Asus R061PT User Manual
Eee PC
User Manual
Windows® 7 Edition
Eee PC 1016 Series
E5772
Table of Contents
About This User’s Manual ......................................................................................................iv
Notes for This Manual .............................................................................................................iv
Safety Precautions.....................................................................................................................v
Transportation Precautions ...................................................................................vi
Charging Your Batteries..........................................................................................vii
Airplane Precautions ...............................................................................................vii
Chapter 1: Knowing the Parts
Top Side ....................................................................................................................................1-2
Bottom Side .............................................................................................................................1-5
Front Side ................................................................................................................................. 1-6
Right Side .................................................................................................................................1-7
Left Side ....................................................................................................................................1-8
Keyboard Usage .....................................................................................................................1-9
Special Function Keys ...........................................................................................1-9
Touchpad Usage ..................................................................................................................1-11
Chapter 2: Getting Started
Powering on your Eee PC ................................................................................................... 2-2
First-time Startup ..................................................................................................................2-3
Desktop .....................................................................................................................................2-5
Network Connection ............................................................................................................2-6
Configuring a wireless network connection.................................................2-6
Local Area Network ................................................................................................2-7
Browsing web pages ...........................................................................................2-10
Chapter 3: Using the Eee PC
ASUS Update ...........................................................................................................................3-2
Updating the BIOS through the Internet ....................................................... 3-2
Updating the BIOS through a BIOS file ...........................................................3-3
Bluetooth Connection(on selected models) ...............................................................3-4
Super Hybrid Engine ............................................................................................................3-6
Super Hybrid Engine Modes...............................................................................3-6
ii
Table of Contents
Eee Docking ............................................................................................................................3-7
Access .........................................................................................................................3-7
Sharing .......................................................................................................................3-7
Experience (on selected models) ......................................................................3-8
Tools ............................................................................................................................ 3-8
Boingo (on selected models) ............................................................................................3-8
Microsoft® Office Trial (on selected models) ................................................................3-9
Chapter 4: System Recovery
System Recovery....................................................................................................................4-2
Boot Booster............................................................................................................................4-5
Appendix
Declarations and Safety Statements ..............................................................................A-2
FCC Radio Frequency (RF) Exposure Caution Statement .........................A-3
Declaration of Conformity(R&TTE directive 1999/5/EC)...........................A-4
IC Radiation Exposure Statement for Canada ..............................................A-4
CE Mark Warning ....................................................................................................A-6
Wireless Operation Channel for Different Domains ..................................A-7
France Restricted Wireless Frequency Bands ...............................................A-7
UL Safety Notices ....................................................................................................A-8
Power Safety Requirement .................................................................................A-9
REACH Notice ...........................................................................................................A-9
Global Environmental Regulation Compliance and Declaration ......A-10
Takeback Services................................................................................................A-10
Nordic Lithium Cautions (for lithium-ion batteries)................................A-11
Copyright Information ......................................................................................................A-13
Limitation of Liability ........................................................................................................A-14
Service and Support .......................................................................................................... A-14
ASUS Eee PC
iii
About This User’s Manual
You are reading the Eee PC User’s Manual. This User’s Manual provides
information regarding the various components in the Eee PC and how to
use them. The following are major sections of this User’s Manual:
1. Knowing the Parts
Provides information on the Eee PC’s components.
2. Getting Started
Provides information on getting started with the Eee PC.
3. Using the Eee PC
Provides information on using the Eee PC’s utilities.
4. System Recovery
Gives you information on system recovery.
5. Appendix
Gives you safety statements.
The actual bundled applications differ by models and territories.
There may be differences between your Eee PC and the pictures
shown in this manual. Please accept your Eee PC as being correct.
Notes for This Manual
A few notes and warnings are used throughout this guide, allowing you
to complete certain tasks safely and effectively. These notes have different
degrees of importance as follows:
WARNING! Important information that must be followed for safe
operation.
IMPORTANT! Vital information that must be followed to prevent
damage to data, components, or persons.
TIP: Tips for completing tasks.
NOTE: Information for special situations.
iv
Table of Contents
Safety Precautions
The following safety precautions will increase the life of the Eee PC. Follow
all precautions and instructions. Except as described in this manual, refer
all servicing to qualified personnel. Do not use damaged power cords,
accessories, or other peripherals. Do not use strong solvents such as
thinners, benzene, or other chemicals on or near the surface.
