All specifications apply over 0 °C to + 55 °C unless otherwise noted
and are covered by the product warranty. The analyzer will meet its
specifications when: it’s within the one year calibration cycle, AUTO
ALIGN [ALL] is selected, stored a minimum 2 hours within the operating temperature range, turned on for at least 5 minutes, Align Now
RF has been run once every 24 hour period. Characteristics describe
product performance that is useful in the application of th product,
but is not covered by the product waranty. Typical performance is
beyond specifications that 80% of the units exhibit 95% confidence
level over 20 to 30°C not including measurement uncertainty and is
not covered by the product warranty.
Frequency specifications
Frequency range
E4401B
50 Ω 9 kHz to 1.5 GHz
75 Ω 1 MHz to 1.5 GHz
E4402B 9 kHz to 3.0 GHz
dc coupled (Option UKB) 30 Hz
6
to 3 GHz
ac coupled (Option UKB) 100 kHz to 3 GHz
E4404B
dc coupled 9 kHz to 6.7 GHz
dc coupled (Option UKB) 30 Hz
6
to 6.7 GHz
ac coupled 100 kHz to 6.7 GHz
Band
0 9 kHz to 3.0 GHz
(Option UKB) 100 Hz to 3.0 GHz
1 2.85 GHz to 6.7 GHz
E4405B
dc coupled 9 kHz to 13.2 GHz
dc coupled (Option UKB) 30 Hz
6
to 13.2 GHz
ac coupled 100 kHz to 13.2 GHz
Band N
4
0 1– 9 kHz to 3.0 GHz
0 (Option UKB) 30 Hz
6
to 3.0 GHz
1 1– 2.85 GHz to 6.7 GHz
2 2– 6.2 GHz to 13.2 GHz
E4407B
Internal mixing 9 kHz to 26.5 GHz
dc coupled (option UKB) 30 Hz6 to 26.5 GHz
ac coupled (option UKB) 10 MHz to 26.5 GHz
Band N
4
0 1– 9 kHz to 3.0 GHz
0 (option UKB) 30 Hz6to 3.0 GHz
1 1– 2.85 GHz to 6.7 GHz
2 2– 6.2 GHz to 13.2 GHz
3 4– 12.8 GHz to 19.2 GHz
4 4– 18.7 GHz to 26.5 GHz
External mixing (Option AYZ) 18 GHz to 325 GHz
Agilent E4401B, E4402B, E4404B,
E4405B, and E4407B
Data Sheet
ESA-E Series Spectrum Analyzers
These specifications apply to the Agilent
Technologies E4401B, E4402B, E4404B,
E4405B, and E4407B spectrum analyzers.
2
Frequency reference
(Option 1D5)
Aging ±2 × 10
–6
/year ±1 × 10
–7
/year
Temperature stability ±5 × 10
–6
±1 × 10
–8
(20 to 30 °C)
Settability ±5 × 10
–7
±1 × 10
–8
Frequency readout accuracy
(Start, Stop, Center, Marker) ±(frequency indication x
frequency reference error
1
+ span
accuracy +15% of RBW + 10 Hz +
1 Hz x N
4
)
Marker frequency counter
2
Accuracy
3
±(marker frequency × frequency
reference error
1
+ counter
resolution)
Counter resolution Selectable from 1 Hz to 100 kHz
Frequency span
Range 0 Hz (zero span), 100 Hz to the
maximum frequency range of
the analyzer
Resolution 2 Hz × N
4
Accuracy
(>2000 sweep points) ±0.5% of span
Sweep time
Range
Span >0 Hz 1 ms to 4000 s
Span = 0 Hz 10 µs to 4000 s
(Option AYX) 50 ns to 4000 s
(Option B7D) 25 ns to 4000 s
Accuracy ±1%
Sweep trigger Free Run, Single, Line, Video,
External, delay, Offset,
Gate (Option 1D6), and TV
(Option B7B)
Delay trigger range 1 µs to 400 s
Sweep (trace) point range 101 to 8192
Span = 0 Hz 2 to 8192
Resolution bandwidth 1 kHz to 5 MHz (–3 dB) in 1-3-10
sequence.
