

1 GHz

500 MHz

100 MHz

-120

-140

-160
1 Hz 10 Hz 100 Hz 1 kHz 10 kHz 100 kHz 1 MHz 10 MHz

1 10 100 1000 10000 100000 1000000 10000000

Offset from carrier

Typical phase noise at different center frequencies (with the R&S

®

FSW-B4 option for offsets ≤ 10 Hz).

Sweep time

Sweep time range span = 0 Hz 1 µs to 16000 s

span  10 Hz 1 µs to 16000 s 1

Sweep time accuracy span = 0 Hz ±0.1 % (nom.)

span  10 Hz ±3 % (nom.)

1

The selected sweep time is the net data acquisition time (without the extra time needed for hardware settling or FFT processing).

®

Rohde & Schwarz R&S

FSW Signal and Spectrum Analyzer 5

Version 05.01, December 2012

Resolution bandwidths

Sweep filters and FFT filters

Resolution bandwidths (–3 dB) 1 Hz to 10 MHz in 1/2/3/5 sequence

with R&S®FSW-B8 option, span = 0 Hz 20 MHz, 50 MHz, 80 MHz additionally
Bandwidth uncertainty < 3 % (nom.)
Shape factor 60 dB:3 dB < 5 (nom.)

Channel filters

Bandwidths (–3 dB) standard

(RRC = root raised cosine)

with R&S®FSW-B8 option 20 MHz, 28 MHz, 40 MHz, 80 MHz

Bandwidth accuracy < 2 % (nom.)
Shape factor 60 dB:3 dB < 2 (nom.)

Video bandwidths standard 1 Hz to 10 MHz in 1/2/3/5 sequence

with R&S®FSW-B8 option 20 MHz, 50 MHz, 80 MHz additionally

100 Hz, 200 Hz, 300 Hz, 500 Hz
1/1.5/2/2.4/2.7/3/3.4/4/4.5/5/6/8.5/9/10/

12.5/14/15/16/18 (RRC)/20/21/

24.3 (RRC)/25/30/50/100/150/192/200/
300/500 kHz
1/1.228/1.28 (RRC)/1.5/2/3/3.84 (RRC)/

4.096 (RRC)/5/10 MHz

additionally

Signal analysis bandwidth standard 10 MHz (nom.)

with R&S®FSW-B28 option 20 MHz, 28 MHz (nom.) additionally

with R&S®FSW-B40 option 20 MHz, 28 MHz, 40 MHz (nom.)

additionally

with R&S®FSW-B80 option 20 MHz, 28 MHz, 40 MHz, 80 MHz (nom.)

additionally

with R&S®FSW-B160 option 20 MHz, 28 MHz, 40 MHz, 80 MHz,

160 MHz (nom.) additionally

6 Rohde & Schwarz R&S

®

FSW Signal and Spectrum Analyzer

Version 05.01, December 2012

Level

Display range displayed noise floor up to +30 dBm

Max. input level

DC voltage AC coupled 50 V

DC coupled 0 V
CW RF power RF attenuation = 0 dB 20 dBm (= 0.1 W)

RF attenuation  10 dB

without R&S®FSW-B25 option or
with R&S

®

FSW-B25 option installed

and mechanical attenuation  10 dB

Pulse spectral density RF attenuation = 0 dB, RF preamplifier off 97 dB µV/MHz
Max. pulse voltage without R&S®FSW-B25 option or electronic attenuation off

RF attenuation  10 dB 150 V

with R&S®FSW-B25 option installed, electronic attenuation on

mechanical attenuation = 0 dB 25 V
mechanical attenuation  10 dB 75 V

Max. pulse energy without R&S®FSW-B25 option or electronic attenuation off

RF attenuation  10 dB, 10 µs 1 mWs

with R&S®FSW-B25 option installed, electronic attenuation on

mechanical attenuation  10 dB, 10 µs 1 mWs

Intermodulation

1 dB compression of input mixer
(two-tone)

RF attenuation = 0 dB, RF preamplifier off

fin  3 GHz +15 dBm (nom.)
3 GHz < fin  8 GHz +10 dBm (nom.)
fin > 8 GHz +7 dBm (nom.)

with R&S®FSW-B24 option, RF attenuation = 0 dB, RF preamplifier on

fin  3 GHz –13 dBm (nom.)
3 GHz < fin  8 GHz –20 dBm (nom.)
fin > 8 GHz –23 dBm (nom.)

Third-order intercept point (TOI) R&S®FSW8, R&S®FSW13, R&S®FSW26, R&S®FSW43, RF attenuation = 0 dB,

level 2 × –15 dBm, f > 5 × RBW, YIG preselector on, RF preamplifier off

fin < 10 MHz 28 dBm (nom.)
10 MHz  fin < 1 GHz > 25 dBm, typ. 30 dBm
1 GHz  fin < 3 GHz > 20 dBm, typ. 25 dBm 2
3 GHz  fin < 8 GHz > 17 dBm, typ. 20 dBm

R&S®FSW13, R&S®FSW26, RF attenuation = 0 dB,

level 2 × –15 dBm, f > 5 × RBW, YIG preselector on, RF preamplifier off

fin  8 GHz > 12 dBm, typ. 17 dBm

R&S®FSW43, RF attenuation = 0 dB,

level 2 × –20 dBm, f > 5 × RBW, YIG preselector on, RF preamplifier off

8 GHz  fin  13,6 GHz > 8 dBm, typ. 11 dBm
13,6 GHz  fin  40 GHz > 10 dBm, typ. 15 dBm
fin > 40 GHz 12 dBm (nom.)

R&S®FSW8, R&S®FSW13, R&S®FSW26 with R&S®FSW-B24 option,

RF attenuation = 0 dB, level 2 × –50 dBm, f > 5 × RBW,

YIG preselector on, RF preamplifier on

10 MHz  fin < 1 GHz –10 dBm (nom.)
1 GHz  fin < 8 GHz –13 dBm (nom.)
8 GHz  fin  26.5 GHz –15 dBm (nom.)

R&S®FSW43 with R&S®FSW-B24 option,

RF attenuation = 0 dB, level 2 × –55 dBm, f > 5 × RBW,

YIG preselector on, RF preamplifier on

10 MHz  fin < 1 GHz –5 dBm (nom.)
1 GHz  fin < 4 GHz –10 dBm (nom.)
fin > 4 GHz –20 dBm (nom.)

30 dBm (= 1 W)

2

With R&S®FSW-B13 highpass filter option, highpass off. With highpass on, the TOI degrades by 5 dB (nom.).

®

Rohde & Schwarz R&S

FSW Signal and Spectrum Analyzer 7

Version 05.01, December 2012

®

Second-harmonic intercept point (SHI) R&S

YIG preselector on, RF preamplifier off

R&S®FSW43, RF attenuation = 0 dB, level = –5 dBm,

YIG preselector on, RF preamplifier off

R&S®FSW8, R&S®FSW13, R&S®FSW26, R&S®FSW43 with R&S®FSW-B24 option,

RF attenuation = 0 dB, level = –50 dBm, YIG preselector on, RF preamplifier on

FSW8, R&S®FSW13, R&S®FSW26, RF attenuation = 0 dB, level = –5 dBm,

1 MHz < fin  350 MHz > 50 dBm, typ. 62 dBm
350 MHz < fin  500 MHz > 70 dBm, typ. 80 dBm
500 MHz < fin < 1.5 GHz 3 > 47 dBm, typ. 52 dBm
500 MHz < fin < 1.5 GHz 4 > 62 dBm, typ. 70 dBm

1.5 GHz  fin  4 GHz > 62 dBm, typ. 70 dBm
4 GHz < fin  13.5 GHz 65 dBm (nom.)

1 MHz < fin  500 MHz > 45 dBm, typ. 55 dBm
500 MHz < fin < 1.5 GHz 3 > 47 dBm, typ. 56 dBm
500 MHz < fin < 1.5 GHz 4 > 52 dBm, typ. 60 dBm

1.5 GHz  fin  4 GHz > 62 dBm, typ. 70 dBm
4 GHz < fin  21.75 GHz 65 dBm (nom.)

50 MHz < fin  21.75 GHz 10 dBm (nom.)

3

Without R&S®FSW-B13 highpass filter option or highpass off.

4

With R&S®FSW-B13 highpass filter option, highpass on.

