E5061B Network Analyzer

• 100 kHz to 1.5/3 GHz

• 5 Hz to 3 GHz

Data Sheet

Defi nitions

All specifications apply over a 23 °C ±5 °C range (unless otherwise stated) and
90 minutes after the instrument has been turned on.

Specifi cation (spec.):

Warranted performance. Specifications include guardbands to account for the
expected statistical performance distribution, measurement uncertainties, and
changes in performance due to environmental conditions.

Supplemental information is intended to provide information that is helpful for
using the instrument but that is not guaranteed by the product warranty.

Typical (typ.):

Describes performance that will be met by a minimum of 80% of all products. It
is not guaranteed by the product warranty.

Supplemental performance data (SPD):

Represents the value of a parameter that is most likely to occur; the expected
mean or average. It is not guaranteed by the product warranty.

General characteristics:

A general, descriptive term that does not imply a level of performance.

E5061B Test Set Options

50 Ω RF NA options

E5061B-115 Transmission/Refl ection test set, 100 kHz to 1.5 GHz, 50 Ω system

impedance

E5061B-215 S-parameter test set, 100 kHz to 1.5 GHz, 50 Ω system impedance

E5061B-135 Transmission/Refl ection test set, 100 kHz to 3 GHz, 50Ω system

impedance

E5061B-235 S-parameter test set, 100 kHz to 3 GHz, 50 Ω system impedance

75 Ω RF NA options

E5061B-117 Transmission/Refl ection test set, 100 kHz to 1.5 GHz, 75 Ω system

impedance

E5061B-217 S-parameter test set, 100 kHz to 1.5 GHz, 75 Ω system impedance

E5061B-137 Transmission/Refl ection test set, 100 kHz to 3 GHz, 75 Ω system

impedance

E5061B-237 S-parameter test set, 100 kHz to 3 GHz, 75 Ω system impedance

LF-RF NA option

E5061B-3L5 LF-RF network analyzer with DC bias source, 5 Hz to 3 GHz

2

S-Parameter Measurement

Corrected system performance

The specifications in this section apply for measurements made with the Agilent
E5061B network analyzer with the following conditions:

• No averaging applied to data

• Environmental temperature of 23 °C ±5 °C, with less than 1 °C deviation from
the calibration temperature

• Response and isolation calibration not omitted

Table 1. System dynamic range

1,2

Description Specification SPD

System dynamic range

(Option 3L5)

100 kHz to 1 MHz, 3 kHz IF bandwidth 90 dB

1 MHz to 3 GHz, 3 kHz IF bandwidth 95 dB

5 to 100 Hz, 2Hz IF bandwidth 90 dB

100 Hz to 9 kHz,10 Hz IF bandwidth 100 dB

9 to 100 kHz, 10 Hz IF bandwidth 110 dB

100 kHz to 1 MHz, 10 Hz IF bandwidth 115 dB

1 MHz to 3 GHz, 10 Hz IF bandwidth 120 dB 130 dB

(Option 115, 135, 215, 235, 117, 137, 217, 237)

100 to 300 kHz, 3 kHz IF bandwidth 75 dB

300 kHz to 1 MHz, 3 kHz IF bandwidth 90 dB

1 MHz to 3 GHz, 3 kHz IF bandwidth 95 dB

100 to 300 kHz, 10 Hz IF bandwidth 100 dB

300 kHz to 1 MHz, 10 Hz IF bandwidth 115 dB

1 MHz to 3 GHz, 10 Hz IF bandwidth 120 dB 130 dB

1. The test port dynamic range is calculated as the difference between the test port rms noise fl oor

and the source maximum output power. The effective dynamic range must take measurement
uncertainty and interfering signals into account.

2. The specifi cation might not be met at the frequencies 1.4 MHz, 4.0 MHz, 4.333 MHz, 6.333

MHz, 25MHz and 90 MHz.

3

Table 2. Corrected system performance with Type-N 50 Ω connectors,

0.01

0.1

1

10

-90-80-70-60-50-40-30-20-10010

100 Hz to 100 kHz
100 kHz to 1 GHz
1 GHz to 3 GHz

S11 = S22 = 0 ; Source power = -10 dBm

Magnitude

Transmission Coefficient (dB)

Uncertainty (dB)

0

0.01

0.02

0.03

0.04

0.05

0 0.2 0.4 0.6 0.8 1

100 Hz to 100 kHz
100 kHz to 1 GHz
1 GHz to 3 GHz

S21 = S12 = 0 ; Source power = -10 dBm

Reflection Coefficient (Linear)

Magnitude

Uncertainty (Linear)

85032F calibration kit, full 2-port calibration

Network analyzer: E5061B-3L5, calibration kit: 85032F (Type-N, 50 Ω),
calibration: full 2-port

IF bandwidth = 10 Hz, No averaging applied to data, environmental temperature
= 23 °C ±5 °C with < 1 °C deviation from calibration temperature, isolation calibration
not omitted

Description Specification (dB)

Directivity 49 49 46

Source match 41 41 40

Load match 49 49 46

Refl ection tracking 0.011 0.011 0.021

Transmission tracking 0.019 0.019 0.026

Figure 1. Transmission uncertainty (specifi cation)

100 Hz to 100 kHz 100 kHz to 1 GHz 1 GHz to 3 GHz

Phase

100

10

100 Hz to 100 kHz
100 kHz to 1 GHz
1 GHz to 3 GHz

Figure 2. Refl ection uncertainty (specifi cation)

1

Uncertainty (Degrees)

0.1

S11 = S22 = 0 ; Source power = -10 dBm

Transmission Coefficient (dB)

Phase

10

8

6

4

Uncertainty (Degrees)

2

0

0 0.2 0.4 0 .6 0 .8 1

S21 = S12 = 0 ; Source Power = -10 dBm

Reflection Coefficient (Linear)

100 Hz to 100 kHz
100 kHz to 1 GHz
1 GHz to 3 GHz

-90

-80-7 0-6 0-5 0-4 0-3 0-2 0-1 0010

4

Table 3. Corrected system performance with Type-N 50 Ω connectors,

0

0.01

0.02

0.03

0.04

0.05

0 0.2 0.4 0.6 0.8 1

100 Hz to 100 kHz
100 kHz to 1GHz
1 GHz to 3 GHz

S21 = S12 = 0 ; Source power = -10 dBm

Reflection Coefficient (Linear)

Magnitude

Uncertainty (Linear)

0.1

1

10

100

100 Hz to 100 kHz
100 kHz to 1GHz
1 GHz to 3 GHz

S11 = S22 = 0 ; Source power = -10 dBm

Transmission Coefficient (dB)

Phase

Uncertainty (Degrees)

-90-8 0-70-6 0-5 0-4 0-30-20-10010

85032F calibration kit, enhanced response calibration

Network analyzer: E5061B-3L5, calibration kit: 85032F (Type-N, 50 Ω),
calibration: enhanced response

IF bandwidth = 10 Hz, No averaging applied to data, environmental temperature
= 23 °C ±5 °C with < 1 °C deviation from calibration temperature, isolation calibration
not omitted

Description Specification (dB)

Directivity 49 49 46

Source match 41 41 40

Load match 49 49 46

Refl ection tracking 0.011 0.011 0.021

Transmission tracking 0.019 0.019 0.033

Figure 3. Transmission uncertainty (specifi cation)

Magnitude

10

1

100 Hz to 100 kHz
100 kHz to 1GHz
1 GHz to 3 GHz

100 Hz to 100 kHz 100 kHz to 1 GHz 1 GHz to 3 GHz

0.1

Uncertainty (dB)

