Asrock Fatal1ty B450 Gaming K4 Quick Installation Guide

Version 1.0
Published June 2018
Copyright©2018 ASRock INC. All rights reserved.

Copyright Notice:

No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Inc.

Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock. ASRock assumes no responsibility for
any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or tness for a particular
purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of prots, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from any
defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for
any other reasonably foreseeable loss or damage caused by our goods. You are also entitled
to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure. If you require assistance please call ASRock Tel

: [phone] ext.123 (Standard International call charges apply)

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI
logo are trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries.

Fatal1ty Story

Who knew that at age 19, I would be a World Champion PC gamer. When I was 13, I actually
played competitive billiards in professional tournaments and won four or ve games o guys
who played at the highest level. I actually thought of making a career of it, but at that young
age situations change rapidly. Because I’ve been blessed with great hand-eye coordination and
a grasp of mathematics (an important element in video gaming) I gravitated to that activity.

GOING PRO

I started professional gaming in 1999 when I entered the CPL (Cyberathlete Professional
League) tournament in Dallas and won $4,000 for coming in third place. Emerging as one
of the top players in the United States, a company interested in sponsoring me ew me to
Sweden to compete against the top 12 players in the world. I won 18 straight games, lost
none, and took rst place, becoming the number one ranked Quake III player in the world
in the process. Two months later I followed that success by traveling to Dallas and defending
my title as the world’s best Quake III player, winning the $40,000 grand prize. From there
I entered competitions all over the world, including Singapore, Korea, Germany, Australia,
Holland and Brazil in addition to Los Angeles, New York and St. Louis.

WINNING STREAK

I was excited to showcase my true gaming skills when defending my title as CPL
Champion of the year at the CPL Winter 2001 because I would be competing in a totally
dierent rst person shooter (fps) game, Alien vs. Predator II. I won that competition and
walked away with a new car. e next year I won the same title playing Unreal Tournament
2003, becoming the only three-time CPL champion of the year. And I did it playing a
different game each year, something no one else has ever done and a feat of which I am
extremely proud.

At QuakeCon 2002, I faced o against my rival ZeRo4 in one of the most highly
anticipated matches of the year, winning in a 14 to (-1) killer victory. Competing at Quakecon
2004, I became the World’s 1st Doom3 Champion by defeating Daler in a series of very
challenging matches and earning $25,000 for the victory.

Since then Fatal1ty has traveled the globe to compete against the best in the world, winning
prizes and acclaim, including the 2005 CPL World Tour Championship in New York City for
a $150,000 rst place triumph. In August 2007, Johnathan was awarded the rst ever Lifetime
Achievement Award in the four year history of the eSports-Award for “showing exceptional
sportsmanship, taking part in shaping eSports into what it is today and for being the prime
representative of this young sport. He has become the gurehead for eSports worldwide”.

LIVIN’ LARGE

Since my rst big tournament wins, I have been a “Professional Cyberathlete”, traveling the
world and livin’ large with lots of International media coverage on outlets such as MTV,
ESPN and a 60 Minutes segment on CBS to name only a few. It's unreal - it's crazy. I’m living
a dream by playing video games for a living. I’ve always been athletic and took sports like
hockey and football very seriously, working out and training hard. is discipline helps me
become a better gamer and my drive to be the best has opened the doors necessary to become
a professional.

A DREAM

Now, another dream is being realized – building the ultimate gaming computer, made
up of the best parts under my own brand. Quality hardware makes a huge difference in
competitions…a couple more frames per second and everything gets really nice. It’s all about
getting the computer processing faster and allowing more uid movement around the maps.

My vision for Fatal1ty hardware is to allow gamers to focus on the game without worrying
about their equipment, something I’ve preached since I began competing. I don’t want to
worry about my equipment. I want to be there – over and done with - so I can focus on
the game. I want it to be the fastest and most stable computer equipment on the face of the
planet, so quality is what Fatal1ty Brand products represent.

Johnathan “Fatal1ty” Wendel

e Fatal1ty name, Fatal1ty logos and the Fatal1ty likeness are registered trademarks of Fatal1ty, Inc., and are used
under license. © 2018 Fatal1ty, Inc. All rights reserved. All other trademarks are the property of their respective
owners.

