ASUS SignArrange
User Guide
1
Table of Contents
Start using ASUS SignArrange…………………………………………………………………………………………. 3
Authorization via Serial Number…………………………………………………………………………………….. 4
Let’s get started with ASUS SignArragne…………………………………………………………………………. 6
1.Enter this APP………………………………………………………………………………………………………….. 6
2.Settings……………………………………………………………………………………………………………………. 6
2.1Start………………………………………………………………………………………………………………….. 7
2.2Account…………………………………………………………………………………………………………….. 8
2.3System………………………………………………………………………………………………………………. 9
Template downloading, Scheduling and Recurring.………..……………………………………………….. 11 “Landscape & Portrait template” play back content allocation and file folder setting………. 12 Landscape Template…………………………….…………………………………………………………………………. 13 Portrait Template………………………….………………………………………………………………………………… 15 “Number Calling Template” play back content allocation and file folder setting……………... 17 Number Calling template………………………………………………………………………………………………... 19 Prepare the content and an example………………………………………………………………………………. 21 Network content…………..……………………..………………………………………………………………………... 24 Things to know…………………………………..……………………..…………………………………………………... 26
2
Welcome! ASUS SignArrange, a standalone digital signage software designed for ASUS Android device. It can load various templates and play content from USB drive/SD card or local PC folder. Neither server nor back office needed. It is simple and easy to use yet flexible and powerful for many non-networked and networked Applications.
Start using ASUS SignArrange
1.Turn on your android device and access internet.
2.Click the ASUS SignArrange icon.
3.SignArrange APP will automatically detect and show the corresponding hardware serial number. Choose “Activate” to start this APP.
4.Once activated, you will NOT see Activation screen again.
5.Select a template.
6.Store the contents in either USB or SD card, the android device will detect the media files such as photos, videos or texts. (Please see detail in the next section.)
7.If choosing network content playback, this APP will automatically search and download the available contents. If not found, the APP will automatically play the contents downloaded last time.
3
Authorization via Serial Number
1.For first time use, ASUS Android device will automatically authorize the right to access SignArrange APP while connecting online. Machines will keep authorizing every time turning on until authorizing successfully.
2.For those unsuccessfully authorized android machines, “free trail” is the alternative for those machines.
3.Go to “Settings” → “account” to look for “authorized serial number” for the android machines that have been activated successfully.
(Figure 1)
G3LSKW001670
Automatically authorize the APP for first time use when connecting online.
(Figure 2)
Click “Settings” to enter “Start” , “Account” & “System”.
4
(Figure 3)
Click “Account” to look for authorized serial number.
(Figure 4)
(Note: User can click on the “Active” button beside license key while choosing free trail. )
5
Let’s get started with ASUS SignArrange
1. Click ASUS SignArrange |
to enter this APP. |
Click to Playback.
Click to Set up.
Click to Exit.
2. “Settings”
Start, Account & System are the three functions in “Set up” menu. Click “Done” to exit this page.
6
2.1Start
There are two options to choose. Click on “Save” button to save.
1)Start app when power up: Auto start this app when power up. Default is OFF. [Note] Be sure to turn on if you dedicated this APP for the devices.
2)Start app when alarm: Set time for auto start and auto stop. Be sure to have correct time and time zone setting in your Android device.
[Note] CA001, SA495-Y & SA555-Y have RTC (real time clock) to make sure the on/off time of this APP; CAX21 always has to connect online to make sure the correctness of time, otherwise will make the schedule malfunction.
[Note] This program does NOT wake up device when power off .
7
2.2Account
It shows the license key, the template-selected button, Schedule and Recurrence On/Off button. Click on “Save” button to save.
Please see next chapter on downloading template and making contents in detail.
Click on “Template 1”button to select the template and “OK” button to save.
Landscape (H)
Number Calling
(NUM)
Portrait (V)
8