9 kHz and 120 kHz (–6 dB) EMI
bandwidths.
Option 1DR Adds 10, 30, 100, and 300 Hz (–3 dB)
bandwidths and 200 Hz (–6 dB)
EMI bandwidth.
(for spans ≤5 MHZ)
Accuracy
1 kHz to 3 MHz ±15%
5 MHz ±30%
10 Hz to 300 Hz (Option 1DR) ±10%
Selectivity (characteristic)
–60 dB/–3 dB
10 Hz to 300 Hz <5:1
6
digital, approximately
Gaussian shape
1 kHz to 5 MHz <15:1
6
synchronously tuned four
poles, approximately Gaussian
shape
Video bandwidth range 30 Hz to 3 MHz
6
in 1-3-10
sequence
Option 1DR Adds 1 Hz, 3 Hz
,
and 10 Hz
(for RBW ≤1 kHz)
Stability
Noise sidebands (1 kHz RBW, 30 Hz VBW and sample detector)
Offset from CW signal Typical
E4401B
≥1 kHz na ≤–79 dBc/Hz (Option 1D5)
≥10 kHz ≤–93 dBc/Hz ≤–95 dBc/Hz
≥20 kHz ≤–100 dBc/Hz ≤–102 dBc/Hz
≥30 kHz ≤–104 dBc/Hz ≤–106 dBc/Hz
≥100 kHz ≤–113 dBc/Hz ≤–116 dBc/Hz
E4402/04/05/07B
≥1 kHz na ≤-78 dBc/Hz (Option 1D5)
≥10 kHz ≤-90 dBc/Hz
21
≤-94 dBc/Hz
21
≥20 kHz ≤-100 dBc/Hz21≤-105 dBc/Hz
21
≥30 kHz ≤-106 dBc/Hz21≤-112 dBc/Hz
21
≥100 kHz ≤-119 dBc/Hz21≤-122 dBc/Hz
21
≥1 MHz ≤-125 dBc/Hz21≤-127 dBc/Hz
21
≥5 MHz ≤-127 dBc/Hz21≤-129 dBc/Hz
21
≥10 MHz ≤-131 dBc/Hz21≤-136 dBc/Hz
21
Option 120
≥1 MHz ≤-133 dBc/Hz
21
≤-136 dBc/Hz
21
≥5 MHz ≤-135 dBc/Hz21≤-139 dBc/Hz
21
≥10 MHz ≤-137 dBc/Hz21≤-141 dBc/Hz
21
Residual FM
1 kHz RBW, 1 kHz VBW ≤150 × N
4
Hz pk-pk in 100 ms
Option 1D5 ≤100 × N
4
Hz pk-pk in 100 ms
Option 1DR ≤10 × N
4 Hz6
pk-pk in 20 ms
Option 1DR and 1D5 ≤2 × N
4
Hz pk-pk in 20 ms
System-related sidebands
≥30 kHz offset from CW signal ≤–65 dBc + 20 Log N
4
Amplitude specifications
Amplitude range
Measurement range Displayed Average Noise Level
(DANL) to maximum safe input level
Input attenuator range
E4401B 0 to 60 dB, in 5 dB steps
E4402B/04B/05B 0 to 65 dB (75 dB
6
), in 5 dB steps
E4407B 0 to 65 dB, in 5 dB steps
3
Maximum safe input level
Average continuous power
(input attenuator ≥15 dB)
E4401B +30 dBm (1 W)
E4401B (75 Ω Option 1DP) +75 dBmV (0.4 W)
