Asrock B650M PG Riptide User Manual

Contact Information

If you need to contact ASRock or want to k now more about ASRock, you’re welcome

to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer

for further information. For technical questions, please submit a support request

form at https://event.asrock.com/tsd.asp

ASRock Incorporation

e-mail: [e-mail]

ASRock EUROPE B.V.

e-mail: [e-mail]

ASRock America, Inc.

e-mail: [e-mail]

Scan the QR code to view more manuals and documents.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 6

1.4 I/O Panel 8

1.5 Block Diagram 10

Chapter 2 Installation 11

2.1 Installing the CPU 12

2.2 Installing the CPU Fan and Heatsink 15

2.3 Installing Memory Modules (DIMM)

2.4 Connecting the Front Panel Header 26

2.5 Installing the Motherboard 27

2.6 Installing SATA Drives 28

2.7 Installing a Graphics Card 30

2.8 Connecting Peripheral Devices 32

2.9 Connecting the Power Connectors 33

2.10 Power On 34

2.11 Jumpers Setup 35

2.12 Onboard Headers and Connectors 36

2.13 Smart Switches 49

2.14 Post Status Checker 51

24

2.15 M.2 SSD Module Installation Guide (M2_1) 52

2.16 M.2 SSD Module Installation Guide (M2_2) 55

Chapter 1 Introduction

ank you for purchasing ASRock B650M PG Riptide motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

Becau se the motherboard specications and the BIOS soware mig ht be updated, the
content of this documentation will be subject to change without notice. In ca se any modi­cations of thi s documentation occur, the updated version wil l be avail able on ASRock’s
website w ithout further notice. If you require technical support rel ated to this mother­board, please visit our webs ite for specic information about the model you are using. You
may nd the l atest VGA cards and CPU support list on ASRock’s website as well. ASRock
website http://www.asrock.com.

1.1 Package Contents

ASRock B650M PG Riptide Motherboard (Micro ATX Form Factor)

•

ASRock B650M PG Riptide User Manual

•

2 x Serial ATA (SATA) Data Cables (Optional)

•

2 x Screws for M.2 Sockets (Optional)

•

1 x Stando for M.2 Socket (Optional)

•

B650M PG Riptide

1

1.2 Specications

Platform

CPU

Chipset

Memory

•

•

•

•

•

•

•

•

•

* Please refer to Memory Support List on ASRock 's website for

more information. (http://www.asrock.com/)

Micro ATX Form Factor

2oz Copper PCB

Supports AMD Socket AM5 RyzenTM 7000 Series Processors

AMD B650

Dual Channel DDR5 Memory Technology

4 x DDR5 DIMM Slots

Supports DDR5 ECC/non-ECC, un-buered memory up to

620 0+(OC)*

Max. capacity of system memory: 128GB

Supports Extreme Memory Prole (X MP) and EXTended

Proles for Overclocking (EXPO) memory modules

Expansion
Slot

Graphics

Audio

CPU:

1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*

•

Chipset:

1 x PCIe 4.0 x16 Slot (PCIE4), supports x4 mode*

•

2 x PCIe 3.0 x1 Slots (PCIE2 and PCIE3)*

•

* Supports NVMe SSD as boot disks

Supports AMD CrossFireTM

•

15μ Gold Contact in VGA PCIe Slot (PCIE1)

•

Integrated AMD RDNATM 2 graphics (Actual support may

•

vary by CPU)

1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR,

•

HDCP 2.3 and max. resolution up to 4K 120Hz

1 x DisplayPort 1.4 with DSC (compressed), supports HDCP

•

2.3 and max. resolution up to 4K 120Hz

7.1 CH HD Audio (Realtek ALC897 Audio Codec)

•

Nahimic Audio

•

2

LAN

USB

Rear Panel
I/O

B650M PG Riptide

2.5 Gigabit LAN 10/100/1000/2500 Mb/s

•

Dragon RTL8125BG

•

Supports Phantom Gaming LAN Soware

•

- Smart Auto Adjust Bandwidth Control

- Visual User Friendly UI

- Visual Network Usage Statistics

- Optimized Default Setting for Game, Browser, and

Streaming Modes

- User Customized Priority Control

1 x USB 3.2 Gen2 Type-C (Rear)

•

1 x USB 3.2 Gen2 Type-A (Rear)

•

1 x USB 3.2 Gen1 Type-C (Front)

•

6 x USB 3.2 Gen1 (2 Rear, 4 Front)

•

8 x USB 2.0 (4 Rear, 4 Front)

•

* All USB ports support ESD Protection

1 x HDMI Port

•

1 x DisplayPort 1.4

•

1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (ReDriver)

•

1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (ReDriver)

•

2 x USB 3.2 Gen1 Ports (USB32_23 are Lightning Gaming

•

Por ts.)

