G41C-GS / G41C-S

User Manual

Version 1.2

Published December 2013

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identification or explanation and to the owners’ benefit, without intent to infringe.

Disclaimer:Disclaimer:

Disclaimer:

Disclaimer:Disclaimer:

Specifications and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or fitness for a particular purpose.

In no event shall ASRock, its directors, officers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of profits, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in

California, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

ContentsContents

Contents

ContentsContents

1 Introduction1 Introduction

1 Introduction

1 Introduction1 Introduction

1.1 Package Contents .......................................................... 5

1.2 Specifications ................................................................ 6

1.3 Motherboard Layout (G41C-GS / G41C-S) ................... 11

1.4 I/O Panel (G41C-GS) ..................................................... 12

1.5 I/O Panel (G41C-S) ........................................................ 13

2 Installation2 Installation

2 Installation

2 Installation2 Installation

2.1 Screw Holes ................................................................. 14

2.2 Pre-installation Precautions ........................................... 14

2.3 CPU Installation .............................................................. 15

2.4 Installation of Heatsink and CPU fan ............................. 17

2.5 Installation of Memory Modules (DIMM) ......................... 18

2.6 Expansion Slots (PCI and PCI Express Slots) ..................... 20

2.7 Jumpers Setup .............................................................. 21

2.8 Onboard Headers and Connectors .............................. 22

2.9 SATAII Hard Disk Setup Guide ....................................... 25

2.10 Serial ATA (SATA) / Serial ATAII (SATAII) Hard Disks

Installation ...................................................................... 26

2.11 Driver Installation Guide ............................................... 26

2.12 Untied Overclocking Technology .................................. 26

3 BIOS S3 BIOS S

3 BIOS S

3 BIOS S3 BIOS S

ETUP UTILITYETUP UTILITY

ETUP UTILITY

ETUP UTILITYETUP UTILITY

3.1 Introduction .................................................................... 27

3.1.1 BIOS Menu Bar .................................................... 27

3.1.2 Navigation Keys ................................................... 28

3.2 Main Screen ................................................................... 28

3.3 OC Tweaker Screen ...................................................... 30

3.4 Advanced Screen ......................................................... 34

3.4.1 CPU Configuration ................................................ 35

3.4.2 Chipset Configuration .......................................... 37

3.4.3 ACPI Configuration ............................................... 42

3.4.4 Storage Configuration ......................................... 43

3.4.5 PCIPnP Configuration ........................................... 45

3.4.6 Floppy Configuration ........................................... 46

3.4.7 Super IO Configuration ........................................ 47

3.4.8 USB Configuration ............................................... 48

3.5 Hardware Health Event Monitoring Screen .................. 49

3.6 Boot Screen ................................................................... 50

3.6.1 Boot Settings Configuration .................................. 50

......................................................................................................

...................................................

......................................................................................................

............................................................................................................

......................................................

............................................................................................................

......................................................................................

...........................................

......................................................................................

5 5

14 14

27 27

3.7 Security Screen ............................................................ 51

3.8 Exit Screen .................................................................... 52

4 Software Support4 Software Support

4 Software Support

4 Software Support4 Software Support

4.1 Install Operating System ............................................... 53

4.2 Support CD Information ................................................. 53

4.2.1 Running Support CD ............................................ 53

4.2.2 Drivers Menu ........................................................ 53

4.2.3 Utilities Menu ........................................................ 53

4.2.4 Contact Information .............................................. 53

......................................................................................

...........................................

......................................................................................

53 53

Chapter 1 IntroductionChapter 1 Introduction

Chapter 1 Introduction

Chapter 1 IntroductionChapter 1 Introduction

Thank you for purchasing ASRock G41C-GS / G41C-S motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control. It de-

livers excellent performance with robust design conforming to ASRock’s commit-

ment to quality and endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-by-step

guide to the hardware installation. Chapter 3 and 4 contain the configuration guide to

BIOS setup and information of the Support CD.

