Atec Agilent-E4443A, Agilent-E4445A, Agilent-E4440A, Agilent-E4447A, Agilent-E4446A User Manual

40/80 MHz

Analysis Bandwidth

Now Available On

Agilent PSA Series
Spectrum Analyzers

Data Sheet

50 GHz PSA!

The Agilent PSA Series offers high­performance spectrum analysis, up
to 50 GHz, with powerful one-button
measurements, a versatile feature
set, and a leading-edge combination
of flexibility, speed, accuracy, analysis
bandwidth, and dynamic range. From
millimeter wave and phase noise
measurements to spur searches and
modulation analysis, the PSA Series
offers unique and comprehensive
high-performance solutions to R&D
and manufacturing engineers in
cellular and emerging wireless com­munications, aerospace, and defense.

For more information regarding the PSA wide
analysis bandwidth, see the 40/80 MHz BW
digitizers, Option 140/122, technical overview
at www.agilent.com/fi nd/ps

Models

E4443A 3 Hz to 6.7 GHz

E4445A 3 Hz to 13.2 GHz

E4440A 3 Hz to 26.5 GHz*

E4447A 3 Hz to 42.98 GHz

E4446A 3 Hz to 44 GHz*

E4448A 3 Hz to 50 GHz*

* 325 GHz with external mixing

Table of Contents

Defi nitions and Conditions . . . . . .3

Frequency Specifi cations . . . . . . . 4

Frequency range . . . . . . . . . . . . . . . . 4

Frequency reference . . . . . . . . . . . . . 4

Frequency readout accuracy . . . . . . 4

Marker frequency counter . . . . . . . . 4

Frequency span . . . . . . . . . . . . . . . . . 4

Sweep time and triggering . . . . . . . . 5

Sweep (trace) point range . . . . . . . . 5

Gated sweep . . . . . . . . . . . . . . . . . . . 5

Gated FFT . . . . . . . . . . . . . . . . . . . . . 5

Resolution bandwidth (RBW) . . . . . 5

Analysis bandwidth . . . . . . . . . . . . . 6

Video bandwidth (VBW) . . . . . . . . . . 6

Stability . . . . . . . . . . . . . . . . . . . . . . . 6

Amplitude Specifi cations . . . . . . . 7

Amplitude range . . . . . . . . . . . . . . . . 7

Maximum safe input level . . . . . . . . 7

1 dB gain compression (two tone) . 7
Typical gain compression (two tone) . . 7
Displayed average noise level (DANL) . . 8

Display range . . . . . . . . . . . . . . . . . 10

Frequency response . . . . . . . . . . . . 10

Input attenuation switching

uncertainty . . . . . . . . . . . . . . . . . . . 10

Total absolute amplitude accuracy 10
Input voltage standing wave ratio

(VSWR) . . . . . . . . . . . . . . . . . . . . . . 11

Resolution bandwidth switching

uncertainty . . . . . . . . . . . . . . . . . . . 11

Reference level . . . . . . . . . . . . . . . . 11

Display scale switching uncertainty . . .11

Display scale fidelity . . . . . . . . . . . . 11

Spurious response . . . . . . . . . . . . . 11

Second harmonic distortion (SHI) . .12
Third-order intermodulation

distortion (TOI) . . . . . . . . . . . . . . . . 12

Residual responses . . . . . . . . . . . . . 14

Trace detectors . . . . . . . . . . . . . . . . 14

EMI detectors . . . . . . . . . . . . . . . . . 14

Option E444xA-1DS, preamplifier . . .14
Option E444xA-110, preamplifier . . 14

Measurement speed . . . . . . . . . . . . 14

Option AYZ, external mixing . . . . . . 15

Option 123, preselector bypass . . . . 15

Power Suite Measurement

Specifi cations . . . . . . . . . . . . . . . . 16

Channel power . . . . . . . . . . . . . . . . 16

Occupied bandwidth . . . . . . . . . . . . 16

Adjacent channel power . . . . . . . . 16

Multi-carrier power and ACP . . . . . 16

Power statistics CCDF . . . . . . . . . . 16

Harmonic distortion . . . . . . . . . . . . 16

Intermod (TOI) . . . . . . . . . . . . . . . . . 16

Burst power . . . . . . . . . . . . . . . . . . . 16

Spurious emission . . . . . . . . . . . . . 17

Spectrum emission mask (SEM) . . 17

General Specifi cations . . . . . . . . . 18

Temperature range . . . . . . . . . . . . . 18

EMI compatibility . . . . . . . . . . . . . . 18

Audio noise . . . . . . . . . . . . . . . . . . . 18

Military specification . . . . . . . . . . . 18

Power requirements . . . . . . . . . . . . 18

Weight . . . . . . . . . . . . . . . . . . . . . . . 18

Dimensions . . . . . . . . . . . . . . . . . . . 18

Warranty . . . . . . . . . . . . . . . . . . . . . 18

Calibration cycle . . . . . . . . . . . . . . . 18

Input and Outputs . . . . . . . . . . . . . 19

Front panel . . . . . . . . . . . . . . . . . . . 19

Rear panel . . . . . . . . . . . . . . . . . . . . 19

PSA Series Ordering Information 21

PSA Series spectrum analyzer . . . . 21

Options . . . . . . . . . . . . . . . . . . . . . . 21

Related Literature . . . . . . . . . . . . 23

Support, Services, and

Assistance . . . . . . . . . . . . . . . . . . 24

2

Defi nitions and Conditions

Specifications describe the perfor­mance of parameters covered by
the product warranty and apply over
0 to 55 °C unless otherwise noted.
Typical describes additional product
performance information that is not
covered by the product warranty. It is
performance beyond specifications
that 80 percent of the units exhibit
with a 95 percent confidence level
over the temperature range 20 to
30 °C. Typical performance does not
include measurement uncertainty.

Nominal values indicate expected
performance, or describe product
performance that is useful in the
application of the product, but is not
covered by the product warranty.

The analyzer will meet its specifica­tions when:

stored a minimum of two hours

•
within the operating temperature
range and turned on for at least
30 minutes with Auto Align On
selected.

the instrument is within its one

•
year calibration cycle.

Align All Now has been performed

•

within the past 24 hours or when
the temperature changes 3 °C.

the instrument is under auto

•
couple control, except that Auto
Sweep Time = Accy.

DC coupling applied if center

•
frequency is < 20 MHz.

This PSA Series data sheet is a sum­mary of the complete specifications
and conditions, which are available in
the PSA Series Spectrum Analyzers

Specification Guide.

The PSA Series Spectrum Analyzers
Specification Guide can be obtained

on the web through:

www.agilent.com/find/psa

Then follow this selection process:

Select “Technical Support” under

•
Key Library Information

Select “Manuals and Guides”

•

Download specifications guide.