0.01

S11 = S22 = 0 ; Source power = -10 dBm

Transmission Coefficient (dB)

Figure 4. Refl ection uncertainty (specifi cation)

-90-8 0-70-60-5 0-40-3 0-20-1 0010

Phase

10

8

6

4

Uncertainty (Degrees)

2

0

0 0.2 0.4 0.6 0.8 1

S21 = S12 = 0 ; Source Power = -10 dBm

Reflection Coefficient (Linear)

100 Hz to 100 kHz
100 kHz to 1GHz
1 GHz to 3 GHz

5

Table 4. Corrected system performance with Type-N 50 Ω connectors,

300 kHz to 10 MHz
10 MHz to 1 GHz
1 GHz to 3 GHz

0

0.01

0.02

0.03

0.04

0.05

S21 = S12 = 0; Source Power = -10 dBm

Reflection Coefficient (Linear)

Magnitude

Uncertainty (Linear)

0 0.2 0.4 0.6 0.8 1

85092C ECal Module, full 2-port calibration

Network analyzer: E5061B-3L5, calibration kit: 85092C (Type-N, 50 Ω 300 kHz to 9 GHz),
calibration: Full 2 port

IF bandwidth = 10 Hz, No averaging applied to data, environmental temperature
= 23 °C ±5 °C with < 1 °C deviation from calibration temperature, isolation calibration
not omitted

Description Specification (dB)

Directivity 45 52 54

Source match 36 45 44

Load match 41 47 47

Refl ection tracking 0.100 0.040 0.040

Transmission tracking 0.056 0.039 0.040

Figure 5. Transmission uncertainty (specifi cation)

300 kHz to 10 MHz 10 MHz to 1 GHz 1 GHz to 3 GHz

Magnitude

10

1

0.1

Uncertainty (dB)

0.01

300 kHz to 10 MHz
10 MHz to 1 GHz
1 GHz to 3 GHz

Transmission Coefficient (dB)

S11 = S22 = 0; Source Power = -10 dBm

Figure 6. Refl ection uncertainty (specifi cation)

Phase

100

10

1

Uncertainty (Degrees)

-90-80-70-60-50-40-30-20-10010

0.1

300 kHz to 10 MHz
10 MHz to 1 GHz
1 GHz to 3 GHz

Transmission Coefficient (dB)

S11 = S22 = 0; Source Power = -10 dBm

-90-80-70-60-50-40-30-20-10010

Phase

10

8

6

4

Uncertainty (Degrees)

2

0

0 0.2 0.4 0.6 0.8 1

S21 = S12 = 0; Source Power = -10 dBm

Reflection Coefficient (Linear)

300 kHz to 10 MHz
10 MHz to 1 GHz
1 GHz to 3 GHz

6

Table 5. Corrected system performance with Type-N 50 Ω connectors,
85032F calibration kit, full 2-port calibration

Network analyzer: E5061B-115/135/215/235, calibration kit: 85032F (Type-N, 50 Ω),
calibration: Full 2 port

IF bandwidth = 10 Hz, No averaging applied to data, environmental temperature
= 23 °C ±5 °C with < 1 °C deviation from calibration temperature, isolation calibration
not omitted

Description Specification (dB)

Directivity 49 49 46

Source match 41 41 40

Load match 48 49 46

Refl ection tracking 0.011 0.011 0.021

Transmission tracking 0.035 0.028 0.034

Figure 7. Transmission uncertainty (specifi cation)

100 kHz to 300 kHz 300 kHz to 1 MHz 1 MHz to 3 GHz

Magnitude

10

1

0.1

Uncertainty (dB)

0.01

100 kHz to 300 kHz

300 kHz to 1 MHz

1 MHz to 3 GHz

Transmission Coefficient (dB)

S11 = S22 = 0; Source Power = -10 dBm

Figure 8. Refl ection uncertainty (specifi cation)

Magnitude

0.05

0.04

0.03

0.02

Uncertainty (Linear)

0.01

0

100 kHz to 300 kHz

300 kHz to 1 MHz
1 MHz to 3 GHz

S11 = S22 = 0; Source Power = -10 dBm

0 0.2 0.4 0.6 0.8 1

Reflection Coefficient (Linear)

Phase

100

10

100 kHz to 300 kHz

300 kHz to 1 MHz
1 MHz to 3 GHz

1

Uncertainty (Degrees)

S11 = S22 = 0; Source Power = -10 dBm

0.1

-90-8 0-7 0-6 0-50-4 0-3 0-2 0-1 0010

Transmission Coefficient (dB)

-90-80-70-60-50-40-30-20-10010

Phase

10

8

6

4

Uncertainty (Degrees)

2

0

0 0.2 0.4 0.6 0.8 1

Reflection Coefficient (Linear)

100 kHz to 300 kHz

300 kHz to 1 MHz

1 MHz to 3 GHz

S11 = S22 = 0; Source Power = -10 dBm

7

Table 6. Corrected system performance with Type-N 50 Ω connectors,
85032F calibration kit, enhanced response calibration

Network analyzer: E5061B-115/135/215/235, calibration kit: 85032F (Type-N, 50 Ω),
calibration: enhanced response calibration

IF bandwidth = 10 Hz, No averaging applied to data, environmental temperature
= 23 °C ±5 °C with < 1 °C deviation from calibration temperature, isolation calibration
not omitted

Description Specification (dB)

Directivity 49 49 46

Source match 41 41 40

Load match 48 49 46

Refl ection tracking 0.011 0.011 0.021

Transmission tracking 0.035 0.028 0.034

Figure 9. Transmission uncertainty (specifi cation)

100 kHz to 300 kHz 300 kHz to 1 MHz 1 MHz to 3 GHz

Magnitude

10

1

0.1

Uncertainty (dB)

0.01

100 kHz to 300 kHz

300 kHz to 1 MHz

1 MHz to 3 GHz

Transmission Coefficient (dB)

S11 = S22 = 0; Source Power = -10 dBm

Figure 10. Refl ection uncertainty (specifi cation)

Magnitude

0.05

0.04

0.03

0.02

Uncertainty (Linear)

0.01

0

100 kHz to 300 kHz

300 kHz to 1 MHz

1 MHz to 3 GHz

S11 = S22 = 0; Source Power = -10 dBm

0 0.2 0.4 0.6 0.8 1

Reflection Coefficient (Linear)

Phase

100

10

Uncertainty (Degrees)

0.1

-90-80-70-60-50-40-30-20-1010 0

10

8

6

4

Uncertainty (Degrees)

2

0

100 kHz to 300 kHz
300 kHz to 1 MHz
1 MHz to 3 GHz

1

S11 = S22 = 0; Source Power = -10 dBm

-90-80-70-60-50-40-30-20-10010

Transmission Coefficient (dB)

Phase

100 kHz to 300 kHz

300 kHz to 1 MHz

1 MHz to 3 GHz

S11 = S22 = 0; Source Power = -10 dBm

0 0.2 0.4 0.6 0.8 1

Reflection Coefficient (Linear)

8

Table 7. Corrected system performance with Type-N 50 Ω connectors,
85092C ECal Module, full 2-port calibration

Network analyzer: E5061B-115/135/215/235, calibration kit: 85092C (Type-N, 50 Ω),
calibration: Full 2 port

IF bandwidth = 10 Hz, No averaging applied to data, environmental temperature
= 23 °C ±5 °C with < 1 °C deviation from calibration temperature, isolation calibration
not omitted

