ASRock AB350M Pro4 operation manual

Version 1.0

Published January 2017

Copyright©2017 ASRock INC. All rights reserved.

Copyright Notice:

No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Inc.

Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock. ASRock assumes no responsibility for
any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or tness for a particular
purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of prots, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from any
defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see ww w.dtsc.ca.gov/hazardouswaste/
perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for
any other reasonably foreseeable loss or damage caused by our goods. You are also entitled
to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure. If you require assistance please call ASRock Tel

: [phone] ext.123 (Standard International call charges apply)

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI
logo are trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 6

1.4 I/O Panel 10

Chapter 2 Installation 12

2.1 Installing the CPU 13

2.2 Installing the CPU Fan and Heatsink 15

2.3 Installing Memory Modules (DIMM) 24

2.4 Expansion Slots (PCI Express Slots) 26

2.5 Jumpers Setup 27

2.6 Onboard Headers and Connectors 28

2.7 M.2_SSD (NGFF) Module Installation Guide (M2_1) 33

2.8 M.2_SSD (NGFF) Module Installation Guide (M2_2) 36

Chapter 3 Software and Utilities Operation 39

3.1 Installing Drivers 39

3.2 ASRock Live Update & APP Shop 40

3.2.1 UI Overview 40

3.2.2 Apps 41

3.2.3 BIOS & Drivers 44

3.2.4 Setting 45

3.3 ASRock RGB LED 46

Chapter 4 UEFI SETUP UTILITY 48

4.1 Introduction 48

4.1.1 UEFI Menu Bar 48

4.1.2 Navigation Keys 49

4.2 Main Screen 50

4.3 OC Tweaker Screen 51

4.4 Advanced Screen 52

4.4.1 CPU Conguration 53

4.4.2 North Bridge Conguration 54

4.4.3 South Bridge Conguration 55

4.4.4 Storage Conguration 56

4.4.5 Super IO Conguration 57

4.4.6 ACPI Conguration 58

4.4.7 USB Conguration 59

4.4.8 Trusted Computing 60

4.5 Tools 61

4.6 Hardware Health Event Monitoring Screen 63

4.7 Security Screen 64

4.8 Boot Screen 65

4.9 Exit Screen 67

Chapter 1 Introduction

ank you for purchasing ASRock AB350M Pro4 / A320M Pro4 motherboard,

a reliable motherboard produced under ASRock ’s consistently stringent quality

control. It delivers excellent performance with robust design conforming to

ASRock’s commitment to quality and endurance.

In this manual, Chapter 1 and 2 contains the introduction of the motherboard

and step-by-step installation guides. Chapter 3 contains the operation guide of the

soware and utilities. Chapter 4 contains the conguration guide of the BIOS setup.

Becau se the motherboard specications and the BIOS soware might be updated, the
content of this manual will be subject to change without notice. In ca se any modica­tions of this manual occur, the updated version will be available on ASRock’s website
without further notice. If you require technical suppor t related to this motherboard,
please visit our website for spe cic information about the model you are using. You
may nd the l atest VGA cards and CPU support list on ASRock ’s website a s well.
ASRock website http://www.a srock .com.

1.1 Package Contents

ASRock AB350M Pro4 / A320M Pro4 Motherboard (Micro ATX Form Factor)

•

ASRock AB350M Pro4 / A320M Pro4 Quick Installation Guide

•

ASRock AB350M Pro4 / A320M Pro4 Support CD

•

1 x I/O Panel Shield

•

2 x Serial ATA (SATA) Data Cables (Optional)

•

2 x Screws for M.2 Sockets (Optional)

•

AB350M Pro4
A320M Pro4

English

1

1.2 Specications

Platform

CPU

Chipset

Memory

•

•

•

•

•

•

•

•

•

•

•

* Please refer to page 24 for DDR4 UDIMM maximum frequency

support.

•

•

Micro ATX Form Factor

Solid Capacitor design

Supports AMD Socket AM4 A-Series APUs (Bristol Ridge)

and Ryzen CPUs (Summit Ridge)

Digi Power design

9 Power Phase design

Supports 95W Air Cooling

AMD Promontory B350 (AB350M Pro4)

AMD Promontory A320 (A320M Pro4)

Dual Channel DDR4 Memory Technology

4 x DDR4 DIMM Slots

Supports DDR4 2667/2400/2133 ECC & non-ECC, un-bu-

ered memory*

Max. capacity of system memory: 64GB

15μ Gold Contact in DIMM Slots

English

2

Expansion
Slot

Graphics

1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)*

•

* Supports NVMe SSD as boot disks

* PCIE2 will downgrade to x8 mode when A-Series APU is

installed.

1 x PCI Express 2.0 x16 Slot (PCIE3: x4 mode (AB350M Pro4)

•

/ x2 mode (A320M Pro4))

1 x PCI Express 2.0 x1 Slot

•

Integrated AMD RadeonTM R7/R5 Series Graphics in A-series

•

APU

DirectX 12, Pixel Shader 5.0

•

Max. shared memory 2GB

•

ree graphics output options: D-Sub, DVI-D and HDMI

•

Supports Triple Monitor

•

Audio

Supports HDMI with max. resolution up to 4K x 2K

•

(4096x2160) @ 24Hz / (3840x2160) @ 30Hz

Supports DVI-D with ma x. resolution up to 1920x1200 @

•

60Hz

Supports D-Sub with max. resolution up to 1920x1200 @

•

60Hz

Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

•

HBR (High Bit Rate Audio) with HDMI Port (Compliant

HDMI monitor is required)

Supports HDCP with DVI-D and HDMI Ports

•

Supports Full HD 1080p Blu-ray (BD) playback with DVI-D

•

and HDMI Ports

7.1 CH HD Audio with Content Protection (Realtek ALC892

•

Audio Codec)

* To congure 7.1 CH HD Audio, it is required to use an HD

front panel audio module and enable the multi-channel audio

feature through the audio driver.

Premium Blu-ray Audio support

•

Supports Surge Protection

•

ELNA Audio Caps

•

AB350M Pro4
A320M Pro4

LAN

Rear Panel
I/O

PCIE x1 Gigabit LAN 10/100/1000 Mb/s

•

Realtek RTL8111GR

•

Supports Wake-On-LAN

•

Supports Lightning/ESD Protection

•

Supports LAN Cable Detection

•

Supports Energy Ecient Ethernet 802.3az

•

Supports PXE

•

1 x PS/2 Mouse Port

•

1 x PS/2 Keyboard Port

•

1 x D-Sub Port

•

1 x DVI-D Port

•

1 x HDMI Port

•

2 x USB 2.0 Ports (Supports ESD Protection)

•

1 x USB 3.0 Type-C Port (Supports ESD Protection)

•

English

3

English

Storage

Connector

4 x USB 3.0 Ports (Supports ESD Protection)

•

1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

•

LED)

HD Audio Jacks: Line in / Front Speaker / Microphone

•

4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,

•

RAID 1 and RAID 10), NCQ, AHCI and Hot Plug*

* M2_ 2 and SATA3_4 share lanes. If either one of them is in use,

the other one will be disabled.