(input attenuator ≥5 dB)
E4402B/04B/05B/07B +30 dBm (1 W)
Peak pulse power
(input attenuator ≥30 dB)
E4401B +30 dBm (1 W)
E4401B (75 Ω Option 1DP) +75 dBmV (0.4 W)
E4402B/04B/05B/07B +50 dBm (100 W)
dc
E4401B, E4402B 100 Vdc
E4401B (75 Ω Opt. 1DP) 100 Vdc
E4402B (Option UKB) 0 Vdc (dc coupled)
50 V (ac coupled)
E4404B, E4405B 0 Vdc (dc coupled)
50 V (ac coupled)
E4407B 0 Vdc
1 dB gain compression (total power at input mixer
5
)
50 MHz to 6.7 GHz 0 dBm
6.7 GHz to 13.2 GHz –3 dBm
13.2 GHz to 26.5 GHz –5 dBm
Displayed Average Noise Level (DANL) (dBm)
(Input terminated, 0 dB attenuation, sample detector)
1 kHz RBW; 30 Hz VBW
10 Hz RBW; 1 Hz VBW (Option 1DR)
1 kHz RBW 10 Hz RBW 10 Hz RBW 10 Hz RBW
(Option 1DR) (Option 1DR) (Option 1DR)
(w/preamp (w/preamp
Option 1DS) Option 1DS)
Typical
E4401B
400 kHz to 1 MHz ≤–115 ≤–134 ≤–150 ≤–155
1 MHz to 500 MHz ≤–119 ≤–138 ≤–154 ≤–156
500 MHz to 1 GHz ≤–117 ≤–136 ≤–152 ≤–156
1 GHz to 1.5 GHz ≤–114 ≤–133 ≤–150 ≤–155
E4402B
30 Hz to 9 kHz
22
na ≤–93 na na
(Option UKB)
9 kHz to 100 kHz
22
na ≤–109 na na
100 kHz to 1 MHz
22
na ≤–135 na na
1 MHz to 10 MHz
22
≤–117 ≤–136 na ≤–152
10 MHz to 1 GHz ≤–117 ≤–136 ≤–152
19
≤–156
1 GHz to 2 GHz ≤–116 ≤–135 ≤–153
19
≤–156
2 GHz to 3 GHz ≤–114 ≤–133 ≤–151
19
≤–154
E4404/05B/07B
30 Hz to 9 kHz
22
na ≤–93 na na
(Option UKB)
9 kHz to 100 kHz
22
na ≤–109 na na
100 kHz to 1 mHz
22
na ≤–135 na na
1 MHz to 10 MHz
22
≤–117 ≤–137 na ≤–155
10 MHz to 1 GHz ≤–116 ≤–135 ≤–151
19
≤–157
1 GHz to 2 GHz ≤–116 ≤–135 ≤–151
19
≤–155
2 GHz to 3 GHz ≤–112 ≤–131 ≤–149
19
≤–152
3 GHz to 6 GHz ≤–112 ≤–131 na ≤–138
6 GHz to 12 GHz ≤–111 ≤–130 na ≤–137
12 GHz to 22 GHz ≤–107 ≤–126 na ≤–134
22 GHz to 26.5 GHz ≤–106 ≤–125 na ≤–132
E4407B (Option AYZ)
External mixer
6
≤–134 + ≤–153 + na na
external mixer external mixer
conversion conversion
loss loss
Display range
Log scale 0.1, 0.2, 0.5 dB/division and 1 to 20 dB/
division in 1dB steps;
ten divisions displayed.