Description Specification (dB)

Directivity 45

Source match 36

Load match 41

Refl ection tracking 0.1

Transmission tracking 0.059

Figure 11. Transmission uncertainty (specifi cation)

300 kHz to 3 GHz

Magnitude

10

1

0.1

Uncertainty (dB)

0.01

300 kHz to 1 MHz

1 MHz to 3 GHz

S11 = S22 = 0; Source Power = -10 dBm

Transmission Coefficient (dB)

Figure 12. Refl ection uncertainty (specifi cation)

Magnitude

0.05

0.04

0.03

0.02

Uncertainty (Linear)

0.01

300 kHz to 1 MHz

1 MHz to 3 GHz

S11 = S22 = 0; Source Power = -10 dBm

Phase

100

10

1

300 kHz to 1 MHz

1 MHz to 3 GHz

Uncertainty (Degrees)

S11 = S22 = 0; Source Power = -10 dBm

0.1

-90-80-70-60-50-40-30-20-10010

Phase

10

8

6

4

Uncertainty (Degrees)

2

Transmission Coefficient (dB)

300 kHz to 1 MHz

1 MHz to 3 GHz

S11 = S22 = 0; Source Power = -10 dBm

-90-80-70-60- 50-40-30- 20-10010

0

0 0.2 0.4 0.6 0.8 1

Reflection Coefficient (Linear)

0

0 0.2 0.4 0.6 0.8 1

Reflection Coefficient (Linear)

9

Table 8. Corrected system performance with Type-N 75 Ω connectors,
85036B calibration kit, full 2-port calibration

Network analyzer: E5061B-117/137/217/237, calibration kit: 85036B (Type-N, 75 Ω),
calibration: Full 2 port

IF bandwidth = 10 Hz, No averaging applied to data, environmental temperature
= 23 °C ±5 °C with < 1 °C deviation from calibration temperature, isolation calibration
not omitted

Description Specification (dB)

Directivity 49 48 44

Source match 48 41 35

Load match 48 48 44

Refl ection tracking 0.004 0.010 0.019

Transmission tracking 0.022 0.028 0.052

Figure 13. Transmission uncertainty (specifi cation)

100 kHz to 300 kHz 300 kHz to 1 MHz 1 MHz to 3 GHz

Magnitude

10

1

0.1

Uncertainty (dB)

0.01

100 kHz to 300 kHz

300 kHz to 1 MHz

1 MHz to 3 GHz

S11 = S22 = 0; Source Power = -10 dBm

Transmission Coefficient (dB)

Figure 14. Refl ection uncertainty (specifi cation)

Magnitude

0.05

0.04

0.03

0.02

Uncertainty (Linear)

0.01

0

100 kHz to 300 kHz

300 kHz to 1 MHz

1 MHz to 3 GHz

S11 = S22 = 0; Source Power = -10 dBm

0 0.2 0.4 0.6 0.8 1

Reflection Coefficient (Linear)

Phase

100

10

1

Uncertainty (Degrees)

0.1

-90-80-70-60-50-40-30-20-10010

10

8

6

4

Uncertainty (Degrees)

2

0

100 kHz to 300 kHz

300 kHz to 1 MHz
1 MHz to 3 GHz

S11 = S22 = 0; Source Power = -10 dBm

-90-80-70-60- 50-40-30-20-10010

Transmission Coefficient (dB)

Phase

100 kHz to 300 kHz

300 kHz to 1 MHz

1 MHz to 3 GHz

S11 = S22 = 0; Source Power = -10 dBm

0 0.2 0.4 0.6 0.8 1

Reflection Coefficient (Linear)

10

Table 9. . Corrected system performance with Type-N 75 Ω connectors,
85036B calibration kit, enhanced response calibration

Network analyzer: E5061B-117/137/217/237, calibration kit: 85036B (Type-N, 75 Ω),
calibration: enhanced response calibration

IF bandwidth = 10 Hz, No averaging applied to data, environmental temperature
= 23 °C ±5 °C with < 1 °C deviation from calibration temperature, isolation calibration
not omitted

Description Specification (dB)

Directivity 49 48 44

Source match 48 41 35

Load match 48 48 44

Refl ection tracking 0.004 0.010 0.019

Transmission tracking 0.022 0.028 0.052

Figure 15. Transmission uncertainty (specifi cation)

100 kHz to 300 kHz 300 kHz to 1 MHz 1 MHz to 3 GHz

Magnitude

10

1

0.1

Uncertainty (dB)

0.01

100 kHz to 300 kHz

300 kHz to 1 MHz

1 MHz to 3 GHz

Transmission Coefficient (dB)

S11 = S22 = 0; Source Power = -10 dBm

Figure 16. Refl ection uncertainty (specifi cation)

Magnitude

0.05

0.04

0.03

0.02

Uncertainty (Linear)

0.01

0

100 kHz to 300 kHz

300 kHz to 1 MHz
1 MHz to 3 GHz

S11 = S22 = 0; Source Power = -10 dBm

0 0.2 0.4 0.6 0.8 1

Reflection Coefficient (Linear)

Phase

100

10

1

100 kHz to 300 kHz

300 kHz to 1 MHz
1 MHz to 3 GHz

Uncertainty (Degrees)

S11 = S22 = 0; Source Power = -10 dBm

0.1

-90-80-70-60-50-40-30-20-10010

Phase

10

8

6

4

Uncertainty (Degrees)

2

0

0 0.2 0.4 0.6 0.8 1

Transmission Coefficient (dB)

S11 = S22 = 0; Source Power = -10 dBm

100 kHz to 300 kHz

300 kHz to 1 MHz

1 MHz to 3 GHz

-90-80-70-60-50-40-30-20-10010

Reflection Coefficient (Linear)

11

Uncorrected system performance

Table 10. Uncorrected system performance (correction: off)

Description Specification Typical

Directivity (Option 3L5) 25 dB

Directivity
(Option 115, 135, 215, 235,
117, 137, 217, 237)

Source match
(Option 3L5)

Source match
(Option 115, 135, 215, 235,
117, 137, 217, 237)

Load match (3L5) 15 dB

Load match
(Option 3L5, Source AC
Couple Mode)

Load match
(Option 115, 135, 215, 235,
117, 137, 217, 237)

Transmission tracking (3L5) ±1.0 dB

Transmission tracking
(Option 115, 135, 215, 235,
117, 137, 217, 237)

Refl ection tracking (3L5) ±1.0 dB

Refl ection tracking
(Option 115, 135, 215, 235,
117, 137, 217, 237)

20 dB
(at 100 kHz to 300 kHz)
25 dB
(at 300 kHz to 3 GHz)

25 dB

20 dB
(at 100 kHz to 300 kHz)
25 dB
(at 300 kHz to 3 GHz)

(at 5 Hz to 2 GHz)
12 dB
(at 2 to 3 GHz)

10 dB
(at 100 k to 300 kHz)
15 dB
(at 300 k to 3 GHz)

(at 100 Hz to 3 GHz)

±1.5 dB
(at 100 k to 300 kHz)
±1.0 dB
(at 300 k to 3 GHz)

(at 100 Hz to 3 GHz)

±1.5 dB
(at 100 k to 300 kHz)
±1.0 dB
(at 300 k to 3 GHz)

10 dB
(at 100 Hzk to 300 kHz)
15 dB
(at 300 kHz to 2 GHz)
12 dB
(at 2 to 3 GHz)

±1.0 dB
(at 5 to 100 Hz)