Because the motherboard specifications and the BIOS software might be

updated, the content of this manual will be subject to change without

notice. In case any modifications of this manual occur, the updated

version will be available on ASRock website without further notice. You

may find the latest VGA cards and CPU support lists on ASRock website

as well. ASRock website

If you require technical support related to this motherboard, please visit

our website for specific information about the model you are using.

www.asrock.com/support/index.asp

1.1 P1.1 P

ackack

1.1 P

1.1 P1.1 P

ASRock G41C-GS / G41C-S Motherboard

(Micro ATX Form Factor: 9.6-in x 7.8-in, 24.4 cm x 19.8 cm)

ASRock G41C-GS / G41C-S Quick Installation Guide ASRock G41C-GS / G41C-S Support CD

Two Serial ATA (SATA) Data Cables (Optional)

One I/O Panel Shield

age Contentsage Contents

ack

age Contents

ackack

age Contentsage Contents

http://www.asrock.com

1.21.2

SpecificationsSpecifications

1.2

Specifications

1.21.2

SpecificationsSpecifications

Platform - Micro ATX Form Factor: 9.6-in x 7.8-in, 24.4 cm x 19.8 cm CPU - LGA 775 for Intel

CoreTM 2 Extreme / CoreTM 2 Quad / Core

2 Duo / Pentium® Dual Core / Celeron® Dual Core / Celeron®,

supporting Penryn Quad Core Yorkfield and Dual Core

Wolfdale processors

- Supports FSB1333/1066/800/533 MHz

- Supports Hyper-Threading Technology (see CAUTION 1)

- Supports Untied Overclocking Technology (see CAUTION 2)

- Supports EM64T CPU

Chipset - Northbridge: Intel

G41

- Southbridge: Intel® ICH7

Memory - Dual Channel DDR3/DDR2 Memory Technology

(see CAUTION 3)

- 2 x DDR3 DIMM slots

- Supports DDR3 1333(OC)/1066/800 non-ECC, un-buffered memory (see CAUTION 4)

- Max. capacity of system memory: 8GB (see CAUTION 5)

- 2 x DDR2 DIMM slots

- Supports DDR2 800/667/533 non-ECC, un-buffered memory (see CAUTION 4)

- Max. capacity of system memory: 8GB (see CAUTION 5)

Expansion Slot - 1 x PCI Express x16 slot

- 1 x PCI Express x1 slot

- 2 x PCI slots

Graphics - Intel

Graphics Media Accelerator X4500

- Pixel Shader 4.0, DirectX 10

- Max. shared memory 1759MB (see CAUTION 6)

- Supports D-Sub with max. resolution up to 2048x1536

@ 75Hz

Audio - 5.1 CH HD Audio (Realtek ALC662 / VIA

VT1705 Audio Codec)

LAN - G41C-GS:

Realtek PCIE x1 Gigabit LAN RTL8111DL,

speed 10/100/1000 Mb/s

- G41C-S:

Realtek PCIE x1 LAN 8103EL / 8102EL, speed 10/100 Mb/s

- Supports Wake-On-LAN

Rear Panel I/O I/O Panel

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x Serial Port: COM1

- 1 x VGA Port

- 4 x Ready-to-Use USB 2.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)

- HD Audio Jack: Line in / Front Speaker / Microphone

Connector - 4 x SATAII 3.0 Gb/s connectors (No Support for RAID and

“Hot Plug” functions) (see CAUTION 7)

- 1 x ATA100 IDE connector (supports 2 x IDE devices)

- 1 x Floppy connector

- 1 x Print port header

- CPU/Chassis/Power FAN connector

- 24 pin ATX power connector

- 4 pin 12V power connector

- Front panel audio connector

- 2 x USB 2.0 headers (support 4 USB 2.0 ports) (see CAUTION 8)

BIOS Feature - 8Mb AMI BIOS

- AMI Legal BIOS

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- SMBIOS 2.3.1 Support

- VCCM, NB, VTT, GTLRef Voltage Multi-adjustment

- Supports Smart BIOS

Support CD - Drivers, Utilities, AntiVirus Software (Trial Version), Google

Chrome Browser and Toolbar

Unique Feature - ASRock OC Tuner (see CAUTION 9)

- Intelligent Energy Saver (see CAUTION 10)

- Instant Boot

- ASRock Instant Flash (see CAUTION 11)

- ASRock OC DNA (see CAUTION 12)

- Hybrid Booster:

- CPU Frequency Stepless Control (see CAUTION 13)

- ASRock U-COP (see CAUTION 14)

- Boot Failure Guard (B.F.G.)