Disconnect the AC power before cleaning. Wipe the Eee PC using a
clean cellulose sponge or chamois cloth dampened with a solution
of nonabrasive detergent and a few drops of warm water and
remove any extra moisture with a dry cloth.
DO NOT place on uneven
or unstable work surfaces.
Seek servicing if the casing
has been damaged.
DO NOT expose to dirty or
dusty environments. DO
NOT operate during a gas
leak.
DO NOT press or touch the
display panel. Do not place
together with small items
that may scratch or enter
the Eee PC.
DO NOT leave the Eee PC
on your lap or any part
of the body to prevent
discomfort or injury from
heat exposure.
DO NOT place or drop objects
on top and do not shove any
foreign objects into the Eee
PC.
DO NOT expose to strong
magnetic or electrical fields.
DO NOT expose to or use near
liquids, rain, or moisture. DO
NOT use the modem during
electrical storms.
Battery safety warning: DO
NOT throw the battery in
fire. DO NOT short circuit the
contacts. DO NOT disassemble
the battery.
ASUS Eee PC
v
SAFE TEMP: This Eee PC
should only be used
in environments with
ambient temperatures
between 5°C (41°F) and
35°C (95°F).
INPUT RATING: Refer to the
rating label on the bottom
of the Eee PC and be sure
that your power adapter
complies with the rating.
DO NOT carry or cover a
Eee PC that is powered
ON with any materials that
Incorrect installation of
battery may cause explosion
and damage the Eee PC.
will reduce air circulation
such as a carrying bag.
DO NOT throw the Eee PC in municipal waste. This product has
been designed to enable proper reuse of parts and recycling. The
symbol of the crossed out wheeled bin indicates that the product
(electrical, electronic equipment and mercury-containing button
cell battery) should not be placed in municipal waste. Check local
regulations for disposal of electronic products.
DO NOT throw the battery in municipal waste. The symbol of the
crossed out wheeled bin indicates that the battery should not be
placed in municipal waste.
Transportation Precautions
To prepare your Eee PC for transport, you should turn it OFF and
disconnect all external peripherals to prevent damage to the
connectors. The hard disk drive’s head retracts when the power is turned
OFF to prevent scratching of the hard disk surface during transport.
Therefore, you should not transport your Eee PC while the power
is still ON. Close the display panel to protect the keyboard and display
panel.
The Eee PC’s surface is easily dulled if not properly cared for. Be careful
not to rub or scrape surfaces when transporting your Eee PC. You can put
your Eee PC in a carrying case for protection from dirt, water, shock, and
scratches.
vi
Table of Contents
Charging Your Batteries
If you intend to use battery power, be sure to fully charge your battery
pack before going on long trips. Remember that the power adapter
charges the battery pack as long as it is plugged into the computer and an
AC power source. Be aware that it takes much longer to charge the battery
pack when the Eee PC is in use.
Remember to fully charge the battery (8 hours or more) before first use
and whenever it is depleted to prolong battery life. The battery reaches its
maximmum capacity after a few full charging and discharging cycles.
Airplane Precautions
Contact your airline if you want to use the Eee PC on the airplane. Most
airlines have restrictions for using electronic devices. Most airlines allow
electronic use only between and not during takeoffs and landings.
There are three main types of airport security devices: X-ray
machines (used on items placed on conveyor belts), magnetic
detectors (used on people walking through security checks), and
magnetic wands (hand-held devices used on people or individual
items). You can send your Eee PC and diskettes through airport X-ray
machines. However, it is recommended that you do not send your
Eee PC or diskettes through airport magnetic detectors or expose
them to magnetic wands.
ASUS Eee PC
vii
viii
Table of Contents
Top Side
Bottom Side
Front Side
Right Side
Left Side
Keyboard Usage
Touchpad Usage
Chapter 1:
Knowing the Parts
1
Top Side
4
7
10
5
8
9
2
3
1
6
Refer to the diagram below to identify the components on this side of the
Eee PC.
The top side may vary in appearance depending on models.
1-2
The keyboard differs for each territory.
Chapter 1: Knowing the Parts
1
Camera Cover Switch
The camera cover switch allows you to open and close the
protective camera cover. Slide the switch to the left to close the
camera cover. Slide the switch to the right to open the camera
cover.