±1.0 dB
(at 5 to 100 Hz)

12

Test port output (Source)

Table 11. Test port output frequency

Description Specification Typical

Range (Option 3L5) 5 Hz to 3 GHz
Range (Option 115, 135, 215, 235,

117, 137, 217, 237)
Resolution 1 mHz
Source stability ±7 ppm (5 to 40 °C)
CW accuracy ±7 ppm ±1 mHz

High stability option (Option 1E5)

CW accuracy ±1 ppm ±1 mHz
Stability ±0.05 ppm (5 to 40 °C)

Table 12. Test port output power

Description Specification Typical

Level accuracy
(Option 3L5)

Level accuracy
(Option 115, 135, 215,

235)

Level accuracy
(Option 117, 137, 217,

237)

Level Lineality
(Option 3L5)

Level Lineality
(Option 115, 135, 215,
235, 117, 137, 217, 237)

Range
(Option 3L5)

±0.8 dB (at 0 dBm, 50 MHz absolute)
±1.0 dB (at 5 Hz to 1.5 GHz, 0 dBm,
relative to 50 MHz)
±1.5 dB (at 1.5 GHz to 3 GHz, 0 dBm,
relative to 50 MHz)

±0.8 dB (at 0 dBm, 50 MHz absolute)
±1.5 dB (at 100 kHz to 300 kHz, 0 dBm,
relative to 50 MHz)
±1.0 dB (at 300 kHz to 3 GHz, 0 dBm,
relative to 50 MHz)

±0.8 dB (at 0 dBm, 50 MHz absolute)
±1.5 dB (at 100 kHz to 300 kHz, 0 dBm,
relative to 50 MHz)
±1.0 dB (at 300 kHz to 2 GHz, 0 dBm,
relative to 50 MHz)

±0.75 dB (at –10 to 10 dBm, 0 dBm reference)

±0.75 dB (at –10 to 5 dBm, 100 kHz to 300
kHz, 0 dBm reference)
±0.75 dB (at –10 to 10 dBm, 300 kHz to 3 GHz,
0 dBm reference)

–45 dBm to 10 dBm

100 kHz to 3 GHz

±0.5 ppm per year

±1.0 dB (at 2 GHz to
3 GHz, 0 dBm,
relative to 50 MHz)

Range
(Option 115, 135, 215,
235, 117, 137, 217, 237)

Sweep Range
(Option 3L5)

Sweep Range
(Option 115, 135, 215,
235, 117, 137, 217, 237)

Level resolution 0.05 dB

Table 13. Test port output signal purity

–45 dBm to 5 dBm (at 100 kHz to 300 kHz)
–45 dBm to 10 dBm (at 300 kHz to 3 GHz)

–45 dBm to 10 dBm

–45 dBm to 5 dBm (at 100 kHz to 300 kHz)
–45 dBm to 10 dBm (at 300 kHz to 3 GHz)

Description Specification Typical

Harmonics (2nd or 3rd) < –25 dBc (at 5 dBm)

Non-harmonic spurious < –25 dBc (at 5 dBm)

13

Test port input

Table 14. Test port input levels

Description Specification Typical

Damage level (Option 3L5) +20 dBm, ±7 V DC
Damage level (Option 115, 135,

215, 235, 117, 137, 217, 237)
Absolute Amplitude Accuracy < ±3 dB

Crosstalk
(Option 3L5)

Crosstalk
(Option 115, 135, 215, 235, 117,
137, 217, 237)

Table 15. Test port input (noise fl oor)

1

–

85 dB (at 5 Hz to 100 Hz)

–

100 dB (at 100 Hz to 9 kHz)

–

110 dB (at 9 to 100 kHz)

–

115 dB (at 100 kHz to 3 GHz)

–

100 dB (at 100 to 300 kHz)

–

110 dB (at 300 k to 1MHz)

–

115 dB (at 1 MHz to 3 GHz)

Description Specification Typical

Noise Floor (Option 3L5)

–

3 kHz Bandwidth

Noise Floor (Option 3L5)
10 Hz Bandwidth

Noise Floor (Option 115, 135,
215, 235, 117, 137, 217, 237)
3 kHz Bandwidth

Noise Floor (Option 115, 135,
215, 235, 117, 137, 217, 237)
10 Hz Bandwidth

80 dBm (100 k to 1 MHz)

–

85 dBm (1M to 3 GHz)

–

80 dBm (5 to 100 Hz)

–

90 dBm (100 Hz to 9 kHz)

–

100 dBm (9 to 100 kHz)

–

105 dBm (100 k to 1 MHz)

–

110 dBm (1 M to 3 GHz)

–

70 dBm (100 to 300 kHz)

–

80 dBm (300 k to 1 MHz)

–

85 dBm (1M to 3 GHz)

–

95 dBm (100 to 300 kHz)

–

105 dBm (300 k to 1 MHz)

–

110 dBm (1M to 3 GHz)

+20 dBm, ±30 V DC

(at 0 dBm)

1. The specifi cation might not be met at the frequencies 25MHz and 90 MHz Line and Fan related

frequency.

14

Table 16. Test port input (trace noise)

Description Specification Typical

Trace Noise Magnitude
(Option 3L5)
source power level = + 10 dBm

Trace Noise Magnitude
(Option 115, 135, 215, 235, 117,
137, 217, 237)
Maximum output power level
3 kHz Bandwidth

Trace Noise Phase (Option 3L5)
source power level = + 10 dBm

Trase Noise Phase
(Option 115, 135, 215, 235, 117,
137, 217, 237)
Maximum output power level
3 kHz Bandwidth

5 mdB rms
(< 10 kHz)
Automatic IF Bandwidth

5 mdB rms
(10 kHz to 3 GHz)
3 kHz Bandwidth

15 mdB rms
(100 to 300 kHz)

8 mdB rms
(300 kHz to 1 MHz)

5 mdB rms
(1 MHz to 3 GHz)

0.03° rms
(< 10 kHz)
Automatic IF Bandwidth

0.03° rms
(10 kHz to 3 GHz)
3 kHz Bandwidth

0.09° rms
(100 to 300 kHz)

0.05° rms
(300 kHz to 1 MHz)

0.03° rms
(1 MHz to 3 GHz)

Table 17. Test port input (stability)

Description Specification SPD

Stability magnitude (Option 3L5)

3 MHz to 3 GHz 0.01 dB/°C

Stability magnitude (Option 115,
135, 215, 235, 117, 137, 217, 237)

100 kHz to 300 kHz
300 kHz to 3 MHz
3 MHz to 3 GHz

Stability phase (Option 3L5)

3 MHz to 3 GHz 0.1 °/°C

Stability phase (Option 115,
135, 215, 235, 117, 137, 217, 237)

100 kHz to 300 kHz
300 kHz to 3 MHz
3 MHz to 3 GHz

0.05 dB/°C

0.02 dB/°C

0.01 dB/°C

0.5 °/°C

0.2 °/°C

0.1 °/°C

15

Table 18. Test port input (dynamic accuracy)

Accuracy of the test port input power reading is relative to –10 dBm reference input
power level.