4 x USB 2.0 Ports

•

1 x RJ-45 LAN Port

•

1 x BIOS Flashback Button

•

HD Audio Jacks: Line in / Front Speaker / Microphone

•

Storage

CPU:

1 x Blazing M.2 Socket (M2_1, Key M), supports type

•

2260/2280 PCIe Gen5x4 (128 Gb/s) mode*

Chipset:

1 x Hyper M.2 Socket (M2_2, Key M), supports ty pe

•

2260/2280 PCIe Gen4x4 (64 Gb/s) mode*

4 x SATA3 6.0 Gb/s Connectors

•

* Supports NVMe SSD as boot disks

* Supports ASRock U.2 Kit

3

RAID

Connector

Supports RAID 0, RAID 1 and RAID 10 for SATA storage

•

devices

Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe stor-

•

age devices*

* Requires additional M.2 NVMe expansion cards to support

RA ID 10

1 x SPI TPM Header

•

1 x Power LED and Speaker Header

•

1 x RGB LED Header*

•

3 x Addressable LED Headers**

•

1 x CPU Fan Connector (4-pin)***

•

1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan

•

Speed Control)****

3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan

•

Speed Control)*****

1 x 24 pin ATX Power Connector

•

1 x 8 pin 12V Power Connector

•

1 x 4 pin 12V Power Connector

•

1 x Front Panel Audio Connector

•

1 x underbolt AIC Connector (5-pin) (Supports ASRock

•

underbolt 4 AIC Card)

2 x USB 2.0 Headers (Support 4 USB 2.0 ports)

•

2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports)

•

1 x Front Panel Type C USB 3.2 Gen1 Header

•

* Supports in total up to 12V/3A, 36W LED Strip

** Support in total up to 5V/3A, 15W LED Strip

*** CPU_FAN1 supports the fan power up to 1A (12W).

**** CPU_FAN2/WP supports the fan power up to 2A (24W).

***** CHA_FAN1~3/WP support the fan power up to 2A (24W).

***** CPU_FAN2/WP and CHA_FAN1~3/WP can auto detect

if 3-pin or 4-pin fan is in use.

BIOS
Feature

OS

AMI UEFI Legal BIOS with GUI support

•

Microso® Windows® 10 64-bit / 11 64-bit

•

4

FCC, CE

Certica­tions

* For detailed product information, please visit our website: http://www.asrock .com

Please realiz e that there is a certain risk involved with overclocking, including adjusting
the setting in the BIOS, applying Untied Overclocking Technol ogy, or using third-party
overclocking tools. Overclocking may aect your system’s stability, or even cause damage to
the components and devices of your system. It should be done at your own r isk and expense.
We are not responsible for pos sible damage caused by overclocking.

•

ErP/EuP ready (ErP/EuP ready power supply is required)

•

B650M PG Riptide

5

ATXP WR 1

Top:
RJ-45

USB 3.2 Gen1
T: USB32_2
B: USB32_3

1

1

1

1

1

1

1

1

1

HD_AUDIO1

1

TB1

AUDIO
CODEC

CPU_FAN2
/WP

CHA_FAN1
/WP

1

1

USB32_ 4_5

ADDR_L ED3

ATX12V1

CPU_FAN1

HDLED RESET

PLED PWRBTN

PANEL1

PCIE3

Top:

LINE IN

Center:

FRONT

Bottom :

MIC IN

USB_7_8

ATX12V2

SATA3_4

SATA3_3

ADDR_LED2

PCIE4

22

1

9

11

23

14

6

7

26

24

28

20

23

29

8

VGA

BOOT

CPU

DRAM

SPK_PLED1

21

15

B6 5 0 M PG

R I P T I D E

27

BIOS
ROM

USB32_ TC2

4

DDR5 _A2 (64 b it, 288 -pin mo dule)

DDR5 _A1 (64 b it, 288 -pin mo dule)

DDR5 _B2 (64 b it, 288 -pin mo dule)

DDR5 _B1 (64 b it, 288 -pin mo dule)

USB32_6_7

CLR
CMOS1

5

1

SPI_TPM_J1

RoHS

RGB_LE D1

SATA3_1

SATA3_2

M2_ 2

M2_ 1

10

12

13

CHA_FAN2
/WP

CHA_FAN3
/WP

USB_5_6

1

ADDR_LED1

25

19 18 17 16

PCIE1

PCIE2

BIOS
_FB1

HDM I1

DP_ 1

USB 3.2 Gen2
T:USB32_1
B: USB32_TC1

USB 2.0

USB_2

USB 2.0

USB_1

USB 2.0

USB_4

USB 2.0

USB_3

LAN

AMD
B650

1.3 Motherboard Layout

6

No. Description

1 8 pin 12V Power Connector (ATX12V1)

2 4 pin 12V Power Connector (ATX12V2)

3 CPU Fan Connector (CPU_FAN1)

4 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1)

5 2 x 288-pin DDR5 DIMM Slots (DDR5_A2, DDR5_B2)