Hardware - CPU Temperature Sensing Monitor - Chassis Temperature Sensing

- CPU/Chassis/Power Fan Tachometer

- CPU Quiet Fan

- Voltage Monitoring: +12V, +5V, +3.3V, Vcore

OS - Microsoft

Windows® 7 / 7 64-bit / Vista

/ VistaTM 64-bit /

XP / XP 64-bit compliant

Certifications - FCC, CE

- EuP Ready (EuP ready power supply is required) (see CAUTION 15)

* For detailed product information, please visit our website:

WAR NING

Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using the thirdparty overclocking tools. Overclocking may affect your system stability, or even cause damage to the components and devices of your system. It should be done at your own risk and expense. We are not responsible for possible damage caused by overclocking.

http://www.asrock.com

CAUTION!

1. About the setting of “Hyper Threading Technology”, please check page 36.

2. This motherboard supports Untied Overclocking Technology. Please read “Untied Overclocking Technology” on page 26 for details.

3. This motherboard supports Dual Channel Memory Technology . Before you implement Dual Channel Memory Technology, make sure to read the installation guide of memory modules on page 18 for proper installation.

4. Please check the table below for the CPU FSB frequency and its corresponding memory support frequency.

CPU FSB Frequency Memory Support Frequency

1333 DDR3 800, DDR3 1066, DDR3 1333

DDR2 667, DDR2 800

1066 DDR3 800, DDR3 1066

DDR2 667, DDR2 800

800 DDR3 800

DDR2 667, DDR2 800

533 DDR3 800

DDR2 533 * DDR3 1333 memory modules will operate in overclocking mode. * When you use a FSB533-CPU on this motherboard, it will run at

DDR3 533 if you adopt a DDR3 800 memory module.

* If you adopt FSB1333-CPU and DDR3 1333 memory module on this

motherboard, you need to adjust the jumper. Please refer to page 22 for proper jumper settings.

5. Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 7 / VistaTM / XP. For Windows® OS with 64-bit CPU, there is no such limitation. In order to maximize the system memory, please install 4GB memory module with 16 cells or 2GB memory modules with at least 8 cells.

6. The maximum shared memory size is defined by the chipset vendor and is subject to change. Please check Intel® website for the latest information.

7. Before installing SATAII hard disk to SATAII connector, please read the “SAT AII Hard Disk Setup Guide” on page 25 to adjust your SATAII hard disk drive to SATAII mode. You can also connect SATA hard disk to SATAII connector directly.

8. Power Management for USB 2.0 works fine under Microsoft® Windows 7 64-bit / 7 / VistaTM 64-bit / VistaTM / XP 64-bit / XP SP1 or SP2.

9. It is a user-friendly ASRock overclocking tool which allows you to surveil your system by hardware monitor function and overclock your hardware devices to get the best system performance under Windows® environment. Please visit our website for the operation procedures of ASRock OC Tuner. ASRock website:

10. Featuring an advanced proprietary hardware and software design, Intelligent Energy Saver is a revolutionary technology that delivers unparalleled power savings. In other words, it is able to provide exceptional power saving and improve power efficiency without sacrificing computing performance. Please visit our website for the operation procedures of Intelligent Energy Saver. ASRock website: http://www.asrock.com

11. ASRock Instant Flash is a BIOS flash utility embedded in Flash ROM. This convenient BIOS update tool allows you to update system BIOS without entering operating systems first like MS-DOS or Windows®. With this utility, you can press <F6> key during the POST or press <F2> key to BIOS setup menu to access ASRock Instant Flash. Just launch this tool and save the new BIOS file to your USB flash drive, floppy disk or hard drive, then you can update your BIOS only in a few clicks without preparing an additional floppy diskette or other complicated flash utility. Please be noted that the USB flash drive or hard drive must use FAT32/16/12 file system.