Description Specification Typical

Dynamic accuracy magnitude
(Option 3L5)

Reference = –10 dBm

Dynamic accuracy magnitude
(Option 115, 135, 215, 235, 117, 137, 217, 237)

Reference = –10 dB

±0.303 dB
(at 10 dBm)

±0.087 dB
(at –30 dBm)

±2.141 dB
(at –100 dBm)

±0.303 dB
(at 10 dBm)

±0.087 dB
(at –30 dBm)

±2.141 dB
(at –100 dBm)
300 kHz to 3 GHz

±0.383 dB
(at 10 dBm)

±0.167 dB
(at –30 dBm)

Dynamic accuracy phase (Option 3L5)

Reference = –10 dB

Dynamic accuracy phase
(Option 115, 135, 215, 235, 117, 137, 217, 237)

Reference = –10 dB

±2.221 dB
(at –100 dBm)
100 to 300 kHz

±2.04 °
(at 10 dBm)

±0.58 °
(at -30 dBm)

±16.23 °
(at –100 dBm)

±2.04 °
(at 10 dBm)

±0.58 °
(at –30 dBm)

±16.23 °
(at –100 dBm)
300 kHz to 3 GHz

±2.58 °
(at 10 dBm)

±1.11 °
(at –30 dBm)

±16.94 °
(at –100 dBm)
100 to 300 kHz

16

Figure 17. Dynamic Accuracy Option 3L5

Accuracy [deg]

10

1

Accuracy [dB]

0.1

0.01

Input Power [dBm]

Figure 18. Option 115. 135, 117, 137, 215, 235, 217, 237

Dynamic Accuracy (Magnitude)

10

Dynamic Accuracy (Magnitude)

Spec.(300k㻡f㻡3GHz)

Spec.(100k㻡f

䋼300k)

100

Dynamic Accuracy (Phase)

10

1

-100-90-80-70-60-50-40-30-20-10010

0.1

Input Power [dBm]

Dynamic Accuracy (Phase)

100

Spec.(300k㻡f㻡3GHz)

Spec.(100k㻡f䋼300k)

-100-90-80-70-60-50-40-30-20-10010

1

Accuracy [dB]

0.1

0.01

Input Power [dBm]

10

Accuracy [deg]

1

- 100- 90- 80- 70- 60- 50- 40- 30- 20- 10010

0.1

Input Power [dBm]

-100- 90-80- 70- 60-50- 40-30- 20- 10010

17

Table 19. Test port input (group delay)

Group Delay (Typical)

0.001

0.01

0.1

1

10

100

0.01 0.1 1 10 100

Aperture (MHz)

Accuracy (nsec)

E5061B 3L5 Full Two Port Cal Using 85032F

Frequency = 1 GHz

S11 = 0; S21 = 1; S12 = 0; S22 = 0

IF Bandwidth = 10 Hz; Average Factor = 1

Cal power = -10 dBm; Meas power = -10 dBm; Electrical Length = 10 m

Group Delay (Typical)

0.001

0.01

0.1

1

10

100

0.01 0.1 1 10 100

Aperture (MHz)

Accuracy (nsec)

E5061B 237 Enhanced Transmission Response Cal Using 85036B

Frequency = 1 GHz

S11 = 0; S21 = 1; S12 = 0; S22 = 0

IF Bandwidth = 1 Hz; Average Factor = 1

Cal power = -10 dBm; Meas power = -10 dBm; Electrical Length = 10 m

Description Specification Supplemental information

Aperture
(selectable)

Maximum aperture 25% of frequency span

Minimum delay Limited to measuring no more

Accuracy See graph below

The following graph shows group delay accuracy with Type-N full 2-port
calibration and a 10 Hz IF bandwidth. Insertion loss is assumed to be < 2 dB.

Figure 19. Group delay (typical)

(frequency span)/
(number of points –1)

than 180° of phase change
within the minimum aperture.

In general, the following formula can be used to determine the accuracy, in
seconds, of specific group delay measurement: ±phase accuracy (deg)/[360 x
aperture (Hz)]

1. Group delay is computed by measuring the phase change within a specifi ed step

(determined by the frequency span and the number of points per sweep).

18

Gain Phase Measurement (Option 3L5 only)

Source Characteristics (LF Out)

Table 20. Source characteristics output frequency

Description Specification Typical

Range 5 Hz to 30 MHz

Resolution 1 mHz

Source stability ±7 ppm (5 °C to 40 °C)

CW accuracy ±7 ppm ±1 mHz

High stability option (Option 1E5)

CW accuracy ±1 ppm ±1 mHz

Source stability ±0.05 ppm (5 °C to 40 °C)

±0.5 ppm per year

Table 21. Source characteristics output power

Description Specification SPD

Level accuracy ±1 dB

(at 0 dBm absolute 200 Hz)

±2 dB
(at 0 dBm, relative to 200 Hz)

Level ±1 dB

(at -10 dBm to 10 dBm, 0
dBm reference)

Range –45 dBm to 10 dBm

Sweep range –45 dBm to 10 dBm

Level resolution 0.05 dB

±1 dB
(at -45 dBm to -10 dBm, 0
dBm reference)

Table 22. Source characteristics output signal purity

Description Specification Typical

Harmonics (2nd or 3rd) < –20 dBc

(at 5 dBm)

Non-harmonic spurious < –25 dBc

(at 5 dBm)

Table 23. Source characteristics output impedance

Description Specification Typical

Impedance 50 Ω nominal

Return loss > 10 dBc

19

Test Port Input Characteristics

Table 24. Test port input attenuator

Description Specification

Input attenuator 0 dB, 20 dB

Table 25. Test port input levels

Description Specification Typical

Maximum test port
input level

Damage level 26 dBm, ±42 V DC

Absolute amplitude
accuracy

Ratio accuracy

Magnitude (for the
same attenuation
setting for both inputs)

Phase (for the same
attenuation setting for
both inputs)
Noise level (referenced to
full scale input level at 23
°C ±5 °C)
0 dB attenuation, 50
Short termination.

Crosstalk

1

(for T/R)
For input R: 10 dBm, 20 dB
attenuation
For input T: 0 dB
attenuation, short
termination

15 dBm (at 20 dB attenuation, 50 Ω)

-5 dBm (at 0 dB attenuation, 50 Ω)

1.78 V

0.18 V

(at 20 dB attenuation, 1 MΩ)

peak

(at 0 dB attenuation, 1 MΩ)

peak

< ±1.5 dB (at -15 dBm, 0 dB
attenuation, 50 Ω input impedance)
< ±1.5 dB (at 5 dBm, 20 dB
attenuation, 50 Ω input impedance)

< ±1 dB at (-15 dBm, 0 dB Att.) or (5
dBm,20 dB Att.) 50 Ω impedance
< ±3 dB at (-15 dBm, 0 dB Att) or (5
dBm, 20 dB Att.) 1 MΩ impedance
using 50 Ω feedthrough
< ±5 °C at (-15 dBm,0 dB Att) or (5
dBm, 20 dB Att.), 50 Ω impedance

-95 dB (at 5 Hz to 100 Hz, 2 Hz IF
bandwidth)

-95 dB

(at 100 Hz to 9kHz, 10 Hz IF

bandwidth)

Ω

,

-105 dB

(at 9 kHz to 100 kHz, 10 Hz IF

bandwidth)

-115 dB

(at 100 kHz to 10 MHz, 10 Hz IF

bandwidth)

-110 dB

(at 10 MHz to 30 MHz, 10 Hz IF

bandwidth)

-110 dB (at 5 Hz to 100 kHz)

-120 dB
(at 100 kHz to 10 MHz, 10 Hz IF bandwidth)

-110 dB
(at 10 MHz to 30 MHz, 10 Hz IF bandwidth)

(at 1 MΩ)
26 dBm, ±7 V DC
(at 50 Ω)

1. The specifi cation might not be met at the frequencies 25 MHz, line and fan related frequency.

20

Table 26. Test port input (Trace noise)