1 x Ultra M.2 Socket (M2_1), supports ty pe 2242/2260/2280

•

M.2 PCI Express module up to Gen3 x4 (32 Gb/s) (with Ryzen

CPU) or Gen3 x2 (16 Gb/s) (with A-Series APU)**

1 x M.2 Socket (M2_2), supports type 2230/2242/2260/2280

•

M.2 SATA3 6.0 Gb/s module**

** Supports NVMe SSD as boot disks

** Supports ASRock U.2 Kit

1 x COM Port Header

•

1 x TPM Header

•

1 x Power LED and Speaker Header

•

1 x RGB LED Header

•

* Supports up to 12V/3A, 36W LED Strip

1 x AMD Fan LED Header

•

1 x CPU Fan Connector (4-pin)

•

* e CPU Fan Connector supports the CPU fan of ma ximum

1A (12W) fan power.

2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin) (Smart Fan

•

Speed Control)

* CHA_FAN1 can auto detect if 3-pin or 4-pin fan is in use.

1 x 24 pin ATX Power Connector

•

1 x 8 pin 12V Power Connector

•

1 x Front Panel Audio Connector

•

1 x AMD LED Fan USB Header (for AB350M Pro4 only)

•

2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD

•

Protection)

1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Supports ESD

•

Protection)

4

BIOS
Feature

Hardware
Monitor

OS

Certica­tions

AB350M Pro4
A320M Pro4

AMI UEFI Legal BIOS with multilingual GUI support

•

Supports “Plug and Play”

•

ACPI 5.1 compliance wake up events

•

Supports jumperfree

•

SMBIOS 2.3 support

•

DRAM Voltage multi-adjustment

•

CPU/Chassis temperature sensing

•

CPU/Chassis Fan Tachometer

•

CPU/Chassis Quiet Fan

•

CPU/Chassis Fan multi-speed control

•

Voltage monitoring: +12V, +5V, +3.3V, Vcore

•

Microso® Windows® 10 64-bit

•

* For the updated Windows® 10 driver, please visit ASRock’s web-

site for details: http://www.asrock.com

FCC, CE, WHQL

•

ErP/EuP ready (ErP/EuP ready power supply is required)

•

* For detailed product information, please visit our website: http://ww w.asrock.com

Please realize that the re is a certain r isk involved with overclo cking, including adju st­ing the setting in the BIOS, applying Untied Ove rclocking Technology, or using third­party o verclocking tools. Overclocking may aect your system’s stability, or even c ause
damage to the components and dev ices of your system. It should be done at your own
risk and expense. We are not responsible for possible damage cau sed by overclocking.

English

5

1.3 Motherboard Layout

ATXP WR 1

Sup er

I/O

CLRCMOS1

1

PCI E2

1

USB_2_3

HD_AUDI O1

1

CPU_FAN1

Top:

LINE IN

Center :

FRONT

Bottom :

MIC IN

RJ- 45 L AN

USB 2 .0
T: USB1
B: US B2

SOCKE T AM 4

Fro nt U SB 3. 0

1

COM1

CMO S

Bat tery

ATX12V1

USB 3.0

USB31_T C_1

M2_1

Ult ra M .2

PCIe G en3 x4

USB3_3 _4

1

CHA_FAN1

CHA_FAN2

HDLED RESET

PLED PWRBTN

PANEL1

1

RoH S

SPK_PLED 1

1

PCI E xp res s 3.0

DDR4 _A1 (64 bit, 288 -pin mod ule)

DDR4 _A2 (64 bit, 288 -pin mod ule )

DDR4 _B1 (64 bit, 288 -pin mod ule )

DDR4 _B2 (64 bit, 288 -pin mod ule )

PCI E1

PCI E3

M2_2

M2_2_CT 2M2_2_CT 3M 2_2_CT4 M2_2_CT1

AMD

Pro m ont ory

B35 0

PS2

Keybo ard

PS2

Mouse

USB 3 .0
T: USB2
B: US B3

USB 3 .0
T: USB4
B: US B5

RGB_HEADE R11AMD_FAN_LE D1

1

USB_5

1

M2_1_CT 3M2_1_CT 2M 2_1_CT1

1

USB_2_4

TPMS1

1

SATA3_3

SATA3_4

SATA3_1

SATA3_2

AB35 0M Pro4

HDMI 1

DVI1

VGA1

AB350M Pro4:

BIOS
ROM

English

6

No. Description

1 ATX 12V Power Connector (ATX12V1)

2 CPU Fan Connector (CPU_FAN1)

3 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)

4 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)

5 RGB LED Header (RGB_HEADER1)

6 AMD Fan LED Header (AMD_FAN_LED1)

7 ATX Power Connector (ATXPWR1)

8 USB 3.0 Header (USB3_3_4)

9 AMD LED Fan USB Header (USB_5)

10 SATA3 Connector (SATA3_3)

11 SATA3 Connector (SATA3_4)

12 SATA3 Connector (SATA3_2)

13 SATA3 Connector (SATA3_1)

14 System Panel Header (PANEL1)

15 Power LED and Speaker Header (SPK_PLED1)

16 Chassis Fan Connector (CHA_FAN2)

17 USB 2.0 Header (USB_2 _3)

18 USB 2.0 Header (USB_2 _4)

19 Clear CMOS Jumper (CLRCMOS1)

20 COM Port Header (COM1)

21 TPM Header (TPMS1)

22 Front Panel Audio Header (HD_ AUDIO1)

23 Chassis Fan Connector (CHA _FAN1)

AB350M Pro4
A320M Pro4

English

7

A320M Pro4:

ATXP WR 1

Sup er

I/O

CLRCMOS1

1

PCI E2

1

USB_2_3

HD_AUDI O1

1

CPU_FAN1

Top:

LINE IN

Center :

FRONT

Bottom :

MIC IN

RJ- 45 L AN

USB 2 .0
T: USB1
B: US B2

SOCKE T AM 4

Fro nt U SB 3. 0

1

COM1

CMO S

Bat tery

ATX12V1

USB 3.0

USB31_T C_1

M2_1

Ult ra M .2

PCIe G en3 x4

USB3_3 _4

1

CHA_FAN1

CHA_FAN2

HDLED RESET

PLED PWRBTN

PANEL1

1

RoH S

SPK_PLED 1

1

PCI E xp res s 3.0

DDR4 _A1 (64 bit, 288 -pin mod ule)