®

8 Rohde & Schwarz R&S

FSW Signal and Spectrum Analyzer

Version 05.01, December 2012

®

®

Displayed average noise level of the R&S

FSW8

RF attenuation = 0 dB, termination = 50 , normalized to 1 Hz RBW, trace average,

average mode log, sample detector, +5 °C to +40 °C, RF preamplifier off

2 Hz  f  100 Hz < –110 dBm, typ. –120 dBm
100 Hz < f  1 kHz < –120 dBm, typ. –130 dBm
1 kHz < f < 9 kHz < –135 dBm, typ. –147 dBm

RF attenuation = 0 dB, termination = 50 , log. scaling, normalized to 1 Hz RBW,

RBW = 1 kHz, VBW = 1 Hz, +5 °C to +40 °C, RF preamplifier off,

without R&S

®

FSW-B25 electronic attenuator option

9 kHz  f  1 MHz < –145 dBm, typ. –150 dBm
1 MHz < f  1 GHz < –150 dBm, typ. –154 dBm
1 GHz < f < 3 GHz 3 < –152 dBm, typ. –156 dBm
1 GHz < f < 3 GHz 4 < –155 dBm, typ. –160 dBm
3 GHz  f  8 GHz < –152 dBm, typ. –156 dBm

add 1 dB to the above values if R&S®FSW-B25 option is installed

RF attenuation = 0 dB, termination = 50 , log. scaling, normalized to 1 Hz RBW,

RBW = 1 kHz, VBW = 1 Hz, +5 °C to +40 °C, with R&S

RF preamplifier = 30 dB, without R&S

®

FSW-B25 electronic attenuator option

®

FSW-B24 option,

10 MHz < f  50 MHz –154 dBm (nom.)
50 MHz < f  150 MHz < –163 dBm, typ. –166 dBm
150 MHz < f  8 GHz < –166 dBm, typ. –169 dBm

add 1 dB to the above values if R&S®FSW-B25 option is installed
Improvement with noise cancellation for noise-like signals 13 dB (nom.)

Displayed average noise level of the R&S

FSW13, R&S®FSW26, without R&S®FSW-B24 option

RF attenuation = 0 dB, termination = 50 , normalized to 1 Hz RBW, trace average,

average mode log, sample detector, +5 °C to +40 °C

2 Hz  f  100 Hz < –110 dBm, typ. –120 dBm
100 Hz < f  1 kHz < –120 dBm, typ. –130 dBm
1 kHz < f < 9 kHz < –135 dBm, typ. –147 dBm

RF attenuation = 0 dB, termination = 50 , log. scaling, normalized to 1 Hz RBW,

RBW = 1 kHz, VBW = 1 Hz, +5 °C to +40 °C, f  8 GHz: YIG preselector on,

without R&S

®

FSW-B25 electronic attenuator option

9 kHz  f  1 MHz < –145 dBm, typ. –150 dBm
1 MHz < f  1 GHz < –149 dBm, typ. –154 dBm
1 GHz < f < 3 GHz 3 < –151 dBm, typ. –156 dBm
1 GHz < f < 3 GHz 4 < –154 dBm, typ. –159 dBm
3 GHz  f < 8 GHz < –151 dBm, typ. –156 dBm
8 GHz  f < 13.6 GHz < –150 dBm, typ. –155 dBm

13.6 GHz  f < 18 GHz < –149 dBm, typ. –153 dBm
18 GHz  f < 25 GHz < –147 dBm, typ. –150 dBm
25 GHz  f < 26.5 GHz < –143 dBm, typ. –146 dBm

add 1 dB to the above values for frequencies < 8 GHz, 2 dB for frequencies  8 GHz,

®

FSW-B25 option is installed

if R&S

RF attenuation = 0 dB, termination = 50 , log. scaling, normalized to 1 Hz RBW,

RBW = 1 kHz, VBW = 1 Hz, +5 °C to +40 °C, YIG preselector off,

without R&S

®

FSW-B25 electronic attenuator option

8 GHz  f < 13.6 GHz < –150 dBm, typ. –155 dBm

13.6 GHz  f < 25 GHz < –149 dBm, typ. –153 dBm
25 GHz  f < 26.5 GHz < –147 dBm, typ. –150 dBm

add 2 dB to the above values if R&S®FSW-B25 option is installed
Improvement with noise cancellation for noise-like signals 13 dB (nom.)

®

Rohde & Schwarz R&S

FSW Signal and Spectrum Analyzer 9

Version 05.01, December 2012

®

Displayed average noise level of the R&S

FSW13, R&S®FSW26, with R&S®FSW-B24 option

RF attenuation = 0 dB, termination = 50 , normalized to 1 Hz RBW, trace average,

average mode log, sample detector, +5 °C to +40 °C, RF preamplifier off

2 Hz  f  100 Hz < –110 dBm, typ. –120 dBm
100 Hz < f  1 kHz < –120 dBm, typ. –130 dBm
1 kHz < f < 9 kHz < –135 dBm, typ. –147 dBm

RF attenuation = 0 dB, termination = 50 , log. scaling, normalized to 1 Hz RBW,

RBW = 1 kHz, VBW = 1 Hz, +5 °C to +40 °C, f  8 GHz: YIG preselector on,

RF preamplifier off, without R&S

®

FSW-B25 electronic attenuator option

9 kHz  f  1 MHz < –145 dBm, typ. –150 dBm
1 MHz < f  1 GHz < –149 dBm, typ. –154 dBm
1 GHz < f < 3 GHz 3 < –151 dBm, typ. –156 dBm
1 GHz < f < 3 GHz 4 < –154 dBm, typ. –159 dBm
3 GHz  f < 8 GHz < –151 dBm, typ. –156 dBm
8 GHz  f < 13.6 GHz < –149 dBm, typ. –154 dBm

13.6 GHz  f < 18 GHz < –148 dBm, typ. –152 dBm
18 GHz  f < 25 GHz < –145 dBm, typ. –149 dBm
25 GHz  f < 26.5 GHz < –141 dBm, typ. –145 dBm

add 1 dB to the above values for frequencies < 8 GHz, 2 dB for frequencies  8 GHz,

®

FSW-B25 option is installed

if R&S

RF attenuation = 0 dB, termination = 50 , log. scaling, normalized to 1 Hz RBW,

RBW = 1 kHz, VBW = 1 Hz, +5 °C to +40 °C, YIG preselector off,

RF preamplifier off, without R&S

®

FSW-B25 electronic attenuator option

8 GHz  f < 13.6 GHz < –149 dBm, typ. –154 dBm

13.6 GHz  f < 25 GHz < –148 dBm, typ. –152 dBm
25 GHz  f < 26.5 GHz < –145 dBm, typ. –149 dBm

add 2 dB to the above values if R&S®FSW-B25 option is installed

RF attenuation = 0 dB, termination = 50 , log. scaling, normalized to 1 Hz RBW,

RBW = 1 kHz, VBW = 1 Hz, +5 °C to +40 °C, YIG preselector on,

RF preamplifier = 30 dB, without R&S

®

FSW-B25 electronic attenuator option

10 MHz < f  50 MHz –154 dBm (nom.)
50 MHz < f  150 MHz < –163 dBm, typ. –166 dBm
150 MHz < f  8 GHz < –166 dBm, typ. –169 dBm
8 GHz < f  13.6 GHz < –164 dBm, typ. –168 dBm

13.6 GHz < f  22 GHz < –162 dBm, typ. –166 dBm
22 GHz < f  26.5 GHz < –157 dBm, typ. –161 dBm

add 1 dB to the above values for frequencies < 8 GHz, 2 dB for frequencies  8 GHz,

®

if R&S

FSW-B25 option is installed

Improvement with noise cancellation for noise-like signals 13 dB (nom.)

®

10 Rohde & Schwarz R&S

FSW Signal and Spectrum Analyzer

Version 05.01, December 2012

Displayed average noise level of the R&S®FSW43, without R&S®FSW-B24 option

RF attenuation = 0 dB, termination = 50 , normalized to 1 Hz RBW, trace average,

average mode log, sample detector, +5 °C to +40 °C

2 Hz  f  100 Hz < –110 dBm, typ. –120 dBm
100 Hz < f  1 kHz < –120 dBm, typ. –130 dBm
1 kHz < f < 9 kHz < –135 dBm, typ. –147 dBm

RF attenuation = 0 dB, termination = 50 , log. scaling, normalized to 1 Hz RBW,

RBW = 1 kHz, VBW = 1 Hz, +5 °C to +40 °C, f  8 GHz: YIG preselector on

9 kHz  f  1 MHz < –145 dBm, typ. –150 dBm
1 MHz < f  1 GHz < –149 dBm, typ. –154 dBm
1 GHz < f < 3 GHz 3 < –151 dBm, typ. –156 dBm
1 GHz < f < 3 GHz 4 < –154 dBm, typ. –159 dBm
3 GHz  f < 8 GHz < –151 dBm, typ. –156 dBm
8 GHz  f < 13.6 GHz < –150 dBm, typ. –154 dBm

13.6 GHz  f < 18 GHz < –149 dBm, typ. –153 dBm
18 GHz  f < 25 GHz < –147 dBm, typ. –151 dBm
25 GHz  f  34 GHz < –143 dBm, typ. –147 dBm
34 GHz < f  40 GHz < –140 dBm, typ. –144 dBm
40 GHz < f  43.5 GHz < –138 dBm, typ. –142 dBm

RF attenuation = 0 dB, termination = 50 , log. scaling, normalized to 1 Hz RBW,

RBW = 1 kHz, VBW = 1 Hz, +5 °C to +40 °C, YIG preselector off

8 GHz  f < 13.6 GHz < –152 dBm, typ. –157 dBm

13.6 GHz  f < 18 GHz < –151 dBm, typ. –156 dBm
18 GHz  f < 25 GHz < –149 dBm, typ. –154 dBm
25 GHz  f  34 GHz < –147 dBm, typ. –151 dBm
34 GHz < f  40 GHz < –144 dBm, typ. –148 dBm
40 GHz < f  43.5 GHz < –142 dBm, typ. –146 dBm

Improvement with noise cancellation for noise-like signals 13 dB (nom.)