6 Addressable LED Header (ADDR_LED3)

7 RGB LED Header (RGB_LED1

8 ATX Power Connector (ATXPWR1)

9 Front Panel Type C USB 3.2 Gen1 Header (USB32_TC2)

10 SATA3 Connector (SATA3_1)

11 SATA3 Connector (SATA3_2)

12 USB 3.2 Gen1 Header (USB32_4 _5)

13 SPI TPM Header (SPI_TPM_J1)

14 SATA3 Connec tors (SATA3_ 4)(Upper), (SATA 3_3)(Lower)

15 System Panel Header (PANEL1)

16 Power LED and Speaker Header (SPK_PLED1)

17 Clear CMOS Jumper (CLRCMOS1)

18 USB 3.2 Gen1 Header (USB32_6_7)

19 Post Status Checker (PSC)

20 Chassis/Water Pump Fan Connector (CHA_FAN3/WP)

21 USB 2.0 Header (USB_5_6)

22 USB 2.0 Header (USB_7_8)

23 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)

24 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)

25 Addressable LED Header (ADDR_LED1)

26 Addressable LED Header (ADDR_LED2)

27 5-pin underbolt AIC Connector (TB1)

28 Front Panel Audio Header (HD_AUDIO1)

29 CPU/Water Pump Fan Connector (CPU_FAN2/WP)

)

B650M PG Riptide

7

1.4 I/O Panel

2

1

3

11 10

No. Description No. Description

1 2.5G LAN RJ-45 Port* 7 USB 3.2 Gen2 Type-A Port

2 Line In (Light Blue)** (USB32_1)

3 Front Speaker (Lime)** 8 USB 3.2 Gen2 Type-C Port

4 Microphone (Pink)** (USB32_TC1)

5 USB 3.2 Gen1 Type-A Ports 9 BIOS Flashback Button

(USB32_23)*** 11 HDMI Port

6 USB 2.0 Ports (USB_1234) 12 DisplayPort 1.4

9

7

8

6

45

8

B650M PG Riptide

*ere are two LED s on each LAN port. Please re fer to the table below for the LAN port LED indication s.

ACT/LINK LED

SPEED LED

LAN Por t

Activity / Link LED Speed LED

Status Description Status Description

O No Link O 10Mbps connection

Blinking Data Activity Orange

On Link Green 2.5Gbps connection

** Function of the Audio Ports in 7.1-channel Conguration:

Port Function

Light Blue (Rear panel) Rear Speaker Out
Lime (Rear panel) Front Speaker Out
Pink (Rear panel) Central /Subwoofer Speaker Out
Lime (Front panel) Side Speaker Out

100Mbps/1Gbps

connection

*** USB32_ 23 are the Lightning Gaming Ports.

9

1.5 Block Diagram

Rear USB 3.2 Gen2 Type A

Rear USB 3.2 Gen2 Type C

M.2(PCIe x4)

PCIe x16 Gen4 Slot

x16 Gen4

Channel A

PCIe x4 Slot

x4 Gen5

x4 Gen4

Channel B

DP0

AMD AM5

Processor

LGA1718

AZ(HD Audio)

ReDriver

Displayport

DP1

10Gb/s

SPI

eSPI

ReDriver5Gb/s

10Gb/s

M.2(PCIe x4 Gen4)

x4 Gen4

PCIe x4 Gen4 BUS

480Mb/s

5Gb/s

USB2.0 Hub

GL852

Realtek RTL8125B 2.5G LAN

x1

1st

5Gb/s

PCIe x1 Slot

x1

AMD PROM21

Chipset

5Gb/s

480Mb/s

PCIe x1 Slot

x1

SATA 6Gb

10

DDR5 Slot x2

DDR5 Slot x2

HDMI Port

SIO NCT6796D-S

Flash ROM

Audio Codec ALC897 3

Rear USB 3.2 Gen1 1 port

Front USB 3.2 Gen1 4 port

Front USB 3.2 Gen1 Type C

Front USB 2.0 4 port

Rear USB 3.2 Gen1 1 port

SATA 4 port

Rear USB 2.0 4 port

B650M PG Riptide

Chapter 2 Installation

is is a Micro ATX form factor motherboard. Before you install the motherboard,

study the conguration of your chassis to ensure that the motherboard ts into it.

Pre-installation Precautions

Take note of the following precautions before you install motherboard components

or change any motherboard settings.

Make sure to unplug the power cord before insta lling or removing the motherboard

•

components. Failure to do so may cause physical injuries and damages to motherboard

components.

In order to avoid damage from static electricity to the motherboard’s components,

•

NEVER place your motherboard directly on a carpet. Also remember to use a grounded

wrist strap or touch a safety grounded object before you handle the components.

Hold components by the edges and do not touch the ICs.

•

Whenever you uninstall any components, place them on a grounded anti-static pad or

•

in the bag that comes with the components.

When placing screws to secure the motherboard to the chassis, please do not over-

•

tighten the screws! Doing so may damage the motherboard.

11

2.1 Installing the CPU

1. Before you insert the 1718-Pin CPU into the socket , please check if the PnP cap is on the
socket, if the CPU surface is unclean , or if there are any bent pins in the socket. Do not
force to in sert the CPU into the socket if above situation is found. Otherwise, the CPU
will be seriously damaged.

2. Unplug all power cables be fore installing the CPU.

Tutorial Video

12

Turn your CPU to the correct orientation before opening

the CPU socket cover.

B650M PG Riptide

1

A

B

3

2

4

Carefully place the CPU in as at as

possible. Do not drop it.