DDR4 _A2 (64 bit, 288 -pin mod ule )

DDR4 _B1 (64 bit, 288 -pin mod ule )

DDR4 _B2 (64 bit, 288 -pin mod ule )

PCI E1

PCI E3

M2_2

M2_2_CT 2M2_2_CT 3M 2_2_CT4 M2_2_CT1

AMD

Pro m ont ory

A32 0

PS2

Keybo ard

PS2

Mouse

USB 3 .0
T: USB2
B: US B3

USB 3 .0
T: USB4
B: US B5

RGB_HEADE R11AMD_FAN_LE D1

1

M2_1_CT 3M2_1_CT 2M 2_1_CT1

1

USB_2_4

TPMS1

1

SATA3_3

SATA3_4

SATA3_1

SATA3_2

20

19

21

22

A320 M Pro 4

HDMI 1

DVI1

VGA1

1

5

3

2

4

6

7

English

8

BIOS
ROM

8

9

10

11

12

17

18

14

15

16

13

No. Description

1 ATX 12V Power Connector (ATX12V1)

2 CPU Fan Connector (CPU_FAN1)

3 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)

4 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)

5 RGB LED Header (RGB_HEADER1)

6 AMD Fan LED Header (AMD_FAN_LED1)

7 ATX Power Connector (ATXPWR1)

8 USB 3.0 Header (USB3_3_4)

9 SATA3 Connector (SATA3_3)

10 SATA3 Connector (SATA3_4)

11 SATA3 Connector (SATA3_2)

12 SATA3 Connector (SATA3_1)

13 System Panel Header (PANEL1)

14 Power LED and Speaker Header (SPK_PLED1)

15 Chassis Fan Connector (CHA_FAN2)

16 USB 2.0 Header (USB_2 _3)

17 USB 2.0 Header (USB_2 _4)

18 Clear CMOS Jumper (CLRCMOS1)

19 COM Port Header (COM1)

20 TPM Header (TPMS1)

21 Front Panel Audio Header (HD_AUDIO1)

22 Chassis Fan Connector (CHA _FAN1)

AB350M Pro4
A320M Pro4

English

9

1.4 I/O Panel

1

4

2

3

5

English

11

10

8 7913 12

No. Description No. Description

1 PS/2 Mouse Port 8 USB 3.0 Ports (USB3_23)

2 DVI-D Port 9 USB 3.0 Type-C Port (USB31_TC_1)

3 LAN RJ-45 Port* 10 HDMI Port

4 Line In (Light Blue)** 11 D-Sub Port

5 Front Speaker (Lime)** 12 USB 2.0 Ports (USB_1_2)

6 Microphone (Pink)** 13 PS/2 Keyboard Port

7 USB 3.0 Ports (USB3_45)

* ere are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications .

ACT/LINK L ED

SPEED LE D

LAN Por t

Activity / Link LED Speed LED

Status Description Status Description

O No Link O 10Mbps connection
Blinking Data Activity Orange 100Mbps connection
On Link Green 1Gbps connection

6

10

** To congure 7.1 CH HD Audio, it i s required to use an HD front panel audio module and enable the multi­channel audio feature through the audio driver.

Please set Speaker Conguration to “7.1 Speaker”in the Realtek HD Audio Manager.

AB350M Pro4
A320M Pro4

Function of the Audio Por ts in 7.1-channel Con guration:

Port Function

Light Blue (Rear panel) Rear Speaker Out
Lime (Rear panel) Front Speaker Out
Pink (Rear panel) Central /Subwoofer Speaker Out
Lime (Front panel) Side Speaker Out

English

11

Chapter 2 Installation

is is a Micro ATX form factor motherboard. Before you install the motherboard,

study the conguration of your chassis to ensure that the motherboard ts into it.

Pre-installation Precautions

Take note of the following precautions before you install motherboard components

or change any motherboard settings.

Make sure to unplug the power cord before installing or removing the motherboard.

•

Failure to do so may cause physical injuries to you and damages to motherboard

components.

In order to avoid damage from static electricity to the motherboard’s components,

•

NEVER place your motherboard directly on a carpet. Also remember to use a grounded

wrist strap or touch a safety grounded object before you handle the components.

Hold components by the edges and do not touch the ICs.

•

Whenever you uninstall any components, place them on a grounded anti-static pad or

•

in the bag that comes with the components.

When placing screws to secure the motherboard to the chassis, please do not over-

•

tighten the screws! Doing so may damage the motherboard.

English

12

2.1 Installing the CPU

Unplug all power cables be fore installing the CPU.

1

AB350M Pro4
A320M Pro4

2

English

13

3

English

14

2.2 Installing the CPU Fan and Heatsink

Aer you install the CPU into this motherboard, it is necessary to install a larger

heatsink and cooling fan to dissipate heat. You also need to spray thermal grease

between the CPU and the heatsink to improve heat dissipation. Ma ke sure that the

CPU and the heatsink are securely fastened and in good contact with each other.

Please turn o the power or remove the power cord before changing a CPU or heatsink.

Installing the CPU Box Cooler SR1

1

AB350M Pro4
A320M Pro4

2

English

15

3

English

16

4

1

N

FA

_

U

P

C

Installing the AM4 Box Cooler SR2

1

AB350M Pro4
A320M Pro4

2

English

17

3

English

18

AB350M Pro4
A320M Pro4

4

1

N

FA

_

U

P

C

5

4-pin FAN cable

RGB LED Cable

1

FAN

CPU_

1

D

LE

_

N

FA

_

D

AM

+12V

*e diagram shown here are for reference only. Please refer to page 32 for the orientation of

AMD Fan LED Header (AMD_FAN_LED1).

English

19

Installing the AM4 Box Cooler SR3

1

English

20

2

AB350M Pro4
A320M Pro4

3

4

21

English

5

CPU_FAN1

English

22

AB350M Pro4
A320M Pro4

6

1

N

FA

_

U

P

C

1

D

E

L

_

N

FA

_

D

AM

+12V

or

7

1

N

FA

_

U

P

C

1

D

E

L

_

N

FA

_

D

AM

5

_

B

S

U

Please note that only one cable should be used at a time in this step.

If you select AMD_FAN_LED1, please install ASRock utility "ASRock RGB LED".

If you select USB connector, please install AMD utility "SR3 Settings So ware".

*e diagram shown here are for reference only. Please refer to page 32 for the orientation of AMD Fan

LED Header (AMD_FAN_LED1) and page 29 for the orientation of AMD LED Fan USB Header (USB_5).

23

English

2.3 Installing Memory Modules (DIMM)

is motherboard provides four 288-pin DDR4 (Double Data Rate 4) DIMM slots,

and supports Dual Channel Memory Technology.

1. For dual channel conguration, you always need to install identical (the same

brand, speed , size and chip-type) DDR4 DIMM pairs.