Rohde & Schwarz R&S

®

FSW Signal and Spectrum Analyzer 11

Version 05.01, December 2012

®

Displayed average noise level of the R&S

FSW43, with R&S®FSW-B24 option

RF attenuation = 0 dB, termination = 50 , normalized to 1 Hz RBW, trace average,

average mode log, sample detector, +5 °C to +40 °C

2 Hz  f  100 Hz < –110 dBm, typ. –120 dBm
100 Hz < f  1 kHz < –120 dBm, typ. –130 dBm
1 kHz < f < 9 kHz < –135 dBm, typ. –147 dBm

RF attenuation = 0 dB, termination = 50 , log. scaling, normalized to 1 Hz RBW,

RBW = 1 kHz, VBW = 1 Hz, +5 °C to +40 °C, f  8 GHz: YIG preselector on,

RF preamplifier off

9 kHz  f  1 MHz < –145 dBm, typ. –150 dBm
1 MHz < f  1 GHz < –149 dBm, typ. –154 dBm
1 GHz < f < 3 GHz 3 < –150 dBm, typ. –155 dBm
1 GHz < f < 3 GHz 4 < –153 dBm, typ. –158 dBm
3 GHz  f < 8 GHz < –150 dBm, typ. –155 dBm
8 GHz  f < 13.6 GHz < –148 dBm, typ. –152 dBm

13.6 GHz  f < 18 GHz < –147 dBm, typ. –151 dBm
18 GHz  f < 25 GHz < –145 dBm, typ. –149 dBm
25 GHz  f  34 GHz < –140 dBm, typ. –144 dBm
34 GHz < f  40 GHz < –137 dBm, typ. –141 dBm
40 GHz < f  43.5 GHz < –135 dBm, typ. –140 dBm

RF attenuation = 0 dB, termination = 50 , log. scaling, normalized to 1 Hz RBW,

RBW = 1 kHz, VBW = 1 Hz, +5 °C to +40 °C, YIG preselector off,

RF preamplifier off

8 GHz  f < 13.6 GHz < –150 dBm, typ. –155 dBm

13.6 GHz  f < 18 GHz < –149 dBm, typ. –154 dBm
18 GHz  f < 25 GHz < –147 dBm, typ. –152 dBm
25 GHz  f  34 GHz < –144 dBm, typ. –149 dBm
34 GHz < f  40 GHz < –141 dBm, typ. –145 dBm
40 GHz < f  43.5 GHz < –139 dBm, typ. –144 dBm

RF attenuation = 0 dB, termination = 50 , log. scaling, normalized to 1 Hz RBW,

RBW = 1 kHz, VBW = 1 Hz, +5 °C to +40 °C, YIG preselector on,

RF preamplifier = 30 dB

100 kHz < f  1 MHz < –160 dBm, typ. –163 dBm
1 MHz < f  3 GHz < –165 dBm, typ. –169 dBm
3 GHz < f  8 GHz < –162 dBm, typ. –166 dBm
8 GHz < f  18 GHz < –162 dBm, typ. –167 dBm
18 GHz < f  26.5 GHz < –161 dBm, typ. –166 dBm

26.5 GHz < f  40 GHz < –160 dBm, typ. –164 dBm
40 GHz < f  43.5 GHz < –157 dBm, typ. –162 dBm

Improvement with noise cancellation for noise-like signals 13 dB (nom.)

Spurious responses YIG preselector on for f  8 GHz, mixer level  –10 dBm

5

,

sweep optimization: auto or dynamic
Image response fin – 2 × 8997 MHz (1st IF) < –90 dBc

fin – 2 × 1317 MHz (2nd IF) < –90 dBc

fin – 2 × 37 MHz (3rd IF) < –90 dBc
Intermediate frequency response 1st IF (8997 MHz) < –90 dBc

2nd IF (1317 MHz) < –90 dBc

3rd IF (37 MHz) < –90 dBc
Residual spurious response RF attenuation = 0 dB

f  1 MHz < –90 dBm
1 MHz < f < 8900 MHz < –110 dBm
f  8900 MHz < –100 dBm

f = receive frequency
Local oscillators related spurious 10 Hz  offset from carrier < 200 Hz < –90 dBc + 20 log (fin/GHz)

offset from carrier > 200 Hz < –100 dBc + 20 log (fin/GHz)
Vibrational environmental stimuli max. 0.21 g RMS < –60 dBc + 20 log (fin/GHz) (nom.)

5

Mixer level = signal level – RF attenuation + preamplifier gain.

®

12 Rohde & Schwarz R&S

FSW Signal and Spectrum Analyzer

Version 05.01, December 2012

Level display

Logarithmic level axis 1 dB to 200 dB, in steps of 1/2/5
Linear level axis 10 % of reference level per level division,

10 divisions or logarithmic scaling
Number of traces 6
Trace detector max. peak, min. peak, auto peak (normal),

sample, RMS, average
Trace functions clear/write, max. hold, min. hold, average,

view
Setting range of reference level –130 dBm to (–10 dBm + RF attenuation

– RF preamplifier gain), in steps of

0.01 dB

Units of level axis logarithmic level display dBm, dBµV, dBmV, dBµA, dBpW

linear level display µV, mV, µA, mA, pW, nW

Level measurement uncertainty

Absolute level uncertainty at 64 MHz

RBW = 10 kHz, level = –10 dBm, reference level = –10 dBm, RF attenuation = 10 dB

without R&S®FSW-B25 option or

< 0.2 dB ( = 0.07 dB)

electronic attenuator off
with R&S®FSW-B25 option,

< 0.4 dB ( = 0.14 dB)

electronic attenuator on
Frequency response,
referenced to 64 MHz,
YIG preselector on

RF attenuation = 10 dB, 20 dB, 30 dB, 40 dB, RF preamplifier off, +20 °C to +30 °C,
electronic attenuator off

2 Hz  f < 9 kHz < 1 dB (nom.)

9 kHz  f < 10 MHz < 0.45 dB ( = 0.17 dB)

10 MHz  f < 3.6 GHz < 0.3 dB ( = 0.10 dB)

3.6 GHz  f  8 GHz < 0.5 dB ( = 0.17 dB)

8 GHz < f < 22 GHz, span < 1 GHz < 1.5 dB ( = 0.50 dB)

22 GHz  f  26.5 GHz, span < 1 GHz < 2 dB ( = 0.67 dB)

26.5 GHz < f  43.5 GHz, span < 1 GHz < 2.5 dB ( = 0.83 dB)

any RF attenuation or electronic attenuator on, +15 °C to +40 °C

2 Hz  f < 9 kHz < 1 dB (nom.)

9 kHz  f < 3.6 GHz < 0.6 dB ( = 0.20 dB)

3.6 GHz  f  8 GHz < 0.8 dB ( = 0.27 dB)

8 GHz < f < 22 GHz, span < 1 GHz < 2 dB ( = 0.67 dB)

22 GHz  f  26.5 GHz, span < 1 GHz < 2.5 dB ( = 0.83 dB)

26.5 GHz < f  43.5 GHz, span < 1 GHz < 3 dB ( = 1.0 dB)

RF attenuation  20 dB, RF preamplifier on, +20 °C to +30 °C

10 MHz  f < 3.6 GHz < 0.6 dB ( = 0.2 dB)

3.6 GHz  f  8 GHz < 0.8 dB ( = 0.27 dB)

8 GHz < f < 22 GHz, span < 1 GHz < 2 dB ( = 0.67 dB)

22 GHz  f  26.5 GHz, span < 1 GHz < 2.5 dB ( = 0.83 dB)

26.5 GHz < f  43.5 GHz, span < 1 GHz < 3 dB ( = 1.0 dB)

Frequency response,
referenced to 64 MHz,
YIG preselector off

RF attenuation = 10 dB, 20 dB, 30 dB, 40 dB, RF preamplifier off, +20 °C to +30 °C,
electronic attenuator off

f < 8 GHz same values as with preselector on

8 GHz  f < 22 GHz < 1.5 dB ( = 0.5 dB)

22 GHz  f  26.5 GHz < 2 dB ( = 0.6 dB)

26.5 GHz < f  43.5 GHz, span < 1 GHz < 2.5 dB ( = 0.83 dB)

any RF attenuation or electronic attenuator on, +15 °C to +40 °C

f < 8 GHz same values as with preselector on

8 GHz  f < 22 GHz < 2 dB ( = 0.6 dB)

22 GHz  f  26.5 GHz < 2.5 dB ( = 0.75 dB)

26.5 GHz < f  43.5 GHz, span < 1 GHz < 3 dB ( = 1.0 dB)

RF attenuation  20 dB, RF preamplifier on, +20 °C to +30 °C

f < 8 GHz same values as with preselector on

8 GHz  f < 22 GHz < 2 dB ( = 0.6 dB)

22 GHz  f  26.5 GHz < 2.5 dB ( = 0.75 dB)

26.5 GHz < f  43.5 GHz, span < 1 GHz < 3 dB ( = 1.0 dB)

Rohde & Schwarz R&S

®

FSW Signal and Spectrum Analyzer 13

Version 05.01, December 2012

Attenuator switching uncertainty f = 64 MHz, 0 dB to 70 dB,

< 0.2 dB ( = 0.07 dB)

referenced to 10 dB attenuation

Uncertainty of reference level setting input mixer level  –15 dBm 0 dB 6

input mixer level > –15 dBm < 0.1 dB (nom.)