Motherboard Layout

ATXPWR1

Supe r

I/O

CLRCMOS2

1

1

USB_3_4

HD_AUDIO1

1

Top:

LINE IN

Center :

FRONT

Bottom :

MIC IN

RJ- 45 LAN

SOCKETAM4

1

COM1

HDM I1

CMOS

Battery

ATX12V1

M2_ 1

Ultra M.2

PCIe Gen3x4

USB3_5 _6

1

CHA_FAN1/WP

HDLED RESET

PLED PWRBTN

PANEL1

1

RoHS

SPK_PLED1

1

DDR 4_A1 (6 4 bit, 28 8-pin m odule )

DDR 4_A2 (6 4 bit, 28 8-pin m odule )

DDR 4_B1 (6 4 bit, 28 8-pin m odule )

DDR 4_B2 (6 4 bit, 28 8-pin m odule )

PCIE1

M2_ 2

AMD

Promontory

B450

USB 3.1 Gen1

T: USB1
B: USB2

USB 3.1 Gen1

T: USB3
B: USB4

AMD_FAN_LED1

1

1

USB_1_2

TPMS1

1

SATA3_1

SATA3_2

SATA3_A1

B450 G aming K4

PCIE2

PCIE3

PCIE5

PCIE6

PCIE4

CHA_FAN2/WP CHA_FAN3/WP

SATA3_A2

SATA3_3

SATA3_4

USB 3.1 Gen2
T: USB31_TA_1
B:USB31_TC_1

USB 2. 0

T: USB5

B: USB 6

PS2

Keyb oard

/Mou se

26

27

VGA 1

FATALTY

1

DISP LAY1

CPU_FAN2/WP

CPU_FAN1

1

ADDR_LED1

1

RGB_LED1

9

23

24

Fatal1ty B450 Gaming K4 Series

1

2

4

3

5

6

BIOS
ROM

7

8

10

11

12

13

25

22

21

20

17

18

19

15

16

14

English

1

No. Description

1 ATX 12V Power Connector (ATX12V1)

2 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)

3 AMD Fan LED Header (AMD_FAN_LED1)

4 CPU Fan / Waterpump Fan Connector (CPU_FAN2/WP)

5 CPU Fan Connector (CPU_FAN1)

6 ATX Power Connector (ATXPWR1)

7 USB 3.1 Gen1 Header (USB3_5_6)

8 SATA3 Connector (SATA3_2)

9 SATA3 Connector (SATA3_1)

10 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)

11 SATA3 Connector (SATA3_A1)

12 SATA3 Connector (SATA3_A2)

13 SATA3 Connector (SATA3_3)

14 SATA3 Connector (SATA3_4)

15 Power LED and Speaker Header (SPK_PLED1)

16 System Panel Header (PANEL1)

17 Chassis Fan / Waterpump Fan Connector (CHA_FAN3/WP)

18 Chassis Fan / Waterpump Fan Connector (CHA_FAN2/WP)

19 Clear CMOS Jumper (CLRCMOS2)

20 Addressable LED Header (ADDR_LED1)

21 USB 2.0 Header (USB_3_4)

22 USB 2.0 Header (USB_1_2)

23 COM Port Header (COM1)

24 RGB LED Header (RGB_LED1)

25 TPM Header (TPMS1)

26 Front Panel Audio Header (HD_AUDIO1)

27 Chassis Fan / Waterpump Fan Connector (CHA_FAN1/WP)

English

2

I/O Panel

Fatal1ty B450 Gaming K4 Series

1

2

13

No. Description

1 Fatal1ty Mouse Port (USB5)

2 USB 2.0 Port (USB6)

3 DisplayPort 1.2

4 LAN RJ-45 Port*

5 Line In (Light Blue)**

6 Front Speaker (Lime)**

7 Microphone (Pink)**

* ere are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.