Description Specification Typical

Trace noise

(at IF automatic bandwidth,
<10 kHz)

(at 3 kHz bandwidth, 10 kHz to
30 MHz at -5 dBm, 0 dB
attenuation, 50 Ω)

Trace noise phase

(at IF automatic bandwidth,
<10 kHz)

(at 3 kHz bandwidth, 10 kHz to
30 MHz at -5 dBm, 0 dB
attenuation, 50 Ω)

Table 27. Test port input (stability)

5 mdB rms

5 mdB rms

0.03° rms

0.03° rms

Description Specification SPD

Stability magnitude < ±0.02 dB/°C

Stability phase < ±0.2°/°C

Table 28. Test port input (Dynamic Accuracy)

1

Description Specification Typical

Dynamic accuracy magnitude

(0 dB attenuation, 50 Ω) ±0.303 dB at -5 dBm

±0.09 dB at -15 dBm
±0.056 dB at -25 dBm
±0.073 dB at -35 dBm
±0.087 dB at -45 dBm
±0.103 dB at -55 dBm
±0.121 dB at -65 dBm
±0.15 dB at -75 dBm
±0.211 dB at -85 dBm
±0.371 dB at -95 dBm
±0.841 dB at -105 dBm
±2.141 dB at -115 dBm

Dynamic accuracy phase

(0 dB attenuation, 50 Ω) ±2.04 ° at -5 dBm

±0.6 ° at -15 dBm
±0.37 ° at -25 dBm
±0.48 ° at -35 dBm
±0.58 ° at -45 dBm
±0.68 ° at -55 dBm
±0.81 ° at -65 dBm
±1.00 ° at -75 dBm
±1.41 ° at -85 dBm
±2.5 ° at -95 dBm
±5.83 ° at -105 dBm
±16.23 ° at -115 dBm

±5 °
(+15 dBm, 20
dB attenuation)

1. Accuracy of the test port input power reading is relative to –25 dBm reference input power level.

21

Figure 20. Dynamic Accuracy

0.1

0.01

10

1

Dynamic Accuracy (Magnitude)

-115-105-95-85-75-65-55-45-35-25-15-5

Input Power [dBm]

100

10

1

Accuracy [dB]

0.1

Dynamic Accuracy (Phase)

Accuracy [deg]

-115-105-95-85-75-65-55-45-35-25-15-5

Input Power [dBm]

Table 29. Test port input impedance

Description Specification Typical

Impedance 50 Ω nominal

1 MΩ // 30 pF

Return loss > 15 dB at 50 Ω input

DC Bias (Option 3L5 only)

Table 30. DC bias

Description Specification

DC voltage bias

Output Port Port 1, LF Out

Range 0 to ±40 V (100 mA max)

Resolution 1 mV ±(0 V to 10 V)

4 mV ±(10 V to 40 V)

Accuracy

1

Output Impedance 50 Ω nominal

DC bias monitor at IFBW = AUTO (=< 100 Hz)

Voltage accuracy ±{0.4 % + 50 mV}

Current accuracy ±{1 % + 500 µA + (|Vdc[V]|/10 kΩ) }

±{0.1% + 4 mV} (at Open Port) 23 ±5° C

(at 23 °C ±5 °C)
±{0.4 % + 50 mV} x4
(at 5 °C to 40 °C)
Automatic IF Bandwidth ≤ 100 Hz

(at 23 ±5 °C)
±{1 % + 500 µA + (|Vdc[V]|/10 kΩ) } x2
(at 5 °C to 40 °C)
Automatic IF Bandwidth ≤ 100 Hz

1. DC Switching Transient Noise: ±30 mV (SPD) when port or power switching occur.

22

General information

Table 31. System bandwidths

Description General Specification

IF bandwidth settings

Range 1 Hz to 300 kHz

Nominal settings are:
1, 1.5, 2, 3, 4, 5, 7

Table 32. Front panel information

Description General Specification Typical

Connectors

Type Type-N, female; 50 or 75 Ω

(Ports 1 and 2)

BNC, female; 50 Ω or 1 M Ω
(Ports R and T)
BNC, female; 50 Ω
(LF Out)

Probe Power
(Option 3L5)

Display

Size 10.4 in TFT color LCD

Resolution XGA (1024 x 768)

1

15 V ±5 % (400 mA)

-12.6 V ±5 % (300 mA)
(combined load for both
probe connections)

1. Valid pixels are 99.99% and more. Below 0.01% of fi xed points of black, blue, green or red are

not regarded as failure.

23

Table 33. Rear panel information

Description General Characteristics

External trigger input connector

Type BNC female
Input level Low threshold voltage: 0.5 V

High threshold voltage: 2.1 V

Input level range: 0 to +5 V
Pulse width ≥ 2 µsec
Polarity Postitive or negative

External trigger output connector

Type BNC, female
Maximum output current 50 mA
Output level Low level voltage: 0 V

High level voltage: 5 V

Adjustable (1 µsec to 1 sec)

Polarity Positive or negative

External reference signal input connector

Type BNC, female
Input frequency 10 MHz ±10 ppm (Typical)
Input level 0 dBm ±3 dB (Typical)

Internal reference signal output
connector

Type BNC, female
Output frequency 10 MHz ±7 ppm (Typical)
Output level 0 dBm ±3 dB into 50 Ω
Output impedance 50 Ω nominal

Internal reference signal oven
connector

Type BNC, female
Output frequency 10 MHz ±1 ppm
Output level 0 dBm minimum
VGA video output 15-pin mini D-Sub; female; drives VGA compatible

monitors
GPIB 24-pin D-Sub (type D-24), female; compatible with

IEEE-488
USB port Universal serial bus jack, type A confi guration

(4 contacts inline, contact 1 on left); female; provides

connection to printer, ECal module, USB/GPIB interface
USB (USBTMC) interface port Universal serial bus jack, Type B confi guration

(4 contacts inline); female; provides connection to an

external PC; compatible with USBTMC-USB 488 and

USB 2.0.
LAN 10/100/1000 BaseT Ethernet, 8-pin confi guration; auto

selects between the two data rates

24 bit I/O port 36-pin Centronics, female; provides connection to

Line power

1

Frequency 47 Hz to 63 Hz
Voltage 90 to 132 VAC, or 198 to 264 VAC (automatically

VA max 300 VA max

handler system

switched)

1. A third-wire ground is required.

24

Table 34. EMC and safety

Description General Characteristics

EMC

European Council Directive 2004/108/EC
IEC 61326-1:2005

ISM 1-A

ICES/NMB-001 ICES-001:2006 Group 1, Class A

N10149

Safety

ISM 1-A

LR95111C

Environment

25

EN 61326-1:2006
CISPR 11:2003+A1:2004
EN 55011:2007
Group 1, Class A
IEC 61000-4-2:1995 +A2:2000
EN 61000-4-2:1995 +A2:2001
4 kV CD / 8 kV AD
IEC 61000-4-3:2006
EN 61000-4-3:2006

1-3 V/m, 80-1000 MHz/1.4 GHz - 2.7 GHz, 80% AM
IEC 61000-4-4:2004
EN 61000-4-4:2004
1 kV power/0.5 kV signal lines
IEC 61000-4-5:2005
EN 61000-4-5:2006

0.5 kV line-line/1 kV line-ground
IEC 61000-4-6:2003 + A1:2004+ A2:2006
EN 61000-4-6:2007
3 V, 0.15-80 MHz, 80% AM
IEC 61000-4-11:2004
EN 61000-4-11:2004

0.5-300 cycle, 0%/70%

AS/NZS CISPR11:2004 Group 1, Class A

European Council Directive 2006/95/EC
IEC 61010-1:2001 / EN 61010-1:2001
Measurement Category I
Pollution Degree 2
Indoor Use

CAN/CSA C22.2 No. 61010-1-04
Measurement Category I
Pollution Degree 2
Indoor Use

This product complies with the WEEE Directive
(2002/96/EC) marking requirements. The affi xed
label indicates that you must not discard this
electrical/electronic product in domestic household
waste.
Product Category: With reference to the equipment
types in the WEEE Directive Annex I, this
product is classed as a “Monitoring and Control
instrumentation” product.
Do not dispose in domestic household waste.
To return unwanted products, contact your local
Agilent offi ce, or see
www.agilent.com/environment/product/
for more information.