2. It is unable to activate Dual Channel Memor y Technology with only one or three
memor y module installed.

3. It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4
slot; otherwise, this motherboard and DIMM may be damaged.

DDR4 UDIMM Maximum Frequency Support

A-Series APUs:

UDIMM Memory Slot

A1 A2 B1 B2

- SR - - 2400

- DR - - 2400

- SR - SR 2400

- DR - DR 2133

SR SR SR SR 1866

SR/DR DR SR/DR DR 1866

Frequency

(Mhz)

English

24

Ryzen CPUs:

UDIMM Memory Slot

A1 A2 B1 B2

- SR - - 2667

- DR - - 2667

- SR - SR 2667

- DR - DR 2400-2667

SR SR SR SR 2133-2400

SR/DR DR SR/DR DR 1866-2133

SR: Single rank DIMM, 1Rx4 or 1R x8 on DIMM module label

DR: Dua l ran k DIMM, 2Rx4 or 2R x8 on DIMM module label

Frequency

(Mhz)

AB350M Pro4
A320M Pro4

e DIMM only ts in one correct orientation. It will cause permanent dam age to
the mothe rboard and the DIMM if you force the DIMM into the slot at incor rect
orientation .

1

2

3

English

25

2.4 Expansion Slots (PCI Express Slots)

ere are 3 PCI Express slots on the motherboard.

Before installing an ex pansion card, please make sure that the power supply is
switched o or the power cord is unplugged. Plea se read the documentation of the
expan sion card and mak e necessary hardware settings for the card before you start
the installation.

PCIe slots:

PCIE1 (PCIe 2.0 x1 slot) is used for PCI Express x1 lane width cards.

PCIE2 (PCIe 3.0 x16 slot) is used for PCI Express x16 lane width graphics cards.*

PCIE3 (PCIe 2.0 x16 slot) is used for PCI Express x4 (AB350M Pro4) / x2 (A320M

Pro4) lane width graphics cards.

* PCIE2 will downgrade to x8 mode when A-Series APU is installed.

English

26

2.5 Jumpers Setup

e illustration shows how jumpers are setup. When the jumper cap is placed on

the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper

is “Open”. e illustration shows a 3-pin jumper whose pin1 and pin2 are “Short”

when a jumper cap is placed on these 2 pins.

Clear CMOS Jumper

(CLRMOS1)

(see p.6, No. 19 or p.8, No.

18)

CLRMOS1 allows you to clear the data in CMOS. To clear and reset the system

parameters to default setup, please turn o the computer and unplug the power

cord from the power supply. Aer waiting for 15 seconds, use a jumper cap to

short pin2 and pin3 on CLRMOS1 for 5 seconds. However, please do not clear the

CMOS right aer you update the BIOS. If you need to clear the CMOS when you

just nish updating the BIOS, you must boot up the system rst, and then shut it

down before you do the clear-CMOS action. Please be noted that the password,

date, time, and user default prole will be cleared only if the CMOS battery is

removed.

Clear CMOSDefault

AB350M Pro4
A320M Pro4

If you clear the CMOS, the case open may be detec ted. Please adjust the BIOS option
“Clear Status” to clear the record of previou s chassis intrusion status.

English

27

2.6 Onboard Headers and Connectors

Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over
these header s and connectors. Placing jumper caps over the headers and connectors
will cause permanent damage to the motherboard.

System Panel Header

(9-pin PANEL1)

(see p.6, No. 14 or p.8, No.

13)

PWRBTN (Power Switch):

Connec t to the power switch on the chassi s front panel. You may congure the way to
turn o your system using the power switch.

RESET (Reset Switch):

Connec t to the reset switch on the chassi s front panel. P ress the reset sw itch to restart
the computer if the compute r freezes and fails to perform a normal restart.

PLED (Syste m Power LED):

Connec t to the power status indicator on the chassis front panel. e LED i s on when
the system is ope rating. e LED keeps blinking when the system i s in S3 sleep state.
e LED is o when the system i s in S4 sle ep state or powered o (S5).

HDLED (Ha rd Drive Activity LED):

Connec t to the hard drive ac tivity LED on the chassis front panel. e LED is on when
the hard dr ive is reading or w riting data.

e front panel de sign may dier by chassis. A front pane l module mainly consists
of power switch , reset switch, power LED, hard dr ive activity LED, speak er and etc.
When connecting your chassis front panel module to this head er, make sure the wire
assig nments and the pin assig nments are matched correctly.

1

PLE D+

PLE D-

HDL ED-

HDL ED+

PWR BTN #

GND

RES ET#

GND

GND

Connect the power

switch, reset switch and

system status indicator on

the chassis to this header

according to the pin

assignments below. Note

the positive and negative

pins before connecting

the cables.

English

28

AB350M Pro4

PLE D-

SPE AK ER

A320M Pro4

Power LED and Speaker

Header

(7-pin SPK_PLED1)

(see p.6, No. 15 or p.8, No.

14)

Serial ATA3 Connectors

(SATA3_1:

see p.6, No. 13 or p.8, No.

12)

(SATA3_2:

see p.6, No. 12 or p.8, No.

11)

(SATA3_3:

see p.6, No. 10 or p.8, No.

9)

(SATA3_4:

see p.6, No. 11 or p.8, No.

10)

AMD LED Fan USB

Header

(4-pin USB_5)

(see p.6, No. 9)

DUM MY
+5V

1

PLE D+

SATA3_3

SATA3_1

DUM MY

PLE D+

Please connect the

chassis power LED and

the chassis speaker to this

header.

ese four SATA3

connectors support SATA

SATA3_4

data cables for internal

storage devices with up to

6.0 Gb/s data transfer rate.

SATA3_2

* M2_ 2 and SATA3_4

share lanes. If either one

of them is in use, the other

one will be disabled.

is header is used for

connecting the USB

connector on the AMD

SR3 Heatsink.

USB 2.0 Headers

(9-pin USB_2_3)

(see p.6, No. 17 or p.8, No.

16)

(9-pin USB_2_4)

(see p.6, No. 18 or p.8, No.

17)

USB _PW R

1

USB _PW R

P-

P+

GND

DUM MY

GND

P+

P-

ere are two headers

on this motherboard.

Each USB 2.0 header can

support two ports.

English

29

GND

FAN_V OLTAGE

FAN_S PEE D

USB 3.0 Header

(19-pin USB3_3_4)

(see p.6 or 8, No. 8)

Vbus

IntA _PA_S SRX-

IntA _PA_S SRX+

IntA _PA_S STX-

IntA _PA_S STX+

IntA _PA_D -

IntA _PA_D +

VbusVbus

IntA _PB_ SSRX -

IntA _PB_ SSRX +

GND

IntA _PB_ SSTX -

GND

IntA _PB_ SSTX +

GND

IntA _PB_ D-

GND

IntA _PB_ D+

Dumm y

1

ere is one header on

this motherboard. Each

USB 3.0 header can

support two ports.