•

3

Frequency Specifi cations

Frequency range

E4443A (DC coupled) 3 Hz to 6.7 GHz (AC coupled) 20 MHz to 6.7 GHz
E4445A (DC coupled) 3 Hz to 13.2 GHz (AC coupled) 20 MHz to 13.2 GHz
E4440A (DC coupled) 3 Hz to 26.5 GHz
E4447A (DC coupled) 3 Hz to 42.98 GHz
E4446A (DC coupled) 3 Hz to 44 GHz
E4448A (DC coupled) 3 Hz to 50 GHz

1. 325 GHz with external mixers

Band Harmonic mixing mode (N)

0 1– 3 Hz to 3 GHz
1 1– 2.85 GHz to 6.6 GHz
2 2– 6.2 GHz to 13.2 GHz
3 4– 12.8 GHz to 19.2 GHz
4 4– 18.7 GHz to 26.8 GHz
5 4+ 26.4 GHz to 31.15 GHz
6 8– 31.0 GHz to 50.0 GHz

Frequency reference

Accuracy ±[(time since last adjustment x aging rate) + temperature stability + calibration accuracy]
Aging rate ± 1 x 10
Temperature stability 20 °C to 30 °C ±1 x 10
Achievable initial calibration accuracy ±7 x 10
Example frequency reference accuracy
1 year after last adjustment

–8

= ±(1 x 1 x 10–7 + 1 x 10–8 + 7 x 10–8)
= ±1.8 x 10

–7

/ year

1

1

1

–8

–7

(AC coupled) 20 MHz to 26.5 GHz

0 °C to 55 °C ±5 x 10

–8

1

Frequency readout accuracy (start, stop, center, marker)

± (marker frequency x frequency reference accuracy + 0.25% x span + 5% x RBW + 2 Hz + 0.5 x horizontal resolution*)

* Horizontal resolution is span/(sweep points – 1)

Marker frequency counter

Accuracy ±(marker frequency x frequency reference accuracy + 0.100 Hz)
Delta counter accuracy ±(delta frequency x frequency reference accuracy + 0.141 Hz)
Counter resolution 0.001 Hz

Frequency span (FFT and swept mode)

Range 0 Hz (zero span), 10 Hz to maximum frequency of model
Resolution 2 Hz

Accuracy ±[0.2% x span + span / (sweep points – 1)]

4

Frequency Specifi cations (continued)

Sweep time and triggering

Range Span = 0 Hz 1 µs to 6000 s

Span ≥ 10 Hz 1 ms to 2000 s

Accuracy Span ≥ 10 Hz, sweep ±0.01% nominal

Span ≥ 10 Hz, FFT ±40% nominal
Span = 0 Hz ±0.01% nominal

Trigger Free run, line, video, RF burst, external

front, external rear, frame (basic mode)

Trigger delay Span = 0 Hz, or FFT –150 ms to +500 ms

Span ≥ 10 Hz, swept 1 µs to 500 ms
Resolution 0.1 µs

Sweep (trace) point range

Span = 0 Hz 2 to 8192
Span ≥ 10 Hz 101 to 8192

Gated sweep

Gate length 10 µs to 500 ms
Gate delay range 0 to 500 ms
Gate delay jitter 33.3 ns p-p nominal

Gated FFT

Delay range –150 to +500 ms
Delay resolution 100 ns or 4 digits whichever is more
Gate duration 1.83/RBW ± 2% nominal

Resolution bandwidth (RBW)

Range (–3.01 dB bandwidth) 1 Hz to 3 MHz (10% steps), 4, 5, 6, 8 MHz
Bandwidth accuracy (power) RBW range 1 Hz to 51 kHz ±0.5% (± 0.022 dB)

56 kHz to 75 kHz ±1.0% (± 0.044 dB)
82 kHz to 330 kHz ±0.5% (± 0.022 dB)
360 kHz to 1.1 MHz (< 3 GHz CF) ±1.0% (± 0.044 dB)

1.2 MHz to 2.0 MHz (< 3 GHz CF) ±0.07 dB nominal

2.2 MHz to 6.0 MHz (< 3 GHz CF) ±0.2 dB nominal
Bandwidth accuracy (–3.01 dB) RBW range 1 Hz to 1.5 MHz ±2% nominal
Selectivity (–60 dB/–3 dB) 4.1:1 nominal
EMI bandwidths (CISPR compliant) 200 Hz, 9 kHz, 120 kHz, 1 MHz
EMI bandwidths (MIL STD 461E compliant) 10 Hz, 100 Hz, 1 kHz, 10 kHz, 100 kHz, 1 MHz

5

Frequency Specifi cations (continued)

SSB

Ph

N

i

(dB

/H

)

Analysis bandwidth

1

Maximum bandwidth

with Option 140
with Option 122

2

2

40 MHz
80 MHz

with Option B7J 10 MHz

1. Analysis bandwidth is the instantaneous bandwidth available around a center frequency over which the input signal can be digitized for further

analysis or processing in the time, frequency, or modulation domain.

2. Not available for E4447A.

Video bandwidth (VBW)

Range 1 Hz to 3 MHz (10% steps), 4, 5, 6, 8 MHz and wide open
Accuracy ±6% nominal

Stability

Noise sidebands

(20 °C to 30 °C, CF = 1 GHz)

Residual FM < (1 Hz X N) p-p in 1 s, typical, see frequency range for N (harmonic number)

3

Offset Specifi cation Typical

100 Hz –91 dBc/Hz –96 dBc/Hz
1 kHz –103 dBc/Hz –108 dBc/Hz
10 kHz –116 dBc/Hz –118 dBc/Hz
30 kHz –116 dBc/Hz –118 dBc/Hz
100 kHz –122 dBc/Hz –124 dBc/Hz
1 MHz –145 dBc/Hz –147 dBc/Hz, –148 dBc/Hz nominal
6 MHz –154 dBc/Hz –156 dBc/Hz, –156.5 dBc/Hz nominal
10 MHz –156 dBc/Hz –157.5 dBc/Hz, –158 dBc/Hz nominal

3. For nominal values, refer to Figure 1.

Nominal Phase Noise at Common Cellular Communication Frequencies,

£ (f) Optimized versus f

–70
–80

z

–90

c

se
o

ase

–100
–110
–120
–130
–140
–150

1 GHz

2 GHz

–160
–170

0.1 1 10 100 1000 10000

Offset Frequency (kHz)

Figure 1. Nominal phase noise at common cellular frequencies

6

Amplitude Specifi cations

Amplitude range

Measurement range Displayed average noise level (DANL) to maximum safe input level
Input attenuator range (3 Hz to 50 GHz) 0 to 70 dB in 2 dB steps

Maximum safe input level

Average total power +30 dBm (1 W)

Preamp (Option E444xA-1DS) +30 dBm

Preamp (Option E444xA-110) +23 dBm
Peak pulse power < 10 µs pulse width, < 1% duty cycle and input attenuation ≥ 30 dB +50 dBm (100 W)
DC volts DC coupled < ±0.2 Vdc AC coupled (E4443A, E4445A, E4440A only) ±100 Vdc

1 dB gain compression (two-tone)