13

5

Make sure the CPU is aligned with the

socket before locking it into place.

6

7

14

Make sure the black cover plate

is always in place until it pops o

when closing the socket lever.

Please save the cover if the processor is removed. e cover must be placed if you wish to
return the motherboard for aer service.

B650M PG Riptide

1

2.2 Installing the CPU Fan and Heatsink

Aer you install the CPU into this motherboard, it is necessary to install a larger

heatsink and cooling fan to dissipate heat. You also need to spray thermal grease

between the CPU and the heatsink to improve heat dissipation. Make sure that the

CPU and the heatsink are securely fastened and in good contact with each other.

Please turn o the power or remove the powe r cord before changing a CPU or heatsink.

Installing the CPU Cooler (Type 1)

2

15

3

4

16

CPU_FAN1

Installing the CPU Cooler (Type 2)

1

2

B650M PG Riptide

17

3

4

18

CPU_FAN1

B650M PG Riptide

5

CPU_FAN1

RGB_LED1

+12V

*e illustrations shown here are for reference purposes only and may not exactly match

the model you purchase.

19

Installing the CPU Cooler (Type 3)

1

2

20

B650M PG Riptide

3

4

21

5

AN1

CPU_F

22

B650M PG Riptide

6

CPU_FAN1

RGB_LED1

+12V

or

CPU_FAN1

RGB_LED1

USB_1_2

Please note that only one cable should be used at a time in this step.

If you select RGB_L ED1, please install ASRock utility "ASRock Polychrome SYNC".

If you select USB connector, please install AMD utility "SR3 Settings Soware".

*e illustrations shown here are for reference purposes only and may not exactly match

the model you purchase.

23

2.3 Installing Memory Modules (DIMM)

is motherboard provides four 288-pin DDR5 (Double Data Rate 5) DIMM slots,

and supports Dual Channel Memory Technology.

1. For dual channel conguration, you always need to instal l identical (the same brand ,

speed , size and chip-type) DDR5 DIMM pairs.

2. It is unable to activate Dual Channel Memor y Technology with only one or three me mory

module installed.

3. It is not allowed to in stall a DDR, DDR2 , DDR3 or DDR4 memor y module into a DDR5

slot; otherw ise, this motherboard and DIMM may be damaged .

4. e DIMM only ts in one correct orientation. It will cause permanent damage to the

motherboard and the DIMM if you force the DIMM into the sl ot at incorrec t orientation.

Recommended Memory Conguration

1 DIMM

A1 A2 B1 B2

V

2 DIMMs

A1 A2 B1 B2

V V

4 DIMMs

A1 A2 B1 B2

V V V V

e rst boot may take some time.

Please be patient and refer to the following table for booting time.

*It may vary by dierent setups.

Memory 1st boot after clear CMOS

2 x 16GB 90 sec
2 x 32GB 150 sec
4 x 16GB 170 sec
4 x 32GB 315 se c

24

B650M PG Riptide

1

2

3

25

2.4 Connecting the Front Panel Header

1

32:(56:

+''/('

5(6(76:

32:(5/('

32:(5/('

2

RESET SW

HDD LED

26

3$1(/

System Panel Header

910

Power SW (-) RESET SW (+)

B

Power LED (-)

A

Power LED (+)

12

PANEL1

RESET SW (-)Power SW (+)

HDD LED (-)

HDD LED (+)

Front Panel Wires

D

C

ABC D

2.5 Installing the Motherboard

RIPTIDE

B65 0M P G

B650M PG Riptide

27

2.6 Installing SATA Drives

1

Optical Drive

SATA Drive

2

28

SATA Data Cable

B650M PG Riptide

3

4

SATA Power Connector

SATA Data Connector

29

2.7 Installing a Graphics Card

1

30

CLICK!

Expansion Slots (PCIe Slots)

ere are 4 PCI Express slots on the motherboard.

Before instal ling an expansion card, ple ase ma ke sure that the power supply is switched o
or the power cord is unplug ged. Please read the documentation of the expansion card and
make necessary hardware settings for the card before you start the installation.

PCIe slots:

PCIE1 (PCIe 4.0 x16 slot) is used for PCIe x16 lane width graphics cards.

PCIE2 (PCIe 3.0 x1 slot) is used for PCIe x1 lane width cards.

PCIE3 (PCIe 3.0 x1 slot) is used for PCIe x1 lane width cards.

PCIE4 (PCIe 4.0 x16 slot) is used for PCIe x4 lane width graphics cards.

PCIe Slot Congurations

PCIE1 PCIE4

Single Graphics Card Gen4x16 N/A

B650M PG Riptide

Two Graphics Cards in

CrossFireTM Mode

For a better thermal environment, please connect a cha ssis fan to the motherboard’s
chassis fan connector (CHA_ FAN1~3/WP) when using multipl e graphics card s.

Gen4x16 Gen4x4

31

2.8 Connecting Peripheral Devices

32

2.9 Connecting the Power Connectors

B650M PG Riptide

$7;9

$7;3:5

33

2.10 Power On

1

2

3

4

34

B650M PG Riptide

2.11 Jumpers Setup

e illustration shows how jumpers are setup. When the jumper cap is placed on

the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is

“O pen”.