2
Microphone (Built-in)
3
Built-in Camera
4
Display Panel
Presentation Mode Button
5
This button offers quick access to the presentation mode. In the
presentation mode, the screensaver is turned off automatically
and your Eee PC is switched to LCD + CRT Mode directly if it is
linked to an external monitor or a projector. Moreover, if you’ve
opened your PowerPoint file firstly before pressing this button,
this button functions as <Shift> + <F5> to enter the slideshow
mode beginning with the slide you are viewing.
6
Wireless/Bluetooth Button
The wireless/bluetooth button toggles the internal wireless
LAN or Bluetooth ON or OFF. When enabled, the corresponding
wireless/bluetooth indicator lights up.
You can also press <Fn> + <F2> to toggle the internal wireless
LAN or Bluetooth ON or OFF.
Power Switch (Windows)
7
The power switch allows powering ON and OFF the Eee PC and
recovering from STR. Press the switch once to turn ON and hold
it to turn OFF the Eee PC. The power switch only works when the
display panel is opened.
Power Indicator
The power indicator lights when the Eee PC is turned ON and
blinks slowly when the Eee PC is in the Save-to-RAM (Sleep)
mode. This indicator is OFF when the Eee PC is turned OFF.
ASUS Eee PC
1-3
8
Keyboard
The keyboard differs for each territory.
9
Touchpad and Buttons
Status Indicators
10
Power Indicator
The power indicator lights when the Eee PC is turned ON and
blinks slowly when the Eee PC is in the Save-to-RAM (Sleep)
mode. This indicator is OFF when the Eee PC is turned OFF.
Battery Charge Indicator
The battery charge indicator (LED) shows the battery
charging status as follows:
Powered ON
High battery power
(95%–100%)
Medium battery power
(11%–94%)
Low battery power
(0%–10%)
Powered OFF / Standby mode
High battery power
(95%–100%)
Medium battery power
(11%–94%)
Low battery power
(0%–10%)
With Adapter Without Adapter
Green ON Off
Orange ON Off
Orange Blinking Orange Blinking
With Adapter Without Adapter
Green ON Off
Orange ON Off
Orange Blinking Off
1-4
Hard Disk Drive (HDD) Indicator
The hard disk drive indicator blinks when data is written to
or read from the disk drive.
Wireless/Bluetooth Indicator
This is only applicable on models with built-in wireless LAN/
Bluetooth (on selected models). When the built-in wireless
LAN/Bluetooth is enabled, this indicator lights.
Chapter 1: Knowing the Parts
Bottom Side
3
1
2
Refer to the diagram below to identify the components on this side of the
Eee PC.
The bottom side may vary in appearance depending on model.
The bottom of the Eee PC can get very hot. Be careful when
handling the Eee PC while it is in operation or recently been in
operation. High temperatures are normal during charging or
operation. DO NOT USE ON SOFT SURFACES SUCH AS SOFAS
OR BEDS, WHICH MAY BLOCK THE VENTS. DO NOT PUT THE
Eee PC ON YOUR LAP OR OTHER PARTS OF THE BODY TO
AVOID INJURY FROM THE HEAT.
ASUS Eee PC
1-5
1
1
Battery Pack
Battery time varies by usage and by the specifications for this
Eee PC. The battery pack cannot be disassembled and must be
purchased as a single unit.
Battery Lock
2
The battery lock secures the battery pack. When the battery pack
is properly installed, it automatically locks in place. To remove the
battery pack, slide the battery lock inward.
Memory Compartment
3
The memory module is secured in a dedicated compartment.
Front Side
Refer to the diagram below to identify the components on this side of the
Eee PC.
1-6
1
Audio Speaker System
Audio features are software controlled.
Chapter 1: Knowing the Parts
Right Side
1 2 3 4 5 6
Refer to the diagram below to identify the components on this side of the
Eee PC.
1
Memory Card Slot
The built-in memory card reader can read SD/SDHC/MMC cards.
Headphone Output Jack
2
Microphone Jack
3
The microphone jack is designed to connect the microphone
used for voice narrations or simple audio recordings.