Bandwidth switching uncertainty referenced to RBW = 10 kHz < 0.1 dB ( = 0.04 dB)

Nonlinearity of displayed level

Logarithmic level display S/N > 16 dB, 0 dB  level  –70 dB < 0.1 dB ( = 0.04 dB)

S/N > 16 dB, –70 dB < level  –90 dB < 0.2 dB ( = 0.08 dB)

Linear level display S/N > 16 dB, 0 dB to –70 dB < 5 % of reference level (nom.)

Total measurement uncertainty

YIG preselector on signal level = 0 dB to –70 dB below reference level, S/N > 20 dB, sweep time = “auto”,

RF attenuation = 10 dB, 20 dB, 30 dB, 40 dB, RF preamplifier off,
electronic attenuator off, span/RBW < 100, 95 % confidence level, +20 °C to +30 °C

9 kHz  f  10 MHz ±0.37 dB

10 MHz < f  3.6 GHz ±0.27 dB

3.6 GHz < f  8 GHz ±0.37 dB

8 GHz < f  22 GHz ±1.4 dB

22 GHz < f  26.5 GHz ±1.7 dB

26.5 GHz < f  43.5 GHz ±2.5 dB

YIG preselector off signal level = 0 dB to –70 dB below reference level, S/N > 20 dB, sweep time = “auto”,

RF attenuation = 10 dB, 20 dB, 30 dB, 40 dB, RF preamplifier off,
electronic attenuator off, span/RBW < 100, 95 % confidence level, +20 °C to +30 °C

8 GHz  f  22 GHz ±1.0 dB

22 GHz < f  26.5 GHz ±1.2 dB

26.5 GHz < f  43.5 GHz ±1.7 dB

Adjacent channel power dynamic range

Adjacent channel leakage ratio (ACLR) 3GPP WCDMA, single carrier, 1 DPCH, carrier frequency = 2 GHz

noise cancellation off 7

1st adjacent channel –76 dB (nom.)
2nd adjacent channel –82 dB (nom.)

noise cancellation on

1st adjacent channel –88 dB (nom.)
2nd adjacent channel –90 dB (nom.)

Optimum mixer level 3GPP WCDMA, single carrier, 1 DPCH, carrier frequency = 2 GHz

noise cancellation off

1st adjacent channel –5 dBm (nom.)
2nd adjacent channel 0 dBm (nom.)

noise cancellation on

1st adjacent channel –12 dBm (nom.)
2nd adjacent channel –5 dBm (nom.)

Measurement speed 8

Local measurement and display update
rate
Remote measurement, 1000 sweep
averages

9

Remote measurement and LAN transfer 8 5 ms (200/s) (meas.)
Marker peak search 1.7 ms (meas.)
Center frequency tune and transfer 8 f  8 GHz 15 ms (meas.)

6

The reference level setting affects only the graphical representation of the measurement result on the display, not the measurement itself.

The reference level setting causes no additional uncertainty in measurement results.

7

Noise cancellation off represents the raw performance of the R&S®FSW without numeric compensation for its inherent noise.

8

Sweep points set to 1001 points (= default), sweep optimization set to “speed”.

9

Measured with PC equipped with Intel® Core™ i7 CPU 2.8 GHz and Gbit LAN interface.

1001 sweep points 1.25 ms (800/s) (meas.)

1001 sweep points 1.0 ms (1000/s) (meas.)

f > 8 GHz 65 ms (meas.)

14 Rohde & Schwarz R&S

®

FSW Signal and Spectrum Analyzer

Version 05.01, December 2012

Trigger functions

Trigger

Trigger source free run, video, external, IF power,

Trigger offset span  10 Hz 5 ns to 20 s

span = 0 Hz (–sweep time) to 20 s

Min. trigger offset resolution span > 0 Hz 5 ns

span = 0 Hz, trigger offset > 0 5 ns
span = 0 Hz, trigger offset < 0 sweep time/number of sweep points

Max. deviation of trigger offset 5 ns

IF power trigger

Sensitivity min. signal power –60 dBm + RF attenuation –

max. signal power –10 dBm + RF attenuation –

IF power trigger bandwidth RBW > 500 kHz 20 MHz (nom.)

RBW  500 kHz, FFT 20 MHz (nom.)
RBW  500 kHz, swept 6 MHz (nom.)

RF power trigger

Sensitivity min. signal power –30 dBm + RF attenuation –

max. signal power +10 dBm + RF attenuation –

RF power trigger bandwidth f  8 GHz 8 GHz (nom.)

f > 8 GHz 500 MHz (nom.) 11

Gated sweep

Gate source video, external, IF power, RF power
Gate delay 5 ns to 20 s, min. resolution 5 ns
Gate length 5 ns to 20 s, min. resolution 5 ns
Max. deviation of gate length ±5 ns

RF power

RF preamplifier gain (nom.)

RF preamplifier gain (nom.)

RF preamplifier gain (nom.)

RF preamplifier gain (nom.)

10

Audio demodulator

Demodulation

AF demodulation types AM and FM
Audio output loudspeaker and phone jack
Marker stop time in spectrum mode 100 ms to 60 s

I/Q data

Memory length max. 400 Msample I and Q
Word length of I/Q samples sampling rate > 100 MHz or

Sampling rate 100 Hz to 200 MHz
Max. signal analysis bandwidth
(equalized)

number of samples > 300 Msample
otherwise 24 bit

standard 10 MHz
with R&S®FSW-B28 option 28 MHz (nom.) 11
with R&S®FSW-B40 option 40 MHz (nom.) 11
with R&S®FSW-B80 option 80 MHz (nom.) 11
with R&S®FSW-B160 option 160 MHz (nom.) 11

18 bit

10

Sweep optimization = “auto”.

11

YIG preselector off for f  8 GHz.

Rohde & Schwarz R&S

®

FSW Signal and Spectrum Analyzer 15

Version 05.01, December 2012

Signal analysis bandwidth ≤ 80 MHz

Amplitude flatness (1.25 × signal analysis bandwidth) 

f

< 8 GHz

center

f

 8 GHz, YIG preselector off ±0.5 dB (nom.)

center

Deviation from linear phase (1.25 × signal analysis bandwidth) 

< 8 GHz

f

center

f

 8 GHz, YIG preselector off ±2° (nom.)

center

±0.3 dB (nom.)

±1° (nom.)

Level display nonlinearity see “Display nonlinearity”
Level measurement uncertainty see “Total measurement uncertainty,

YIG preselector off”
Third-order intermodulation distortion see “Third-order intercept point (TOI)”
ADC related spurious response mixer level = –30 dBm 12

analysis bandwidth < 17 MHz –100 dBc (nom.)
17 MHz  analysis bandwidth < 80 MHz –80 dBc (nom.)

Other spurious responses see “Spurious responses”

Signal analysis bandwidth 80 MHz to 160 MHz

13

Amplitude flatness YIG preselector off for f  8 GHz

150 MHz  f
4 GHz  f
8 GHz  f

26.5 GHz  f

< 4 GHz ±0.5 dB (nom.)

center

< 8 GHz ±0.7 dB (nom.)

center

< 26.5 GHz ±1 dB (nom.)

center

 43.5 GHz ±2 dB (nom.)

center

Deviation from linear phase YIG preselector off for f  8 GHz

150 MHz  f
4 GHz  f
8 GHz  f

26.5 GHz  f

< 4 GHz ±1° (nom.)

center

< 8 GHz ±2° (nom.)

center

< 26.5 GHz ±2.5° (nom.)

center

 43.5 GHz ±4° (nom.)

center

Level display nonlinearity 0 dB to –70 dB < 0.15 dB (nom.)
Level measurement uncertainty add 0.2 dB (nom.) to the values in

“Total measurement uncertainty,

YIG preselector off”
Third-order intermodulation distortion 150 MHz  f

two –20 dBm tones at input mixer
within analysis bandwidth

 8 GHz:

f

center

two –25 dBm tones at input mixer
within analysis bandwidth

< 8 GHz:

center

–70 dBc (nom.)