Clear CMOS Jumper

(CLRC MOS1) (see p.6, No. 17)

CLRCMOS1 allows you to clear the data in CMOS. e data in CMOS includes

system setup information such as system password, date, time, and system setup

parameters. To clear and reset the system parameters to default setup, please

turn o the computer and unplug the power cord, then use a jumper cap to short

the pins on CLRCMOS1 for 3 seconds. Please remember to remove the jumper

cap aer clearing the CMOS. If you need to clear the CMOS when you just nish

updating the BIOS, you must boot up the system rst, and then shut it down

before you do the clear-CMOS action.

RIPTIDE

B65 0M PG

CLRCMOS1

2-pin Jumper

Short: Clear CMOS

Open: Default

35

2.12 Onboard Headers and Connectors

Onboard heade rs and connectors are NOT jumpers. Do NOT place jumper caps over these

System Panel Header

(9-pin PANEL1) (see p.6, No. 15)

Connect the power button, reset button and system status indicator on the chassis

to this header according to the pin assignments below. Note the positive and

negative pins before connecting the cables.

heade rs and connectors. Pla cing jumper caps over the head ers and connectors will cau se
permanent damage to the motherboard.

RIPTIDE

B65 0M PG

PANEL1

PLED+

1

HDLED+

PLED-

PWRBTN#

GND

HDLED-

GND

GND

RESET#

PWRBTN (Power Bu tton):

Connec t to the power button on the chassis front panel . You may congure the way to tur n
o your system using the power button.

RESET (Reset Button):
Connec t to the reset button on the chassis front panel . Press the reset button to restart the
computer if the computer freezes and fails to perform a nor mal restart .

PLED (Syste m Power LED):
Connec t to the power status indicator on the cha ssis front panel. e LED is on when the
system is operating. e LED keeps blinking when th e syste m is in S1/S3 sleep state. e
LED is o when the system is in S4 sleep state or powe red o (S5).

HDLED (Ha rd Drive Activity LED):
Connec t to the hard drive ac tivit y LED on the chassis front pane l. e LED is on when the
hard drive is reading or writing data.

e front panel de sign may dier by chassis. A f ront panel module mainly consi sts of power
button, reset button, power LED, hard drive a ctivity LED, speaker and etc. When connect­ing your ch assis front panel module to this header, make sure the wire assignments and the
pin assignme nts are matched correctly.

36

Power LED and Speaker Header

1

+5V

DUMMY

PLED+

PLED+

PLED-

DUMMY

SPEAKER

(7-pin SPK_PLED1) (see p.6, No. 16)

Please connect the chassis power LED and the chassis speaker to this header.

B650M PG Riptide

RIPTIDE

B65 0M PG

SPK_PLED1

Serial ATA3 Connectors

Ver ti c a l:

(SATA3_1) (see p.6, No. 10)

(SATA3_2) (see p.6, No. 11)

Right Angle:

(SATA3_3) (see p.6, No. 14)(Lower)

(SATA3_4) (see p.6, No. 14)(Upper)

ese four SATA3 connectors support SATA data cables for internal storage

devices with up to 6.0 Gb/s data transfer rate.

RIPTIDE

B65 0M PG

SATA3_2 SATA3_1

SATA3_4

SATA3_3

37

USB 2.0 Headers

DUMMY

GND

GND

P+

P-

USB_PWR

P+

P-

USB_PWR

1

DUMMY

GND

GND

P+

P-

USB_PWR

P+

P-

USB_PWR

1

(9-pin USB_5_6) (see p.6, No. 21)

(9-pin USB_7_8) (see p.6, No. 22)

ere are two headers on this motherboard. Each USB 2.0 header can support two

ports.

RIPTIDE

B65 0M PG

USB_5_6

USB_7_ 8

38

USB 3.2 Gen1 Headers

IntA_P_D+

(19-pin USB32_4_5) (see p.6, No. 12)

(19-pin USB32_6_7) (see p.6, No. 18)

ere are two headers on this motherboard. Each USB 3.2 Gen1 header can

support two ports.

RIPTIDE

B650M PG Riptide

B65 0M PG

USB32_6_7

IntA_P_D-

GND

1

IntA_P_D-

IntA_P_D+

ID

IntA_P_SSTX+

IntA_P_SSTX-

GND

IntA_P_SSTX-

IntA_P_SSTX+

GND

IntA_P_SSRX+

IntA_P_SSRX-

Vbus

IntA_P_SSRX-

IntA_P_SSRX+

GND

Vbus

USB32_4 _5

Vbus

IntA_PA_SSRX-

IntA_PA_SSRX+

GND

IntA_PA_SSTX-

IntA_PA_SSTX+

GND

IntA_PA_D-

IntA_PA_D+

VbusVbus

IntA_PB_SSRX-

IntA_PB_SSRX+

GND

IntA_PB_SSTX-

IntA_PB_SSTX+

GND

IntA_PB_D-

IntA_PB_D+

Dummy

1

39

Front Panel Type C USB 3.2 Gen1 Header

J_SENSE

OUT2_L

1

MIC_RET

PRESENCE#

GND

OUT2_R

MIC2_R

MIC2_L

OUT_RET

(20-pin USB32_TC2) (see p.6, No. 9)

ere is one Front Panel Type C USB 3.2 Gen1 Header on this motherboard. is

header is used for connecting a USB 3.2 Gen1 module for additional USB 3.2 Gen1

ports.