English

Front Panel Audio Header

(9-pin HD_AUDIO1)

(see p.6, No. 22 or p.8, No.

21)

1. High Denition Audio supports Jack Sen sing, but the panel wire on the chas sis mu st
suppor t HDA to function correctly. Please follow the instructions in our manual and
chassis manual to install your syste m.

2. If you use an AC’97 audio panel , please install it to the front panel audio header by
the steps below:
A. Connect Mic_IN (MIC) to MIC2_ L.
B. Conne ct Audio_R (RIN) to OUT2_R and Audio_ L (LIN) to OUT2_ L.
C. Connect Ground (GND) to Ground (GND).
D. MIC_ RET and OUT_RET are for the HD audio panel only. You don’t need to
connec t them for the AC’97 audio panel.
E. To activate the front mic, go to the “FrontMic” Tab in the Realtek Control panel
and adju st “Recording Volume”.

Chassis Fan Connectors

(4-pin CHA_FAN1)

(see p.6, No. 23 or p.8, No.

22)

(3-pin CHA_FAN2)

(see p.6, No. 16 or p.8, No.

15)

GND

PRE SEN CE#

MIC _RE T

1

FAN _S PEE D_ CON TR OL

CHA _F AN_ SP EED

OUT 2_L

J_S ENS E

OUT 2_R

MIC 2_R

MIC 2_L

FAN _V OLT AG E

GND

OUT _RE T

is header is for

connecting audio devices

to the front audio panel.

Please connect fan cables

to the fan connectors and

match the black wire to

the ground pin.

30

AB350M Pro4

5

1

8

GND

FAN_ VOLTAG E_C ONT ROL

FAN_ SPE ED

FAN_ SPE ED_C ONT ROL

A320M Pro4

CPU Fan Connector

(4-pin CPU_FAN1)

(see p.6 or 8, No. 2)

ATX Power Connector

(24-pin ATXPWR1)

(see p.6 or 8, No. 7)

ATX 12V Power

Connector

(8-pin ATX12V1)

(see p.6 or 8, No. 1)

Serial Port Header

(9-pin COM1)

(see p.6, No. 20 or p.8, No.

19)

1

12

1

RRX D1

DDC D#1

DDT R#1

TTX D1

24

13

DDS R#1

CCT S#1

RRTS #1

GND

is motherboard pro-

vides a 4-Pin CPU fan

(Quiet Fan) connector.

If you plan to connect a

3-Pin CPU fan, please

connect it to Pin 1-3.

is motherboard pro-

vides a 24-pin ATX power

connector. To use a 20-pin

ATX power supply, please

plug it along Pin 1 and Pin

13.

is motherboard

provides a 8-pin ATX 12V

power connector. To use a

4-pin ATX power supply,

please plug it along Pin 1

and Pin 5.

is COM1 header

supports a serial port

module.

RRI #1

TPM Header

(17-pin TPMS1)

(see p.6, No. 21 or p.8, No.

20)

is connector supports

GN D

LAD 0

LAD 3

+3 V

+3V S B

PC IRS T #

Trusted Platform Module

PC ICL K

FRA M E

(TPM) system, which can

1

securely store keys, digital

D

GN

GN D

SER IRQ #

S_P WRD WN #

GN D

LAD 1

LAD 2

SMB _DA TA_ MAI N

certicates, passwords,

and data. A TPM system

also helps enhance

SMB _CL K_M AIN

network securit y, protects

digital identities, and

ensures platform integrity.

English

31

RGB LED Header

(4-pin RGB_HEADER1)

(see p.6 or 8, No. 5)

1

12V G R B

RGB LED header is used to con-

nect RGB LED extension cable

which allows users to choose

from various LED lighting ef-

fects.

Caution: Never install the RGB

LED cable in the wrong orienta-

tion; otherwise, the cable may

be damaged.

*Please refer to page 46 for for

further instructions on these two

headers.

English

AMD FAN LED Header

(4-pin AMD_FAN_

LED1)

(see p.6 or 8, No. 6)

1

12V G R B

AMD FAN LED Header is used

to connect RGB LED

extension cable that comes with

AMD heatsink. e cable

connection allows users to choose

from various LED lighting

eects.

Caution: Never install the FAN

LED cable in the wrong orienta-

tion; otherwise, the cable may

be damaged.

32

AB350M Pro4
A320M Pro4

2.7 M.2_SSD (NGFF) Module Installation Guide (M2_1)

The M.2, also known as the Next Generat ion Form Factor (NGFF), is a small size and

versatile card edge connector that aims to replace mPCIe and mSATA. The Ultra M.2

Socket (M2_1) supports type 2242/2260/2280 M.2 PCI Express module up to Gen3 x4 (32

Gb/s) (with Ryzen CPU) or Gen3 x2 (16 Gb/s) (with A-Series APU).

Installing the M.2_SSD (NGFF) Module

Step 1

Prepare a M.2_SSD (NGFF) module

and the screw.

3

2

Step 2

Depending on the PCB type and

length of your M.2_SSD (NGFF)

module, nd the corresponding nut

location to be used.

1

ABC

No. 1 2 3

Nut Location A B C

PCB Length 4.2cm 6cm 8cm

Module Type Type 2242 Type2260 Type 2280

33

English

Step 3

Move the stando based on the

module type and length.

ABC

e stando is placed at the nut

location C by default. Skip Step 3

and 4 and go straight to Step 5 if you

are going to use the default nut.

Otherwise, release the stando by

hand.

Step 4

Peel o the yellow protective lm on

ABC

the nut to be used. Hand tighten the

stando into the desired nut location

on the motherboard.

Step 5

Align and gently insert the M.2

(NGFF) SSD module into the M.2

ABC

slot. Please be aware that the M.2

(NGFF) SSD module only ts in one

orientation.

English

34

A

BC

AB350M Pro4
A320M Pro4

Step 6

Tighten the screw with a screwdriver

to secure the module into place.

NUT1NUT2

Please do not overtighten the screw

as this might damage the module.

M.2_SSD (NGFF) Module Support List

Vendor Interface P/N

Intel PCIe INTEL 6000P-SSDPEKKF256G7 (nvme)
Intel PCIe INTEL 6000P-SSDPEKKF512G7 (nvme)
Intel PCIe INTEL 600P-SSDPEKKW256G7-256GB (nvme)
Kingston PCIe Kingston SHPM2280P2 / 240G (Gen2 x4)
SanDisk PCIe SanDisk-SD6PP4M-128G(Gen2 x2)
Samsung PCIe Samsung XP941-MZHPU512HCGL(Gen2x4)

For the latest updates of M.2_SSD (NFGG) module support list, please visit our website for

details: http://www.asrock.com

35

English

2.8 M.2_SSD (NGFF) Module Installation Guide (M2_2)

5

The M.2, also known as the Next Generat ion Form Factor (NGFF), is a small size and

versatile card edge connector that aims to replace mPCIe and mSATA. e M.2 Socket

(M2_2) supports type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module.