12

,

12

,

reference level = signal level + 6 dB
Residual spurious response RF attenuation 0 dB, f
ADC related spurious response single tone within analysis bandwidth,

mixer level = –10 dBm

 150 MHz –90 dBm (nom.)

center

12

,

–70 dBc (nom.)

reference level = signal level,

 150 MHz

f

center

Other spurious responses see “Spurious responses”

12

Level of a tone at the input mixer (also abbreviated as “mixer level”) = signal level – RF attenuation + preamplifier gain.

13

R&S®FSW-B160 option is required for 80 MHz to 160 MHz analysis bandwidth.

®

16 Rohde & Schwarz R&S

FSW Signal and Spectrum Analyzer

Version 05.01, December 2012

Inputs and outputs

RF input

Impedance 50 
Connector R&S®FSW8, R&S®FSW13 N female

R&S®FSW26 APC 3.5 mm male (compatible with SMA)

R&S®FSW43 2.92 mm male (compatible with SMA)
VSWR of R&S®FSW8 RF attenuation  4 dB

10 MHz  f  8 GHz typ. 1.87 14

5 dB  RF attenuation  9 dB

10 MHz  f < 1 GHz < 1.5, typ. 1.20 14
10 MHz  f < 3.6 GHz < 1.5, typ. 1.31 14

3.6 GHz  f  8 GHz < 2.0, typ. 1.51 14

RF attenuation  10 dB

10 MHz  f < 1 GHz < 1.2, typ. 1.09 14
1 GHz  f < 3.6 GHz < 1.5, typ. 1.19 14

3.6 GHz  f  8 GHz < 2.0, typ. 1.42 14

VSWR of R&S®FSW13 RF attenuation  4 dB

10 MHz  f  13.6 GHz typ. 1.87 14

5 dB  RF attenuation  9 dB

10 MHz  f < 3.6 GHz < 1.5, typ. 1.25 14

3.6 GHz  f  13.6 GHz < 2.0, typ. 1.29 14

RF attenuation  10 dB

10 MHz  f < 1 GHz < 1.2, typ. 1.10 14
1 GHz  f < 3.6 GHz < 1.5, typ. 1.14 14

3.6 GHz  f  13.6 GHz < 2.0, typ. 1.22 14

VSWR of R&S®FSW26, R&S®FSW43 RF attenuation  4 dB

10 MHz  f  26.5 GHz typ. 1.87 14

26.5 GHz < f  40 GHz typ. 2.0 14
40 GHz < f  43.5 GHz 2.0 (nom.)

5 dB  RF attenuation  9 dB

10 MHz  f  3.5 GHz < 1.5, typ. 1.24 14

3.5 GHz < f  8 GHz < 1.8, typ. 1.26 14
8 GHz < f  18 GHz < 1.8, typ. 1.39 14
18 GHz < f  26.5 GHz < 2.0, typ. 1.43 14

26.5 GHz < f  40 GHz < 2.5, typ. 1.8 14
40 GHz < f  43.5 GHz 2.0 (nom.)

RF attenuation  10 dB

10 MHz  f  3.5 GHz < 1.2, typ. 1.12 14

3.5 GHz < f  8 GHz < 1.5, typ. 1.19 14
8 GHz < f  18 GHz < 1.5, typ. 1.25 14
18 GHz < f  26.5 GHz < 2.0, typ. 1.37 14

26.5 GHz < f  40 GHz < 2.5, typ. 1.7 14
40 GHz < f  43.5 GHz 2.0 (nom.)

Setting range of attenuator 0 dB to 79 dB, in 1 dB steps 15

Probe power supply

Supply voltages +15 V DC, –12.6 V DC and ground,

Noise source control

Connector BNC female
Output voltage 0 V/28 V, max. 100 mA, switchable (nom.)

Power sensor

Connector 6-pin LEMOSA female for R&S®NRP-Zxx

max. 150 mA (nom.)

power sensors

14

Typical VSWR performance: performance expected to be met in 95 % of the cases with a confidence level of 95 %, temperature +20 °C to +30 °C,

input set to “DC coupling”. These values are not warranted and are subject to modification if a significant change in the statistical behavior of
production instruments is observed.

15

Mechanical RF attenuator: 5 dB steps. Electronic IF attenuator: 1 dB steps.

®

Rohde & Schwarz R&S

FSW Signal and Spectrum Analyzer 17

Version 05.01, December 2012

USB interface 7 ports, type A plug, version 2.0

1 port, type B plug, version 2.0

AF output

Connector 3.5 mm mini-jack
Output impedance 10  (nom.)
Open-circuit voltage up to 1.5 V, adjustable

External trigger/gate

Number of ports 1 × input, 2 × input/output, selectable
Connector BNC female
Trigger input voltage 0.5 V to 3.5 V (nom.)
Trigger output voltage TTL-compatible, 0 V/5 V (nom.)
Impedance 10 k (nom.)

Reference input 1 MHz to 20 MHz

Connector BNC female
Impedance 50  (nom.)
Input frequency range 1 MHz  fin  20 MHz, in 1 Hz steps
Required level > 0 dBm

Reference input 100 MHz

Connector SMA female
Impedance 50  (nom.)
Input frequency range 100 MHz
Required level 0 dBm to 10 dBm

Reference output 10 MHz

Connector BNC female
Impedance 50  (nom.)
Output frequency 10 MHz
Level 10 dBm (nom.)

Reference output 1 MHz to 20 MHz

Connector BNC female
Impedance 50  (nom.)
Output frequency internal reference not active

external reference same as reference input signal
Level same as reference input signal

Reference output 100 MHz

Connector SMA female
Impedance 50  (nom.)
Output frequency 100 MHz
Level 6 dBm (nom.)

Reference output 640 MHz

Connector SMA female
Impedance 50  (nom.)
Output frequency 640 MHz
Level 16 dBm (nom.)

IF/video output

Connector BNC female, 50  (nom.)

IF out

Bandwidth equal to RBW setting
IF frequency (RBW/2) to (240 MHz – RBW/2)
Output level center frequency > 10 MHz, span = 0 Hz

0 dBm (nom.)
or I/Q Analyzer on, signal at reference
level and center frequency

18 Rohde & Schwarz R&S

®

FSW Signal and Spectrum Analyzer

Version 05.01, December 2012

®

Video out

Bandwidth equal to VBW setting
Output scaling log. display scale logarithmic

lin. display scale linear

Output level center frequency > 10 MHz, span = 0 Hz,

1 V, open circuit (nom.)
signal at reference level and center
frequency

IF wide output (with R&S

FSW-B160 option only)

Connector BNC female, 50  (nom.)

IF out

IF frequency center frequency  200 MHz 50 MHz to 550 MHz (nom.)
Max. bandwidth (6 dB) YIG preselector off 500 MHz
Output level RF attenuation auto,

–20 dBm (nom.)
reference level  –15 dBm,
signal level = reference level

Aux port

Connector 9-pin D-Sub male
Output TTL-compatible, 0 V/5 V (nom.),

max. 15 mA (nom.)

Input TTL-compatible, max. 5 V (nom.)

IEC/IEEE bus control interface in line with

IEC 625-2 (IEEE 488.2)

Command set SCPI 1997.0
Connector 24-pin Amphenol female
Interface functions SH1, AH1, T6, L4, SR1, RL1, PP1, DC1,

DT1, C0

LAN interface 10/100/1000BaseT
Connector RJ-45

External monitor

Connector DVI-D, DisplayPort Rev 1.1

Synchronization input

Connector HDMI

Synchronization output

Connector HDMI

®

Rohde & Schwarz R&S

FSW Signal and Spectrum Analyzer 19

Version 05.01, December 2012

–

General data

Display 30.7 cm (12.1”) WXGA color touchscreen

Resolution 1280 × 800 pixel (WXGA resolution)
Pixel failure rate < 1 × 10

Data storage

Internal standard solid state disk  8 Gbyte
External supports USB 2.0 compatible memory

devices

Temperature

Temperature operating temperature range +5 °C to +50 °C

permissible temperature range 0 °C to +55 °C
storage temperature range –40 °C to +70 °C

Climatic loading +40 °C at 90 % rel. humidity,

in line with EN 60068-2-30,

without condensation

Mechanical resistance

Vibration sinusoidal 5 Hz to 55 Hz

displacement: 0.15 mm constant

amplitude (1.8 g at 55 Hz);

55 Hz to 150 Hz

acceleration: 0.5 g constant

in line with EN 60068-2-6
random 10 Hz to 300 Hz, acceleration 1.2 g

(RMS), in line with EN 60068-2-64

Shock 40 g shock spectrum,

in line with MIL-STD-810E method

no. 516.4, procedure I,

MIL-PRF-28800F, class 3

5

EMC in line with EMC Directive 2004/108/EC

including:

IEC/EN 61326-1

IEC/EN 61326-2-1

CISPR 11/EN 55011

16, 17

16

IEC/EN 61000-3-2

IEC/EN 61000-3-3

Recommended calibration interval 1 year

Power supply

AC input voltage range 100 V to 240 V
AC supply frequency 50 Hz to 60 Hz / 400 Hz,
Max. input current 7.3 A (100 V) to 4.6 A (240 V)
Power consumption R&S®FSW8 150 W without options,

250 W with all options (meas.)
R&S®FSW13, R&S®FSW26 175 W without options,

275 W with all options (meas.)
R&S®FSW43 200 W without options,

300 W with all options (meas.)

Safety in line with IEC 61010-1, EN 61010-1,

UL 61010-1,

CAN/CSA-C22.2 No. 61010-1-04

Test mark VDE-GS, CCSAUS

16

Emission limits for class B equipment.