3

9 8101214

11

No. Description

8 USB 3.1 Gen1 Ports (USB3_34)

9 USB 3.1 Gen1 Ports (USB3_12)

10 USB 3.1 Gen2 Type-A Port (USB31_TA_1)

11 USB 3.1 Gen2 Type-C Port (USB31_TC_1)

12 HDMI Port

13 D-Sub Port

14 PS/2 Mouse/Keyboard Port

4

5

6

7

ACT/LINK LED

SPEED LED

LAN Por t

Activity / Link LED Speed LED

Status Description Status Description

O No Link O 10Mbps connection
Blinking Data Activity Orange 100Mbps connection
On Link Green 1Gbps connection

English

3

** To congure 7.1 CH HD Audio, it i s required to use an HD front panel audio module and enable the multi­channel audio feature through the audio driver.

Please set Speaker Conguration to “7.1 Speaker”in the Realtek HD Audio Manager.

Function of the Audio Ports in 7.1-channel Conguration:

English

4

Port Function

Light Blue (Rear panel) Rear Speaker Out
Lime (Rear panel) Front Speaker Out
Pink (Rear panel) Central /Subwoofer Speaker Out
Lime (Front panel) Side Speaker Out

Fatal1ty B450 Gaming K4 Series

Chapter 1 Introduction

ank you for purchasing ASRock Fatal1ty B450 Gaming K4 Series motherboard,
a reliable motherboard produced under ASRock ’s consistently stringent quality
control. It delivers excellent performance with robust design conforming to
ASRock’s commitment to quality and endurance.

Becau se the motherboard specications and the BIOS soware might be updated, the
content of this manual will be subject to change without notice. In ca se any modica­tions of this manual occur, the updated version will be available on ASRock’s website
without further notice. If you require technical suppor t related to this motherboard,
please visit our website for spe cic information about the model you are using. You
may nd the l atest VGA cards and CPU support list on ASRock’s website a s well.
ASRock website http://www.asrock.com.

1.1 Package Contents

ASRock Fatal1ty B450 Gaming K4 Series Motherboard (ATX Form Factor)

•

ASRock Fatal1ty B450 Gaming K4 Series Quick Installation Guide

•

ASRock Fatal1ty B450 Gaming K4 Series Support CD

•

1 x I/O Panel Shield

•

2 x Serial ATA (SATA) Data Cables (Optional)

•

2 x Screws for M.2 Sockets (Optional)

•

English

5

1.2 Specications

Platform

CPU

Chipset

Memory

* Please refer to Memory Support List on ASRock’s website for
more information. (http://www.asrock.com/)
* Please refer to page 23 for DDR4 UDIMM maximum frequency
support.

ATX Form Factor

•

Solid Capacitor design

•

AMD AM4 Socket

•

Digi Power design

•

9 Power Phase design

•

Supports 105W Water Cooling (Pinnacle Ridge); Supports

•

95W Water Cooling (Summit Ridge); Supports 65W Water
Cooling (Raven Ridge)

AMD Promontory B450

•

Dual Channel DDR4 Memory Technology

•

4 x DDR4 DIMM Slots

•

AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4

•

3200+(OC)/2933/2667/2400/2133 ECC & non-ECC, un­buered memory*
AMD Ryzen series CPUs (Summit Ridge) support DDR4

•

3200+(OC)/2933(OC)/2667/2400/2133 ECC & non-ECC, un­buered memory*
AMD Ryzen series CPUs (Raven Ridge) support DDR4

•

3200+(OC)/2933(OC)/2667/2400/2133 non-ECC, un-buered
memory*

Max. capacity of system memory: 64GB

•

15μ Gold Contact in DIMM Slots

•

English

6

Fatal1ty B450 Gaming K4 Series

Expansion
Slot

Graphics

AMD Ryzen series CPUs (Summit Ridge and Pinnacle Ridge)

2 x PCI Express 3.0 x16 Slots (PCIE2: x16 mode; PCIE4: x4

•

mode)*

AMD Ryzen series CPUs (Raven Ridge)

2 x PCI Express 3.0 x16 Slots (PCIE2: x8 mode; PCIE4: x4

•

mode)*

* Supports NVMe SSD as boot disks
* If M2_1 is occupied, PCIE4 will be disabled.