12. The software name itself – OC DNA literally tells you what it is capable of. OC DNA, an exclusive utility developed by ASRock, provides a convenient way for the user to record the OC settings and share with others. It helps you to save your overclocking record under the operating system and simplifies the complicated recording process of overclocking settings. With OC DNA, you can save your OC settings as a profile and share with your friends! Your friends then can load the OC profile to their own system to get the same OC settings as yours! Please be noticed that the OC profile can only be shared and worked on the same motherboard.

13. Although this motherboard offers stepless control, it is not recommended to perform over-clocking. Frequencies other than the recommended CPU bus frequencies may cause the instability of the system or damage the CPU.

14. While CPU overheat is detected, the system will automatically shutdown. Before you resume the system, please check if the CPU fan on the motherboard functions properly and unplug the power cord, then plug it back again. To improve heat dissipation, remember to spray thermal grease between the CPU a nd the he atsink when you in stall the PC system.

http://www.asrock.com

15. EuP, stands for Energy Using Product, was a provision regulated by

European Union to define the power consumption for the completed system.

According to EuP, the total AC power of the completed system shall be

under 1.00W in off mode condition. To meet EuP standard, an EuP ready

motherboard and an EuP ready power supply are required. According to

Intel’s suggestion, the EuP ready power supply must meet the standard of

5v standby power efficiency is higher than 50% under 100 mA current

consumption. For EuP ready power supply selection, we recommend you

checking with the power supply manufacturer for more details.

1010

1.3 Motherboard Layout (G41C-GS / G41C-S)1.3 Motherboard Layout (G41C-GS / G41C-S)

1.3 Motherboard Layout (G41C-GS / G41C-S)

1.3 Motherboard Layout (G41C-GS / G41C-S)1.3 Motherboard Layout (G41C-GS / G41C-S)

19.8cm (7.8 in)

Keyboard

Mouse

PS2

PS2_USB_PWR1

ATX12V2

CPU_FAN1

COM1

VGA1

EuP Ready

FSB1333

DDR2 800

USB 2.0 T: U SB 2 B: USB3

USB 2.0 T: U SB 0 B: USB1

MicIn

28 27

26 25

Bottom:

LineOut

HD_AUDIO1

LPT1

CODEC

Center:

AUDIO

RoHS

Top: RJ-45

LineIn

Top:

EUP_LAN

EUP_AUDIO1

CMOS

Battery

LAN PHY

PCIE2

Chipset

PCIE1

FSB1

Intel

G41

DX10

ICH7

Super

CLRCMOS1

FLOPPY1

PCI1

PCI2

8Mb BIOS

IDE1

USB4_5

PANEL1

PLEDPWRBTN

HDLED RESET

USB6_7

1819

DDR3 1333

Dual Channel

Intel

FSB800

DDRII_1 (64bit, 240-pin module)

SATAII_1

SATAII_2

FSB800

DDR3_A1 (64bit, 240-pin module)

DDRII_2 (64bit, 240-pin module)

SPEAKER1

FSB800

DDR3_B1 (64bit, 240-pin module)

PWR_FAN1

CHA_FAN1

SATAII_3

SATAII_4

24.4cm (9.6 in)

7 8

12 13

1 PS2_USB_PWR1 Jumper 16 Primary SATAII Connector (SA T AII_1; Red) 2 ATX 12V Connector (ATX12V2) 17 USB 2.0 Header (USB6_7, Blue) 3 CPU Fan Connector (CPU_FAN1) 18 USB 2.0 Header (USB4_5, Blue) 4 ATX Power Connector (ATXPW R1) 19 System Panel He a der (PANEL1, Orange) 5 2 x 240-pin DDR2 DIMM Slots 20 BIOS SPI Chip

(Dual Channel: DDRII_1, DDRII_2; Yellow) 21 Floppy Connector (FLOPPY1)

6 2 x 240-pin DDR3 DIMM Slots 22 Print Port Header (LPT1, Purple)