RBW = 1 kHz 0 to -85 dB from reference level is
calibrated
RBW = 300 Hz (Option 1DR) 0 to -120
13
dB from reference level
is calibrated
Linear scale 10 divisions
Scale units dBm, dBmV, dBµV, Volts, and Watts
(Option BAA) add Hz
Marker readout resolution
Log scale
0 to –85 dB 0.04 dB
0 to –120 dB (Option 1DR) 0.04 dB
Linear scale 0.01% of reference level
Fast sweep times for zero span (Option AYX)
(sweeptimes ≤ sweep points –1/100 kHz)
Log scale
0 to –85 dB 0.3 dB
Linear 0.3% of reference level
Frequency response (10 dB input attenuation)
Absolute
7
/Typical Relative flatness
8
E4401B
9 kHz to 1.5 GHz ±0.5 dB na ±0.5 dB
E4402B/04B/05B/07B
30 Hz to 3 GHz
6
±0.5 dB na ±0.5 dB
(Option UKB)
9 kHz to 3.0 GHz ±0.46 dB ±0.14 dB ±0.5 dB
3.0 GHz to 6.7 GHz ±1.5 dB ±0.38 dB ±1.3 dB
6.7 GHz to 13.2 GHz ±2.0 dB ±0.68 dB ±1.8 dB
13.2 GHz to 26.5 GHz ±2.0 dB ±0.86 dB ±1.8 dB
Input attenuation switching uncertainty at 50 MHz
Attenuation setting
0 dB to 5 dB ±0.3 dB
10 dB reference
15 dB ±0.3 dB
20 to 60 dB (E4401B) ±(0.1 dB + 0.01 x attenuator setting)
20 to 65 dB ±(0.1 dB + 0.01 x attenuator setting)
Absolute amplitude accuracy
Typical
At reference settings
15
±0.34 dB ±0.13 dB
E4401B ±0.30 dB ±0.10 dB
Preamp on
16
(Option 1DS) ±0.37 dB ±0.14 dB
External mixer (Option AYZ) IF INPUT absolute amplitude
accuracy + external mixer
conversion loss accuracy
17
Overall amplitude accuracy
9
±(0.54 dB + absolute frequency
response)
4
RF input VSWR
6
(at tuned frequency, 10 dB attenuation)
E4401B
1 MHz to 1.5 GHz 1.35:1
E4402B
9 kHz to 100 kHz 2:1
100 kHz to 3 GHz 1.4:1
E4404B/05B
9 kHz to 100 kHz 2:1
100 kHz to 6.7 GHz 1.3:1
6.7 GHz to 13.2 GHz 1.5:1
E4407B
9 kHz to 6.7 GHz 1.3:1
6.7 GHz to 13.2 GHz 1.5:1
13.2 GHz to 22 GHz 2:1
22 GHz to 26.5 GHz 2.2:1
Resolution bandwidth switching uncertainty
(at reference level)
1 kHz RBW Reference
10 Hz to 3 MHz RBW ±0.3 dB
5 MHz RBW ±0.6 dB
Reference level
Range –149.9 dBm to maximum mixer level
+ attenuator setting
Resolution
Log scale ±0.1 dB
Linear scale ±0.12% of reference level
Accuracy (reference level ±0.3 dB (–10 dBm to –60 dBm)
– attenuator setting ±0.5 dB (–60 dBm to –85 dBm)
+ preamp gain) ±0.7 dB (–85 dBm to –90 dBm)
Display scale fidelity
Log maximum cumulative
RBW ≥ 1 KHz
dB below reference level Typical
0 dB (Reference) ±0.00 dB ±0.00 dB
>0 to 10 dB ±0.22 dB ±0.08 dB
>10 to 20 dB ±0.24 dB ±0.09 dB
>20 to 30 dB ±0.26 dB ±0.10 dB
>30 to 40 dB ±0.40 dB ±0.23 dB
>40 to 50 dB ±0.57 dB ±0.35 dB
>50 to 60 dB ±0.57 dB ±0.35 dB
>60 to 70 dB ±0.66 dB ±0.39 dB
>70 to 80 dB ±0.66 dB ±0.46 dB
>80 to 85 dB ±1.15 dB ±0.79 dB
RBW ≥ 300 Hz, (Option 1DR)(span >0 Hz)
0 dB to –98 dB ±(0.3 dB + 0.01 x dB from
reference level)
≥98 to 120 dB ±(2.0 dB from reference level)
6
Log incremental accuracy
0 dB to –80 dB ±0.4dB/4dB from reference level
Linear accuracy ±2% of reference level
Linear-to-log switching
Uncertainty
±0.15 dB at reference level
Spurious responses
Second harmonic distortion
E4401B
2 MHz to 750 MHz <–75 dBc for –40 dBm tone at input
mixer
5
. (+35 dBm SHI)
E4402/04/05/07B
10 MHz to 500 MHz <–65 dBc for –30 dBm tone at input
mixer
5
.