RIPTIDE

USB32_TC2

B65 0M PG

USB Type-C Cable

Front Panel Audio Header

(9-pin HD_AUDIO1) (see p.6, No. 28)

is header is for connecting audio devices to the front audio panel.

HD_AUDIO1

RIPTIDE

B65 0M PG

High Denition Audio supports Jack Sensing , but the panel wire on the chassis must sup­port HDA to function cor rectly. Please follow the instructions in our manual and chassi s
manual to install your system .

40

Chassis/Water Pump Fan Connectors

GND

L

GND

L

GND

L

(4-pin CHA_FAN1/WP) (see p.6, No. 24)

(4-pin CHA_FAN2/WP) (see p.6, No. 23)

(4-pin CHA_FAN3/WP) (see p.6, No. 20)

is motherboard provides three 4-Pin water cooling

you plan to connect a 3-Pin

chassis

water cooler fan, please connect it to Pin 1-3.

RIPTIDE

B65 0M PG

chassis

fan connectors. If

CH A _FAN3/ WP

FAN_VOLTAGE

CHA_FAN_SPEED

FAN_SPEED_CONTRO

1 2 3 4

B650M PG Riptide

CH A _FAN1/ WP

FAN_VOLTAGE

CHA_FAN_SPEED

FAN_SPEED_CONTRO

1 2 3 4

CH A _FAN2/WP

FAN_VOLTAGE

CHA_FAN_SPEED

FAN_SPEED_CONTRO

1 2 3 4

41

CPU Fan Connector

FAN_SPEED_CONTROL

4 3 2 1

1
2
3
4

L

(4-pin CPU_FAN1) (see p.6, No. 3)

is motherboard provides a 4-Pin CPU fan (Quiet Fan) connector. If you plan to

connect a 3-Pin CPU fan, please connect it to Pin 1-3.

RIPTIDE

B65 0M PG

CPU_ FA N1

GND

+12V

CPU_F

AN_SPEED

CPU/Water Pump Fan Connector

(4-pin CPU_FAN2/WP) (see p.6, No. 29)

is motherboard provides a 4-Pin water cooling CPU fan connector. If you plan

to connect a 3-Pin CPU water cooler fan, please connect it to Pin 1-3.

RIPTIDE

B65 0M PG

CPU_ FA N2/ W P

GND

FAN_VOLTAGE

CPU_FAN_SPEED
FAN_SPEED_CONTRO

42

B650M PG Riptide

4

1

8 5

ATX Power Connector

(24-pin ATXPWR1) (see p.6, No. 8)

is motherboard provides a 24-pin ATX power connector. To use a 20-pin ATX

power supply, please plug it along Pin 1 and Pin 13.

RIPTIDE

B65 0M PG

ATX PW R1

12

24

1

13

ATX 12V Power Connector

(8-pin ATX12V1) (see p.6, No. 1)

is motherboard provides a 8-pin ATX 12V power connector. To use a 4-pin

ATX power supply, please plug it along Pin 1 and Pin 5.

*Warning: Please make sure that the power cable connected is for the CPU and

not the graphics card. Do not plug the PCIe power cable to this

connector.

RIPTIDE

B65 0M PG

ATX12V1

43

ATX 12V Power Connector

1

SPI_DQ3

#

(4-pin ATX12V2) (see p.6, No. 2)

Please connect an ATX 12V power supply to this connector.

*e power supply plug ts into this connector in only one orientation.

*Connecting an ATX 12V 4-pin cable to ATX12V2 is optional.

*For advanced overclocking we suggest using this connector together with

ATX12V1.

RIPTIDE

B65 0M PG

ATX12V2

SPI TPM Header

(13-pin SPI_TPM_J1) (see p.6, No. 13)

is connector supports SPI Trusted Platform Module (TPM) system, which can securely

store keys, digital certicates, passwords, and data. A TPM system also helps enhance

network security, protects digital identities, and ensures platform integrity.

SPI_TPM_ J1

RIPTIDE

B65 0M PG

SPI_PWR

SPI_CS0

SPI_DQ2

Dummy

CLK

RSMRST#

SPI_MISO

SPI_MOSI

RST#

TPM_PIRQ

SPI_TPM_CS

GND

44

B650M PG Riptide

1

underbolt AIC Connector

(5-pin TB1) (see p.6, No. 27)

Please connect a underboltTM add-in card (AIC) to the underbolt AIC connector via

the GPIO cable.

*Please install the underboltTM AIC card to PCIE4 (default slot).

*For the underbolt compatibility and limitation, please visit w ww.asrock.com.

RIPTIDE

B65 0M PG

TB1

45

RGB LED Header

B

+12V

(4-pin RGB_LED1) (see p.6, No. 7)

is RGB header is used to connect RGB LED extension cable which allow users to choose

from various LED lighting eects.