Total power at input mixer
20 MHz to 200 MHz 0 dBm +3 dBm nominal
200 MHz to 3 GHz +3 dBm +7 dBm nominal
3 GHz to 6.6 GHz +3 dBm +4 dBm nominal

6.6 GHz to 26.5 GHz –2 dBm 0 dBm nominal

26.5 GHz to 50 GHz 0 dBm nominal

Preamp on (Option E444xA-1DS) 10 MHz to 200 MHz –30 dBm nominal

200 MHz to 3 GHz –25 dBm nominal

Preamp on (Option E444xA-110) 10 MHz to 200 MHz –24 dBm nominal

200 MHz to 3 GHz –20 dBm nominal

3.0 GHz to 6.6 GHz –23 dBm nominal

6.6 GHz to 30 GHz –27 dBm nominal
30 GHz to 50 GHz –24 dBm nominal

Typical gain compression (two-tone)

Mixer level Compression
20 MHz to 200 MHz 0 dBm < 0.5 dB
200 MHz to 6.6 GHz +3 dBm < 0.5 dB

6.6 GHz to 26.5 GHz –2 dBm < 0.4 dB

7

Amplitude Specifi cations (continued)

Displayed average noise level (DANL)

(Input terminated, sample or average detector, averaging type = Log, 20 to 30 °C)

Zero span and swept
normalized to 1 Hz
RBW and 0 dB
attenuation

E4443A/E4445A/E4440A 3 Hz to 1 kHz — –110 dBm nominal —

1 kHz to 10 kHz — –130 dBm nominal —
10 kHz to 100 kHz –137 dBm –141 dBm –137 dBm
100 kHz to 1 MHz –145 dBm –149 dBm –145 dBm
1 MHz to 10 MHz –150 dBm –153 dBm –150 dBm
10 MHz to 1.2 GHz –154 dBm –155 dBm –154 dBm

1.2 GHz to 2.1 GHz –153 dBm –154 dBm –153 dBm

2.1 GHz to 3.0 GHz –152 dBm –153 dBm –152 dBm
3 GHz to 6.6 GHz –152 dBm –153 dBm –151 dBm

6.6 GHz to 13.2 GHz –150 dBm –152 dBm –149 dBm

13.2 GHz to 20 GHz –147 dBm –149 dBm –146 dBm
20 GHz to 26.5 GHz –143 dBm –145 dBm –143 dBm

Preamp ON (Option 1DS) 100 kHz to 200 kHz –159 dBm –162 dBm –158 dBm

200 kHz to 500 kHz –159 dBm –162 dBm –158 dBm
500 kHz to 1 MHz –163 dBm –165 dBm –162 dBm
1 MHz to 10 MHz –166 dBm –168 dBm –165 dBm
10 MHz to 500 MHz –169 dBm –170 dBm –168 dBm
500 MHz to 1.1 GHz –168 dBm –169 dBm –167 dBm

1.1 GHz to 2.1 GHz –167 dBm –168 dBm –166 dBm

2.1 GHz to 3.0 GHz –165 dBm –166 dBm –165 dBm

Preamp ON (Option 110) 10 to 50 MHz –148 dBm –154 dBm –148 dBm

50 to 500 MHz –153 dBm –164 dBm –153 dBm
500 MHz to 2.1 GHz –166 dBm –168 dBm –166 dBm

2.1 to 3 GHz –166 dBm –168 dBm –166 dBm
3 to 6.6 GHz –165 dBm –166 dBm –165 dBm

6.6 to 13.2 GHz –163 dBm –165 dBm –163 dBm

13.2 to 16 GHz –162 dBm –165 dBm –162 dBm
16 to 19 GHz –162 dBm –164 dBm –162 dBm
19 to 26.5 GHz –159 dBm –161 dBm –159 dBm

Zero span and swept
normalized to 1 Hz
RBW 0 dB
attenuation (typical)

FFT only actual 1 Hz
RBW 0 dB attenuation

8

Amplitude Specifi cations (continued)

Displayed average noise level (DANL)

(Input terminated, sample or average detector, averaging type = Log, 20 to 30 °C) continued

Zero span and swept
normalized to 1 Hz
RBW and 0 dB
attenuation

E4447A/E4446A/E4448A 3 Hz to 1 kHz — –110 dBm nominal —

1 kHz to 10 kHz — –130 dBm nominal —
10 kHz to 100 kHz –137 dBm –141 dBm –137 dBm
100 kHz to 1 MHz –145 dBm –150 dBm –145 dBm
1 MHz to 10 MHz –150 dBm –155 dBm –150 dBm
10 MHz to 1.2 GHz –153 dBm –154 dBm –152 dBm

1.2 GHz to 2.1 GHz –152 dBm –153 dBm –151 dBm

2.1 GHz to 3 GHz –151 dBm –152 dBm –150 dBm
3 GHz to 6.6 GHz –151 dBm –152 dBm –150 dBm

6.6 GHz to 13.2 GHz –146 dBm –149 dBm –146 dBm

13.2 GHz to 20 GHz –144 dBm –146 dBm –143 dBm
20 GHz to 22.5 GHz –143 dBm –146 dBm –143 dBm

22.5 GHz to 26.8 GHz –140 dBm –144 dBm –140 dBm

26.8 GHz to 31.15 GHz –142 dBm –145 dBm –141 dBm

31.15 GHz to 35 GHz –134 dBm –136 dBm –133 dBm
35 GHz to 38 GHz –129 dBm –132 dBm –129 dBm
38 GHz to 44 GHz –131 dBm –134 dBm –131 dBm
44 GHz to 49 GHz –128 dBm –131 dBm –127 dBm
49 GHz to 50 GHz –127 dBm –130 dBm –126 dBm

Preamp ON (Option 1DS) 100 kHz to 200 kHz –158 dBm –162 dBm –157 dBm

200 kHz to 500 kHz –158 dBm –162 dBm –157 dBm
500 kHz to 1 MHz –161 dBm –165 dBm –160 dBm
1 MHz to 10 MHz –167 dBm –169 dBm –166 dBm
10 MHz to 500 MHz –167 dBm –169 dBm –167 dBm
500 MHz to 1.2 GHz –166 dBm –168 dBm –166 dBm

1.2 GHz to 2.1 GHz –165 dBm –167 dBm –165 dBm

2.1 GHz to 3.0 GHz –163 dBm –165 dBm –163 dBm

Preamp ON (Option 110) 10 to 50 MHz –148 dBm –158 dBm –148 dBm

50 to 500 MHz –153 dBm –164 dBm –153 dBm
500 MHz to 1.2 GHz –165 dBm –168 dBm –165 dBm

1.2 to 2.1 GHz –165 dBm –168 dBm –165 dBm

2.1 to 3 GHz –165 dBm –167 dBm –165 dBm
3 to 6.6 GHz –165 dBm –167 dBm –165 dBm

6.6 to 13.2 GHz –162 dBm –165 dBm –162 dBm

13.2 to 19 GHz –161 dBm –163 dBm –161 dBm
19 to 22.5 GHz –161 dBm –162 dBm –161 dBm