(Dual Channel: DDR3_A1, DDR3_B1; Blue) 23 Clear CMOS Jumper (CLRCMOS1) 7 North Bridge Controller 2 4 PCI Slots (PCI1-2) 8 PCI Express x16 Slot (PCIE1) 25 FSB1 Jumper 9 Power Fan Connector (PWR_FAN1) 26 PCI Express x1 Slot (PCIE2) 10 Chassis Fan Connector (CHA_FAN1) 27 EUP Audio Jumper (EUP_AUDIO1) 11 IDE1 Connector (IDE1, Blue) 28 EUP LAN Jumper (EUP_LAN1) 12 Third SA TAII Connector (SAT AII_3; Red) 29 Front Panel Audio Header 13 Fourth SA TAII Connector (SAT AII_4; Red) (HD_AUDIO1, Lime) 14 Chassis Speaker Header (SPEAKER 1, Purple) 30 775-Pin CPU Socket 15 Secondary SA T AII Connector (SA T AII_2; Red)

1111

1.4 I/O Panel (G41C-GS)1.4 I/O Panel (G41C-GS)

1.4 I/O Panel (G41C-GS)

1.4 I/O Panel (G41C-GS)1.4 I/O Panel (G41C-GS)

910

1 PS/2 Mouse Port (Green) 6 USB 2.0 Ports (USB01)

* 2 RJ-45 Port 7 USB 2.0 Ports (USB23)

3 Line In (Light Blue) 8 VGA Port 4 Line Out (Lime) 9 COM Port 5 Microphone (Pink) 10 PS/2 Keyboard Port (Purple)

LAN Port LED Indications

Activity/Link LED SPEED LED

Status Description Status Description

Off No Activity Off 10Mbps connection

Blinking Data Activity Orange 100Mbps connection

Green 1Gbps connection

To enable Multi-Streaming function, you need to connect a front panel audio cable to the front

panel audio header. Please refer to below steps for the software setting of Multi-Streaming. For Windows® XP:

After restarting your computer, you will find “Mixer” tool on your system. Please select “Mixer

ToolBox” , click “Enable playback multi-streaming”, and click “ok”. Choose “2CH” or

ACT/LINK LED

LAN Port

SPEED LED

“4CH” and then you are allowed to select “Realtek HDA Primary output” to use Rear Speaker

and Front Speaker, or select “Realtek HDA Audio 2nd output” to use front panel audio. Then

reboot your system. For Windows® 7 / VistaTM:

After restarting your computer, please double-click “Realtek HD Audio Manager” on the

system tray. Set “Speaker Configuration” to “Quadraphonic” or “Stereo”. Click “Device

advanced settings”, choose “Make front and rear output devices playbacks two different audio

streams simultaneously”, and click “ok”. Then reboot your system.

1212

1.4 I/O Panel (G41C-S)1.4 I/O Panel (G41C-S)

1.4 I/O Panel (G41C-S)

1.4 I/O Panel (G41C-S)1.4 I/O Panel (G41C-S)

910

1 PS/2 Mouse Port (Green) 6 USB 2.0 Ports (USB01)

* 2 RJ-45 Port 7 USB 2.0 Ports (USB23)

3 Line In (Light Blue) 8 VGA Port 4 Line Out (Lime) 9 COM Port 5 Microphone (Pink) 10 PS/2 Keyboard Port (Purple)

LAN Port LED Indications

Activity/Link LED SPEED LED

Status Description Status Description

Off No Activity Off 10Mbps connection

Blinking Data Activity Orange 100Mbps connection

To enable Multi-Streaming function, you need to connect a front panel audio cable to the front

panel audio header. Please refer to below steps for the software setting of Multi-Streaming. For Windows® XP:

After restarting your computer, you will find “Mixer” tool on your system. Please select “Mixer

ToolBox” , click “Enable playback multi-streaming”, and click “ok”. Choose “2CH” or

ACT/LINK LED

LAN Port

SPEED LED

“4CH” and then you are allowed to select “Realtek HDA Primary output” to use Rear Speaker

and Front Speaker, or select “Realtek HDA Audio 2nd output” to use front panel audio. Then

reboot your system. For Windows® 7 / VistaTM:

After restarting your computer, please double-click “Realtek HD Audio Manager” on the

system tray. Set “Speaker Configuration” to “Quadraphonic” or “Stereo”. Click “Device

advanced settings”, choose “Make front and rear output devices playbacks two different audio

streams simultaneously”, and click “ok”. Then reboot your system.