Caution: Never install the RGB LED cable in the wrong orientation; otherwise, the

cable may be damaged.

RIPTIDE

RGB_LED1

B65 0M PG

R

G

1

46

Connect your RGB LED strip to the

Header (RGB_LED1)

1. Never in stall the RGB LED cable in the w rong orientation; otherw ise, the cabl e

may be damaged.

2. Before in stalling or removing your RGB LED cable, please power o your system

and unplug the power cord from the power supply. Failure to do so may cause dam­ages to motherboard components.

1. Please note that the RGB LED strips do not come with the package.

2. e RGB LED hea der supports standard 5050 RGB LED strip (12V/G/R/B), with a

maximum power rating of 3A (12V) and length within 2 meters.

on the motherboard.

RGB LED

1

B

R

G

V

2

1

B650M PG Riptide

1

1

Addressable LED Headers

(3-pi n A DDR_LE D1) (see p.6, No. 25)

(3-pin ADDR_LED2) (see p.6, No. 26)

(3-pin ADDR_LED3) (see p.6, No. 6)

ese headers are used to connect

choose from various LED lighting eects.

Caution: Never install the Addressable LED cable in the wrong orientation; otherwise,

the cable may be damaged.

RIPTIDE

B65 0M PG

Addressable

LED extension cables which allow users to

ADDR_LED3

ADDR_LED1

GND

DO_ADDR

VOUT

ADDR_LED2

GND

DO_ADDR

VOUT

Connect your

to the

LED1 / ADDR_LED2 / ADDR_LED3)

Addressable RGB LED

strips

Addressable LED Headers (ADDR_

on

the motherboard.

1

47

1. Never in stall the RGB LED cable in the w rong orientation; otherw ise, the cabl e may be
damaged.

2. Before in stalling or removing your RGB LED cable, please power o your system and
unplug the power cord from the power supply. Failure to do so may cau se damages to
motherboard components.

1. Please note that the RGB LED strips do not come with the package.

2. e RGB LED hea der supports WS2812B ad dressable RGB LED strip (5V/Data/

GND), with a ma ximum power rating of 3A (5V) and length within 2 meters .

48

2.13 Smart Button

e motherboard has a smart button: BIOS Flashback Button, allowing users to

ash the BIOS.

BIOS Flashback Button

(BIOS_FB1) (see p.8, No. 9)

BIOS Flashback Button allows users to ash the BIOS.

B650M PG Riptide

RIPTIDE

B65 0M PG

USB BIOS Flashback port

BIOS_FB1

49

ASRock BIOS Flashback feature al lows you to update BIOS wit hout powering on the system, even
without CPU.

Before u sing the BIOS Flashback function, please suspend BitLocke r and any encry ption
or security relying on the TPM. Make sure that you have already stored and backup-ed
the recovery key. If the recovery key is missing while e ncryption is active, the d ata will stay
encrypted and the system will not boot into the operating system. It is recommended to dis­able f TPM before updating the BIOS. Otherwise an unpre dictable failure may occur.

To use the USB BIOS Flashback func tion, Please fol low the steps below.

1. Download the latest BIOS le from ASRock 's website : http://www.asrock.com.

2. Copy t he BIOS le to your USB a sh drive. Please make sure the le system of

your USB ash drive must be FAT32.

3. Extract BIOS le from the zip  le.

4. Rename the le to “creative.rom” and save it to t he root directory of X: USB ash drive.

5. Plug the 24 pin power con nector to the mot herboard. en turn on the power supply's AC
switch.
*ere is no need to power on t he system.

6. en plug your USB drive to the USB BIOS Flashback por t.

7. Press the BIOS Flashback Switch for about three seconds. en the LED starts to blink.

8. Wait unti l the LED stops blinking, indicating that BIOS ashing has been completed.
*If the LED light turns solid green, this means that the BIOS Flashback is not
operating properly. Please ma ke sure that you plug t he USB drive to the USB BIOS Flashback
port.
**If the LED does not light up at a ll then please disconnect power from the system and remove/
disconnect t he CMOS battery from the motherboard for several minutes. Reconnect power
and battery and try agai n.

50

B650M PG Riptide

DRAM

VGA

CPU

BOOT

2.14 Post Status Checker

Post Status Checker (PSC) diagnoses the computer when users power on the

machine. It emits a red light to indicate whether the CPU, memory, VGA or

storage is dysfunctional. e lights go o if the four mentioned above are function-

ing normally.

RIPTIDE

B65 0M PG

Tutorial Video

51

2.15 M.2 SSD Module Installation Guide (M2_1)

2

e M.2 is a small size and versatile card edge connector that aims to replace mPCIe and

mSATA. e Blazing M.2 Socket (M2 _1, Key M) supports type 2260/2280 PCIe Gen5x4 (128

Gb/s) mode.

Installing the M.2 SSD Module

Step 1

Prepare a M.2 SSD module.

1

AB

No. 1 2

Nut Location A B

PCB Length 6cm 8cm

Module Type Type 2 260 Ty p e 2 2 8 0

Step 2

Depending on the PCB type and

length of your M.2 SSD module, nd

the corresponding nut location to be

used.