17

Immunity test requirement for industrial environment (EN 61326 table 2).

®

20 Rohde & Schwarz R&S

FSW Signal and Spectrum Analyzer

Version 05.01, December 2012

Dimensions and weight

Dimensions (nom.) W × H × D, including front handles and

rear feet

462 mm × 240 mm × 504 mm

(18.15 in × 9.44 in × 19.81 in)

Net weight without options (nom.) R&S®FSW8 18.6 kg (41.01 lb)

R&S®FSW13 20.2 kg (44.53 lb)
R&S®FSW26 20.2 kg (44.53 lb)
R&S®FSW43 20.9 kg (46.07 lb)

Rohde & Schwarz R&S

®

FSW Signal and Spectrum Analyzer 21

Version 05.01, December 2012

Options

R&S®FSW-B13 highpass filters

Frequency

Frequency range filter 1 1 GHz to 1.75 GHz

filter 2 1.75 GHz to 3 GHz

Stopband attenuation
500 MHz to 875 MHz filter 1 > 20 dB (nom.)
875 MHz to 1.5 GHz filter 2 > 20 dB (nom.)

Other specifications
Level measurement uncertainty see base unit specification
Displayed average noise level
Intermodulation
Measurement uncertainty

R&S®FSW-B17 digital baseband interface

I/Q data IN

Interface LVDS

connector 26-pin female MDR (Mini D Ribbon)

Transfer protocol Rohde & Schwarz digital I/Q Interface 18
User data sample rate 100 sample/s to 100 Msample/s (nom.)

resolution 18 bit for I and 18 bit for Q
general purpose signals 2 bit

I/Q data OUT

Interface LVDS

connector 26-pin female MDR (Mini D Ribbon)

Transfer protocol Rohde & Schwarz digital I/Q Interface 18
User data sample rate 100 sample/s to 100 Msample/s (nom.)

resolution 20 bit for I and 20 bit for Q

Max. I/Q bandwidth standard 10 MHz

with R&S®FSW-B28 option 28 MHz
with R&S®FSW-B40 option 40 MHz
with R&S®FSW-B80 option 80 MHz
with R&S®FSW-B160 option 80 MHz

R&S®FSW-B21 LO/IF connections for external mixers
(for R&S

LO signal

Frequency range 7.65 GHz to 17.45 GHz
Level +20 °C to +30 °C +15.5 dBm ± 1 dB

IF input

IF frequency set signal analysis bandwidth

Full-scale level compression < 1 dB

®

FSW43 only)

+5 °C to +40 °C +15.5 dBm ± 3 dB

 80 MHz, bandwidth dependent 1310 MHz to 1330 MHz
> 80 MHz 1530 MHz

2-port mixer
(LO output/IF input, front panel)
3-port mixer (IF input, front panel) –20 dBm (nom.)

–20 dBm (nom.)

18

Rohde & Schwarz Digital IQ Interface is a Rohde & Schwarz company standard for the transmission of digital I/Q data.

It is supported by a wide range of instruments (signal generators, signal analyzers and communications testers and the R&S

®

22 Rohde & Schwarz R&S

FSW Signal and Spectrum Analyzer

®

EX-IQ-BOX)

Version 05.01, December 2012

Level uncertainty IF input level = reference level = –25 dBm, RBW = 30 kHz, mixer conversion loss set to

0 dB, 2-port mixer, LO output/IF input connector (front panel)
+20 °C to +30 °C < 1 dB
+5 °C to +40 °C < 3 dB
IF input level = reference level = –25 dBm, RBW = 30 kHz, mixer conversion loss set to
0 dB, 3-port mixer, IF input connector (front panel)
+20 °C to +30 °C < 1 dB
+5 °C to +40 °C < 3 dB

Inputs and outputs

LO output/IF input SMA female, 50 
IF input SMA female, 50 

R&S®FSW-B24 RF preamplifier

Frequency

Frequency range R&S®FSW8 100 kHz to 8 GHz

R&S®FSW13 100 kHz to 13.6 GHz
R&S®FSW26 100 kHz to 26.5 GHz
R&S®FSW43 100 kHz to 43.5 GHz

Setting range
RF preamplifier gain R&S®FSW8, R&S®FSW13 15 dB/30 dB (nom.) (selectable)

R&S®FSW26. R&S®FSW43 30 dB (nom.)

Other specifications
Level measurement uncertainty see base unit specification
Displayed average noise level
Intermodulation
Measurement uncertainty

R&S®FSW-B25 electronic attenuator

Frequency

Frequency range R&S®FSW8 10 MHz to 8 GHz

R&S®FSW13, R&S®FSW26 10 MHz to 13.6 GHz

19

Setting range 0 dB to 30 dB, in 1 dB steps

Level measurement uncertainty see base unit specification

Displayed average noise level electronic attenuator on the specification of the base unit degrades

by 3 dB + 0.25 dB × f / 1 GHz (nom.)

Intermodulation

Third-order intercept point (TOI) electronic attenuator off or

see base unit specification
electronic attenuator on and
RF attenuation = 0 dB
electronic attenuator on, RF attenuation = 30 dB

10 MHz to 500 MHz 30 dBm (nom.)
500 MHz to 13.6 GHz 40 dBm (nom.)

19

Electronic RF attenuator: 5 dB steps. Electronic IF attenuator: 1 dB steps.

Rohde & Schwarz R&S

®

FSW Signal and Spectrum Analyzer 23

Version 05.01, December 2012

R&S®FSW-B71 analog baseband inputs,

®

R&S

Frequency

Frequency range (equalized) R&S®FSW-B71

Spectral purity

Phase noise offset 1 kHz –134 dBc (1 Hz) (nom.)

Inputs

Connectors
Maximum safe input voltage any input, sum of DC + AC ±4 V
Input voltage range (full scale) peak voltage ±2 V, ±1 V, ±0.5 V, ±0.25 V
Max. common mode input range -3 V to +3 V
Input impedance single ended 50  (nom.)

Input return loss 0 Hz to 40 MHz –35 dB (nom.)

Amplitude

Absolute amplitude accuracy f

Amplitude linearity 0 dB to –80 dB relative to full scale ±0.1 dB (nom.)
Frequency response

Channel match (I/Q imbalance)

FSW-B71E 80 MHz analysis bandwidth for analog baseband inputs

I only, Q only DC to 40 MHz
I + jQ –40 MHz to +40 MHz
R&S®FSW-B71E
I only, Q only DC to 80 MHz
I + jQ –80 MHz to +80 MHz

offset 10 kHz –138 dBc (1 Hz) (nom.)
offset 100 kHz –144 dBc (1 Hz) (nom.)

_ _

I, I, Q, Q

differential 100  (nom.)
common mode at DC 20 k (nom.)

40 MHz to 80 MHz

®

FSW-B71E only)

(R&S

= 1 MHz,

input

input voltage = full scale –6dB

Amplitude relative to 1 MHz

0 Hz to 40 MHz ±0.15 dB
40 MHz to 80 MHz

®

FSW-B71E only)

(R&S

Deviation from linear phase 0 Hz to 40 MHz ±1 degree (nom.)

40 MHz to 80 MHz

®

(R&S

FSW-B71E only)

Amplitude match accuracy 0 Hz to 20 MHz ±0.06 dB (2)

20 MHz to 40 MHz ±0.1 dB (2)
40 MHz to 80 MHz

®

(R&S

FSW-B71E only)

Phase match accuracy 0 Hz to 20 MHz ±0.3 degree (nom.)

20 MHz to 40 MHz ±0.6 degree (nom.)
40 MHz to 80 MHz

®

FSW-B71E only)

(R&S

–30 dB (nom.)

±0.15 dB

±0.25 dB

±2 degree (nom.)

±0.15 dB (2)

±1 degree (nom.)

24 Rohde & Schwarz R&S

®

FSW Signal and Spectrum Analyzer

Version 05.01, December 2012

Dynamic Range

Crosstalk –80 dB (nom.)
Signal to noise ratio any input range, relative to full scale 145 dBc (1 Hz) (nom.)
Displayed average noise level (rms) 2 MHz to 80 MHz

range

±2 V peak –130 dBm (1 Hz) (72 nV ( 1 Hz)) nom.
±1 V peak –136 dBm (1 Hz) (36 nV ( 1 Hz)) nom.
±0.5 V peak –142 dBm (1 Hz) (18 nV ( 1 Hz)) nom.
±0.25 V peak –148 dBm (1 Hz) (9 nV ( 1 Hz)) nom.