22.5 to 26.8 GHz –155 dBm –160 dBm –155 dBm

26.8 to 31.15 GHz –157 dBm –161 dBm –157 dBm

31.15 to 35 GHz –152 dBm –156 dBm –152 dBm
35 to 38 GHz –146 dBm –150 dBm –146 dBm
38 to 41 GHz –146 dBm –150 dBm –146 dBm
41 to 44 GHz –146 dBm –150 dBm –146 dBm
44 to 45 GHz –143 dBm –150 dBm –143 dBm
45 to 49 GHz –143 dBm –146 dBm –143 dBm
49 to 50 GHz –140 dBm –145 dBm –140 dBm

Zero span and swept
normalized to 1 Hz
RBW and 0 dB
attenuation (typical)

FFT only actual 1 Hz
RBW 0 dB attenuation

9

Amplitude Specifi cations (continued)

Display range

Log scale 0.1 to 1 dB/division in 0.1 dB steps 1 to 20 dB/division in 1 dB steps (10 display divisions)
Linear scale 10 divisions
Scale units dBm, dBmV, dBµV, dBmA, dBµA, V, W, A, dBµV/m, dBµA/m, dBpT, dBG

Frequency response (10 dB input attenuation, 20 to 30 °C, preselector centering applied above 3 GHz)

E4443A/E4445A/E4440A 3 Hz to 3 GHz ±0.38 dB (±0.11 dB typical)

3 GHz to 6.6 GHz ±1.50 dB (±0.6 dB typical)

6.6 GHz to 22 GHz ±2.00 dB (±1.0 dB typical)
22 GHz to 26.5 GHz ±2.50 dB (±1.3 dB typical)

E4447A/E4446A/E4448A 3 Hz to 3 GHz ±0.38 dB (±0.15 dB typical)

3 GHz to 6.6 GHz ±1.50 dB (±0.6 dB typical)

6.6 GHz to 22 GHz ±2.00 dB (±1.2 dB typical)
22 GHz to 26.8 GHz ±2.50 dB (±1.3 dB typical)

26.4 GHz to 31.15 GHz ±1.75 dB (±0.6 dB typical)

31.15 GHz to 50 GHz ±2.50 dB (±1.0 dB typical)
Frequency response at attenuation ≠ 10 dB
(Atten = 20, 30, or 40 dB)
Preamp on (Option E444xA-1DS),
(for all models)
Preamp on (Option E444xA-110,
0 dB input attenuation)
E4443A/E4445A/E4440A

E4447A/E4446A/E4448A 10 MHz to 3.05 GHz ±1.3 dB (±0.5 dB typical)

10 MHz to 2.2 GHz ±0.53 dB

2.2 GHz to 3 GHz ±0.69 dB

100 kHz to 3 GHz ±0.70 dB < (±0.30 dB typical)

10 MHz to 3.0 GHz ±1.0 dB (±0.35 dB typical)

3.0 to 6.6 GHz ±1.75 dB (±0.8 dB typical)

6.6 to 13.2 GHz ±3.0 dB (±1.0 dB typical)

13.2 to 19 GHz ±3.0 dB (±1.2 dB typical)

19 to 26.5 GHz ±4.0 dB (±2.0 dB typical)

3.0 to 6.6 GHz ±2.5 dB (±1.0 dB typical)

6.6 to 13.2 GHz ±2.5 dB (±1.2 dB typical)

13.2 to 19 GHz ±3.0 dB (±1.5 dB typical)

19 to 26.5 GHz ±4.0 dB (±2.0 dB typical)

26.5 to 31.15 GHz ±3.0 dB (±1.2 dB typical)

31.15 to 50 GHz ±3.5 dB (±1.6 dB typical)

Input attenuation switching uncertainty (Attenuator setting ≥ 2 dB)

At 50 MHz ±0.18 dB ±0.053 dB typical
3 Hz to 3 GHz ±0.3 dB nominal
3 GHz to 13.2 GHz ±0.5 dB nominal

13.2 GHz to 26.5 GHz ±0.7 dB nominal

26.5 GHz to 50 GHz ±1.0 dB nominal

Total absolute amplitude accuracy (10 dB attenuation, 20 to 30 °C, 10 Hz ≤ RBW ≤ 1 MHz, input signal –10 to –50 dBm,
all settings auto-coupled except Auto Swp Time = Accy, any reference level, any scale)

At 50 MHz ±0.24 dB (±0.06 dB typical)
At all frequencies ±(0.24 dB + frequency response), ±(0.06 dB+

frequency response) typical

3 Hz to 3 GHz (95% confi dence) ±0.19 dB
Preamp on (Option E444xA-1DS) ± (0.36 dB + frequency response), ±(0.09 dB+ frequency response) typical
Preamp on (Option E444xA-110) ± (0.40 dB + frequency response), ±(0.15dB + frequency response) typical

10

Amplitude Specifi cations (continued)

Input voltage standing wave ratio (VSWR) (≥ 8 dB input attenuation)

50 MHz to 3 GHz < 1.2:1 nominal
3 GHz to 18 GHz < 1.6:1 nominal
18 GHz to 26.5 GHz < 1.9:1 nominal

26.5 GHz to 50 GHz < 1.57:1 nominal
Preamp on (50 MHz to 3 GHz) (≥ 10 dB
attenuation)
Preamp on (Option E444xA-110)
(> 10 dB input attenuation)
E4443A/E4445A/E4440A

E4447A/E4446A/E4448A 200 MHz to 6.6 GHz < 1.2:1

Resolution bandwidth switching uncertainty (referenced to 30 kHz RBW)

1 Hz to 1 MHz RBW ±0.03 dB

1.1 MHz to 3 MHz RBW ±0.05 dB
4, 5, 6, 8 MHz RBW ±1.0 dB

< 1.2:1 nominal

200 MHz to 6.6 GHz < 1.4:1

6.6 to 13.2 GHz < 1.7:1

13.2 to 19.2 GHz < 1.5:1

19.2 to 26.5 GHz < 1.8:1

6.6 to 13.2 GHz < 1.4:1

13.2 to 19.2 GHz < 1.3:1

19.2 to 31 GHz < 1.5:1

31 to 50 GHz < 1.7:1

Reference level

Range Log scale –170 dBm to +30 dBm in 0.01 dB steps

Linear scale 707 pV to 7.07 V in 0.1% steps

Accuracy 0 dB

Display scale switching uncertainty

Switching between linear and log 0 dB
Log scale/div switching 0 dB

Display scale fi delity

≤ –20 dBm input mixer level ±0.07 dB total
–20 dBm < mixer level ≤ –10 dBm ±0.13 dB total

Spurious response (mixer level = –40 dBm)

General spurious 100 Hz ≤ f < 10 MHz from carrier (–73 + 20 log N) dBc

f ≥ 10 MHz from carier (–80 + 20 log N) dBc, (–90 + 20 log N) dBc typical

See frequency range for N

11

Amplitude Specifi cations (continued)