52

Step 3

B650M PG Riptide

2

Before installing a M.2 SSD

1

module, please loosen the screws to

remove the M.2 heatsink.

1

*Please remove the protective lms

on the bottom side of the M.2

heatsink before you install a M.2

SSD module.

Step 4

Peel o the yellow protective lm on

the nut A. Prepare the M.2 stando

that comes with the package, and

B

A

hand tighten it into the nut A. Skip

Step 4 if your M.2 SSD module is

Type 228 0 .

Step 5

Align and gently insert the M.2 SSD

module into the M.2 slot. Please

be aware that the M.2 SSD module

only ts in one orientation.

AB

AB

o

20

53

NUT1NUT2B

Correct Installation:

e SSD's PCB is in proper place, and

the M.2 heatsink can be screwed in.

Step 6

Tighten the screw with a screwdriver

to secure the module into place.

Please do not overtighten the screw

as this might damage the module.

Skip Step 6 if your M.2 SSD module is

Type 228 0 .

Step 7

Before securing the M.2 heatsink,

make sure to align the notch on

the SSD to the stando on the

motherboard if you use a Type 2280

SSD module; otherwise, the SSD

module may be damaged.

54

Incorrect Installation:

e SSD's PCB sits between M.2 heatsink

and stando. Do not continue.

Step 8

B650M PG Riptide

1

2

For the latest updates of M.2 SSD module support list, please visit our website for details:

http://www.asrock.com

Tighten the screws with a screwdriver

3

to secure the module (if your M.2

SSD module is Type 2280) and M.2

heatsink into place in the order

shown. Tighten screw opposite the

M.2 connector rst (2), and then

tighten the one next to the M.2

connector (3).

*Please do not overtighten the screw

as this might damage the module and

M.2 heatsink.

55

2.16 M.2 SSD Module Installation Guide (M2_2)

2

e M.2 is a small size and versatile card edge connector that aims to replace mPCIe and

mSATA. e Hyper M.2 Socket (M2_ 2, Key M), supports type 2260/2280 PCIe Gen4x4 (64

Gb/s) mode.

Installing the M.2 SSD Module

Step 1

Prepare a M.2 SSD module and the

screw.

1

AB

No. 1 2

Nut Location A B

PCB Length 6cm 8cm

Module Type Type 2 260 Ty p e 2 2 8 0

Step 2

Depending on the PCB type and

length of your M.2 SSD module, nd

the corresponding nut location to be

used.

56

B650M PG Riptide

Step 3

Move the stando based on the

module type and length.

B

B

A

A

AB

e stando is placed at the nut

location B by default. Skip Step 3 and

4 and go straight to Step 5 if you are

going to use the default nut.

Otherwise, release the stando by

hand.

Step 4

Peel o the yellow protective lm on

the nut to be used. Hand tighten the

stando into the desired nut location

on the motherboard.

Step 5

Align and gently insert the M.2 SSD

module into the M.2 slot. Please

be aware that the M.2 SSD module

only ts in one orientation.

AB

o

20

Step 6

Tighten the screw with a screwdriver

to secure the module into place.

NUT1NUT2B

Please do not overtighten the screw

as this might damage the module.

For the latest updates of M.2 SSD module support list, please visit our website for details:

http://www.asrock.com

57

Version 1.0

Published September 2022

Copyright©2022 ASRock INC. All rights reserved.

Copyright Notice:

No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Inc.

Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock. ASRock assumes no responsibility for
any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or tness for a particular
purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of prots, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from any
defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that

may cause undesired operation.

e terms HDMI® and HDMI High-Denition Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI Licensing LLC in the United States and other
countries.

WARNING

THIS PRODUCT CONTAINS A BUTTOON BATTERY
If swallowed, a button battery can cause serious injury or death.
Please keep batteries out of sight or reach of children.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate”

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for
any other reasonably foreseeable loss or damage caused by our goods. You are also entitled
to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure. If you require assistance please call ASRock Tel
: [phone] ext.123 (Standard International call charges apply)

ASRock INC. hereby declares that this device is in compliance with the essential require­ments and other relevant provisions of related UKCA Directives. Full text of UKCA decla­ration of conformity is available at: http://www.asrock.com

ASRock INC. hereby declares that this device is in compliance with the essential require­ments and other relevant provisions of related Directives. Full text of EU declaration of
conformity is available at: http://www.asrock.com

ASRock follows the green design concept to design and manufacture our products, and
makes sure that each stage of the product life cycle of ASRock product is in line with global
environmental regulations. In addition, ASRock disclose the relevant information based
on regulation requirements.

Please refer to https://www.asrock.com/general/about.asp?cat=Responsibility for informa­tion disclosure based on regulation requirements ASRock is complied with.

DO NOT throw the motherboard in municipal waste. is product has been
designed to enable proper reuse of parts and recycling. is symbol of the
crossed out wheeled bin indicates that the product (electrical and electronic
equipment) should not be placed in municipal waste. Check local regulations
for disposal of electronic products.