500 MHz to 1.5 GHz <–75 dBc for –30 dBm tone at input
mixer
2
. (+45 dBm SHI)
1.5 GHz to 2.0 GHz <–85 dBc for –10 dBm tone at input
mixer
2
.
>2.0 GHz <–100 dBc for –10 dBm tone at input
mixer
5
(or below displayed average
noise level).
Third-order intermodulation distortion
E4401B
10 MHz to 1.5 GHz <–87 dBc for two –30 dBm tones at
input mixer
5
and >50 kHz separation.
(+13.5 dBm TOI, +19 dBm typical)
E4402B/04B/05B/07B
100 MHz to 3.0 GHz <–85 dBc for two –30 dBm tones at
input mixer
5
and >50 kHz separation.
(+12.5 dBm TOI, +16 dBm typical)
>3.0 GHz to 6.7 GHz <–82 dBc for two –30 dBm tones at
input mixer
5
and >50 kHz separation.
(+11 dBm TOI, +18 dBm typical)
>6.7 GHz <–75 dBc for two –30 dBm tones at
input mixer
5
and >50 kHz seperation.
Other input-related spurious
>30 kHz offset <–65 dBc for –20 dBm tone at input
mixer
5
.
Residual responses (input terminated and 0 dB attenuation)
150 kHz to 6.7 GHz <–90 dBm
Amplitude reference output
E4402B/04B/05B/07B –20 dBm (nominal), 50 MHz
General specifications
Temperature range
Operating 0 °C to + 55 °C
Storage –40 °C to + 75 °C
EMI compatibility Conducted and radiated interference
is in compliance with CISPR Pub.
11/1990 Group 1 Class A
(Option 060) CISPR Pub. 11/1990 Group 1 Class B
23
Audible noise <40 dBa pressure and <4.6 bels
power (ISODP7779)
Military specification Type tested to the environmental
specifications of MIL-PRF-28800F
class 3.
Power requirements
ON (line 1) 90 to 132 V rms, 47 to 440 Hz
195 to 250 V rms, 47 to 66 Hz
Power consumption <300 W
Standby (line 0) Power consumption <5 W
dc operation
Voltage 12 to 20 Vdc
Power consumption <200 W
5
Data storage (nominal)
Internal 200 traces or states
External
(1.44 MB floppy disk) 200 traces or states
Weight
6
(without options)
E4401B 13.2 kg (29.1 lbs.)
E4402B 15.5 kg (34.2 lbs.)
E4404B/05B/07B 17.1 kg (37.7 lbs.)