1313

Chapter 2 InstallationChapter 2 Installation

Chapter 2 Installation

Chapter 2 InstallationChapter 2 Installation

G41C-GS / G41C-S is a Micro ATX form factor (9.6" x 7.8", 24.4 x 19.8 cm)

motherboard. Before you install the motherboard, study the configuration of your

chassis to ensure that the motherboard fits into it.

Make sure to unplug the power cord before installing or removing the

motherboard. Failure to do so may cause physical injuries to you and

damages to motherboard components.

2.1 Screw Holes2.1 Screw Holes

2.1 Screw Holes

2.1 Screw Holes2.1 Screw Holes

Place screws into the holes indicated by circles to secure the motherboard to the

chassis.

Do not over-tighten the screws! Doing so may damage the motherboard.

2.2 Pre-installation Precautions2.2 Pre-installation Precautions

2.2 Pre-installation Precautions

2.2 Pre-installation Precautions2.2 Pre-installation Precautions

Take note of the following precautions before you install motherboard components

or change any motherboard settings.

1. Unplug the power cord from the wall socket before touching any component.

2. To avoid damaging the motherboard components due to static electricity, NEVER

place your motherboard directly on the carpet or the like. Also remember to use

a grounded wrist strap or touch a safety grounded object before you handle

components.

3. Hold components by the edges and do not touch the ICs.

4. Whenever you uninstall any component, place it on a grounded antistatic pad or

in the bag that comes with the component.

1414

Before you install or remove any component, ensure that the power is

switched off or the power cord is detached from the power supply.

Failure to do so may cause severe damage to the motherboard, peripherals,

and/or components.

2.3 CPU Installation2.3 CPU Installation

2.3 CPU Installation

2.3 CPU Installation2.3 CPU Installation

For the installation of Intel 775-LAND CPU,

please follow the steps below.

Before you insert the 775-LAND CPU into the socket, please check if

the CPU surface is unclean or if there is any bent pin on the socket.

Do not force to insert the CPU into the socket if above situation is

found. Otherwise, the CPU will be seriously damaged.

775-Pin Socket Overview

Step 1. Open the socket:

Step 1-1. Disengaging the lever by depressing

Lift Lever Up to 90°

down and out on the hook to clear

retention tab.

Step 1-2. Rotate the load lever to fully open po-

sition at approximately 135 degrees.

Step 1-3. Rotate the load plate to fully open po-

sition at approximately 100 degrees.

Step 2. Insert the 775-LAND CPU:

Step 2-1. Hold the CPU by the edges where are

marked with black lines.

Step 2-2. Orient the CPU with IHS (Integrated

Heat Sink) up. Locate Pin1 and the two

orientation key notches.

Pin1

orientation

key notch

orientation

key notch

CPU Marked Corner

Socket Marked Corner

alignment key

Pin1

black line

alignment key

775-LAND CPU

775-Pin Socket

1515

For proper inserting, please ensure to match the two orientation key

notches of the CPU with the two alignment keys of the socket.

Step 2-3. Carefully place the CPU into the socket

by using a purely vertical motion.

Step 2-4. Verify that the CPU is within the socket

and properly mated to the orient keys.

Step 3. Remove PnP Cap (Pick and Place Cap):

Use your left hand index finger and thumb to

support the load plate edge, engage PnP cap

with right hand thumb and peel the cap from the

socket while pressing on center of PnP cap to

assist in removal.

1. It is recommended to use the cap tab to handle and avoid kicking

off the PnP cap.

2. This cap must be placed if returning the motherboard for after

service.

Step 4. Close the socket:

Step 4-1. Rotate the load plate onto the IHS.

Step 4-2. While pressing down lightly on load

plate, engage the load lever.

Step 4-3. Secure load lever with load plate tab

under retention tab of load lever.

1616

+ 37 hidden pages

Asrock G41C-GS User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