* M2_2 and SATA3_4 share lanes. If either one of them is in use, the other one will be

disabled.

Installing the M.2_SSD (NGFF) Module

Step 1

Prepare a M.2_SSD (NGFF) module

and the screw.

English

4

3

Step 2

Depending on the PCB type and

length of your M.2_SSD (NGFF)

module, nd the corresponding nut

2

1

A

BCD

location to be used.

No. 1 2 3 4

Nut Location A B C D

PCB Length 3cm 4.2cm 6cm 8cm

Module Type Type2230 Type 2242 Ty pe2260 Type 2280

36

AB350M Pro4
A320M Pro4

Step 3

Move the stando based on the

module type and length.

e stando is placed at the nut

A

BCD

A

BCD

ABC

location D by default. Skip Step 3

and 4 and go straight to Step 5 if you

are going to use the default nut.

Otherwise, release the stando by

hand.

Step 4

Peel o the yellow protective lm on

the nut to be used. Hand tighten the

stando into the desired nut location

on the motherboard.

Step 5

Align and gently insert the M.2

(NGFF) SSD module into the M.2

slot. Please be aware that the M.2

(NGFF) SSD module only ts in one

orientation.

A

BC

English

37

Step 6

Tighten the screw with a screwdriver

to secure the module into place.

NUT1NUT2

Please do not overtighten the screw

as this might damage the module.

M.2_SSD (NGFF) Module Support List

Vendor Interface P/N

ADATA SATA ADATA - AXNS381E-128GM-B
Crucial SATA Crucial-CT240M500SSD4-240GB
EZLINK SATA EZLINK P51B-80-120GB
Intel SATA INTEL 540S-SSDSCKKW240H6-240GB
Kingston SATA Kingston-RBU-SNS8400S3 / 180GD
Kingston SATA Kingston SM2280S3G2/120G - Win8.1
LITEON SATA LITEON LJH-256V2G-256GB (2260)
PLEXTOR SATA PLEXTOR PX-128M7VG-128GB
PLEXTOR SATA PLEXTOR PX-128M6G-2260-128GB
SanDisk SATA SanDisk-SD6SN1M-128G
SanDisk SATA SanDisk X400-SD8SN8U-128G
SanDisk SATA Sandisk Z400s-SD8SNAT-128G-1122
Transcend SATA Transcend TS256GMTS800-256GB
Transcend SATA Transcend TS64GMTS400-64GB
V-Color SATA V-Color 120G
V-Color SATA V-Color 240G
WD SATA WD BLUE WDS100T1B0B-00AS40
WD SATA WD GREEN WDS240G1G0B-00RC30

English

38

For the latest updates of M.2_SSD (NFGG) module support list, please visit our website for

details: http://www.asrock.com

Chapter 3 Software and Utilities Operation

3.1 Installing Drivers

e Support CD that comes with the motherboard contains necessary drivers and

useful utilities that enhance the motherboard’s features.

Running The Support CD

To begin using the support CD, insert the CD into your CD-ROM drive. e CD

automatically displays the Main Menu if “AUTORUN” is enabled in your computer.

If the Main Menu does not appear automatically, locate and double click on the le

“ASRSETUP.EXE” in the Support CD to display the menu.

Drivers Menu

e drivers compatible to your system will be auto-detected and listed on the

support CD driver page. Please click Instal l All or follow the order from top to

bottom to install those required drivers. erefore, the drivers you install can work

properly.

Utilities Menu

e Utilities Menu shows the application soware that the motherboard supports.

Click on a specic item then follow the installation wizard to insta ll it.

AB350M Pro4
A320M Pro4

To improve Windows 7 compatibility, please download and install the following hot
x provided by Microso.
“KB2720599”: http://support.microso.com/ kb/2720599/en-us

English

39

3.2 ASRock Live Update & APP Shop

e ASRock Live Update & APP Shop is an online store for purchasing and

downloading soware applications for your ASRock computer. You can quick ly and

easily insta ll various apps and support utilities. With ASRock Live Update & APP

Shop, you can optimize your system and keep your motherboard up to date simply

with a few clicks.

Double-click on your desktop to access ASRock Live Update & APP Shop
utility.

*You need to be connected to the Internet to download apps f rom the ASRock Live Update & APP Shop.

3.2.1 UI Overview

Category Panel

Hot News

English

40

Information Panel

Category Panel: e category panel contains several category tabs or buttons that

when selected the information panel below displays the relative information.

Information Panel: e information panel in the center displays data about the

currently selected category and allows users to perform job-related tasks.

Hot News: e hot news section displays the various latest news. Click on the image

to visit the website of the selected news and know more.

3.2.2 Apps

When the "Apps" tab is selected, you will see all the available apps on screen for you

to download.

Installing an App

Step 1

Find the app you want to install.

AB350M Pro4
A320M Pro4

e most recommended app appears on the le side of the screen. e other various

apps are shown on the right. Please scroll up and down to see more apps listed.

You can check the price of the app and whether you have already intalled it or not.

- e red icon displays the price or "Free" if the app is free of charge.

- e green "Installed" icon means the app is installed on your computer.

Step 2

Click on the app icon to see more details about the selected app.

English

41

Step 3

If you want to install the app, click on the red icon to start downloading.

Step 4

When installation completes, you can nd the green "Installed " icon appears on the

upper right corner.

English

42

To uninstall it, simply click on the trash can icon .
*e trash icon may not appear for certain apps.

Upgrading an App

You can only upgrade the apps you have already installed. When there is an

available new version for your app, you will nd the mark of "New Version"

appears below the installed app icon.

Step 1

Click on the app icon to see more details.

AB350M Pro4
A320M Pro4

Step 2

Click on the yellow icon to start upgrading.

English

43

3.2.3 BIOS & Drivers

Installing BIOS or Drivers

When the "BIOS & Drivers" tab is selected, you will see a list of recommended or

critical updates for the BIOS or drivers. Please update them all soon.

Step 1

Please check the item information before update. Click on to see more details.

Step 2

English

44

Click to select one or more items you want to update.

Step 3

Click Update to start the update process.

3.2.4 Setting

In the "Setting" page, you can change the language, select the server location, and

determine if you want to automatically run the ASRock Live Update & APP Shop

on Windows startup.