Table 35. Analyzer environment and dimensions

Description General Characteristics

Operating environment

Temperature +5 °C to +40 °C

Error-corrected temperature range 23 °C ±5 °C with < 1 °C deviation from calibration

temperature

Humidity 20% to 80% at wet bulb temperature < +29 °C

(non-condensing)

Altitude 0 to 2,000 m (0 to 6,561 feet)

Vibration 0.21 G maximum, 5 Hz to 500 Hz

Non-operating storage environment

Temperature –10 °C to +60 °C

Humidity 20% to 90% at wet bulb temperature < 40 °C

(non-condensing)

Altitude 0 to 4,572 m (0 to 15,000 feet)

Vibration 0.5 G maximum, 5 Hz to 500 Hz

Dimensions

Weight

Magnetic Susceptibility

Magnetic Emission

Height = 235 mm, Width = 432 mm, Depth = 296 mm.
See fi gures 10 to 12.

14.0 kg

Degradation of some product specifi cations can
occur in the presence of ambient power frequency
magnetic fi elds of 30 A/m or greater.
The product self-recovers and operates as speci­fi ed when removed or shielded from the ambient
magnetic fi eld.
When the analyzer tuned frequency is identical
to the immunity test signal frequency, there may
be signals of up to −80 dB of full-scale response
displayed on the screen.

Emission of magnetic fi eld may occur at the left
side of the where two cooling fans are installed.
Its magnitude can be as much as 160A/m and
25A/m at 0cm and 1cm apart from the center of
the fan, respectively. It is recommended to have
enough clearance between the cooling fans and
magnetically sensitive device or instruments.

26

Figure 21. Dimensions (front view, in millimeters) 1

17

1M! +26 dBm RF



50! +26 dBm RF

Avoid Static

42 V DC Max CAT Ι

7 V DC Max CAT Ι

!/50!

1M

44 22 90 99

DC Bias

ELECTROSTATIC DISCHARGE

OR EXCESSIVE INPUT VOLTAGE

MAY DAMAGE CIRCUITS.

±42V Peak Max Output

ChannelChannel

ChannelChannel

TraceTrace

TraceTrace

ChannelChannel

Trace Trace

Meas Format

Scale Display

Avg

Cal

Start Stop

SpanCenter

Sweep Trigger

50!

7

1

0

Entry Bk Foc

Marker MacroMarker

Analysis

Marker

Save/ System

Probe Power

DC Bias

+20 dBm RF 7 V DC Max CAT Ι

20 29 30 30

8 9

2 3

.

Macro Macro

G/n

M/μ

654

k/m

x 1

+/㪄

HelpHelp

PresetPreset

75

50!

22

37

e5061bfront

191

Gain-Phase Test Ports

Figure 22. Dimensions (rear view, in millimeters)

432

426

63

21 20 22 145 44

61

NOTE

Switch must remain

TEST SET I/F

13130 9 17

10 MHz

VIDEO

WARNING:

Serial Label

Serial Label

No operator serviceable parts inside.
Refer servicing to qualified personnel.

E5061B

ICES/NMB-001

4

Windows Label

Windows Label

46

237

GPIB

169

168

144

141

75

53

166

ON while operating.

115 V

50/60 Hz 300 VA Max

LINE

7

221

174

167

165

152

e5061brear

1. Options 115, 135, 215, 235,117, 137, 217, 237 has no gain-phase test port and probe power.

27

Figure 23. Dimensions (side view, in millimeters)

277

22223 32

235

e5061bside

18 215

19

13 222

28

Measurement throughput summary

Table 36. Typical cycle time for measurement completion

1, 2

(ms) (Display update: off)

Number of points

51 201 401 1601

Start 1 GHz, stop 1.2 GHz, 30 kHz IF bandwidth

Uncorrected 5 15 26 89

2-port cal 14 33 56 181

Start 1 GHz, stop 1.2 GHz, 300 kHz IF bandwidth

Uncorrected 4 9 15 43

2-port cal 11 21 33 88

Start 1 MHz, stop 3 GHz, 30 kHz IF bandwidth

Uncorrected 10 23 37 119

2-port cal 24 48 78 241

Start 1 MHz, stop 3 GHz, 300 kHz IF bandwidth

Uncorrected 9 17 26 73

2-port cal 20 37 54 148

1

Table 37. Typical cycle time for measurement completion

(ms) (Display update: on)

Number of points

51 201 401 1601

Start 1 GHz, stop 1.2 GHz, 30 kHz IF bandwidth

Uncorrected 45 47 49 103

2-port cal 55 59 69 195

Start 1 GHz, stop 1.2 GHz, 300 kHz IF bandwidth

Uncorrected 45 47 50 64

2-port cal 55 59 64 103

Start 1 MHz, stop 3 GHz, 30 kHz IF bandwidth

Uncorrected 45 47 50 133

2-port cal 55 61 90 255

Start 1 MHz, stop 3 GHz, 300 kHz IF bandwidth

Uncorrected 45 47 50 87

2-port cal 55 59 67 163

1. Typical performance.

2. Measured with the fi rmware revision A.02.00.

29

Table 38. Data transfer time 1 (ms)

Number of points

51 201 401 1601

SCPI over GPIB

REAL 64 6 16 29 112

ASCII 29 109 215 848

SCPI over GPIB/USB (82357B)

REAL 64 8 14 23 77

ASCII 73 282 563 2247

SCPI over 100 Mbps LAN (SICL-LAN)

REAL 64 5 5 6 8

ASCII 4 8 13 41

SCPI over 100 Mbps LAN (Socket)

REAL 64 2234

ASCII 20 72 142 562

SCPI over USB

REAL 64 3345

ASCII 4 10 19 69

COM (program executed in the analyzer)

Variant type 1111

2

2

2

2

3

1. Typical performance.

2. Measured using a VEE Pro 9.0 program running on a 2.4 GHz Pentium
Transferred complex S

data, using :CALC:DATA?SDATA.

11

®

4,

3. Measured using E5061B VBA macro running inside the analyzer. Transferred complex S

30

data.

11

Measurement capabilities

Number of measurement channels Up to 4 independent measurement channels. A

measurement channel is coupled to stimulus
response settings including frequency, IF
bandwidth, power level, and number of points.

Number of display windows Each measurement channel has a display

window. Up to 4 display windows (channels) can
be displayed.

Number of traces 4 data traces and 4 memory traces per channel

Measurement choices

Measurement parameter
conversion

Data formats Log magnitude, linear magnitude, phase,

Data markers 10 independent markers per trace. Reference

Marker functions

Marker search Max value, min value, multi-peak, multi-target,

Marker-to functions Set start, stop, center to active marker stimulus

Search range User defi nable.

