B250M-C PRO
CONFIDENTIAL
Agenda
• Produce Overview- B250M-C PRO
– Product Position / Schedule
– Product Overview
– Product Spec
• Product Unique features
– Anti-Moisture Coating
– Anti-Sulfur Resistors
– 10K Japanese capacitors
• Commercial Motherboard
– Dependable Reliability
24/7 Dependability
– Efficient Management
ASUS BIOS Tools
– EZ Assembling
Box-header Design |
Fixed-position Connectors | Colored Connectors
| Enhanced ESD Design
| ACC Support
CONFIDENTIAL
Product Overview
B250M-C PRO
CONFIDENTIAL
Commercial Motherboard
Product Overview
B250M-C PRO
DVI-I Port
Display Port
10K Japanese Capacitors
USB3.0
LAN
Audio
PCIe SafeSlot
PCIe 3.0/2.0 x16
4 x DDR4 Slots
2133/2400 Support
Support 14nm CPU
®
Intel
LGA 1151 Socket
M.2 M Key
2242/2260/2280/22110
(PCIe x 4 mode)
®
Intel
SATA 6Gb/s Ports
B250 Chipset
CONFIDENTIAL
ASUS Commercial Motherboard
B250M-C PRO UNIQUE FEATURES
CONFIDENTIAL
Designed for Harsh Environment
• IT industry, server farms, communication base stations
• Outdoor and on-road applications, lighting and traffic control
• Marine, mining, agricultural and winery equipment
Anti-moisture coverage
Higher coverage than standard
design
Dust and Moisture, OUT!
10K Japanese
K
Capacitors
+
20% temperature
tolerance and 5X longer
lifespan
Card slagging and PCIe
breaking, OUT!
SafeSlot PCIex16
Fortified PCIe with solid soldering
Anti-sulfur resistors
Long-term protection
against electrical shorts
Sulfurization
and shorts, OUT!
CONFIDENTIAL
SafeSlot PCIe x16
Fortified PCIe with solid soldering, Avoid PCIe Slot breaking
and prevent the card from sagging.
SafeSlot is the PCIe slot reinvnted by ASUS and
engineered to provide superior and shearing
Special Metal design for better
strength
Anchored to the
motherboard by a
special hook
resistance which protect your graphics card
investment and keep the graphics card firmly in the
onboard slot.
CONFIDENTIAL
10K Japanese c ap acito rs
+20% temp. tolerance and 5X longer lifetime usage.
Temperature
tolerance
Lifespan
Standard Cap
10K Japanese Cap
5 times longer
Unique 10K Japanese capacitors
+20% temperature tolerance
and 5X longer lifespan
CONFIDENTIAL
Thermal test
Better thermal performance relative to competitors, this provides a longer
life-span of the system and components.
ASUS B250M-C PRO
ASUS B250M-C PRO
Competitor B250 Chipset
Competitor B250 Chipset
CONFIDENTIAL
Anti-sulfur resistors
B250M-C PRO can be operated under the harsh environments .
Against FOS issue
Under
Against Black
residue
(Flowers of Sulfur)
The critical environmental factors of sulfur pollution:
• Where oils, lubricants or fossil fuels are used
• Rubber seals, gaskets, grommets or molded coatings of affected material
• Air polluted industrial area or areas containing biological or volcanic gasses
CONFIDENTIAL
ReliabilityAnti-moisture Coating
An exceptional corrosion-resistance solution!
Standard design
Partial Coating
Anti-Moisture Coating provides
motherboard protection and
higher levels of humidity tolerance.
Higher coverage Coating
B250M-C PRO
Build up for populated
environments, such as
factories, data centers and
internet cafes.
Anti-moisture coating
on critical IC
Moisture
Exposed IC pins and
sensitive components
CONFIDENTIAL
Reliability-24/7 Op eration
Ensure safe and smooth operation
B250M-C PRO use military certified components and undergo punishing burn-in
tests, with temperatures of up to 55
Aging time
B250M-C PRO
168hr
24/7
Standard
24/7
168hr
°C for 168 hours and at humidity levels as 90%!
Relative
Temperature
Humidity
55°C
45°C
90%
85%
The best endurance of temperature and humidity
CONFIDENTIAL
ASUS Commercial Motherboard
ASUS COMMERCIAL
MOTHERBOARD
CONFIDENTIAL
ASUS Commercial Motherboard
Exclusive Features
ASUS is the world’s biggest and best-known motherboard brand, renowned for our
user-focused design thinking.
The ASUS commercial motherboard provides reliability, stability and easy
manageability by 5X Protection III, ASUS BIOS tool, EZ assembling design.
EZ
Dependable Reliability Efficiency Management
Assembly
CONFIDENTIAL
ASUS Commercial Motherboard
Commercial BIOS K it
Tailored BIOS tools for system integrat ion com panies!