AB350M Pro4
A320M Pro4

45

English

3.3 ASRock RGB LED

ASRock RGB LED is a lighting control utility specically designed for unique individuals with

sophisticated tastes to build their own st ylish colorful lighting system. Simply by connecting the

LED strip, you can customize various lighting schemes and patterns, including Static, Breathing,

Strobe, Cycling, Music, Wave and more.

Connecting the LED Strip

Connect your RGB LED strip to the

motherboard.

RGB LED Header (RGB_HEADER1)

1

B

R

G

V

2

1

RGB_HEADER1

1

12V G R B

on the

English

46

1. Never in stall the RGB LED cable in the w rong orientation; otherwi se, the cable
may be damaged.

2. Before installing or removing your RGB LED cable, pl ease power o your system
and unplug the powe r cord from the power supply. Failure to do so m ay cause dam­ages to motherboard components.

1. Please note that the RGB LED strips do not come with the package.

2. e RGB LED header supports standard 5050 RGB LED strip (12V/G/R/B), with a
maximum power rating of 3A (12V) and length within 2 meters.

ASRock RGB LED Utility

Now you can adjust the RGB LED color through the ASRock RGB LED utility. Download

this utility from the ASRock Live Update & APP Shop and start coloring your PC style

your way!

Drag the tab to customize your

preference.

Toggle on/o the

RGB LED switch

Sync RGB LED eects

for all LED regions of

the motherboard

Select a RGB LED light eect

from the drop-down menu.

AB350M Pro4
A320M Pro4

47

English

Chapter 4 UEFI SETUP UTILITY

4.1 Introduction

is section explains how to use the UEFI SETUP UTILITY to congure your

system. You may run the UEFI SETUP UTILITY by pressing <F2> or <Del> right

aer you power on the computer, other wise, the Power-On-Self-Test (POST) will

continue with its test routines. If you wish to enter the UEFI SETUP UTILITY aer

POST, restart the system by pressing <Ctl> + <Alt> + <Delete>, or by pressing the

reset button on the system chassis. You may also restart by turning the system o

and then back on.

Becau se the UEFI soware is constantly being upd ated, the following UEFI setup
screens and de scriptions are for reference purpose only, and they may not exactly
match what you see on your scre en.

4.1.1 UEFI Menu Bar

e top of the screen has a menu bar with the following selections:

English

48

Main

OC Tweaker

Advanced

Tool

H/W Monitor

Security

Boot

Exit

For setting system time/date information

For overclocking congurations

For advanced system congurations

Useful tools

Displays current hardware status

For security settings

For conguring boot settings and boot priority

Exit the current screen or the UEFI Setup Utility

4.1.2 Navigation Keys

Use < > key or < > key to choose among the selections on the menu bar, and

use < > key or < > key to move the cursor up or down to select items, then

press <Enter> to get into the sub screen. You can also use the mouse to click your

required item.

Please check the following table for the descriptions of each navigation key.

Navigation Key(s) Description

AB350M Pro4
A320M Pro4

+ / -

<Tab>

<PGUP>

<PGDN>

<HOME>

<END>

<F1>

<F7>

<F9>

<F10>

<F12>

<ESC>

To change option for the selected items

Switch to next function

Go to the previous page

Go to the next page

Go to the top of the screen

Go to the bottom of the screen

To display the General Help Screen

Discard changes and exit the SETUP UTILITY

Load optimal default values for all the settings

Save changes and exit the SETUP UTILITY

Print screen

Jump to the Exit Screen or exit the current screen

49

English

4.2 Main Screen

When you enter the UEFI SETUP UTILITY, the Main screen will appear and

display the system overview.

AB350M Pro4:

English

50

A320M Pro4:

4.3 OC Tweaker Screen

In the OC Tweaker screen, you can set up overclocking features.

AB350M Pro4
A320M Pro4

Becau se the UEFI soware is constantly being upd ated, the following UEFI setup
screens and de scriptions are for reference purpose only, and they may not exactly
match what you see on your scre en.

Voltage Conguration

DRAM Voltage

Use this to select DRAM Voltage. e default value is [Auto].

+1.8 Voltage

Congure +1.8V voltage.

VDDP

Congure the voltage for the VDDP.

English

51

4.4 Advanced Screen

In this section, you may set the congurations for the following items: CPU

Conguration, North Bridge Conguration, South Bridge Conguration, Storage-

Conguration, Super IO Conguration, ACPI Conguration, USB Conguration

and Trusted Computing.

English

52

Setting wrong values in this sec tion may cause the system to malfunction.

UEFI Conguration

Active Page on Entry

Select the default page when entering the UEFI setup utility.

Full HD UEFI

When [Auto] is selected, the resolution will be set to 1920 x 1080 if the monitor

supports Full HD resolution. If the monitor does not support Full HD resolution,

then the resolution will be set to 1024 x 768. When [Disable] is selected, the

resolution will be set to 1024 x 768 directly.

4.4.1 CPU Conguration

Cool 'n' Quiet

Use this item to enable or disable AMD’s Cool ‘n’ QuietTM technology. e default

value is [Enabled]. Conguration options: [Enabled] and [Disabled]. If you install

Windows® OS and want to enable this function, please set this item to [Enabled].

Please note that enabling this function may reduce CPU voltage and memory

frequency, and lead to system stability or compatibility issue with some memory

modules or power supplies. Please set this item to [Disable] if above issue occurs.

AB350M Pro4
A320M Pro4

AMD fTPM Switch

Use this to enable or disable AMD CPU fTPM.

SVM Mode

When this option is set to [Enabled], a VMM (Virtual Machine Architecture) can

utilize the additional hardware capabilities provided by AMD-V. e default value is

[Enabled]. Conguration options: [Enabled] and [Disabled].

C6 Mode

Use this item to enable or disable Core C6 mode. e default value is [Enabled].

English

53

4.4.2 North Bridge Conguration

IOMMU

Use this to enable or disable IOMMU. e default value of this feature is [Disabled].

Share Memory

Congure the size of memory that is allocated to the integrated graphics processor

when the system boots up.

English

54

4.4.3 South Bridge Conguration

Onboard HD Audio

Enable/disable onboard HD audio. Set to Auto to enable onboard HD audio and

automatically disable it when a sound card is installed.

AB350M Pro4
A320M Pro4

Front Panel

Enable/disable front panel HD audio.

Deep Sleep

Congure deep sleep mode for power saving when the computer is shut down.

Restore on AC/Power Loss

Select the power state aer a power failure. If [Power O] is selected, the power will

remain o when the power recovers. If [Power On] is selected, the system will start

to boot up when the power recovers.

English

55

4.4.4 Storage Conguration

SATA Controller(s)

Enable/disable the SATA controllers.

SATA Mode

AHCI: Supports new features that improve performance.

English

56

RAID: Combine multiple disk drives into a logical unit.

4.4.5 Super IO Conguration

Serial Port

Enable or disable the Serial port.