Tracking Performs marker search continuously or on

Fault location functions (Option 010)

Transformation to distance and
time domain

Impedance Measurement Analysis (Option 005)

Impedance Measurement Selectable Impedance Parameter and Equivalent

Option 115,135,117 and 137 - S11, S21, Absolute
Option 215, 235 and 237 - S11, S21, S12, S22, Absolute
Option 3L5 - S11, S21, S12, S22, T/R, T, R, Absolute

Available to convert S-parameters into refl ection
impedance, transmission impedance, refl ection
admittance, transmission admittance, and 1/S.

expanded phase, positive phase, group delay,
SWR, real, imaginary, Smith chart, polar.

marker available for delta marker operation. Smith
chart format includes 5 marker formats: linear
magnitude/phase, log magnitude/phase, real/
imaginary, R + jX, and G + jB. Polar chart format
includes 3 marker formats: linear magnitude/
phase, log magnitude/phase, and real/imaginary.

peak, peak left, peak right, target, target left,
target right, and width parameters with user­defi ned bandwidth values.

value; set reference to active marker response
value; set electrical delay to group delay at active
marker.

demand.

Selectable transformation type from bandpass,
lowpass impulse, lowpass step.
Selectable window from maximum, normal and
minimum.

Circuit analysis Capability

31

Source control

Measured number of points per
sweep

Sweep type Linear sweep, segment sweep, log sweep , power

Segment sweep Defi ne independent sweep segments. Set number

Sweep trigger Set to continuous, hold, or single, sweep with

Power Set source power from -45 dBm to 10 dBm. The

User defi nable from 2 to 1601.

sweep and DC bias sweep.

of points, test port power levels, IF bandwidth,
delay time, sweep time independently for each
segment.

internal, external, manual, or bus trigger.

power slope function compensates source power
error.

Trace functions

Display data Display current measurement data, memory

data, or current measurement and memory data
simultaneously.

Trace math Vector addition, subtraction, multiplication or

division of measured complex values and memory
data.

Title Add custom title to each channel window.

Titles are printed on hardcopies of displayed
measurements

Autoscale Automatically selects scale resolution and

reference value to vertically center the trace.

Electrical delay Offset measured phase or group delay by a

defi ned amount of electrical delay, in seconds.

Phase offset Offset measured phase or group delay by a

defi ned amount in degrees.

Statistics Calculates and displays mean, standard deviation

and peak-to-peak deviation of the data trace.

32

Data accuracy enhancement

Measurement calibration Measurement calibration signifi cantly reduces

measurement uncertainty due to errors caused
by system directivity, source and load match,
tracking and crosstalk. Full 2-port calibration
removes all the systematic errors for the
related test ports to obtain the most accurate
measurements.

Calibration types available

Response Simultaneous magnitude and phase correction of

frequency response errors for either refl ection or
transmission measurements.

Response and isolation Compensates for frequency response and

crosstalk errors of transmission measurements.

Enhanced response Compensates for frequency response and source

match errors.

One-port calibration Compensates for directivity, frequency response

and source match errors.

Full 2-port calibration
(option 215, 235, 217, 237, 3L5)

Interpolated error correction With any type of accuracy enhancement

Velocity factor Enter the velocity factor to calculate the

Reference port extension Redefi ne the measurement plane from the plane

Compensates for directivity, source match,
refl ection tracking, load match, transmission
tracking and crosstalk. Crosstalk calibration can
be omitted.

applied, interpolated mode recalculates the
error coeffi cients when the test frequencies are
changed. The number of points can be increased
or decreased and the start/stop frequencies can
be changed.

equivalent physical length.

where the calibration was done.

33

Storage

Internal hard disk drive Store and recall instrument states, calibration

data, and trace data into internal hard drive. Trace
data can be saved in CSV (comma separated
value) format. All fi les are MS-DOS
Instrument states include all control settings,
limit lines, segment sweep tables, and memory
trace data.

File sharing Internal hard disk drive (D:) can be accessed from

an external Windows

®

PC through LAN.

Screen hardcopy Printouts of instrument data are directly produced

on a printer through USB interfaces.

System capabilities

Familiar graphical user interface The analyzer employs a graphical user interface

based on Windows

®

operating system. There are
three ways to operate the instrument manually:
you can use a hardkey interface, touch screen
interface or a mouse interface.

Limit lines Defi ne the test limit lines that appear on the

display for pass/fail testing. Defi ned limits may be
any combination of horizontal/sloping lines and
discrete data points.

®

-compatible.

Automation

GPIB/LAN/USB Internal

SCPI

COM

Methods

Internal analyzer execution Applications can be developed in a built-in

Controlling via GPIB The GPIB interface operates to IEEE 488.2 and

LAN

Protocol TCP/IP

Function Telnet, SICL-LAN

USB

Protocol USB Test and Measurement Class (TMC)

××

×

®

(Visual Basic for Applications) language.

VBA
Applications can be executed from within the
analyzer via COM (component object model) or
using SCPI.

SCPI protocols. The analyzer can be controlled
by a GPIB external controller. The analyzer can
control external devices using a USB/GPIB
interface.

interface that communicates over USB, complying
with the IEEE 488.1 and IEEE 488.2 standards.

34

www.agilent.com

www.agilent.com/find/ena

Agilent Email Updates

www.agilent.com/find/emailupdates

Get the latest information on the
products and applications you select.

www.lxistandard.org

LAN eXtensions for Instruments puts
the power of Ethernet and the Web
inside your test systems. Agilent is a
founding member of the LXI consortium.

Agilent Channel Partners

www.agilent.com/find/channelpartners

Get the best of both worlds: Agilent’s
measurement expertise and product
breadth, combined with channel
partner convenience.

Agilent Advantage Services is com­mitted to your success throughout
your equipment’s lifetime. We share
measurement and service expertise
to help you create the products that
change our world. To keep you com­petitive, we continually invest in tools
and processes that speed up calibra­tion and repair, reduce your cost of
ownership, and move us ahead of
your development curve.

www.agilent.com/find/advantageservices

www.agilent.com/quality

For more information on Agilent Technol­ogies’ products, applications or services,
please contact your local Agilent office.

The complete list is available at:

www.agilent.com/find/contactus

Americas

Canada [phone]
Brazil (11) 4197 3500
Mexico 01800 5064 800
United States [phone]

Asia Pacific

Australia 1 800 629 485
China 800 810 0189
Hong Kong 800 938 693
India 1 800 112 929
Japan 0120 (421) 345
Korea 080 769 0800
Malaysia 1 800 888 848
Singapore 1 800 375 8100
Taiwan 0800 047 866
Other AP Countries (65) 375 8100

Europe & Middle East

Belgium 32 (0) 2 404 93 40
Denmark 45 70 13 15 15
Finland 358 (0) 10 855 2100
France 0825 010 700*

*0.125 €/minute

Germany

49 (0) 7031 464 6333
Ireland 1890 924 204
Israel 972-3-9288-504/544
Italy 39 02 92 60 8484
Netherlands 31 (0) 20 547 2111
Spain 34 (91) 631 3300
Sweden 0200-88 22 55
United Kingdom 44 (0) 118 9276201

Microsoft® is a U.S. registered trademark of
Microsoft Corporation.

For other unlisted Countries:

www.agilent.com/find/contactus

Revised: October 14, 2010

Product specifications and descriptions
in this document subject to change
without notice.

© Agilent Technologies, Inc. 2010
Printed in USA, December 16, 2010
5990-4392EN