4 x PCI Express 2.0 x1 Slots

•

Supports AMD Quad CrossFireXTM and CrossFireXTM**

•

** is feature is only supported with Ryzen Series CPUs (Summit
Ridge, Pinnacle Ridge and Raven Ridge).

TM

Integrated AMD Radeon

•

Series APU*

* Actual support may vary by CPU

DirectX 12, Pixel Shader 5.0

•

Max. shared memory 2GB

•

Three graphics output options: D-Sub, HDMI and

•

DisplayPort 1.2

Supports Triple Monitor

•

Supports HDMI with max. resolution up to 4K x 2K

•

(4096x2160) @ 24Hz / (3840x2160) @ 30Hz
Supports DisplayPort 1.2 with max. resolution up to 4K x 2K

•

(4096x2160) @ 60Hz
Supports D-Sub with max. resolution up to 1920x1200 @

•

60Hz
Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

•

HBR (High Bit Rate Audio) with HDMI Port
(Compliant HDMI monitor is required)
Supports HDCP with HDMI and DisplayPort 1.2 Ports

•

Supports 4K Ultra HD (UHD) playback with HDMI and

•

DisplayPort 1.2 Ports

Vega Series Graphics in Ryzen

English

7

Audio

LAN

Rear Panel
I/O

7.1 CH HD Audio with Content Protection (Realtek ALC892

•

Audio Codec)
* To congure 7.1 CH HD Audio, it is required to use an HD
front panel audio module and enable the multi-channel audio
feature through the audio driver.

Premium Blu-ray Audio support

•

Supports Surge Protection

•

ELNA Audio Caps

•

PCB Isolate Shielding

•

Individual PCB Layers for R/L Audio Channel

•

Supports Creative SoundBlaster Cinema5

•

PCIE x1 Gigabit LAN 10/100/1000 Mb/s

•

Realtek RTL8111H

•

Supports Wake-On-LAN

•

Supports Lightning/ESD Protection

•

Supports Energy Ecient Ethernet 802.3az

•

Supports PXE

•

1 x PS/2 Mouse/Keyboard Port

•

1 x D-Sub Port

•

1 x HDMI Port

•

1 x DisplayPort 1.2

•

2 x USB 2.0 Ports (Supports ESD Protection)

•

* 1 x Fatal1ty Mouse Port (USB 2.0) is included

1 x USB 3.1 Gen2 Type-A Port (10 Gb/s) (Supports ESD Pro-

•

tec tion)

1 x USB 3.1 Gen2 Type-C Port (10 Gb/s) (Supports ESD Pro-

•

tec tion)

4 x USB 3.1 Gen1 Ports (Supports ESD Protection)

•

1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

•

LED)

HD Audio Jacks: Line in / Front Speaker / Microphone

•

English

8

Storage

Connector

Fatal1ty B450 Gaming K4 Series

4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,

•

RAID 1 and RAID 10), NCQ, AHCI and Hot Plug*
2 x SATA3 6.0 Gb/s Connectors by ASMedia ASM1061, sup-

•

port NCQ, AHCI and Hot Plug
* M2_2, SATA3_3 and SATA3_4 share lanes. If either one of
them is in use, the others will be disabled.

1 x Ultra M.2 Socket (M2_1), supports M Key type

•

2242/2260/2280 M.2 PCI Express module up to Gen3 x4

(32 Gb/s) (with Summit Ridge, Raven Ridge and Pinnacle

Ridge)**

1 x M.2 Socket (M2_2), supports M Key type

•

2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module and

M.2 PCI Express module up to Gen3 x2 (16 Gb/s)**
** If M2_1 is occupied, PCIE4 will be disabled.
** Supports NVMe SSD as boot disks
** Supports ASRock U.2 Kit

1 x COM Port Header

•

1 x TPM Header

•

1 x Power LED and Speaker Header

•

1 x RGB LED Header

•

* Supports in total up to 12V/3A, 36W LED Strip

1 x Addressable LED Header

•

* Supports in total up to 5V/3A, 15W LED Strip

1 x AMD Fan LED Header

•

*e AMD Fan LED Header supports LED strips of maximum
load of 3A (36W) and length up to 2.5M.