Second harmonic distortion (SHI)

E4443A/E4445A/E4440A Distortion (dBc) SHI (dBm)

10 MHz to 460 MHz (–40 dBm mixer level) –82 +42
460 MHz to 1.18 GHz (–40 dBm mixer level) –92 +52

1.18 GHz to 1.5 GHz (–40 dBm mixer level) –82 +42

1.5 GHz to 2.0 GHz (–10 dBm mixer level) –90 +80

2.0 GHz to 13.25 GHz (–10 dBm mixer level) –100 +90

E4447A/E4446A/E4448A 10 MHz to 460 MHz (–40 dBm mixer level) –82 +42

460 MHz to 1.18 GHz (–40 dBm mixer level) –92 +52

1.18 GHz to 1.5 GHz (–40 dBm mixer level) –82 +42

1.5 GHz to 2.0 GHz (–10 dBm mixer level) –90 +80

2.0 GHz to 3.25 GHz (–10 dBm mixer level) –94 +84

3.25 GHz to 13.25 GHz (–10 dBm mixer level) –96 +86

13.25 GHz to 25 GHz (–10 dBm mixer level) –100 nominal +90 nominal
Preamp on (Option E444xA-1DS),
for all models
Preamp on (Option E444xA-110),
for all models

Third-order intermodulation distortion

(TOI) (two –30 dBm tones at input mixer with tone separation > 15 kHz, 20 to 30 °C )

E4443A/E4445A/E4440A Distortion (dBc) TOI (dBm)

E4447A/E4446A/E4448A 10 MHz to 100 MHz –90 +15 (+20 typical)

Preamp on (Option E444xA-1DS),
(for all models, two –45 dBm tones
at preamp input)

Preamp on (Option E444x-110),
(two –45 dBm tones at preamp input)
E4443A/E4445A/E4440A

E4447A/E4446A/E4448A 10 MHz to 3 GHz –15 dBm nominal

10 MHz to 1.5 GHz (–45 dBm at preamp input) –60 nominal +15 nominal

10 to 460 MHz (–45 dBm at preamp input) –55 nominal +10 nominal
460 MHz to 25 GHz (–45 dBm at preamp input) –60 nominal +15 nominal

10 MHz to 100 MHz –88 +14 (+17 typical)
100 MHz to 400 MHz –90 +15 (+18 typical)
400 MHz to 1.7 GHz –92 +16 (+19 typical)

1.7 GHz to 2.7 GHz –94 +17 (+19 typical)

2.7 GHz to 3.0 GHz –94 +17 (+20 typical)

3.0 GHz to 6.0 GHz –90 +15 (+18 typical)

6.0 GHz to 16 GHz –76 +8 (+11 typical)

16 GHz to 26.5 GHz –84 +12 (+14 typical)

100 MHz to 400 MHz –92 +16 (+21 typical)
400 MHz to 1.7 GHz –94 +17 (+20 typical)

1.7 GHz to 2.7 GHz –96 +18 (+21 typical)

2.7 GHz to 3.0 GHz –96 +18 (+21 typical)

3.0 GHz to 6.0 GHz –92 +16 (+21 typical)

6.0 GHz to 16 GHz –84 +12 (+15 typical)

16.0 GHz to 26.5 GHz –84 +12 (+16 typical)

26.5 GHz to 50 GHz –85 nominal +12.5 nominal

10 MHz to 500 MHz –15 nominal
500 MHz to 3 GHz –13 nominal

10 MHz to 3 GHz –15 dBm nominal
3 to 6.6 GHz –21 dBm nominal

6.6 to 13.2 GHz –23 dBm nominal

13.2 to 19 GHz –23 dBm nominal

19 to 26.5 GHz –25 dBm nominal

3 to 6.6 GHz –21 dBm nominal

6.6 to 13.2 GHz –23 dBm nominal

13.2 to 19 GHz –23 dBm nominal

19 to 26.5 GHz –25 dBm nominal

12

Amplitude Specifi cations (continued)

Nominal Dymamic Range

Band 0

–60

–70

DANL (1 HZ RBW)
Second Harmonic Distortion
Third Order Distortion

–80

–90

1.25 to 1.5 GHz

400 MHz to 1.25 GHz

–100

to mixer level (dB)

–110

DANL and distortion relative

–120

–130

–80 –70 –60 –50 –40 –30 –20 –10

Mixer Level (dBm)

Figure 2. Nominal dynamic range – Band 0, for second and third
order distortion, E4443A, E4445A, and E4440A – 3 Hz to 3 GHz

Nominal Dymamic Range

Bands 1 to 4

–60

DANL (1 HZ RBW)
Second Harmonic Distortion

–70

–80

–90

Third Order Distortion

20 to 26.5 GHz

13.2 to 20 GHz

6.6 to 13.2 GHz

3.0 to 6.6 GHz

6 to 16 GHz

16 to 26.5 GHz

3 to 6 GHz

–100

to mixer level (dB)

–110

DANL and distortion relative

–120

1.5 to 2.0 GHz

2.0 GHz to 13.25 GHz

–130

–80 –70 –60 –50 –40 –30 –20 –10

Mixer Level (dBm)

Figure 3. Nominal dynamic range – Bands 1 to 4, second and third
order distortion, E4443A, E4445A, E4440A – 3 GHz to 26.5 GHz

Nominal dynamic range

for second- and third-order distortion bands 5 and 6

26.5 GHz to 50 GHz

TOI = +12.5 dBm

-50

-60

DANL = -127 dBm, RBW

DANL = -129 dBm

-70

DANL = -141 dBm, RBW = 1 Hz, 26.4 to 31.15 GHz

-80

Dynamic range dBc

-90

-100

, RBW = 1 Hz, 31.15 to 44 GHz

= 1

Hz, 44 to 50 GHz

SOI = +90 dBM

-110

-70 -60 -50 -40 -30 -20 -10

Mixer level (dBm)

[Input level minus attenuator setting]

Figure 4. Nominal dynamic range – Bands 5 to 6, E4447A, E4446A,
and E4448A 26.4 GHz to 50 GHz

13

Amplitude Specifi cations (continued)

Residual responses

Input terminated and 0 dB attenuation 200 kHz to 6.6 GHz –100 dBm

6.6 GHz to 26.8 GHz –100 dBm nominal

26.8 GHz to 50 GHz –90 dBm nominal

Trace detectors

Normal, peak, sample, negative peak, log power average, RMS average, and voltage average

EMI detectors

CISPR Peak, quasi-peak and average
MIL-STD Peak

Option E444xA-1DS, preamplifi er

Frequency range 100 kHz to 3 GHz
Gain 28 dB nominal
Noise fi gure 7 dB nominal

Option E444xA-110, preamplifi er

Frequency range 10 MHz to 50 GHz
Gain 10 MHz to 30 GHz 27 dB (nominal)

30 to 50 GHz 24 dB (nominal)