ASUS understands how important a custo mize d product i mpacts u se rs’ mind share,
experience the brand ne w ASUS CM BIOS tools for partial B IO S update solution!
DMI value edit tool
BIOS value edit tool
ME update tool
Logo flash tool
OA key tool
Add customer’s information such as company name in to BIOS.
Customized BIOS option.
Update ME without flash whole BIOS.
Add customer’s LOGO through updating BIOS.
Add or remove OA key.
.
ASUS BIOS Tools minimize SI’s response time!
*Please contact local TSD/FAE to obtain the related BIOS tools for manufacturing requests.
CONFIDENTIAL
ASUS Commercial Motherboard
Commercial BIOS K it
Assume a SI have a Logo flash request for 1000pcs motherboards
ASUS Commercial BIOS Kit
6X Faster
By segmented BIOS design
120
Sec.
Before(eg. B150M-C)
120
sec
120
Sec
120
Sec
After(eg. PRIME B250M-C)
20
sec
20
Sec
20
20
Sec.
Sec
CONFIDENTIAL
ASUS Control Center
Provides high visibility and the best IT-management experiences
ASUS Control Center
is a centralized IT-management suite that
enhances enterprise productivity with
comprehensive control through a very
friendly user interface.
*Each purchase of a Corporate Stable Model product
entitles the customer to the free Classic edition of
Control Center.
Hardware &
Software Monitoring
Remote
Management
Asset
Management
Mobile
Control
Security
CONFIDENTIAL
ASUS Commercial Motherboard
Reliability-Enhan ced ESD Protection
ESD can happen suddenly, and damage is easily underestimated.
ASUS ESD Guards prevent damage from electrostatic discharge, up to +/- 10kV for air
discharge and +/-6kV for contact discharge.
Audio port
LAN port
USB Connectors
DP, D-SUB, DVI,
HDMI port
Keyboard & mouse
USB 3.0 & USB 2.0 header
ASUS providing greater component longevity
CONFIDENTIAL
ASUS Commercial Motherboard
EZ Assembly-Box-header Design
Box headers for common USB 3.0 & 2.0 headers
Standard design
Easy lead to pin bend
With Box header design
Quickly install and
keep pins safe
CONFIDENTIAL
ASUS Commercial Motherboard
EZ AssemblingFixed-position Connectors
ASUS promise all CM Series MBs keep key connectors consistence.
No need to worry changing chassis layout when using different MBs!
Front
panel
Audio
LPT
header
TPM
header
USB
header
SATA ports
Promote your competitiveness
with ASUS!
CONFIDENTIAL
Intel® Optane Memory Ready
SUPERB PERFORMANCE
CONFIDENTIAL
Intel® Optane Memory Ready
Superb Performance
Intel Optane Memory Ready
Intel® Optane™ memory* is a revolutionary high-speed
storage technology — and it’s built right into Prime 200
series motherboards! Intel Optane accelerates your
storage devices** to reduce boot times and speed
application launches, so everything just feels faster,
smoother and more fun.
* Enabled by the use of an 7th-generation Intel® processor, driver and BIOS update
** Enabled by relevant BIOS update and drivers
32GB/S M.2*
Speed up with onboard M.2 — up to 32Gbps
With x4 PCI Express 3.0/2.0 bandwidth, M.2 supports
up to 32Gbps data-transfer speeds. It is the perfect
choice for an operating system or application drive,
making your whole PC or professional apps work as
fast as possible.
CONFIDENTIAL
Commercial Motherboard
kabylake Platfo rm Overview
EDP
3 DDI
10/100/1000
LAN PHY
PCIE 3.0
SATA 6Gb/s
th
7 Gen
Intel®
Processor
DMI 3.0
Intel®
Q270/B250
Series
Chipset
DDR4 2400
DDR3L 1600
X16 PCIE 3.0
USB 3.0
USB 2.0
CPU Advantages
• LGA 1151 Socket
• 14nm CPU
• DDR4 & DDR3L support
• Up to 3 independent displays
• Support for Intel® Optane™ Technology*
Chipset Advantages
• PCIE 3.0 support
• PCIE RAID support**
• Up to 8 x USB 3.0 ports***
• Up to 6 x SATA 6Gb/s ports***
• Support for Intel® Optane™ Technology*
• Support Intel® vPro Technology****
CPU Compatibility
Enhanced SPI
SPI
* Intel® Optane Technology is only supported when using 7th Generation Intel® processors.
** Via Intel® Rapid Storage Technology and onboard HW design.
*** Via Intel I/O Port Flexibility Technology.
**** Intel® vPro will be supported on the platform when only using the corresponding CPU. Only Q-Series Chipset support Intel® vPro Technology.
LPC
Audio
SMBus
• Support 7th Gen Intel® Processor
• Support 6th Gen Intel® Processor*