AB350M Pro4
A320M Pro4

Serial Port Address

Select the address of the Serial port.

English

57

4.4.6 ACPI Conguration

Suspend to RAM

It is recommended to select auto for ACPI S3 power saving.

ACPI HPET Table

Enable the High Precision Event Timer for better performance and to pass WHQL

tests.

English

58

PS/2 Keyboard Power On

Allow the system to be waked up by a PS/2 Keyboard.

PCIE Devices Power On

Allow the system to be waked up by a PCIE device and enable wake on LAN.

Ring-In Power On

Allow the system to be waked up by onboard COM port modem Ring-In signals.

RTC Alarm Power On

Allow the system to be waked up by the rea l time clock alarm. Set it to By OS to let

it be handled by your operating system.

4.4.7 USB Conguration

USB Controller

Enable or disable all the USB ports.

AB350M Pro4
A320M Pro4

Legacy USB Support

Enable or disable Legacy OS Support for USB 2.0 devices. If you encounter USB

compatibility issues it is recommended to disable legacy USB support. Select UEFI

Setup Only to support USB devices under the UEFI setup and Windows/Linux

operating systems only.

USB 3.0 Controller

Enable or disable all the USB 3.0 ports.

XHCI Legacy Support

Enable or disable XHCI Controller Legacy support.

English

59

4.4.8 Trusted Computing

Security Device Support

Enable to activate Trusted Platform Module (TPM) security for your hard disk

drives.

English

60

4.5 Tools

RGB LED

ASRock RGB LED allows you to adjust the RGB LED color to your liking.

AB350M Pro4
A320M Pro4

Easy RAID Installer

Easy R AID Installer helps you to copy the R AID driver from the support CD to

your USB storage device. Aer copying the drivers please change the SATA mode to

RAID, then you can start installing the operating system in RAID mode.

English

61

Instant Flash

Save UEFI les in your USB storage device and run Instant Flash to update your

UEFI.

Internet Flash - DHCP (Auto IP), Auto

ASRock Internet Flash downloads and updates the latest UEFI rmware version

from our servers for you. Please setup network conguration before using Internet

Flash.

*For BIOS backup and recovery purpose, it is recommended to plug in your USB

pen drive before using this function.

Network Conguration

Use this to congure internet connection settings for Internet Flash.

English

62

Internet Setting

Enable or disable sound eects in the setup utility.

UEFI Download Server

Select a server to download the UEFI rmware.

4.6 Hardware Health Event Monitoring Screen

is section allows you to monitor the status of the hardware on your system,

including the parameters of the CPU temperature, motherboard temperature, fan

speed and voltage.

AB350M Pro4
A320M Pro4

CPU Fan 1 Setting

Select a fan mode for CPU Fan 1, or choose Customize to set 5 CPU temperatures

and assign a respective fan speed for each temperature.

Chassis Fan 1 Setting

Select a fan mode for Chassis Fan 1, or choose Customize to set 5 CPU temperatures

and assign a respective fan speed for each temperature.

Chassis Fan 1 Temp Source

Select a fan temperature source for Chassis Fan 1.

Over Temperature Protection

When Over Temperature Protection is enabled, the system automatically shuts

down when the motherboard is overheated.

English

63

4.7 Security Screen

In this section you may set or change the supervisor/user password for the system.

You may also clear the user password.

Supervisor Password

Set or change the password for the administrator account. Only the administrator

has authority to change the settings in the UEFI Setup Utility. Leave it blank and

press enter to remove the password.

English

64

User Password

Set or change the password for the user account. Users are unable to change the

settings in the UEFI Setup Utility. Leave it blank and press enter to remove the

password.

Secure Boot

Enable to support Secure Boot.

4.8 Boot Screen

is section displays the available devices on your system for you to congure the

boot settings and the boot priority.

Fast Boot

Fast Boot minimizes your computer's boot time. In fast mode you may not boot

from an USB storage device.

AB350M Pro4
A320M Pro4

Boot From Onboard LAN

Allow the system to be waked up by the onboard LAN.

Setup Prompt Timeout

Congure the number of seconds to wait for the setup hot key.

Bootup Num-Lock

Select whether Num Lock should be turned on or o when the system boots up.

Boot Beep

Select whether the Boot Beep should be turned on or o when the system boots up. Please

note that a buzzer is needed.

Full Screen Logo

Enable to display the boot logo or disable to show normal POST messages.

English

65

AddOn ROM Display

Enable AddOn ROM Display to see the AddOn ROM messages or congure the

AddOn ROM if you've enabled Full Screen Logo. Disable for faster boot speed.

CSM (Compatibility Support Module)

CSM

Enable to launch the Compatibility Support Module. Please do not disable unless

you’re running a WHCK test.

English

66

Launch PXE OpROM Policy

Select UEFI only to run those that support UEFI option ROM only. Select Legacy

only to run those that support legacy option ROM only. Select Do not launch to not

execute both legacy and UEFI option ROM.

Launch Storage OpROM Policy

Select UEFI only to run those that support UEFI option ROM only. Select Legacy

only to run those that support legacy option ROM only. Select Do not launch to not

execute both legacy and UEFI option ROM.

Launch Video OpROM Policy

Select UEFI only to run those that support UEFI option ROM only. Select Legacy

only to run those that support legacy option ROM only. Select Do not launch to not

execute both legacy and UEFI option ROM.

4.9 Exit Screen

Save Changes and Exit

When you select this option the following message, “Save conguration changes

and exit setup?” will pop out. Select [OK] to save changes and exit the UEFI SETUP

UTILITY.

AB350M Pro4
A320M Pro4

Discard Changes and Exit

When you select this option the following message, “Discard changes and exit

setup?” will pop out. Select [OK] to exit the UEFI SETUP UTILITY without saving

any changes.

Discard Changes

When you select this option the following message, “Discard changes?” will pop

out. Select [OK] to discard all changes.

Load UEFI Defaults

Load UEFI default values for a ll options. e F9 key can be used for this operation.

Launch EFI Shell from lesystem device

Copy shellx64.e to the root directory to launch EFI Shell.

English

67

Contact Information

If you need to contact ASRock or want to know more about ASRock, you’re welcome

to visit ASRock’s website at http://ww w.asrock.com; or you may contact your dealer

for further information. For technical questions, please submit a support request

form at http://www.asrock.com/support/tsd.asp

ASRock Incorporation

2F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,

Taipei City 112, Taiwan (R.O.C.)

ASRock EUROPE B.V.

Bijsterhuizen 11-11

6546 AR Nijmegen

e Netherlands

Phone: [phone]

Fax: [phone]

ASRock America, Inc.

13848 Magnolia Ave, Chino, CA91710

U.S.A.

Phone: [phone]

English

68

Fax: [phone]