Noise fi gure 10.0 MHz to 30 MHz 12.5 dB (nominal)

30 MHz to 3 GHz 7.8 dB (nominal)
3 to 30 GHz 10.3 dB (nominal)
30 to 50 GHz 21.8 dB (nominal)

Measurement speed

Local measurement and display update rate ≥ 50/s nominal
Remote measurement and GPIB transfer rate 101 sweep points ≥ 45/s nominal

401 sweep points ≥ 30/s nominal
601 sweep points ≥ 25/s nominal

14

Other Specifi cations

Option AYZ, external mixing

Frequency range 18 to 325 GHz (to 110 GHz with the Agilent unpreselected mixer)
LO output

Frequency range 3.05 GHz to 6.89 GHz
Power output (20 to 30 °C) E4440A 14.5 dBm min 18.5 dBm max

E4446A and E4448A 3.05 to 3.2 GHz 14.5 dBm min 20 dBm max

3.2 to 6.7 GHz 14.5 dBm min 18.8 dBm max

6.7 to 6.89 GHz 14.5 dBm min 18.5 dBm max typical

VSWR 2.0:1 nominal

IF input

Frequency 321.4 MHz, ±30 MHz
Maximum safe input range 10 dBm
Absolute amplitude accuracy ± 1.2 dB (20 to 30 °C)
VSWR 1.5:1 nominal

Mixer bias current

Range ± 10 mA
Resolution 0.01 mA
Accuracy ± 0.02 mA nominal
Output impedance 477 Ω nominal

Mixer bias voltage

Range ± 3.7 V (open circuit)

Preselector tune voltage 1.5 V/GHz of LO nominal

Option 123, preselector bypass

Frequency range

E4440A 3.05 to 26.5 GHz

E4443A 3.05 to 6.7 GHz

E4445A 3.05 to 13.2 GHz

E4446A 3.05 to 44 GHz

E4447A 3.05 to 42.98 GHz

E4448A 3.05 to 50 GHz

1. When the preselector bypass option is installed and enabled, some aspects of the analyzer performance change.

Please refer to the PSA specifi cation guide for more details.

1

15

Power Suite Measurement Specifi cations

Channel power

Amplitude accuracy, W-CDMA or IS95
(20 to 30 °C, mixer level < –20 dBm)

Occupied bandwidth

Frequency accuracy ±[span/600] nominal

Adjacent channel power

Accuracy, W-CDMA (ACLR)
(at specifi c mixer levels and ACLR ranges)

MS ±0.12 dB ±0.17 dB
BTS ±0.22 dB ±0.22 dB
Dynamic range (typical)
Without noise correction –74.5 dB –82 dB
With noise correction
Offset channel pairs measured ACP
speed (fast method). Data measurement
and transfer time 30 ms nominal (0.2 dB
standard deviation)

Multi-carrier power and ACP

ACPR dynamic range, W-CDMA
(5 MHz offset, RRC weighted, 3.84 MHz
noise bandwidth)

Two carriers –70 dB nominal
Four carriers –66 dB nominal
With noise correction –76 dB nominal

ACPR accuracy
(two carriers, 5 MHz offset, –48 dBc ACPR)
Multiple number of carriers measured Up to 12

±0.68 dB ( ±0.18 dB typical)

Adjacent Alternate

–81 dB –88 dB
1 to 6

±0.38 dB nominal

Power statistics CCDF

Histogram resolution 0.1 dB

Harmonic distortion

Maximum harmonic number 10th
Results Fundamental power (dBm), relative harmonics power (dBc), total harmonic distortion in %

Intermod (TOI)

Measure the third-order products and intercepts from two tones

Burst power

Methods Power above threshold, power within burst width
Results Single burst output power, average output power, maximum power, minimum power

within burst, burst width

16

Power Suite Measurement Specifi cations (continued)

Spurious emission

W-CDMA (1980 MHz region, 1.2 MHz RBW)
Table driven spurious signals; search across
regions.

Relative dynamic range 80.6 dB (82.4 dB typical)
Absolute sensitivity –89.7 dBm (–91.7 dBm typical)

Spectrum emission mask (SEM)

cdma2000® (750 kHz offset)

Relative dynamic range (30 kHz RBW) 85.3 dB (88.3 dB typical)
Absolute sensitivity –105.7 dBm (–107 dBm typical)
Relative accuracy ±0.09 dB

3GPP W-CDMA (2.515 MHz offset)

Relative dynamic range (30 kHz RBW) 87.3 dB (89.5 dB typical)
Absolute sensitivity –105.7 dBm (–107.7 dBm typical)
Relative accuracy ±0.10 dB

17

General Specifi cations

Temperature range

Operating 0 °C to +55 °C
Storage –40 °C to +70 °C

EMI compatibility

Radiated and conducted emission is in compliance with CISPR Pub 11/1996 Class B

Radiated immunity

Complies with the radiated electromagnetic fi eld immunity requirements in IEC/EM 61326 using performance criteria B.

Audio noise

ISO 7779 sound pressure Lp < 55 dBA

Environmental conditions

Samples of this product have been type tested in accordance with the Agilent Environmental Test manual and veifi ed to be robust
against the environmental stresses of storage, transportation and end-use, those stresses include but are not limited to temperature,
humidity, shock, vibration, altitude and power line conditions.

Test methods are aligned with IEC 60068-2 and levels are similar to MIL-PRF-28800F Class 3.

Power requirements

Voltage and frequency (nominal) 100 to 120 V, 50/60/400 Hz

200 to 240 V, 50/60 Hz

Power consumption

On < 260 watts, no options, (< 450 watts, all options)
Standby < 20 watts

Data storage

Internal 512 MB (nominal)
Floppy drive (10 to 40 °C) 3.5” 1.44 MB

(nominal)

Weight (without options)

E4443A/E4445A/E4440A

E4447A/E4446A/E4448A

Net
Shipping
Net
Shipping

23 kg (50 lbs) nominal
33 kg (73 lbs) nominal
24 kg (53 lbs) nominal
33 kg (73 lbs) nominal

Dimensions

Height 177 mm (7.0 in)
Width 426 mm (16.8 in)
Length 483 mm (19 in)

Warranty

The E4440A, E4443A, E4445A, E4446A, E4447A, and E4448A are supplied with a one-year standard warranty.

Calibration cycle

The recommended calibration cycle is two years. Calibration services are available through Agilent service centers.