1 x CPU Fan Connector (4-pin)

•

* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.

1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan

•

Speed Control)
* e CPU/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.

3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan

•

Speed Control)
* e Chassis/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.

English

9

BIOS
Feature

Hardware
Monitor

* CPU_FAN2/WP, CHA_FAN1/WP, CHA_FAN2/WP and
CHA_FAN3/WP can auto detect if 3-pin or 4-pin fan is in use.

1 x 24 pin ATX Power Connector

•

1 x 8 pin 12V Power Connector

•

1 x Front Panel Audio Connector

•

2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD

•

Protection)
1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports)

•

(Supports ESD Protection)

AMI UEFI Legal BIOS with multilingual GUI support

•

Supports “Plug and Play”

•

ACPI 5.1 compliance wake up events

•

Supports jumperfree

•

SMBIOS 2.3 support

•

DRAM Voltage multi-adjustment

•

Temperature Sensing: CPU, MB

•

Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water

•

Pump Fans
Quiet Fan (Auto adjust chassis fan speed by CPU tempera-

•

ture): CPU, CPU/Water Pump, Chassis/Water Pump Fans
Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/

•

Water Pump Fans
Voltage monitoring: +12V, +5V, +3.3V, Vcore

•

English

10

Microso® Windows® 10 64-bit

OS

Certica­tions

* For detailed product information, please visit our website: http://www.asrock .com

Please realize that the re is a certain risk involved with overclocking, including adjust­ing the setting in the BIOS, applying Untied Ove rclocking Technology, or using third­party overclocking tools. Overclocking may aect your system’s stability, or even cause
damage to the components and devices of your system. It should be done at your own
risk and expense. We are not responsible for possible damage cau sed by overclocking.

•

FCC, CE

•

ErP/EuP ready (ErP/EuP ready power supply is required)

•

Fatal1ty B450 Gaming K4 Series

Chapter 2 Installation

is is an ATX form factor motherboard. Before you install the motherboard, study
the conguration of your chassis to ensure that the motherboard ts into it.

Pre-installation Precautions

Take note of the following precautions before you install motherboard components
or change any motherboard settings.

Make sure to unplug the power cord before installing or removing the motherboard.

•

Failure to do so may cause physical injuries to you and damages to motherboard
components.
In order to avoid damage from static electricity to the motherboard’s components,

•

NEVER place your motherboard directly on a carpet. Also remember to use a grounded
wrist strap or touch a safety grounded object before you handle the components.
Hold components by the edges and do not touch the ICs.

•

Whenever you uninstall any components, place them on a grounded anti-static pad or

•

in the bag that comes with the components.
When placing screws to secure the motherboard to the chassis, please do not over-

•

tighten the screws! Doing so may damage the motherboard.

11

English

2.1 Installing the CPU

Unplug all power cables be fore installing the CPU.

1

English

12

2

Fatal1ty B450 Gaming K4 Series

3

13

English

2.2 Installing the CPU Fan and Heatsink

Aer you install the CPU into this motherboard, it is necessary to install a larger
heatsink and cooling fan to dissipate heat. You also need to spray thermal grease
between the CPU and the heatsink to improve heat dissipation. Make sure that the
CPU and the heatsink are securely fastened and in good contact with each other.

Please turn o the power or remove the power cord before changing a CPU or heatsink.

Installing the CPU Box Cooler SR1

1

English

14

2

Fatal1ty B450 Gaming K4 Series

3

4

1

N
FA

_

U

P

C

English

15

Installing the AM4 Box Cooler SR2

1

2

English

16

Fatal1ty B450 Gaming K4 Series

3

17

English

4

1

N
FA

_

U

P

C

5

4-pin FAN cable

English

18

RGB LED Cable

1

N

FA

CPU_

1

D

E

L

_

N

FA

_

D

AM

+12V

*e diagram shown here are for reference only. Please refer to page 32 for the orientation of
AMD Fan LED Header (AMD_FAN_LED1).

