Atec FOS-120A-FLS-130A User Manual

Single- or dual-wavelength configuration

2-kHz signal generation for fiber identification

Dual powering: 9 V battery and AC adapter/charger

Auto-off function

Light Source/Laser Source

FOS-120A/FLS-130A

The FOS-120A Light Source and FLS-130A Laser Source deliver
excellent stability. They are compatible with the FOT-10A and
FOT-20A Power Meters, which are suitable for a variety of

testing applications including continuity and end-to-end testing.

Versatility

The FOS-120A Light Source and FLS-130A Laser Source feature
single- and dual-wavelength sources from single or double ports.
The units deliver continuous wave (CW) signals for power/loss
measurements and 2-kHz signal generation for fiber identification.
Certain FOS-120A models and all FLS-130A models are equipped with
EXFO's Universal Interface.

Unit Powering

Powering options include a 9 V battery and a standard AC adapter.
The battery life offers a minimum of seven hours of continuous operation.
An auto-off function with a 10-minute timer is included to preserve
battery life.

Accessories

Each unit comes complete with a rigid carrying case, a shockproof PVC
holster with strap, as well as SC, ST and FC connectors.

Delivering Optical Source Stability

Key Features

" Single- or dual-wavelength configuration
" 2-kHz signal generation for fiber identification
" Dual powering: 9 V battery and AC adapter/charger
" Auto-off function
" Rigid carrying case and shockproof holster with strap
" Equipped with EXFO’s Universal Interface, except for certain FOS-120A models

FOS-120A/FLS-130A

Specifications

Specifications—FOS-120A Light Source (LED)
Models FOS-121A FOS-122A FOS-123A FOS-124A FOS-125A

Wavelength

1

(nm) 850 ± 30 1310 ± 40 1550 ± 30 850 ± 30 1310 ± 30

1310 ± 40 1550 ± 30

Spectral width

2, 3

(nm) 50 145 70 50/145 70/70

Launch power

3

(dBm)
9/125 µm N/A N/A -25 N/A -20/-25
50/125 µm -17 -20 -25 -17/-20 -20/-25

62.5/125 µm -14 -16 -25 -14/-16 -20/-25

Power stability

4

(dB)
1 h ± 0.03 ± 0.06 ± 0.08 ± 0.03/± 0.06 ± 0.06/± 0.08
8 h ± 0.05 ± 0.10 ± 0.12 ± 0.05/± 0.10 ± 0.10/± 0.12

Output ports 1 1 1 2 2

Specifications—FLS-130A Laser Source (Laser)
Models FLS-132A FLS-133A FLS-135A FLS-136A

Wavelength

1

(nm) 1310 ± 20 1550 ± 20 1310 ± 20 1310 ± 20

1550 ± 20 1550 ± 20
Spectral width5(nm) ≤ 5 ≤ 5 ≤ 5/5 ≤ 5/5
Launch power

3

(dBm)
9/125 µm -7 -7 -7/-7 -8/-8
50/125 µm -7 -7 -7/-7 -8/-8

62.5/125 µm -7 -7 -7/-7 -8/-8

Power stability

4

(dB)
1 h ± 0.06 ± 0.08 ± 0.06/± 0.08 ± 0.06/± 0.08
8 h ± 0.10 ± 0.12 ± 0.10/± 0.12 ± 0.10/± 0.12

Output ports 1 1 2 1

General Specifications—FOS-120A and FLS-130A

Size (H × W × D) 22.2 cm × 10.3 cm × 5.9 cm (8 3/4 in × 4 1/16 in × 2 1/4 in)
Weight

unit 0.6 kg (1.4 lb)
shipping 1.8 kg (4 lb)

Temperature

operating -10 °C to 50 °C (14 °F to 122 °F)

Standard Accessories

User Guide, carrying case, 9 V battery, AC adapter, protective holster, shoulder strap and Certificate of Compliance.