18

Inputs and Outputs

Front panel

RF input

Connector
E4443A/E4445A Type-N female, 50 Ω
E4440A Type-N female, 50 Ω
Option E4440A-BAB APC 3.5 male
E4447A/E4446A/E4448A 2.4 mm male, 50 Ω

Probe power

Voltage/current (nominal) +15 Vdc, ±7% at 150 mA max

–12.6 Vdc, ±10% at 150 mA max

Ext trigger input

Connector BNC female
Impedance 10 kΩ nominal
Trigger level range –5 to +5 V

1st LO output (Option AYZ)

Connector SMA female
Frequency range 3 to 7 GHz

IF input (Option AYZ)

Connector SMA female
Frequency 321.4 MHz

Rear panel

10 MHz OUT (switched)

Connector BNC female, 50 Ω
Output amplitude ≥ 0 dBm nominal
Frequency accuracy 10 MHz ± (10 MHz x frequency reference accuracy)

Ext Ref In

Connector BNC female, 50 Ω
Input amplitude range –5 to +10 dBm nominal
Input frequency 1 to 30 MHz nominal
Frequency lock range ± 5 x 10-6 of specifi ed external reference input frequency

Trigger in

Connector BNC female
External trigger input Impedance > 10 kΩ nominal

Trigger level range –5 to +5 V

Trigger 1 and Trigger 2 outputs

Connector BNC female
Trigger 1 output HSWP (high = sweeping)

Impedance 50 Ω nominal
Level 5 V TTL

Trigger 2 output Gate

19

Inputs and Outputs (continued)

Rear panel (continued)

Monitor output

Connector VGA compatible, 15-pin mini D-SUB
Format VGA (31.5 kHz horizontal, 60 Hz vertical sync rates, non-interlaced) Analog RGB
Resolution 640 X 480

Noise source drive output (used by Option 219)

Connector BNC female
Output voltage On 28.0 ± 0.1 V (60 mA maximum)

Off < 1 V

Remote programming

GPIB interface Connector IEEE-488 bus connector

GPIB codes SH1, AH1, T6, SR1, RL1, PP0, DC1, C1, C2, C3, and C28, DT1, L4, C0
Serial interface connector 9-pin D-SUB male (factory use only)
LAN TCP/IP interface RJ45 Ethertwist
USB interface (Option 111, standard) Slave mode/device-side only, USB 2.0 compliant, type B connector

Parallel printer interface connector 25-pin D-SUB female

321.4 MHz IF output
Connector SMA female, 50 Ω nominal
Frequency 321.4 MHz nominal
Conversion gain

Low band (3 Hz to 3.05 GHz) • +2 to +4 dB nominal
High/mm band (2.85 GHz to

• –6 to –8 dB nominal

PSA’s upper frequency limit)
High/mm band (2.85 GHz to

• –9 to –17 dB nominal

PSA’s upper frequency limit);
preselector off (Opt 123)

Bandwidth (-3 dBm)

Low band (3 Hz to 3.05 GHz)• 40 MHz or 60 MHz 2 nominal
High band (2.85 to 26.5 GHz)• 35 to 70 MHz
mm band (26.5 to 50 GHz)• 40 MHz or 60 MHz 2 nominal
High/mm band (2.85 GHz to

• 240 MHz nominal

PSA’s upper frequency limit);
preselector off (Option 123)

Pre-sel tune output

Connector BNC female

1

3

nominal

1. Not available for the E4447A.

2. 40 MHz standard, 60 MHz with Option 122 or 140 installed in instrument. When Option 122 or 140 is installed, the IF output signal

is now centered at 300 MHz and the BW of the output centered at 300 MHz is approximately 95 MHz.

3. The bandwidth in the microwave preselected bands increases approximately monotonically between the lowest and highest tuned

frequencies. Refer to the PSA Specifi cations Guide (E4440-90606) for more details.

20

PSA Series Ordering Information

For further information, refer to PSA Confi guration Guide, 5989-2773EN

PSA Series spectrum analyzer

E4443A 3 Hz to 6.7 GHz
E4445A 3 Hz to 13.2 GHz
E4440A 3 Hz to 26.5 GHz
E4447A 3 Hz to 42.98 GHz
E4446A 3 Hz to 44 GHz
E4448A 3 Hz to 50 GHz

Options

To add options to a product, use the
following ordering scheme:
Model E444xA (x = 0, 3, 5, 6, 7 or 8)
Example options E4440A-B7J,

E4448A-1DS

Warranty & Service

Standard warranty is one year.
R-51B-001-3C 1-year return-to-

Agilent warranty
extended to 3 years

Calibration

Recommended calibration cycle is two years

R-50C-011-3 Inclusive calibration

R-50C-013-3

E444xA-0BW Service manual
E444xA-UK6 Commercial calibration

E444xA-A6J Factory ANSI Z540

E444xA-1A7 Factory ISO 17025

R-52A Calibration software

N7810A PSA Series calibration

1

plan, 3 year coverage
Inclusive calibration

plan and cal data,
3 year coverage

certifi cate with test
data

standard-compliant
calibration

standard-compliant
calibration

and licensing (ordered
with PSA)

application software
(stand-alone order)

Measurement Personalities

E444xA-226 Phase noise
E444xA-219 Noise fi gure Requires Option IDS or 110

to meet specifi cations
E444xA-241 Flexible digital modulation analysis
E444xA-BAF W-CDMA Requires B7J
E444xA-210 HSDPA/HSUPA (for W-CDMA) Requires B7J and BAF
E444xA-202 GSM w/ EDGE Requires B7J
E444xA-B78 cdma2000 Requires B7J
E444xA-214 1xEV-DV Requires B7J and B78
E444xA-204 1xEV-DO Requires B7J
E444xA-BAC cdmaOne Requires B7J
E444xA-BAE NADC, PCD Requires B7J
E444xA-217 WLAN Requires 122 or 140
E444xA-211 TD-SCDMA power measurement
E444xA-212 TD-SCDMA modulation
E444xA-213 HSPA for TD-SCDMA Requires Option 212
E444xA-215 External source control
E444xA-266 Programming code compatibility suite
E444xA-233 Built-in measuring receiver personality
E444xA-23A AM/FM/PM triggering Requires Option 233
E444xA-23B CCITT fi lter
E444xA-239 N9039A RF preselector control

Requires Option 233

1. Options not available in all countries

21

PSA Series Ordering Information (continued)

For further information, refer to PSA Confi guration Guide, 5989-2773EN

Hardware

E444xA-1DS RF internal preamplifi er

(100 kHz to 3 GHz)

E444xA-110 RF/µW internal preamplifi er (10 MHz

to upper frequency limit of the PSA)
E444xA-B7J Digital demodulation hardware
E444xA-122 80 MHz bandwidth digitizer E4440A/43A/45A/46A/48A,

E444xA-140 40 MHz bandwidth digitizer E4440A/43A/45A/46A/48A,

E444xA-123 Switchable MW preselector bypass

E444xA-124 Y-axis video output
E444xA-AYZ External mixing

E444xA-107 Audio input 100 kΩ Requires 233 to operate;

E444xA-111 USB device side I/O interface Shipped standard in all PSA
E444xA-115 512 MB user memory

E444xA-117 Secure memory erase Excludes 115
E4440A-BAB Replaces type-N input connector

with APC 3.5 connector
E444xA-H70 70 MHz IF output Excludes 122, 140. Not

E444xA-HYX 21.4 MHz IF output Available for all PSA models
E444xA-HY3 Switched LO for Options AYZ and 123 For E4446A/48A only