Dimensions
Without handle 222mm(H) x 409mm(D) x 373mm(W)
With handle (maximum) 222mm(H) x 516mm(D) x 416mm(W)
Measurement speed
Inputs/outputs
Front panel
INPUT 50 Ω Type N (f)
Option 1DP 75 Ω BNC (f)
Option BAB 50 Ω APC 3.5 (m)
RF OUT 50 Ω Type N (f)
Option 1DP 75 Ω BNC (f)
PROBE POWER +15 Vdc, –12.6 Vdc at 150 mA
6
maximum
EXT KEYBOARD 6-pin mini-DIN, PC keyboards (for
entering screen titles and file menus)
Speaker front-panel knob controls volume
Headphone 3.5mm (1/8 inch) miniature audio jack
Power output 0.2 W into 4 Ω
6
AMPTD REF OUT 50 Ω
20
, BNC (f)
IF INPUT (Option AYZ) 50 Ω
20
, SMA (f)
LO OUTPUT (Option AYZ) 50 Ω
20
, SMA (f)
Rear panel
10 MHz REF OUT 50 Ω
20
, BNC (f), >0 dBm
6
10 MHz REF IN 50 Ω
20
, BNC (f), –15 to +10 dBm
6
GATE TRIG/EXT TRIG IN BNC (f), 5 V TTL
GATE/HI SWP OUT BNC (f), 5 V TTL
VGA OUTPUT VGA compatible monitor, 15–pin mini
D-SUB, (31.5 kHz horizontal, 60 Hz
vertical sync rates, non-interlaced)
Analog RGB 640 x 480
IF, sweep and video ports (Option A4J or AYX)
AUX IF OUT BNC (f), 21.4 MHz, nominal –10 to
–70 dBm
20
(uncorrected)
AUX VIDEO OUT BNC (f), 0 to 1 V
6
(uncorrected)
HI SWP IN BNC (f), low stops sweep, (5 V TTL)
HI SWP OUT BNC (f), (5 V TTL)
SWP OUT BNC (f), 0 to +10 V
6
ramp
GPIB interface
(Option A4H) IEEE-488 bus connector
Serial interface
(Option 1AX) RS-232, 9-pin D-SUB (m)
Parallel interface
(Option A4H or 1AX) 25-pin D-SUB (f), printer port only
Option specifications
Option 1D6 time-gated spectrum analysis
Gate delay/length
Range 1 µs to 400 s
Resolution <gate delay(s)/65000; rounded up
to nearest µs.
Accuracy ±(500 ns + 0.01% × gate delay
readout)
Option 1DN and 1DQ tracking generator
Frequency range
E4401B
Option 1DN, (50 Ω) 9 kHz to 1.5 GHz
Option 1DQ, (75 Ω) 1 MHz to 1.5 GHz
E4402B/04B/05B/07B
Option 1DN, (50 Ω) 9 kHz to 3.0 GHz
RBW range 1 kHz to 5 MHz
Output power level range
E4401B
Option 1DN 0 to –70 dBm
Option 1DQ +42.75 to –27.25 dBmV
E4402B/04B/05B/07B
Option 1DN –2 to –66 dBm
Output vernier range
E4401B 10 dB
E4402B/04B/05B/07B 8 dB
Output attenuator range
E4401B 0 to 60 dB, 10 dB steps
E4402B/04B/05B/07B 0 to 56 dB, 8 dB steps
Output flatness
E4401B
Option 1DN, (50 Ω)
9 kHz to 10 MHz ±2.0 dB
10 MHz to 1.5 GHz ±1.5 dB
Option 1DQ, (75 Ω)
1 MHz to 10 MHz ±2.5 dB
1 MHz to 10 MHz ±2.0 dB
E4402B/04B/05B/07B
9 kHz to 10 MHz ±3.0 dB
10 MHz to 3.0 GHz ±2.0 dB
Effective source match (characteristic)
E4401B <2.5:1
E4402B/04B/05B/07B <2.0:1 (0 dB attenuator)
<1.5:1 (8 dB attenuator)
E4401B E4402B E4404B,E4405B
E4407B
Local measurement rate
10
≥50/sec ≥45/sec ≥40/sec
Remote measurement
and GPIB transfer rate
11
≥45/sec ≥45/sec ≥40/sec
RF center frequency
tuning time
18
≤75 ms ≤75 ms ≤75 ms
6
Spurious output
Harmonic spurs
E4401B
(0 dBm output)
9 kHz to 20 MHz <
–20 dBc
20 MHz to 1.5 GHz <
–25 dBc
E4402B/04B/05B/07B
(–1 dBm output)
20 kHz to 3 GHz <–25 dBc
Non-Harmonic spurs
E4401B <–35 dBc
E4402B/04B/05B/07B
9 kHz to 2 GHz <–27 dBc
2 GHz to 3 GHz <–23 dBc
Dynamic range