4
USB Port (3.0/2.0/1.1 or 2.0/1.1)
The USB (Universal Serial Bus) port is compatible with USB 3.0, 2.0,
or USB 1.1 devices such as keyboards, pointing devices, cameras,
and storage devices, connected in a series up to 4.8Gbits/sec (USB
3.0), 480Mbits/sec (USB 2.0), and 12Mbits/sec (USB 1.1).
5
Kensington® Lock port
The Kensington® lock port allows the Eee PC to be secured
using Kensington® compatible security products. These security
products usually include a metal cable and lock that prevent the
Eee PC to be removed from a fixed object.
6
LAN Port (10/100M bit or 10/100/1000M bit)
The eight-pin RJ-45 LAN port supports a standard Ethernet cable
for connection to a local network.
ASUS Eee PC
1-7
Left Side
1
2
3
4
Refer to the diagram below to identify the components on this side of the
Eee PC.
Power (DC) Input
1
The supplied power adapter converts AC power to DC power
for use with this jack. Power supplied through this jack supplies
power to the Eee PC and charges the internal battery pack. To
prevent damage to the Eee PC and battery pack, always use the
supplied power adapter.
THE ADAPTER MAY BECOME WARM TO HOT WHEN IN USE. BE
SURE NOT TO COVER THE ADAPTER AND KEEP IT AWAY FROM
YOUR BODY.
2
15 pin D-Sub Display (Monitor) Output
3
USB Port (2.0/1.1)
4
Air Vents
The air vents allow cool air to enter and warm air to exit the Eee PC.
Ensure that paper, books, clothing, cables, or other objects do not
block any of the air vents or else overheating may occur.
1-8
Chapter 1: Knowing the Parts
Keyboard Usage
Special Function Keys
The following defines the colored hot keys on the Eee PC’s keyboard. The
colored commands can only be accessed by first pressing and holding the
function key while pressing a key with a colored command. Some function
icons appear in the Notification area after activation.
Zz Icon (F1): Places the Eee PC in suspend mode
(Save-to-RAM).
Radio Tower (F2) (Wireless Models Only): Toggles the
internal wireless LAN or Bluetooth (on selected models) ON
or OFF with an on-screen-display.
When enabled, the corresponding wireless indicator will
light.
Touchpad (F3): Toggles the touchpad ON/OFF.
Resolution Selection (F4): Press to adjust the display
resolution.
Sun Down Icon (F5): Decreases the display brightness.
Sun Up Icon (F6): Increases the display brightness.
Crossed Screen Icon (F7): Turns off the display backlight.
LCD/Monitor Icons (F8): Toggles between the Eee PC’s
LCD display and an external monitor.
Task Manager Icon (F9): Initiates the Task Manager to
view the application process or terminates applications.
Crossed Speaker Icon (F10): Mutes the speaker.
ASUS Eee PC
1-9
Volume Down Icon (F11): Decreases speaker volume.
Volume Up Icon (F12): Increases the speaker volume.
Super Hybrid Engine (Fn+Space Bar): Toggles among
various power saving modes. The selected mode is shown
on the display.
Num Lk (Insert): Toggles the numeric keypad
(number lock) ON and OFF. Allows use of a larger portion of
the keyboard for number entering.
Scr Lk (Delete): Toggles the “Scroll Lock” ON and OFF.
Allows you to use a larger portion of the keyboard for cell
navigation.
Pg Up (↑): Press to scroll up in documents or the web
browser.
Pg Dn (↓): Press to scroll down in documents or the web
browser.
Home (←): Press to move the pointer to the beginning of
the line.
End (→): Press to move the pointer to the end of the line.
Windows icon: Displays the start menu.
Menu with pointer icon : Activates the properties menu
and is equivalent to right-clicking the touchpad/mouse on
an object.
1-10
Chapter 1: Knowing the Parts
Touchpad Usage
Clicking/Tapping - With the pointer over an item, press the left button
or use your fingertip to touch the touchpad lightly, keeping your finger
on the touchpad until the item is selected. The selected item will change
color. The following 2 illustrations produce the same results.
Double-clicking/Double-tapping - This is a common skill for launching
a program directly from the corresponding icon you select. Move the
pointer over the icon you wish to execute, press the left button or tap the
pad twice in rapid succession, and the system launches the corresponding
program. If the interval between the clicks or taps is too long, the
operation will not be executed. The following 2 illustrations produce the
same results.
ASUS Eee PC
1-11
Loading...