Laser Safety

21 CFR 1040.10 and IEC-60825-1 CLASS 1 LASER PRODUCT

CLASS 1 LED PRODUCT

Notes

1. At 23 ˚C.

2. FWHM = Full width at half maximum.

3. Typical.

4. For a temperature stability of ± 1 ˚C.

5. rms = root mean square.

Find out more about EXFO’s extensive line of high-performance portable instruments by visiting our Web site at www.exfo.com

Rugged Handheld Solutions

• OLTS

• Power Meter

• Light Source

• Talk Set

• OSA

• PMD

• Chromatic Dispersion Analyzer

• Multiwavelength Meter

DWDM Test Systems

Optical FiberUNIVERSAL TEST SYSTEM

• OTDR

• OLTS

• ORL

• Switch

Protocol

• 10/100 and Gigabit Ethernet

• SONET/SDH (DS0 to OC-192c)

• SDH/PDH (64Kb/s to STM-64c)

Ordering Information

SPFOS120AFLS130A.1AN © 2003 EXFO Electro-Optical Engineering Inc. All rights reserved. Printed in Canada 03/04

EXFO has made every effort to ensure that the information contained in this specification sheet is accurate. However, we accept no
responsibility for any errors or omissions, and we reserve the right to modify design, characteristics and products at any time without obligation.

Units of measurement in this document conform to SI standards and practices.

Contact EXFO for prices and availability or to obtain the phone number of your local EXFO distributor.

For the most recent version of this spec sheet, please go to the EXFO website at http://www.exfo.com/support/techdocs.asp
In case of discrepancy, the Web version takes precedence over any printed literature.
All names, trademarks, products and services mentioned are registered or unregistered trademarks of their respective owners.

CORPORATE HEADQUARTERS 465 Godin Avenue Vanier (Quebec) G1M 3G7 CANADA Tel.: [phone] ·Fax: [phone]
EXFO AMERICA 1201 Richardson Drive, Suite 260 Richardson TX 75080 USA Tel.: [phone] ·Fax: [phone]
EXFO EUROPE Le Dynasteur, 10/12 rue Andras Beck 92366 Meudon la Forêt Cedex FRANCE Tel.: [phone] ·Fax: [phone]
EXFO ASIA-PACIFIC 151 Chin Swee Road, #03-29 Manhattan House SINGAPORE 169876 Tel.: [phone]·Fax: [phone]
EXFO CHINA Beijing New Century Hotel Office Tower, Room 1754-1755 Beijing 100044 P. R. China Tel.: [phone] · Fax: [phone]

No. 6 Southern Capital Gym Road

TOLL-FREE (USA and Canada) Tel.: [phone] www.exfo.com

• [e-mail]

FOS-12XA-XX

Light Source

Model

FOS-121A = 850 nm
FOS-122A = 1300 nm
FOS-123A = 1550 nm
FOS-124A = 850/1300 nm (2 ports)
FOS-125A = 1310/1550 nm (2 ports)

Connector

50 = FC/PC
54 = SC/PC
74 = ST/PC

EI-EUI-28 = UPC/DIN 47256*
EI-EUI-76 = UPC/HMS-10/AG*
EI-EUI-89 = UPC/FC narrow key*
EI-EUI-90 = UPC/ST*
EI-EUI-91 = UPC/SC*
EI-EUI-95 = UPC/E-2000*

* for models FOS-123A and FOS-125A only

Example: FOS-123A-EI-EUI-89

FLS-13XA-XX

Laser Source

Model

FLS-132A = 1310 nm
FLS-133A = 1550 nm
FLS-135A = 1310/1550 nm (2 ports)
FLS-136A = 1310/1550 nm (1 port)

Connector

50 = FC/PC
54 = SC/PC
74 = ST/PC

EI-EUI-28 = UPC/DIN 47256
EI-EUI-76 = UPC/HMS-10/AG
EI-EUI-89 = UPC/FC narrow key
EI-EUI-90 = UPC/ST
EI-EUI-91 = UPC/SC
EI-EUI-95 = UPC/E-2000

Example: FLS-135A-EI-EUI-89