Maximum output power – displayed average noise level
Output power sweep range
E4401B
Option 1DN (–15 dBm to 0 dBm) – (source
attenuator setting)
Option 1DQ (+27.75 dBmV to +42.75 dBmV) –
(source attenuator setting)
E4402B/04B/05B/07B
Option 1DN (–10 dBm to –2 dBm) – (source
attenuator setting)
Option 1DS preamp
Frequency range
E4401B 100 kHz to 1.5 GHz
E4402B/04B/05B/07B 1 MHz to 3 GHz
Gain +20 dB
20
Noise figure
E4401B 4 dB
6
E4402B/04B/05B/07B 5 dB
6
Option AYZ external mixing
LO OUTPUT
Frequency range 2.9 to 7.1 GHz
Power
2.9 to 6.1 GHz 15 to 17.5 dBm at the mixer
2.9 to 7.1 GHz 13 to 17.5 dBm
VSWR <1.9:1
IF INPUT
Frequency range 321.4 MHz ±5 MHz
Maximum safe input level 10 dBm (ac), ±10 V (dc)
VSWR <1.9:1.6
Absolute amplitude accuracy
14
(reference levels from –10 to –60 dB)
Amplitude corrections
20 °C to 30 °C 0 °C to 55 °C
15 to 30 dB 1.0 dB 1.5 dB
>30 to 50 dB 1.2 dB 1.7 dB
>50 to 60 dB 1.4 dB 1.9 dB
1 dB gain compression level –20 dBm with –10 dBm
reference level and 0 dB
amplitude corrections
Mixer bias (IF INPUT)
Voltage
Maximum range ±3.3 V
Linear compliant range ±2 V
Current (0 Ω load)
Range ±10 mA
Resolution <20 µA
Accuracy ± (3% + resolution)
Output impedence 490 Ω
20
Option BAA FM demodulation
6
Optimum input level ≥(–60 dBm + attenuator
setting–preamp gain) and
within 30 dB of the
reference level
FM deviation (FM gain)
Range 10 kHz to 1 MHz
Resolution provides 1 Hz display
annotation resolution
FM deviation range
10 kHz to 40 kHz 12 Hz
>40 kHz to 200 kHz 60 Hz
>200 kHz to 1 MHz 300 Hz
Accuracy
12
<(2% of FM deviation
range + 2 × resolution)
FM bandwidth (–3 dB)
FM deviation range
10 kHz to 40 kHz 7.5 × FM deviation range
>40 kHz to 200 kHz 1.3 ×FM deviation range
>200 kHz to 1 MHz 0.3 × FM deviation range
Option B7B TV trigger and picture on screen
Amplitude requirements
6
TV source: SA Top 50% of linear display
TV source: EXT VIDEO IN 500 mVp-p to 2 Vp-p
Compatible standards NTSC-M, NTSC-Japan
PAL-M, PAL-B, D, G, H, I,
PAL-N, PAL-N combination,
SECAM-L
Field selection Entire frame, even, odd
TV trigger line selection 1 to 625
7
Notes
1. Frequency reference error = (aging rate x period of time since adjustment + settability + temperature stability).
2. Not available in RBW <1 kHz (Option 1DR).
3. Marker level to DANL >25 dB, RBW/span ≥0.002.
4. N = LO harmonic mixing mode.
5. Mixer power level (dBm) = input power (dBm)—input attenuation (dB).
6. Characteristic
7. Referenced to 50 MHz amplitude reference (20 °C to 30 °C).
8. Referenced to midpoint between highest and lowest frequency response deviations (20 °C to 30 °C).
9. For reference levels 0 to –50 dBm; input attenuation 10 dB; 1 kHz RBW; 1 kHz video BW; log scale; log range,
0 to 50 dB; coupled sweep time; sample detector; signal input, 0 to –50 dBm; span = 20 kHz; internal mixing
(20 °C to 30 °C).
10. Characteristic; factory preset, fixed center frequency, sweep points = 101, auto align off, RBW = 1 MHz,
stop frequency ≤3 GHz, span >10MHz and ≤600 MHz (E4401B, span >102 MHz and ≤400 MHz).