Installing the AM4 Box Cooler SR3

1

Fatal1ty B450 Gaming K4 Series

2

English

19

3

4

English

20

Fatal1ty B450 Gaming K4 Series

5

CPU_FAN1

21

English

6

1

N

FA

_

U

P

C

1

D

E

L

_

N

FA

_

D

AM

+12V

or

7

English

22

1

N

FA

_

U

P

C

1

D

E

L

_

N

FA

_

D

AM

5

_

B

S

U

Please note that only one cable should be used at a time in this step.
If you select AMD_FAN_LED1, please install ASRock utility "ASRock Polychrome LED".
If you select USB connector, please install AMD utility "SR3 Settings Soware".

*e diagram shown here are for reference only. Please refer to page 32 for the orientation of
AMD Fan LED Header (AMD_FAN_LED1).

Fatal1ty B450 Gaming K4 Series

2.3 Installing Memory Modules (DIMM)

is motherboard provides four 288-pin DDR4 (Double Data Rate 4) DIMM slots,
and supports Dual Channel Memory Technology.

1. For dual channel conguration, you always need to install identical (the same
brand, speed , size and chip-type) DDR4 DIMM pairs.

2. It i s unable to activate Dual Channel Memory Technology with only one or three
memory module installed.

3. It i s not allowed to install a DDR , DDR2 or DDR3 memor y module into a DDR4
slot; otherwise, this motherboard and DIMM may be damaged.

DDR4 UDIMM Maximum Frequency Support

Ryzen Series CPUs (Pinnacle Ridge):

UDIMM Memory Slot

A1 A2 B1 B2

- SR - - 2667

- DR - - 2400

- SR - SR 2667

- DR - DR 2400

SR SR SR SR 2133

SR/DR DR SR/DR DR 1866

Frequency

(Mhz)

Ryzen Series CPUs (Summit Ridge):

UDIMM Memory Slot

A1 A2 B1 B2

- SR - - 2667

- DR - - 2667

- SR - SR 2667

- DR - DR 2400-2667

SR SR SR SR 2133-2400

SR/DR DR SR/DR DR 1866-2133

Frequency

(Mhz)

English

23

Ryzen Series CPUs (Raven Ridge):

UDIMM Memory Slot

A1 A2 B1 B2

- SR - - 2933

- DR - - 2667

- SR - SR 2667

- DR - DR 2400

SR SR SR SR 2133

SR/DR DR SR/DR DR 1866

SR: Single rank DIMM, 1Rx4 or 1Rx8 on DIMM module label

DR: Dual rank DIMM, 2Rx4 or 2R x8 on DIMM module label

Frequency

(Mhz)

English

24

Fatal1ty B450 Gaming K4 Series

e DIMM only ts in one correct orientation. It will cause permanent damage to
the mothe rboard and the DIMM if you force the DIMM into the slot at incor rect
orientation.

1

2

3

English

25

2.4 Expansion Slots (PCI Express Slots)

ere are 6 PCI Express slots on the motherboard.

Before installing an ex pansion card, please make sure that the power supply is
switched o or the power cord is unplugged. Plea se read the documentation of the
expan sion card and make necessary hardware settings for the card before you start
the installation.

PCIe slots:

PCIE1 (PCIe 2.0 x1 slot) is used for PCI Express x1 lane width cards.
PCIE2 (PCIe 3.0 x16 slot) is used for PCI Express x16 lane width graphics cards.
PCIE3 (PCIe 2.0 x1 slot) is used for PCI Express x1 lane width cards.
PCIE4 (PCIe 3.0 x16 slot) is used for PCI Express x4 lane width graphics cards.*
PCIE5 (PCIe 2.0 x1 slot) is used for PCI Express x1 lane width cards.
PCIE6 (PCIe 2.0 x1 slot) is used for PCI Express x1 lane width cards.
* If M2_1 is occupied, PCIE4 will be disabled.

PCIe Slot Congurations

PCIE2 PCIE4

Ryzen Series CPUs (Pinnacle Ridge) x16 x4

English

26

Ryzen Series CPUs (Summit Ridge) x16 x4

Ryzen Series CPUs (Raven Ridge) x8 x4