Excludes 110

Excludes 1DS

excludes 140, 107, H70

excludes 122, 107, H70
Excludes AYZ (For E4446A/

48A, Option HY3 allows
coexistance of 123 and AYZ)

E4440A/47A/46A/48A only,
excludes 123 (For E4446A/
48A, Option HY3 allows
coexistance of 123 and AYZ)

excludes 122, 140

instruments with serial
number prefi x ≥ MY4615
unless 117 license is activated

available for E4447A

PC Software

E444xA-230

E444xA-235

BenchLink Web Remote Control

Software

Wide BW digitizer external

calibration wizard

Requires 122 or 140
E4443A/45A/40A/46A/48A

Accessories

E444xA-1CM Rack mount kit
E444xA-1CN Front handle kit
E444xA-1CP Rack mount with handles
E444xA-1CR Rack slide kit
E444xA-015 6 GHz return loss measurement accessory kit
E444xA-045 Millimeter wave accessory kit
E444xA-0B1 Extra manual set including CD ROM

22

Related Literature

Publication Title Publication Type Publication Number

PSA in general

Selecting the Right Signal Analyzer for Your Needs
PSA Series
PSA Series
Self-Guided Demonstration for Spectrum Analysis

Wide bandwidth and vector signal analysis

40/80 MHz Bandwidth Digitizer
Using Extended Calibration Software for Wide Bandwidth Measurements,
PSA Option 122 & 89600 VSA
PSA Series Spectrum Analyzer Performance Guide Using 89601A Vector Signal
Analysis Software
89650S Wideband VSA System with High Performance Spectrum Analysis

Measurement personalities and applications

Phase Noise Measurement Personality
Noise Figure Measurement Personality
External Source Measurement Personality
Flexible Digital Modulation Analysis Measurement Personality
W-CDMA and HSDPA/HSUPA Measurement Personalities
GSM with EDGE Measurement Personality
cdma2000
1xEV-DO Measurement Personality
cdmaOne Measurement Personality
WLAN Measurement Personality
NADC/PDC Measurement Personality
TD-SCDMA Measurement Personality
Built-in Measuring Receiver Personality/Agilent N5531S Measuring Receiver
BenchLink Web Remote Control Software
IntuiLink Software
Programming Code Compatibility Suite

®

and 1xEV-DV Measurement Personalities

Selection Guide 5968-3413E
Brochure 5980-1284E
Confi guration Guide 5989-2773EN
Product Note 5988-0735EN

Technical Overview 5989-1115EN
Application Note 1443 5988-7814EN

Product Note 5988-5015EN

Technical Overview 5989-0871EN

Technical Overview 5988-3698EN
Technical Overview 5988-7884EN
Technical Overview 5989-2240EN
Technical Overview 5989-1119EN
Technical Overview 5988-2388EN
Technical Overview 5988-2389EN
Technical Overview 5988-3694EN
Technical Overview 5988-4828EN
Technical Overview 5988-3695EN
Technical Overview 5989-2781EN
Technical Overview 5988-3697EN
Technical Overview 5989-0056EN
Technical Overview 5989-4795EN
Product Overview 5988-2610EN
Data Sheet 5980-3115EN
Technical Overview 5989-1111EN

Hardware options

PSA Series Spectrum Analyzers Video Output (Option 124)
PSA Series Spectrum Analyzers, Option H70,70 MHz IF Output

Spectrum analyzer fundamentals

Optimizing Dynamic Range for Distortion Measurements
PSA Series Amplitude Accuracy
PSA Series Swept and FFT Analysis
PSA Series Measurement Innovations and Benefi ts
Spectrum Analysis Basics
Vector Signal Analysis Basics
8 Hints for Millimeter Wave Spectrum Measurements
Spectrum Analyzer Measurements to 325 GHz with the Use of External Mixers
EMI

23

Technical Overview 5989-1118EN
Product Overview 5988-5261EN

Product Note 5980-3079EN
Product Note
Product Note 5980-3081EN
Product Note 5980-3082EN
Application Note 150
Application Note 150-15 5989-1121EN
Application Note 5988-5680EN
Application Note 1453
Application Note 150-10

5980-3080EN

5952-0292

5988-9414EN
5968-3661E

www.agilent.com

www.agilent.com/fi nd/psa

Agilent Email Updates

www.agilent.com/fi nd/emailupdates

Get the latest information on the
products and applications you select.

Agilent Direct

www.agilent.com/fi nd/agilentdirect

Quickly choose and use your test
equipment solutions with confi dence.

Agilent

Open

www.agilent.com/fi nd/open

Agilent Open simplifi es the process
of connecting and programming
test systems to help engineers
design, validate and manufacture
electronic products. Agilent offers
open connectivity for a broad range
of system-ready instruments, open
industry software, PC-standard
I/O and global support, which are
combined to more easily integrate
test system development.

cdma2000 is a registered certifi cation
mark of the Telecommunications Industry
Association. Used under license.

Remove all doubt

Our repair and calibration services
will get your equipment back to you,
performing like new, when prom­ised. You will get full value out of
your Agilent equipment through­out its lifetime. Your equipment
will be serviced by Agilent-trained
technicians using the latest factory
calibration procedures, automated
repair diagnostics and genuine parts.
You will always have the utmost
confi dence in your measurements.
For information regarding self
maintenance of this product, please
contact your Agilent offi ce.

Agilent offers a wide range of ad­ditional expert test and measure­ment services for your equipment,
including initial start-up assistance,
onsite education and training, as
well as design, system integration,
and project management.

For more information on repair and
calibration services, go to:

www.agilent.com/fi nd/removealldoubt

Product specifi cations and descriptions
in this document subject to change
without notice.

For more information on Agilent
Technologies’ products, applications or
services, please contact your local Agilent

offi ce. The complete list is available at:

www.agilent.com/fi nd/contactus

Americas

Canada [phone]
Latin America 305 269 7500
United States [phone]

Asia Pacifi c

Australia 1 800 629 485
China 800 810 0189
Hong Kong 800 938 693
India 1 800 112 929
Japan 0120 (421) 345
Korea 080 769 0800
Malaysia 1 800 888 848
Singapore 1 800 375 8100
Taiwan 0800 047 866
Thailand 1 800 226 008

Europe & Middle East

Austria 01 36027 71571
Belgium 32 (0) 2 404 93 40
Denmark 45 70 13 15 15
Finland 358 (0) 10 855 2100
France 0825 010 700*

*0.125 €/minute

Germany 07031 464 6333
Ireland 1890 924 204
Israel 972-3-9288-504/544
Italy 39 02 92 60 8484
Netherlands 31 (0) 20 547 2111
Spain 34 (91) 631 3300
Sweden 0200-88 22 55
Switzerland 0800 80 53 53
United Kingdom 44 (0) 118 9276201
Other European Countries:
www.agilent.com/fi nd/contactus

Revised: October 1, 2008

© Agilent Technologies, Inc. 2005, 2008
Printed in USA, November 15, 2008
5980-1284E