Residual DC (I/Q offset) relative to full scale –54 dB (nom.)
Residual response range ±0.25 V peak –90 dBm (nom.)
Spurious response with full scale input signal

0 Hz to 40 MHz –75 dBc (nom.)
40 MHz to 80 MHz

®

FSW-B71E only)

(R&S

–70 dBc (nom.)

Third order intermodulation distortion two CW signals, voltage = full scale –6 dB (each signal)

0 Hz to 40 MHz –80 dBc (nom.)
40 MHz to 80 MHz (R&S®FSW-B71E only)

differential –80 dBc (nom.)
single ended –74 dBc (nom.)

Probes

Probes supported on connectors I and Q active single ended probes R&S®RT-ZS10E

R&S®RT-ZS10

R&S®RT-ZS20

R&S®RT-ZS30

R&S®RT-ZS60
active differential probes R&S®RT-ZD20

R&S®RT-ZD30

R&S®RT-ZD40

RF measurements using probes

Supported connector "Input source RF" set to

I
"Baseband input I"

Maximum input frequency 5 GHz 20
Frequency response see probe specification for frequency

response of probe

add the probe frequency response to the

®

FSW frequency response specified

R&S

in section "Total measurement

uncertainty"

20

Maximum frequency supported by the connector. To identify the maximum achievable input frequency when using a probe, the probe specification

must be taken into account.

®

Rohde & Schwarz R&S

FSW Signal and Spectrum Analyzer 25

Version 05.01, December 2012

Ordering information

Designation Type Order No.

Signal and Spectrum Analyzer, 2 Hz to 8 GHz R&S®FSW8 1312.8000.08
Signal and Spectrum Analyzer, 2 Hz to 13.6 GHz R&S®FSW13 1312.8000.13
Signal and Spectrum Analyzer, 2 Hz to 26.5 GHz R&S®FSW26 1312.8000.26
Signal and Spectrum Analyzer, 2 Hz to 43.5 GHz R&S®FSW43 1312.8000.43

Accessories supplied

Power cable, Quick Start Guide and CD-ROM (with operating manual and service manual)

®

R&S

FSW26: adapter 3.5 mm (APC3.5-compatible) female/female

®

FSW43: adapter 2.92 mm female/female

R&S

Options

Designation Type Order No. Retrofittable Remarks

OCXO Precision Frequency Reference R&S®FSW-B4 1313.0703.02 yes user-retrofittable
Resolution Bandwidth > 10 MHz R&S®FSW-B8 1313.2464.26 no for the R&S®FSW8,

Resolution Bandwidth > 10 MHz R&S®FSW-B8 1313.2464.02 no with span = 0 Hz.

Highpass Filter for Harmonic Measurements R&S®FSW-B13 1313.0761.02 yes user-retrofittable
Digital Baseband Interface R&S®FSW-B17 1313.0784.02 yes user-retrofittable
Spare Solid State Drive (removable hard drive) R&S®FSW-B18 1313.0790.02 yes user-retrofittable
LO/IF connections for external mixers R&S®FSW-B21 1313.1100.43 yes for the R&S®FSW43.

RF Preamplifier, 100 kHz to 13.6 GHz R&S®FSW-B24 1313.0832.13 yes for the R&S®FSW8/13.

RF Preamplifier, 100 kHz to 26.5 GHz R&S®FSW-B24 1313.0832.26 yes for the R&S®FSW26.

RF Preamplifier, 100 kHz to 43.5 GHz R&S®FSW-B24 1313.0832.43 yes for the R&S®FSW43.

Electronic Attenuator, 1 dB steps R&S®FSW-B25 1313.0990.02 yes for the R&S®FSW8/13/26.

USB Mass Memory Write Protection R&S®FSW-B33 1313.3602.02 no pre-installation ex factory
28 MHz Analysis Bandwidth R&S®FSW-B28 1313.1645.02 yes user-retrofittable
40 MHz Analysis Bandwidth R&S®FSW-B40 1313.0861.02 yes user-retrofittable
80 MHz Analysis Bandwidth R&S®FSW-B80 1313.0878.02 yes user-retrofittable
160 MHz Analysis Bandwidth R&S®FSW-B160 1313.1668.02 yes contact service center
Analog Baseband Inputs,

R&S®FSW-B71 1313.1651.13 yes for the R&S®FSW8 and

40 MHz Analysis Bandwidth

Analog Baseband Inputs,

R&S®FSW-B71 1313.1651.26 yes for the R&S®FSW26/43.
40 MHz Analysis Bandwidth
80 MHz Analysis Bandwidth for

R&S®FSW-B71E 1313.6547.02 yes R&S®FSW-B71 required.
Analog Baseband Inputs

®

R&S

FSW13, and

®

FSW26,

R&S
with span = 0 Hz.
The signal analysis
bandwidth is defined by the

®

FSW-B28/-B40/-B80

R&S
and -B160 options, not by

®

the R&S

FSW-B8 option

The signal analysis
bandwidth is defined by the

®

FSW-B28/-B40 and

R&S

-B80 options, not by the

®

FSW-B8 option

R&S

Contact service center

Contact service center

Contact service center

Contact service center

Contact service center

®

FSW13.

R&S
Contact service center

Contact service center

User-retrofittable

26 Rohde & Schwarz R&S

®

FSW Signal and Spectrum Analyzer

Version 05.01, December 2012

Firmware

Pulse Measurements R&S®FSW-K6 1313.1322.02
Analog Modulation Analysis for AM/FM/M R&S®FSW-K7 1313.1339.02
GSM/EDGE/EDGE Evolution/VAMOS

R&S®FSW-K10 1313.1368.02
Measurements
Multicarrier Group Delay Measurements R&S®FSW-K17 1313.4150.02
Noise Figure Measurements R&S®FSW-K30 1313.1380.02
Phase Noise Measurements R&S®FSW-K40 1313.1397.02
Vector Signal Analysis R&S®FSW-K70 1313.1416.02
3GPP FDD (WCDMA) BS Measurements

R&S®FSW-K72 1313.1422.02
(incl. HSDPA and HSDPA+)
3GPP FDD (WCDMA) MS Measurements

R&S®FSW-K73 1313.1439.02
(incl. HSUPA and HSUPA+)
TD-SCDMA BS Measurements R&S®FSW-K76 1313.1445.02
TD-SCDMA UE Measurements R&S®FSW-K77 1313.1451.02
CDMA2000® BS Measurements R&S®FSW-K82 1313.1468.02
CDMA2000® MS Measurements R&S®FSW-K83 1313.1474.02
1xEV-DO BS Measurements R&S®FSW-K84 1313.1480.02
1xEV-DO MS Measurements R&S®FSW-K85 1313.1497.02

802.11a/b/g Measurements R&S®FSW-K91 1313.1500.02 To support signal analysis

bandwidths > 10 MHz,
one of the options

®

FSW-B28/-B40/

R&S

-B80/-B160 is needed.

802.11n Measurements R&S®FSW-K91N 1313.1516.02 Requires R&S®FSW-K91.

802.11ac Measurements R&S®FSW-K91AC 1313.4209.02

To support signal analysis
bandwidths > 10 MHz,
one of the options

®

FSW-B28/-B40/

R&S

-B80/-B160 is needed.
EUTRA/LTE FDD Downlink Measurements R&S®FSW-K100 1313.1545.02 To support signal analysis
EUTRA/LTE TDD Downlink Measurements R&S®FSW-K104 1313.1574.02

bandwidths > 10 MHz,
one of the options

®

FSW-B28/-B40/

R&S

-B80/-B160 is needed.
PC software
OFDM Vector Signal Analysis Software R&S®FSQ-K96 1310.0202.02 spectrum analyzer

required
OFDM Vector Signal Analysis Software R&S®FSQ-K96PC 1310.0219.02 usable with or without
EUTRA/LTE FDD Downlink PC Software R&S®FS-K100PC 1309.9916.02

spectrum analyzer
EUTRA/LTE Uplink FDD PC Software R&S®FS-K101PC 1309.9922.02
EUTRA/LTE Downlink MIMO PC Software

R&S®FS-K102PC 1309.9939.02
(incl. LTE-Advanced)
EUTRA/LTE Uplink MIMO PC Software

R&S®FS-K103PC 1309.9945.02
(incl. LTE-Advanced)
EUTRA/LTE TDD Downlink PC Software R&S®FS-K104PC 1309.9951.02
EUTRA/LTE TDD Uplink PC Software R&S®FS-K105PC 1309.9968.02
Distortion Analysis PC Software R&S®FS-K130PC 1310.0090.02

Rohde & Schwarz R&S

®

FSW Signal and Spectrum Analyzer 27

Version 05.01, December 2012

Upgrades

Designation Type Order No. Retrofittable Remarks

Analysis Bandwidth Upgrade from 28 MHz to
40 MHz
Analysis Bandwidth Upgrade from 40 MHz to
80 MHz

Analysis Bandwidth Upgrade from 80 MHz to
160 MHz

R&S®FSW-U40 1313.5205.02 yes user-retrofittable,

R&S®FSW-U80 1313.5211.02 yes user-retrofittable,

R&S®FSW-U160 1313.5754.02 yes contact service center,

®

FSW-B28 required

R&S

®

R&S

FSW-B40 or

®

FSW-U40 required

R&S

®

FSW-B80 or

R&S

®

R&S

FSW-U80 required

Service options

Service options

Extended Warranty, one year R&S®WE1FSW Please contact your local
Extended Warranty, two years R&S®WE2FSW
Extended Warranty, three years R&S®WE3FSW
Extended Warranty, four years R&S®WE4FSW
Extended Warranty with Calibration Coverage, one year R&S®CW1FSW
Extended Warranty with Calibration Coverage, two years R&S®CW2FSW
Extended Warranty with Calibration Coverage, three years R&S®CW3FSW
Extended Warranty with Calibration Coverage, four years R&S®CW4FSW

Extended warranty with a term of one to four years (WE1 to WE4)

Repairs carried out during the contract term are free of charge

21

. Necessary calibration and adjustments carried out during repairs are
also covered. Simply contact the forwarding agent we name; your product will be picked up free of charge and returned to you in top
condition a couple of days later.