11. Characteristic; factory preset, fixed center frequency, sweep points = 101, auto align off, RBW = 1 MHz,
stop frequency =3 GHz, span = 20 MHz, GPIB interface, display and markers off, fixed center frequency, single sweep.
12. In time-domain sweeps.
13. 0 to –70 dB range when span = 0 Hz, or when auto ranging is off.
14. RBW 1 kHz; VBW 1 kHz; scale linear or log; span 2 kHz; sweep time coupled; sample detector; signal at
reference level.
15. Reference level –25 dBm (E4401B) or –20 dBm (E4402B/04B/05B/07B); (75 Ω reference level + 28.75 dBmV);
input attenuation 10 dB; center frequency 50 MHz; RBW 1 kHz; VBW 1 kHz; scale linear or log; span 2 kHz; sweep
time coupled, sample detector, signal at reference level.
16. Reference level –30 dBm; (75 Ω reference level + 18.75 dBmV); input attenuation 0 dB; center frequency 50 MHz;
RBW 1 kHz; VBW 1 kHz; scale linear or log; span 2 kHz; sweep time coupled, signal at reference level.
17. Preselector centered with the Agilent 11974-series mixers.
18. Characteristic; includes center frequency tuning + measurement + GPIB transfer times, stop frequency ≤3GHz,
sweep points = 101, display and markers off, single sweep.
19. 20 to 30 °C
20. Nominal
21. Add 20 log (N) for frequencies >6.7 GHz.
22. Typical
23. Meeting class A performance during dc operation.
Agilent Technologies’ Test and Measurement
Support, Services, and Assistance
Agilent Technologies aims to maximize the value you receive,
while minimizing your risk and problems. We strive to ensure
that you get the test and measurement capabilities you paid
for and obtain the support you need. Our extensive support
resources and services can help you choose the right Agilent
products for your applications and apply them successfully.
Every instrument and system we sell has a global warranty.
Support is available for at least five years beyond the production life of the product. Two concepts underlay Agilent's
overall support policy: “Our Promise” and “Your Advantage.”
Our Promise
Our Promise means your Agilent test and measurement equipment will meet its advertised performance and functionality.
When you are choosing new equipment, we will help you with
product information, including realistic performance specifications and practical recommendations from experienced test
engineers. When you use Agilent equipment, we can verify
that it works properly, help with product operation, and provide basic measurement assistance for the use of specified
capabilities, at no extra cost upon request. Many self-help
tools are available.
Your Advantage
Your Advantage means that Agilent offers a wide range of
additional expert test and measurement services, which you
can purchase according to your unique technical and business
needs. Solve problems efficiently and gain a competitive edge
by contacting us for calibration, extra-cost upgrades, out-ofwarranty repairs, and on-site education and training, as well
as design, system integration, project management, and other
professional services. Experienced Agilent engineers and technicians worldwide can help you maximize your productivity,
optimize the return on investment of your Agilent instruments
and systems, and obtain dependable measurement accuracy
for the life of those products.
By internet, phone, or fax, get assistance
with all your test and measurement needs.
Online assistance:
www.agilent.com/find/assist
Phone or Fax
United States:
(tel) 1 800 452 4844
Canada:
(tel) 1 877 894 4414
(fax) (905) 282 6495
Europe:
(tel) (31 20) 547 2323
(fax) (31 20) 547 2390
Japan:
(tel) (81) 426 56 7832
(fax) (81) 426 56 7840
Latin America:
(tel) (305) 269 7500
(fax) (305) 269 7599
Australia:
(tel) 1 800 629 485
(fax) (61 3) 9210 5947
New Zealand:
(tel) 0 800 738 378
(fax) 64 4 495 8950
Asia Pacific:
(tel) (852) 3197 7777
(fax) (852) 2506 9284
Product specifications and descriptions
in this document subject to change
without notice.
Copyright © 2000, 2001 Agilent Technologies
Printed in USA, April 23, 2001
5968-3386E
Loading...