Rohde & Schwarz sales
office.

Extended warranty with calibration (CW1 to CW4)

Enhance your extended warranty by adding calibration coverage at a package price. This package ensures that your
Rohde & Schwarz product is regularly calibrated, inspected and maintained during the term of the contract. It includes all repairs
calibration at the recommended intervals as well as any calibration carried out during repairs or option upgrades.

21

and

21

Excluding defects caused by incorrect operation or handling and force majeure. Wear-and-tear parts are not included.

®

28 Rohde & Schwarz R&S

FSW Signal and Spectrum Analyzer

Version 05.01, December 2012

®

Recommended extras

Designation Type Order No.

Headphones 0708.9010.00
IEC/IEEE Bus Cable, 1 m R&S®PCK 0292.2013.10
IEC/IEEE Bus Cable, 2 m R&S®PCK 0292.2013.20
19" Rack Adapter R&S®ZZA-KN5 1175.3040.00

Matching Pads, 50/75 Ω

L section, matching at both ends R&S®RAM 0358.5414.02
Series resistor, 25 , matching at one end
(taken into account in instrument function RF INPUT 75 )

High-Power Attenuators

100 W, 3/6/10/20/30 dB, 1 GHz R&S®RBU100 1073.8495.xx

50 W, 3/6/10/20/30 dB, 2 GHz R&S®RBU50 1073.8695.xx

50 W, 20 dB, 6 GHz R&S®RDL50 1035.1700.52

Connectors and cables

Probe power connector, 3-pin 1065.9480.00
N-Type Adapter for R&S®RT-Zxx oscilloscope probes R&S®RT-ZA9 1417.0909.02
Cable for connecting digital baseband interfaces of
Rohde & Schwarz instruments (accessory for R&S

®

FSW-B17)

DC blocks

DC Block, 10 kHz to 18 GHz (N type) R&S®FSE-Z4 1084.7443.02

External harmonic mixers (for R&S®FSW43 with R&S®FSW-B21 option)

Harmonic Mixer 40 GHz to 60 GHz R&S®FS-Z60 1089.0799.02
Harmonic Mixer 50 GHz to 75 GHz R&S®FS-Z75 1089.0847.02
Harmonic Mixer 60 GHz to 90 GHz R&S®FS-Z90 1089.0899.02
Harmonic Mixer 75 GHz to 110 GHz R&S®FS-Z110 1089.0947.05

R&S®RAZ 0358.5714.02

(xx = 03/06/10/20/30)

(xx = 03/06/10/20/30)

R&S

SMU-Z6 1415.0201.02

®

Rohde & Schwarz R&S

FSW Signal and Spectrum Analyzer 29

Version 05.01, December 2012

Power sensors supported 22

Designation Type Order No.

Universal Power Sensor, 10 MHz to 8 GHz, 100 mW,

R&S®NRP-Z211 1417.0409.02
2-path
Universal Power Sensor, 10 MHz to 8 GHz, 200 mW R&S®NRP-Z11 1138.3004.02
Universal Power Sensor, 10 MHz to 18 GHz, 100 mW,

R&S®NRP-Z221 1417.0309.02
2-path
Universal Power Sensor, 10 MHz to 18 GHz, 200 mW R&S®NRP-Z21 1137.6000.02
Universal Power Sensor, 10 MHz to 18 GHz, 2 W R&S®NRP-Z22 1137.7506.02
Universal Power Sensor, 10 MHz to 18 GHz, 15 W R&S®NRP-Z23 1137.8002.02
Universal Power Sensor, 10 MHz to 18 GHz, 30 W R&S®NRP-Z24 1137.8502.02
Power Sensor Module with Power Splitter,

R&S®NRP-Z27 1169.4102.02
DC to 18 GHz, 500 mW
Power Sensor Module with Power Splitter,

R&S®NRP-Z37 1169.3206.02
DC to 26.5 GHz, 500 mW
Thermal Power Sensor, 0 Hz to 18 GHz, 100 mW R&S®NRP-Z51 1138.0005.02
Thermal Power Sensor, 0 Hz to 40 GHz, 100 mW R&S®NRP-Z55 1138.2008.02
Thermal Power Sensor, 0 Hz to 50 GHz, 100 mW R&S®NRP-Z56 1171.8201.02
Thermal Power Sensor, 0 Hz to 67 GHz, 100 mW R&S®NRP-Z57 1171.8401.02
Wideband Power Sensor, 50 MHz to 18 GHz, 100 mW R&S®NRP-Z81 1137.9009.02
Average Power Sensor, 9 kHz to 6 GHz, 200 mW R&S®NRP-Z91 1168.8004.02
Average Power Sensor, 9 kHz to 6 GHz, 2 W R&S®NRP-Z92 1171.7005.02

Probes supported by option R&S®FSW-B71/-B71E

Designation Type Order No.

1.0 GHz, active, 1 M, 0.8 pF R&S®RT-ZS10E 1418.7007.02

1.0 GHz, active, 1 M, 0.8 pF, micro button R&S®RT-ZS10 1410.4080.02

1.5 GHz, active, 1 M, 0.8 pF, micro button R&S®RT-ZS20 1410.3502.02

3.0 GHz, active, 1 M, 0.8 pF, micro button R&S®RT-ZS30 1410.4309.02

6.0 GHz, active, 1 M, 0.3 pF, micro button R&S®RT-ZS60 1418.7307.02

1.5 GHz, active, differential, 1 M, 0.6 pF, micro button R&S®RT-ZD20 1410.4409.02

3.0 GHz, active, differential, 1 M, 0.6 pF, micro button R&S®RT-ZD30 1410.4609.02

4.5 GHz, active, differential, 1 M, 0.4 pF, micro button R&S®RT-ZD40 1410.5205.02

The Bluetooth
Rohde & Schwarz is under license.

CDMA2000

“WiMAX Forum” is a registered trademark of the WiMAX Forum. “WiMAX”, the WiMAX Forum logo, “WiMAX Forum Certified”, and the
WiMAX Forum Certified logo are trademarks of the WiMAX Forum.

®

word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by

®

is a registered trademark of the Telecommunications Industry Association (TIA-USA).

For product brochure, see PD 5214.5984.12 and www.rohde-schwarz.com

22

For average power measurement only.

®

30 Rohde & Schwarz R&S

FSW Signal and Spectrum Analyzer

Version 05.01, December 2012

Rohde & Schwarz R&S

®

FSW Signal and Spectrum Analyzer 31

Service you can rely on

52145

❙ Worldwide
❙ Local and personalized
❙ Customized and flexible
❙ Uncompromising quality
❙ Long-term dependability

About Rohde & Schwarz

Rohde & Schwarz is an independent group of companies
specializing in electronics. It is a leading supplier of solu­tions in the fields of test and measurement, broadcasting,
radiomonitoring and radiolocation, as well as secure
communications. Established more than 75 years ago,
Rohde & Schwarz has a global presence and a dedicated
service network in over 70 countries. Company headquar­ters are in Munich, Germany.

Environmental commitment

❙ Energy-efcient products
❙ Continuous improvement in environmental sustainability
❙ ISO 14001-certied environmental management system

Cert ied Quali ty Syste m

ISO 9001

Rohde & Schwarz GmbH & Co. KG

www.rohde-schwarz.com

Regional contact

❙ Europe, Africa, Middle East | [phone]

[e-mail]

❙ North America | 1 888 TEST RSA (1 888 837 87 72)

[e-mail]

❙ Latin America | [phone]

[e-mail]

❙ Asia/Pacic | [phone]

[e-mail]

❙ China | [phone]/[phone]

[e-mail]

R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG
Trade names are trademarks of the owners | Printed in Germany (as)
PD 5214.5984.22 | Version 05.01 | December 2012 | R&S®FSW
Subject to change
© 2011 - 2012 Rohde & Schwarz GmbH & Co. KG | 81671 München, Germany

98422
